Parts Manual fo
r
22" VARIABLE SPEED 3N1
WALK BEHIND MOWERS
Revision: B 5/13/2011
Briggs & Stratton Yard Power Products Group
Manual No. 7104293
535 Macon Road
McDonough, GA, 30253 U.S.A.
800-935-2967
Descri
p
tionModel No.
780075
6
NSXPV2270
780075
7
NSXPV2270E
780070
7
SPXV2270
780070
8
SXPV2270E

Not for
Reproduction

Not for
Reproduction
Table Of Content
s
TP 400-5481-B-WB-N
22" VARIABLE SPEED 3N1
3
Manual No. 7104293
PAGE GROUP
4Handle & Controls Group (Manual Start)
6Drive Control Assembly (Manual Start)
8Handle & Controls Group (Electric Start)
10 Drive Control Assembly (Electric Start)
12 Mower Deck Group
14 Engine, Blade & Grass Bag Group
16 Transmission & Wheels Group
18 Decals Group

Not for
Reproduction
Manual No. 7104293 22" VARIABLE SPEED 3N1
4
Handle & Controls Group (Manual Start)

Not for
Reproduction
Footnotes:
Manual No. 710429322" VARIABLE SPEED 3N1
5
Handle & Controls Group (Manual Start)
Part No Descri
p
tionItem Qty
1 7090015 1 BOLT, 1/4-20 x 1-3/4” Round Head Square Neck, GR 2, YZ
2 7090391 4 WASHER, 5/16” Internal Tooth Lock
3 7090951 2 NUT, 5/16-18 Large Flange Center Lock
4 7091189 2 BOLT, 5/16-18 x 2” Curved Head Square Neck, GR 2
5 723873 2 BOLT, 5/16-18 x 3/4” Square Neck Carriage, GR 5
6 1931338 2 BOLT, 5/16-18 x 1-3/4” Round Head Square Neck Carriage
7 2860694 2 NUT, 1/4-20 Hex Flange (Esna), YZ
8 7024649 2 WIRE TIE, 11 Inch Standard Black Nylon
9 7101410 1 ROPE GUIDE, (1/4-20 thread)
10 7102990 4 KNOB, Handle, (5/16-18 internal threads) 5-Prong
11 7103774 1 METER, Service Indicator
12 7300649BH 2 HANDLE, Connecting, 21” / 22” WBM
13 7301189BH 1 HANDLE, Lower
14 7501967 1 ASSEMBLY, Drive Control, MY2010 Walk
7800707, 7800756 & 7800774

Not for
Reproduction
Manual No. 7104293 22" VARIABLE SPEED 3N1
6
Drive Control Assembly (Manual Start)

Not for
Reproduction
Footnotes:
Manual No. 710429322" VARIABLE SPEED 3N1
7
Drive Control Assembly (Manual Start)
Part No Descri
p
tionItem Qty
1 7091075 1 SCREW, #10-24 x 5/8” Hex Washer Self-Tap, GR 5 BZ
2 7091195 4 SCREW, #10-16 x 3/4” Pan Head Self-Tap Combo, BZ
3 1960593 1 NUT, #10-24 Speed Retainer w/extrusion
4 7102803 2 LEVER, Drive Control
5 7102804 2 LEVER, OPC, Control
6 7102805 1 CAM, Drive, LH
7 7102806 1 CAM, Drive, RH
8 7103325 1 CONTROL PANEL, Bottom, MY Mower
9 7103326 1 PANEL, Bottom Control, WBM, RH
10 7103327 1 PANEL, Bottom Control, WBM, LH
11 7103456 1 PANEL, Access, Maintenance Reminder
12 7104294 1 PANEL, Top Control
13 7104689 1 SPRING, Tension, Drive Control
14 7104752 1 CABLE, OPC, 2010 NXT
15 7105092 1 CABLE, Control, 2010 NXT (Was 7103770)
16 7900081 4 SCREW, #10-16 x 2” Hi-Lo Cross Pan Head
Model pt. #'s: 7800707, 7800756 & 7800774

