Snapper RD2140 (2690774) User manual

Parts Manual fo
r
LAWN TRACTOR ELECTRIC CLUTCH
LT300 SERIES
HYDRO DRIVE 4WD RMO & ACS "RD"
Revision IR, TP 400-5419-IR-TC-N10/15/2008
Briggs & Stratton Yard Power Products Group
Manual No. 7006271
535 Macon Road
McDonough, GA, 30253 U.S.A.
800-935-2967
MODEL
RD2140 (2690774)

Table Of Content
s
TP 400-5419-IR-TC-N
LAWN TRACTOR ELECTRIC CLUTCH
LT300 SERIES 3
Manual No. 7006271
PAGE GROUP
4Wheels & Tires Group
6Hood, Grille & Dash Group
8Steering Group - Power Steering
10 Frame & Front Axle Group - 4WD
14 Controls Group
18 Cruise Control Group
20 Transmission Group - Tuff Torq K-4664
24 Seat Deck & Fuel Tank Group
26 Engine & Electric Clutch Group - 21HP Briggs & Stratton, Vanguard
28 Decals Group
30 40" Mower Deck - Housing, Arbors & Blade
32 40" Mower Deck - Belt, Idle Arm & Hitch
34 40" Mower Deck - Height Adjustment & Roller Bar
38 Hopper Group
42 Electrical Group

TP 400-5419-IR-TC-N
Manual No. 7006271 LAWN TRACTOR ELECTRIC CLUTCH
LT300 SERIES
4

Wheels & Tires Group
Footnotes:
TP 400-5419-IR-TC-N
Manual No. 7006271LAWN TRACTOR ELECTRIC CLUTCH
LT300 SERIES 5
Part No Descri
p
tionItem Qt
y
Note
1 1732202 2 WHEEL & TIRE ASSEMBLY, Front (Includes Ref. Nos. 2, 3, 4, 5)
2 1733882 1 TIRE, 15 x 6, Super Turf
3 1664090 1 TUBE, Tire, Front, 4.10/3.50
4 1717056 2 BEARING, Ball
5 1722837 1 WHEEL, 4-1/2” x 6”
6 2172353 4 VALVE STEM & CAP ASSEMBLY
7 1722726A 4 WASHER, Special, (As Required)
8 1919394 4 WASHER, 1, (As Required)
9 2832577 2 RING, Retaining, External #98
10 1722676 4 CAP, Hub, Gray
11 1729279 2 KEY, Parellel, 3/16 x 3/16 x 1-1/2
12 2960202 4 WASHER, 3/4
13 1709527 2 SPACER
14 1732203 2 WHEEL & TIRE ASSEMBLY (Includes Ref. Nos. 6, 15, 16 &
17)
15 1733881 1 TIRE, 20 x 10, 8 Super Turf
16 2173477 1 TUBE, Tire, 20 x 8, Rear
17 1722835 1 WHEEL, 7 x 7.96, W/ 3/4 OD Shaft
18 1722717A 2 WASHER, Special
19 1960114 2 WASHER, 3/4
20 2827794 2 RING, “E” External

Hood, Grille & Dash Group
TP 400-5419-IR-TC-N
Manual No. 7006271 LAWN TRACTOR ELECTRIC CLUTCH
LT300 SERIES
6

