Snell IQSDA32 Operator's manual

snellgroup.com
User Instruction Manual
IQSDA30/IQSDA32
Intelligent Reclocking High Performance HD-SDI/SD-SDI Distribution
Amplifiers

IQSDA30/IQSDA32 www.snellgroup.com Information and Notices
Issue 2 Rev 3 Page 2 ©2015 Snell Limited
Information and Notices
Copyright and Disclaimer
Copyright protection claimed includes all forms and matters of copyrightable material and
information now allowed by statutory or judicial law or hereinafter granted, including without
limitation, material generated from the software programs which are displayed on the screen
such as icons, screen display looks etc.
Information in this manual and software are subject to change without notice and does not
represent a commitment on the part of Snell Limited. The software described in this manual is
furnished under a license agreement and can not be reproduced or copied in any manner
without prior agreement with Snell Limited or their authorized agents.
Reproduction or disassembly of embedded computer programs or algorithms prohibited.
No part of this publication can be transmitted or reproduced in any form or by any means,
electronic or mechanical, including photocopy, recording or any information storage and
retrieval system, without permission being granted, in writing, by the publishers or their
authorized agents.
Snell operates a policy of continuous improvement and development. Snell reserves the right
to make changes and improvements to any of the products described in this document
without prior notice.
Contact Details
Customer Support
For details of our Regional Customer Support Offices please visit the Snell website and
navigate to Support/Customer Support.
www.snellgroup.com/support/customer-support
Customers with a support contract should call their personalized number, which can be found
in their contract, and be ready to provide their contract number and details.

IQSDA30/IQSDA32 www.snellgroup.com Contents
Issue 2 Rev 3 Page 3 ©2015 Snell Limited
Contents
Information and Notices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
1. Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.1 Module Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.1.1 IQSDA30 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.1.2 IQSDA32 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.2 Order Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
1.2.1 IQSDA30 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
1.2.2 IQSDA32 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
1.3 Rear Panel View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.3.1 IQSDA30 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.3.2 IQSDA32 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.4 Enclosures. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
1.4.1 B-style Enclosure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
1.4.2 A-style Enclosures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
1.5 Feature Summary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
1.5.1 IQSDA30 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
1.5.2 IQSDA32 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2. Technical Specification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
2.1 IQSDA30. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
2.2 IQSDA32. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
3. Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
3.1 IQSDA30. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
3.1.1 Inputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
3.1.2 Outputs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
3.2 IQSDA32. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
3.2.1 Inputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
3.2.2 Outputs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
4. Card Edge LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
5. Controlling the IQSDA30/32 from the RollCall Control Panel . . . . . . . . . . . . . . . 17
5.1 Unit Status. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
5.2 Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
5.2.1 Input 1 SDI Rate. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
5.2.2 Output 1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
5.2.3 Input 2 SDI Rate and Output 2 (IQSDA30 only). . . . . . . . . . . . . . . . . . . 19
5.3 Memory 1-16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
5.4 Logging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
5.4.1 Log Field Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
5.5 RollTrack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
5.5.1 Disable All . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
5.5.2 RollTrack Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
5.5.3 RollTrack Source . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
5.5.4 RollTrack Address . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
5.5.5 RollTrack Command. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
5.5.6 RollTrack Sending . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
5.5.7 RollTrack Status. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

IQSDA30/IQSDA32 www.snellgroup.com Contents
Issue 2 Rev 3 Page 4 ©2015 Snell Limited
5.6 Setup. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
5.6.1 Product Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
5.6.2 Default Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
5.6.3 Factory Defaults. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
5.6.4 Restart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
5.6.5 Input 1/2 Name. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
6. Controlling the IQSDA30/32 from an Active Front Panel . . . . . . . . . . . . . . . . . . . 27
6.1 Information Window. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
6.2 Control Window. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

IQSDA30/IQSDA32 www.snellgroup.com Introduction
Issue 2 Rev 3 Page 5 ©2015 Snell Limited
1. Introduction
1.1 Module Description
1.1.1 IQSDA30
The IQSDA30 provides dual inputs with 3 outputs per input for distribution of HD-SDI 3 Gbit/s,
1.5 Gbit/s or 270 Mbit/s SD-SDIsignals in a single width package. Its 80m 3G, 180m HD input
equalization performance and non re-clocking distribution of wide-band signals make it ideal
for all distribution applications. For HD/SD only applications an HD/SD-SDI version is
available, with an option to upgrade firmware for 3 Gbit/s operation when required.
1.1.2 IQSDA32
The IQSDA32 is a distribution amplifier for HD-SDI 3 Gbit/s, 1.5 Gbit/s or 270 Mbit/s SD-SDI
signals providing 7 equalized and reclocked outputs of the input in a single width package. Its
80m 3G, 180m HD input equalization performance and non re-clocking distribution of
wide-band signals make it ideal for all distribution applications. For HD/SD only applications
an HD/SD-SDI version is available, with an option to upgrade firmware for 3 Gbit/s operation
when required.

