Softbank 302sh User manual

302SH User Guide

SoftBank 302SH

302SH User Guide Contents

Introduction

Introduction.........................................................................3

Getting Started

Package Contents............................................................... 6

Parts & Functions.............................................................. 6

USIM Card Installation....................................................... 7

Handset Memory & SD Card.............................................. 8

Charging Handset..............................................................11

Power On/Off................................................................... 13

Touchscreen Operations................................................... 14

Basic Operations

Basic Operations...............................................................18

Applications.......................................................................20

Handset Phone Number.................................................... 21

Mobile Manners................................................................. 21

Text Entry.........................................................................22

Google™ Accounts............................................................ 24

Google Play....................................................................... 26

Security Codes.................................................................. 28

USIM PIN............................................................................29

Screen Lock....................................................................... 30

Software Updates.............................................................30

Handset Interface

Welcome Sheet (Lock Screen) Basics...............................34

3-Line Home Basics.......................................................... 35

Status Bar......................................................................... 36

Notifications Window.......................................................37

Using Quick Launcher.......................................................38

Using Mini-Applications & Mini-Widgets........................ 39

Customizing 3-Line Home................................................ 40

Phone

Calling................................................................................ 44

Optional Services..............................................................45

Address Book.................................................................... 50

Messaging & Browser

Messaging.......................................................................... 52

Sending S! Mail/SMS.........................................................52

Opening & Replying to S! Mail/SMS................................54

Opening Received S! Mail/SMS........................................ 56

Creating/Sending Gmail....................................................56

Opening Received Gmail................................................... 57

Using Internet Mail.......................................................... 58

Web Browsing (Browser).................................................. 60

Camera

Photo Camera....................................................................66

Video Camera.................................................................... 67

Music & Images

Music & Images.................................................................70

Music Files (Music)........................................................... 70

Still Images & Video (Album)...........................................71

Connectivity

Wi-Fi...................................................................................74

Tethering Option.............................................................. 76

Bluetooth®........................................................................ 77

Global Services

Global Roaming................................................................. 82

Calling from Outside Japan.............................................83

Settings

About Settings..................................................................86

Sound Settings..................................................................87

Wallpaper & Display Settings..........................................89

Recent Apps Key Setting................................................. 90

Device Info........................................................................ 90

Add Account......................................................................91

Wi-Fi Settings...................................................................92

Home Applications Setting.............................................. 92

Storage Settings...............................................................93

Application Settings.........................................................93

Data Transfer................................................................... 94

Other Settings..................................................................96

Appendix

Specifications..................................................................106

Customer Service............................................................107

Safety Precautions

Safety Precautions.........................................................110

Important Product Information.....................................116

Handset & Hardware Care............................................. 117

General Notes................................................................. 119

FCC Notice...................................................................... 120

RF Exposure Information/Specific Absorption Rate (SAR)

Information..................................................................... 121

Water Resistance............................................................122

Introduction SoftBank 302SH

Introduction

Thank you for purchasing SoftBank 302SH.

Before You Begin

・Read "Quick Tips" (in お願いとご注意) and this guide

thoroughly beforehand for proper usage.

・Accessible services may be limited by contract conditions.

・Unauthorized copying of any part of this guide is

prohibited.

・Guide content subject to change without prior notice.

Guide Usage Notes

・SoftBank 302SH is referred to as "handset" in this guide.

・Most operation descriptions are based on default settings.

・Unless noted otherwise, descriptions are for application

sheet in 3-Line Home.

・"Confirmation" refers to authentication prompt, selection,

caution or other message that appears after operation.

・Some operation descriptions may be omitted.

・In this guide and on handset, "abroad" means "outside Japan"

with regard to handset/service usage.

・In this guide, microSD/microSDHC/microSDXC Card is

referred to as "SD Card."

Screenshots & Key Labels

Screenshots and key labels are provided for reference only.

Actual handset windows, menus, etc. may differ in appearance.

Accessing Functions Guide

In application sheet, (Guide)

・Guide usage information and confirmation for automatic

updates appear at initial startup. Follow onscreen prompts.

