SolarShine SR981 User manual

SR971,SR972 Solar station operation manual
-------------------------------------------------------------------------------------------------------------------------------------
0

SR971,SR972 Solar station operation manual
-------------------------------------------------------------------------------------------------------------------------------------
1
Contents
1. Safety information---------------------------------------------------------------------------------------4
1.1 About this manual-------------------------------------------------------------------------------------4
1.2 Liability waiver------------------------------------------------------------------------------------------4
1.3 Important remark---------------------------------------------------------------------------------------4
1.4 Description of symbols-------------------------------------------------------------------------------5
2. Overview of solar station------------------------------------------------------------------------------5
2.21 Technical date of solar station SR981 & SR982 -------------------------------------------8
3. Mounting of solar station-----------------------------------------------------------------------------10
4. Attention Items for solar station installation ---------------------------------------------------10
5. Wire connection of solar controller---------------------------------------------------------------12
5.1 Open the connection box--------------------------------------------------------------------------12
5.2 Change fuses----------------------------------------------------------------------------------------13
5.3 Terminal connection--------------------------------------------------------------------------------13
6. Control operation description-----------------------------------------------------------------------15
6.1 Operation button-------------------------------------------------------------------------------------15
6.2 Signal description------------------------------------------------------------------------------------16
6.3 Time / week setup-----------------------------------------------------------------------------------17
6.4 Menu structure---------------------------------------------------------------------------------------18
6.5 Menu description------------------------------------------------------------------------------------19
6.6 System description----------------------------------------------------------------------------------21
6.6.1 System（1 collector array –1 tank –1 pump –auxiliary heating）
----------------------------------------------------------------------------------------------------------------21
7. Functional parameter setup-------------------------------------------------------------------------22
7.1 Access to main menu-------------------------------------------------------------------------------22
7.2 Access to submenu----------------------------------------------------------------------------------22
7.3 Main menu - THET Timing heating-------------------------------------------------------------23
7.4 Main menu - tCYC Temperature and time in three time section for DHW hot
water---------------------------------------------------------------------------------------------------------26
7.5 Main menu - DT Temperature difference function-------------------------------------------30
7.6 Main menu TEMP Temperature----------------------------------------------------------------31
7.6.1 Submenu - EMOF Collector safety switch-off temperature-----------------------------32
7.6.2 Submenu - CMX Maximum limited collector temperature( collector cooling

SR971,SR972 Solar station operation manual
-------------------------------------------------------------------------------------------------------------------------------------
2
function)---------------------------------------------------------------------------------------------------33
7.6.3 Submenu - CMN Low temperature protection of collector---------------------------34
7.6.4 Submenu - CFR Frost protection of collector-------------------------------------------35
7.6.5 Submenu - REC Tank recooling temperature-------------------------------------------36
7.6.6 Submenu –SMX1 Maximum temperature of tank------------------------------------36
7.6.7 Submenu - C-F Celsius and Fahrenheit temperature transferring---------------37
7.7 Main menu - FUN Auxiliary function----------------------------------------------------------37
7.7.1 Submenu - DVWG Anti-Legionella function----------------------------------------------38
7.7.2 Submenu - CIRC Activate and deactivate DHW hot water circulation pump -----38
7.7.3 Submenu - nMIN Solar circuit pump speed adjusting（RPM speed controlling）
-------------------------------------------------------------------------------------------------------------39
7.7.3.1 Submenu - DTS Standard temperature difference（for circuit pump’s speed
adjusting）-----------------------------------------------------------------------------------------------40
7.7.4 Submenu - OHQM Thermal energy measuring------------------------------------------40
7.7.5 Submenu - FMAX Flow rate------------------------------------------------------------------42
7.7.6 Submenu - MEDT Type of heat transfer liquid-------------------------------------------42
7.7.7 Submenu - MED% Concentration of heat transfer liquid------------------------------42
7.7.8 Submenu - INTV Interval function--------------------------------------------------------43
7.7.8.1 Submenu - ISTP Interval function stop time-------------------------------------------44
7.7.8.2 Submenu - IRUN Interval function operation time-------------------------------------44
7.7.9 Submenu –AHO/AHF Tank thermostat function----------------------------------------44
7.7.10 Submenu - COOL Tank cooling function-------------------------------------------------45
7.8 Mainmenu - HND manual function---------------------------------------------------------------47
7.9 Mainmenu - PASS password setup--------------------------------------------------------------48
7.10 Mainmenu - RSET, Recovery to factory set-------------------------------------------------49
7.11 On/Off button----------------------------------------------------------------------------------------49
7.12 Holiday function-------------------------------------------------------------------------------------50
7.13 Manual heating--------------------------------------------------------------------------------------50
7.14 Temperature query function----------------------------------------------------------------------51
8.Protection function-------------------------------------------------------------------------------------52
8.1 Memory protection-----------------------------------------------------------------------------------52
8.2 Screen protection------------------------------------------------------------------------------------52
9. Trouble shooting---------------------------------------------------------------------------------------52

