Snapper LT75 SERIES User manual

Parts Manual fo
r
Revision IR,
PREMIUM RIDER 33" (84cm)
LT75 SERIES
TP 400-5415-IR-RE-N9/12/2008
Briggs & Stratton Yard Power Products Group
535 Macon Road
McDonough, GA, 30253 U.S.A.
800-935-2967 Manual No. 885194
MODEL
7800352, LT75RD-CE
7800353, LT75RD-CE, FR
7800356, LT75RD-CE
7800357, LT75RD-CE, FR

Table Of Content
s
TP 400-5415-IR-RE-N
PREMIUM RIDER 33" (84cm)
LT75 SERIES 3
Manual No. 885194
PAGE GROUP
4Wheel & Tire Group
6Steering Group
10 Seat, Body, Dash & Fuel Tank Group
12 Drive Group
16 Engine & Electric Clutch Group - Briggs & Stratton
18 Electrical Group
20 Decals Group - Brand & Model
22 Decals Group - Common & Safety
24 33" Mower Deck - Housing & Arbors Group
28 33" Mower Deck - Arbors Group
30 Bagger Group

Wheel & Tire Group
TP 400-5415-IR-RE-N PREMIUM RIDER 33" (84cm) LT75 SERIES
4
Manual No. 885194

Wheel & Tire Group
Footnotes:
TP 400-5415-IR-RE-N
Manual No. 885194PREMIUM RIDER 33" (84cm)
LT75 SERIES 5
Part No Descri
p
tionItem Qt
y
Note
1 885029 2 REAR TIRE ASSY - 16/650
2 885028 2 FRONT TIRE ASSY - 13/500
3 721318 4 HUB CAP
4 720010 2 RING- -E-.750D-.050T
5 722620 4 WASHER - FLAT
7 722617 4 WASHER - FLAT
8 720390 2 PIN-COTTER.13D-.880L

Steering Group
TP 400-5415-IR-RE-N PREMIUM RIDER 33" (84cm) LT75 SERIES
6
Manual No. 885194

Steering Group
Footnotes:
TP 400-5415-IR-RE-N
Manual No. 885194PREMIUM RIDER 33" (84cm)
LT75 SERIES 7
Part No Descri
p
tionItem Qt
y
Note
1 729275 1 COVER, INTEGRA
2 727627 1 ST WHEEL INTEGRA - HARD
3 885022 1 FOOTREST CAP
4 885106 1 SHAFT, STEERING - LONG
5 720563 1 BELLOWS
6 720173 2 WASHER.54.81 16G FLT
7 885007 1 FOOTREST SLEEVE - SNAPPER
8 885002 1 FOOTREST - PLASTIC
9 721950A 1 SUPPORT, STEERING
10 721966 1 BEARING, UPPER STEERING
11 726537A 2 LINK, DRAG
12 885036A 1 BRACKET, SUPPORT
13 729342A 1 BRACKET, AXLE FRONT
14 885081A 1 AXLE AND SPINDLE ASSY
15 721949A 1 RACK, STEERING
16 721971 1 GEAR, PINION
17 721973 2 ROLLER
18 721970 1 BEARING, LOWER STEERING
19 727201A 1 PLATE, GEAR MTG.
20 720107 2 BOLT, SHOULDER
21 720145 2 NUT.31-18 HEX FLG CTRLKZ
22 722584 1 WASHER-1-1.3 16G FLT
23 722622 2 WASHER, .328X1.062X.062 Z
24 720211 2 BOLT-HEX.31-24X2.75 PLAIN
25 720142 2 NUT.38-16 HEX FLG CTRLKZ
26 722395 2 NUT.31-24 FLANGELOCK Z-BL
27 722580 2 WASHER.39-1. 14G FLT
28 722858 13 SCREW-.312-18X.75
29 720117 1 RING- -E-1.00D-.050T
30 727875 2 BUMPER-FRONT AXLE EPDM
31 720042 1 SCREW-THD.FORM.HEX.
32 722593 1 WASHER.34-1.2 11G FL
33 722863 1 SCREW
34 720192 2 BOLT-HEX.38-16x1.50 Z
35 885110 1 THROTTLE CONTROL
36 722841 2 SCREW Z/BL CHROMATE
37 885118 1 TINNERMAN CLIP

Steering Group
TP 400-5415-IR-RE-N PREMIUM RIDER 33" (84cm) LT75 SERIES
8
Manual No. 885194

Steering Group
Footnotes:
TP 400-5415-IR-RE-N
Manual No. 885194PREMIUM RIDER 33" (84cm)
LT75 SERIES 9
Part No Descri
p
tionItem Qt
y
Note
38 885102 1 FLOORMAT, RH
39 885103 1 FLOORMAT, LH
40 885223A 1 STEERING SUPPORT PLATE
41 721246 1 RETAINER - SPRING
42 729075 2 SCREW-TAPPING 10-16

