Bioclimatic ActiveOx Series Technical Document

OUR MISSION
To design and build quality engineered air cleaning systems
to provide indoor comfort, protect occupants, and ensure the
reliability of critical systems and processes.
Bioclimatic.com
003-OCT-2021
IMPORTANT
Save this Document
for Future Reference &
Warranty Information
ActiveOx Series
Installation, Operation
and Maintenance Guide

Installation, Operation & Maintenance Guide ActiveOx Series 2
1-800-394-3458 003-OCT-2021 Bioclimatic.com
! I M P O RTANT !
READ THIS BEFORE STARTING INSTALLATION.
DO NOT THROW AWAY THIS GUIDE.
How to Contact Us: If you need help, please contact a
Bioclimatic Air Systems Representative for technical assistance.
For installation you MUST:
■ Always disconnect power to the unit before handling any of the
components.
■ DO NOT connect to the power before the installation is complete and
personnel are aware of the imminent operation.
■ Carefully read this instruction booklet before beginning the installation.
■ Follow each installation or repair step exactly as shown and explained in
this guide.
■ Observe all local, state, national and international electrical codes.
■ Pay close attention to all warnings and caution notices given in this guide.
!CAUTION!
Do not touch while in operation shut off electricity before servicing!
This equipment should be inspected frequently and collected dirt removed from it regularly to prevent excessive
accumulation that may result in flashover or risk of fire.
!MISE EN GARDE!
Ne touchez pas pendant le fonctionnement couper l’électricité avant l’entretien
Cet équipement doit être inspecté fréquemment et la saleté collectée doit être retirée régulièrement pour éviter toute
accumulation excessive pouvant entraîner un contournement ou un risque d’incendie.

Installation, Operation & Maintenance Guide ActiveOx Series 3
1-800-394-3458 003-OCT-2021 Bioclimatic.com
Table of Contents
01 INTRODUCTION 4
1.1 Disclaimer 4
1.2 Receiving 4
1.3 Storage 4
1.4 Warranty 5
02 PHYSICAL DESCRIPTION & THEORY OF OPERATION 6
2.1 Principle of Operation 6
2.1.1 ActiveOx Generator Bi-Polar Ionization Unit 6
2.1.2 System Regulation 6
2.1.3 Building Management System Control (BMSC) 6
03 INSTALLATION 7
3.1 Initial Setup 7
3.2 Installation 7
3.3 Wiring 7
04 OPERATION 8
05 MAINTENANCE 8
06 TROUBLESHOOTING GUIDE 8
07 SPECIFICATIONS 9
7.1 Electrical 9
7.2 Mechanical 9
08 APPENDICES 10
09 PRODUCT NUMBERS 11

Installation, Operation & Maintenance Guide ActiveOx Series 4
1-800-394-3458 003-OCT-2021 Bioclimatic.com
01 INTRODUCTION
1.1 Disclaimer
These instructions are submitted with the implicit understanding that:
1. This manual is to guide the user of Bioclimatic Air Systems (B.A.S.) equipment in the proper installation, operation, and
maintenance procedures to insure maximum equipment life with efficient operation.
2. The customer has assigned competent maintenance and operating personnel to the system described herein and will assume
operational and maintenance responsibility upon start-up of the system.
3. The customer will read and thoroughly examine the foregoing instructions and will notify the seller of any points not fully
understood, points of conflict or error.
4. The customer, in lieu of any notification to the contrary, has read and fully understands the operation of the system and
is aware of the hazards of corrosion, abrasion and fire or explosion and shall take the necessary steps in the operation of
equipment to control such hazards to the maximum extent possible.
5. Start-up assistance or field engineering service provided by B.A.S. shall in no way relieve the customer of responsibility for the
proper operation of the system.
1.2 Receiving
Products leaving the B.A.S. factory are inspected and in satisfactory operating condition. All equipment should be thoroughly
inspected when received. Although all units are properly packaged, rough handling in transit can cause breakage. Any shortage
or damage should be reported at once to the transportation company. Note the damage on the bill of lading before signing
for the shipment. No equipment may be returned to Bioclimatic without written authorization. Returned equipment sent
without authorization will be refused and returned to sender.
All products are shipped F.O.B. (Ex Works, FCA) Bioclimatic warehouse. Responsibility for all equipment passes to the buyer at the
time equipment is loaded onto the carrier’s truck.
1.3 Storage
If the generator unit(s) are not installed upon delivery, it should be stored in a cool, dry, weather protected location. Do not stack
any other equipment on top of the unit.
Continue on Next page
IMPORTANT: Any modifications to the unit by unauthorized personnel will void factory warranty.
The unit must be installed in accordance with the manufacturer’s instructions to preserve warranty.

