Smeg FD54PXNF1 User manual

NO-FROST REFRIGERATOR
Instruction Booklet
REFRIGERATEUR A FROID VENTILE
Guide D’utilisation
Manuale Di Istruzioni
NO FROST KOELKAST
Handleiding
NO-FROST KÜHLSCHRANK
Betriebsanleitung
FRIGORIFERO NO-FROST
FRIGORÍFICO SIN ESCARCHA
manual de instrucciones
FRIGORIFICO NO-FROST
Livro de Instruções
ХОЛОДИЛЬНИК NO-FROST
инструкция по эксплуатации
FD54PXNF1

UK- 1-
INDEX
BEFOREUSINGTHEAPPLIANCE.....................................................................2
Recommendations.........................................................................................................2
InstallationandSwitchingOnTheAppliance..................................................................3
BeforeSwitching On.....................................................................................................4
THEVARIOUSFUNCTIONANDPOSSIBILITIES...............................................4
ThermostatSetting........................................................................................................4
Accessories.................................................................................................................5
Making IceCubes............................................................................................................5
FastFreezing Shelf.........................................................................................................5
ChillerShelf.....................................................................................................................5
Drawer..............................................................................................................................6
WineRack........................................................................................................................6
FreshDial.........................................................................................................................6
Crisperand CrisperShelf.................................................................................................7
Removingthecrispercover..........................................................................................8
ARRANGINGFOODINTHEAPPLIANCE..........................................................9
RefrigeratorCompartment.............................................................................................9
FreezerCompartment....................................................................................................9
CLEANINGANDMAINTENANCE......................................................................10
Defrosting...................................................................................................................10
ReplacingTheRefrigeratorand FreezerLightBulb.......................................................11
TRANSPORTATIONAND CHANGINGOFINSTALLATIONPOSITION..............11
Changing ofDoorOpening Direction.............................................................................11
BEFORECALLINGYOURAFTERSALESSERVICE.........................................12
THEPARTSOFTHEAPPLIANCEANDTHECOMPARTMENTS.......................13
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

UK- 2-
PART-1. BEFOREUSINGTHEAPPLIANCE
SpecialInstructions
•Ifthemodel,which contains R600a(thecoolantisobutane),naturalgas,thatisvery
environmentalfriendlybutalsocombustible.Whentransporting and installing the
unitcaremustbe takentoensurethatnoneoftherefrigerationcircuitcomponents
becomedamaged.Inthe eventofdamage avoidnakedflamesorignitionsources
andventilatetheroominwhich theunitisplacedforafewminutes.
•Ifthisapplianceistoreplacean oldrefrigeratorwithalock;breakorremovethelock
as asafetymeasurebeforestoringit, toprotectchildrenwhileplaying mightlock
themselvesinside.
•Oldrefrigeratorsand freezerscontaininsulationgasesandrefrigerant,which must
be disposedofproperly.Please ensurethattherefrigeration tubing isnotdamaged.
IMPORTANTNOTE:
Pleasereadthisbookletbeforeinstalling andswitchingonthisappliance.Themanu-
facturerassumes no responsibilityforincorrectinstallation andusageas describedin
thisbooklet.
Recommendations
Warning: Donotusemechanicaldevicesorotherartificialmeans toacceleratethe
defrostingprocess.Donotuseelectricalappliances inthefoodstorageoftheappliance.
Keeptheappliance ventilationopenings free.Donotdamagethe refrigerator’srefriger-
antcircuit.
•Donotuseadoptersorshuntswhich couldcauseoverheatingorburning.
•Donotplug old,warped powersupplycables.
•Donottwistand bendthecables.
•Donotallowchildrentoplaywiththeappliance.Children must
NEVER sitondrawers/shelves orhangfromthedoor.
•Donotplug the powersupplywithwethands.
•Donotplace containers(glassbottlesortincontainers)ofliq-
uidsintothefreezerespeciallygassyliquidsas they couldcause
thecontainertoburstduring freezing.
•Bottles,which containahighpercentageofalcoholmustbe
sealedwellandplacedverticallyintherefrigerator.
•Donottouch the coolingsurfaces,especiallywithwethandsas
youcouldbe burntorhurt.
•Donoteatice,which havejustbeenremoved fromthe freezer.
•Ifthe supplycordisdamageditmustbereplacedbythe manu-
facturerorservice agentorappointed qualified person.
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