Not for
Reproduction
Manual No. 7104293 22" VARIABLE SPEED 3N1
8
Handle & Controls Group (Electric Start)

Not for
Reproduction
Footnotes:
Manual No. 710429322" VARIABLE SPEED 3N1
9
Handle & Controls Group (Electric Start)
Part No Descri
p
tionItem Qty
1 7028765 1 SWITCH, ES, Start/Run
2 7102990 4 KNOB, Handle, (5/16-18 internal threads) 5-Prong
3 7090015 1 BOLT, 1/4-20 x 1-3/4” Round Head Square Neck, GR 2, YZ
4 7090391 4 WASHER, 5/16” Internal Tooth Lock
5 7090951 2 NUT, 5/16-18 Large Flange Center Lock
6 7091189 2 BOLT, 5/16-18 x 2” Curved Head Square Neck, GR 2
7 1931333 2 BOLT, 5/16-18 x 3/4” Round Head Short Square Neck Carriage, GR 5
8 2860694 2 NUT, 1/4-20 Hex Flange (Esna), YZ
9 7023506 1 BEZEL, Black
10 7024649 4 WIRE TIE, 11 Inch Standard Black Nylon
11 7101410 1 ROPE GUIDE, (1/4-20 thread)
12 7102931 1 BATTERY, 12V DC, 1.3A / HR
13 7103774 1 METER, Service Indicator
14 7104149 1 NUT, Plastic, 5/8-32
15 7300649BH 2 HANDLE, Connecting, 21” / 22” WBM
16 7301189BH 1 HANDLE, Lower
17 7502046 1 ASSEMBLY, Drive Control, Snapper Electric Start
18 1931338 2 BOLT, 5/16-18 x 1-3/4” Short Square Neck Carriage, GR 5
19 7011138 1 KEY, Ignition, Pair
20 7103988 1 CHARGER, Battery, 14V 260MA, 120V AC
Model pt. #'s: 7800708, 7800757 & 7800775

Not for
Reproduction
Manual No. 7104293 22" VARIABLE SPEED 3N1
10
Drive Control Assembly (Electric Start)

Not for
Reproduction
Footnotes:
Manual No. 710429322" VARIABLE SPEED 3N1
11
Drive Control Assembly (Electric Start)
Part No Descri
p
tionItem Qty
1 7091075 3 SCREW, #10-24 x 5/8” Hex Washer Self-Tap, GR 5 BZ
2 7091195 4 SCREW, #10-16 x 3/4” Pan Head Self-Tap Combo, BZ
3 1960593 3 NUT, #10-24 Speed Retainer w/extrusion
4 7102803 2 LEVER, Drive Control
5 7102804 2 LEVER, OPC, Control
6 7102805 1 CAM, Drive, LH
7 7102806 1 CAM, Drive, RH
8 7103325 1 CONTROL PANEL, Bottom, MY Mower
9 7103326 1 PANEL, Bottom Control, WBM, RH
10 7103327 1 PANEL, Bottom Control, WBM, LH
11 7103345 1 ACCESS DOOR, Battery Control Panel, WBM
12 7103456 1 PANEL, Access, Maintenance Reminder
13 7104395 1 HARNESS, Snapper React Drive
14 7104396 1 PANEL, Top Control
15 7104689 1 SPRING, Tension, Drive Control
16 7104752 1 CABLE, OPC, 2010 NXT
17 7105092 1 CABLE, Control, 2010 NXT (Was 7103770)
18 7900081 4 SCREW, #10-16 x 2” Hi-Lo Cross Pan Head
Model pt. #'s: 7800708, 7800757 & 7800775

Not for
Reproduction
Manual No. 7104293 22" VARIABLE SPEED 3N1
12
Mower Deck Group

