Smith and Locke 9370R User manual

Locke & Co, BA22 8RT
Fitting Instructions: Soft Close for Metal Drawer Systems
1. The product has two assembly parts for their respective location:
White Metal Bracket –Drawer
Grey Plastic Soft Close Unit - Cabinet
The distance between the side of the drawer and the inside of the cabinet must
be between 15- 16mm
2. Check the size of your drawer runner to determine lengths L1 & L2 using the table below.
3. On the inside of your cabinet, mark the location of the position of your soft close unit –as per
the below diagram –L1 is the distance of the screw hole from cabinet front.
Runner Size
Distance L1
Distance L2
300mm
70mm
123.5mm
350mm
102mm
155.5mm
400mm
134mm
187.5mm
450mm
166mm
219.5mm
500mm
198mm
251.5mm
550mm
262mm
315.5mm

Locke & Co, BA22 8RT
4. Once confirmed insert the given M4 screws in the two holes along the length of the soft close
unit.
5. Install the metal bracket at the centre of ‘L2’using the given screws - with the 90° bend
wrapping around the bottom of the drawer.
