Snapper 7800923-00 User manual

Not for
Reproduction
Parts Manual fo
r
21" STEEL DEC
K
WALK BEHIND MOWER
SINGLE SPEED FRONT WHEEL DRIV
E
Revision: - 1/17/2013
Briggs & Stratton Yard Power Products Group
Manual No. 7106030
535 Macon Road
McDonough, GA, 30253 U.S.A.
800-935-2967
Descri
p
tionModel No.
7800923-0
0
SP70

Not for
Reproduction

Not for
Reproduction
Table Of Content
s
TP 400-5535---WB-N
21" STEEL DECK
WALK BEHIND MOWER 3
Manual No. 7106030
PAGE GROUP
4Handle Group
6Deck Group
8Drive Group
10 Decals Group

Not for
Reproduction
Manual No. 7106030 21" STEEL DECK
WALK BEHIND MOWER
4
Handle Group

Not for
Reproduction
Footnotes:
Manual No. 710603021" STEEL DECK
WALK BEHIND MOWER 5
Handle Group
Part No Descri
p
tionItem Qty
4 703486 NUT, Square, 1/4-20
5 703530 HANDLE, Lower
6 703483 BOLT, Carriage, 5/16-18 x 1, GR5
24 703463 NUT, Flange Lock, 1/4-20
25 1101453MA KNOB, Wing, 5/16-18
36 703526 BAIL, Drive
37 703531 HANDLE, Upper
39 110122MA KNOB, 1/4-20
40 1701011SM TIE, Self Lock
41 703485 GUIDE, Rope
42 703564 CABLE, Control
43 703562 CABLE, Drive
44 703528 BAIL, Blade Control
45 703489 NUT, Wing
46 703522 BOLT, Shoulder, 1/4-20
62 703492 GRIP, Foam

Not for
Reproduction
Manual No. 7106030 21" STEEL DECK
WALK BEHIND MOWER
6
Deck Group

Not for
Reproduction
Footnotes:
Manual No. 710603021" STEEL DECK
WALK BEHIND MOWER 7
Deck Group
Part No Descri
p
tionItem Qty
1 703541 DECK, 21"
3 703482 SCREW, 5/16-14 x 3/4
12 703499 TRAILING SHIELD
14 703474 FRAME, Grass Bag
15 703384 GRASS BAG
16 703468 DOOR, Rear Discharge
17 703512 SPRING, Torsion, RH
18 703513 SPRING, Torsion, LH
20 B4300GS SCREW, 1/4-20 x 1/2
21 703515 SPRING, Compression
22 703508 COVER, Front
38 7091081SM SCREW, 1/4-15 x 3/4
47 703502 NOZZLE, Water
49 703501 SPRING BODY
51 703504 TRAY, Lower
53 703525 ROD, Pivot
56 703376 CHUTE, Side Discharge
57 703566 MULCH PLUG (Includes Ref. Nos. 58, 59 & 60)
58 703517 SPRING, Torsion
59 703529 PIN, Hinge
60 703538 BRACKET, Chute Deflector
61 703557 ADAPTER, Water Nozzle

Not for
Reproduction
Manual No. 7106030 21" STEEL DECK
WALK BEHIND MOWER
8
Drive Group

Not for
Reproduction
Footnotes:
Manual No. 710603021" STEEL DECK
WALK BEHIND MOWER 9
Drive Group
Part No Descri
p
tionItem Qty
2 703559 BEARING ASSEMBLY
7 703407 SCREW, 3/8-16 x 1
8 703790 ADAPTER, Blade
9 703371 BLADE, Mulching
10 703520 SUPPORT, Blade
11 01X142MA SCREW, 3/8-24 x 1-1/2
13 703514 WIRE, Transmission
19 703490 KNOB, Adjustment Lever
23 703539 CLIP, Front Axle
26 703547 AXLE ASSEMBLY, Front
27 703558 BAFFLE, Engine
28 703545 AXLE ASSEMBLY, Rear
29 703552 GEAR, 14T, RH
29A 703553 GEAR, 14T, LH (Not Illustrated)
30 703480 SCREW, 1/4-20 x .390
31 703556 TRANSMISSION
32 5025394SM NUT, Flange Lock, 3/8-16
33 703386 WHEEL, Front
34 703473 WHEEL, Rear
35 703487 PIN, Dowel
38 7091081SM SCREW, 1/4-15 x 3/4
50 703521 BOLT, Shoulder, 1/4-20 x 1/2
52 703373 V-BELT, 3L, 34.13, V-SPD
48 703500 COVER, Dust
54 703511 HUBCAP, Front, 8" Silver

Not for
Reproduction
Manual No. 7106030 21" STEEL DECK
WALK BEHIND MOWER
10
Decals Group

Not for
Reproduction
Footnotes:
Manual No. 710603021" STEEL DECK
WALK BEHIND MOWER 11
Decals Group
Part No Descri
p
tionItem Qty
1 703536 DECAL, Speed
2 703534 DECAL, Controls

Not for
Reproduction

Not for
Reproduction

Not for
Reproduction

Not for
Reproduction

Not for
Reproduction
Parts Manual fo
r
21" STEEL DECK
WALK BEHIND MOWER
IT IS THE POLICY OF BRIGGS & STRATTON CORP TO IMPROVE ITS
PRODUCTS WHENEVER IT IS POSSIBLE AND PRACTICAL TO DO SO.
WE RESERVE THE RIGHT TO MAKE CHANGES OR ADD
IMPROVEMENTS AT ANY TIME WITHOUT INCURRING ANY
OBLIGATION TO MAKE SUCH CHANGES ON PRODUCTS
SINGLE SPEED FRONT WHEEL DRIVE
Revision: - 1/17/2013
Manual No. 7106030
Copyright © 2013
Milwaukee, WI USA. All Rights Reserved
