SmoothTalker Stealth Z1 User manual

®
Stealth Series Dual Band Booster Amplifiers
BRB Stealth Z1
User Manual
COTTAGES
BUILDINGS
HOMES
Increases your Cellular and PCS Band
Signals, expands your service coverage
area, enhances voice call quality and
signicantly increases Data speeds.

Table of Contents
Pg. 2
Kit Type Configurations..............................................................................3
Optional parts................................................................................................3
Antenna and Booster Installation..........................................................4
Installation Illustrations...............................................................................5
Control panel ................................................................................................6
LED lights - Outside signal level/RX power..........................................6
Frequently asked questions......................................................................7
Troubleshooting guide.............................................................................7
Inside Antennas ............................................................................................8
Outside Antennas ........................................................................................8
Splitters/Power Dividers.............................................................................8
Extention Cables ..........................................................................................9
Specifications..............................................................................................11
Glossary of terms.......................................................................................12
FCCInformation..........................................................................................12
Warranty.....................................................................................................12
This is a CONSUMER device
BEFORE USE, you MUST REGISTER THIS DEVICE with your wireless provider and
have your provider’s consent. Most wireless providers consent to the use of
signal boosters. Some providers may not consent to the use of this device on
their network. If you are unsure, contact your provider.
You MUST operate this device with approved antennas and cables as specified
by the manufacturer.
Antennas MUST be installed at least 20 cm (8 inches) from any person.
You MUST cease operating this device immediately if requested by the FCC or a
licensed wireless service provider.
WARNING. E911 locator information may not be provided or may be inaccurate
forcalls served by using this device.
To comply with FCC rules the use of this device in any building is for personal use only.

Package Contents
Typical Configuration
Pg. 3
AC/DC Power Supply
Indoor Antenna
Outdoor Antenna
Main Booster Unit
Optional Parts
Co-Ax Cables
RF Splitter/Power Divider
Co-Ax Adapters
2” 11” 14” 26”
Avaliable Antennas
Antenna Pole Mount Kit
BRBZ Series
(Individual Kit Configuration Parts Included Vary By Model)
NOTE : Your model may ship with different antennas.

Antenna and Booster Installation
a) Location: There are three choices. fig. 2, 3, 4.
The choice of donor antenna location depends on the signal strength at the donor antenna
location. Use your phone to determine if signal at your chosen location is adequate. Better
signal level at the donor antenna location equals larger indoor coverage area.
b) Directional Donor Antenna: if using an optional directional donor antenna, point the
antenna toward the desired tower. If the location of the desired tower is not known, initiate a
phone call and use the signal indicator on your phone after the booster is operational, while
turning the donor antenna, to determine optimum donor antenna direction for maximum
signal strength.
c) Omni-directional Donor Antenna: if using an omni-directional donor antenna, it is
recommended that it is placed as far as possible from the inside antenna, usually, ‘outside pole
mount’ is recommended (Fig. 4). Use of omni-directional antennas will require more
separation distance compared to directional antennas. Fig. 1
Donor Antenna: (outdoor signal antenna)
Distribution Antenna: (indoor signal antenna)
Connection and Start Procedure:
Amplifier/Booster Location:
Install the repeater in a location that has proper ventilation, away from excessive heat and
moisture.
a) Location: There are three choices. fig. 2, 3, 4.
The choice of donor antenna location depends on the area to be covered.
b) Directional Distribution Antenna: it is recommended that directional antennas
are oriented in a fashion that is back to back of each other Fig. 1
c) Omni-directional Distribution Antenna: it is important that omni-directional
antennas are separated as far apart as possible from each other. Use of omni-directional
antennas will require more separation distance compared to directional antennas
d) Splitting Indoor Signal: it is possible to use more than one indoor antenna to
cover areas that are separated by walls or floors by using antenna splitters or
power dividers, however splitters have a level of signal loss (3dB) and the added cable run
will also have signal loss, therefore the coverage area will be diminished. As a general rule, if
outside signal is good, splitting signal to more than one
distribution antenna results in reasonable coverage.
If outside signal is poor or marginal, splitting signal to more than one distribution antenna
results in decreased coverage for both distribution antennas.
Use only genuine SmoothTalker splitters. Contact your dealer or www.smoothtalker.com
WARNING:
Make sure all cables have a good connection and are connected to the corresponding
antenna port on the Booster.
DO NOT APPLY POWER or turn on the power switch on the Amplifier/Booster
before all cables and antennas are connected.
Antenna connections must be snug and hand tight, ‘Do Not Use Pliers or Wrench’.
Connect the cable from outdoor antenna to RF port (antenna connector) labeled “Outdoor
Antenna”. Connect cable from indoor antenna to RF port labeled “Indoor Antenna”.
Connect supplied AC/DC power supply to the amplifier and plug it into power source.
Turn on the power switch on the Amplifier/Booster.
Pg. 4

