Snapper 7800165 User manual

Not for
Reproduction
Parts Manual fo
r
Revision: E
2
2" STEEL DECK WALK BEHIND MOWERS
3/25/2011
Briggs & Stratton Yard Power Products Group
535 Macon Road
McDonough, GA, 30253 U.S.A.
800-935-2967 Manual No. 7006258
Descri
p
tionModel No.
780041
8
NS2265
780022
8
NS2265
7800607 NS22675
7800419 NSP2265
7800229 NSP2265
780060
8
NSP22675
7800189 S2265
7800604 S22675
7800165 SP2265
7800605 SP22675

Not for
Reproduction

Not for
Reproduction
Table Of Content
s
22" STEEL DECK WALK BEHIND MOWERS
3
Manual No. 7006258
PAGE GROUP
4Handles & Controls (Push)
6Handles & Controls (Self-Propelled)
8Deck Assembly (Push)
10 Deck Assemby (Self-Propelled)
12 Engine, Blade & Front Cover
14 Height-of-Cut Assemblies
16 Decals

Not for
Reproduction
22" STEEL DECK WALK BEHIND MOWERS
4
Manual No. 7006258
Handles & Controls (Push)

Not for
Reproduction
Footnotes:
Manual No. 700625822" STEEL DECK WALK BEHIND MOWERS
5
Handles & Controls (Push)
Part No Descri
p
tionItem Qty
1 7101405 1 UPPER HANDLE, Plastic, Snapper Push
2 7101321BH 1 BAIL, Plastic Handle, WBM
3 7090015 2 BOLT, 1/4-20 x 1-3/4” Round Head Square Neck, GR 2, YZ
4 2860694 3 NUT, 1/4-20, Hex Flange (Esna) YZ
5 7300649BH 2 HANDLE, Connecting, 21”/22” WBM
6 7101410 1 ROPE GUIDE (1/4-20 thread)
7 7035744 2 KNOB, 5/16-18 Wing (5/16-18 thread) (Black)
8 7091189 2 BOLT, 5/16-18 x 2” Curved Head Square Neck, GR 2
9 7090391 2 WASHER, 5/16” Internal Tooth Lock
10 7300628BH 1 HANDLE, Lower, 22” WBM
11 7101395 1 CABLE, Bail, 22” WBM
12 7101202 2 KNOB, Quick Release
13 7101199 2 BUSHING, Handle Pin
14 7101200 2 SPRING, Compression
15 7101198 2 PIN, Handle Adjust
16 7090958 2 BOLT, 5/16-18 x 1-1/2” Round Head Short Square Neck, GR 5 or 7091303
17 7090951 2 NUT, 5/16-18 Large Flange Center Lock
18 7102573 1 GRASS BAG, 22” Rear Discharge replaces 7101246
19 7101230A 1 BAG FRAME, 22” WBM (Weldment)
20 7024649 3 WIRE TIE,11” Standard Black Nylon
21 7026421 1 GRIP, Rectangular (Black)

Not for
Reproduction
22" STEEL DECK WALK BEHIND MOWERS
6
Manual No. 7006258
Handles & Controls (Self-Propelled)

Not for
Reproduction
Footnotes:
Manual No. 700625822" STEEL DECK WALK BEHIND MOWERS
7
Handles & Controls (Self-Propelled)
Part No Descri
p
tionItem Qty
1 7101312 1 UPPER HANDLE, Plastic, WBM
2 7101417 1 ASSY, Control Head, 22” WBM, Single Speed (incl.Clutch Lever, Box, & Drive Cable)
3 7101321BH 1 BAIL, Plastic Handle, WBM
4 7090015 2 BOLT, 1/4-20 x 1-3/4” Round Head Square Neck, GR 2, YZ
5 2860694 3 NUT, 1/4-20, Hex Flange (Nyloc) YZ
6 7300670A 1 PLATE, Control Panel
7 95050 4 SCREW, #8-16 x 5/8” Recessed Pan Head Twin Helix (Torx) or 7100225
8 7300649BH 2 HANDLE, Connecting, 21”/22” WBM
9 7101410 1 GUIDE, Rope (1/4-20 thread)
10 7035744 2 KNOB, 5/16-18 Wing (5/16-18 thread) (Black)
11 7091189 2 BOLT, 5/16-18 x 2” Curved Head Square Neck, GR 2
12 7090391 2 WASHER, 5/16” Internal Tooth Lock
13 7300628BH 1 HANDLE, Lower, 22” WBM
14 7101395 1 CABLE, Bail, 22” WBM
15 7101202 2 KNOB, Quick Release
16 7101199 2 BUSHING, Handle Pin
17 7101200 2 SPRING, Compression
18 7101198 2 PIN, Handle Adjust
19 7090958 2 BOLT, 5/16-18 x 1-1/2” Round Head Short Square Neck, GR 5 or 7091303
20 7090951 2 NUT, 5/16-18 Large Flange Center Lock
21 7102573 1 GRASS BAG, 22” Rear Discharge or 7101246
22 7101230A 1 BAG FRAME, 22” WBM (Weldment)
23 7026421 1 GRIP, Rectangular (Black)
24 7024649 3 WIRE TIE, 11” Standard Black Nylon