UK- 3-
•Theapplianceisnotintended forusebypeople(includingchildren)withreduced
physical,sensoryormentalcapabilities,orlackofexperienceandknowledge,un-
less theyhavebeengiven supervision orinstruction concerning use oftheappli-
ance byapersonresponsiblefortheirsafety.Childrenshouldbe supervisedtoen-
surethattheydon’tplaywiththeappliance.
•Ifthesupplycordisdamagedit mustbe replacedbythemanufacturerorservice
agentorappointedperson.
InstallationandSwitching OnTheAppliance
•Thisappliance isconnectingto220-240Vand 50 Hz.
•You canofferhelpfromtheservice toinstalland switchingontheappliancewithout
anycost.
•Beforemakingtheconnectiontothepowersupply,ensurethatthevoltage onthe
nameplatecorresponds tothevoltageofelectricalsysteminyourhome.
•If thesocketdoesnotmatchtherefrigeratorplug,replacethe plug withasuitable
one(atleast16 A)
•Insert the plugintoasocketwithanefficientgroundconnection.If thesockethas no
groundcontact,wesuggestyoucallanelectricianforassistance.
•Manufacturerisnotresponsibleforfailuretocompletethegroundconnection as
describedinthisbooklet.
•Donotplacetheapplianceindirectsunlight.
•Donotuseinopen airand shallnotbeexposedtothe rain.
•Placetherefrigeratorfarfromheatsourcesand inawell-venti-
latedposition.Therefrigeratorshouldbeatleast50cmfrom
radiators,gas orcoalstoves and5cmfarfromelectricalstoves.
•Keepthetopfree foratleast15 cm.
•Donotplaceheavyand lotsofthingsontheappliance.
•Iftheapplianceisinstallednexttoanotherrefrigerator orfreezer,
observe aminimumdistance of2cmtopreventcondensation.
•Installthedistance adjustmentplastic(the part withblackvanes
attherear)byturningit 90°topreventthe condenserfromtouch-
ingthewall.
•Theappliancemustbestandfirmlyandlevelonthe floorUse
thetwofrontlevelling-feettocompensateforanevenfloor.
•Inordertohaveaircirculationunderthe appliance,thespace
undertheappliance mustbe open.Don’tclose itwithcarpet,
etc.
•The outsideoftheapplianceand theaccessoriesinsideshould
be cleanedwithasolutionofwaterand liquidsoap;the inside
ofthe appliance withsodiumbicarbonatedissolvedinlukewarm
water.Afterdryingreplace allthe accessories.
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

UK- 4-
PART-2. THEVARIOUSFUNCTIONAND POSSIBILITIES
ThermostatSetting
FREEZERTHERMOSTATREFRIGERATORTHERMOSTAT
Freezerandrefrigeratorthermostatautomaticallyregulatesthe inside temperatureof
thecompartments.Byrotating the knobfromposition 1to5,coldertemperatures canbe
obtained.Incoldseasons,youcansetlowerpositions inordertodecreasetheenergy
consumption.
FreezerThermostatSetting;
1–2: Forshort-termstorage offoodinthefreezercompartment, you canset theknob
betweenminimumandmediumposition.
3–4:Forlong-termstorage offoodinthefreezercompartment,youcansetknob
mediumposition.
5: Forfreezingthe freshfood.Th appliancewillworklonger. Afteryou get thecold
condition youmustpositiontoitsoriginalposition.
RefrigeratorThermostat Setting;
1–2:Forlesscoldlyconditions.
3–4:Fornormalconditions.
5:Forcolderconditions.
•Notethat;theambienttemperature,temperatureofthefreshlystoredfoodand how
oftenthe doorisopened,affectsthetemperatureintherefrigeratorand freezercom-
partment.If required,change the temperaturesetting.
•Whenyou firstswitch ontheappliance,forstarting asuitablecooling,theappliance
shouldwork24hourscontinuouslyuntilit coolsdowntosufficienttemperature.
•Inthistimedonotopenthe doorsooften andplace alot offoodinsidetheappliance.
•Iftheunit isswitchedoff orunplugged,you mustallowatleast5minutesbefore
restartingorre-plugged the unitinordernottodamagethe compressor.
BeforeSwitchingOn
•Wait after3hoursbeforepluggingtheapplianceintothemainpower
toensureproperperformance.
•Therecanbean odourwhenyoufirstswitch on the appliance.Itwill
disappearafterthe appliancestartstocool.
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