Omni directional antennas separation distance - Far
Directional antennas separation distance - Close
Fig. 1
Fig. 2
Fig. 3
Fig. 4
Pg. 5

Control Panel: Understanding the Control Panel and LED lights
General: Mobile networks, phones and data devices operate in two frequency bands
(800Mhz & 1900Mhz). The Stealth Booster will amplify signals in both bands if they are
present. The band that the phone or cellular data device will transmit (TX) and receive (RX)
on is determined by the cellular provider and cannot be chosen by the user. The booster
LED lights will indicate outside signal level and booster gain.
Outside 800MHz RX
Indicator (Orange LED)
Outside 1900MHz RX
Indicator (Orange LED)
800MHz Gain Level
(Green LED)
1900MHz Gain Level
(Green LED)
Pg. 6
Orange LED Lights (RX):
There two orange LED lights, one for the 800MHz cellular band and one for the 1900MHz
PCS band. LED ON state indicates that the RX (Receive Signal) function of the band is
functioning normally.
LED Off state indicates that the band is shut down.
Green LED Lights (TX):
There two Green LED lights, one for the 800MHz cellular band and one for the 1900MHz
PCS band.
Solid ON state indicates that the TX (Transmit Signal) function of the indicated band is on
and is at maximum gain.
Flashing Green LED in either 800MHz or 1900MHz indicates gain reduction in that band
Each flash equals 3db reduction in gain. One flash represents a 3dB reduction, two flashes
represents a 6dB reduction etc. until the total gain of the booster has been suppressed.
Causes of Flashing Green LED Lights:
1-If the outside antenna is located too close to the inside antenna or phone holder the
booster will reduce gain in order to suppress any oscillation (feedback loop) and the Green
LED will flash. To achieve higher gain or max gain further separation of the inside and
outside antennas is required.
2-If the booster is close to a cellular tower (Strong cell tower signal ) it will automatically re-
duce its gain to protect the network. This condition will change as the booster approaches
or leaves a cellular tower. This is normal and cannot be defeated or altered by the user.