Not for
Reproduction
22" STEEL DECK WALK BEHIND MOWERS
8
Manual No. 7006258
Deck Assembly (Push)

Not for
Reproduction
Footnotes:
Manual No. 700625822" STEEL DECK WALK BEHIND MOWERS
9
Deck Assembly (Push)
Part No Descri
p
tionItem Qty
1 7300401D 1 DECK, 22” Walk
2 7900067 3 SCREW, 1/4-20 x 11/16” Pan Head Self-Tap (Torx) or 722848
3 7091020 4 PUSHNUT, 1/4”
4 7300855D 1 BRACKET, Chute
5 7300856D 1 PLATE, Mulch, 22” RB Scott's
6 722507 1 SPRING, Chute (Torsion)
7 7101067 1 ROD, Pivot (1/4” Dia. x 5.55”)
8 721682 1 COVER, Mulch, Plastic, Black
9 721681 1 SIDE CHUTE, Plastic, Black
10 7103347 1 GUARD, Rear
11 7091286 4 SCREW, #10-24 x 1/2” Hex Washer Self-Tap (Sems)
12 7091619 4 NUT, 3/8-16 Hex Flange Lock, YZ
13 7501055 1 * ASSY, Height-Of-Cut, Left Rear, 22” WBM, Push & Propelled
14 7501056 1 * ASSY, Height-Of-Cut, Right Rear, 22” WBM, Push & Propelled
15 7501294 1 * ASSY, Height-Of-Cut, Left Front, 22” WBM, Push
16 7501293 1 * ASSY, Height-Of-Cut, Right Front, 22” WBM, Push
17 7100633 4 GRIP, Height Latch
18 7500540 4 ASSY, Wheel & Bearing, 8 x 2 Idle, DW Tread incl. two 1-1/8” O.D. Flanged Ball Bearings (p/n
7101380)
19 7300440D 1 BAFFLE, Front, 22” WBM
20 722604 4 WASHER, 1” O.D. x .387 I.D. Flat
21 7091585 4 NUT, 3/8-16 Hex Center Lock, YZ
22 7101350 4 HUBCAP, Black
23 7300854D 1 BAFFLE, Rear, 22” Deck or 725105
24 7101243 1 DOOR, 22” Rear
25 7101070 1 ROD, Pivot, Rear Door (1/4” Dia. X 17-1/2”)
26 7101461 1 SPRING, Torsion, Rear Door, 22” WBM
27 7300668BH 1 BRACKET, Lower Handle, RH, 22” WBM
28 7300669BH 1 BRACKET, Lower Handle, LH, 22” WBM
29 7091318 2 BOLT, 5/16-18 x 3/4” Hex Head Cap, GR5
30 7091601 2 NUT, 5/16-18 Flange Lock, YZ
Note: * This assembly is also shown on Height-of-Cut Assemblies page.

Not for
Reproduction
22" STEEL DECK WALK BEHIND MOWERS
10
Manual No. 7006258
Deck Assemby (Self-Propelled)

