Snapper Yard Cruiser YZ16424BVE Operation and maintenance manual

Safety Instructions & Operator’s Manual for
YARD CRUISER
HYDRO DRIVE
SERIES 4
MODELS
YZ16424BVE
YZ20484BVE
MODEL NUMBER EXPLANATION
Y Z 16 42 4 B V E
MODEL DESIGNATION ENGINE OPTIONS
DRIVE SYSTEM TYPE ENGINE TYPE
ENGINE HORSE POWER ENGINE MODEL
CUTTING WIDTH SERIES DESIGNATION
Y
– Yard Cruiser
Z – Zero Turning Radius 16 – 16 HP Engine 20 – 20 HP Engine 42 - 42” Cutting Deck 48 - 48” Cutting Deck 4 - Series Designation B - Briggs Engine V – Over Head Valve
E - Electric Start
Thank you for buying a SNAPPER Product! Before operating your YARD CRUISER, read this manual carefully
and pay particular attention to the “IMPORTANT SAFETY INSTRUCTIONS” on Pages 2 & 3. Remember that all
power equipment can be dangerous if used improperly. Also keep in mind that SAFETY requires careful use in
accordance with the operating instructions and common sense!
COPYRIGHT © 2002
SNAPPER INC.
ALL RIGHTS RESERVED MANUAL No. 6-3260 (REV. 1, 6/28/02)

2
IMPORTANT SAFETY INSTRUCTIONS
WARNING: This powerful cutting machine is capable of amputating hands and feet and can throw objects that
can cause injury and damage! Failure to comply with the following SAFETY instructions could result in serious
injury or death to the operator or other persons. The owner of the machine must understand these instructions
and must allow only persons who understand these instructions to operate machine. Each person operating the
machine must be of sound mind and body and must not be under the influence of any substance, which might
impair vision, dexterity or judgment. If you have any questions pertaining to your machine which your dealer
cannot answer to your satisfaction, call or write the Customer Service Department at SNAPPER, McDonough,
Georgia 30253. Phone: [phone]).
PROTECTION FOR CHILDREN
Tragic accidents can occur if the operator is not alert
to the presence of children. Children are often
attracted to the machine and the mowing activity.
Never assume that children will remain where you last
saw them.
1. KEEP children out of the mowing area and under
the watchful care of a responsible adult.
2. DO NOT allow children in yard when machine is
operated (even with the blade OFF).
3. DO NOT allow children or others to ride on
machine or on attachments (even with the blades
OFF). They may fall and be seriously injured.
4. DO NOT allow pre-teenage children to operate
machine.
5. ALLOW only responsible adults & teenagers with
mature judgment under close adult supervision to
operate machine.
6. DO NOT operate blades in reverse. STOP BLADES.
LOOK and SEE behind and down for children, pets
and hazards before and while backing.
7. USE EXTRA CARE when approaching blind
corners, shrubs, trees, or other objects that may
obscure vision.
PROTECTION AGAINST TIPOVERS
Slopes are a major factor related to loss-of-control
and tip-over accidents, which can result in severe
injury or death. All slopes require extra CAUTION. If
you cannot back up the slope or if you feel uneasy on
the slope, DO NOT mow it. Use extra care with grass
catchers or other attachments; these affect the
handling and the stability of the machine.
1. DO NOT operate machine on slopes exceeding 15
degrees (27% grade).
2. Exercise EXTREME CAUTION on slopes above 10
degrees (18% grade). Turn blades OFF when
traveling uphill. Use a slow speed and avoid
sudden or sharp turns.
3. DO NOT operate machine back and forth across
face of slopes. Operate up and down. Practice on
slopes with blades off.
4. AVOID uphill starts. If machine stops going uphill
or tires lose traction, turn blades OFF and back
slowly down the slope.
PROTECTION AGAINST TIPOVERS
(Continued From Previous Column)
5. STAY ALERT for holes and other hidden hazards.
Tall grass can hide obstacles. Keep away from
ditches, washouts, culverts, fences and
protruding objects.
6. KEEP A SAFE DISTANCE (at least 3 feet) away
from edge of ditches and other drop offs. The
machine could turn over if an edge caves in.
7. Always begin forward motion slowly and with
caution.
8. Use weights or a weighted load carrier in accordance
with instructions supplied with a grass catcher. DO
NOT operate machine on slopes exceeding 10
degrees (18% grade) when equipped with grass
catcher.
9. DO NOT put your foot on the ground to try to
stabilize the machine.
10. DO NOT operate machine on wet grass. Reduced
traction could cause sliding.
11. DO NOT operate machine under any condition
where traction, steering or stability is doubtful.
PREPARATION
1. Read, understand, and follow instructions and
warnings in this manual and on the machine,
engine and attachments. Know the controls and
the proper use of the machine before starting.
2. Only mature, responsible persons shall operate
the machine and only after proper instruction.
3. Data indicates that operators age 60 and above,
are involved in a large percentage of mower-
related injuries. These operators should evaluate
their ability to operate the mower safely enough to
protect themselves and others from serious injury.
4. Handle fuel with extra care. Fuels are flammable
and vapors are explosive. Use only an approved
fuel container. DO NOT remove fuel cap or add
fuel with engine running. Add fuel outdoors only
with engine stopped and cool. Clean spilled fuel
from machine. DO NOT smoke.
5. Practice operation of machine with BLADES OFF
to learn controls and develop skills.
6. Check the area to be mowed and remove all
objects such as toys, wire, rocks, limbs and other
objects that could cause injury if thrown by blade
or interfere with mowing.