Frequently Asked Questions
My booster is powered, running and the lights are on but my signal did not improve. Why?
Check your antenna connections and make sure they are snug. Also make sure that the external
and internal antennas are connected to corresponding antenna ports of the booster.
Should the booster get hot? Normal operation temperature for the booster is approximately 109°
F, or 43° C. This will feel warm to the touch.
Will the booster improve Voice and Data signals? Yes.
How large should my inside coverage area be? Coverage area is dependent on two factors; the
booster’s gain and the signal level at the outside antenna. It is possible to cover a large area with a
low gain booster if the outside signal is excellent, conversely, it is possible to have
relatively small coverage area with a high gain booster if the signal outside is really poor.
How do I increase my indoor coverage area? If your inside coverage area is inadequate, try to
move your external antenna to a location with better signal. If antenna location is optimized the
coverage area is still too small, use a higher gain booster. If outside signal is really poor and the
high gain booster does not increase the coverage area enough, use a line amplifier to increase
gain and TX power (pg 5).
Will the booster boost signals from service providers other than mine? Yes. Smoothtalker
Stealth series boosters are wideband RF amplifiers that will improve all Cellular and PCS signals
in your area.
Why does my friend’s phone show better signal than mine? Your friend’s phone is probably
using a different service provider that has a tower closer to your location than your service
provider. For best indoor coverage, make sure that your outside antenna is pointing at your
service provider’s tower.
Can I leave my booster on continuously? Yes.
Can I leave my booster on during a lightning storm? To be 100% sure that lighning will not
damage the booster, you must unplug it from the wall and disconecct the external antenna from
the booster. If you must keep connected during lightning you can use a lightning arrestor on the
antenna and high quality surge protector on the power supply, however, Smoothtalker warranty
does not cover lightning damage.
I need more cable length. What do I use? Only 50 Ohm co-ax cable should be used. Please con-
tact SmoothTalker for cables and connectors.
Troubleshooting Guide
Condition
Automatic Shutdown.
Oscillation (feedback)
Suppression:
Automatic cannot be manually
overridden.
High power control due to
High RX signal (signal from
tower):
Automatic cannot be
manually overridden.
High power control due to
High TX signal (signal from
phones):
Automatic cannot be
manually overridden.
Orange and green LED ash
simultaneously every 2 secs in the freq.
band that has been shutdown.
One or more green LED solid ON, one
green LED ashing or OFF.
One or more green LED solid ON, one
green LED ashing or OFF.
One or more green LED solid ON, one
green LED ashing or OFF.
Separate antennas and/or re-orient directional
antennas (back to back) and power OFF/ON the
booster.
Gain has been reduced to suppress oscillation (feed-
back). Separate antennas and/or re-orient directional
antennas (back to back) and power OFF/ON the
booster.
Gain has been reduced to suppress high RX signal:
a) Directional donor (outside) antenna: turn to point
away from tower.
b) Omni antenna: change to a location with lower
signal.
Gain has been reduced to suppress high TX signal.
Normally temporary but if phone or cellular device is
constantly too close to inside antenna, move device
away from internal antenna.
LED indicators Action
Pg. 7

Antenna Description Cable
Minimum
Cable Loss
(dB)
Maximum
Antenna
Gain (dBi)
Net Gain
(dB)
SEMD1XL,
NL Inside Antenna 18 . SEMRC205 -2.00 8.14 6.14
SEMOXL,
NL Inside Antenna 18 . SEMRC205 -2.00 0.00 -2.00
SEMOX, N Inside Antenna 10 . SEMRC205 -2.00 0.00 -2.00
SEMD1GL Inside Antenna 18 . RG6 -1.80 8.14 6.34
SEMOGL Inside Antenna 18 . RG6 -1.80 0.00 -1.80
SEMOG Inside Antenna 10 . RG6 -0.90 0.00 -0.90
SEMR1 Inside Antenna Direct to Booster 0.00 0.00 0.00
SEMRBL1 Inside Antenna Direct to Booster 0.00 0.00 0.00
Inside Antennas
FCC Rules specify that all approved antennas, cables and accessories to
be used with this booster are to be listed in this manual. e approved
accessories are listed below.
Pg. 8
Splitters/Power Dividers
Part # Description Insertion loss
(dB) Net gain (dB)
ADCSPN2 “N” type 2-way splitter -3.0 -3.00
ADCSPN3 “N” type 3-way splitter -4.8 -4.80
ADCSPG2 RG6 type 2-way splitter -4.0 -4.00
ADCSPG3 RG6 type 3-way splitter -6.00 -6.00
ADCSPG4 RG6 type 4-way splitter -7.50 -7.50

