Kenmore 625.347001 User manual

1
Sears,Roebuck andCo., HoffmanEstates,IL 60179 U.S.A.
SAVE THISMANUAL
Reverse Osmosis
Drinking WaterSystem
uWarranty
uHowToInstall
uHowIt Works
uCareOf
uRepairParts
OWNER’S
MANUAL
MODELNO.
625.347001
Caution:
Read and Follow
All SafetyRulesand
Operating Instructions
BeforeFirstUse of
ThisProduct.
If you have questionswhen
installing,operating or
maintaining your reverse
osmosis system,call this
toll--free number...
1--800--426--9345
PRINTEDINU.S.A.

2
-- WARRANTY--
Sears,Roebuck andCo., D/817 WA,HoffmanEstates,IL 60179
Foroneyearfromthedateofpurchase,whentheReverseOsmosisDrinkingWaterSystemisinstalled
andmaintainedinaccordancewithourinstructions,Searswill repair,free ofcharge,defectsinmaterial
andworkmanship,exceptfiltercartridgesandtheR.O.membrane.
TO OBTAINWARRANTYSERVICE,SIMPLYCONTACT THENEARESTSEARS SERVICECENTER
THROUGHOUT THEUNITEDSTATES.Thiswarrantyappliesonlywhilethisproductisin useinthe
UnitedStates.
Thiswarrantygivesyouspecificlegalrights,andyoumayhaveotherrightswhichvaryfromstatetostate.
FULL WARRANTYONREVERSEOSMOSISDRINKINGWATERSYSTEM
(exceptfiltercartridgesandR.O.membrane)
SEARSINSTALLATIONPOLICY
All installationlaborarrangedbySears shall beper-
formedinaneat,workmanlikemannerinaccor-
dancewithgenerallyacceptedtradepractices.Fur-
ther,all installations shall complywithalllocallaws,
codes,regulations,andordinances.Customershall
also beprotected,duringinstallation,byinsurance
relatingtoPropertyDamage,Workman’sCom-
pensationand PublicLiability.
SEARSINSTALLATIONWARRANTY
Inadditiontoanywarrantyextendedtoyouonthe
Searsmerchandiseinvolved,whichwarrantybe-
comeseffectivethedatethemerchandiseisinstalled,
shouldtheworkmanshipofanySears arranged
installationprovefaultywithinoneyear,Searswill,
upon noticefromyou,causesuchfaultsto becor-
rectedatnoadditionalcost toyou.
-- SAFETYGUIDES--
BReadall steps,guides andrulescarefullybefore
installingand using your reverseosmosis system.
Followall stepsexactlytocorrectlyinstall.Reading
thismanualwill alsohelpyoutogetall thebenefits
fromthereverseosmosis system.
BDonotattempttousethisproducttomakesafe
drinkingwaterfromnon-potablewatersources.Do
notusethesystemonmicrobiologicallyunsafewa-
ter,orwaterofunknown quality.
BCheckwithyourlocalpublicworksdepartment
forplumbingand sanitationcodes.Youmustfol-
low theirguidesasyouinstall thesystem.Follow
yourlocalcodesiftheydifferwithguidesinthis
manual.
BThereverseosmosissystemworksonwaterpres-
suresof40 psi(minimum) to125 psi(maximum).If
yourhousewaterpressureisoverthemaximum,
installapressurereducingvalveinthewatersupply
pipetothereverseosmosis system.
BDonotinstall thereverseosmosis systemout-
side,orinextremehotorcoldtemperatures.Temper-
atureof thewatersupplytothereverseosmosis sys-
tem mustbebetween40_Fand100_F.Donotinstall
onhotwater.
BReadtheotherlimits(pH,hardness,etc.)inthe
specifications andbesureyourwatersupplycon-
forms.Alsosee “WaterSupply”onpage3.