Not for
Reproduction
Footnotes:
Manual No. 710429322" VARIABLE SPEED 3N1
13
Mower Deck Group
Part No Descri
p
tionItem Qty
1 7600155D 1 DECK, 22”, Rear Wheel Drive, Washout (used on 7800756 & 7800707 models)
1 7600159D 1 DECK, 22", Rear Wheel Drive, Washout, Electric Start (used on 7800757 & 7800708 models)
2 7300885BH 1 BRACKET, Lower Handle, LH, 22 WBM
3 7300915BH 1 BRACKET, Lower Handle, RH, 22 WBM
4 7103298 1 COVER, Mulching
5 7103299 1 CHUTE, Side Discharge, 22” WBM
6 7103295 1 COVER, Front, Push/Rear Wheel Drive
7 7091020 3 PUSHNUT, 1/4”
8 7101067 1 ROD, Pivot
9 7900067 6 SCREW, 1/4-20 x .550 Self-Tap (Torx)
10 722507 1 SPRING, Torsion
11 7300855D 1 BRACKET, Chute
12 7900073 2 BOLT, 1/4-20 x 1-1/2” Shoulder
13 7090699 4 BOLT, 1/4-20 x 3/4” Hex Flange Lock, GR 5
14 7103296 1 DEBRIS SHIELD, Front
15 7103323 1 GUARD, Rear 22”
16 722398 3 NUT, 1/4-20 Hex Flange Lock
17 7501541 1 ASSEMBLY, Door, 22” WBM (Incl. items 7, 29, 30, 31 & 32)
18 1960518 3 BOLT RETAINER, 1/4”
19 7091075 2 SCREW, #10-24 x 5/8” Hex Washer Face Self-Tap, GR 5
20 1960593 2 NUT, #10-24 Retainer Speed w/extrusion
21 7103453 1 PLUG, Mulching, 22” Deck
22 7900018 2 SCREW, Round Washer Head Torx, Hi-Lo
23 7090803 3 BOLT, 1/4-20 x 5/8” Flat Head Square Neck, GR 5
24 7023295 4 U-NUT, 1/4-20
25 7103293 1 BAFFLE, Rear, Rear Wheel Drive WBM
26 7104819 1 BELT COVER, Rear Drive (Was 7103294)
27 7900079 2 PUSH NUT, 3/16”
28 7301020 1 BAFFLE, Front
29 7103292 1 HINGE, Rear Discharge Door
30 7103309 1 SPRING, Torsion, Rear Door
31 7103322 1 ROD, Pivot, Rear Door
32 7103291 1 DOOR, Rear Discharge
33 7103957 1 WASHER, Hose
34 7103804 1 ADAPTOR, Washout Port, WBM
35 7103919 1 COUPLING, Hose
36 7091546 1 WASHER, 5/8” Internal Tooth Lock YZ (Was 7090880)
37 1960716 1 NUT, 5/8-11, NC-2B Black Hex Jam

Not for
Reproduction
Manual No. 7104293 22" VARIABLE SPEED 3N1
14
Engine, Blade & Grass Bag Group

Not for
Reproduction
Footnotes:
Manual No. 710429322" VARIABLE SPEED 3N1
15
Engine, Blade & Grass Bag Group
Part No Descri
p
tionItem Qty
1 7900072 3 SCREW, 3/8-16 x 1-1/4” Hex Washer Self-Tap
2 7103517 2 BELT GUIDE, Engine
3 7100437 1 PULLEY, Engine
4 7092086 1 SET SCREW, 5/16-18 x 1/2” Hex Recess
5 7091214 1 KEY, #HP-506 Hi-Pro
6 7101414 1 BLADE HUB, 21” WBM, Rear Drive, 2 Position
7 7103288BZ 1 BLADE, Wave, Steel Deck
8 7012063 1 WASHER, Cone
9 7090167 1 SCREW, 3/8-24 x 2” Hex Head Cap, GR 5
10 7103305A 1 BAG FRAME, Rear Discharge (weldment)
11 7103375 1 GRASS BAG, 22” Rear Discharge
12 128L02 0115 F1 1 * ENGINE, B&S, 700 Series, X-Spec (used on 7800756 model)
12 128L05 0116 F1 1 * ENGINE, B&S, 700 Series, ES, X-Spec (used on 7800757 model)
12 128T02 0740 B3 1 * ENGINE, B&S, 700 Series, B3, X-Spec (used on 7800707 model)
12 128T05-0110-B1 1 * ENGINE, B&S, 700 Series, Quantum, ES (used on 7800708 model)
NOTE: * Purchase engine parts from engine manufacturer dealer.

