Smipack SL55 User manual

Smipack SL55 Shrink Wrap Machine

S L series -Use and maintenance manual
3
Translation from the original
USE AND MAINTENANCE MANUAL
L-seal hood packer
SL45 - SL55
MANUAL CODE:
DATE OF CREATION:
REVISION:
VERSION DATE:
DM210649
11.04.2012
C
07.03.2016

4
Translation from the original
PREFACE
While thanking you for choosing us, SMIPACK S.p.A. is pleased to welcome you among its
large range of customers, hoping that the use of this machine will fully satisfy you.
This manual can be used for the model SL45 - SL55. It has been drawn up to put you in
conditions to be able to intervene on the various parts, and to understand the various
maintenance and intervention operations.
We recommend strictly keeping to the standards prescribed herein in order to guarantee
efficiency, duration and performance.
SMIPACK S.p.A. will not be held liable for direct or indirect consequences due to a proper or
improper use of this publication. We reserve the right to perform technical modifications on our
systems and on this manual without prior notice.
SMIPACK S.p.A. - Via Piazzalunga, 30 - 24015 S. Giovanni Bianco (BG) - ITALY
Tel. [phone] - Fax [phone]
READ THIS MANUAL CAREFULLY AND FULLY BEFORE INSTALLING THE
MACHINE.
THIS MANUAL IS AN INTEGRAL PART OF THE MACHINE AND MUST
THEREFORE ACCOMPANY IT UNTIL ITS FINAL DISMANTLING.

S L series -Use and maintenance manual
5
Translation from the original
CE DECLARATION OF CONFORMITY
(Directive 2006/42/EC - Annex IIA)
Company name and address of manufacturer of the machine :
SMIPACK S.p.A. - Via Piazzalunga 30, 24015 San Giovanni Bianco (BG) - ITALY
Tel. [phone] - Fax [phone]
Name and address of the company authorized to compile the technical documentation :
SMIPACK S.p.A. - Via Piazzalunga 30, 24015 San Giovanni Bianco (BG) - ITALY
We here by declare that the machine model SL45 - SL55
with the function of: L-seal hood packer
complies with Directive 2006/42/EC and to provisions of law which transpose Directives 2004/
108/EC (Electromagnetic compatibility) and 2006/95/EC (Low-voltage)
It also complies with the following harmonised standards:
• EN ISO 12100: 2010
• EN ISO 13849-1:2008 + AC:2009
• EN IEC 60204-1:2006
Giuseppe Nava
(Legal Representative)
San Giovanni Bianco, 25/01/2016