SR971,SR972 Solar station operation manual
-------------------------------------------------------------------------------------------------------------------------------------
3
9.1 Trouble protection-----------------------------------------------------------------------------------52
9.2 Trouble checking------------------------------------------------------------------------------------53
10 Quality Guarantee------------------------------------------------------------------------------------55
11. Technical data----------------------------------------------------------------------------------------56
12. Delivery scope---------------------------------------------------------------------------------------57
13. Devices matchable to this controller-----------------------------------------------------------57

SR971,SR972 Solar station operation manual
-------------------------------------------------------------------------------------------------------------------------------------
4
1.Safety information
1.1 About this manual
This manual describes the installation, function and operation of a solar station, which
integrates a solar controller. When installing the remaining components e.g. the solar
collectors, pump assemblies and the storage unit, be sure to observe the appropriate
installation instructions provided by each manufacturer.
Installation, electrical connection, commissioning and maintenance of the device may only
be performed by trained professional personnel. The professional personnel must be familiar
with this manual and follow the instructions contained herein.
1.2 Liability waiver
The manufacturer cannot monitor the compliance with these instructions or the
circumstances and methods used for installation, operation, utilization and maintenance of
this controller. Improper installation can cause damages to material and persons. This is the
reason why we do not take over responsibility and liability for losses, damages or cost that
might arise due to improper installation, operation or wrong utilization and maintenance or
that occur in some connection with the aforementioned. Moreover we do not take over
liability for patent infringements or infringements –occurring in connection with the use of
this controller- on third parties rights. The manufacturer preserves the right to put changes to
product, technical date or installation and operation instructions without prior notice. As soon
as it becomes evident that safe operation is no longer possible (e.g visible damage). Please
immediate take the device out of operation. Note: ensure that the device cannot be
accidentally placed into operation.
1.3 Important remark
We have carefully checked the texts and pictures of this manual and provided the best of our
knowledge and ideas, however inevitable errors maybe exist. Please note that we can not
guarantee that this manual is given in the integrity of image and text, they are just some
examples, and they apply only to our own system. Incorrect, incomplete and erroneous
information and the resulting damage we do not take responsibility.

SR971,SR972 Solar station operation manual
-------------------------------------------------------------------------------------------------------------------------------------
5
1.4 Description of symbols
Safety symbol: Safety instructions in the text are marked with a warning triangle.
They indicate measures which can lead to injury of persons or safety risks.
Operation steps: small triangle “►”is used to indicate operation step.
Notes: Contains important information on operation or function.
2. Overview of solar station
SR971 single pipeline system

