FAME MC 10 User manual

Important safety instructions! Please read before connection!
RISK OF ELECTRIC SHOCK
DO NOT OPEN
√
ATTENTION: To prevent the risk of electric shock, do
not open the unit under any circumstances.
Refer all maintenance and repair work to a qualified
workshop or contact your dealer.
The lightning flash symbol warns the user
of uninsulated voltage and the risk of
electric shock.
The exclamation point symbol alerts the
user to important maintenance and
operating instructions in the instruction
manual.
Suitable for indoor use only

Read operating instructions

This symbol defines the minimum distance
of the object to be illuminated.
For environmental reasons, please recycle the
packaging correctly.
A new product can sometimes lead to unwanted odours
or to minimal smoke development for a short period of
time. This reaction is normal and disappears after a few
minutes.
The unit is intended for indoor use only (IP20)! Please
use the device only in a dry environment. Keep the unit
away from rain, moisture, direct heat and dust.
In order to avoid condensation in the device, the device
should adapt to the ambient temperature before start-
up.
Please place the device in a well ventilated place, out of
the reach of flammable materials or liquids.
Do not cover any ventilation openings as this may
result in overheating.
Please disconnect the power plug if the unit is not to be
used for a long period of time or if maintenance work is
to be carried out.
The device is designed for a maximum ambient
temperature of 40° Celsius.

The device should not be installed by inexperienced
persons and must be installed in compliance with the
mechanical and electrical safety regulations in your
country.

If the power cord is damaged, it must be replaced
immediately with an original spare part from the
manufacturer.

Make sure that the mains voltage is not higher than the
voltage indicated on the housing.

In case of a malfunction of the device, please contact your
dealer and stop the operation of the device immediately.


ENGLISH
Power supply/power cord
The power cord must not be laid near hot objects such
as heaters or radiators
Avoid excessive buckling of the power cord
Do not place heavy objects on the cable
Ensure that no one can step on or trip over the cable
and do not roll any objects over it
Pay attention to the mains voltage prescribed for this
device
Only the enclosed power supply unit may be used
The condition of the electrical plug must be checked
regularly. If necessary, remove any dirt or dust that
has accumulated on it
Only suitable sockets with safety earthing may be used.
Improper or missing grounding is associated with the
risk of electric shock
Place the unit on a flat surface to avoid slipping or
falling
WARNING! Please –do not open!
The device does not contain any user serviceable parts
Do not attempt to disassemble the unit, remove or
modify any internal components.
If the device does not function properly, stop using it
and have it checked by a qualified person, e.g. from
the Music Store
WARNING! Liquids!
The device must not be exposed to rain
Avoid use near water or in humid weather conditions
Do not place any containers with liquids next to them
(vases, drinks, etc.). Liquid may enter the openings of
the device when it tips over
Manufacturer: MUSIC STORE professional GmbH,
Istanbulstraße 22-26, 51103 Cologen, Germany

ENGLISH
Congratulations on your new FAME MC 10 microphone amplifier!
Thank you for choosing a FAME product. Through efficient FAME enables development and
economical production of high-quality products at a fantastic price.
Please read the instruction manual carefully to learn about all the features of this
product and keep it for future use.
Have fun with your new product!
Your FAME Team
Guarantee:
The current general terms and guarantee conditions
of the Music Store professional GmbH apply.
You can view it at: www.musicstore.de
If you have any questions or suggestions,
please contact us:
Music Store professional GmbH
Istanbulstr. 22-26
51103 Cologne
Managing Director: Michael Sauer
WEEE-Reg.-No. DE 41617453
Tel: [phone]
Fax: [phone]
[e-mail]
Intended use:
The product FAME MC 10 was designed for use as an amplifier for incoming microphone signals.
The device may only be used for this purpose and in accordance with the operating instructions.
Other purposes as well as operation under other operating conditions are expressly not intended
and can lead to damage to property or personal injury! No liability is assumed for damage resulting
from improper use.
It must be ensured that the device is operated exclusively by trained and competent users who are
in full possession of their mental, physical and sensory abilities. The use of other persons is
expressly only permitted at the request of a person responsible for their safety, who instructs or
supervises the use.
Content
Amount
MC 10 microphone amplifier
1x
12V Power cord
1x
Manual
1x
Scope of delivery:

ENGLISH
Safety instructions:
DANGER! (For babies and children)
Packaging, plastic films and other packaging materials must be properly stored or
disposed of. They must be kept out of the reach of babies and children due to the risk of
suffocation.
Make sure that children never use the device unattended! In addition, make sure that
children do not remove any (small) parts from the device, as they could suffocate by
swallowing them!
DANGER! (Electrical shock due to high voltages in the device)
Do not remove the housing. There are no parts to be maintained in the device. Inside the
device there are components which are under high electrical voltage.
The device must not be used as soon as damage or the absence of components,
protective devices or housing parts is noticed!
DANGER! (Electric shock caused by short circuit)
Modifications to the power cord or plug are prohibited. Failure to do so may result in fire
or death due to electric shock!
NOTE! (Fire hazard)
Ensure that the unit is not exposed to a direct source of heat and is used away from open
fire. Never cover or tape any ventilation slits or the device itself.
NOTE! (Operating conditions)
Due to its structural characteristics, the device is designed for indoor use. Never expose
the device to rain, moisture or liquids as this may cause damage. Vibrations, dirt or
sunlight can also cause damage - avoid them!
NOTE! (Power supply)
It is essential that you check that the device voltage matches your local mains voltage. It
is strongly recommended that you fuse your mains socket with a residual current circuit
breaker (FI).
If you do not use your device for a longer period of time, disconnect it from the mains.
to minimize danger. The same applies to storm conditions such as thunderstorms or
floods, etc..

ENGLISH
Installation:
Be sure to check the unit for damage before using it. Optimally, use the original packaging or
suitable transport or storage packaging to protect the product from dust, moisture, etc. when not
in use.
Equipment and use:
The FAME MC 10 allows to amplify incoming microphone signals. The front also features a high-
pass switch that filters out footstep/low-frequency noise and a 48V phantom power switch (for
condenser microphones). The connectors are standardized 3-pin XLR sockets. Please read the
following instructions to avoid damage to the device:
Commissioning:
All connections of the device should be made before switching on. Only use high-quality cables
that are as short as possible for the connections.
-Connect your microphone to the input of the MC10 via the microphone cable
(standard -3pin XLR).
-Connect the output of the MC10 to the input of a mixer/audio interface or similar via
XLR cable.
-Only switch on 48V phantom power when using a condenser microphone.
-Do not turn on 48V phantom power until the unit is fully wired and activated.
-Turn off 48V phantom power before turning off the unit
Note on operation:
When switching on the FAME MC 10, make sure that the gain control is turned to 0 and turn it
up slowly. The Clip LED lights red when the signal is overdriven. Turn down the Gain knob until
the Clip LED stops lighting. When using headphones, it is recommended that you lower the
volume control before turning on the headphones and turn it up slowly. This procedure prevents
hearing damage by not exposing the ear to sudden, extreme/ loud signals.

ENGLISH
Specifications:
Features
MC 10
Frequency range
50HZ up to 20kHz (+/- 3dB)
High-pass filter
- 6dB/octave from 90 Hz
Input level
-34 dBu up to -3 dBu
max. output level
+26 dBu (XLR balanced) // -24 dBu (mini-jack
unbalanced)
Output level range
+30 dB up to +60 dB
Output impedance
200 Ohm
Equivalent inherent noise
-80 dB (min. Gain) // -52 dB (max. Gain)
harmonic distortion
0,03% at 1kHz (min. Gain)
Phantom voltage
48V
Input
XLR female
Outputs
XLR male + 3,5mm mini-jack
Power supply tolerance
DC voltage 12-16V
Switches
Phantom Power, LF-Cut, On/Off
Power supply (included)
12V DC power supply unit
Functionalities
OpenType

ENGLISH
Troubleshooting:
The following overview serves as an aid for quick troubleshooting. If you are unsafe, contact the
manufacturer, the dealer or the corresponding specialist personnel.
Never open the device on your own!
If the specified corrections have not led to success, please contact our service staff. The contact
details can be found at www.musicstore.de
Environmental protection:
The company MUSIC STORE professional GmbH always strives to reduce the burden of packaging
to a minimum. The use of environmentally friendly and recyclable materials is always of
elementary importance. Please complete the packaging after use to the appropriate recyclings.
Disposal of packaging:
Ensure that paper packaging, plastic material, etc. are recycled separately. Observe the
labels and the corresponding regulations.
Disposal of batteries:
Batteries do not belong in the garbage! Please dispose of batteries in accordance with
official regulations at collection points or disposal stations.
Disposal of your old device:
This device is subject to the WEEE directive (Waste Electrical and Electronic Equipment)
in its currently valid form. The device must not be disposed of with normal household
waste.
The device must be disposed of by an approved disposal company or by the responsible
municipal disposal office. The regulations applicable in your country must be observed!
Symptom
Troubleshooting
No sound
Check the enclosed mains connection and your
fuse.
Check the wiring. Connectors must be fully
inserted and snap into place!
Slowly increase the volume with the volume
controller.

ENGLISH
MS ID: REC0007048-000
09/2018