Guide indicator appears on Status Bar by default. To hide

Guide indicator:

In application sheet, (Guide) Indicator

off Back

Getting Started

Package Contents............................................................... 6

Parts & Functions.............................................................. 6

USIM Card Installation....................................................... 7

Handset Memory & SD Card.............................................. 8

Charging Handset..............................................................11

Power On/Off................................................................... 13

Touchscreen Operations................................................... 14

Package Contents

・Handset (SoftBank 302SH)

・Battery is built into handset.

・Handset back cover is not removable.

・AC Charger (SHCEJ1)

・Desktop Holder (SHEFD1/2/3/4)

・TV Input-to-Micro USB Cable

・クイックスタート (Japanese)

・お願いとご注意 (Japanese) with English "Quick Tips"

・Warranties (Japanese) for handset and AC Charger

Parts & Functions

Handset Parts

Name Description

SD/USIM

Card Slot Access USIM Card and SD Card.

Earpiece Hear other party's voice through this.

Charging

Terminals

(Side)

For use with Desktop Holder.

Notification

Lamp

Illuminates while charging or for

notifications (missed calls, new messages,

etc.).

Mic Talk to other party through this.

Headphone

Port

Connect Headphones with Mic (optional

accessories) here.

Antenna Pull out for Full Seg/One Seg reception.

Proximity/

Light Sensor

Detects ambient light level and prevents

Touchscreen misoperation during call.

Display Touch Display to select menu items, open

functions, scroll pages, etc.

Internal

Camera Shoot photos or videos.

Strap

Eyelet Attach Straps here.

Getting Started SoftBank 302SH

Name Description

Infrared

Port Transfer files using Infrared.

External

Camera Shoot photos or videos.

Mobile

Light Use as a camera flash, flashlight, etc.

External

Device Port

(Side)

Connect AC Charger or Micro USB Cable

here.

Mic

(Recorder Mic)

Captures ambient sounds while recording

videos.

FeliCa Logo Place over reader/writer to use NFC/

Osaifu-Keitai®.

Speaker Listen to music, video sounds, Full Seg/

One Seg audio, etc. through this.

Handset Keys

Name Description

(Power Key)

Activate/cancel Screen lock. Long Press

for power on/off or phone options.

(Volume Down

Key)

Decrease Volume. In Welcome sheet (lock

screen) or 3-Line Home, Touch & Hold to

activate/cancel Silent mode.

(Volume Up

Key)

Increase Volume. In Welcome sheet (lock

screen), Touch & Hold to turn on Mobile

Light1.

1　To turn off, Press .

USIM Card Installation

USIM Card is an IC card containing customer and

authentication information, including handset number.

Inserting USIM Card

Always power off beforehand.

If SD Card is inserted, remove it first. (SD Card needs to be

removed to insert USIM Card.)

・For SD Card removal procedure, see "Removing SD Card."

Open Card Slot Cover

Pull out USIM Tray

・Do not pull USIM Tray forcefully or at an angle; damage may

result. Gently pull it straight out from the edge.

Place USIM Card in USIM Tray

・Check orientation of USIM Card (see the notch), then gently

place it with metal contacts facing up.

Insert USIM Tray into USIM Card Slot (bottom opening)

・Check orientation of USIM Tray, then insert it all the way.

Close Card Slot Cover

・Close Card Slot Cover firmly. Debris trapped between gasket

and base may allow ingress of liquid.

Removing USIM Card

Always power off beforehand.

If SD Card is inserted, remove it first. (SD Card needs to be

removed to remove USIM Card.)

・For SD Card removal procedure, see "Removing SD Card."

Open Card Slot Cover

Pull out USIM Tray

・Do not pull USIM Tray forcefully or at an angle; damage may

result. Gently pull it straight out from the edge.

Remove USIM Card

Insert USIM Tray into USIM Card Slot (bottom opening)

・Check orientation of USIM Tray, then insert it all the way.

Close Card Slot Cover

・Close Card Slot Cover firmly. Debris trapped between gasket

and base may allow ingress of liquid.