White page

7
Translation from the original
S L series -Use and maintenance manual
CE DECLARATION OF CONFORMITY ................................................................................................................................................ 5
1. GENERAL STANDARDS AND RECOMMENDATIONS .............................9
1.1 HOW TO READ AND USE THE MANUAL ........................................................................................................9
1.2 WARRANTY AND EXCLUSION OF LIABILITY .................................................................................................9
1.3 REFERENTIAL STANDARDS .........................................................................................................................10
1.4 SYMBOLS KEY ...............................................................................................................................................10
2. MACHINE INSTALLATION .......................................................................13
2.1 DESCRIPTION OF MACHINE COMPONENTS .............................................................................................13
2.2 WEIGHT AND DIMENSIONS OF PACKED MACHINE ...................................................................................13
2.3 MACHINE WEIGHT AND DIMENSIONS .........................................................................................................14
2.4 TRANSPORTATION AND UNPACKING .........................................................................................................14
2.5 MOUNTING MACHINE SUPPORTS ...............................................................................................................15
2.6 INSERTING FUSES IN THE POWER BOARD ...............................................................................................16
2.7 ELECTRICAL CONNECTION ..........................................................................................................................17
2.8 ELECTRICAL INSTALLATION DATA ..............................................................................................................17
2.9 CONDITIONS FOR USE .................................................................................................................................17
2.10 DEMOLITION AND WASTE DISPOSAL .........................................................................................................18
3. INFORMATION ON THE MACHINE .........................................................19
3.1 DESCRIPTION OF THE MACHINE .................................................................................................................19
3.2 DESCRIPTION OF DANGER ZONES .............................................................................................................19
3.3 IDENTIFICATION DATA AND TECHNICAL DATA OF THE MACHINE .........................................................20
3.4 TECHNICAL SPECIFICATIONS OF THE PRODUCT .....................................................................................21
3.5 FEATURES OF THE FILM ..............................................................................................................................21
3.6 DETERMINATION OF FILM WIDTH ...............................................................................................................22
3.7 FILM SEALING OPERATION ..........................................................................................................................22
3.8 FILM HEAT-SHRINKING OPERATION ...........................................................................................................23
4. PREPARING THE MACHINE FOR USE ...................................................25
4.1 POSITIONING REEL AND FILM PASSAGE ...................................................................................................25
4.2 ADJUSTING FILM PERFORATORS ...............................................................................................................25
4.3 ADJUSTING HEIGHT OF PRODUCT SUPPORT MESH ...............................................................................26
4.4 ADJUSTING HOOD OPENING .......................................................................................................................26
4.5 POSITIONING REEL HOLDER SUPPORT AND PRODUCT HOLDING PLATE ...........................................27
4.6 FIRST FILM SEALING .....................................................................................................................................27
4.7 PACKAGING PRODUCTS ..............................................................................................................................28
5. OPERATION AND USE .............................................................................29
5.1 OPERATOR PANEL INTERFACE .................................................................................................................29
5.2 TURNING THE MACHINE ON ........................................................................................................................30
5.3 MACHINE OPERATION ..................................................................................................................................30
5.4 SAVING A PROGRAM ....................................................................................................................................31
5.5 PARAMETERS MENU .....................................................................................................................................31
5.6 ACCESS TO RESERVED MENU ....................................................................................................................33
5.7 DESCRIPTION OF SYMBOLS ON DISPLAY .................................................................................................33
6. CLEANING AND MAINTENANCE ............................................................35
6.1 GENERAL WARNINGS AND PRECAUTIONS ...............................................................................................35
6.2 NATURE AND FREQUENCY OF MAINTENANCE CHECKS AND INTERVENTIONS ..................................35
6.3 REPLACING SEALING BLADE .......................................................................................................................36
SUMMARY

8
Translation from the original
6.4 REPLACING PTFE AND SILICON RUBBER ..................................................................................................37
6.5 MACHINE ACCESS AREAS FOR INSPECTIONS .........................................................................................38
7. ANOMALIES AND FAULTS - HOW TO RESOLVE ..................................39
7.1 SOLUTIONS TO OPERATING PROBLEMS ...................................................................................................39
7.2 ERROR AND MESSAGE DISPLAYS ..............................................................................................................40
END MANUAL ..............................................................................................................................................................44

S L series -Use and maintenance manual
9
Translation from the original
1.1 HOW TO READ AND USE THE MANUAL
This manual constitutes an integral part of the machine and therefore it must be preserved
during its entire lifetime and must be handed on to eventual future owners.
Purpose of use and maintenance manual
Before carrying out any type of operation on the machine, you must carefully read this manual
and any attached documentation in order to avoid possible damage to the machine, to persons
or to objects.
The manual and all attached documents must be kept in a place which can be easily accessed,
close to the machine and known to the users (operators and maintenance personnel) so that
they may be consulted promptly when circumstances require it.
SMIPACK S.p.A. will not be held liable for possible faults, accidents or problems due to failure
to comply with the provisions contained in this user manual or caused by unauthorised
modifications and installations of accessories.
Preservation of use and maintenance manual
•Keep the use and maintenance manual with care.
•Do not remove, tear or rewrite parts of the use and maintenance manual.
• Make sure that any amendment implemented is incorporated in the text.
Consulting use and maintenance manual
Consultation of this manual is facilitated by the insertion, in the first pages, of a summary which
allows you to quickly locate the topics described.
Method for updating manual in the event of modifications to the machine
The descriptions and illustrations of this manual cannot be contested. SMIPACK S.p.A.
reserves the right (while maintaining the essential features) to modify these machines at any
time for their functional, commercial and aesthetic improvement without being obliged to
update previous manuals and production except for exceptional situations.
Any updates or integrations of the manual will be considered an integral part of it. We would
like to thank you in advance for any suggestions which you would like to point out to us in order
to implement further improvement.
1.2 WARRANTY AND EXCLUSION OF LIABILITY
SMIPACK declines all liability deriving from:
- electrical and pneumatic supply defects;
- lack of maintenance;
- pollution external to the machine;
- unauthorised modifications and repairs;
- use of non-original spare parts;
- acts of God such as earthquakes, floods or fires.
CHAPTER 1 - GENERAL STANDARDS AND RECOMMENDATIONS