IQSDA30/IQSDA32 www.snellgroup.com Introduction
Issue 2 Rev 3 Page 6 ©2015 Snell Limited
1.2 Order Codes
The following product order codes are covered by this manual.
1.2.1 IQSDA30
1.2.2 IQSDA32
Note:
Modules with “A” order codes (for example, IQSDA3047-1A)can be fitted into either A- or
B-style enclosures. Modules with “B” order codes (for example, IQSDA3047-1B)can only
be fitted into B-style enclosures. See page 8.
IQSDA3047-1A
IQSDA3047-1B Dual Channel HD/SD-SDI Reclocking Distribution Amplifier. 2 inputs, 3 outputs per input.
IQSDA3047-1A3
IQSDA3047-1B3 Dual Channel 3G/HD/SD-SDI Reclocking Distribution Amplifier. 2 inputs, 3 outputs per input.
IQSDA3061-1A3
IQSDA3061-1B3 Dual Channel 3G/HD/SD-SDI Re-clocking Distribution Amplifier with relay input bypass. 2 inputs, 2 outputs per input.
IQSDA30-3G Upgrade for IQSDA30 Dual Channel HD/SD-SDI Reclocking
Distribution Amplifier to operate with 3 Gbit/s SDI signals.
IQSDA3247-1A
IQSDA3247-1B HD/SD-SDI Reclocking Distribution Amplifier. 1 input, 7 outputs.
IQSDA3247-1A3
IQSDA3247-1B3 3G/HD/SD-SDI Reclocking Distribution Amplifier. 1 input, 7 outputs.
IQSDA3261-1A
IQSDA3261-1B HD/SD-SDI Reclocking Distribution Amplifier. 1 input, 6 outputs, relay bypass.
IQSDA3261-1A3
IQSDA3261-1B3 3G/HD/SD-SDI Reclocking Distribution Amplifier. 1 input, 6 outputs, relay bypass.
IQSDA32-3G Upgrade for IQSDA32 HD/SD-SDI Reclocking Distribution Amplifier
to operate with 3 Gbit/s SDI signals.

IQSDA30/IQSDA32 www.snellgroup.com Introduction
Issue 2 Rev 3 Page 7 ©2015 Snell Limited
1.3 Rear Panel View
The following rear panel types are available.
1.3.1 IQSDA30
IQSDA3047-1A(B) / IQSDA3047-1A(B)3
IQSDA3061-1A(B)3
1.3.2 IQSDA32
IQSDA3247-1A(B) / IQSDA3247-1A(B)3
IQSDA3261-1A(B) / IQSDA3261-1A(B)3
Note:
The input signal will bypass the module and be routed to the respective output in the event
of module removal or power failure.
Note:
The input signal will bypass the module and be routed to the respective output in the event
of module removal or power failure.

IQSDA30/IQSDA32 www.snellgroup.com Introduction
Issue 2 Rev 3 Page 8 ©2015 Snell Limited
1.4 Enclosures
The module can be fitted into the enclosure types shown.
1.4.1 B-style Enclosure
Enclosure order codes: IQH3B-S-0, IQH3B-S-P
1.4.2 A-style Enclosures
Enclosure order code: IQH1A-S-P
Enclosure order codes: IQH3A-S-0, IQH3A-S-P
Enclosure order codes: IQH3A-E-0, IQH3A-E-P, IQH3A-0-0, IQH3A-0-P
Enclosure order code: IQH1A-S-P
Important:
Although IQ modules are interchangeable between enclosures, their rear panels are
enclosure specific. An IQH3B enclosure accepts modules with either “A” or “B” order
codes. An IQH3A or IQH1A enclosure accepts modules with “A” order codes only. See
page 6.