3
IMPORTANT SAFETY INSTRUCTIONS
PREPARATION
(Continued From Previous Page)
7. Keep people and pets out of mowing area.
Immediately STOP blades, STOP engine, and
STOP machine if anyone enters the area.
8. Check shields, deflectors, switches, blade
controls and other safety devices frequently for
proper operation and location.
9. Make sure all safety decals are clearly legible.
Replace if damaged.
10. Protect yourself when mowing and wear safety
glasses, long pants and substantial footwear.
11. Know how to STOP blades and engine quickly
in preparation for emergencies.
12. Use extra care when loading or unloading the
machine into a trailer or truck.
13. Check grass catcher components frequently for
signs of wear or deterioration and replace as
needed to prevent injury from thrown objects
going through weak or worn spots.
OPERATION
1. Mount and dismount machine from left side.
2. Start engine from operator's seat, if possible.
Make sure blades are OFF and parking brake is
set.
3. DO NOT leave machine with engine running.
STOP engine, STOP blades, SET brake, and
Remove key before leaving operators position
of any reason.
4. DO NOT operate machine unless properly
seated with feet on feet rests or pedal(s).
5. STOP BLADES and ENGINE and make sure
blades have stopped before removing grass
catcher or unclogging mower to prevent loss of
fingers or hand.
6. Blades must be OFF except when cutting grass.
Set blades in highest position when mowing
over rough ground.
7. Keep hands and feet away from rotating blades
underneath deck. DO NOT place foot on ground
while BLADES are ON or machine is in motion.
8. DO NOT operate machine without entire grass
catcher or guards in place. DO NOT point
discharge at people, passing cars, windows or
doors.
9. Slow down before turning.
10. Watch out for traffic when near or crossing
roadways.
11. STOP engine immediately after striking an
obstruction. Inspect machine and repair
damage before resuming operation.
12. Operate machine only in daylight or with good
artificial light.
13. Move joystick (if equipped) SLOWLY to
maintain control during speed and directional
changes.
OPERATION
(Continued From Previous Column)
14. Exercise CAUTION when pulling loads. Limit loads
to those you can safely control and attach loads to
hitch plate as specified with SNAPPER attachment
instructions.
15. DO NOT operate engine in enclosed areas. Engine
exhaust gases contain carbon monoxide, a deadly
poison.
MAINTENANCE
1. DO NOT store machine or fuel container inside
where fumes may reach an open flame, spark or
pilot light such as in a water heater, furnace, clothes
dryer or other gas appliance. Allow engine to cool
before storing machine in an enclosure. Store fuel
container out of the reach of children in a well
ventilated, unoccupied building.
2. Keep engine free of grass, leaves or excess grease
to reduce fire hazard and engine overheating.
3. When draining fuel tank, drain fuel into an approved
container outdoors and away from open flame.
4. Check brakes frequently; adjust, repair or replace as
needed.
5. Keep all bolts, nuts and screws properly tight.
Check that all cotter pins are in proper position.
6. Always provide adequate ventilation when running
engine. Exhaust gases contain carbon monoxide,
an odorless and deadly poison.
7. Disconnect negative (black) cable from battery
before performing maintenance or service.
Cranking engine could cause injury.
8. DO NOT work under machine without safety blocks.
9. Service engine and make adjustments only when
engine is stopped. Remove spark plug wire(s) from
spark plug(s) and secure wire(s) away from spark
plug(s).
10. DO NOT change engine governor speed settings or
overspeed engine.
11. Lubricate machine at intervals specified in manual
to prevent controls from binding.
12. Mower blades are sharp and can cut. Wrap the
blades or wear heavy leather gloves and use
CAUTION when handling them.
13. DO NOT test for spark by grounding spark plug
next to spark plug hole; spark plug could ignite gas
exiting engine.
14. Have machine serviced by an authorized SNAPPER
dealer at least once a year and have the dealer
install any new safety devices.
15. Use only genuine SNAPPER replacement parts to
assure that original standards are maintained.
16. If battery is removed, DO NOT operate engine
without insulating Positive + battery cable terminal
with electrical tape, or sparking from battery cables
can result.

5
TABLE OF CONTENTS
IMPORTANT SAFETY INSTRUCTIONS.........................................................................2-3
TABLE OF CONTENTS......................................................................................................4
SECTION 1 - FAMILIARIZATION.......................................................................................5
SECTION 2 - OPERATING INSTRUCTIONS..................................................................6-9
Pre-start Checklist ............................................................................................6-7
Rolling Machine w/o Engine Running................................................................6
Starting & Stopping Engine, Propelling Mower .............................................7-8
Starting & Stopping Mower Blades ....................................................................8
Starting & Stopping Wheel Drive........................................................................8
Setting & Releasing Parking Brake.....................................................................8
Cutting Height Adjustment..................................................................................9
SECTION 3 - MAINTENANCE INSTRUCTIONS ........................................................10-13
Service – After First Five Hours........................................................................10
Change Engine Oil ..........................................................................................10
Check Mower Blade........................................................................................10
Check Mower Drive Belt .................................................................................11
Check Transaxle Drive Belts..........................................................................11
Service - Every 25 Operating Hours .................................................................11
Check Engine..............................................................................................11-12
Check Mower Components............................................................................12
Mower Blade Spindle – Lubrication .........................................................12-13
Mower Deck Linkage – Lubrication...............................................................13
Front Wheel Bearings - Lubrication..............................................................13
Front Caster Wheel Pivot Shaft .....................................................................13
Parking Brake Pivot Bushings.......................................................................13
Service - Annually...............................................................................................14
Engine ..............................................................................................................14
Air Filter............................................................................................................14
Oil Filter............................................................................................................14
Engine Oil.........................................................................................................14
Transaxle..........................................................................................................14
Fuel Filter.........................................................................................................14
Storage – Out of Season....................................................................................14
SECTION 4 - ADJUSTMENTS AND REPAIR.............................................................15-22
Engine Adjustments & Repair...........................................................................15
Mower Deck & Components Adjustments.......................................................15
Mower Drive Belt Adjustment ...........................................................................15
Mower Drive Belt Replacement.........................................................................15
Belt Removal & Replacement.......................................................................15-16
Blade Brake.........................................................................................................16
Mower Deck Adjustment (Levelness - Side to Side 48” Deck)..................16-17
Mower Deck Adjustment (Front to Rear Pitch 48” Deck) ...............................17
Mower Deck Adjustment (Side to Side, 42” & 48” Decks)..............................18
Mower Deck Adjustment (Front to Rear Pitch, 42” Decks) ............................19
Mower Deck Timing Rod – (42” Decks)............................................................19
Wheel Brake Adjustment...................................................................................19
Mower Blade Wear Limits..................................................................................20
Blade Sharpening...............................................................................................20
Blade Replacement ............................................................................................20
Battery Removal .................................................................................................21
Battery Installation .............................................................................................21
Battery Service & Charging...............................................................................21
New Battery Preparation...............................................................................21-22
Battery Testing ...................................................................................................22
TROUBLESHOOTING.................................................................................................23-24
Maintenance/Replacement Parts ......................................................................24
SERVICE SCHEDULE......................................................................................................25
WARRANTY......................................................................................................................26
PRIMARY MAINTENANCE..........................................................................................27-30
PRODUCT REGISTRATION FORM.................................................................................31

