Solar Stik PRO-VERTER 5000-220 AGS BFF1 Operating instructions

Updated: 20221123
PROGRAMMING GUIDE
FOR THE
PRO-VERTER
5000-220 AGS BFF1
ATSC L1 SYSTEM WITH 13 KW GENERATOR
Note: The L1 Systems have two PRO-Verter 5000-220-BFF1s.
Program BOTH #1 and #2 with the same values.

PRO-Verter Programming for L1 System with 13 kW Generator
November 2022 |Solar Stik® Inc.2 |
CTRL
01 AC In Control
Auto Connect
02 CHG Control
Multi-Stage
03 Gen Control
OFF
Set AC In Control
Auto Connect
Set CHG Control
Multi-Stage
Set Gen Control
AUTO
Set AC In Control
VDC Connect
Set CHG Control
Start Float
Set Gen Control
ON
Set AC In Control
Time Connect
Set CHG Control
Start Bulk
Set Gen Control
OFF
Set AC In Control
SOC Connect
Set AC In Control
AC In - Disabled
See Setup Button 04 Menu Options
METER
Status
01 DC Meters
Status
02 AC Meters
Status
04 AGS Meters
01A DC Volts
26.2 VDC
02A Output Volts
230 VAC/ 50.0 Hz
01B DC Amps
0 Amps
02B Load Amps
0 Amps AC
02C Input Amps
0 Amps AC
02D Inv/Chg Amps
0 Amps AC
Status
03 Timers
03A Charge Time
Status
03B Since Absorb
27.8 VDC
03C Since EQ
0.0 Hours
CTRL Button Menus
METER Button Menus: Read-only Displays
Continued on next page
Programming Menu Map
R
R
R
R R R R
P
P
P
R R
R R
FAVS Button Menus
FAVS
F1 Battery Type
CC/CV
F4 LBCO
24.0 Volts
F2 AmpHour Size
450AH
F3 AC Input
Amps = 26 A
F5 Gen Run VDC
Set Stop Gen
Volts = 28.4
Set Stop Volts
Delay = 15 sec
Set Start Gen
Volts = 24.6
Set Start Volts
Delay = 15 sec
Set CV Chg Done
HOLD CV/CHG VDC
Set CV Charge
Volts = 29.0
Set Max Charge
AMPS = 100

|3November 2022 |Solar Stik® Inc.
PRO-Verter Programming for L1 System with 13 kW Generator
[Status/Fault]
05 BMK Meters
METER
04 AGS Meters
Auto
04A AGS Status
[AGS Status]
04B DC Volts-AGS
## VDC
04C Gen Run Time
##.# Hrs
04E Since Gen Run
## Days
04D AGS Temp
##F
04F Since 100%
## Days
04G Hour Meter
##### Hrs
AC In Start Amp Fault Amp Fault Test
Gen Cooldown Start Exercise Fault Exercise Fault Time
Gen Warm-up Start SOC Fault Gen Run Fault Topoff
Manual Run Start Temp Fault MaxRn Fault VDC
No Comm Start Test Fault SOC Fault 100% SOC
(No AGS present) Start Time
Off Start Topoff
Quiet Time Start VDC
Ready Start 100% SOC
Available Statuses Windows in 04A:
05A BMK Status 05B Battery SOC
Think’n
BMK Ready
No Comm (No BMK)
Factory Fault
Power-up Fault
Unknown Fault ##
Think’n
###%
Factory Fault
Power-Up Fault
Unknown Fault ##
05C DC Volts-BMK
28.28 VDC
05A Statuses: 05B Readings:
05D DC Amps-BMK
140 ADC
05E DC AH In/Out
10 AH
05F Reset AH In/Out
### AH
05G Total AH Out
### AH
05H Minimum VDC
### VDC
05I Maximum VDC
XXX VDC
05J Days Since
100% SOC X
Resettable menu
selections. Press
and hold knob
for 3 seconds to
reset values.
METER Button Menus continued

