Snapper LT140H331KV Series User manual

Parts Manual fo
r
Revision 2,
LAWN TRACTOR MANUAL CLUTCH
SERIES 1
COPYRIGHT
©
2006
McDonough, GA, 30253 U.S.A.
TP 400-5213-2-TC-N
7/14/2006 Manual No. 7006427
SNAPPER PRODUCTS, INC.
ALL RIGHTS RESERVED.
HYDRO DRIVE
(
1991 1/2
)
MODEL
ELT140H331KV
ELT140H411KV
LT140H331K
V
LT140H411K
V
RLT140H331KV

Table Of Content
s
TP 400-5213-2-TC-N
Manual No. 7006427LAWN TRACTOR MANUAL CLUTCH
SERIES 1 3
PAGE GROUP
4Hood, Bumper, Headlights
6Wheels - Front
8Wheels - Rear
10 Engine, Engine Base & Drive Parts
14 Transmission Support & Components I
16 Transmission Support & Components II
18 Dash Panel
20 Steering And Front Axle Parts
22 Seat, Rear Fender
24 Clutch, Brake & Transmission Controls
28 Transmission Group
32 Transmission - Service Parts
34 Implement Lift Parts
36 Blade Engagement
38 33" Cutting Deck, Belts, Brakes
44 41" Cutting Deck
48 Belt, Blade Brake, 41" Deck
50 Fuel Tank & Battery
52 Electrical System
54 Schematic Electrical System (Kohler Engines Only)

Hood, Bumper, Headlights
TP 400-5213-2-TC-N
Manual No. 7006427 LAWN TRACTOR MANUAL CLUTCH
SERIES 1
4

Hood, Bumper, Headlights
Footnotes:
TP 400-5213-2-TC-N
Manual No. 7006427LAWN TRACTOR MANUAL CLUTCH
SERIES 1 5
Part No Descri
p
tionItem Qt
y
Note
1 7063298 1 KIT, Hood Assembly, Sloped Mozart Was 61082 or 61383 (Includes 2
thru 18)
2 1 HOOD (No longer available, use kit 7063298) Was 19411
3 7016766 1 ROD, Hood Latch
4 7076978 10 NUT, 1/4-20 Hex Lock
5 1 HEAT SHIELD, Hood 3" x 5" (No longer available) Was 17787
6 2 DECAL-SNAPPER, Molded Logo (No longer available) Was 16974 or 36438 or 24980
7 7090999 10 SCREW, 1/4-20 x 5/8" Torx, Truss Head
8 1 BUMPER (R.H.) (No longer available) Was 19412
1 BUMPER (L.H. Shown) (No longer available) Was 19413
9 7012691 2 CLIP, Wiring Harness .31"
10 7017174 1 DECAL, Reflect (R.H.)
7017175 1 DECAL, Reflect (L.H. Shown)
11 7033265 2 BRACKET, Latch Hook
12 1 BUMPER, Front (No longer available) Was 19414
13 7091106 5 SCREW, #12 x 1/2"
14 7024893 1 LENS, Clear Bezel Was 19415
15 7016756 2 BULB, Headlights, 1156
16 7016757 2 SOCKET, Headlight Bulb
17 7016765 1 HARNESS, Headlight Wiring
18 7017359 1 CLIP, Hood Latch
19 1 DECAL-SNAPPER, Molded Logo 4" - Blue (No longer available) Was 22968 (LT140H33 &
LT140H41)
7022969 1 DECAL-SNAPPER, Molded Logo 4" - Green (RLT140H33)
20 1 DECAL, 1550LX - Blue (R.H.)(No longer available) Was 22986 (LT140H33 &
LT140H41)
1 DECAL, 1550LX - Blue (L.H. Shown)(No longer available) Was 22987 (LT140H33 &
LT140H41)
7022988 1 DECAL, 1550RX - Green (R.H.) (RLT140H33)
7022989 1 DECAL, 1550RX - Green (L.H. Shown) (RLT140H33)
21 7022975 1 DECAL, Convertible - Blue (LT140H33)
7022977 1 DECAL, Twin-Turbo - Blue (LT140H41)
1 DECAL, Recycling - Green (No longer available) Was 22972 (RLT140H33)

Wheels - Front
TP 400-5213-2-TC-N
Manual No. 7006427 LAWN TRACTOR MANUAL CLUTCH
SERIES 1
6

Wheels - Front
Footnotes:
TP 400-5213-2-TC-N
Manual No. 7006427LAWN TRACTOR MANUAL CLUTCH
SERIES 1 7
Part No Descri
p
tionItem Qt
y
Note
1 7058517 2 ASSEMBLY, Front Tire & Rim 15x5.50-6.00 Was 52185 (Includes Items 2, 3
& 4)
2 7022772 2 RIM, 6 x 4.50 Was 16739
3 7072704 2 TIRE, 15-5.50 x 6 Was 16740
4 7012234 2 VALVE, Air (Snap-in)
5 7014483 4 BEARING, Wheel Flanged PM .758 ID x 1.38 OD x 1.0 L
6 7032027 2 WASHER .77 x 1.5 x .06
7 7019417 2 WHEEL-COVER
8 7091516 2 COTTER-PIN 5/32 x 1 YZ Was 90364
9 7076998 2 FITTING, Lube 1/4-28 Tapered Thread Was 13876