6
Section 1 - FAMILIARIZATION
FIGURE 1.1
1.1 INTRODUCTION
This manual has been prepared for the operator’s of the
SNAPPER YARD CRUISER. Its purpose, aside from
recommending standard operating procedures and routine
service requirements, is to promote SAFETY through the
use of accepted operating practices. Read, Understand and
Follow the IMPORTANT SAFETY INSTRUCTIONS on
Pages 2 and 3 of this manual and All SAFETY messages
on the YARD CRUISER and its attachments before
operating. SNAPPER recommends returning the YARD
CRUISER to an authorized SNAPPER dealer annually for
inspection and addition of any new devices which might
upgrade the safetyof the mower.
1.2 NOMENCLATURE
The nomenclature drawing above, Figure 1.1, shows the
essential parts of the SNAPPER YARD CRUISER. It is
recommended that all operators of this equipment
become thoroughly familiar with the controls,
components, and operation of this machine before
operating. Specific details involving the engine are found
in the separate engine owner’s manual. Study these
manuals before operating and keep both handy for future
reference. For the nearest SNAPPER dealer in your
area, check the yellow pages under the heading LAWN
MOWERS. For engine parts and service, look for the
engine manufacturer’s dealers under the heading,
ENGINES - gasoline.
KEY
SWITCH
JOYSTICK
CONTROL
HANDLE
OPERATOR’S
SEAT
FUEL
TANK
PARKING
BRAKE BRAKE
RELEASE
BUTTON
CHOKE
CONTROL
BLADE
SWITCH
ENGINE
SPEED
CONTROL
DECK LIFT
HANDLE
DISCHARGE
DEFLECTOR
IMPORTANT! The figures and illustrations in
this manual are provided for reference only
and may differ from your specific model.
Contact your Snapper dealer if you have
questions.

7
Section 2 - OPERATING INSTRUCTIONS
2.1 PRE-START CHECK LIST
Make the following checks and perform the service
required before each start-up.
2.1.1. Check tires and add or release air as needed
to bring pressure to 12 P.S.I. in front and 12 P.S.I. in
rear tires.
2.1.2. Check guards, deflectors and covers to make
sure all are in place and securely tightened.
2.1.3. Check engine oil and add oil as needed to
bring level up to the FULL mark. Refer to engine
owner’s manual for oil specifications. See Figure 2.1.
FIGURE 2.1
2.1.4. Check Blade switch to insure it works freely.
Switch is pulled “OUT” into the “ON” position for
blade engagement or pushed back “IN” into the
“OFF” position for blade disengagement. See
Figure 2.2. IMPORTANT: Disengagement stops the
blades rotation.
FIGURE 2.2
2.1.5. Clean exterior surfaces of cutting deck and
engine of any accumulation of dirt, grass, oil, etc.
Keep engine air intake screen and cooling fins clear
at all times.
2.1.6. Add fuel to tank of the YARD CRUISER
outside where fumes can safely dissipate. Make
sure fuel filler cap is tight and vent is open after
refueling. See Figure 2.3. Refer to engine owner’s
manual for fuel specifications.
FIGURE 2.3
IMPORTANT: To roll the machine without the engine
running, pressure within the hydraulic pumps must be
released. Tilt seat up and move control lever down to
release pressure. NOTE: Control lever must be in the
“UP” position to drive machine. See Figure 2.4.
DO NOT USE CONTROL TO RELEASE PRESSURE AND
COAST DOWN SLOPES. RELEASE PRESSURE ONLY WHEN
MACHINEMOTIONCANBECONTROLLEDANDENGINEOFF.
FIGURE 2.4
SAFE LEVEL
AREA
ENGINE OIL DIPSTICK
MOVE CONTROL
LEVER UP TO
DRIVE MACHINE
CONTROL
LEVER
MOVE CONTROL LEVER
DOWN TO ROLL MACHINE
BATTERY
FUEL
FILLER
CAP OPEN
VENT
FUEL
TANK
PUSH “IN” TO
DISENGAGE
PULL “OUT”
TO ENGAGE
BLADE
SWITCH

8
Section 2 - OPERATING INSTRUCTIONS
IMPORTANT: This YARD CRUISER is equipped with
hydrostatic drive. The forward, rearward and
steering movement of the machine is controlled by a
joystick lever. Joystick operations should be
performed only from the operator’s position in the
seat. A small movement of the joystick can cause the
machine to move instantly. Move joystick very
carefully and slowly.
1. Always move the joystick to the center position to
“STOP” machine. IMPORTANT: To stop machine
always return the joystick with hand assistance to
the neutral position. Always engage parking brake
when leaving operator’s seat.
2. Move the joystick forward to propel the machine
forward.
3. Move the joystick rearward to propel the machine
backward.
4. Move the joystick to the right to rotate the front of
the machine in circular motion to the right, as in
turning around to go in a different direction.
5. Move the joystick to the left to rotate the front of
the machine in circular motion to the left, as in
turning around to go in a different direction.
2.2 STARTING & OPERATION
2.2.1. ENGINE (ELECTRIC START)
IMPORTANT: When the ignition key is turned to
“START”, the engine will not turn over and will not start
unless the Parking Brake is engaged and the Blade
Switch is in the “Off” position. The operator should be
in the seat. Start engine as follows:
1. Move joystick lever to (N) Neutral position. See
Figure 2.5.
2. Make certain the blade switch is in the “Off”
position. See Figure 2.6.
3. Make certain the parking brake is engaged. See
Figure 2.5.
4. Open vent on fuel filler cap by turning
counterclockwise. IMPORTANT: Failure to open
vent on the fuel filler cap can cause engine to stall.
See Figure 2.3.
5. Pull choke control up to choke position.
6. Move engine speed control to the “Fast” (Rabbit)
position. See Figure 2.6.
7. Turn key to the “START” position until engine
starts. See Figure 2.5. NOTE: If after 5 seconds of
cranking the engine and it does not start, release the
key. Attempt starting again after waiting for
approximately 20 seconds.
8. After engine starts, push choke control in to the
“OFF” position, move engine speed control to the
desired speed position, allow a brief warm-up until
engine runs smooth.
WARNING
DO NOT leave machine with engine running. STOP
engine. STOP blades. Engage park brake. Remove
key. DO NOT park machine on slopes.
FIGURE 2.5
FIGURE 2.6
(Continued on Next Page)
RUN
POSITION TURN KEY
TO START
POSITION
DECAL VIEWED FROM
OPERATOR’S POSITION
JOYSTICK IS IN
NEUTRAL POSITION
PARKING BRAKE
ENGAGED
PULL CHOKE
CONTROL OUT
TO START ENGINE
MOVE ENGINE
SPEED CONTROL
TO FAST POSITION