BThereverseosmosismembranecontains a pre-
servativeforstorageandshipment.Besuretopurge
asinstructedon page9beforeusingproductwater.

3
-- TABLEOFCONTENTS--
WhereToInstall theROSystem........ 4
Tools andMaterialsNeeded........... 4
InstallationSteps.................... 5-9
ColdWaterSupplySaddleValve..... 5
DrainAdapter..................... 6
Faucet............................ 6-7
RO Assembly...................... 7
StorageTank,TubingConnections.... 8
InstallationSteps-continued
Sanitizing,PressureTest,Purging.... 9
How theROSystemWorks........... 10
CareofROSystem................... 11-14
Dimensions,Specifications............ 15
RepairParts......................... 16-17
RemoteInstallationLocations......... 18
-- WHATYOUR REVERSEOSMOSIS SYSTEMWILL DO--
YourReverseOsmosis(RO)DrinkingWaterSystem
is a watertreatmentunit.It useshouseholdwater
pressuretoreverseanaturalphysicalprocess called
osmosis.Water,underpressure,isforcedthrougha
semi-permeablemembranewhereminerals andim-
puritiesarefilteredout.Cleandrinkingwatergoesto
thefaucetorstorage,whileminerals andimpurities
aresenttothedrainwithROwastewater.Theminer-
als andimpurities aremeasuredinwateras totaldis-
solvedsolids(TDS).
Thesystemincludesreplaceablepreand postfilter
sediment-carboncartridges.Theprefilter removes
sand,silt,dirt,rustparticles,othersediments,and
chlorinefromthewatersupplybeforeitcanenterthe
ROmembrane.Thepostfilter removes anytastes
and/orodorsthatmayremaininthewater,after
passingthroughtheROmembrane,andjustbefore
goingtotheROfaucet.Toprevent waterwaste,an
automaticshutoffvalvecloseswhentheROfaucetis
closedandthestoragetankisfull.
Yourreverseosmosissystemgivesyouacontinuous
supplyofsparklingclear,deliciouswaterfordrink-
ing,cookingandotheruses.Foodswill lookand
tastebettertoo.HavinghighqualityROproductwa-
teratyourfingertipseliminatestheneedto buy
bottledwater.Thestoragetankholdsover2gallons
ofROproduct waterforyourneeds.
-- BEFOREYOUBEGINTOINSTALL THEROSYSTEM--
CheckYourWaterSupply:Thecoldwatersupplyto
theROsystem mustbewithincertainqualitylimits.
Seethespecificationtableonpage15.Ifsupplywater
isnot withinlimits,theROsystemcan notmake
product wateras itshouldandreducedROmem-
branelifewill result.
TrainedsalespeopleatSearscanarrangeforafree
wateranalysis.Theanalysiswilltell youifotherwa-
tersupplytreatmentisneededbeforegoingtothe
ROsystem.
CAUTION:Chlorineinthewaterwilldestroythe
ROmembrane.Mostcities add chlorinetothewa-
tersupplytokill bacteria.Theprefilter removes
chlorineuptothelimitsshowninthespecifications
beforeitenterstheROmembrane.It isimportant
toreplacetheprefiltercartridgeatleastevery6
months.See theROcareguideonpage14.
Check PartsIncluded:Unpackthecartonandre-
movetheROsystem.Inadditiontotheassembled
ROandthestoragetank,thesystemincludesthe
partsillustratedbelow,a separatelengthof tubing,
andthismanual.
DRAIN
ADAPTER
ROPRODUCT
WATERFAUCET
WATERSUPPLYSADDLEVALVE
TUBING
ADAPTERS
FIG. 1
HANGER
WASHERS&
SCREWS

4
-- WHERETOINSTALL THEROSYSTEM--
TheROassemblyandstoragetankisdesignedfor
installationunderthesink,usuallyinthekitchenor
bathroom.TheROassemblymountsonawall sur-
face,orcanlayonthecabinetfloornexttothestorage
tank.Hangerwashersandwoodscrewsareincluded
forcabinet wall mounting.TheROproduct water
faucetinstallsonthesink,oronthecountertopnext
tothesink(pages 6 and7).