Hood, Grille & Dash Group
Footnotes:
TP 400-5419-IR-TC-N
Manual No. 7006271LAWN TRACTOR ELECTRIC CLUTCH
LT300 SERIES 7
Part No Descri
p
tionItem Qt
y
Note
1 1728031D 1 HOOD, W/Scoop
4 1721804D 1 PANEL, R.H. Side
5 1721803D 1 PANEL, L.H. Side
6 1721810 1 HEADLIGHT ASSEMBLY (Includes Ref. Nos. 22, 23 & 24)
7 1721802D 1 GRILLE
8 1930641 12 NUT, Hex Flange 1/4-20 Whiz Lock
9 1726827 1 DASHBOARD (Used only on YT & LT models)
10 1726894 1 DASHBOARD, W/Hydraulic Lift Slot (Used only on GT models)
12 1721808A 1 HINGE, Hood L.H.
13 1721809A 1 HINGE, Hood R.H.
14 1723123 1 ROD, Dash Support
15 1933896 1 NUT, Hex Lock 10-24 w/Nylon Insert
16 1960392 1 SCREW, Pan Head Phillips #10-24 x 1
17 1960295 12 SCREW, Hex Whiz Lock Flange 1/4-20 x 5/8
18 1733457A 1 DUCT, Air Inlet
19 1726895 1 DASHBOARD, w/Buzzer Hole (Used only on Barons models)
20 1722285 1 COVER, Dash (Used only on Barons models)
21 1722607 1 SCREW, Pan Head Torx #8-16 x 1/2 Plastite (Used only on Barons models)
22 1677371 4 BULB, Headlight
23 1723451 4 SOCKET ASSEMBLY, Seal
24 1722902 1 REFLECTOR, Headlight

Steering Group - Power Steering
TP 400-5419-IR-TC-N
Manual No. 7006271 LAWN TRACTOR ELECTRIC CLUTCH
LT300 SERIES
8

Steering Group - Power Steering
Footnotes:
TP 400-5419-IR-TC-N
Manual No. 7006271LAWN TRACTOR ELECTRIC CLUTCH
LT300 SERIES 9
Part No Descri
p
tionItem Qt
y
Note
1 1733363 1 STEERING WHEEL
4 1724685A 1 PLATE, Steering Mounting
5 1960655 2 CARRIAGE BOLT, 5/16-18 x 1-1/4 G5
6 1725294 1 ADAPTER, Tilt
7 1723898 2 SPACER
8 1933988 2 NUT, Push Pal
9 1960636 2 NUT, Hex Keps 5/16-18
10 1733790 1 STEERING UNIT, Tilt
11 1686970 1 BELLOWS, Tilt Steering Unit w/Slot
12 1725024 1 CAP, Steering Wheel
13 1716518 2 DECAL, Power Steering
15 1960576 1 NUT, Hex Lock ESNA Light 5/8-18

Frame & Front Axle Group - 4WD
TP 400-5419-IR-TC-N
Manual No. 7006271 LAWN TRACTOR ELECTRIC CLUTCH
LT300 SERIES
10

Frame & Front Axle Group - 4WD
Footnotes:
TP 400-5419-IR-TC-N
Manual No. 7006271LAWN TRACTOR ELECTRIC CLUTCH
LT300 SERIES 11
Part No Descri
p
tionItem Qt
y
Note
1 1734731A 1 FRAME ASSEMBLY, Front & Rear 4WD
2 1733139A 1 TOWER & SUPPORT ASSEMBLY
3 1723528A 1 SUPPORT, Seat Deck
4 1722602A 1 SUPPORT, Drawbar
5 1733918A 1 BRACKET ASSEMBLY, Steering 4WD
6 1721805A 1 BUMPER, 4GA
7 1733480 1 AXLE ASSEMBLY, Front
8 1734241A 1 PIVOT ASSEMBLY, Axle w/Bushings
9 1960755 1 CAPSCREW, Hex Head, 5/8-11 x 2-1/2 G5
12 1931348 2 CARRIAGE BOLT, 3/9-16 x 3/4 G5
13 1702779 1 JOINT, Ball 1/2-20
14 1708236 1 SPACER
15 1919262 1 NUT, Hex Jam, 1/2-20
16 2860681 1 NUT, Hex, 3/8-16
18 1733166A 1 BRACKET, Cylinder Mounting
20 2172914 1 SPACER
21 1737058 1 CYLINDER, Hydraulic Steering
22 197487 3 CAPSCREW, Hex Head, M12-1-3/4 x 35
23 1733863 1 SHAFT & BRACKET ASSEMBLY, Axle Pivot
24 1960035 2 WASHER, 5/8
25 1734511A 1 STOP, "L" Steering
26 1664847 4 SCREW, Hex Washer Head Taptite, 5/16-18 x 3/4
27 2860646 2 NUT, Hex Flange 5/8-11 Two-Way Lock
28 1923683 4 SCREW, Hex Washer head, Taptite, 3/8-16 x 3/4
31 1923114 2 CAPSCREW, Hex 1/2-13 x 1
30 1928352 4 NUT, Hex Flange 3/8-16 Whiz Lock
32 1921210 2 CAPSCREW, Hex 3/8-16 x 1
33 1960086 4 SCREW, Truss Head Torx Drive 5/16-18 x 7/8
34 1733581 2 PIN, Dowel
35 1960170 3 WASHER, 1/2
36 1916966 3 LOCKWASHER, Spring
38 1960754 6 LOCKWASHER, Spring
39 1950036 6 CAPSCREW, Hex Head
40 1667812 1 SPACER, Powdered Metal
41 1733403 2 FITTING, Hose Elbow, 45 Degrees, 13/16-16 x 3/4-16
42 1737062 1 HOSE ASSEMBLY, Hydraulic
43 1737063 1 HOSE ASSEMBLY, Hydraulic
44 1733501A 1 BRACKET, Hose Mounting 10GA

