SNDWAY SW-800 User manual

Use’s Manual
Laser Distance Meter Telescope
SW-800 1200 1500 EN manual 12pages.indd 1 05/17/2013 13:42:11

SW-800 1200 1500 EN manual 12pages.indd 1 05/17/2013 13:42:11

2
2
Application scope and product introduction
The laser distance meter telescope and
multifunctional meterage angle meterage
distance telescope is a portable optoelectronic
device combined The laser distance meter and a
monocular in one.
• Itcanmeasurethedistanceofastationaryor
slowlymovingobjectwithinacertainrange,and
atthesametime,canobservetheobjectwith
greatclearness.Itpossessesmanyadvantages,
suchasahighaccuracy,shortmeasuringtime,
low power consumption and automatic shutoff for
power saving etc.
• Multifunctionalmeterageanglemeterage
distance telescope can Taking advantage of
thelatestscienctilictechnology,thisdevicecan
simultaneouslymeasurethedistancesandangle
ofthetarget.Itcoulddisplaytheangle,straight
linedistance,horizontaldistanceandheight.
• The transmission power of this device is very
smallandnoharmtousers'eyes,anytargetcan
be measured at random. It is compact, light in
weight,smallinvolume,veryeasytooperateand
carryabout.OnepieceofCR2/3vbatteryisused
whichcanbeboughtandchangedeasily.
• The laser distance meter telescope can be
widely used for travel, sightseeing, golf sports,
hunting,campingaswellaforanymeasurement
ofoutdoorprojects.itisaverygoodassistantto
improveouroutdoorlifequality.
SW-800 1200 1500 EN manual 12pages.indd 2 05/17/2013 13:42:11

3
3
Technology specifications:
NO Specications
Measuringrange 5-900M 5-1200M 5-1500M
MeasuringAccuracy ±1.0M
Anglerange ±60°(Onlymultifunctionalmodel)
Magnication 6X
Objectivecaliber 25.0mm
Eyepiececaliber 16.0mm
Exit pupil caliber 3.8mm
Diopteradjustable
range
±5°
Battery CR2\3V
Weightofthebody 185g
Laser wave length 905nm
Working temperature -20-50℃
Viewingangle 7°
Size 104*72*41mm
SW-800 1200 1500 EN manual 12pages.indd 3 05/17/2013 13:42:11

4
4
•Multifunctional meterage angle meterage
distance telescope appearance
Appearance
• Laser distance meter telescope appearance
•Laser 
emission
•Laserreceiving
lens
•Power/startbutton •Observation
eyepiece
•Rotation-type
focusing
•Battery
cover
•Laser
emission
•Laser receiving
lens
•Power/startbutton
•Power/startbutton
•Observation
eyepiece
•Rotation-type
focusing
•Battery
cover
SW-800 1200 1500 EN manual 12pages.indd 4 05/17/2013 13:42:11

5
5
LCD display
1.SCAN----------------Scanningmodesign;
2. ----------------Batterylowvoltagemarks;
3. ----------------Laserlaunchmarks;
6. M----------------Straightdistancedatadisplayunit;
5. ----------------Straightdistancedatashows;
4. ----------------Given.someindication;
• Laser distance meter telescope appearance.
1
2
3
4
5
6
SCAN
M
SW-800 1200 1500 EN manual 12pages.indd 5 05/17/2013 13:42:11

6
6
•Multifunctional meterage angle meterage distance
telescope appearance.
1
2
3
4
5
6
7
8
9
SCAN
MY
MY Hgt
Hor
MY
2.“SCAN”---------Scanningmodesign;
1. ---------Batterylowvoltagemarks;
4. ---------Laserlaunchmarks;
8.M/Y---------Straightdistancedatadisplayunit;
5. MY Hor---------Levelrangedata,displayunit;
9. MY Hgt---------Verticalheightdata,unitdisplay;
6. ---------Angledatashows;
3. ---------Givensomeindication;
7. ---------Straightdistancedatashows;
SW-800 1200 1500 EN manual 12pages.indd 6 05/17/2013 13:42:12