9
Section 2 - OPERATING INSTRUCTIONS
2.2.2. MOWER BLADE
1. With engine running, move engine speed control
to the Rabbit or “Fast” position.
2. Pull the blade switch out into the “ON” position to
engage the mower blades. See Figure 2.7.
FIGURE 2.7
3. Release the parking brake. See Figure 2.7.
WARNING
DO NOT operate blades in reverse. STOP Blades.
LOOK and SEE behind and down for children, pets
and hazards before and while backing.
4. Move joystick carefully in the desired direction to
propel the machine. A small movement of the
joystick can cause the machine to move instantly.
Move joystick carefully and slowly.
2.3 STOPPING
2.3.1. ENGINE
1. Stop engine by turning key to the “OFF” position.
See Figure 2.8.
FIGURE 2.8
WARNING
DO NOT leave the machine with the engine running.
STOP engine. STOP blades. Engage parking brake.
Remove key. DO NOT park machine on slopes.
2.3.2. WHEEL DRIVE
1. Stop motion of riding mower by moving joystick
to neutral (N) position. See Figure 2.8.
2.3.3. MOWER BLADE
1. Push the blade switch in to “OFF” position to
disengage or stop the mower blades. See Figure 2.7.
WARNING
Blades must stop rotating in 5 seconds or less after
blades have been turned off. DO NOT operate
machine until blade brake has been repaired and
functioning properly. Contact your SNAPPER dealer
for assistance.
2.3.4. PARKING BRAKE
1. Manually position joystick in the neutral position.
2. Engage parking brake by pushing button at the
top of lever and then pulling the parking brake lever
slowly back to the “ON” position.
3. Release parking brake by pushing button at the
top of lever and moving brake lever forward to the
“OFF” position. Refer Figure. 2.7.
DISENGAGE
PARKING
BRAKE
PULL BLADE
SWITCH OUT TO
THE “ON” POSITION
ENGINE SPEED
CONTROL IN THE
“FAST” POSITION
TURN KEY TO
“OFF” OR STOP
POSITION
DECAL VIEWED FROM
OPERATOR’S POSITION

10
Section 2 - OPERATING INSTRUCTIONS
2.3.5. CUTTING HEIGHT ADJUSTMENT
This machine has seven different cutting height
positions. IMPORTANT: When positioning the
cutting deck into a higher cutting position, pull up on
the deck lift handle only, it is not necessary to pull
up on the release lever at the same time. Use the
release lever when moving deck cutting height to a
lower cutting position.
1. Grasp both handles together to disengage
latch.
2. Raise or lower handles to desired height.
3. Release lower handle to engage latch. See
Figure 2.9.
FIGURE 2.9
DECK LIFT
HANDLE DECK LIFT HANDLE SHOWN
IN HIGHEST NOTCH.
RELEASE
LEVER
DETENT
PLATE
CONNECTING BAR OMITTED IN THIS
VIEW FOR CLARITY

11
Section 3 - MAINTENANCE
3.1 INTRODUCTION
To retain the quality of the YARD CRUISER, use
genuine SNAPPER replacement parts only. Contact a
local SNAPPER dealer for parts and service assistance.
For the correct part or information for a particular mower,
always mention the model and serial number.
3.2 SERVICE - AFTER FIRST 5 HOURS
WARNING
DO NOT attempt any adjustments, maintenance or
service with the engine or blade running. STOP
blade. STOP engine. Set brake. Remove key. Remove
spark plug wire from spark plug and secure wire
away from spark plug. Engine and components can
be extremely hot. Avoid burns by allowing engine
and components sufficient time to cool.
3.2.1. CHANGE ENGINE OIL
1. Place bricks or wooden blocks under the front
wheels to lower rear of engine.
2. Place a 4 quart minimum capacity container
under the end of the oil drain.
3. Loosen or remove oil fill cap on engine.
4. Install the drain hose (Supplied in hardware bag)
onto drain plug nipple and place hose into drain
container.
5. Rotate drain plug counter-clockwise and pull out
to open and allow oil to drain out. See Figure 3.1.
FIGURE 3.1
6. After all the oil has drained, close the drain by
pushing in and rotating clockwise to close. Wipe up
any oil that may have spilled. Dispose of drained oil
properly. See Figure 3.1.
7. Change oil filter at every oil change. Refer to your
engine owner’s manual for service instructions.
8. Fill engine crankcase with new oil. Refer to your
engine owner’s manual for oil specifications.
3.2.2. SERVICE ENGINE AIR CLEANER
The engine is equipped with a dual element air
cleaner. Both the foam pre-cleaner and cartridge
require service. Refer to Engine Owner's Manual for
recommended service procedures.
3.2.3. CHECK MOWER BLADE
1. Make sure fuel cap is on tight. Start engine and
allow it to run until engine runs out of fuel. Close vent
on fuel filler cap. See Figure 2.3.
2. Engage parking brake.
3. Turn key to “OFF” position and remove key from
ignition switch.
WARNING
Wear heavy leather gloves when handling or working
around cutting blades. Blades are extremely sharp and
can cause severe injury.
4. Carefully stand YARD CRUISER on rear bumper.
It may be necessaryto have help to stand unit up.
5. Check torque of blade mounting bolts or nuts.
Torque to:
42” Decks -- 30 to 40 ft. lbs.
48” Decks – 80 to 90 ft. lbs.
See Figure 3.2.
6. Check blade for sharpness, wear and damage.
Refer to Section “BLADE WEAR LIMITS”.
FIGURE 3.2
7. Check blade for straightness.
WARNING
DO NOT use a cutting blade that shows signs of
excessive wear or damage. Refer to Section
“MOWER BLADE REPLACEMENT” for proper blade
inspection and service procedures.
INSTALL HOSE
ONTO OIL DRAIN
NIPPLE
OIL DRAIN
ROTATE 1/4 TURN
COUNTERCLOCKWISE
AND PULL OUT TO
DRAIN ENGINE OIL.
BLADE MOUNTING TORQUE:
42” -- 30 TO 40 FT. LBS.
48” -- 80 TO 90 FT. LBS.
TWIN & TRIPLE BLADE DECK