UK- 5-
Accessories
MakingIceCubes
•Takeouttheice makingtray
•Fillthewaterinlevelofline.
•Placetheicemakingtray initsoriginalposition
•Whenicecubesareformed,twistthelever todrop
off icecubesintotheicebox.
Donotfill theiceboxwithwaterinordertomake
ice. It can bebroken.
FastFreezingShelf
•Usethe fastfreezingshelftofreezehome
cooking (andfreshfoodswhich iswanted
tofreeze)morequicklybecauseofthe
freezing room’sgreaterfreezing power.
•Foropeningtheshelf pull thecoverup, and
slideitintotheshelf.Youcancloseitin
the sameway.
Notethat; besurethatthe coveroffastfreezing shelfisclosedbeforeclosingthe
compartmentdoor. Ifnot, it can notshowitsfastfreezing power.
ChillerShelf
Keepingfood intheChillercompartmentallows
food retainfreshness and flavourlonger,whilepre-
serving itsfreshappearance.When chillertraybe-
comes dirty,removeitandwash it withwater.
(Waterfreezes at0°C,butfoods containingsalt
or sugarfreeze attemperaturelower than that)Nor-
mallypeopleuse thechillercompartmentforraw
fish,lightlypickled,rice,etc...
Donotput foodsyouwanttofreeze orice traysinordertomakeice.
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

UK- 6-
Drawer
Drawercompartmenthas fourpieces of
drawerboxesinordertoallowyou tokeepyour
foods andusethese forbreakfasteasily.
Forconsumer’susagecomfort and forthe
optimumofstoragefoods,youcaneasilymove
yourdrawertorightortoleftdirection.
Alsoyoucaneasilypull the drawer
compartmentand takeit outwhenneeded.
Note: Inordertopreventdryingofthefoodsandmixingof thesmellsyou shouldclose
drawerboxes cover.
WineRack
Itallowsyoutokeep yourbottlesinhorizon-
talposition depending on yourstorageofrefrig-
erator.
Youcaneasilyloadtheshelfunderthe wine
rack bymoving wine racktorightortoleft.
Ifyoudonotneedtothisaccessoryplease
pulltheglassshelf towardsyouandthentake
outwinerack fromglass shelfbymovingitto
rightorleft. Please donotforgetthatyoucanfix
itanyofglassshelvesinyourproduct.
Note: topreventofspillingthedrinks inyourbottleplease keep yourbottlelidas
closed.
Fresh Dial
Incaseofthecrisperistotallyfull,the freshdialislocatedinfrontofcrisper,shouldbe
opened.Bymeansofthisthe airinthecrisperandhumidityratewillbecontrolled and
endurancelifewill beincreased.
Freshdial
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

UK- 7-
Crisperand CrisperShelf
Thecrispercompartmentabsorbsanddecomposes ethylenegas (*) emittedfrom
fruitsandvegetableswitha“FILTER”inthe crispershelf,keeping fruitsandvegetables
fresh.Thefilteralsoeliminatesunpleasantodoursfrominsidethecrisper,and control
theexcess waterreleasedbythevegetables,maintaining ahigh humidityenvironment
inside thecrisper.Whenthecrispershelfbecomedirty,removethefilterbytakingoutthe
filtercoverandwashthecrispercoverwithwater.
!Donotwash the“Humidity-ControlFilter”withwater.
(*)NOTE; Ethylene gasisagas,produced fromfruitsand vegetables,whichacceler-
ates the ageing offruitsand vegetables.Forexample, spinach and broccoliturntoyellow
coloureasilyinplaceswhereethylene gasisabundant
CrisperCoverHumidityComtrolFilter
FilterCover
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

UK- 8-
Removing thecrispercover
First Step: Removing thecrispers
•Itiseasy topulloutthe crisperbecauseof
thecrisperhas rollers.
•Pull thecrisperoutas faras possibleand
pull thefrontpartupandout
SecondStep: TakingoutthePartitionCrisper
Centerbetween the crispers.
•BendthePartitiontowardleft fromthebottom
ofthe part
•Take outthePartitioncrisper
ThirdStep: Takingoutthe crisper cover
•Pulloutthecrispercover.
•Take outthecrispercover.
NOTE: Make the inverseofthesameoperation fortheresettingthecrispercover.
All writtenand visualdescriptions intheaccessories
mayvaryaccording totheappliance model.
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

