SNOWJOE sunjoe 24V-HCSWP-6-LTE User manual

Model 24V-HCSWP-6-LTE Form No. SJ-24V-HCSWP-6-LTE-880E-M
OPERATOR’S MANUAL
CORDLESS TELESCOPING
POLE + PRUNING SAW
24V* IONMAX | 2.0 Ah | 6-INCH
Original instructions.
© 2023 Snow Joe, LLC. All rights reserved.
1
A Division of Snow Joe, LLC
*DISCLAIMER: Initial no-load voltage, when fully charged,
peaks at 24V; nominal voltage under typical load is 21.6V.
SAVE THESE INSTRUCTIONS
R
TM
IMPORTANT!
Safety Instructions
All Operators Must Read These
Instructions Before Use
Always follow these safety guidelines. Failure to do so may result
in serious bodily injury or death.
General Safety
mWARNING! This appliance is not intended for use
by children or by unassisted, unsupervised persons whose
physical, sensory or mental capabilities prevent them from using
it safely. Children should be supervised to ensure that they do
not play with the appliance.
Before starting up your machine, please check it carefully
for any defects. If you find any, do not start up your machine.
Contact your authorized Snow Joe®+ Sun Joe®dealer or
call the Snow Joe®+ Sun Joe®customer service center at
1-866-SNOWJOE (1-866-766-9563).
mWARNING! When using the power tool, basic safety
precautions should always be followed to reduce the risk of fire,
electric shock, and personal injury. These include:
1. Keep work area clean and well-lit – Cluttered, dark areas
invite accidents. Always inspect the area where the pole +
pruning saw is to be used.
2. Avoid dangerous environments – Do not use the power
tool in rain, in damp or wet locations, or in bad weather,
especially when there is a risk of lighting. This decreases the
risk of being struck by lighting. Do not operate the power tool
in gaseous or explosive atmospheres or use the power tool
near flammable or combustible liquids. Motors in these tools
may spark, and the sparks might ignite fumes.
3. Know your product – Know how to start and stop the
machine. Be thoroughly familiar with the controls.
4. Keep children, bystanders, and pets away –
All spectators, including pets, should be kept a safe distance
away from the work area.
5. Dress properly – Do not wear loose clothing or jewelry. They
can get caught in moving parts. Protective rubber gloves and
non-slip footwear are recommended when working outdoors.
6. Avoid Slipping – Exercise caution to avoid slipping or falling.
Wear protective footwear that will protect your feet and
improve your footing on slippery surfaces.
7. Stay alert – Watch what you are doing. Use common sense.
Do not operate the power tool when you are tired,
or under the influence of alcohol or drugs.
8. Do not overreach – Keep proper footing and balance at
all times.
9. Prevent unintentional starting – Do not pull the trigger
before connecting to battery pack, picking up or
carrying the appliance. Do not carry the pole + pruning
saw with your finger on the trigger.
10. Use the right appliance – Do not use the power tool for any
applications other than those for which it was intended.
11. The chain is sharp – Don't grasp the exposed chain or
cutting edges when picking up or holding the power tool.
12. Use two hands – Hold the telescoping pole and handle with
both hands to avoid loss of control.
13. Remove the battery – Remove the battery from the power
tool when it is not in use, before servicing it, when changing
accessories, and when performing any other maintenance
task.
14. Use safety glasses – Also use safety footwear, snug-fitting
clothing, protective gloves, hearing and head protection.
15. Use head protection – Always use head protection when
operating the power tool overhead. Falling debris can result
in serious personal injury.
16. Do not force the tool – It will perform better with less
likelihood of personal or mechanical injury if it is used at the
rate for which it was designed.
17. Check for damaged parts – Before further use of the
appliance, all guards and parts should be carefully checked
to determine that it will operate properly and perform its
intended function. Check for alignment of moving parts,
binding of moving parts, breakage of parts, mounting, and
any other condition that may affect its operation. A guard
or other part that is damaged should be properly repaired
or replaced. Contact the Snow Joe®+ Sun Joe®customer
service center at 1-866-SNOWJOE (1-866-766-9563) for
assistance.