Frame & Front Axle Group - 4WD
TP 400-5419-IR-TC-N
Manual No. 7006271 LAWN TRACTOR ELECTRIC CLUTCH
LT300 SERIES
12

Frame & Front Axle Group - 4WD
Footnotes:
TP 400-5419-IR-TC-N
Manual No. 7006271LAWN TRACTOR ELECTRIC CLUTCH
LT300 SERIES 13
Part No Descri
p
tionItem Qt
y
Note
45 1733402 2 FITTING, Bulkhead Union 13/16-16
46 1931333 2 CARRIAGE BOLT, 5/16-18 x 3/4 G5
47 1960636 2 NUT, Hex KEPS, 5/16-18
48 1733947 2 NUT, Jam 13/16-16
49 1960103 1 WASHER, 3/8
50 1931355 1 CARRIAGE BOLT, 3/8-16 x 2-1/4 G5
51 1733044A 1 SUPPORT, Steering Unit 7GA
52 1924856 4 SCREW, Hex Washer Head Taptite 5/16-18 x 1/2
53 1723866 1 NUT, Push 3/8

Controls Group
TP 400-5419-IR-TC-N
Manual No. 7006271 LAWN TRACTOR ELECTRIC CLUTCH
LT300 SERIES
14

Controls Group
Footnotes:
TP 400-5419-IR-TC-N
Manual No. 7006271LAWN TRACTOR ELECTRIC CLUTCH
LT300 SERIES 15
Part No Descri
p
tionItem Qt
y
Note
1 1721353 1 ROD, Brake
2 1721891 1 KNOB, Push On, Red
3 1930591 1 CAPSCREW, Hex Head Flange Lock, 5/16-18 x 3/4
4 1960687 3 NUT, Hex Flange, 3/8-16 ESNA
5 1721134 1 PULLEY ASSEMBLY, 3 OD, W/Bearing
6 1667811 2 SPACER
7 1922755 3 WASHER, 3/8
8 1710545 1 PULLEY, Idler 4 OD
9 1960315 2 CARRIAGE BOLT, 3/8-16 x 2 G5
10 1663114 2 BUSHING
11 1727370 1 ARM & HUB ASSEMBLY, Idler
12 1733844 1 SPRING, Extension
13 1960020 1 WASHER, 5/8
14 1924366 1 WASHER, 5/8
15 1704420 1 RING, Clipring
16 1704314 1 FITTING, Lube, 1/4 Ball Check
17 1710539 1 PULLEY, Idler 3-1/4 OD
18 1960315 1 CARRIAGE BOLT, 3/8-16 x 2 G5
19 1918447 1 PIN, Cotter
20 1924940 1 WASHER
21 1727408 1 ROD, Brake (Flat Ends)
22 1722460 1 PIN, Quick
23 1919326 1 WASHER
24 1721354A 1 LATCH, Brake
25 1726763 1 CONTROL ASSEMBLY, Foot Pedal
26 1721995 1 SPRING, Extension
27 1686612 1 CAM, Roller
28 1920397 1 NUT, Hex Lock ESNA, 1/4-20
29 1960636 8 NUT, Hex KEPS, 5/16-18
30 1931320 1 CARRIAGE BOLT, 1/4-20 x 1-1/4
31 1664847 3 CAPSCREW, Hex head Washer Taptite, 5/16-18 x 3/4
32 1919381 1 WASHER
33 1919438 1 NUT, Hex Lock ESNA, 5/16-18
34 1927557 3 NUT, Hex Flange Lock, 5/16-18
35 1722535A 1 PEDAL, Brake
36 1721577 1 PAD, Brake Pedal
37 1931334 4 CARRIAGE BOLT, 5/16-18 x 7/8