Seat, Body, Dash & Fuel Tank Group
TP 400-5415-IR-RE-N PREMIUM RIDER 33" (84cm) LT75 SERIES
10
Manual No. 885194

Seat, Body, Dash & Fuel Tank Group
Footnotes:
TP 400-5415-IR-RE-N
Manual No. 885194PREMIUM RIDER 33" (84cm)
LT75 SERIES 11
Part No Descri
p
tionItem Qt
y
Note
1 885003D 1 FOOTREST
2 885001A 1 SEAT SUPPORT
3 885009A 1 SEAT SUPPORT COVER
4 885091A 1 DECK LIFT INDEX ASSY
5 885002 1 FOOTREST - PLASTIC
6 885004 1 BODY - PLASTIC - SNAPPER
7 885021 1 BATTERY COVER - SNAPPER
8 885010A 1 SEAT BRACKET
9 885060A 1 SEAT SUPT. BRKT. RH
10 885061A 1 SEAT SUPT. BRKT. LH
11 722411 2 SPRING - SEAT
12 720049 4 BOLT-CRG.31-18X1.12
13 720139 4 NUT
14 720095 6 BOLT, SHOULDER SELF TAP
15 720102 2 BOLT-SHD .32-18X .375D
16 720145 4 NUT
17 720159 2 WASHER
18 720358 4 SCREW
19 9075071 1 SEAT - PREMIUM
20 885108 4 SHOULDER BOLT
21 885100A 1 LEVER - SEAT ADJ.
22 722858 8 SCREW-.312-18X.75
23 722866 6 SCREW .25-20x0.59 HEX
24 720049 2 CARRIAGE BOLT
25 721403 2 HOSE CLAMP - YELLOW
26 729007 1 FUEL LINE
27 727333 1 FUEL CAP
28 885006 1 TANK, FUEL 1.6 GAL.
29 885101A 1 BRACKET, FUEL TANK
30 720048 2 BOLT, CARRIAGE 1/4"
31 720132 2 NUT
32 720173 2 WASHER .54.81 16G FLT
33 721609 1 FOAM BAFFLE
34 720140 4 NUT
35 885215 1 GRIP - SEAT ADJ. LEVER

Drive Group
TP 400-5415-IR-RE-N PREMIUM RIDER 33" (84cm) LT75 SERIES
12
Manual No. 885194

Drive Group
Footnotes:
TP 400-5415-IR-RE-N
Manual No. 885194PREMIUM RIDER 33" (84cm)
LT75 SERIES 13
Part No Descri
p
tionItem Qt
y
Note
1 885058A 1 FRAME CHANNEL - PREMIUM
2 885069A 1 ARM - IDLER PULLEY ASSY
3 885168A 1 PLATE - REINFORCEMENT
4 885034A 2 BRACKET, TRANSAXLE
5 726515A 1 BRKT, FRONT HANGER PIVOT
6 727241A 1 PLATE, HITCH
7 885064 1 M/D IDLER STUD
8 885074A 1 WW LIFTER ASSEMBLY
9 720145 1 NUT.31-18 HEX FLG CTRLKZ
10 722858 18 SCREW-. 312-18X.75
11 885068A 1 WS ASM. PEDAL C/B
12 885116A 1 PLATE, REAR
13 885070A 1 WW HYDRO ARM ASSY
14 885089A 1 WW REVERSE PEDAL ASSY
15 720065 2 BOLT, CARRIAGE 1/4"
16 720133 4 NUT, 1/4"
17 720358 5 SCREW-.312-18X.75
18 720389 3 PIN, COTTER
19 722031 1 PULLEY - IDLER - BACKSIDE
20 721353 1 NUT-ADJUSTING
21 722009 1 IDLER PULLEY - FIXED
22 885030 1 TRANSMISSION - HYDRO GEAR
23 885053A 2 BRKT, REAR HANGER R.H.
24 721221 2 PIN - THREADED SHLDR
25 720142 2 NUT.38-16 HEX FLG CTRLKZ
26 885031A 1 BRKT - TORQUE STRAP
27 720257 1 CLUTCH & BRAKE PEDAL
28 885104 1 ROD, PARKING BRAKE
29 885026 1 PARKING BRAKE KNOB
30 720650 2 SQUARE KEY
31 885076 1 ADJUSTING NUT
32 720215 1 BOLT-HEX .31-18X2.50 P&OIL
33 720216 4 BOLT-HEX .31-18X3.00PO&L
34 720145 4 NUT.31-18 HEX FLG CTRLKZ
35 720148 3 NUT.38-16 FLANGELOCK ZINC
36 720159 2 WASHER .26.75 16G FLT
37 720166 3 WASHER

Drive Group
TP 400-5415-IR-RE-N PREMIUM RIDER 33" (84cm) LT75 SERIES
14
Manual No. 885194