18. Maintain the power tool with care – Keep the cutting edges
sharp and clean for optimal performance and to reduce the
risk of injury. Keep the handles dry, clean, and free from
oil and grease. Follow the additional recommendations
described in the maintenance section
of this manual.

2
19. Store indoors – When not in use, the power tool should be
stored indoors in a dry and high or locked-up place out of
the reach of children.
20. Do not use the power tool if the trigger does not turn it
on and off. Any power tool that cannot be controlled is
dangerous and must be repaired.
21. Keep all parts of the body away from the chain. Do not remove
cut material or hold material to be cut while the chain is moving.
Make sure the switch is off when clearing jammed material. The
chain will continue moving for a while after the tool is turned
off. A moment of inattention while operating the power tool may
result in serious personal injury.
22. Carry the power tool by the handle with the chain stopped.
When transporting or storing the power tool, always keep the
chain and guide bar in the bar sheath. Proper handling of the
pole + pruning saw will reduce the chance of personal injury.
23. Hold the product by insulated surfaces only. In the event that
the chain comes into contact with hidden wiring, exposed
metal parts of the product may become “live” and give the
operator an electric shock.
24. The unit has not been designed to provide protection from
electric shock in the event of contact with overhead electric
lines. Never use the power tool near any electrical power
lines. Contact with or use near power lines may cause
serious injury or electric shock resulting in death. Maintain a
minimum clearance of 50 ft (15 m) from all power lines.
25. Do not modify or attempt to repair the appliance or the
battery pack (as applicable) except as indicated in the
instructions for use and care.
mWARNING! Before inspecting, cleaning, or servicing the
machine, remove the battery and wait for all moving parts to
stop. Failure to follow these instructions can result in serious
personal injury or property damage.
mWARNING! Do not use this appliance without reading this
instruction manual.
mWARNING! Do not use the appliance within range of
persons unless they are wearing protective clothing.
mWARNING! Do not operate the cordless power tool in a
tree, on a ladder, or on scaffolding. Using the tool under such
circumstances is extremely dangerous.
mWARNING! Do not let familiarity with this type of tool
prevent you from taking all necessary precautions. Remember
that a careless fraction of a second is sufficient to inflict serious
injury.
mWARNING! The cordless pole + pruning saw must be
fully assembled before operation! Do not use the tool that is only
partly assembled or assembled with damaged parts!
mWARNING! Starting, stopping, and restarting an electric
motor repeatedly within a few seconds can generate a great
deal of heat and damage the motor. To protect the life of your
cordless power tool, always wait at least five seconds after
stopping before restarting the unit.
mWARNING! Electrical Shock Hazard – Before starting
up your machine, please check it carefully for any defects. If
you find any, do not start up your machine and contact your
distributor.
NOTE: Take care of small parts that are removed during
assembly or when making adjustments. Keep them secure to
avoid loss.
Please contact an authorized Snow Joe®+ Sun Joe®dealer
or call the Snow Joe®+ Sun Joe®customer service center at
1-866-SNOWJOE (1-866-766-9563) for all maintenance or
operations not foreseen in this manual. Any operation performed
in an unauthorized service center or by unqualified personnel
will completely invalidate the warranty.
mWARNING! For your safety and that of others:
• Correct maintenance is essential to maintain the original
efficiency and safety of the machine over time.
• Keep all nuts, bolts, and screws tight to be sure the
equipment is in safe working condition.
• Never use the machine with worn or damaged parts.
Damaged parts are to be replaced and never repaired.
mWARNING! Always wear protective gloves during
maintenance operations.
mWARNING! Use only original manufacturer’s replacement
parts, accessories and attachments. Failure to do so can
cause possible injury and poor performance. To order genuine
replacement parts or accessories for the Sun Joe®cordless
pole + pruning saw, please visit sunjoe.com or contact the
Snow Joe®+ Sun Joe®customer service center at
1-866-SNOWJOE (1-866-766-9563).