Handset Memory & SD Card

Handset supports SD Card up to 64 GB. Some SD Cards may

not operate properly.

In addition to SD Cards, use handset memory as storage for

system files, applications, shot photos/videos, etc.

Inserting SD Card

Always power off beforehand.

Open Card Slot Cover

Insert SD Card into SD Card Slot (top opening)

・Insert SD Card all the way with terminals facing up.

Close Card Slot Cover

・Close Card Slot Cover firmly. Debris trapped between gasket

and base may allow ingress of liquid.

Getting Started SoftBank 302SH

Formatting SD Card

When using a new SD Card for the first time, format it on

handset before trying to save images, music, etc.

・Formatting deletes all SD Card files.

・Charge handset while formatting or charge it adequately

beforehand.

In application sheet, (Settings)

Storage

Erase microSD

Erase SD card

Enter Operation Password OK

・If Operation Password is unset, follow onscreen prompts.

Erase everything

All SD Card files will be deleted.

Unmounting SD Card

In application sheet, (Settings)

Storage

Unmount microSD OK

Unmount microSD changes to Mount microSD . (SD Card

is unmounted.)

・To have SD Card recognized again, Tap Mount microSD .

Removing SD Card

Always power off beforehand.

Open Card Slot Cover

Remove SD Card

・Gently push in SD Card and release; it pops out. Carefully

remove SD Card without bending it.

Close Card Slot Cover

・Close Card Slot Cover firmly. Debris trapped between gasket

and base may allow ingress of liquid.

Getting Started SoftBank 302SH

Handset Memory & SD Card Usage Notes

Handset Memory & SD Card Files

Handset memory files and SD Card files may be lost/

altered accidentally. Keep a separate copy of important

information. SoftBank Mobile Corp. is not liable for any

damages resulting from accidental loss/alteration of

information.

・Never power off while files are being accessed.

microSDXC Card

Handset supports microSDXC Cards (SDXC-compatible SD

Cards). microSDXC Cards are supported by SDXC-compatible

devices only.

Exchanging Files with Non-SDXC-Compatible

Devices

To exchange files between handset and non-SDXC-

compatible devices, use SD Cards (microSD/microSDHC

Cards) supported by handset and those devices. Inserting a

microSDXC Card used on handset in a non-SDXC-compatible

device may corrupt card files. In such cases, do not format

the microSDXC Card on that device even if prompted to do

so.

・Formatting deletes all microSDXC Card files and changes

the file system. The original memory capacity may

be unavailable after formatting. To use a corrupted

microSDXC Card, format it on an SDXC-compatible device.

Handling SD Cards Used on Other Mobiles

After installing SD Card used on other mobiles (such as

previously used handsets) into handset, the notification

Application data is present in the microSD. may appear on

Status Bar. To use files on such SD Cards on handset, copy

files to handset memory as follows.

Drag Status Bar down for Notifications Window

Application data is present in the microSD. Follow

onscreen prompts

・If the same folder/file name exists in handset memory,

overwrite confirmation appears. Handset memory files

cannot be restored once overwritten.

Handset Memory

Photos and videos shot on handset are saved to handset

memory by default. Depending on downloaded application

(sold separately), corresponding files are saved to handset

memory even if SD Card is specified as their save location

in application description.

SD Card Caution

Keep SD Card away from infants; may cause choking if

swallowed.

Charging Handset

Battery is built into handset.

Desktop Holder, AC Charger, Micro USB Cable (optional

accessory), Micro USB Charging Adapter (optional accessory)

and In-Car Charger (optional accessory) are not water

proof. Never charge handset while it is wet; may cause fire,

malfunction or burns due to electric shock or short-circuiting.

Be sure to dry it before use.

Desktop Holder

Use Desktop Holder (SHEFD1/2/3/4) with AC Charger

(SHCEJ1).

・Never charge handset while it is wet.

Insert Micro USB plug of AC Charger into connector port of

Desktop Holder

・Insert Micro USB plug in correct orientation; otherwise,

connector port of Desktop Holder may be damaged. Check

contours and orientation of Micro USB plug before inserting

it.