Cable Part # Description Cable
Minimum
Cable loss
(dB)
SEMRCBXmaXfe10 extension cable 10 . SEMRC205 -1.00
SEMRCBXmaXfe20 extension cable 20 . SEMRC205 -2.00
SEMRCBXmaXfe30 extension cable 30 . SEMRC205 -3.00
SEMRCBXmaXfe40 extension cable 40 . SEMRC205 -4.00
SEMRCBXmaXfe50 extension cable 50 . SEMRC205 -5.00
SEMRCBXmaXfe60 extension cable 60 . SEMRC205 -6.00
SEMRCBNmaNfe10 extension cable 10 . SEMRC205 -1.00
SEMRCBNmaNfe20 extension cable 20 . SEMRC205 -2.00
SEMRCBNmaNfe30 extension cable 30 . SEMRC205 -3.00
SEMRCBNmaNfe40 extension cable 40 . SEMRC205 -4.00
SEMRCBNmaNfe50 extension cable 50 . SEMRC205 -5.00
SEMRCBNmaNfe60 extension cable 60 . SEMRC205 -6.00
SEMRCBL4maL4fe10 extension cable 10 . LMR400 -0.60
SEMRCBL4maL4fe20 extension cable 20 . LMR400 -1.20
SEMRCBL4maL4fe30 extension cable 30 . LMR400 -1.80
SEMRCBL4maL4fe40 extension cable 40 . LMR400 -2.40
SEMRCBL4maL4fe50 extension cable 50 . LMR400 -3.00
SEMRCBL4maL4fe60 extension cable 60 . LMR400 -3.60
SEMRCBL4maL4fe70 extension cable 70 . LMR400 -4.20
SEMRCBL4maL4fe80 extension cable 80 . LMR400 -4.80
SEMRCBL4maL4fe90 extension cable 90 . LMR400 -5.40
SEMRCBL4maL4fe100 extension cable 100 . LMR400 -6.00
SEMRCBGmaGfe10 extension cable 10 . RG6 -0.90
SEMRCBGmaGfe20 extension cable 20 . RG6 -1.80
SEMRCBGmaGfe30 extension cable 30 . RG6 -2.70
SEMRCBGmaGfe40 extension cable 40 . RG6 -3.60
SEMRCBGmaGfe50 extension cable 50 . RG6 -4.50
Extension Cables
Pg. 9

Cable Part # Description Cable
Minimum
Cable loss
(dB)
SEMRCBGmaGfe60 extension cable 60 . RG6 -5.40
SEMRCBGmaGfe70 extension cable 70 . RG6 -6.30
SEMRCBGmaGfe80 extension cable 80 . RG6 -7.20
SEMRCBGmaGfe90 extension cable 90 . RG6 -8.10
SEMRCBGmaGfe100 extension cable 100 . RG6 -9.00
Extension Cables (continued)
Outside Antennas
Antenna Description Minimum
Cable Length
850
MHz
1900
MHz
Maximum
Antenna
Gain (dBi)
850
Mhz
1900
Mhz
SEMD1XL, NL Outside Antenna 48  SEM-
RC205 -5.28 -10.56 8.14 2.86 -7.70
SEMDA2XL, NL Outside Antenna 48  SEM-
RC205 -5.28 -10.56 9.14 3.86 -6.70
SEMOXL, NL Outside Antenna 48  SEM-
RC205 -5.28 -10.56 0.00 -5.28 -15.84
SEM26THX, N Outside Antenna 48  SEM-
RC205 -5.28 -10.56 7.14 1.86 -8.70
SEM26THXL,
NL Outside Antenna 55  SEM- RC205 -6.05 -12.10 5.14 -0.91 -13.01
SEMD1GL Outside Antenna 48  RG6 -2.9 -4.32 8.14 5.26 0.94
SEMDA2GL Outside Antenna 48  RG6 -2.9 -4.32 9.14 6.26 1.94
SEMOGL Outside Antenna 48  RG6 -2.9 -4.32 0.00 -2.88 -7.20
SEM26THG, Outside Antenna 48  RG6 -2.9 -4.32 7.14 4.26 -0.06
SEM26THGL Outside Antenna 55  RG6 -3.3 -4.95 5.14 1.84 -3.11
Cable Loss (dB) Cable Loss (dB)
Pg. 10