Cleaning the Tool
mWARNING! Never let any liquid get inside the motor
housing and NEVER immerse any part of the housing in liquid.
1. Stop the motor and remove the battery.
2. Clean dirt and debris from the body of the tool, using a damp
cloth with a mild detergent.
NOTE: Do not use any strong detergents on the plastic
housing or the handle, as they can be damaged by certain
aromatic oils such as pine and lemon, and by solvents such
as acetone.
Storage
mWARNING! Do not at any time let brake fluids, gasoline,
petroleum-based products, penetrating oils, solvents, etc., come
in contact with plastic parts. Chemicals can damage, weaken, or
destroy plastic which may result in serious personal injury.
1. Stop the motor and remove the battery.
2. Clean the pole + pruning saw thoroughly before storing.
3. Always place the bar sheath on the guide bar before storing
or transporting the pole + pruning saw. Use caution to avoid
the sharp chain.

3
4. Store the pole + pruning saw indoors, in a dry place that is
inaccessible to children. Keep away from corrosive agents
such as garden chemicals and de-icing salts.
5. We recommend using the original package for storage or
covering the product with a suitable cloth or enclosure to
protect it against dust.
Specific Safety Warnings
for Pole + Pruning saw
1. Only the pole + pruning saw operator should be in the
work area.
2. Do not use the pole + pruning saw to cut down trees.
3. Always use two hands when operating the pole + pruning
saw. Grip the pole + pruning saw securely with one hand on
the trigger and the other hand on the pole.
4. Before starting the pole + pruning saw, make sure that the
saw chain is not in contact with any object.
5. Do not allow the pole + pruning saw to make contact with
grounded objects such as pipes, fences, and metal posts.
6. Do not force the pole + pruning saw while cutting. Apply light
pressure. It will perform more effectively and safely if it is
used at the rate for which it was designed.
7. Use extreme caution when cutting a limb that is under tension.
When wood tension is released, the limb could spring back
and strike the operator, causing severe injury or death.
8. During transport, hold the pole at its balance point, with the
guide bar and chain facing to the rear.
9. Do not cut small brush and saplings with the pole + pruning
saw. Small branches may catch in the chain and be whipped
towards the operator, which could pull the operator off
balance.
10. Never stand directly under the limb you are trimming. Always
position yourself outside the path of falling debris.
11. Keep a firm, steady pressure on the pole + pruning saw while
cutting. Do not try to cut limbs larger in diameter than the
length of the guide bar.
12. Keep other people and pets away from the cutting end of
the pole + pruning saw and at a safe distance away from the
work area.
Kickback
mWARNING!Kickback may occur when the nose or tip of
the guide bar touches an object, or when the wood closes in
and pinches the saw chain in the cut.
AVOID CONTACTING THE GUIDE BAR TIP WITH ANY OBJECT.
In some cases, when the tip makes contact with an object, the
saw may rapidly kick up and back towards the operator. Material
pinching the chain may also push the saw back rapidly towards
the operator. Either of these reactions may cause you to lose
control of the pole + pruning saw, which could result in serious
personal injury. Follow the necessary precautions indicated
below to avoid kickbacks.
• Always use two hands when operating the pole + pruning
saw, one hand gripping the trigger and the other hand
gripping the pole. Use a firm grip. Thumbs and fingers must
wrap around the trigger and the pole.
• Keep all guards in place on the pole + pruning saw. Make
sure they are in proper working order.
• Do not overreach or extend arms above shoulder height.
• Keep solid footing and balance at all times.
• Never try cutting through two branches at the same time.
Only cut one at a time.
• Do not bury the guide bar nose or try to cut by boring the
guide bar nose into the wood.
• Watch for shifting of wood or other forces that may pinch the
chain.
• Use extreme caution when re-entering a previous cut.
• Use the chain and guide bar supplied with this pole +
pruning saw. Only use genuine Snow Joe®+ Sun Joe®
replacement parts designed specifically for use with this pole
+ pruning saw.