UK- 9-
PART-3. ARRANGINGFOODINTHEAPPLIANCE
RefrigeratorCompartment
•Tosetthe refrigeratorcompartmentto2-3graphicbarwillbeenough fornormal conditions.
•Toreducehumidityand consequent increaseof frostneverplaceliquidsinunsealedcontain-
ersintherefrigerator.
•Neverplacewarmfoodintherefrigerator. Warmfood shouldbeallowedtocoolatroomtem-
peratureandshouldbearrangedtoensureadequateaircirculationinthe refrigeratorcom-
partment.
•Arrangethemeatandcleanedfish(wrapped inpackagesor sheetsof plastic) whichyouwill
usein1-2days.
•Youcanput thefruitsandvegetablesintocrisper without packing.
FreezerCompartment
•Tosetthe freezercompartment to2-3graphicbarwill be enoughfornormalconditions.
•The useoffreezeris,storing ofdeep-frozen orfrozenfoods forlongperiodsoftimeand
making icecubes.
•Donotputfresh and warmfoods tothefreezerdoorshelvestobefrozen.Onlyusefor
storageoffrozenfoods.
•Donotput fresh andwarmfood withfrozenfoodsidebysideasitcanthawthefrozenfood.
•Usethe fastfreezing shelf tofreezehomecooking (andthefoods which iswanted tofreeze)
morequicklybecauseofthe freezing room’sgreaterfreezingpower.
•Whilefreezingfreshfoods(i.e.meat, fishand mincemeat)dividetheminpartsyouwillusein
onetime.
•Whilefreezingfreshfoods ; Maximumamountoffreshfood(inkg)thatcanbefrozenin24
hoursisindicatedontheappliancelabel.
•Foroptimumapplianceperformancetoreachmaximumfreezing capacity,turnthe freezer
thermostatknob toposition max 24 hoursbeforeplacingfreshfoodinthefreezer.
•After placingfresh foodinthefreezer,24hourson max position isgenerallysufficient,After 24
hours, donnotneed toset thefeezerthermostat knob topositionmax.
•Attention; Inorder tosaveenergy,When freezingsmallamountsoffood, donnotneedtoset
thefreezerthermostatknob topositionmax.
• Forstoringthefrozenfoods;theinstructions shownonfrozen foodpackagesshould
always befollowedcarefullyand ifnoinformation isprovidedfoodshouldnotbe stored for
morethan3monthsfromthepurchaseddate.
• Whenbuyingfrozen foods ensurethatthesehavebeenfrozenatsuitabletemperatures
andthatthe packingisintact.
•Frozenfoodsshouldbetransportedinappopriatecontainerstomaintainthequalityof the food
andshouldbereturned tothefreezingsurfacesoftheunitinthe shortestpossibletime.
•If apackageof frozenfoodshowsthesignofhumidityand abnormal swellingit isprobablethat
ithasbeenpreviouslystored atan unsuitabletemperatureand thatthecontentshave deterio-
rated.
• The storage lifeoffrozenfoods dependsontheroomtemperature,thermostatsetting,
howoften thedoorisopened,the typeoffoodandthelengthof timerequired totransportthe
productfromtheshoptoyourhome. Alwaysfollowtheinstructions printedonthe package
andnever exceed themaximumstoragelifeindicated.
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

UK-10-
PART-4. CLEANINGAND MAINTENANCE
•Disconnectunit fromthepowersupplybeforecleaning.
•Donotclean theappliancebypouring water.
•The refrigeratorandfreezercompartmentshouldbe
cleanedperiodicallyusing asolution ofbicarbonateof
soda andlukewarmwater
•Cleanthe accessoriesseparatelywithsoapand water.
Donotcleantheminthe washingmachine.
•Donotuseabrasiveproducts,detergentsorsoaps. After
washing,rinse withcleanwaterand drycarefully.When
thecleaning operations have beencompletedreconnect
theplug oftheunitwithdryhands.
•Youshouldcleanthe condenser withbroomatleast once
ayearinordertoprovideenergysaving andincrease
the productivity.
THEPOWERSUPPLYMUST BE DISCONNECTED.
Defrosting
•Defrosting occursfullyautomaticallyduring opera-
tion;the defrostwateriscollectedbytheevaporat-
ingtray andevaporatesautomatically.
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

