Snapper ECLP21551HV User manual

Parts Manual for
21” ALUMINUM DECK
WALK BEHIND MOWER
COMMERCIAL
SERIES 1
MODEL
ECLP21601RV
ECLP21551HV
IT IS THE POLICY OF SNAPPER TO IMPROVE ITS PRODUCTS WHENEVER IT IS POSSIBLE
AND PRACTICAL TO DO SO. WE RESERVE THE RIGHT TO MAKE CHANGES OR ADD
IMPROVEMENTS AT ANY TIME WITHOUT INCURRING ANY OBLIGATION TO MAKE SUCH
CHANGES ON PRODUCTS MANUFACTURED PREVIOUSLY.
COPYRIGHT © 2003
SNAPPER PRODUCTS INC.
ALL RIGHTS RESERVED
(REV. 4, 06/04/03) MANUAL No. 06200

2
HANDLES & CONTROLS
MANUAL No. 06200 21” CAST ALUMINUM WBM SERIES 1
10
15
30
16
6
7
31
17
1
4
3
31
5
26
28
6 7
33
2
12
10
11
13
11
12
8
18
20
14
23
22
9
10
26 29
21
27
20
24
13
30
19
32
21
25
21
24

3
HANDLES & CONTROLS
ITEM PART NO. DESCRIPTION
1 2-8933 CONTROL, Blade/Engine
2 3-4786 HANDLE, Upper
3 9-1644 PIN, 5/16 x 1-23/32” Clevis
4 2-8815 CONTROL, Wheel Drive
5 9-1645 PIN, 5/16 x 1-7/16” Clevis
6 9-0555 COTTER-PIN, 3/32 x 1/2” (2)
7 9-1076 WASHER, 5/16” Flat (2)
8 9-1251 SCREW, 1/4-20 x 2-1/2” Hex Head Cap, Grade 5
9 2-2779 GUIDE, Pull Rope
10 7-6978 NUT, 1/4-20 Hex Nyloc (4)
11 9-1017 SCREW, #8-32 x 3/8” Fillister Head (2)
12 9-1018 NUT, #8-32 Hex (2)
13 2-3655 KNOB, Engine Speed Control & Ground Speed Control (2)
14 2-8887 CONTROL, Engine Speed (Robin 6HP engine)
-- 2-9083 CONTROL, Engine Speed (Honda 5-1/2 HP engine)
15 2-8886 CONTROL, Ground Speed
16 4-6524 CABLE, Blade/Engine Control (Robin engine)
-- 7-5224 CABLE, Blade/Engine Control (Honda engine)
17 2-9432 DECAL, Ground Drive
18 9-1267 NUT, #10-24 Hex Center Lock
19 9-1941 SCREW, #10-24 x 3/4” Pan Head Machine
20 9-1190 BOLT, 5/16-18 x 1-1/2” Curved Head Carriage (4)
21 9-1298 NUT, 5/16-18 Hex Nyloc (8)
22 9-0391 WASHER, 5/16” Internal Tooth Lock (4)
23 9-0188 WASHER, 11/32” Flat (4)
24 3-4848 BRACKET, Handlebar (2)
25 9-1075 SCREW, #10-24 x 5/8” Slotted Hex Washer Head, Self-Tap
26 7-9577 SCREW, 1/4-20 x 1-1/2” Hex Head Cap, Grade 5
27 2-4641 TIE, Wire (4)
28 2-9431 DECAL, Operator Presence Control
29 4-6518 CABLE, Wheel Drive Control
30 9-0505 SCREW, 1/4-20 x 2” Hex Head Cap, Grade 5 (2)
31 7-3821 COTTER PIN, Bow-Tie Locking (2)
32 9-1552 WASHER, 7/32" Flat
33 9-1702 WASHER, 3/16 Flat (2)
21” CAST ALUMINUM WBM SERIES 1 MANUAL No. 06200

4
CUTTING DECK, BLADE
21” CAST ALUMINUM WBM SERIES 1 MANUAL No. 06200
1
5
DECALS (see page 10)
A 4-6924
B 7-3462
C 2-9784
D 2-3009
E 4-6357
F 2-9779
G 7-2921
H 7-2098
I 2-9776
J 2-2841
K 2-8454
L 7-2820
M 2-9470
N 1-3010
24
39
36
37
20
9
10
12
3
15
21
13
40
25
35 34
33
31
32
17
2
30
28
29
27
18
41
22
23
19
38
26 7
6
4
8
11
16
26
7
14