• Never use a dull or loose chain. Keep the chain sharp and
properly tensioned.
Battery & Charger
Safety Instructions
We pay a great deal of attention to the design of every battery
pack to ensure that we supply you with batteries that are safe,
durable and have a high energy density. The battery cells have
a wide range of safety devices. Each individual cell is initially
formatted and its electrical characteristic curves are recorded.
This data is then used exclusively to be able to assemble the
best possible battery packs.
Despite all the safety precautions, caution must always be
exercised when handling batteries. The following points must
be obeyed at all times to ensure safe use. Safe use can only be
guaranteed if undamaged cells are used. Incorrect handling of
the battery pack can cause cell damage.
IMPORTANT! Analyses confirm that incorrect use and poor care
of high-performance batteries are the main factors responsible
for personal and/or product damage.
mWARNING! Use only approved replacement batteries;
other batteries may damage the power tool and cause it to
malfunction, which can lead to serious personal injury.
mWARNING! Do not use a battery pack or appliance that is
damaged or modified. Damaged or modified batteries may exhibit
unpredictable behavior resulting in fire, explosion or risk of injury.
Have your battery pack serviced by a qualified repair person
using only identical replacement parts. This will ensure that the
safety of the battery pack is maintained.

4
mCAUTION! To reduce the risk of injury, use only official
24V* IONMAX designated chargers with the 24V* IONMAX
battery pack. The use of other batteries or chargers poses a risk
of fire, personal injury and damage. Do not wire a battery pack
to a power supply plug or car cigarette lighter, such misuse will
permanently disable or damage the battery pack.
• Avoid dangerous environments – Do not charge the battery
pack in rain, snow or in damp or wet locations. Do not use
the battery pack or charger in the presence of explosive
atmospheres (gaseous fumes, dust or flammable materials)
because sparks may be generated when inserting or
removing the battery pack, which could lead to a fire.
• Charge in a well-ventilated area – Do not block the charger
vents. Keep them clear to allow for proper ventilation. Do not
allow smoking or open flames near a charging battery pack.
Vented gases may explode.
NOTE: The safe temperature range for the battery is
41°F – 105°F (5°C – 40.5°C). Do not charge the battery
outside in freezing weather; charge it at room temperature.
• Maintain charger cord – When unplugging the charger, pull
the plug, not the cord, from the receptacle to reduce the
risk of damage to the electrical plug and cord. Never carry
the charger by its cord or yank it by the cord to disconnect
it from the receptacle. Keep the cord away from heat, oil
and sharp edges. Make sure the cord will not be stepped
on, tripped over or subjected to damage or stress when the
charger is in use. Do not use the charger with a damaged
cord or plug. Replace a damaged charger immediately.
• Do not use an extension cord unless it is absolutely
necessary – Using the wrong, damaged or improperly wired
extension cord poses a risk of fire and electric shock. If
an extension cord must be used, plug the charger into a
properly wired 16 gauge or larger extension cord with the
female plug matching the male plug on the charger. Make
sure that the extension cord is in good electrical condition.
• Charger XZ2600-0450 is rated for 100 – 240 volt AC
only – The charger must be plugged into an appropriate
receptacle.
• Do not use an electrical adapter – Use of an adapter is not
recommended or sold by the battery charger or battery pack
manufacturer.
• Unplug charger when not in use – Make sure to remove
battery packs from unplugged chargers.
mWARNING! To reduce the risk of electric shock,
always unplug the charger before performing any cleaning or
maintenance. Do not allow water to flow into the charger. Use a
Ground Fault Circuit Interrupter (GFCI) to reduce shock hazards.
• Do not burn or incinerate battery packs – Battery packs
may explode, causing personal injury or damage. Toxic
fumes and materials are created when battery packs are
burned.
• Do not crush, drop or damage battery packs – Do not use
the battery pack or charger if they have sustained a sharp blow,
been dropped, run over or have been damaged in any way
(i.e. pierced with a nail, hit with a hammer, stepped on, etc.).