IQSDA30/IQSDA32 www.snellgroup.com Introduction
Issue 2 Rev 3 Page 9 ©2015 Snell Limited
1.5 Feature Summary
The IQSDA30 and IQSDA32 provide the following features.
1.5.1 IQSDA30
• Dual channel Intelligent 3 Gbit/s SDI, HD-SDI and SD-SDI re-clocking distribution
amplifier
• Will distribute DVB-ASI and other wide-band signals
• Equalizes up to 80m at 3 Gbit/s, 180mat 1.5 Gbit/s and more than 350m at 270Mbit/s
when using Belden 1694A cable
• Standards supported:
• 3G-HD to SMPTE424M
• HD-SDI to SMPTE292M
• SD-SDI to SMPTE259M-C
• DVB-ASI
• Relay Bypass option available
• RollCall monitoring allows all signal paths to be managed
• Extremely compact – up to 32 channels in 3RU – for use where space is at a premium
1.5.2 IQSDA32
• Intelligent 3 Gbit/s SDI, HD-SDI and SD-SDI re-clocking distribution amplifier
• Will distribute DVB-ASI and other wide-band signals
• Equalizes up to 80m at 3 Gbit/s, 180mat 1.5 Gbit/s and more than 350m at 270Mbit/s
when using Belden 1694A cable
• Standards supported:
• 3G-HD to SMPTE424M
• HD-SDI to SMPTE292M
• SD-SDI to SMPTE259M-C
• DVB-ASI
• Relay Bypass option available
• RollCall monitoring allows all signal paths to be managed

IQSDA30/IQSDA32 www.snellgroup.com Technical Specification
Issue 2 Rev 3 Page 10 ©2015 Snell Limited
2. Technical Specification
2.1 IQSDA30
Inputs and Outputs
Signal Inputs
SDI Inputs 2 x
Input Cable Length Up to 80 m Belden 1694A @ 3 Gbit/s
Up to 180 m Belden 1694A @ 1.5 Gbit/s
Up to 350 m Belden 1694A @ 270 Mbit/s
Signal Outputs
SDI Outputs x 3 per input
Controls
Indicators
Power OK (Green)
CPU OK (Green flashing)
Input 1 OK (Green), Bypass (Orange), Loss (Red)
Input 2 OK (Green), Bypass (Orange), Loss (Red)
RollCall Features
Input 1 (2) Rate Select Auto, 3G, HD, SD, DVB-ASI, Bypass (reclocking off)
Input Status Present, Loss, Unknown, Data Rate
Logging Input 1 (2) Type
Input 1 (2) Data Rate
Input 1 (2) Present
Input 1 (2) Error
Input 1 (2) Loss
RollTrack Controls On/Off, Index, Source, Address, Command, Status, Sending
Roll Track Outputs Unused
Input 1 (2) Present
Input 1 (2) Rate Unknown
Input 1 (2) Error
Input 1 (2) Loss
Input 1 (2) 3G
Input 1 (2) HD
Input 1 (2) SD
Other Controls
User Memories Name, save, and recall 16 user memories

IQSDA30/IQSDA32 www.snellgroup.com Technical Specification
Issue 2 Rev 3 Page 11 ©2015 Snell Limited
Specifications
Electrical 3 Gbit/s SDI, SMPTE 424M
1.5 Gbit/s HD-SDI, SMPTE 292M
270 Mbit/s SDI, SMPTE 259M-C / DVB-ASI
Connector/Format BNC/ 75 Ohm panel jack on standard Snell connector panel
Return Loss >-15 dB (270 Mbit/s, 1.5 Gbit/s)
>-10 dB (3 Gbit/s)
Output Jitter SD-SDI 0.2 UI (10 Hz) / 0.2 UI (1 kHz)
3G/HD-SDI 1.0 UI (10 Hz) / 0.2 UI (100 kHz)
Power Consumption
Module Power Consumption 3 W max (A Frames)
4 W max with relay rear (A Frames)
3PR(BFrames)
3 PR with relay rear (B Frames)

