Parts Manual for
REAR ENGINE RIDER
SERIES 22
MODELS
280922B
W280922B
281022BE
281222BE
300922B
301022BE
W301022BE
301222BE
3314522BVE
331522KVE
IT IS THE POLICY OF SNAPPER TO IMPROVE ITS PRODUCTS WHENEVER IT IS POSSIBLE
AND PRACTICAL TO DO SO. WE RESERVE THE RIGHT TO MAKE CHANGES OR ADD
IMPROVEMENTS AT ANY TIME WITHOUT INCURRING ANY OBLIGATION TO MAKE SUCH
CHANGES ON PRODUCTS MANUFACTURED PREVIOUSLY.
COPYRIGHT © 2002
SNAPPER INC.
ALL RIGHTS RESERVED
(Rev. 1, 06/30/02) MANUAL No. 06128

2
CONTENTS
DESCRIPTION PAGE
WHEELS, FRONT........................................................................................................................ 3
WHEELS, REAR ....................................................................................................................4 & 5
FRONT END, STEERING ......................................................................................................6 & 7
MAIN CASE............................................................................................................................8 & 9
DIFFERENTIAL, R.H. FENDER ........................................................................................10 & 11
CHAIN CASE, L.H. FENDER .............................................................................................12 & 13
SMOOTH CLUTCH ASSEMBLY .......................................................................................14 & 15
CUTTING DECKS, DEFLECTORS ....................................................................................16 & 17
RAILS, LIFT ARMS, CAM LIFT .........................................................................................18 & 19
BLADE STOP PEDALS ............................................................................................................. 20
SPINDLE ASSEMBLY ............................................................................................................... 21
BELTS, BRAKES, INTERLOCK ........................................................................................22 & 23
DRIVE DISC ASSEMBLY .......................................................................................................... 24
FUEL TANK & OPERATOR’S SEAT......................................................................................... 25
ENGINES & EXHAUST MUFFLER............................................................................................ 26
THROTTLE CONTROL.............................................................................................................. 27
DECALS .............................................................................................................................28 & 29
ELECTRICAL SYSTEMS (For 9 HP Briggs, Recoil Start)...............................................30 & 31
ELECTRICAL SYSTEMS (For 10 & 12 HP Briggs)..........................................................32 & 33
ELECTRICAL SYSTEMS (For 14.5 HP Briggs)................................................................34 & 35
ELECTRICAL SYSTEMS (For 15 HP Kohler)...................................................................36 & 37
WIRING SCHEMATICS................................................................................................. 38 thru 41
HARDWARE BAGS ...................................................................................................................42
ACCESSORIES AND ATTACHMENTS ..................................................................................... 44
MANUAL No. 06128 R. E. RIDER SERIES 22

3
2, 2A
3
12
5
4
7
9
10
4
6
7
8
11
WHEELS - FRONT
ITEM PART NO. DESCRIPTION
1 5-8943 ASSEMBLY, Front Tire & Rim (Complete)
(Includes Items 2, 3, 4, 5 & 6, )
2 7-3563 TIRE, 11 x 4.00-4 (Kenda)
3 1-7146 RIM (For 4.10/3.50 x 4 Tire)
4 1-1807 BEARING, Ball
5 1-2234 VALVE, Air (Snap-in)
6 1-4669 FITTING Lube
7 1-0935 WASHER, 3/4” I.D.
8 1-1022 CAP, Hub
9 1-1032 SEAL, Felt
10 3-1038 CAP, Dust
11 9-1516 PIN, Cotter 5/32 x 1" (2)
12 1-0821 TUBE, Inner (For 4.10/3.50 x 4 Tire)
R. E. RIDER SERIES 22 MANUAL No. 06128
1 ASSEMBLY

4
6
WHEELS - REAR
LEFT HAND
RIGHT HAND
MANUAL No. 06128 R. E. RIDER SERIES 22
1 ASSEMBLY
7
15
9
13
10
2
13
12
14
11
5
8
34

5
WHEELS - REAR
ITEM PART NO. DESCRIPTION
1 5-8951 ASSEMBLY, Rear Tire & Rim (Includes Items 2, 3 & 4) (28", 30” 33” Models)
2 7-3584 TIRE, 16-6.50 x 8 (33" Models)
3 1-7147 RIM, Extra Wide, (For 16/7.50 x 8 Tire) (33" Models)
4 1-2234 VALVE, Air (Snap-in)
5 1-2332 CLAMP, Right Hand (8, 10 & 13 HP)
-- 1-4542 CLAMP, Right Hand (12, 14 & 15 HP)
6 9-1502 BOLT, 1/2-20 x 3/4" Lug (6)
7 3-1732 BOOT, Right Hand
8 1-1817 SEAL, Oil
9 4-0433 HUB, Rear Wheel R. H. (Weldment)
10 2-3895 CAP, Hub
11 2-3522 CAP, Hub (Left Hand)
12 4-0434 HUB, Rear Wheel L.H. (Weldment)
13 1-1201 NUT, 5/16-24 Hex Center Lock
14 1-1035 BOLT, 5/16-24 x 1-5/8" Tapered (Left Hand)
15 1-1013 BOLT, 5/16-24 x 2" Tapered (Right Hand)
R. E. RIDER SERIES 22 MANUAL No. 06128