Wheels - Rear
TP 400-5213-2-TC-N
Manual No. 7006427 LAWN TRACTOR MANUAL CLUTCH
SERIES 1
8

Wheels - Rear
Footnotes:
TP 400-5213-2-TC-N
Manual No. 7006427LAWN TRACTOR MANUAL CLUTCH
SERIES 1 9
Part No Descri
p
tionItem Qt
y
Note
1 2 ASSEMBLY, Rear Tire & Rim (No longer available) Was 52187 (LT140H41)
2 ASSEMBLY, Rear Tire & Rim (No longer available) Was 52675 (LT140H33 &
RLT140H33)
2 7016744 2 TIRE, 18-8.50 x 8 (Used with 41" Deck)
7022688 2 TIRE, 18-7.50 x 8 (Used with 33" Deck)
3 7016742 2 RIM, 8 x 7 (Used with 41" Deck)
7016741 2 RIM, 8 x 5.375 (Used with 33" Deck)
4 7012234 2 VALVE, Air (Snap-in)
5 7091502 6 BOLT, 1/2-20 x 3/4" Lug Was 90367
6 7019418 2 WHEEL-COVER
7 7040720 2 HUB, Rear Wheel
8 7017173 2 KEY, Square, 3/16 x 2 1/2"
9 7012899 2 RING, Retaining EXT .75 Was 12829

Engine, Engine Base & Drive Parts
TP 400-5213-2-TC-N
Manual No. 7006427 LAWN TRACTOR MANUAL CLUTCH
SERIES 1
10

Engine, Engine Base & Drive Parts
Footnotes:
TP 400-5213-2-TC-N
Manual No. 7006427LAWN TRACTOR MANUAL CLUTCH
SERIES 1 11
Part No Descri
p
tionItem Qt
y
Note
1 7017358 1 DECAL, Engine 14 HP OHV
2 7017313 1 MUFFLER, Exhaust
3 1 ENGINE, Kohler Model CV14S, Spec. PS1431 (Purchase Engine Parts, Other
Than Those Listed, From
Engine Service Outlets.)
4 7091585 4 NUT, 3/8-16 Hex, Center Lock Was 90546
5 7033145 1 BASE, Engine Kohler
6 7091508 2 BOLT, 5/16-18 x 3/4" Short Neck Carriage Was 90788
7 7090595 2 BOLT, 5/16-18 x 3/4" Flange Lock
8 7091575 1 NUT, 5/16-18 Hex Lock Was 90184
9 7014438 1 EYE-BOLT
10 7091008 1 BOLT, 3/8-16 x 2 1/2" Short Neck Carriage
11 7090517 2 WASHER, 3/8" Flat Was 90600
12 7044752 1 BUSHING, Idler Arm .750 OD x .406 ID x .25 L Was 22062
13 7040565 1 ARM, Idler
14 7011029 2 PULLEY, Idler, 4" O.D.
15 7023199 1 PULLEY, Idler, 3 3/4" O.D.
16 7090629 1 BOLT, 3/8-16 x 2 1/4 Hex
17 7090118 1 WASHER, 3/8 Split Lock
18 7091302 1 NUT, 3/8-16 Hex Was 90130
19 7014527 1 SPACER .623 OD x .38 ID x .25 L
20 7011807 1 SPRING, Idler Arm
21 7091601 6 NUT, 5/16-18 Hex Flange Lock Was 90585
22 7019042 1 GUIDE, Belt
23 7090836 1 SCREW, 7/16-20 Socket, Hex Head Cap
24 7091301 1 WASHER, 7/16 Split Lock Was 90247
25 7019036 1 PULLEY ASSEMBLY, Engine
26 7012306 2 BUSHING
27 7023198 2 SCREW, Shoulder, 3/8-16 x 1 5/8"
28 7091619 2 NUT, 3/8-16 Hex Flange Lock Was 90613
29 7016724 1 V-BELT, Traction Drive, (111.6" EL) LT140H33, LT140H41, &
RLT140H33
30 1 AXLE SUPPORT (No longer available) Was 33100
31 7077692 4 BOLT, M8-1.25 x 25MM Hex Head
32 7090187 4 WASHER, 5/16 Split Lock
33 7090661 2 BOLT, 5/16-18 x 1" Hex Flange Lock
34 7091000 2 SCREW, 5/16-18 x 7/8" Truss Head Torx Was 91001
35 7033424 1 SPACER, Kohler Engine
36 7011791 2 RETAINER 5/16"
37 7016719 2 SPACER .750 x .39 ID x .5 L

Engine, Engine Base & Drive Parts
TP 400-5213-2-TC-N
Manual No. 7006427 LAWN TRACTOR MANUAL CLUTCH
SERIES 1
12