• Do not disassemble – Incorrect reassembly may pose
a serious risk of electric shock, fire or exposure to toxic
battery chemicals. If the battery or charger are damaged,
contact an authorized Snow Joe®+ Sun Joe®dealer or
call the Snow Joe®+ Sun Joe®customer service center at
1-866-SNOWJOE (1-866-766-9563) for assistance.
• Battery chemicals cause serious burns – Never let a
damaged battery pack contact the skin, eyes or mouth. If
damaged, battery chemicals will react violently with air, use
rubber or neoprene gloves to safely dispose of it. If skin is
exposed to battery chemicals, wash the affected area with
soap and water. If eyes are exposed to battery chemicals,
immediately flush with water for 20 minutes and seek medical
attention. Remove and dispose of contaminated clothing.
• Do not short circuit – When battery pack is not in use, keep
it away from other metal objects, like paper clips, coins, keys,
nails, screws or other small metal objects, that can make a
connection from one terminal to another. Shorting the battery
terminals together may cause burns or a fire.
• Store your battery pack and charger in a cool, dry
place – Do not store the battery pack or charger where
temperatures may exceed 105°F (40.5°C), such as in direct
sunlight or inside a vehicle or metal building during the
summer.
Information about the battery
1. The battery pack supplied with your cordless power tool is
only partially charged. The battery pack has to be charged
completely before you use the tool for the first time.
2. For optimum battery performance, avoid low discharge
cycles by charging the battery pack frequently.
3. Store the battery pack in a cool place, ideally at 77°F (25°C)
and charged to at least 40%.
4. Lithium-ion batteries are subject to a natural aging process.
The battery pack must be replaced at the latest when
its capacity falls to just 80% of its capacity when new.
Weakened cells in an aged battery pack are no longer
capable of meeting the high power requirements needed for
the proper operation of your cordless pole + pruning saw,
and therefore pose a safety risk.
5. Do not throw battery packs into an open fire as this poses a
risk of explosion.
6. Do not ignite the battery pack or expose it to fire.

5
7. Do not exhaustively discharge batteries. A complete
discharge will damage the battery cells. The most common
cause of exhaustive discharge is lengthy storage. Stop
working as soon as the performance of the battery falls
noticeably or the electronic protection system triggers. For
optimum battery performance, charge the battery pack
frequently. Place the battery pack in storage only after it has
been fully charged.
8. Protect batteries and the tool from overloads. Overloads
will quickly result in overheating and cell damage inside
the battery housing even if this overheating is not apparent
externally.
9. Avoid damage and shocks. Immediately replace batteries that
have been dropped from a height of more than 3 feet
(1 meter) or those that have been exposed to violent shocks,
even if the housing of the battery pack appears to be
undamaged. The battery cells inside the battery may have
suffered serious damage. In such instances, please read the
waste disposal information for proper battery disposal.
10. If the battery pack suffers overloading and overheating, the
integrated protective cutoff will switch off the equipment for
safety reasons.
IMPORTANT! Do not press the ON/OFF trigger switch any
more if the protective cut-off has been activated. This may
damage the battery pack.
11. Recharge only with the charger specified by the
manufacturer. A charger that is suitable for one type of
battery pack may create a risk of fire when used with another
battery pack.
12. Use appliances only with specifically designated battery
packs. Use of any other battery packs may create a risk of
injury and fire.
13. Under abusive conditions, liquid may be ejected from the
battery; avoid contact. If contact accidentally occurs, flush
with water. If liquid contacts eyes, additionally seek medical
help. Liquid ejected from the battery may cause irritation or
burns.
14. Do not use a battery pack or appliance that is damaged
or modified. Damaged or modified batteries may exhibit
unpredictable behavior resulting in fire, explosion or risk of
injury.
15. Do not expose a battery pack or appliance to fire or
excessive temperature. Exposure to fire or temperature
above 266°F (130°C) may cause explosion.