SR971,SR972 Solar station operation manual
-------------------------------------------------------------------------------------------------------------------------------------
6
SR972 double pipeline system
SR971: Solar station with one pipe,
SR972: solar station with double pipes ,
This picture is according to SR972
2.1 Connection from collector ,male thread G1/2, (not exist on SR971)
2.2 Upper mounting hole
2.3 Connection to collector, male thread G1/2
2.4 Safety valve, 6bar
2.5 Solar circulation pressure gauge, measure range 0-10bar
2.6 Discharge/filling valve connection, male thread G1/2 (integrated together)
2.7 Flow temperature sensor, NTC10K,B=3950
2.8 Gravity valve ( flow direction)
2.9 Digital water flow meter
2.10 Solar circulation pump
2.11 Connection to expansion tank, male thread G1/2
2.2
2.17
2.3
2.4
2.5
2.6
2.7
2.8
2.9
2.10
2.11
2.12
2.13
2.16
2.18
2.1
2.15
2.20
2.19
2.14

SR971,SR972 Solar station operation manual
-------------------------------------------------------------------------------------------------------------------------------------
7
2.12 Connection box of controller
2.13 Bottom mounting hole
2.14 Connection from tank, male thread G1/2
2.15 Connection to tank, male thread G1/2 ( not exist on SR971)
2.16 Air saperator including manual release valve (not exist on SR971)
2.17 Return pipe temperature sensor, NTC10K, B=3950(not exist on SR971)
2.18 Front insulation cover
2.19 Operation panel of controller
2.20 Front protection cover of solar station.

SR971,SR972 Solar station operation manual
-------------------------------------------------------------------------------------------------------------------------------------
8
2.21 Technical date of solar station SR971 & SR972
Parts description of solar
station
Parameter
Remark
Solar station
Height
420mm
Width
280mm
Thickness
140mm
Distance between flow/return
160mm
Max. permitted pressure
10 bar
Max. permitted temperature
130℃
Pipe connections
4*G1/2 for SR972
Or 2*G1/2 for SR971
male thread
Safety devices
Safety valve pressure
6bar
Manometer
0～10bar
Connector for expansion tank
G1/2,male thread
Circulation pump
Type of pump
Wilo RS15/6
Max. flow rate
2.5(t/h)
Max. pump head
5.5m
Max. operation pressure
10bar
Medium temperature
-10～110℃
Power supply
220V, 50-60HZ
Shut-off and display unit
Ball valve
G1/2

SR971,SR972 Solar station operation manual
-------------------------------------------------------------------------------------------------------------------------------------
9
Gravity brake
Output
0～16bar
Version
Max. permitted temperature
-20～120℃
Flowmeter
Display/setting range
0.1～20L/min
Air seperator ( no in SR971)
Connections for
flushing/filling unit
For hose fitting
G1/2
Thermal insulation
Material for back and front
casing
EPS/EPP
2 kinds of material can be
chose
Material for front cover
St14
Integrated solar controller
See manual of controller
Return pipe temperature
sensor
NTC10K, B=3950
Flow pipe temperature
sensor
NTC10K, B=3950

SR971,SR972 Solar station operation manual
-------------------------------------------------------------------------------------------------------------------------------------
10
3. Mounting of solar station
►Drill the upper fixing hole
►Fasten the screw
►Mark the bottom fixing hole
►Drill the bottom hole
►Fasten the bottom screw
4. Attention Items for solar station installation
A