Chapter1-Generalstandards and recommendations
10
Translation from the original
The machine is shipped to the Customer ready to be installed, after it has passed all of the
foreseen tests and inspections in the factory, in compliance with legislation in force. The
warranty has a 365 day validity starting from the date of purchase. During the period covered
by warranty, SMIPACK commits itself to remove any faults or defects as long as periodical
maintenance is performed and original parts are always used. Expendable materials, parts
subject to normal wear or breakage, faults caused by atmospheric agents, transporting the
machine to an assistance centre and labour charges are excluded from the warranty. The
warranty is only valid for the original purchaser and only if the warranty certificate is properly
filled out in every part and sent within 20 days from the date of purchase. Repairs carried out
covered by the warranty do not interrupt or extend the warranty period.
The warranty will become void and invalid immediately in the following cases:
> improper use of the machine
> variation of process conditions
> unauthorised tampering by third parties
> failure to comply with that indicated in the instruction manual
> failure to use the manufacturer's original spare parts
1.3 REFERENTIAL STANDARDS
The machine models contained in this manual comply with Legislative Provisions which
transpose the following Directives.
European Directives applied to the equipment and/or the assembly:
• 2006/42/EC - Directive concerning the approximation of the laws of Member states relating
to machinery.
• 2006/95/EC - Directive concerning low voltage.
• 2004/108/EC - Directive concerning electromagnetic compatibility.
Tech ni cal s ta nd ar d s ap pli ed t o t he eq uip me nt an d /o r t he a sse mb ly :
• EN ISO 12100:2010 - Safety of machinery - General design principles - Risk assessment
and risk reduction.
• EN ISO 13849-1:2008 + AC:2009 - Safety of machinery - Safety-related parts of control
systems - Part 1: general principles for design.
• EN IEC 60204-1:2006-06 - Safety of machinery - Electrical equipment of machines - Part
1: general rules
1.4 SYMBOLS KEY
All of the instructions and information contained in this manual are often associated with certain
simple. Their meaning is explained in the following table.

S L series -Use and maintenance manual
11
Translation from the original
N.B.!
Provides important indications to consult the manual or general
warnings. Before operating make sure the indications refer to the
machine model you have purchased.
WARNING!
This indicates situations of risk for the machine and/or for the product
being processed.
ATTENTION!
This indicates personal hazardous situations and suggests standards of
conduct.
HIGH-VOLTAGE ZONE!
Electrocution danger inside electrical control board.
CUTTING DANGER!
Be careful of the upper limbs.
BURNING DANGER!
Be careful not to enter into contact with elevated temperature surfaces.
CRUSHING DANGER!
Be careful not to crush parts of the body, especially the upper limbs.
MOVING PARTS DANGER!
Be careful not to intervene on gears or mechanical systems while in
movement.
ELECTROCUTION DANGER - CUT POWER BEFORE OPERATING!
Make sure to have disconnected voltage before carrying out the
indicated operations.
MECHANICAL MAINTENANCE TECHNICIAN
ELECTRICAL MAINTENANCE TECHNICIAN
EARTHING
The earthing connection of the system is compulsory!