PRO-Verter Programming for L1 System with 13 kW Generator
November 2022 |Solar Stik® Inc.4 |
Range: 12:00AM - 12:00PM (Note: Ensure the clock is set to local time.)
SETUP
01 System Setup
01A Set Clock
11:18AM
01D Max Charg
CC/CV Controlled
01B Screen Setup
Press to Select
01C Temp Display
Celsius
Set Clock
Hour = 11:18AM
Set Screen Setup
Brightness 60%
Set Temp Display
Fahrenheit
Set Clock
Min = 11:18AM
Set Screen Setup
Contrast 100%
Set Temp Display
Celsius
Set Clock
AM/PM = 11:18AM
Set Screen Setup
Pwr Save=15 min
02 Invert Setup
02A Search Watts
OFF
02B LBCO Setting
Volts = 24.0
02C AC In - Time
6:00A to 6:00P
02D AC In-VDC
Range 22.0-28.8 VDC
Set Search Watts
Range: OFF, 5-50
Set LowBatCutOut
Volts = 18.0-24.4
02E AC-In SOC
20-100%
Set Connect
SOC = 20%
Set Disconnect
SOC = 100%
02F Power Up
Always ON
Set Power Up
Always = OFF
Set Power Up
Always = ON
Range: Off,
0-60 min
Setup: 01 System & 02 Inverter Setup
SETUP Button Menus
Continued on next page
Set CONNECT to 22.0 V and DISCONNECT to 28.8 V
When CTRL 01 AC In Control is set to AUTO, this value is ignored.

|5November 2022 |Solar Stik® Inc.
PRO-Verter Programming for L1 System with 13 kW Generator
Range: 5 A to 60 A
Range: GEL, Flooded, AGM1 AGM2, Custom
. . . . . . .
SETUP
Status
03 Charger Setup
03A AC Input
Amps = 26A
03C Battery Type
CC/CV
Set Battery Type
GEL
Set Battery Type
AGM1
Set Battery Type
AGM2
Set Battery Type
Custom
Default = 150
03B VAC Dropout
VAC 190
Set Battery Type
CC/CV
Set CV Chg Done
HOLD CV/CHG VDC
Set CV Charge
Volts = 29.0
Set Max Charge
AMPS = 100
Set CV Chg Done
Time = 0.1-25.5Hrs
Set CV Chg Done
HOLD CV/CHG VDC
Options: Time, Hold,
CV, Chg, Amps
Set Max CC/CV
Time = 0.1-25.5 Hrs, off
Set Recharge
Volts = 24 VDC
Range: 0.0 to 25.5 Hrs
Range: Float, Silent, Multi
03F Max Charge
CC/CV Controlled
03G Final Charge
CC/CV Controlled
Set Max Charge
Time =12.0 Hrs
Range: Time, Amps, SOC
Range: 0.1 to 25.5 Hrs Range: 0 to 250 ADC Range: 50% to 100%
03D Absorb Done
CC/CV Controlled
Set Absorb Done
Time = 1.0 Hrs
Set Absorb Done
Amps = 20 ADC
Set Absorb Done
SOC = 100%
Set Absorb Done
Time
Set Absorb Done
Amps
Set Absorb Done
SOC
03E Max Charge
Rate = 100%
Set Max Charge
Rate = 0-100%
03H EQ Reminder
CC/CV Controlled
Set EQ Reminder
Days = 1-255 days
Setup: 03 Charger
SETUP Button Menus continued
Continued on next page
03I should be OFF

PRO-Verter Programming for L1 System with 13 kW Generator
November 2022 |Solar Stik® Inc.6 |
Set Start Gen
Volts = 18.0-31.8
Set Start Volts
Delay=0 sec-127 min
Set Stop Gen
Volts = 28.4
Set Stop Volts
Delay = 15 sec
continued
SETUP
04A Gen Run VDC
Press Select
Status
04 AGS Setup
Set Start Gen
Volts = 24.6
Set Start Volts
Delay = 15 sec
Set Stop Gen
Volts = 18.0-32.0, Float
Set Stop Volts
Delay=0 sec-127 min
04B Gen Run Time
OFF
Default=OFF-- should be set to OFF
04C Gen Run Amps
OFF Default=OFF -- should be set to OFF
04D Gen Run SOC
OFF Default=OFF -- should be set to OFF
AGS Function Notes
• After 15 seconds at or below 24.6, the PRO-Verter sends the
start signal to the Generator.
• After 15 seconds at or above 28.4 VDC, the PRO-Verter turns off
the Generator.
• If the Generator does not start and the battery voltage gets
down to 24.0 V (LBCO), the AC Out (Inverter) turns off. This is the
LBCO voltage in the menu tree.
SETUP Button Menus continued
Setup: 04 AGS Setup
Continued on next page