UK-11-
PART-5. TRANSPORTATIONAND CHANGING OF
INSTALLATIONPOSITION
•Theoriginalpackagesand foamed polystyrene(PS)canbe concealedifrequired.
•Intransportationtheapplianceshouldbetiedwithawidestripeorastrong rope.
Theruleswrittenonthe corrugated boxmustbeapplied whiletransporting.
•Beforetransportingorchangingoldinstallationposition,allthemoving objects(i.e.,
shelves,crisper…)shouldbetaken outorfixedwithbandsinordertopreventthe
shake.
Replacing TheRefrigeratorand FreezerLightBulb
RefrigeratorLight FreezerLight
1.Unplugtheunitfromthepowersupply,
2.Removetherefrigeratorlightcoverbypullingoutfirmly,
3.Change the presentlightbulbwithanewone ofnotmorethan15 W.
4.Replacethelightcoverandafterwaiting5minutesplug the unit.
ChangingofDoorOpeningDirection
Incase you need tochangedoor-openingdirection,please consultthe domesticafter
salesservice.
(Forsomemodels)
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

UK-12-
What todoifyourrefrigeratordoes notoperate;
Check that;
•Thereisnopower,
•Thegeneralswitchinyourhomeisdisconnected,
•The thermostatsettingison«0»position,
•The socketisnotsufficient. Tocheck this,pluginanotherappliancethatyouknow
whichisworkingintothe samesocket.
What todoif yourrefrigeratorperformspoorly;
Check that;
•You have notoverloadedthe appliance ,
•The doorsareclosedperfectly,
•Thereisnofood incontactwiththerearcabinetwhichmaycauseinsufficientairflow,
•Thereisnoduston the condenser,
•Thereisenoughplaceattherearandsidewalls.
Ifthereisnoise;
Thecooling gas which circulatesinthe refrigeratorcircuit maymake aslightnoise
(bubbling sound)even when thecompressorisnotrunning.Donotworrythisisquite
normal.Ifthesesoundsaredifferentcheck that;
•Theapplianceiswelllevelled
•Nothingistouching therear.
•The stuffsonthe appliance arevibrating.
fyourfridgeisnotcoolingenough;
Yourfridgeisdesigned tooperateintheambienttemperatureintervalsstatedinthe
standards,accordingtotheclimateclassstatedintheinformationlabel.Wedonotrec-
ommendoperating yourfridgeoutofstatedtemperaturesvalue limitsintermsofcooling
effectiveness.
ClimateClassAmbientTemperature(°C)
TBetween 16 and 43 (°C)
ST Between 16 and 38 (°C)
NBetween 16 and 32 (°C)
SN Between 10 and 32 (°C)
Recommendations
•Ifthe applianceisnotusedforlong time(forexampleduringthesummerholidays)
unplugand cleantherefrigeratorleavingthedooropen topreventtheformation of
mildewandsmell.
•Tostopthe appliancecompletely,unplugfrommainsocket(forcleaningandwhen
thedoorsareleft open)
PART-6. BEFORECALLINGYOUR AFTERSALES SERVICE
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

UK-13-
PART-7. THEPARTSOFTHEAPPLIANCEAND THE
COMPARTMENTS
1)FASTFREEZINGSHELF
2)ICETRAY
3)ICEBOX
4)FREEZERSHELF
5)FREEZERCOMPARMENT
6)FREEZERLAMPCOVER
7)CHILLERSHELVES
8)REFRIGERATORLAMPCOVER
9)REFRIGERATORSHELVES
10)DRAWER
11)WINERACK
12)CRISPERCOVER
13)CRISPER
14)KICKPLATE
15)FREEZERSHELF
16)EGGHOLDER
17)TOPSHELFCOVER
18)TOPSHELF
19)EGG SHELF
20)AROMABOX
21)BOTTLEHOLDER
22)BOTTLESHELF
23)FRESHDIAL
24)BOTTOMSHELF
Thispresentation isonlyforinformationaboutthepartsoftheappliance.
Partsmayvaryaccording tothe appliancemodel.
PDFcreated withpdfFactoryProtrialversion www.pdffactory.com

52027877
