Solaris SLX-AAL-PCO Installation instructions

Warranty:
Ultravation® Solaris features Ultravation’s lifetime warranty, with the exception of the
ultraviolet lamp(s), which are warranted for a period of two years aer date of consumer
purchase.
is warranty does not include damage to the unit from accident, misuse or improper
installation.
If this product should become defective, Ultravation will elect to repair or replace the
product free of charge. Ultravation will return repaired or replaced warranted products
pre-paid to the customer, provided that the product was delivered pre-paid.
Ultravation shall have no responsibilities for charges incurred by the customer for
installation or removal of warranted items. Liability is limited only to the replacement or
repair of this product.
is warranty gives you specic legal rights, and you may also have other rights, which
vary from state to state. All returns must be accompanied by a return authorization
number, which may be obtained by contacting Ultravation, Inc.
Ultravation,Inc.
P.O. Box 165, 212 Ideal Way, Poultney, Vermont 05764
Phone: 1-866-GO-UV-AIR (468-8247) • Fax: [phone]
www.ultravation.com • [e-mail]
Copyright © 2018 Ultravation Inc.
REV12-2020
Replacement Lamp Part Numbers:
12” Spectrum Lamp for use in the PCO reactor chamber.........................SLX-RL-PCO10
Maintenance:
Typical maintenance of the Solaris is recommended replacement of the UVC Lamp ev-
ery 18,000 hours approximately 2 years, for optimum results change lamps every year.
UV lamps undergo a photochemical process during operation. is slowly reduces the
amount of UV light generated to disinfect against airborne pathogens.
Important:
When installing new lamps, ensure that the lamp glass is free from any ngerprints or
debris, as this may alter the path of the UV energy. Use rubbing alcohol and a dry cloth
to remove any surface contaminants.
Replacement Lamp Log Sheet:
Included with the product is a replacement lamp log sheet. It is provided as a label so it
can be attached near the installation to ensure lamp replacements are being tracked.
Installation and
Owners Manual
Model # SLX-AAL-PCO
Whole House Air purier with adjustable advanced
oxidation combined with 4x high output Plasma
generation.
Ultravation®
+
-
+
+
-
+
-
-
Made In
USA
PhotoCatalayst component for HVAC
for use with Solaris IAQ Module
(SLX-PowerPro-3-120)

• Solaris photo catalyst module.
• Four self tapping screws
• 24VAC Power cord (attached)
• UVC warning label
• Replacement lamp log sheet
• Warranty card
• Ductboard plate / sealing tape
• Product gasket
Package Contents:
Safety Precautions:
It is recommended that this unit be installed and maintained by a trained technician.
WARNING: UV Hazard. Always protect eyes from ultraviolet light. NEVER look at UV lamps in
operation. Unplug or disconnect power before re-lamping or servicing.
WARNING: Severe eye damage or temporary blindness may occur.
WARNING: DO NOT operate outside of air handler. Mount product in preferred
location rst.
WARNING: No openings should be allowed which would give direct line-of-sight to the UV light.
Note: In the event of accidental breakage or replacement of the ultraviolet lamp, please ensure that
the lamp is disposed of in accordance with local and state environmental laws regarding uores-
cent lamps containing mercury.
Notice: All wiring inside of the air handler in direct line of site of the UV lamp must be shielded
with aluminum foil tape or equivalent non-combustible material. When installing this unit, select
a mounting location that prevents ultraviolet light exposure to synthetic or other plastic com-
ponents with unknown resistance to ultraviolet light. Ultraviolet light may cause color shi or
structural degradation of plastic internal components.
Mechanical installation
1. Determine a location for the Solaris system. Mount the unit on the exit or supply side of the
HVAC system and before the ductwork branches o.
2. Separate the module cover from the mounting plate.
3. Note the orientation of the power module as it connects in only one direction.
4. Mark a 4” round opening (or use the end of the PCO chamber to mark the area) on the air duct
and cut the hole needed for the insertion of the advanced photocatalytic chamber.
5. (optional) attach supplied gasket over PCO module and attach to mounting plate. (Seals against
air duct.)
6. Insert the mounting plate / PCO module into opening and attach to duct with two supplied self
-tapping screws in the lower le and upper right
(only).
7. Adjust purication level. (See next page);
8. plug the lamp connector on to the lamp (note: the pattern of the lamp pins is a rectangle not a
square)
9. Place the module cover on the unit aligning holes in tabs with holes in mounting plate (upper
le /lower right).
10.. Secure the power module to the mounting plate with the remaining two self-tapping screws.
Adjusting the Purication level
e Solaris is a universal air purier with a patented design that provides adjustability to
the advanced photocatalytic process for a variety of treated space sizes. When setting up
your equipment, adjust the purication level (under electronics cover) to the appropriate
position based on the square footage Fine adjustments may be required depending upon
household living characteristics.
Lamp Replacement Procedure:
e UV lamp is shipped installed in the equipment and should
be replaced during an annual service. To replace the UV lamp
follow the steps below:
1. Unplug power cord and remove power module. (See Fig. 1)
2. Note the position of the Photon Clarier and pull adjustment
bar to its full-out position. (See Fig. 2)
3. Remove lamp screws and pull lamp out of PCO module.
(See Fig. 3)
4. Install new lamp and fasten with lamp screws.
5. Set the Photon Clarier to its noted setting.
6. Place the power module on the unit and fasten.
7. Plug in power cord.
Fig. 1
Fig. 2
Fig. 3
Installation
is product must be connected to a Solaris IAQ Module to operate.
1. Disconnect power supply before beginning installation to prevent electrical shock or
equipment damage.
2. plug the two leads from the photocatalytic module to the proper ports
3.. Check installation and reconnect power supply for proper operation.