Not for
Reproduction
Footnotes:
Manual No. 700625822" STEEL DECK WALK BEHIND MOWERS
11
Deck Assemby (Self-Propelled)
Part No Descri
p
tionItem Qty
1 7300400D 1 DECK, 22” Walk, 3 N 1
2 7900067 3 SCREW, 1/4-20 x 11/16” Pan Head Self-Tap (Torx) or 722848
3 7091020 4 PUSHNUT 1/4”
4 7300855D 1 BRACKET, Chute or 726768
5 7300856D 1 PLATE, Mulch, 22” RB Scott's or 726766
6 722507 1 SPRING, Chute (Torsion)
7 7101067 1 ROD, Pivot (1/4” Dia. x 5.55”)
8 721682 1 COVER, Mulch, Plastic, Black
9 721681 1 SIDE CHUTE, Plastic, Black
10 7103347 1 GUARD, Rear or 721685
11 7091286 4 SCREW, #10-24 x 1/2” Hex Washer Self-Tap (Sems)
12 7091619 10 NUT, 3/8-16 Hex Flange Lock, YZ
13 7501055 1 * ASSY, Height-Of-Cut, Left Rear, 22” WBM
14 7501056 1 * ASSY, Height-Of-Cut, Right Rear, 22” WBM
15 7501058 1 * ASSY, Height-Of-Cut, LF, 22” WBM, Propelled
16 7501057 1 * ASSY, Height-Of-Cut, RF, 22” WBM, Propelled
17 7100633 4 GRIP, Height Latch
18 7500540 2 ASSY, Wheel & Bearing, 8 x 2 Idle, DW Tread incl. two 1-1/8” O.D. Flanged Ball Bearings (p/n
7101380)
19 7500542 2 ASSY, Drive Wheel & Bearing, 8 x 2, DW Tread incl. two 1-1/8” O.D. Flanged Ball Bearings (p/n
7101380)
20 722604 4 WASHER, 1” O.D. x .387 I.D. Flat
21 7091585 4 NUT, 3/8-16 Hex Center Lock, YZ
22 7101350 4 HUBCAP, Black
23 7102671 1 SPACER, .526" ID, .840" OD, .502" Wide (Was 720508)
24 7101243 1 DOOR, 22” Rear
25 7101070 1 ROD, Pivot, Rear Door (1/4” Dia. X 17-1/2”)
26 7101461 1 SPRING, Torsion, Rear Door, 22” WBM
27 7300668BH 1 BRACKET, Lower Handle, RH, 22” WBM
28 7300669BH 1 BRACKET, Lower Handle, LH, 22” WBM
29 7091811 2 BOLT, 5/16-18 x 5/8” Hex Flange Lock, YZ
30 7091601 3 NUT, 5/16-18 Flange Lock, YZ
31 7014341 4 RING, External Retaining (Waldes 5133-50)
32 7101207 2 GEAR, Pinion, 22” WBM, Front Wheel Drive
33 7101402 2 DUST SHIELD, Forward, 22” WBM
34 7900054 4 SCREW, 3/8-16 x 3/4” Hex Head Cap, GR 5, YZ
35 7101206 1 TRANSMISSION, 22” WBM Single Speed, Front Wheel Drive used on SP2265 & NSP22656
36 7101270 2 DRIVE PIN, 22” WBM, Front Wheel Drive
37 7300854D 1 BAFFLE, Rear, 22” Deck or 725105
38 7300440D 1 BAFFLE, Front, 22” WBM
39 722410 1 SPRING, Compression
Note: * This assembly is also shown on Height-of-Cut Assemblies page.

Not for
Reproduction
22" STEEL DECK WALK BEHIND MOWERS
12
Manual No. 7006258
Engine, Blade & Front Cover

Not for
Reproduction
Footnotes:
Manual No. 700625822" STEEL DECK WALK BEHIND MOWERS
13
Engine, Blade & Front Cove
r
Part No Descri
p
tionItem Qty
1 7100851 1 BLADE, 22”, Walk Mower
2 7101449 1 ASSEMBLY, Engine Spacer, 22” WBM, Self-Propelled Includes 7101209 (spacer) & 7101448
(3) (bushings)
3 7101195 1 FRONT DECK COVER, 22” Front Wheel Drive
4 7101310 1 FRONT DECK COVER, Rear Discharge WBM
5 7900018 2 SCREW, 4.8 x 1.59 x 13mm, Round Washer Head Hi-Lo (Torx)
6 720351 3 BOLT, 3/8-16 NS x 2-1/2”
7 7090324 3 SCREW, 3/8-16 x 1” Hex Washer Self-Tap
8 7100763 1 PULLEY, Engine, 22” Deck, Single Speed
9 722884 1 SCREW, #8-11 x 5/8” Poly
10 7101193 1 ** BELT, Drive (3L Section, 33.75” effective length)
11 7100740 1 BLADE HUB, 22” Deck, Self Propelled
12 7100862 1 BLADE HUB, 22” Deck, Push
13 721890 1 WASHER, .38” I.D. x 1.183 O.D. Bellville
14 7090824 1 SCREW, 3/8-24 x 1-1/4” Hex Head Cap, GR 5 used on push models
15 720209 1 BOLT, 3/8-24 x 3-1/4” Hex Head, GR 8 used on self-propelled models
16 124T02-0650-B3 1 * ENGINE, B&S, 650 Series X-Spec (used on 7800165 & 7800189 models)
16 124L02-0650-F3 1 * ENGINE, B&S, 650 Series X-Spec (used on 7800228 & 7800229 models)
16 124L02-4650-F3 1 * ENGINE, B&S, 650 Series X-Spec (used on 7800418 & 7800419 models)
16 126T02-0675-B3 1 * ENGINE, B&S, 675 Series X-Spec (used on 7800604 model)
16 126T02-0675-B3 1 * ENGINE, B&S, 675 Series X-Spec (used on 7800605 model)
16 126L02-4675-F3 1 * ENGINE, B&S, 675 Series X-Spec (used on 7800607 & 7800608 models)
NOTE: * Purchase engine parts from engine manufacturer dealer.
NOTE: ** Part number appears on belt.