16. Follow all charging instructions and do not charge the
battery pack or appliance outside of the temperature range
specified in the instructions. Charging improperly or at
temperatures outside of the specified range may damage the
battery and increase the risk of fire.
Information about the charger and the
charging process
1. Please check the data marked on the rating plate of the
battery charger. Be sure to connect the battery charger to
a power supply with the voltage marked on the rating plate.
Never connect it to a different mains voltage.
2. Protect the battery charger and its cord from damage. Keep
the charger and its cord away from heat, oil and sharp
edges. Have damaged cords repaired without delay by a
qualified technician at an authorized Snow Joe®+ Sun Joe®
dealer or call the Snow Joe®+ Sun Joe®customer service
center at 1-866-SNOWJOE (1-866-766-9563).
3. Electrical plugs must match the outlet. Never modify the plug
in any way. Do not use any adapter plugs with grounded
appliances. Unmodified plugs and matching outlets will
reduce the risk of electric shock.
4. Keep the battery charger, battery pack(s) and the cordless
tool out of the reach of children.
5. Do not use the supplied battery charger to charge other
cordless tools.
6. During periods of heavy use, the battery pack will become
warm. Allow the battery pack to cool to room temperature
before inserting it into the charger to recharge.
7. Do not overcharge batteries. Do not exceed the maximum
charging times. These charging times only apply to
discharged batteries. Frequent insertion of a charged or
partially charged battery pack will result in overcharging and
cell damage. Do not leave batteries in the charger for days
on end.
8. Never use or charge batteries if you suspect that it has been
more than 12 months since the last time they were charged.
There is a high probability that the battery pack has already
suffered dangerous damage (exhaustive discharge).
9. Charging batteries at a temperature below 41°F (5°C) will
cause chemical damage to the cells and may cause a fire.
10. Do not use batteries that have been exposed to heat during
the charging process, as the battery cells may have suffered
dangerous damage.
11. Do not use batteries that have suffered swelling or
deformation or those that exhibit other atypical symptoms
(gassing, hissing, cracking, etc.).

6
Protection from environmental influences
1. Wear suitable work clothes. Wear safety goggles.
2. Protect your cordless tool and the battery charger from
moisture and rain. Moisture and rain can cause dangerous
cell damage.
3. Do not use the cordless tool or the battery charger near
vapors and flammable liquids.
4. Use the battery charger and cordless tools only in dry
conditions and at an ambient temperature of 41°F – 105°F
(5°C – 40.5°C).
5. Do not keep the battery charger in places where the
temperature is may to reach over 105°F (40.5°C). In
particular, do not leave the battery charger in a car that is
parked in the sunshine.
6. Protect batteries from overheating. Overloads, overcharging
and exposure to direct sunlight will result in overheating and
cell damage. Never charge or work with batteries that have
been overheated – replace them immediately, if possible.
7. Store the charger and your cordless tool only in dry
locations with an ambient temperature of 41°F – 105°F
(5°C – 40.5°C). Store your lithium-ion battery pack in a
cool, dry place at a temperature of 77°F (25°C). Protect the
battery pack, charger and cordless tool from humidity and
direct sunlight. Only place fully charged batteries in storage
(charged to at least 40%).
8. Prevent the lithium-ion battery pack from freezing. Battery
packs that were stored below 32°F (0°C) for more than
60 minutes must be discarded.
9. When handling batteries, be wary of electrostatic charge.
Electrostatic discharges can damage the electronic
protection system and the battery cells. To avoid electrostatic
discharges never touch the battery terminals.

7
Safety Symbols
The following table depicts and describes safety symbols that may appear on this product. Read, understand, and follow all
instructions on the machine before attempting to assemble and operate.
Symbols Descriptions Symbols Descriptions
READ THE OPERATOR'S MANUAL
– Read, understand, and follow
all instructions in the user manual
before attempting to assemble and
operate.
SAFETY ALERT – Indicates a
precaution, a warning, or a danger.