IQSDA30/IQSDA32 www.snellgroup.com Technical Specification
Issue 2 Rev 3 Page 12 ©2015 Snell Limited
2.2 IQSDA32
Inputs and Outputs
Signal Inputs
SDI Inputs 1 x
Input Cable Length Up to 80 m Belden 1694A @ 3 Gbit/s
Up to 180 m Belden 1694A @ 1.5 Gbit/s
Up to 350 m Belden 1694A @ 270 Mbit/s
Signal Outputs
SDI Outputs x 7 (1, 3, 5, 7 DVB-ASI compatible)
Controls
Indicators
Power OK (Green)
CPU OK (Green flashing)
Input OK (Green), Bypass (Orange), Loss (Red)
RollCall Features
Input 1 (2) Rate Select Auto, 3G, HD, SD, DVB-ASI
Input Status Present, Loss, Unknown, Data Rate
Logging Input Type
Input Data Rate
Input Present
Input Error
Input Loss
RollTrack Controls On/Off, Index, Source, Address, Command, Status, Sending
Roll Track Outputs Unused
Input Present
Input Rate Unknown
Input Error
Input Loss
Input 3G
Input HD
Input SD
Other Controls
User Memories Name, save, and recall 16 user memories

IQSDA30/IQSDA32 www.snellgroup.com Technical Specification
Issue 2 Rev 3 Page 13 ©2015 Snell Limited
Specifications
Electrical 3 Gbit/s SDI, SMPTE 424M
1.5 Gbit/s HD-SDI, SMPTE 292M
270 Mbit/s SDI, SMPTE 259M-C / DVB-ASI
Connector/Format BNC/ 75 Ohm panel jack on standard Snell connector panel
Return Loss >-15 dB (270 Mbit/s, 1.5 Gbit/s)
>-10 dB (3 Gbit/s)
Output Jitter SD-SDI 0.2 UI (10 Hz) / 0.2 UI (1 kHz)
3G/HD-SDI 1.0 UI (10 Hz) / 0.2 UI (100 kHz)
Power Consumption
Module Power Consumption 3 W max (A Frames)
3PR(BFrames)
3.5 W max with Relay Rear

IQSDA30/IQSDA32 www.snellgroup.com Connections
Issue 2 Rev 3 Page 14 ©2015 Snell Limited
3. Connections
This section describes the physical input and output connections provided by the IQSDA30
and IQSDA32.
3.1 IQSDA30
3.1.1 Inputs
Serial digital input to the unit is made via 2 BNC connectors, which terminate in 75 Ohms.
IQSDA3047-1A(B)/IQSDA3047-1A(B)3
IQSDA3061-1A(B)3
3.1.2 Outputs
Serial digital output from the unit is made via 6 BNC connectors, 3 per input (4 on Relay
Bypass version, 2 per input), which terminate in 75 Ohms. Outputs 1 and 3 are DVB-ASI
compatible (Serial Out 1, output 1 and Serial Out 2, output 2 on Relay Bypass Version).
IQSDA3047-1A(B)/IQSDA3047-1A(B)3
IQSDA3061-1A(B)3

IQSDA30/IQSDA32 www.snellgroup.com Connections
Issue 2 Rev 3 Page 15 ©2015 Snell Limited
3.2 IQSDA32
3.2.1 Inputs
Serial digital input to the unit is made via a single BNC connector, which terminate in 75
Ohms.
IQSDA3247-1A(B)/IQSDA3247-1A(B)3
IQSDA3261-1A(B)/IQSDA3261-1A(B)3
3.2.2 Outputs
Serial digital output from the unit is made via 7 BNC connectors (6 on Relay Bypass version),
which terminate in 75 Ohms. Outputs 1, 3, 5, and 7 are DVB-ASI compatible (1, 4 and 6 on
Relay Bypass Version).
IQSDA3247-1A(B)/IQSDA3247-1A(B)3
IQSDA3261-1A(B)/IQSDA3261-1A(B)3

IQSDA30/IQSDA32 www.snellgroup.com Card Edge LEDs
Issue 2 Rev 3 Page 16 ©2015 Snell Limited
4. Card Edge LEDs
The LEDs on the edge of the module indicate its operating status.
Note:
Channel 2 LEDs on IQSDA30 only.
LED Color Description
Power OK Green This indicator is illuminated when a positive power supply
is present.
CPU Green This indicator will blink to indicate CPU activity.
Channel 1 OK Green This indicator is illuminated when input channel 1 is locked
to the input signal.
Channel 1 Bypass Yellow This indicator is illuminated when the signal on input
channel 1 is not being reclocked. That is, in reclock
bypass mode.
Channel 1 Error Red This indicator is illuminated when there is unknown or no
input on input channel 1..
Channel 1 Rate Green This indicator pair shows the rate on input channel 1 as
follows:
• Both LEDs illuminated – 3 Gbit/s
• Left LED only illuminated – 1.5 Gbit/s
• Right LED only illuminated – 270 Mbit/s
• Both LEDs off – Rate unknown
Channel 2 OK Green This indicator is illuminated when input channel 2 is locked
to the input signal.
Channel 2 Bypass Yellow This indicator is illuminated when the signal on input
channel 2 is not being reclocked. That is, in reclock
bypass mode
Channel 2 Error Red This indicator is illuminated when there is unknown or no
input on input channel 2
Channel 2 Rate Green This indicator pair shows the rate on input channel 2 as
follows:
• Both LEDs illuminated – 3 Gbit/s
• Left LED only illuminated – 1.5 Gbit/s
• Right LED only illuminated – 270 Mbit/s
• Both LEDs off – Rate unknown