SR971,SR972 Solar station operation manual
-------------------------------------------------------------------------------------------------------------------------------------
11
Note: In order to avoid jaming the degital flow meter and in result to displays no flow
on solar station, the filter ( A) must be installed on the return and flow pipeline of solar
station.
All devices connected to the controller must conform to the technical specifications of
the controller • Assembly, Installation and maintenance work may only be performed by
properly qualified and authorized personnel with a generally recongnized qualification.
The solar station must be installed indoors, prior to installation, remove sealing caps
from solar station.
The Maximum distance between solar station and water tank is 300mm,keep top edges
of solar station and top edge of storage tank.
Pre-setting, installing and adjusting the expension tank as per the installation and
operation instructions for “expansion tank”, the corrugated connection pipe for the
expansion tank does not need thermal insulation.
Safety valve: Risk of scadling from hot steam with discharge from the safety valve due
to heating and excess pressure in the hydraulic pipes. Drain off discharge from the
safety valve using a copper pipe correctly and in an eco-friendly way, according to valid
technical regulations and load codes, do not allow solar fluid to leak into the
environment.
Be careful of scald from hot fluid. Maxiumu temperature of collectors during
filling/leak check or installation/maintenance work should be below 70oC, allow
collectors to cool down if necessary.
Please ensure hydraulic connections are pressure-tight, connetions pipe should be
insulated, Unused connections must be sealed tight with a suitable end plug.
Air-seperator: if the system is pressue-tight ( no leakage), connect the power supply to
the solar controller, using the manual mode of controller to circuit system for 15 minutes,
then switch-off power supply, solar fluid is heated gradually, air dissolveed in fluid is
released out, through air –seperator to release air. If necessary ,repeats this process
until no more aire is vented out. If the system pressure drops due to over air release,
then it is necessary to refilling fliud to the required pressure.
After filling the system, please check safety valve accoring to its manual.
All safety regulations for working on the power supply are valid, All installtion and
maintenace work should be performed when power is switched-off,

SR971,SR972 Solar station operation manual
-------------------------------------------------------------------------------------------------------------------------------------
12
5. Wire connection of solar controller
5.1 Open the connection box
►Loosen the fixing screw (B) which is on the back of connection box
►Pull out the connection box downwards parallelly. ( C)
►Loosen the protection screw ( D), open the cover of terminal upwards
►Using proper tools ( like knife) to take out the plastic ( E) piece, wires can pentrate
connection termial through preprepared holes.
B
C
D
E

SR971,SR972 Solar station operation manual
-------------------------------------------------------------------------------------------------------------------------------------
13
Note: Please use delivered clamps to fix wires correctly. ( F)
5.2 Change fuses
►Use screw driver(see as picture) , turn to left to spring fuse, fuse parameter: AC250V/6.3A
5.3 Terminal connection
Layput of terminals
F

SR971,SR972 Solar station operation manual
-------------------------------------------------------------------------------------------------------------------------------------
14
Power connection
Input is for power connection, is for connection with ground .
Input ports
Input T1：PT1000 temperature sensor use for collector.
Input T2 ~T5: NTC10K, B=3950 temperature sensor, for measuring temperature of tank and
pipeline
Advice regarding the installation of temperature sensors:
Only original factory equipped Pt1000 temperature sensors are approved for use with the
collector, it is equipped with 1.5meter silicon cable and suitable for all weather conditions, the
cable are temperature resistant up to 280oC, not necessary to distinguish the positive and
negative polarity of the sensor connection.
Only original factory equipped NTC10K,B=3950 temperature sensors are approved for use
with tank and pipe, it is equipped with 1.5meter PVC cable, and the cable are temperature
resistant up to 105oC, not necessary to distinguish the positive and negative polarity of the
sensor connection.
All sensor cables carry low voltage, and to avoid inductive effects, must not be laid close to
230 volt or 400 volt cables (minimum separation of 100mm)
If external inductive effects are existed, e.g. from heavy current cables, overhead train cables,
transformer substations, radio and television devices, amateur radio stations, microwave
devices etc, then the cables to the sensors must be adequately shielded.
Sensor cables may be extended to a maximum length of ca. 100 meter, when cable’s length
is up to 50m, and then 0.75mm2 cable should be used. When cable’s length is up to 100m,
and then 1.5mm2 cable should be used.