12
Section 3 - MAINTENANCE
3.2.4. CHECK MOWER DRIVE BELT
1. Footrest Removal
a. Pull deck lift handle to highest cutting
position. See Figure 3.3.
b. Remove the knobs that secure the corners of
the footrest.
c. Remove footrest.
FIGURE 3.3
2. Checking Mower Belt Tension
The idler and spring provide proper belt tension and
require no adjustment. If belt is frayed, slit, severed
or belt strands exposed, replace belt before
operating mower.
3.2.5. CHECK TRANSAXLE DRIVE BELT
1. Checking Transaxle Belt Tension
The transaxle drive belt requires no adjustment. If
belt is frayed, slit, severed or belt strands exposed,
replace belt before operating mower.
3.3 SERVICE EVERY 25 OPERATING HOURS
3.3.1. ENGINE
1. Engine Cooling System
The engine cooling system consists of an engine
shroud and engine fins. These should be kept clean
and free of debris as needed or cleaned.
2. Engine Oil
Change engine oil. See Section on CHANGE ENGINE
OIL. Refer to engine owner’s manual for oil
specifications.
3. Oil Filter
Change engine oil filter. Refer to engine owner’s
manual for filter specifications.
4. Fuel Filter
Refer to engine owner’s manual for service instructions.
5. Air Filter
Refer to engine owner’s manual for service
instructions.
a. 20 Hp Engines: Change air filter. Remove bolts
that secure air cleaner cover. See Figure 3.4.
IMPORTANT: When cover is removed, you are
viewing the carburetor side of the air filter, which will
appear clean. Remove filter and pre-cleaner for
inspection.
FIGURE 3.4
b. Refer to engine owner's manual for cleaning
and service instructions. Remove and clean engine
air pre-cleaner. Remove and replace engine air
cleaner. See Figure 3.5. Install pre-cleaner and air
cleaner per engine owner’s manual.
FIGURE 3.5
DECK LIFT HANDLE
SHOWN
POSITIONED IN
HIGHEST NOTCH.
RELEASE
LEVER
DECK LIFT
HANDLE
AIR CLEANER
COVER
AIR CLEANER
RETAINING BOLTS
NOTE: YELLOW TABS MUST BE
COMPLETELY INSERTED INTO SLOTS
AIR CLEANER
AIR PRE-
CLEANER

13
Section 3 - MAINTENANCE
3.3 SERVICE EVERY 25 OPERATING HOURS
3.3.1. ENGINE
5. Air Filter
c. Reinstall air cleaner cover. Insert tabs located on
the engine cover into corresponding slots in air
cleaner cover. IMPORTANT: The yellow tabs must
be completely inserted into air cleaner cover or the
compartment will not be completely sealed to
prevent debris from entering into the carburetor.
a. 16 HP Engines: Change air filter. Pull up and
rotate the air cleaner latch to remove cleaner cover.
See Figure 3.4.
IMPORTANT: When cover is removed, you are
viewing the carburetor side of the air filter, which will
appear clean. Remove filter and pre-cleaner for
inspection.
FIGURE 3.4
b. Refer to engine owner's manual for cleaning and
service instructions. Remove and clean engine air
pre-cleaner. Remove and replace engine air
cleaner. See Figure 3.5. Install pre-cleaner and air
cleaner per engine owner’s manual.
FIGURE 3.5
c. Reinstall air cleaner cover. Insert tabs located at
the bottom of the cover into corresponding slots in
engine cover. Position cover and engage latch over
cover and rotate and push down to lock.
3.3.2. MOWER COMPONENTS
1. Mower Drive Belt
Check belt for proper tension. No adjustment required.
Replace belt as needed.
2. Mower Blade
Check blade for sharpness, wear, damage, and
torque. See the section on Mower Blade
Replacement/Repair.
3. Mower Deck Levelness
Check mower deck for proper levelness. Adjust as
required. See section on Mower Deck Adjustment -
Levelness.
WARNING
Lifting or letting down the machine unassisted can
cause severe injury. Always have assistance from
another person when supporting the weight of
machine.
4. Cleaning Mower Deck
a. Make sure fuel cap is on tight. Start engine
and allow it to run until engine runs out of fuel.
Close vent on fuel filler cap. See Figure 2.3.
b. Remove key from ignition switch.
c. Remove spark plug wire(s) and secure away
from spark plug(s).
d. Carefully stand YARD CRUISER on rear
bumper.
e. Clean underside of mower deck, removing all
accumulation of grass clippings and debris.
f. Lower YARD CRUISER to ground. Clean top
of deck, removing all grass clippings and debris.
5. Mower Blade Spindle - Lubrication
a. Lubricate spindle bearings with three shots of
general purpose grease from grease gun. See
Figure 3.6.
FIGURE 3.6
LUBRICATE
SPINDLE
BEARINGS
TOP VIEW OF 48” DECK
AIR CLEANER
COVER
AIR CLEANER
LATCH
AIR CLEANER
AIR PRE-
CLEANER