Note:Tubinglengths allow fortheremovalof the
assemblyfromthehangerwashersforservicing.If
tubinglengths areshortenedforneaterappear-
ance,itmaybenecessarytokeeptheassemblyon
thehangerwashersforservice.
YoucanalsolocatetheROassemblyandstoragetank
inanyremotelocationfromthefaucet,observing
safety guidesonpage2.Youdoneedanearbywater
sourceand drainpoint (see page18).
WaterSupply:ToprovidesupplywatertotheRO
systeminlet,a saddlevalveisincludedtoinstall
(wherecodes permit)onacoldwaterpipe,page5.Pro-
videotherpipefittingsfortubingconnection,astypi-
callyshownonpage5,wheresaddlevalves arenot
allowed.
Drain Point:Asuitabledrainpointisneededfor re-
ject waterfromtheROmembrane.Afloordrain,
laundrytub,standpipe,sump,etc., ispreferred,as
shownintheremotelocationsdrawing,page18.A
sinkp-trapdrainadaptorisincludedtoinstallwhere
codespermit,as anoptionaldrainpoint (page6).
coldwater
supply
ROproduct
waterfaucet
COLDHOT
Storage
Tank
ROAssembly
sinkdrain
p---trap
drainadapter
FIG. 2
-- TOOLSANDMATERIALSNEEDED--
"adjustablewrench,standard pliers,andlarger
adjustablejawpliersorpipewrenchtofitsinkdrain
"slottedand Phillipsheadscrewdrivers
"plumbersputty
"pipejointcompound(threadseal)orTeflontape,
approvedforuseonpotablewatersupplies
"handorbatterypowered drill with1/8”bit (if
neededforthecoldwatersupply valve,page5)
"electricdrillandbits,ifholeisneededfortheRO
faucet,page6 and7
-- 6STEPS TOINSTALL --
STEP1:- InstallColdWaterSupplySaddleValve,or
otherfittings-page5
STEP 2:- Install DrainAdapter-page6
STEP 3:- Install Faucet - pages 6 and7
STEP 4:- Install RO Assembly-page7
STEP5:- InstallStorageTank,MakeRemainingTub-
ingConnections-page8
STEP 6:-Sanitizing,PressureTesting,Purging-
page9

5
-- STEP1: INSTALL COLDWATERSUPPLYSADDLEVALVE--
Checkandcomplywithlocalplumbingcodesas youplan,theninstall acoldfeed(supply)waterfitting.The
fittingmustprovidealeak-tightconnectiontotheRO1/4”tubing(see FIG. 8,page8).Atypicalconnection,
usingtheincludedsaddlevalveis showninFIG.3-Abelow.Anoptionalconnection,usingstandardplumb-
ingfittings(notincluded),is showninB.
Note:CodesinthestateofMassachusettsrequireinstal-
lationbyalicensed plumber,and donotpermit theuse
ofthe saddlevalve.Forinstallation,useplumbing
code248-CMRof theCommonwealthofMassa-
chusetts.
A.SADDLE VALVE
Note:Thisvalvehas a cuttingpinandwill piercea
holeincoppertubingorplasticpipe.Ifinstallingon
ironpipe,youhavetodrilla1/8”holeforthepierc-
ingpin.Readthefollowingdangernoteandbe
suretoturnoffwatertothepipeandtodrainwater
fromitbeforedrilling.
DANGER(ifdrillingmetalpipe):Toprotectyour-
selffromseriousinjuryorfatalshock,useabattery
powered hand drill onlytomakethehole.Donot
use anelectricdrill.
1.Closethehousemainwatershutoffvalveandopen
faucetstodrainwaterfromthesinkcoldwaterpipe.