Chapter1-Generalstandards and recommendations
12
Translation from the original
USE OF SAFETY FOOTWEAR COMPULSORY
USE OF HEARING PROTECTION COMPULSORY
USE OF GLOVES COMPULSORY
CLOTHING COMPULSORY
GOGGLES COMPULSORY

S L series -Use and maintenance manual
13
Translation from the original
2.1 DESCRIPTION OF MACHINE COMPONENTS
2.2 WEIGHT AND DIMENSIONS OF PACKED MACHINE
1REEL HOLDER 8ELECTROMAGNET
2FILM PERFORATORS 9TROLLEY (optional)
3INFEED PRODUCT-HOLDING
PLATE 10 SEALING BLADE
4HOOD 11 OUTFEED PRODUCT DOOR
5POWER BOARD 12 HEAT-SHRINKING FAN
6MASTER SWITCH 13 HEATING ELEMENTS (OVEN
ZONE)
7OPERATOR PANEL
SL45 SL55
X (mm) 1140 1330
Y (mm) 760 910
H (mm) 680 770
WEIGHT (kg) 85 108
CHAPTER 2 - MACHINE INSTALLATION
Fig. 2.1.1
Fig. 2.2.1

Chapter2-Machine installation
14
Translation from the original
2.3 MACHINE WEIGHT AND DIMENSIONS
* without trolley
** with machine holding trolley
*** with machine supports
2.4 TRANSPORTATION AND UNPACKING
SMIPACK S.p.A., depending on the type of transportation and products to be delivered, uses
adequate packaging to guarantee integrity and preservation during transportation. Handle with
care when transporting and positioning the machine. The carrier is liable for damage sustained
during transportation. Be careful not to damage the exposed parts when unpacking the unit.
The machine module must be handled from beneath. Due to the type of packaging, systems
that work from above cannot be used. Lift the machine in the middle from the longest side and
adjust the position of the lift forks at the greatest centred position possible.
ATTENTION!
Before handling, always make sure that the lifting device is suitable to lift the load.
For prolonged storage, place the machine in a covered area at a temperature ranging from -
15 °C to +55 °C, with a humidity degree between 30% and 90% without condensation.
SL45 SL55
X (mm) 1050 1240
Y (mm) 665 805
H (mm)
480 *
1029 **
1015 ***
565 *
1102 **
1100 ***
WEIGHT (kg)
60 *
75 **
71 ***
77 *
95 **
88 ***
Fig. 2.3.1
Fig. 2.4.1

S L series -Use and maintenance manual
15
Translation from the original
2.5 MOUNTING MACHINE SUPPORTS
The SL series models can be positioned on specifically designed machine supports available
on-demand. Two versions are available: A and B.
A: Version with trolley
- Mount the machine holding trolley as shown in fig. 2.5.1.
- Position the machine on the trolley matching the feet 1 with the specific holes 2 and then use
the screws 3 to fasten the trolley to the machine.
B: Version with machine supports
- Mount the wheel on each support as shown in fig. 2.5.3.
- Insert the feet 1 into the holes 2 and then use the screws 3 to fasten the supports.
Fig. 2.5.1
Fig. 2.5.2
Fig. 2.5.3
Fig. 2.5.4

Chapter2-Machine installation
16
Translation from the original
ATTENTION!
Make sure to attach the supports A and B in the correct position.
Mount the two wheels C equipped with brakes at the front of the machine.
2.6 INSERTING FUSES IN THE POWER BOARD
The machine is delivered with the fuses not yet installed in the fuse-holder.
Follow the instructions below, taking into account the machine's power supply:
1 - 230V 1PH+N power supply
Insert the fuse on the phase and the copper wire on the neutral.
2 - 230V 2PH power supply
Insert the two fuses on the phases.
Fig. 2.5.5
Fig. 2.6.1