14
Section 3 - MAINTENANCE
WARNING
DO NOT attempt any adjustments, maintenance or
service with the engine or blade running. STOP
blade. STOP engine. Set brake. Remove key. Remove
spark plug wire from spark plug and secure wire
away from spark plug. Engine and components can
be extremely hot. Avoid burns by allowing engine
and components sufficient time to cool.
5. Mower Blade Spindle - Lubrication
b. 42” Deck spindle assemblies are equipped
with a grease fitting located underneath the
deck. Lubricate spindle bearings with three shots
of general purpose grease from grease gun.
6. Mower Deck Linkage - Lubrication
Lubricate all mower deck linkage pivot points with a
light coat of motor oil.
3.3.3. YARD CRUISER - LUBRICATION
1. Front Wheel Bearings
Lubricate front wheel bearings with five shots of
general purpose grease from grease gun. See
Figure 3.7.
FIGURE 3.7
2. Front Caster Wheel Pivot Shaft
The front frame cover will not have to be removed to
lubricate the pivot shaft. The access hole is at the rear
of the front structure underneath frame cover.
a. The pivot shaft grease fitting can be accessed
through a hole at the rear of the front structure.
Lubricate pivot shaft with three shots of general
purpose grease from grease gun. See Figure 3.8.
FIGURE 3.8
3. Parking Brake Pivot Bushings
a. Make sure fuel cap is on tight. Start engine
and allow it to run until engine runs out of fuel.
Close vent on fuel filler cap.
b. Remove key from ignition switch.
c. Remove spark plug wire(s) and secure away
from spark plug(s).
d. Carefully stand YARD CRUISER on rear
bumper.
e. Lubricate both pivot bushings with three shots
general purpose grease from grease gun. See
Figure 3.9
FIGURE 3.9
YARD CRUISER SHOWN WITH DECK
REMOVED. DECK REMOVAL NOT
NECESSARY FOR LUBRICATION.
LUBRICATE BOTH
PIVOT BUSHINGS
LUBRICATE FRONT WHEEL BEARINGS
FRONT STRUCTURE ACCESS HOLE
LUBRICATE PIVOT
SHAFTS
FRONT COVER
IS REMOVED

15
Section 3 – MAINTENANCE
3.4 SERVICE - ANNUALLY
Perform all maintenance as described in the maintenance
schedule.
3.4.1. Engine
Service engine according to engine owner’s manual.
3.4.2. Air Filter
Refer to engine owner’s manual for service
instructions.
3.4.3. Oil Filter
Refer to engine owner’s manual for service
instructions.
3.4.4. Engine Oil
Refer to engine owner’s manual for service
instructions.
3.4.5. Transaxle
IMPORTANT: DO NOT try to open reservoir cap at
any time. The transaxle is maintenance free. The
transaxle does not require any fluid or any
service. If there is any problem: leakage,
malfunction or etc. return the Yard Cruiser
immediately to the nearest authorized Snapper
dealer for service.
3.4.6. Fuel Filter
Service fuel filter as instructed below. Turn key to
“OFF” position. Engine MUST be stopped and
MUST be cold before removing filter. Perform filter
change when fuel tank and fuel line is empty.
1. Remove hose clamps from fuel filter.
2. Remove fuel lines from filter. Discard filter.
3. Install new fuel filter. Reinstall hose clamps.
See Figure 3.8.
FIGURE 3.8
3.5 STORAGE (OUT OF SEASON)
If desired, the YARD CRUISER can be stored on the
rear bumper. Perform the following procedures to insure
the YARD CRUISER will operate properly when taken
out of storage.
3.5.1. Thoroughly clean the YARD CRUISER by
removing all grass clippings and debris.
3.5.2. Perform maintenance and lubrication as
described in the previous sections.
3.5.3. Drain fuel from fuel tank.
3.5.4. Start engine and allow it to run until engine
runs out of fuel. This allows the carburetor and
fuel system to remain clean during storage.
3.5.5. Remove battery. Refer to Section
“BATTERY REMOVAL AND STORAGE”.
3.5.6. Close vent on fuel filler cap. Remove key.
3.5.7. Carefully stand YARD CRUISER on rear
bumper in desired location for storage.
NEW FUEL
FILTER
HOSE
CLAMPS

16
Section 4 - ADJUSTMENTS & REPAIR
WARNING
DO NOT attempt any adjustments, maintenance or
service with the engine or blade running. STOP
blade. STOP engine. Set brake. Remove key. Remove
spark plug wire from spark plug and secure wire
away from spark plug. Engine and components can
be extremely hot. Avoid burns by allowing engine
and components sufficient time to cool.
4.1 ENGINE ADJUSTMENTS & REPAIR
Refer to the engine owner’s manual for those adjustments
and/or repairs that can be made by the owner.
4.2 MOWER DECK & COMPONENT ADJUSTMENTS
The following mower deck and component adjustments
and repairs can be made by the owner. However, if
there is difficulty in achieving these adjustments and
repairs, it is recommended that these repairs be made by
an authorized SNAPPER dealer.
4.2.1. MOWER DRIVE BELT ADJUSTMENT
The 42” and 48”mower deck drive belts do not
require any adjustment. If the belt does not drive
blade properly, replace belt as needed. See Section
“Belt Replacement”. Belt routing shown on this
page. See Figure 4.1.
4.2.2. MOWER DRIVE BELT REPLACEMENT
Inspect mower drive belt. Replace belt if signs of
excessive wear and/or damage are present.
4.2.3. BELT REMOVAL
1. Remove foot rest.
2. Remove old belt.
4.2.4. BELT REPLACEMENT
1. Route new belt around electric clutch pulley. See
Figure 4.2.
2. Route belt around stationary idler.
3. Remove spring that is connected to idler pulley.
Loosen nut and bolt that secures idler pulley to idler
arm. Route belt between belt guide and idler pulley.
(Continued On Next Page)
FIGURE 4.1
FIGURE 4.2
SPINDLE PULLEY SPINDLE PULLEY
IDLER PULLEY STATIONARY
PULLEY
ELECTRIC CLUTCH
PULLEY
42” DECKS
ELECTRIC
CLUTCH
PULLEY
SPINDLE
PULLEY
STATIONARY
PULLEY
IDLER
PULLEY
SPINDLE
PULLEY
48” DECK
ROUTE MOWER BELT AROUND
ELECTRIC CLUTCH PULLEY
MOWER
BELT
ELECTRIC
CLUTCH
VIEW SHOWN FROM UNDERNEATH WITH DECK
REMOVED, DECK REMOVAL IS NOT NECESSARY
FOR MOWER BELT REPLACEMENT.