IQSDA30/IQSDA32 www.snellgroup.com Controlling the IQSDA30/32 from the RollCall Control Panel
Issue 2 Rev 3 Page 17 ©2015 Snell Limited
5. Controlling the IQSDA30/32 from the RollCall Control Panel
5.1 Unit Status
Information about the status of the unit is displayed in the Unit Status section on each RollCall
Control Panel screen.
The first two lines of the Unit Status display the input status, detected rate, and input selection
method for Input 1. The third and fourth lines of the Unit Status display the same information
for Input 2.

IQSDA30/IQSDA32 www.snellgroup.com Controlling the IQSDA30/32 from the RollCall Control Panel
Issue 2 Rev 3 Page 18 ©2015 Snell Limited
5.2 Input
The input screen enables the type of input signal to be selected.
5.2.1 Input 1 SDI Rate
•Auto: When selected, the unit will automatically detect and reclock any valid input
signal, and the detected rate will be displayed in the Unit Status.
If anything else is detected, the output will not be reclocked. If the On Input Loss /
Mute option is selected, the output will be muted; or, if the On Input Loss / Pass
option is selected, the output will be passed through.
•SD/DVB-ASI (270 Mb): When selected, the unit will reclock only SD/DVB-ASI (270
Mb) signals.
When selected, the On Input Loss controls are greyed out and are inactive. If any
other standard is applied to the unit the output will be muted.
•HD (1.5 Gb): When selected, the unit will reclock only HD (1.5 Gb) signals.
When selected, the On Input Loss controls are greyed out and are inactive. If any
other standard is applied to the unit the output will be muted.
•3G (3 Gb): When selected, the unit will reclock only 3G (3 Gb) signals.
When selected, the On Input Loss controls are greyed out and are inactive. If any
other standard is applied to the unit the output will be muted.
•Reclock Bypass: When selected, the unit will not reclock the input signal. If a
supported rate is detected, the Unit Status will display the detected rate, otherwise, ***
will be displayed.
If the On Input Loss / Mute option is selected, the output will be muted whenever a
recoginized rate is not detected; or, if the On Input Loss / Pass option is selected,
any signal standard, frequency, etc... will pass through.

IQSDA30/IQSDA32 www.snellgroup.com Controlling the IQSDA30/32 from the RollCall Control Panel
Issue 2 Rev 3 Page 19 ©2015 Snell Limited
5.2.2 Output 1
•Mute: When selected, this option applies a mute on Output 1.
•On Input loss / Mute: When selected, if the Input signal is lost, the output signal will
be muted.
•On Input loss / Pass: When selected, if the input signal is lost, it will be passed
unchanged.
5.2.3 Input 2 SDI Rate and Output 2 (IQSDA30 only)
These options are the same as the Input 1 SDI Rate and Output 1 options but are applied to
Input 2 and Output 2.

IQSDA30/IQSDA32 www.snellgroup.com Controlling the IQSDA30/32 from the RollCall Control Panel
Issue 2 Rev 3 Page 20 ©2015 Snell Limited
5.3 Memory 1-16
Use the Memory function to save up to 16 setups to be recalled later. Default memory names
can be changed to provide more meaningful descriptions.
To save settings:
• In the Save Memory column, select a memory location, and then click Save. The
current settings are saved and the memory appears in the Recall Memory column.
To change a memory name:
• In the Save Memory Name field, type the new memory name, and then click S. To
return the memory to its default value, click the preset button (P).
Use the Recall Memory function to recall the settings saved in a memory location. Last
Recalled Memory displays the most recently recalled memory. If a control is changed after a
has been recalled Last Recalled Memory will display an asterisk behind the memory name.
To recall a memory:
• In the Recall Memory column, select the memory to recall. The recalled settings will
be applied and the memory name will appear in the Last Recalled Memory section.