Drive Group
Footnotes:
TP 400-5415-IR-RE-N
Manual No. 885194PREMIUM RIDER 33" (84cm)
LT75 SERIES 15
Part No Descri
p
tionItem Qt
y
Note
38 720173 2 WASHER .54.81 16G FLT
39 727938 4 WASHER
40 720387 3 PIN,COTTER .094x0.75L
41 720069 5 PIN-HAIR .56D-.092T
42 885015 1 BELT - 33" DRIVE
43 722446 1 SPRING, EXT
44 885017 1 SPRING - EXTENSION BRAKE
45 885037A 1 HYDRO PEDAL
46 720048 2 CARRIAGE BOLT
47 885086 1 PAD, HYDRO PEDAL
48 885055 1 ROD - SHIFT LINK
49 885048 1 LEVER, LIFT DECK
50 727798 1 GRIP .50 DELUXE- BLACK
51 721979 1 HANGER - PIN
52 720139 4 NUT. 31-18 HEX FLG SERLKZ
53 885059 1 ROD - ROLL RELEASE
54 885095 1 ROD, BATTERY
55 727869 1 ROD - CLUTCH LINK
56 722867 1 SCREW
57 727619 1 SPRING, EXTENSION
58 725228 2 SPACER
59 722598 6 WASHER
60 885079 1 HYDRO REVERSE PEDAL PAD

Engine & Electric Clutch Group - Briggs & Stratton
TP 400-5415-IR-RE-N PREMIUM RIDER 33" (84cm) LT75 SERIES
16
Manual No. 885194

Engine & Electric Clutch Group - Briggs & Stratton
Footnotes:
TP 400-5415-IR-RE-N
Manual No. 885194PREMIUM RIDER 33" (84cm)
LT75 SERIES 17
Part No Descri
p
tionItem Qt
y
Note
1 * 1 ENGINE - 15.5HP Briggs & Stratton Model 31A677, Type 0136-
B1 For use on models 7800352 & 7800353
1 * 1 ENGINE - 17.5HP Briggs & Stratton Model 31A677, Type 0153-
B1 For use on models 7800356 & 7800357
- 720393 3 TIE,STRAP-BLACK-5.38
2 885011 1 MUFFLER
3 720881 2 GASKET 272293
4 721405 1 ADAPTOR, MUFFLER
5 885128 1 ASSY-HEAT SHIELD
6 885107 1 ELECTRIC CLUTCH
7 885056A 1 ELEC PTO TORQUE STRAP
8 722858 2 SCREW
9 720105 2 BOLT - SHOULDER
10 720045 4 ENG. BOLT -3/8 X1.25
11 720664 2 SCREW.32-18X .88 HHWATAP
12 1960370 1 BOLT-HEX.43-20X2.50 Z-NYL
13 885096 1 STACK PULLEY M/D
14 885063 1 BAFFLE - ENGINE
15 720095 2 SHOULDER SCREW
16 720663 2 5/16-18 SOCKET HEAD
17 1918199 1 WASHER, LOCK
18 722866 1 SCREW.25-20X0.59 HEX
19 721064 1 LOCK-SCREW 223016
20 885041A 1 PLATE, BELT GUIDE
21 720139 1 NUT.31-18 HEX FLG SERLKZ
22 885078A 1 GUIDE, BELT LONG
23 885077 1 GUIDE, BELT SHORT
24 720163 2 WASHER .34.62 16G FLT
25 720146 1 NUT - 1/4-20

Electrical Group
TP 400-5415-IR-RE-N PREMIUM RIDER 33" (84cm) LT75 SERIES
18
Manual No. 885194

Electrical Group
Footnotes:
TP 400-5415-IR-RE-N
Manual No. 885194PREMIUM RIDER 33" (84cm)
LT75 SERIES 19
Part No Descri
p
tionItem Qt
y
Note
1 729388 1 Battery Cable - Negative
2 720123 2 Wingnut
3 720588 1 Boot - Battery - Pos
4 720345 1 Battery Cable - Positive
5 1740463 1 Battery
6 885095 1 Rod, Battery
7 720057 2 Bolt - Carriage
8 722851 2 Screw
9 885113 1 Wire Harness
10 1001575 1 Limit Switch
11 720393 3 Tie Strap
12 721615 1 Solenoid
13 722393 3 Nut
14 720348 1 Cable - Sol. to Starter
15 721108 1 Ignition Switch
16 720889 1 Nut - Igntion Switch
17 727338 1 Cap - Ignition
18 720240 2 Keys
19 1720411 2 Seat Switch
20 1722887 1 PTO Switch
21 885154 1 BUZZER
22 1720411 1 SWITCH - BAG FULL
23 727831 1 BAGGER SWITCH
24 722977 1 FUSE - 15 Amp

Decals Group - Brand & Model
TP 400-5415-IR-RE-N PREMIUM RIDER 33" (84cm) LT75 SERIES
20
Manual No. 885194