17
Section 4 - ADJUSTMENTS & REPAIR
WARNING
DO NOT attempt any adjustments, maintenance or
service with the engine or blade running. STOP
blade. STOP engine. Set brake. Remove key. Remove
spark plug wire from spark plug and secure wire
away from spark plug. Engine and components can
be extremely hot. Avoid burns by allowing engine
and components sufficient time to cool.
4.2.4. BELT REPLACEMENT
(Continued From Previous Page)
4. Route belt onto spindle pulley. Make sure belt is
inside spindle pulley belt guide.
5. Reinstall idler pulley spring. See Figure 4.3.
NOTE: The idler belt guide should be positioned so
the locator tab fits into the corresponding hole found
on the idler arm. See Figure 4.3. Tighten bolt
securely.
6. Reinstall front frame cover.
NOTE: FOR ALL BELT REPLACEMENT PARTS
IDENTIFICATION NUMBERS SEE PAGE 24.
FIGURE 4.3
4.2.5. BLADE BRAKE
The blade switch engages the electric clutch when
pulled out to the “ON” position. When the blade
switch is in the “ON” position the cutting blade(s)
are engaged. The blade switch disengages the
electric clutch when the blade switch is pushed in to
the “OFF” position. When the blade switch is in the
“OFF” position the cutting blade(s) are disengaged.
The electric clutch is non-adjustable. The blade(s)
should stop rotation in 5 seconds or less. If the
electric clutch fails to stop the blade(s) rotation in 5
seconds, contact an authorized SNAPPER dealer to
repair or replace.
WARNING
Blades must stop rotating in 5 seconds or less after
blades have been turned off. DO NOT operate
machine until blade brake has been repaired and
functioning properly. Contact your SNAPPER dealer
for assistance.
4.2.6. MOWER DECK ADJUSTMENT (LEVELNESS)
Side-To-Side (48” Decks)
Before making deck leveling adjustments, check
the tire pressure. Add or release air as needed to
bring pressure to 12 P.S.I. in front and 12 P.S.I. in
rear tires. If tires are properly inflated and mowing is
still uneven, adjust side-to-side deck levelness first
as follows:
1. Place YARD CRUISER on a smooth level
surface.
2. Remove floor pan.
3. Rotate outside blades so tips are pointed to
the sides of deck. See Figure 4.4. Measure the
distance from blade tips to floor. If the
measurement is within 1/8” from side-to-side, the
deck levelness is satisfactory. If the difference
from side-to-side is greater than 1/8”, continue to
Step 4 for adjustment.
FIGURE 4.4
(Continued On Next Page)
IDLER ARM AND BELT
GUIDE DETAIL
42” DECK SHOWN TAB MUST GO
INTO HOLE
LOCATOR TAB
BELT GUIDE
MOWER
BELT
IDLER PULLEY
IDLER
ARM
BELT
GUIDE
STATIONARY
PULLEY
SIDE SIDE
X X-1/8”

18
Section 4 - ADJUSTMENTS & REPAIR
WARNING
DO NOT attempt any adjustments, maintenance or
service with the engine or blade running. STOP
blade. STOP engine. Set brake. Remove key. Remove
spark plug wire from spark plug and secure wire
away from spark plug. Engine and components can
be extremely hot. Avoid burns by allowing engine
and components sufficient time to cool.
4.2.6. MOWER DECK ADJUSTMENT (LEVELNESS)
Side-To-Side (48” Decks)
(Continued From Previous Page)
4. Remove hair pin from pivot rod and pull rod
out of lift arm.
5. Rotate pivot rod up or down to achieve the
proper levelness. See Figure 4.5.
6. Reinstall hair pin into pivot rod.
7. Reinstall floor pan.
FIGURE 4.5
4.2.7. MOWER DECK ADJUSTMENT (LEVELNESS)
Front to Rear Deck Pitch (48” Deck)
Before making deck leveling adjustments, check the
tire pressure. Add or release air as needed to bring
pressure to 12 P.S.I. in front and 12 P.S.I. in rear tires. If
tires are properly inflated and mowing is still uneven,
check side-to-side deck levelness first then proceed
to front to rear adjustment. Adjust front to rear deck
levelness as follows:
1. Place YARD CRUISER on a smooth level
surface.
2. Remove floor pan.
3. Rotate outside blades so tips are pointed to the
front and rear of deck. Measure the distance from
blade tips to floor. The distance should be the
same, or the rear 1/4” higher than the front. If the
rear blade tip is lower or is more than 1/4” higher
than the front, proceed to Step 4 for adjustment.
4. Remove the hair pin from pivot rod on one side
of deck at a time.
5. Rotate each pivot rod up or down the same
number of turns to achieve the proper levelness.
6. Reinstall both hair pins into pivot rods. See
Figure 4.5.
4.2.8. MOWER DECK TIMING ROD - 48” DECKS
The mower deck timing rod is preadjusted at the
factory. It is set to maintain the deck in the same
attitude through all heights of cut. If the timing rod
requires adjustment, contact an authorized SNAPPER
dealer for service.
HAIRPIN
LIFT ARM
PIVOT ROD