WEAR EYE AND HEARING
PROTECTION – For protection
against injury, wear ear defenders
and safety goggles.
WARNING! Do not expose the unit to
rain or wet conditions. Keep dry.
Wear protective gloves and non-slip
footwear when using the machine
and handling debris. m
CAUTION! Avoid contact between
the tip of the guide bar with any
object. Contact with the tip of the
guide bar may cause the chain
saw to kickback, which may cause
serious injury to the user.
The moving part will continuously run
for several seconds after you turn off
the machine.
Correct direction of cutters.
50 ft
(15 m) WARNING! SHOCK HAZARD – Keep
at least 50 ft (15 m) away from power
lines. Do not overreach. Keep proper
footing and balance at all times.
DANGER! ROTATING BLADES –
Keep hands and feet away from
openings while the saw is running.
Only use the battery
charger indoors.
Keep bystanders a minimum
distance of 50 ft (15 m) away from
the work area.

8
Know Your Cordless Pole + Pruning Saw
Read the owner’s manual and safety instructions carefully before operating the cordless pole + pruning saw. Compare the illustration
below to the cordless pole + pruning saw in order to familiarize yourself with the location of the various controls and adjustments.
Save this manual for future reference.
1. Chain/sprocket end cover
2. End cover knob
3. Riving knife
4. 6in(15.24 cm) guide bar
5. 6in(15.24 cm) cutting chain
6. Cutting bar sheath
7. Base plate
8. 24V* IONMAX
lithium-ion battery
(24VBAT-LTE) featuring
exclusive EcoSharp®
technology
Technical Data
Motor...............................................................................................360 W
Battery Voltage Max* ............................................................. 24V D.C.
Battery Capacity ........................................................................... 2.0 Ah
Charger Input ...........................100 – 240V AC | 50/60 Hz | 0.4 A
Charger Output .......................................................26V DC | 450 mA
Charge Time Max ..................................................................... 5 hours
Bar and Chain Length .................................................. 6 in (15.2 cm)
Cutting Thickness Max ................................................. 5.5 in (14 cm)
Multi-Angle Head .................................................................9 positions
(-45° | -30° | -15° | 0° | 15° | 30° | 45° | 60° | 75°)
Telescopic Pole............................................................... 3.7 ft to 5.6 ft
(1.1 m to 1.7 m)
Overhead Reach.................................................... Up to 12 ft (3.6 m)
Oil Tank Capacity ........................................................... 1 fl oz (30 ml)
Net Weight (without pole) ............................................. 2.9 lbs (1.3 kg)
Net Weight (with pole) .................................................. 5.1 lbs (2.3 kg)
9. Charge socket
10. Push lock button (2)
11. Push button for battery
indicator
12. Battery indicator
13. 24V* IONMAX lithium-ion
charger (XZ2600-0450)
14. Charger plug
15. Lubricating oil
16. Hex key wrench
17. Battery compartment
18. Handle grip
19. On/Off switch
20. Safety lock button
21. Ventilation slots
22. Oil inlet
23. Lock button
(pole assembly)
24. Multi-angle lock button
25. Handle locking collar
26. Pole assembly
27. Soft grip
28. Safety switch
29. Upper handle
30. On/off switch
31. Battery compartment
*DISCLAIMER: Initial no‑load voltage, when fully charged, peaks at 24V; nominal voltage under typical load is 21.6V
8 9 1110 12 13 14 15
R
6
16
7
17
3
2
1
22
4
5
18 24 25 2623
20 19
21 27 28 29
30 31

9
Unpacking
Carton Contents
• Pruning saw with chain and bar pre-assembled
• Cutting bar sheath (assembled on the chain and bar)
• Hex key wrench (in the storage slot)
• 1 fl oz (30 ml) lubrication oil
• Pole assembly
• 24V* IONMAX lithium-ion battery
• 24V* IONMAX lithium-ion battery charger
• Manual with registration card
1. Carefully remove the cordless pole + pruning saw and check
to see that all of the above items are supplied.