SR971,SR972 Solar station operation manual
-------------------------------------------------------------------------------------------------------------------------------------
15
Output ports
Output R2:electromagnetic relay, max. switching current 3.5A,
R2 ports wire connection:for tank thermostat function
Output R3：electromagnetic relay, max. switching current 3.5A,
R3 ports wire connection:for tank cooling function.
Output R4：electromagnetic relay, max. switching current 3.5A,
R4 ports wire connection:for hot water circuit pump function.
Output H1：electromagnetic relay , max. switching current 10A,
H1 connection ports: for eletrical heater
Note: Solar pump (installed on solar station) is already connected with controller,
eletronmagnetic valve and sensor connections relay on the system you selected. Shielded
cable should be used.
eBUS interface：Temperature value display anywhere（optional）
By using SR806 seperable display screen can display temperature and the operating status
of selected hydraulic system anywhere, though eBUS to connecte controlling part and
display screen.
Port 1 connected with red wire ( +12V)
Port 2 connected with white wire ( COM)
Port 3 connected with black wire ( GND)
6. Control operation description
6.1 Operation button
Set button exit/confirm upwards downwards
ON/OFF button clock manual heating holiday

SR971,SR972 Solar station operation manual
-------------------------------------------------------------------------------------------------------------------------------------
16
Note:
Connect the sensors, pumps or switching valves to the controller before you connect the
power supply!
After power is switched on, you can set time, password, select system and relevant
parameters.
6.2 Signal description
Signal on displays shows current status. Their means explain in following table.
Signal
Display
Flash display
Electrical heater is in active
Collector safety temperature function
is in active
Tank urgency stop funtion is in active
Collector cooling function is in
active
Collector low temperature
protection is
in active
Collector frost protection function is
in active
Tank recooling function is in active
Tank maximum temperature
protection function is in active
Tank thermostate function is in
active
in active
Tank high temperature cooling
function
in active
Manual function is in active
Holiday function is in active

SR971,SR972 Solar station operation manual
-------------------------------------------------------------------------------------------------------------------------------------
17
6.3 Time / week setup
►Press ，display shows time, “00” blinks on hour area
►Press button to adjust hour of clock.
►Repress , “00” of minute area blinks
►Press 按，to adjust minute of clock
►Repress ，”MO” of week blinks
►Press ，to adjust weekday
►Press “ESC ”to exit setup menu, or wait for 20 seconds to exit ,set parametersare saved
automatically.
Code
Weekday
MO
Monday
TU
Thuesday
WE
Wednsday
TH
Thursday
FR
Friday
SA
Saturday
SU
Sunday

SR971,SR972 Solar station operation manual
-------------------------------------------------------------------------------------------------------------------------------------
18
6.4 Menu structure
Submenu:
Through submenu you can setup more detailed, please make sure to understand the content
in submenu.

SR971,SR972 Solar station operation manual
-------------------------------------------------------------------------------------------------------------------------------------
19
6.5 Menu description
Sr.Nr.
Code
Main menu
Code
submenu
Description
1
tHET
Timing heating in three time periods
2
tCYC
Temperature or time seting in three time periods for
hot water circulation pump
3
DT
Temperature difference adjusting
4
TEMP
Temperature main menu
5
EMOF
Collector safety swith-off tmperature
6
EMON
Collector safety resume temperature
7
CMX
Maximum temperature of collector ( collector cooling
function)
8
CMN
Low temperature protection of collector
9
CFR
Frost protection temperature of collector
10
REC
Tank recooling function
11
SMX1
Maximum temperature of tank 1
12
C-F
C-F temperature display transferring
13
FUN
Auxiliary functions
14
DVWG
Anti legionnaires'bacteria function
15
CIRC
Activate and deactivate DHW hot water circulation
pump
16
nMIN
Speed controlling of circulation pump
（RPM pump controlling）
17
DTS
Standard temperature difference
(for circulation pump speed adjusting)
18
OHQM
Thermal energy measuring
19
FMAX
Flow rate setting
20
MEDT Type of heat transfer liquid
21
MED% Concentration of heat transfer liquid
22
INTV
Interval function
23
ISTP shutdown time setup of interval functin
24
IRUN operation time setup of interval function