Not for
Reproduction
Manual No. 7104293 22" VARIABLE SPEED 3N1
16
Transmission & Wheels Group

Not for
Reproduction
Footnotes:
Manual No. 710429322" VARIABLE SPEED 3N1
17
Transmission & Wheels Group
Part No Descri
p
tionItem Qty
1 7103312 1 TRANSMISSION, Variable Speed, Rear Wheel Drive
2 7400259 1 WELDMENT, Rear Crossbar, RWD
3 7400306 1 WELDMENT, Front Axle
4 7091195 2 SCREW, #10-16 x 3/4” Pan Head Self-Tap, Combo
5 7100863 1 BELT GUIDE, Transmission
6 7103364 1 BELT, 3L, Traction Drive, 22” WBM, RWD (3L Sect., 33.83” Effective Length)
7 7091585 5 NUT, 3/8-16 Hex Center Lock, YZ
8 7100240 1 PULLEY, Transmission Variable Speed, LC WBM
9 7101350 4 HUBCAP, 8” & 9” Spoked Wheel, Snapper Cool Gray (was 7102507)
10 722604 4 WASHER, 1” OD x .387 ID, Flat
11 7027999 2 RETAINING RING, .452-.463 ID (Waldes Truarc 5100-50 or equivalent)
12 7100861 2 PIN, Axle
13 7100820 2 GEAR, Pinion
14 7014341 2 RETAINING RING, .392 Ext. (Waldes No. 5133-50 or equiv.)
15 7091591 4 BOLT, 5/16-18 x 1” Hex Flange Lock, GR 5, YZ
16 7103290 2 HOLDER, Bearing, Rear Wheel Drive
17 7078243 2 BALL BEARING, Axle
18 1931277 4 NUT, 5/16-18 Hex Flange Lock, GR 5, YZ (Was 7091601)
19 7500539 2 WHEEL ASSEMBLY, 9 x 2 Drive, Snapper Tread, w/Ext Gear (includes ball bearings #7101380,
gear #7100914, & screws #7091196)
20 7101367 2 SHIELD, Dust, 21” WBM, RD
21 724887 1 GRIP, Height-Of-Cut
22 7103289 1 LEVER, Spring, Height-Of-Cut
23 7900067 6 SCREW, 1/4-20 x .550 Self-Tap (Torx)
24 7101774 2 SHOULDER BOLT, #10-24
25 7103306D 1 ROD, Lifter Link, WBM
26 7091552 2 WASHER, .219 x .500 x .049 Flat
27 7091290 2 NUT, #10-24 UNC-2B Nyloc
28 7104525 2 SPACER, Shaft, 1/2”
29 7104518 4 BUSHING, Bearing, Rear Wheel Drive
30 7500540 2 WHEEL ASSEMBLY, 8 x 2 Idle, Snapper Tread, Charcoal Gray (includes two ball bearings, p/n
7101380)

Not for
Reproduction
Manual No. 7104293 22" VARIABLE SPEED 3N1
18
Decals Group

Not for
Reproduction
Footnotes:
Manual No. 710429322" VARIABLE SPEED 3N1
19
Decals Group
Part No Descri
p
tionItem Qty
1 7104747 1 DECAL, Start, React
2 7104744 1 DECAL, Drive, React
3 7104746 1 DECAL, Stop, React
4 7104745 1 DECAL, Run, React
5 7101394 1 DECAL, Warning, Rear Discharge Door
6 7102275 1 DECAL, Customer Service, MY08, Snapper
7 7104852 1 DECAL, Briggs Engine, 700 Series
8 7104875 1 DECAL, Briggs Engine, Front Cover “SPX” Series
9 7103963 1 DECAL, Front Shroud, Snapper Logo
10 7103970 1 DECAL, Battery
11 7103965 1 DECAL, Handle, Domed Turtle
12 7104762 1 DECAL, Handle, React Drive
13 7102746 1 DECAL, Spark Arrestor
14 7013010 1 DECAL, Danger, Cut Finger