Installation, Operation & Maintenance Guide ActiveOx Series 5
1-800-394-3458 003-OCT-2021 Bioclimatic.com
1.4 Warranty
The seller warrants the equipment against defective workmanship and material for fifteen (15) months from date of factory
shipment or one (1) year from commissioning, whichever occurs first. In the fulfillment of its warranty, the sole obligation of seller
shall be to repair or replace, at its option, F.O.B. its factory, any part or parts which are returned F.O.B. its factory, shipping charges
prepaid, and which after inspection by seller are found to be defective. Buyer shall notify seller of defect in writing, promptly upon
discovery and within the warranty period. This warranty does not cover defects caused by corrosion or normal deterioration; it
does not extend to consequential damage, loss or delay associated with a warranty defect; and it does not cover any cost of labor,
travel, or other expense associated with the repair or replacement of defective parts. Seller assumes no liability for product loss
or other claims whatsoever arising out of the use or application of the equipment in any operations, whether the machine is used
alone or in conjoint use with other equipment or processes. Notwithstanding the foregoing, seller’s warranty obligations with
respect to any items not manufactured by seller shall not exceed the obligations undertaken by the manufacturer thereof under
express warranty to the seller. This express warranty is in lieu of all other warranties of fitness of the machine for any particular
purpose.
There are no other representations, warranty of condition in any respects either expressed or implied, statutory, or otherwise in
contract or tort, other than what is stated above.
The seller shall not be held liable in any way for consequential damages, however caused.
This warranty will not apply if the seller’s equipment has been damaged due to improper installation, alteration, abuse or misuse,
accident, fire, flood, or unavoidable circumstance. Further, this warranty will not apply if repairs, replacements, or alterations are
made by others without the seller’s prior written authorization.
In the event the state in which the equipment is installed does not permit the limitation or exclusion of implied warranties or
conditions under given circumstances, the provisions of this written warranty are in addition to and not a modification of the
statutory warranties and other rights and remedies provided by such laws.
Any modification to original equipment by any company or person other than the manufacturer will serve to cancel and void all of
the seller’s liability under the manufacturer’s warranty. Enclosures containing electronic components are normally sealed by the
manufacturer to prevent unauthorized tampering or adjustments. Only authorized service provides may break seals to complete
calibration or to trouble shoot the unit. Unauthorized tampering or breaking seals will release the seller from any future liability
under the warranty.
Disclaimer: The air purification technologies provided by Clean Air Group are intended to improve indoor air quality. They are
not intended as a replacement for reasonable precautions aimed at preventing the transmission of contaminants, airborne or
otherwise. All persons having access to the serviced premises should comply with applicable public health laws and guidelines
issued by federal, state and local governments and health authorities such as the Centers for Disease Control and Prevention
(CDC). Clean Air Group does not maintain that its products will protect people from all modes of transmission of bacteria, viruses
or other contaminants, and excludes liability for loss or damage arising from any such claims or the consequences arising out of
the application, use or misuse of its products.

Installation, Operation & Maintenance Guide ActiveOx Series 6
1-800-394-3458 003-OCT-2021 Bioclimatic.com
02 PHYSICAL DESCRIPTION & THEORY OF OPERATION
2.1 Principle of Operation
The ActiveOx Series ionization generator rail is designed specifically for plenum mounting. Generator rails are normally installed in
the supply air side of an air handling unit following the final filter. Alternatively, they can be installed in the return plenum.
2.1.1 ActiveOx Generator Series Bi-Polar Ionization Unit
The ActiveOx Series generator rail is a needlepoint Bi-Polar ionization device. The generator produces synchronized
bipolar ionization of an air stream whose flow is perpendicular to the axis of the needle pair. Depending upon
the volume of air, its velocity, chemical and biological content, ionization is factory pre-set to CFM airflow rating by
means of local control to affect density sufficient to produce the desired volumetric air purification. Externally, the
generator rail includes ionization modules, indicator light fuse, toggle switch, junction box power umbilical, wiring,
and mounting chassis.
2.1.2 System Regulation
Power input to ionization generators is not adjustable.
2.1.3 Building Management System Control (BMSC)
The ActiveOx Series generator rail has the option for a control box for building management system (BMS) or
building automation system (BAS) interface.
The BMS (BAS) dry contact may be wired in series with control boxes.