5
CUTTING DECK, BLADE
ITEM PART NO. DESCRIPTION
1 5-2881 ASSEMBLY, Discharge Door (Commercial)
2 7-2143 GUIDE, Belt
3 9-0700 BOLT, 5/16-18 x 1-1/2” Hex Flange Lock, Grade 5
4 9-1696 SCREW, 1/4-20 x 5/8” Phillips Truss Head Machine Screw (4)
5 ** ENGINE, Robin 6.0 HP Model - EH18V
-- ** ENGINE, Honda 5.5HP Commercial, Model GXV160, Type K1A1ASE
6 6-1962 DECK, 21” Cast Aluminum Short (Red)
7 9-1603 NUT, 1/4-20 Hex Nyloc (6)
8 9-0324 SCREW, 3/8-16 x 1” Hex Washer Face Self-Tapping
9 3-4734 GUARD, Wear (2)
10 9-0585 NUT, 5/16-18 Hex Flange Lock, Grade 5
11 4-2999 BRACKET, R.H. Stiffener
-- 4-3790 BRACKET, L.H. Stiffener (not shown)
12 3-4692 PLATE, Height Adjustment
13 9-1819 SCREW, 1/4-20 x 5/8" Hex Washer Face Self-Tapping (2)
14 4-2988 SPACER, Stiffener (2)
15 9-0595 BOLT, 5/16-18 x 3/4” Hex Flange Lock, Grade 5
16 2-7230 SCREW, 1/4-20 x 1" Hex Head Cap, Grade 5 (2)
17 4-1736 SUPPORT, Front Bumper
18 9-0999 SCREW, 1/4-20 x 5/8” Truss Head (Torx) (4)
19 9-1201 SCREW, #10-24 x 1-1/2” Slotted Hex Washer Head, Self-Tapping
20 4-6506 COVER, Ground Speed Drive Belt
21 9-1711 BOLT, #10-24 x 5/8” Flat Head Carriage (2)
22 9-1075 SCREW, #10-24 x 5/8” Slotted Hex Washer Head, Self-Tapping (4)
23 4-1750 WELDMENT, Baffle
24 9-1892 NUT, 1/4” Push
25 3-3732 SUPPORT, Rear Axle (2)
26 9-0362 SCREW, 1/4-20 x 5/8” Hex Washer Head, Self-Tapping (6)
27 1-6755 KEY, 1/4” Square x 3/4" (for Robin engine) (2)
-- 1-0783 KEY, #505 Hi-Pro (for Honda engine)
28 2-2106 PULLEY, Traction Drive (for Robin engine)
-- 2-1822 PULLEY, Traction Drive (for Honda engine)
29 9-0201 SCREW, 5/16-18 x 5/16” Hex Socket Set
30 7-6979 NUT, 3/8-16 Hex Nyloc (2)
31 2-6631 HUB, Blade Drive, 25mm I.D. (for Robin engine)
-- 2-6630 HUB, Blade Drive, 7/8” I.D. (for Honda engine)
32 2-6428 BLADE, 21” Bagging
33 7-9268 WASHER, 3/8 Split Lock (Heavy)
34 9-0483 SCREW, 3/8-24 x 1-3/4” Hex Cap, Grade 5
35 9-0143 BOLT, 3/8-16 x 1-1/4” Hex Flange Lock (2)
36 9-1714 BOLT, 5/16-18 x 1” Round Head Carriage, Grade 5 (4)
37 9-1267 NUT, #10-24 Hex Center Lock (2)
38 9-0055 WASHER, 1/4 Flat (2)
39 4-3870 SHIELD, Trailing
40 4-3808 ROD, Trailing Shield Pivot (1/4” Diameter)
41 7-3293 PLUG, Hole (Polyethylene)
**PURCHASE ENGINE & ENGINE PARTS FROM ENGINE SERVICE OUTLETS.
21” CAST ALUMINUM WBM SERIES 1 MANUAL No. 06200

6
WHEELS, FRONT & REAR
MANUAL No. 06200 21” CAST ALUMINUM WBM SERIES 1
6
LONGER
WELD-STUD
TO THE FRONT
OF MOWER
SHORTER
WELD-STUD
TO THE REAR
OF MOWER
AXLE/TRANSMISSION
ASSEMBLY & PARTS LIST
SHOWN ON PAGES 8 & 9
1
13
3
5
12
4
7
2
9
8
10
11
6
6
6
6
11
11
11
10
8
2
4
3
13