6
FRONT END, STEERING
MANUAL No. 06128 R. E. RIDER SERIES 22
28
12
6
30
14
31
10
12
15
17
10
31
16
12
6
30
2138
39
37
36
35
5
34
33
26
27
7
9
12
40
20
21
8
20
11
41
25
13
22
4
29
31
10
19
18
3
23
32
24
45

7
42 43
44
FRONT END, STEERING
ITEM PART NO. DESCRIPTION
1 5-8030 STEERING WHEEL (for 5/8”
shaft) (includes item 2)
2 2-3781 LOGO, Steering Wheel
3 1-3862 PIN, 1/4" x 1-1/2" Roll
4 3-8243 LATCH, Parking Brake
5 2-2449 CABLE, Clutch/Brake(54.32”)
(for 28” & 30” Decks)
-- 7-4131 CABLE, Clutch (55” long)
(for 33” & 42” Decks)
6 9-0122 WASHER, 3/8 Flat (2)
7 1-1815 PAD, Clutch/Brake Pedal
8 1-0694 BUSHING, Nylon
9 4-7888 PEDAL, Clutch/Brake (weldment)
10 1-0986 BEARING, Nylon (4)
11 4-6232 SHAFT, Steering (weldment)
12 1-3321 BUSHING, Tie-Rod (4)
13 1-3023 TIE-ROD, Left Hand (7.41” long)
-- 1-2541 TIE-ROD, Left Hand (9.91” long)
14 4-1687 KING-PIN Weldment, Left Hand
15 1-2933 TIE-ROD, R. H. (7.41” long)
-- 1-2540 TIE-ROD, R. H. (9.91” long)
16 4-1688 KING-PIN, Weldment Right Hand
17 5-8040 WELDMENT, Front Axle, Narrow
(28” & 30” Deck)
-- 5-9197 WELDMENT, Front Axle, Wide
(33” Deck)
18 1-4049 FOOT PAD, Short (2)
-- 1-4048 FOOT PAD, Long (2)
ITEM PART NO. DESCRIPTION
19 1-5444 SPRING, Parking Brake
20 9-0183 WASHER, 21/32 I. Dia.(2)
21 4-6158 BUSHING, Nylon (2)
22 1-1714 PIN, Hair
23 2-3667 FOAM COVER, Steering Shaft
24 9-0296 PIN, 3/16 x 1" Cotter
25 9-1514 WASHER, 3/8” Flat (2)
26 1-2867 PIN, Hair (.125” Dia. Wire)
27 2-2881 SPACER, 1/2" (5)
28 1-0776 RING, 1/2” External Retaining
(Heavy Duty)
29 1-0746 RING, 3/4” Ext. Retaining (2)
30 9-0365 PIN, 1/8 x 3/4" Cotter (2)
31 1-0935 WASHER, 5/8 Flat (6)
32 2-3671 COVER, Steering Shaft
33 2-8395 SPACER, Pivot
34 2-8332 STUD, Shoulder (3/8-24 Thread)
35 9-0854 NUT, 3/8-24 Hex Nyloc
36 7-2648 CABLE, Brake (29” long)
37 3-4174 CONNECTOR, Cable (2)
38 9-1495 SCREW, 1/4-20 x 3/4", Gr. 5
39 9-0372 NUT, 1/4-20 Hex Center Lock
40 9-0753 PIN, 3/16" x 1-1/2" Cotter
41 9-0364 PIN, 5/32” x 1” Cotter (2)
42 7-4560 HOLDER, Wire- Bottle
43 9-0913 SCREW, #10-24 x 1/2”
Hex Washer Self-Tap (2)
44 7-4561 BOTTLE, Water
45 7-4599 PLATE, Thrust
R. E. RIDER SERIES 22 MANUAL No. 06128