Controls Group
TP 400-5419-IR-TC-N
Manual No. 7006271 LAWN TRACTOR ELECTRIC CLUTCH
LT300 SERIES
16

Controls Group
Footnotes:
TP 400-5419-IR-TC-N
Manual No. 7006271LAWN TRACTOR ELECTRIC CLUTCH
LT300 SERIES 17
Part No Descri
p
tionItem Qt
y
Note
38 1722083A 1 ACTUATOR, Switch
39 1921333 3 CAPSCREW, Hex Head, 5/16-18 x 1
40 1722070A 1 PEDAL, Forward
41 1721675 1 PAD, Foot Pedal Forward
42 1721674 1 PAD, Foot Pedal Reverse
43 1722071A 1 PEDAL, Reverse
44 1931333 4 CARRIAGE BOLT, 5/16-18 x 3/4
45 1931348 1 CARRIAGE BOLT, 3/8-16 x 3/4
46 1726087A 1 SUPPORT, Idler

Cruise Control Group
TP 400-5419-IR-TC-N
Manual No. 7006271 LAWN TRACTOR ELECTRIC CLUTCH
LT300 SERIES
18

Cruise Control Group
Footnotes:
TP 400-5419-IR-TC-N
Manual No. 7006271LAWN TRACTOR ELECTRIC CLUTCH
LT300 SERIES 19
Part No Descri
p
tionItem Qt
y
Note
1 1960666 1 CAPSCREW, Torx Socket Head, 1/4-20 x 7/8
2 1722303 1 KNOB, Cruise
3 1920397 1 NUT, Hex ESNA Lock, 1/4-20
4 1723258 1 LEVER & BRACKET ASSEMBLY, Cruise
5 1960103 3 WASHER
6 1931333 1 CARRIAGE BOLT, 5/16-18 x 3/4
7 926192 2 WASHER, 9/16 x 1-1/4 x 1/8
8 1709043 1 SPACER
9 1931342 1 CARRIAGE BOLT, 5/16-18 x 2-3/4
10 1960273 1 CARRIAGE BOLT, 5/16-18 x 2-1/4
11 1918447 2 PIN, Cotter
12 1726059 1 ROD, Cruise
13 1960636 2 NUT, Hex KEPS, 5/16-18
14 1960001 2 CAPSCREW, Hex Head Plastite, 10-14 x 5/8
15 1717050 1 SWITCH, Push, Neutral Start, Gray
16 1722080 1 SPACER
17 1919326 1 WASHER
18 1919381 2 WASHER
19 1919438 1 NUT, Hex ESNA Lock, 5/16-18
20 1677746 1 SPRING, Compression
21 1722460 2 PIN, Quick
22 1723099 1 ROD, Cruise Return

Transmission Group - Tuff Torq K-4664
TP 400-5419-IR-TC-N
Manual No. 7006271 LAWN TRACTOR ELECTRIC CLUTCH
LT300 SERIES
20