S L series -Use and maintenance manual
17
Translation from the original
2.7 ELECTRICAL CONNECTION
Power must be cut from the machine for all operations involving connection to the electrical
network.
ATTENTION!
Whenever accessing the electrical system, remember to cut the power and to wait at
least five minutes before operating.
THE EARTH CONNECTION IS COMPULSORY!
Connecting the machine to the mains must be carried out in compliance with standards in force
in the user's country.
Check to make sure that the machine's power supply frequency and voltage (see plate
applied on the machine) correspond to the power supply network.
2.8 ELECTRICAL INSTALLATION DATA
Install a circuit breaker on the machine power supply line which supports the values indicated
in the table.
2.9 CONDITIONS FOR USE
The machines must operate exclusively indoors, protected from the elements, where there are
no explosive atmospheres.
Make sure there is room for its easy installation and maintenance.
The minimum lighting must be 300 lux.
Operating temperatures ranging from +10°C to +40°C are recommended, with a relative
humidity from 30% to 80% without condensation.
Machine protection grade = IP20
SL45 SL55
Nominal
voltage
220÷240 V
(1PH+N+PE)
220÷240 V
(1PH+N+PE)
Nominal
frequency 50÷60 Hz 50÷60 Hz
Nominal
power 1650 W 3700 W
Nominal
current 7 A 17 A

Chapter2-Machine installation
18
Translation from the original
DECLARED NOISE EMISSION VALUES IN COMPLIANCE WITH THE STANDARD ISO
4871 ARE:
A-WEIGHTED EMISSION SOUND PRESSURE LEVEL (AT OPERATOR POSITION): 70 dB
ATTENTION!
The exposure of the operator to noise may also vary due to background noise generated
by other equipment present where the machine is installed. In order to provide
operators with the appropriate PPE hearing protection it may therefore be necessary to
assess the noise within the work environment.
2.10 DEMOLITION AND WASTE DISPOSAL
The machine does not contain dangerous components or substances which require special
disposal procedures. For that which concerns material elimination, comply with the Standards
in the country where the machine has been disassembled.

S L series -Use and maintenance manual
19
Translation from the original
3.1 DESCRIPTION OF THE MACHINE
The SL series hood packer is equipped with a simple but complete control panel connected to
a microprocessor which guarantees high performance and provides the operator with a great
deal of autonomy.
3.2 DESCRIPTION OF DANGER ZONES
The table below describes the zones of the machine where the operator must pay the utmost
attention to avoid possible danger.
ZONE A
Possibility of crushing upper limbs during manual closure of hood.
Possibility of burns by touching the sealing blade just after a packaging cycle.
ZONE B Burns due to contact with very hot elements (tunnel zone with temperature
controlled heating elements).
ZONE C Possibility of entering into contact with fans used for heat-shrinking process
by inserting hands underneath the product support mesh.
ZONE D Possibility of burns by touching the product support mesh.
ZONE E Small pricks caused by perforators on reel holder.
ZONE F During the packaging possibility of burns by touching the hood in plexiglas.
CHAPTER 3 - INFORMATION ON THE MACHINE
Fig. 3.2.1

Chapter3-Information on the machine
20
Translation from the original
ATTENTION!
Leave the hood open when the machine is switched off to allow it to cool down.
Near some zones of the machine, some pictograms were placed in order to recall the attention
of the operator concerning the precautions required to avoid dangers. In order to have greater
understanding of the symbols used, the main ones are described hereafter.
3.3 IDENTIFICATION DATA AND TECHNICAL DATA OF THE
MACHINE
Each machine is provided with a plate where it is easy to recover data which must be
communicated to the manufacturer in case of problems or when requesting spare parts etc.
(ref. 1-2-3-4). This plate also carries electrical technical data for installation of the machine (ref.
a-b-c-d).
1 - Model
2 - Serial number
3 - Machine code
4 - Year of manufacture
a - Nominal voltage
b - Nominal frequency
c - Nominal power
d - Nominal current
ATTENTION! Before performing connections to the electrical mains, make sure that the power
supply voltage is compatible with that shown on the plate.
DANGER DUE TO THE HIGH VOLTAGE ZONE WITH RISK OF
ELECTROCUTION INSIDE ELECTRICAL CONTROL BOARD
BURNING DANGER DUE TO CONTACT WITH HIGH
TEMPERATURE SURFACES
CRUSHING DANGER
CUTTING DANGER - PAY ATTENTION TO YOUR HANDS
Fig. 3.3.1