Operational Bands 800MHz Cellular and 1900MHz PCS
Impedance 50 Ohms
TX Output Power 29.9 dBm EIRP
RX Output Power 11.0 dBM EIRP
Oscillation Control (Automatic) 35 dB in 1db steps
Oscillation Control Timing < 1 sec
RX High Power Control Dynamic up and down < 50 milliseconds
TX High Power Control Dynamic up and down < 50 milliseconds
Current Draw @ 12V 0.5 Amp - 0.8 Amp
Operating Voltage 6V
Noise Figure < 5dB
Operating Temperature -32F to +85F
Outside Antenna Connector MCT Male
Inside Antenna Connector MCT Male
Dimensions 6.25x3.5x1.125 inches
Weight 1.0 Lb
FCC ID S4RBRB81975
Model Maximum Gain
BRBUZ1-72 72dB
BRBUZ1-70 70dB
BRBUZ1-68 68dB
BRBUZ1-65 65dB
BRBUZ1-62 62dB
BRBUZ1-60 60dB
BRBUZ1-58 58dB
BRBUZ1-55 55dB
Specifications
Pg. 11

Glossary of Terms
Attenuation: the reduction of the RF signal usually measured in dB. Attenuation is the opposite
of Gain. Increasing attenuation has the same effect as turning down the volume control of a
radio or stereo speaker.
Booster: also known as: RF amplifier, repeater or signal enhancer.
dB: short form for decibel. Unit of measure for RF signal gain or attenuation.
Directional antenna: an antenna designed to focus its energy mostly in one direction.
Distribution antenna: internal antenna used to distribute signal to the interior of a
building or structure.
Donor Antenna: outside antenna used to provide signal from outside to inside.
Frequency band: the operational frequency range of the Smoothalker booster and the cellular
network frequencies that are amplified. These are commonly referred to as the ‘Cellular Band’
(824-894 Mhz) and the ‘PCS Band’ (1850-1990 Mhz).
Gain: the increase of the RF signal usually measured in dB. Gain is the opposite of
Attenuation. Increasing gain has the same effect as turning up the volume control of a radio or
stereo speaker.
LED: Light Emitting Diode.
Omni-directional antenna: an antenna designed to radiate its energy equally in all
directions.
Oscillation: term to describe a feedback loop. This occurs when the signal from one
antenna reaches the other antenna and the booster amplifies the signal creating a loop. This is
the same effect as the squeal one hears when a speaker is brought close to a microphone.
RF: Radio Frequency.
RX: ‘receive signal’ originating at a base station or tower.
Splitter/Power Divider: a component with input and output connectors that will allow one
originating signal to be split and distributed to two or more antennas.
TX: ‘transmit signal’ originating from a cellular phone or data device.
Warranty
Smoothtalker boosters are warranted against manufacturing defects for a period of one year from the date of purchase.
The original bill of sale is required for any warranty claims.
For warranty claim contact original dealer or smoothtalker.com
Pg. 12
FCC Part: §15.21 Information to Users
“The users manual or instruction manual for an intentional or unintentional radiator shall
caution the user that changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate the equipment.
In cases where the manual is provided only in a form other than paper, such as on a
computer disk or over the Internet, the information required by this section may be
included in the manual in that alternative form, provided the user can reasonably be
expected to have the capability to access information in that form.”
“This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including
interference that may cause undesired operation.”
RF Exposure Warning
Please Note: Antenna should be positioned at least 8”(20cm) from all person/persons as per requirements
necessary to comply with the FCC MPE rules.
Notes:
1-This booster is not user configurable. User changes are a violation under FCC rules and will void the user’s
authority to operate the equipment.
2-User changes changes or modifications will void warranty.