19
Section 4 - ADJUSTMENTS & REPAIR
WARNING
DO NOT attempt any adjustments, maintenance or
service with the engine or blade running. STOP
blade. STOP engine. Set brake. Remove key. Remove
spark plug wire from spark plug and secure wire
away from spark plug. Engine and components can
be extremely hot. Avoid burns by allowing engine
and components sufficient time to cool.
4.2.9. MOWER DECK ADJUSTMENT (LEVELNESS)
1. Side-To-Side (42”Decks)
Before making deck leveling adjustments, check
the tire pressure. Check tires and add or release air
as needed to bring pressure to 12 P.S.I. in front and 12
P.S.I. in rear tires. If tires are properly inflated and
mowing is still uneven, adjust side-to-side deck
levelness as follows:
a. Place YARD CRUISER on a smooth level
surface.
b. Turn engine off and remove key, remove
spark plug wire(s) from spark plug(s) and secure
wire(s) away from plug(s).
c. Place a piece of angle iron, pipe, or similar
object under center of deck at the rear.
d. Remove rear hanger chains and allow center,
rear of deck to rest on angle iron.
e. Measure the distance from blade tips to floor. If
the measurement is within 1/8” from side-to-side,
the deck levelness is satisfactory. If the difference
from side-to-side is greater than 1/8”, continue to
the Step “f” for adjustment. See Figure 4.6.
f. Loosen the shoulder bolt that retains the
eccentric.
g. Turn eccentric “UP” or “DOWN” as required
until blade tips are within 1/8” of the same
distance from the floor. See Figure 4.7.
h. Tighten shoulder bolt loosened in Step “f”.
i. Readjust rear hanger chain pivots to align
with holes in support brackets.
j. Reconnect hanger chains, remove angle iron,
pipe, etc. and recheck side to side level. Adjust
either chain as needed to result in blade tips
being within 1/8” of the same distance from the
floor.
k. Proceed to check front to rear deck pitch.
FIGURE 4.7
(Continued On Next Page)
FRONT OR REAR VIEW OF DECK
TWIN BLADE DECK
ANGLE
IRON
X - 1/8”
X
SIDESIDE
SINGLE BLADE DECK
SIDE
SIDE X - 1/8”
ANGLE IRON
X
42” DECK SHOWN
UP
DOWN
FRONT
LIFT ARM ECCENTRIC
LOOSEN
SHOULDER
BOLT
FIGURE 4.6

20
Section 4 - ADJUSTMENTS & REPAIR
WARNING
DO NOT attempt any adjustments, maintenance or
service with the engine or blade running. STOP
blade. STOP engine. Set brake. Remove key. Remove
spark plug wire from spark plug and secure wire
away from spark plug. Engine and components can
be extremely hot. Avoid burns by allowing engine
and components sufficient time to cool.
4.2.9. MOWER DECK ADJUSTMENT (LEVELNESS)
(Continued From Previous Page)
2. Front to Rear Deck Pitch (42” Decks)
With the YARD CRUISER on a smooth, level
surface, rotate blades until blade tips are at front
and rear of deck. Measure the distance from blade
tips to floor. The distance should be the same, or
the rear 1/4” higher than the front. If the rear blade
tip is lower or is more than 1/4” higher than the
front, proceed with adjustment.
a. Remove rear hanger chains.
b. Turn each hanger pivot the same number of
rotations on the eye-bolt to raise or lower the
rear of the deck. See Figure 4.8.
c. Reinstall rear hanger chains and measure
blade tips again.
d. Repeat steps “a” through “c” until proper
levelness is obtained.
FIGURE 4.8
4.2.10. MOWER DECK TIMING ROD - 42” DECKS
The mower deck timing rod is preadjusted at the
factory. It is set to maintain the deck in the same
attitude through all heights of cut. If the timing rod
requires adjustment, contact an authorized SNAPPER
dealer for service. See Figure 4.9.
FIGURE 4.9
4.2.11. WHEEL BRAKE ADJUSTMENT
Adjust the wheel brake if wheels turn when parking
brake is engaged. Adjust the wheel brake by turning
wheel brake adjusting nut clockwise to increase
braking action or counter clockwise to decrease
braking action. See Figure 4.10.
FIGURE 4.10
X + 1/4”
X
FRONT
REAR
ROTATE HANGER PIVOT:
UP TO RAISE DECK OR
DOWN TO LOWER DECK.
ADJUSTING
NUT DO NOT ADJUST
TIMING
ROD
42” DECK SHOWN
UNDERSIDE VIEW OF
MACHINE
ELECTRIC
CLUTCH
WHEEL
BRAKE ROD
ADJUST
CLOCKWISE TO
INCREASE
BRAKE
ADJUST
COUNTER-
CLOCKWISE TO
DECREASE
BRAKE

21
Section 4 - ADJUSTMENTS & REPAIR
WARNING
DO NOT attempt any adjustments, maintenance or
service with the engine or blade running. STOP
blade. STOP engine. Set brake. Remove key. Remove
spark plug wire from spark plug and secure wire
away from spark plug. Engine and components can
be extremely hot. Avoid burns by allowing engine
and components sufficient time to cool. Wear heavy
leather gloves when handling or working around
cutting blades. Blades are extremely sharp and can
cause severe injury.
4.3 MOWER BLADE REPLACEMENT
4.3.1. BLADE WEAR LIMITS
1. Inspect blade frequently for signs of excessive wear
or damage. See Figure 4.11.
FIGURE 4.11
4.3.2. BLADE SHARPENING
1. Make sure fuel cap is on tight. Start engine and
allow it to run until engine runs out of fuel. Close
vent on fuel filler cap. See Figure 2.3.
2. Remove key from ignition switch.
3. Remove spark plug wire(s) and secure away from
spark plug(s).
4. Carefully stand YARD CRUISER on rear bumper.
5. Remove blade(s). See Figure 4.12.
6. Inspect condition of blade. See Figure 4.11.
7. If blade is in good condition, sharpen at 22 to 28
degrees. DO NOT sharpen beyond existing cutting
edge. See Figure 4.13.
8. Check blade balance after sharpening. If
necessary, correct blade balance by grinding the heavy
end of blade.
9. Reinstall blade. See Figure 4.12. Torque blade
mounting bolts to recommended range of:
42” Deck - 30 to 40 ft. lbs.
48” Deck - 80 to 90 ft. lbs.
FIGURE 4.12
FIGURE 4.13
WARNING
DO NOT use a cutting blade that shows signs of
excessive wear or damage. Wear heavy leather
gloves when handling or working around cutting
blades. Blades are extremely sharp and can cause
severe injury.
4.3.3. BLADE REPLACEMENT
1. Remove blade(s). See Figure 4.12. Replace
blade(s) if it shows signs of excessive wear or
damage.
NOTE: FOR ALL CUTTING BLADE REPLACEMENT
PARTS IDENTIFICATION NUMBERS SEE PAGE 24.
DO NOT SHARPEN
BEYOND ORIGINAL
CUTTING EDGE
BLADE TIP
ORIGINAL CUTTING EDGE
22º TO 28º
NEW BLADE
WEAR LIMIT
(NOTCH STARTS)
DANGEROUS CONDITION!
DO NOT USE ON MOWER!
REPLACE WITH NEW BLADE.
48” DECK
42” DECK