Engine, Engine Base & Drive Parts
Footnotes:
TP 400-5213-2-TC-N
Manual No. 7006427LAWN TRACTOR MANUAL CLUTCH
SERIES 1 13
Part No Descri
p
tionItem Qt
y
Note
38 7091580 2 BOLT, 3/8-16 x 1 3/4" Hex Flange Lock Was 90701

Transmission Support & Components I
TP 400-5213-2-TC-N
Manual No. 7006427 LAWN TRACTOR MANUAL CLUTCH
SERIES 1
14

Transmission Support & Components I
Footnotes:
TP 400-5213-2-TC-N
Manual No. 7006427LAWN TRACTOR MANUAL CLUTCH
SERIES 1 15
Part No Descri
p
tionItem Qt
y
Note
1 1 TRANSMISSION SUPPORT, R.H. (No longer available) Was 33063
2 2 BRACKET, Transmission Mount (No longer available) Was 33059
3 7016360 2 WASHER .406 x 1.38 x .25
4 7017164 1 ROD, Release
5 7023606 1 CAP, Release Rod Was 23525
6 7033061 1 BRACE, Torque
7 7016116 4 NUT, 5/16 Push-On
8 7090361 14 SCREW, 5/16-18 x 5/8" Self-Tapping
9 1 TRANSMISSION SUPPORT, L.H. (No longer available) Was 33062
10 7027198 4 BOLT, 3/8-16 x 1" Hex Flange Lock Was 90582
11 1 EXTENSION, Transmission Support, L.H. (No longer available) Was 35179
12 7091585 4 NUT, 3/8-16 Center Lock Was 90546
13 7090122 4 WASHER, 3/8 SAE
14 7091541 2 SCREW, 5/16-18 x 3/4" Self-Tapping Was 90368
15 1 BRACE, Shift Bracket (No longer available) Was 33065
16 1 EXTENSION, Transmission Support, R.H. (No longer available) Was 35180
17 7022289 2 U-BOLT
18 7033320 2 SADDLE, U-Bolt
19 7091601 2 NUT, 5/16-18 Hex Flange Lock Was 90585
24 7091000 1 SCREW, 5/16-18 X 7/8" Torx Self-Tap

Transmission Support & Components II
TP 400-5213-2-TC-N
Manual No. 7006427 LAWN TRACTOR MANUAL CLUTCH
SERIES 1
16

Transmission Support & Components II
Footnotes:
TP 400-5213-2-TC-N
Manual No. 7006427LAWN TRACTOR MANUAL CLUTCH
SERIES 1 17
Part No Descri
p
tionItem Qt
y
Note
8 7090361 14 SCREW, 5/16-18 x 5/8" Self-Tapping
20 7033068 1 COVER, Rear
21 7017209 1 DECAL, Roll
22 1 COVER, Transmission Oil Access (No longer available) Was 16863
23 7017327 2 SCREW, Expansion

Dash Panel
TP 400-5213-2-TC-N
Manual No. 7006427 LAWN TRACTOR MANUAL CLUTCH
SERIES 1
18

Dash Panel
Footnotes:
TP 400-5213-2-TC-N
Manual No. 7006427LAWN TRACTOR MANUAL CLUTCH
SERIES 1 19
Part No Descri
p
tionItem Qt
y
Note
1 7052685 1 PANEL, Dash Was 52686
2 7090996 4 SCREW, 1/4-20 x 1" Phillips
3 7040734 1 SUPPORT, Steering Shaft
4 7051915 1 CHANNEL, Foot Rest (Includes item 30)
5 7091000 14 SCREW, 5/16-18 x 7/8" Torx, S.T. Was 91001
6 7019400 1 TREAD, Left Side (Non-Skid)
7 7019399 1 TREAD, Right Side (Non-Skid)
8 7090361 2 SCREW, 5/16-18 x 5/8" Hex Cap S.T.
9 7033073 1 MOUNT, Fuel Tank/Battery
10 7026196 1 FLANGE ASSM'Y., Steering Shaft .75" ID Bearing Was 23173
11 7076978 4 NUT, 1/4-20 Hex
12 7090896 2 SCREW, #10-24 x 1/2" Self-Tapping Was 90853
13 7090858 4 SCREW, 5/16-18 x 1/2" Self-Tapping
14 7033078 1 PLATE, Fuel Tank & Battery Mount
15 7091122 4 SCREW, 1/4-20 x 1/2" Hex Cap, S.T. Was 90539
29 7016824 1 CONTROL, Throttle 41.6" Long
30 7017026 1 DECAL, Caution & Instruction
32 1 GROMMET, 5/16 I.D. for .75 Hole (No Longer available) Was 14856
33 7023655 1 HANDLE, Throttle Control
34 7091017 1 SCREW, #8-32 x 3/8" Recessed, Fillister Head
35 7091018 1 NUT, #8-32 Hex
36 1 ROD, Hood Latch (No longer available, try using 7033828) Was 17345
37 7090803 6 BOLT, 1/4-20 x 5/8" Flat Head Carriage
38 7091584 6 NUT, 1/4-20 Hex Flange Lock Was 90583

Steering And Front Axle Parts
TP 400-5213-2-TC-N
Manual No. 7006427 LAWN TRACTOR MANUAL CLUTCH
SERIES 1
20