Extend blades and plug AC Charger into AC outlet

Place handset into Desktop Holder with Charging Terminals

facing down

Notification Lamp goes out when charge is full.

・Push handset down to set it in place and check that

Notification Lamp illuminates red. (Notification Lamp

illuminates green when charge is almost full.)

After charging, remove handset and then Micro USB plug from

Desktop Holder, then unplug AC Charger and retract blades

AC Charger

Use AC Charger (SHCEJ1).

・Never charge handset while it is wet.

Insert Micro USB plug of AC Charger into External Device Port

・Insert Micro USB plug in correct orientation; otherwise,

External Device Port may be damaged. Check contours and

orientation of Micro USB plug before inserting it.

Extend blades and plug AC Charger into AC outlet

Notification Lamp goes out when charge is full.

・Check that Notification Lamp illuminates red. (Notification

Lamp illuminates green when charge is almost full.)

After charging, remove Micro USB plug from External Device

Port, then unplug AC Charger and retract blades

USB Charging

Connect handset to a PC with Micro USB Cable (SHDDL1;

optional accessory).

・Power on handset and PC first.

・Handset may not charge or charge slowly depending on PC

status/environment.

・Never charge handset while it is wet.

Insert Micro USB plug of Micro USB Cable into External Device

Port

・Insert Micro USB plug in correct orientation; otherwise,

External Device Port may be damaged. Check contours and

orientation of Micro USB plug before inserting it.

Insert USB plug of Micro USB Cable into PC USB port

Notification Lamp goes out when charge is full.

・Check that Notification Lamp illuminates red. (Notification

Lamp illuminates green when charge is almost full.)

After charging, remove Micro USB Cable from handset and PC

Getting Started SoftBank 302SH

Lithium-ion Battery & Desktop Holder

Lithium-ion Battery

This product requires a lithium-ion battery. Lithium-

ion batteries are recyclable. To recycle a used lithium-

ion battery, take it to any shop displaying the recycling

symbol.

・To avoid fire or electric shock, do not short-circuit or

disassemble Battery.

Front Duct

When handset is placed into Desktop Holder, sounds from

Speaker can be heard through the opening at the front of

Desktop Holder (front duct), increasing audibility of music,

video sounds, Full Seg/One Seg audio, etc.

Charging Cautions

Handling Cables

Do not pull, bend, or twist cable; may damage the cable.

USB Charging Caution

Handset may power on automatically when connected to a

PC with Micro USB Cable; avoid connection aboard aircraft

or in hospitals, etc. where handset use is prohibited.

Battery Care

To help maintain performance and life of Internal Battery,

do not store in the following conditions.

・Full (immediately after charging is complete)

・Exhausted (too low to power on handset)

Periods of Disuse

Charge handset to approximately 40% at least once every 6

months; if left uncharged, handset may become unusable or

files/settings may be affected.

Bulges of Internal Battery

Depending on usage, bulges may appear near end of battery

life; this does not affect safety.

Internal Battery Replacement

Internal Battery is a consumable item; may need to be

replaced if operating time shortens noticeably. Internal

Battery is not user replaceable; its replacement incurs fees

and requires handset submission to a SoftBank Shop or

other appropriate servicer. For details, contact a SoftBank

Shop or SoftBank Customer Support, General Information.

Power On/Off

Power On

Long Press until SoftBank logo appears

After Power On Graphics, Welcome sheet (lock screen)

appears.

Drag to the bottom of Display

Google & location window opens.

・If confirmation appears, follow onscreen prompts.

・Google & location window may open even when handset is

not used.

Set Google's location service options

Initial setup menu opens.

Power Off

(Long Press)

Power off

Handset shuts down.

Touchscreen Operations

Touch Display to select menu items, open functions, scroll

pages, etc.

Tap

Tap item or key to open or execute corresponding function/

operation.

Touch & Hold

Touch item for 1+ seconds to move icon, open menu, etc.

Drag

Drag item to move it.

Getting Started SoftBank 302SH

Flick

Flick to toggle sheets, pages, etc.

Pinch/Spread

Pinch or Spread to zoom in or out on images, maps, etc.