7
WHEELS, FRONT & REAR
ITEM PART NO. DESCRIPPTION
1 2-9492 BELT, Traction Drive
2 7-4630 WHEEL, 9.0 x 2.0 (Rear Drive) (Includes item 3) (2)
3 7-3618 BUSHING, Wheel (2)
4 9-1593 COTTER-PIN, 3/8" Self Locking (2)
5 4-1744 WELDMENT, Tie Bar
6 9-1598 COTTER-PIN, 1/8" x 3/4" (6)
7 2-4751 SPRING, Tie Bar
8 2-4558 BUSHING, Front Axle (2)
9 4-1739 WELDMENT, Front Axle
10 4-2814 WHEEL, 8.0 x 2.0 (Front) (2)
11 9-1733 WASHER, 1/2" Flat (4)
12 4-6522 SPRING, Clutch (also shown on pages 8 & 9)
13 9-1194 WASHER, 17/32" (2) (also shown on pages 8 & 9)
21” CAST ALUMINUM WBM SERIES 1 MANUAL No. 06200

8
TRANSMISSION
MANUAL No. 06200 21” CAST ALUMINUM WBM SERIES 1
9
*Includes Bearing (P/N 2-4724)
and Bearing Carrier (P/N 2-4722).
4
28
4
5
7 8
20
3
26
27
25
24
21
22
5
6
8
20
10
8
19
13
12
2
9
10
29
30
31
32
14
23
1
8
19
13
11
15
16
17
18
12

9
TRANSMISSION
ITEM PART NO. DESCRIPTION
1 5-3898 AXLE/TRANSMISSION ASSEMBLY (Includes items 2 thru 19 & 24 thru 28)
2 2-8813 ASSEMBLY, Transmission 3-Speed Commercial
3 4-1738 WELDMENT, Rear Axle
4 2-4573 SHIELD, Dust (2)
5 2-4749 PIN, Pawl, 3/16 O.D. (2)
6 2-4549 PINION, Right Hand Drive
7 2-4550 PINION, Left Hand Drive
8 1-4341 RING, Retaining (4)
9 2-6479 SEAL, Pinion (Felt) (2)
10 2-6478 RETAINER, Pinion Seal (2)
11 2-4879 WASHER, Felt
12 2-5066 ASSEMBLY, Bearing Carrier (2)
13 2-4715 BUSHING, Rear Axle (2)
14 2-4748 TUBING, 5/8” I.D. Convoluted
15 9-0361 SCREW, 5/16-18 x 5/8” Hex Washer Head, Self-Tapping (2)
16 3-5325 BRACKET, Transmission
17 9-1187 NUT, M10 x 1.50 Hex Nyloc
18 2-9494 PULLEY, Transmission
19 9-1084 SCREW, 1/4-20 x 3/8” Hex Washer Head, Self- Tapping (4)
20 9-1194 WASHER, 17/32 I.D. x 1-1/2” O.D. (2
21 2-3657 KNOB, Height Adjusting Lever
22 9-0844 PIN, 3/16 x 3/4” Roll
23 4-6522 SPRING, Clutch
24 3-4776 HANDLE, Height Adjustment
25 2-8926 SPACER
26 2-8888 SPRING, Return
27 9-0505 SCREW, 1/4-20 x 2” Hex Head Cap, Grade 5
28 7-6978 NUT, 1/4-20 Hex Nyloc
29 9-1075 SCREW, #10-24 x 5/8” Slotted Hex Washer Head, Self Tapping
30 3-5541 ARM, Shift
31 3-5540 LEVER, Transmission
32 9-1267 NUT, #10-24 Hex Center Lock
ACCESSORIES
ITEM PART NO. DESCRIPTION
GRASS CATCHER 1 4-5199 GRASS CATCHER, Snapper
PARTS Cast Deck Commercial
2 5-3176 FRAME, Grass Catcher
3 2-6421 GRIP
MULCHING PARTS 4 2-6390 PLUG, Mulching
DISCHARGING 5 2-6714 CHUTE, Side Discharge
PARTS (Includes WARNING
Decal P/N 1-3010)
21” CAST ALUMINUM WBM SERIES 1 MANUAL No. 06200
DECAL
P/N 1-3010
3
1
2
4
5

10
DECALS
ITEM PART NO. DESCRIPTION
1 7-2098 DECAL, Snapper (Curved)
2 7-2921 DECAL, Warning (Deck)
3 7-3462 DECAL, Caution Symbols
4 7-4548 DECAL, 2002 Year of Manufacture
-- 7-5378 DECAL, 2003 Year of Manufacture
5 2-9431 DECAL, Operator Presence Control
6 2-9432 DECAL, Ground Drive
7 2-9470 DECAL, Patent Numbers
8 2-9776 DECAL, Euro Community (CE)
9 2-9779 DECAL, Spark Plug International Symbol
MANUAL No. 06200 21” CAST ALUMINUM WBM SERIES 1
9
4
3
2
1
8
7
6
5