Not for
Reproduction
22" STEEL DECK WALK BEHIND MOWERS
14
Manual No. 7006258
Height-of-Cut Assemblies

Not for
Reproduction
Footnotes:
Manual No. 700625822" STEEL DECK WALK BEHIND MOWERS
15
Height-of-Cut Assemblies
Part No Descri
p
tionItem Qty
1 7501056 1 * ASSY, Height-Of-Cut, Right Rear, 22” WBM, Push & Propelled
2 7501055 1 * ASSY, Height-Of-Cut, Left Rear, 22” WBM, Push & Propelled
3 7501057 1 * ASSY, Height-Of-Cut, RF, 22” WBM, Propelled
4 7501058 1 * ASSY, Height-Of-Cut, LF, 22” WBM, Propelled
5 7501293 1 * ASSY, Height-Of-Cut, Right Front, 22” WBM, Push
6 7501294 1 * ASSY, Height-Of-Cut, Left Front, 22” WBM, Push
7 7091497 1 SCREW, 3/8-16 x 1-1/2” Hex Head Cap, GR 5, YZ
8 7900047 1 WASHER, .391 x 1” x 14 Ga. Flat
9 7900046 1 WASHER, .76 x 1.25 x .180 Flat
10 7101205 1 LEVER, Height-Of-Cut, 22” WBM
11 7500409 1 ASSY, Rear Axle, RH 22” WBM
12 7500408 1 ASSY, Rear Axle, LH 22” WBM
13 722611 1 WASHER, 1” I.D. x 1.64 O.D. Bellville
14 7300529 1 INDEX PLATE, Height-Of-Cut, Rear
15 721899 1 SPACER, Height Adjust
16 7013847 1 RETAINER, 3/8” Bolt
17 720118 1 RING, .906 I.D. x .078 Thick, External Retaining
18 7500404 1 ASSY, Front Axle 22”, Propelled
19 7101212 1 LEVER, Height-Of-Cut, 22” WBM
20 7300528 1 INDEX PLATE, Height-Of-Cut, Front Right, 22” WBM
21 7300527 1 INDEX PLATE, Height-Of-Cut, Front Left, 22” WBM
22 720685 1 RETAINER, Bearing
23 720761 1 BALL BEARING, 1/2 I.D. x 1-1/8” O. D. Flanged w/seal
24 7500476 1 ASSY, Front Axle, 22” WBM, Push
Note: * This assembly is also shown on Deck Assemby page.

Not for
Reproduction
22" STEEL DECK WALK BEHIND MOWERS
16
Manual No. 7006258
Decals

Not for
Reproduction
Footnotes:
Manual No. 700625822" STEEL DECK WALK BEHIND MOWERS
17
Decals
Part No Descri
p
tionItem Qty
1 7102153 1 DECAL, Briggs Engine, Snapper
2 7101537 1 DECAL, Front Cover, 22” Snapper, Push
3 7101538 1 DECAL, Front Cover, 22” Snapper, Front Wheel Drive
4 7102152 1 DECAL, Briggs Engine, 650 Series
5 7102151 1 DECAL, Briggs Engine, 675 Series
6 7102303 1 DECAL, Control Head, Single Speed, Snapper
7 7101394 1 DECAL, Warning, Rear Discharge Door
8 7102746 1 DECAL, Spark Arrestor
9 7102275 1 DECAL, Customer Service, MY08, Snapper
10 7013010 1 DECAL, Danger, Cut Finger

Not for
Reproduction

Not for
Reproduction

Not for
Reproduction
Parts Manual fo
r
22" STEEL DECK WALK BEHIND MOWERS
IT IS THE POLICY OF BRIGGS & STRATTON CORP. TO IMPROVE ITS
PRODUCTS WHENEVER IT IS POSSIBLE AND PRACTICAL TO DO SO.
WE RESERVE THE RIGHT TO MAKE CHANGES OR ADD
IMPROVEMENTS AT ANY TIME WITHOUT INCURRING ANY OBLIGATION
TO MAKE SUCH CHANGES ON PRODUCTS MANUFACTURED
Revision: E 3/25/2011
Manual No. 7006258
Copyright
©
2011
Milwaukee, WI USA. All Rights Reserved
Briggs & Stratton Corporation
www.sna
pp
er.com
Briggs & Stratton Yard Power Products Group
535 Macon Road
McDonough, GA, 30253 U.S.A.
800-935-2967