Installation, Operation & Maintenance Guide ActiveOx Series 7
1-800-394-3458 003-OCT-2021 Bioclimatic.com
03 INSTALL ATION
3.1 Initial Setup
Generator rails are normally installed in the supply
air side of an air handling unit following an air filter.
Alternatively, they can be installed in the return
plenum. A minimum MERV 8 rated prefilter is
required. Higher efficiency is a plus.
Minimum clearances between filter and generator
rails and heating or cooling surfaces shall be four
inches (101 mm). Where space permits, increase
clearances on the downstream side of the
generators to 12 inches (305 mm).
Rail assemblies require a minimum of three inches in the direction of airflow (See Appendices for drawing).
Alternatively, generator rails may be installed in the air handling unit supply plenum subject to ambient temperature limitations.
The maximum ambient temperature for the generators is 130º F (54º C).
Follow local and national electric codes.
CAUTION: Do not attempt to connect the generator ActiveOx unit(s) across multi-phase 3 or 4
wire circuits or across any electrical service in which pole to pole voltage exceeds 240 Volts. RMS.
3.2 Installation
Install the rail assembly in accordance with the following guidelines.
3.2.1 See Appendices for a typical installation.
3.2.2 Ionizers must be accessible for future service.
3.2.3 The rail must be installed such that the air blows
across the face of the ionizer modules perpendicular
to the needle electrodes and to an imaginary line that
bisects both needles as indicated by the arrows below.
3.3 Wiring
Connect wiring to the ActiveOx generator rail(s) following the specific wiring diagram for the application.
See Appendices for typical diagram.

Installation, Operation & Maintenance Guide ActiveOx Series 8
1-800-394-3458 003-OCT-2021 Bioclimatic.com
04 OPERATION
To start the generator rail(s), it is necessary to provide the appropriate supply voltage. The blue LEDs on the individual ActiveOx
generator modules will illuminate when energized. The BMS (BAS) DB-9 connector use is optional. To turn off the system – turn
the power switch to the “Off” position.
05 MAINTENANCE
Frequent and extensive maintenance is typically not required. However, for best performance B.A.S. recommends semi-annual
inspections to be sure the modules are free of debris. As a best practice, the modules can be cleaned using a compressed gas
duster (as used to clean electronic equipment) or a cotton swab or small stiff brush (similar to an artist brush). Units must be de-
energized for cleaning and maintenance. Caution should be taken not to damage or bend the needles.
Possible Cause: Possible Solution:
Facility circuit breaker is tripped or turned off. Check the circuit breaker and reset it if necessary.
There is a faulty wiring connection between the circuit
breaker and the ActiveOx generator.
Ensure all wiring connections between the circuit breaker
and ActiveOx generator are secure and correct. See
Appendices for custom wiring diagram.
Check the fuse. Replace with an identical T 630mA Glass 5mm x 20mm
(FST) fuse.
WARNING: DO NOT ATTEMPT TO REPLACE ANYTHING WHILE POWER TO THE SYSTEM IS ON.
DISCONNECT ALL POWER BEFORE SERVICING ANY UNIT.
06 TROUBLESHOOTING GUIDE
Always refer to the custom wiring diagram for the specific job being serviced.
6.1 The ActiveOx Generators Will Not Energize

Installation, Operation & Maintenance Guide ActiveOx Series 9
1-800-394-3458 003-OCT-2021 Bioclimatic.com
07 SPECIFICATIONS
7.1 Electrical
Power Requirement: 10 VDC +/- 10%
Power Consumption: 0.5 Watts
Max Operating Temperature: + 70° C
Humidity Range: 0 - 93% non-condensing
7.2 Mechanical
See Appendices at the end of this document.
Environment: Indoor only

Installation, Operation & Maintenance Guide ActiveOx Series 10
1-800-394-3458 003-OCT-2021 Bioclimatic.com
08 APPENDICES

Installation, Operation & Maintenance Guide ActiveOx Series 11
1-800-394-3458 003-OCT-2021 Bioclimatic.com
09 PRODUCT NUMBERS*
ActiveOx Ionizers
*If your specific model is not listed please contact the factory at:
1-800-394-3458 for operating instructions, safety information and
replacement parts or service.