|7November 2022 |Solar Stik® Inc.
PRO-Verter Programming for L1 System with 13 kW Generator
Set Gen Run Temp
Start = OFF
Set Gen Run Temp
Time =0.5
continued
SETUP
04E Gen Run Temp
Ext Input
Status
04 AGS Setup
Set Gen Run Temp
Start = Ext Input
Set Gen Run Temp
Time =0.5-25.5 Hrs
Default=OFF
Set Gen Run Temp
Start = 65F-95F
Set Max Gen Run
Time = 12.0 Hrs
04F Max Gen Run
Time = 12.0 Hrs
Set Max Gen Run
Time = 0.1-25.5 Hrs Default=12.0 Hrs; Range 0.1-25.5 Hrs
04G Quiet Time
OFF Default=OFF
04I Gen Warm-up
Time = 2 Min
Gen Warm-up
Time = 2 Min
Gen Warm-up
Time =0-127 Sec/Min
Default 60 Seconds
OFF=0 Seconds
Range: 0-127 seconds; 0-127minutes
04J Gen Cool Down
Time = 4 min
Gen Cool Down
Time = 4 min
Gen Cool Down
Time =0-127 Sec/Min
Default 60 Seconds
OFF=0 Seconds
Range: 0-127 seconds; 0-127minutes
SETUP Button Menus continued
Setup: 04 AGS Setup
Continued on next page

PRO-Verter Programming for L1 System with 13 kW Generator
November 2022 |Solar Stik® Inc.8 |
04K Gen 100% SOC
Start Days = Off
Default Off
Range: Off, 1-255
continued
SETUP
05 BMK Setup
05A Charge Eff
Auto
05B AmpHour Size
450 AH
05A Charge Eff
Range: Auto, 50-99%
05B AmpHour Size
Range: 200-2500
Default=Auto
Note: The AmpHour Size value should
be set according to the total capacity
of the battery bank. For example, one
24VDC Li Expander Pak 2400 is 100
Ah. The minimum setting allowed is
200 Ah. Note: The state of charge
reported by the 24VDC PRO-Verter
5000-220 will be accurate only if the
total battery bank size is at least 200
Ah.
SETUP Button Menus continued
Setup: 04 AGS Setup, 05 BMK Setup

|9November 2022 |Solar Stik® Inc.
PRO-Verter Programming for L1 System with 13 kW Generator
TECH
01 Temperatures
Press Select
02 Revisions
Press Select
05 SETUP PIN
SETUP Unlocked
04 Fault History
Press Select
06 Ext Control
Press Select
03 Inv Model
MS4124PE
Inv BTS ###F
Inv Tfmer ###F
Inv FETs ###F
AGS Sensor ###F
ACLD Temp ###F
PT BTS ###F
PT FETs ###F
PT Inductor ###F
02 Revisions
Inverter: 1.1
Set SETUP
Pin = 2022
Set SETUP
Unlock SETUP
Set SETUP
Lock SETUP
Set SETUP
Change PIN
04A Inv Faults
Press Select
06 Ext Control
No Ext Control
[Fault]*
H1 D- 0 HH:MM
06 Ext Control
###
01 Temperatures
Inv BTS ###F
Read-only Displays
Remote: 4.0
AGS: #.#
BMK: #.#
Router: #.#
ACLD: #.#
PT: #.#
Read-only Displays
Read-only Displays
[Status]
VDC ADC
BTS: ###F
Tfmer: ###F
FETs: ###F
* Specic fault listed; if no fault, “No Fault
History” displays. H1= the most recent fault;
H2-H9 are the faults in the earliest/past record
H9 being the oldest.
04B AGS Faults
Press Select
04D Clear Faults
Press Select 04D Clear Faults
in #.# seconds
04D Clear Faults
HISTORY CLEARED
Press and hold
Select for 5 seconds
If “Yes”, only a 3-digit number displays.
07 Show ALL
Menus = NO
07 Set Show all
Menus = Yes or No
or
TECH Button Menus
Default = NO.
If no faults have occurred, “No Fault History” will appear. Further fault information can be found
in section 04, the METER button menus.