2. Inspect the product carefully to make sure no breakage or
damage occurred during shipping. If you find damaged or
missing parts, DO NOT return the unit to the store.
Please call the Snow Joe®+ Sun Joe®customer service
center at 1-866-SNOWJOE (1-866-766-9563).
NOTE: Do not discard the shipping carton and packaging
material until you are ready to use your new cordless pole +
pruning saw. The packaging is made of recyclable materials.
Properly dispose of these materials in accordance with local
regulations.
IMPORTANT! The equipment and packaging material are
not toys. Do not let children play with plastic bags,
foils or small parts. These items can be swallowed and pose
a suffocation risk!
Battery Pack Operation
The equipment is powered by a lithium-ion battery. The battery
pack is completely sealed and maintenance free.
Battery Charge Level Indicator
The battery pack is equipped with a push button for checking
the charge level. Simply press the push button to read off the
battery charge level from the LEDs of the battery indicator:
Lights Light Indicators
Charge level button
The battery is at 30% capacity
The battery is at 60% capacity
The battery is fully charged
NOTE: If the battery indicator button does not appear to be
working, charge the battery.
NOTE: Immediately after using the battery pack, the battery
indicator button may display a lower charge than it will if
checked a few minutes later. The battery cells “recover” some
of their charge after resting.
Charger Operation
mWARNING! Only charge Sun Joe®24V lithium-ion battery
pack with compatible Sun Joe®24V lithium-ion chargers. Other
types of chargers may cause personal injury and damage.
To reduce the risk of electric shock, do not allow water to enter
into the charger.
Charging the Battery
1. Push the push lock buttons on either side of the battery
pack to pull it out from the battery compartment (Fig. 1).
2. Check that the mains voltage is the same as that marked on
the rating plate of the battery charger. Then plug the charger
into an appropriate AC power outlet. Connect the charger
plug into the charging socket of the battery to start charging
(Fig. 2).
Fig. 1
Push lock button
Fig. 2
Battery
indicators

10
3. The battery will take approximately 5 hours to charge. The
battery indicator LEDs will cycle on one by one during the
charging process. Unplug the charger immediately when all
3 LEDs are illuminated.
mCAUTION! FIRE HAZARD. When disconnecting the
charger from the battery, be sure to unplug the charger from the
outlet first, then disconnect the battery from the charger.
mWARNING! This charger does not automatically turn off
when the battery is fully charged. Please take care not to leave
the battery plugged into the charger. Switch off or unplug the
charger at the mains when charging is complete.
4. Timely recharging of the battery will help prolong the
battery's life. Recharge the battery pack when you notice a
drop in the equipment's power.
IMPORTANT! Never allow the battery pack to become fully
discharged as this will cause irreversible damage to the battery.
Assembly
This cordless pruning saw comes completely assembled with
the guide bar and chain pre-installed. Users simply have to
configure the unit as a hand-held pruning saw or a pole pruning
saw before operation. Follow the instructions below to connect
the machine.
mCAUTION! Make sure the battery is not inserted and the
chain are covered by the sheath before assembly.
Pole Pruning Saw Assembly
1. To install the pole, align the ridge on the end of the pole
assembly with the Battery compartment on the handle,slide
the pruning saw downward into the pole assembly until it
clocks into position. (Fig. 3).
Pole
assembly
Fig. 3
2. Slide the battery into the end of the pole assembly, until it
clicks into position. (Fig. 4).
3. To disassemble the pole pruning saw, press the push lock
buttons on the battery to pull it out ofthe equipment (Fig. 5).
4. Press the Lock buttons on pole assembly to pull it out of the
pruning saw (Fig. 6).
Preparing To Work
Checking the Machine
mWARNING! Before performing any checks, adjustments,
repairs or maintenance on the machine, make sure the battery is
not inserted in the compartment.
• Check that all the screws on the machine and the guide bar
are tightly fastened.
• Check that the chain is tensioned correctly, sharp and there
are no signs of any damage.
Fig. 4
Fig. 5
Fig. 6