7
7
Laser distance meter telescope
apparatus operating instructions:
 Thedevicehasonebuttons,It’s"Start"button.
• Press button for about 0.5 second to activate
theinviewLCDdisplaysystem.
• Turn the eyepiece of the monocular until the
target becomes clear.
• Shortlypressthe button and the all data will be
displayedonthescreenoftheLCDimmediately.
Show the location of the various characters.
The laser indicator will blink when laser is
transmitting. In measuring the distance, If the
reection of target is too weak, The LCD will
display"----".
• Hold down the keydoesnotreleaseit,then
start the scan ranging the top left of the screen
displays the scan character "SCAN" With the
change of the target, the straight-line distance
datatoconstantlyrefreshthedisplay.
• Within 20 seconds, no key is pressed, the unit
willautomaticallypoweroff.
• Directional signs, as the battery voltage, when
the  show when the battery voltage is
requiredtoreplacethebattery.
SW-800 1200 1500 EN manual 12pages.indd 7 05/17/2013 13:42:12

8
8
Multifunctional meterage angle meterage
distance telescope appearance. apparatus
operating instructions:
 The device has two buttons, they are "Start"
buttonand"Mode"button.
• Press button for about 0.5 second to activate
the in view LCD display system. Shortly press
the"MODE"button,Twokindsofmeasurement
modecanbeconverted.Oneisthemeasurement
mode of beeline distance, The other is the
measurement mode of Full-function. Long press
the"MODE"button,Unitsofdistance"M/Y"can
be converted.
• Turn the eyepiece of the monocular until the
target becomes clear.
• Shortlypressthe button and the all data will be
displayedonthescreenoftheLCDimmediately.
Show the location of the various characters.
The laser indicator will blink when laser is
transmitting. In measuring the distance, If the
reection of target is too weak, The LCD will
display"----".
 Figure3Aand3Baretwodifferentmeasurements
of the location of the target.
443M
512M
256M
-30° 512M
256MHgt
443MHor
SW-800 1200 1500 EN manual 12pages.indd 8 05/17/2013 13:42:12

9
9
397M
193M
425M
27°
27°
425M
193MHgt
397MHor
•Hold down the keydoesnotreleaseit,then
start the scan ranging the top left of the screen
displays the scan character "SCAN" With the
change of the target, the straight-line distance
data to constantly refresh the display, at the
sametimepointofview,horizontaldistanceand
vertical heightcontinue to refresh the display,
release the key,stopranging.
• Within 20 seconds, no key is pressed, the unit
willautomaticallypoweroff.
•  directional signs, as the battery voltage,
when the showwhenthebatteryvoltageis
requiredtoreplacethebattery.
SW-800 1200 1500 EN manual 12pages.indd 9 05/17/2013 13:42:12

10
10
The points for attention
• Battery life: Continuous operation: about 8,000
(roomtemperature),goalfocus,measurementand
automatic power-down is included in the single
Duty cycle.Thisnumbermayvarydependingon
the other factors of the temperature and the target
shape,color.
• Rangender use a 3V CR2 lithium battery.
However, due to natural discharge, the battery
lifemaybeshorterthanthegivenvalue,suchas
instrumenttooodingorinltrationofthebattery
compartment,replacethebattery.
• Diopter adjustment: adjust the diopter to get a
clear image in the eyepiece display, rst of all,
turnonthepower,thencounterclockwiserotation
oftheeyepieceringuntilthedisplaytogetaclear
focus.
• Multifunction range nder in the United States
emitted is not visible, non-destructive vision
infraredpulselaser,andthenfromtheselected
targetreectionbacktotheopticalreceiver.By
measuring each pulse laser rangender to the
target and back to the time spent, the system
uses advanced precision charging circuit to
instantly calculate the measured distance.
The maximum measuring range of the device
dependsonthetargetreectivity,color,surface
nish,sizeandactualshape.
SW-800 1200 1500 EN manual 12pages.indd 10 05/17/2013 13:42:12

Packing list
Pleasecarefullycheckinstrumentsandattachments
are complete in line with below list.
NO. Item Unit QTY Note
1Masterbody PCS 1
2Masterbag PCS 1
3Holding rope PCS 1
4CR2battery PCS 1
5Cleaningcloth PCS 1Cameralens
6Manual PCS 1
7Gift box PCS 1
SW-800 1200 1500 EN manual 12pages.indd 11 05/17/2013 13:42:12