8
MAIN CASE
MANUAL No. 06128 R. E. RIDER SERIES 22
6
10
12
8
38
19
39
21
37
29
29
32
33
29
CONNECTS TO ITEM 15
ON PAGE 9
31
35
30
23
7
4A
53
50
13
9
34
2A
42
4C
22
5
34
53
52
36
50
53
49
121
38
39
19
48
47
35
53
50
11
50
31
36
51
50
2B
3
*
* NOTE: The heads of these fasteners are located
underneath the main case.
*53
50
31
36

9
MAIN CASE
ITEM PART NO. DESCRIPTION
1 5-8044 WELDMENT, Main Case
-- 5-9202* WELDMENT, Main Case
2A 3-0798 BUMPER, Rear (2)
2B 3-6367 BUMPER (1-piece) (33” Deck)
3 3-7285 FENDER, Left Hand
4A 3-6419* GUIDE, Belt
4B 1-7653 GUIDE, Belt (not shown)
4C 3-6418** GUIDE, Belt
5 4-7189 BRACKET, Drive Support
6 9-0595 BOLT, 5/16-18 X 3/4" Hex
Flange Lock, Grade 5 (2)
7 1-0153 CAP, Bumper (2)
8 9-0585 NUT, 5/16-18 Hex Fl. Lock (6)
9 1-0969 NUT, 5/16-24 Hex Flange Lock
10 2-3676 LINK, Shift (Long)
11 4-1384 ARM, Shift
12 3-3799 BRACE, Cross
13 1-1018 LINK, Shift (Short)
14 9-0196 NUT, 5/16-18 Hex, Gr. 5 or B
15 4-0598 ARM, Shift Handle (weldment)
16 1-0754 SPRING, Shift Handle
17 5-8763 ASSEMBLY, Shift Detent
(Incl. Spring, part no. 2-6292)
18 5-9212 HANDLE, Shift (weldment)
19 9-1503 HAIRPIN, 3/32 X 1-1/2" (2)
20 2-3656 GRIP, Shift Handle
21 3-4299 WING, Rear (2)
22 2-2509 BUSHING, Pilot
23 7-3735 BRACKET, Switch
24 9-0037 PIN, 3/32 x 3/4" Cotter
25 2-3914 PIN, 1/4 x 1-3/4" Tapered Clevis
26 1-9245 BUSHING, Nylon
27 3-1036 WASHER, Thrust (2)
ITEM PART NO. DESCRIPTION
28 1-9246 BUSHING, Nylon (2)
29 9-0361 SCREW, 5/16-18 x 5/8" Self
Tap (14)
30 9-0981 SCREW, #10-32 x 1/4" Hex
Washer Self-Tap (2)
31 9-1296 WASHER, 5/16" Flat (4)
32 1-2652 CLIP, Wire
33 9-0391 WASHER, 5/16”Internal Tooth
Lock
34 9-0484 SCREW, 5/16-18 x 1-1/2" (4)
35 9-1513 SCREW, 5/16-24 x 1-1/2" Hex
Head Cap, Grade 5 (4)
36 1-1791 RETAINER, 5/16 Bolt (4)
37 9-0206 SCREW, 5/16-18 x 3/4" Cap
38 9-0793 SCREW, 5/16-18 X 3/4" Hex
Self-Tap (4)
39 2-8200 SWIVEL (2)
40 2-8989 COVER, Switch (series 19 & earlier)
-- 7-3268 COVER, Solenoid (series 20 & later)
41 2-8990 COVER, Battery
42 9-1272 FASTENER, 1/4” Ratchet (7)
43 1-5761 BOLT, 5/16-18 Shoulder
44 7-3289 LEVER, Over-Ride
45 9-1595 WASHER, 7/16” Flat
46 9-1298 NUT, 5/16-18 Nyloc
47 2-2486 OIL DRAIN, Short
48 2-7972 ASSEMBLY, Oil Valve
49 7-4190 PLATE, Engine (Kohler engine)
50 9-1315 WASHER, 5/16” Split Lock (8)
51 7-7692 BOLT, M8-1.25 x 25mm, Self-
Tap (Kohler)
52 9-0238 SCREW, 5/16-24 x 1” Gr. 5 (4)
53 9-1297 NUT, 5/16-24 Hex, Grade 5 (8)
R. E. RIDER SERIES 22 MANUAL No. 06128
*331522KVE Model only **3314522BVE Model only
50
29
27
26
25
24
40
18
SPRING (2-6292)
PART OF ITEM 17
20
27
16
43
44
45
46
14
17
53
41
28 15

10
DIFFERENTIAL, R. H. FENDER
MANUAL No. 06128 R. E. RIDER SERIES 22
17
1
29
16
16
18
19
20
35
33
14
13
11
28
27
12
31
30
9
10
3
2132
27
28
15
6
7
23
22
8
6
25
26
4
34
5
2A
24 2