2.Observingabovenoteandcaution,drill the1/8”
diameterholeinironpipe.
3.Lookingat figure3A,turnthevalveintoclampX
andtighten(maybealreadyassembled).Turnthe
valvehandleall thewayout.
4.PlacethesealontheinsideofclampXas shown.
Besurethecuttingpindoesnotstickoutbeyondthe
seal.
5.PlaceclampXandZaroundthepipeandsecurein
placewith2 screws.If you predrilleda 1/8”hole,
alignthecuttingpinwithit.Tightenbothscrews
evenly,butdonotovertighten.ClampZwill either
havethreadedscrewholes,or2nuts areincluded.
6.Carefullyturnthehandleinwardtopierceahole
inthecopperorplasticpipe.
B.OPTIONAL PIPEFITTINGS(compressiontype
shown)
Note:Besuretoturnoff thewatersupplyand open
alowfaucet todrainthepipe.
Complyingwithplumbingcodes,install afittingon
thekitchencoldwaterpipetoadapt1/4”ODtubing.
Atypicalconnectionis showninfigure3B.If
threadedfittings areused,besuretousepipejoint
compoundorTeflontapeonoutsidethreads.
handle
clampX
clamp Z
nut(2)--- notreq’d
withall typesof
clampZseal
pre---drill
1/8” hole
forironpipe
coldwater
shutoff
valve
Checklocal
codesfor
approval
nut
insert
ferrule
A.WATERSUPPLYCONNECTION
(using includedsaddle valve)
B.WATERSUPPLY
TYPICALCONNECTION
(using compression fitting)
ferrule
insert
1/4” compression
fitting
cold
water
pipe
1/4”tubingto
ROinlet(see step
2,onpage 8)
usetoconnect
tubing,step2,
onpage 8
FIG. 3
-- partsnotincluded--
See noteoncodes
inthe state of
Massachusetts,
aboveleft.

6
-- STEP2: INSTALL DRAINADAPTER--
JNote:Runningthedraintubingdirectlytoafloor
drain,sump,standpipe,laundrytub,etc., as shown
onpage18,ispreferred.However,if thatisnotpos-
sibleorpractical,theincluded drainadapterinstalls
inthesinkdrainpipe,alwaysaboveoraheadof the
p-trap(FIG. 4).Besuretocomplywithyourlocal
plumbingcodes.Otherdrainpipefittings,inaddi-
tiontotheadapter,maybeneeded.
JThedrainadapterfits 1-1/2”sinkdrainpipe.
JTheadapterinstallsdirectlyontothesinktailpiece
as typicallyshowninFIG. 4 and5.
JLocatesodraintubingfromthefaucet(installedin
step1,page8)makes a straightruntotheadapter,
withoutdips,loops,lowspotsorkinks.
Note:Consultaplumberifyouarenot familiar
withplumbingprocedures.
1.Useaferruleandnuttoassemblethedraintubing
connectortothedrainadapter(FIG.5).Turnthecon-
nectortoabout45_ fromthe12:00position,asshown
(to10:00 or2:00 positionas needed).Tightenthenut
securely.
2.Carefullydisassemblethesinkdrainpipeand
cleanthetailpiecetoassurealeak-tight fit.
3.Install thedrainadapterontothesinktailpiece,
usingaferruleandnut.Snugthenut,butdonot
tighten.
Note:If needed,tomakefit,youcancut toshorten
theunthreadedendof theadapter.Donotcut too
shortsotheadapterwillmakealeak-tightsealwith
theconnectingfitting.
4.Assemblethep-traptothedrainadapter,andoth-
erdrainpipefittingsasrequired(checkcodes) to
completethedrainrun.
5.Tightenallconnections,butdonotovertightenand
breakplasticfittings.
FIG. 4
AB
drain
adapter
45_
sinktailpiece
drainadapter
ferrule
ferrule
nut
nut
draintubing
connector
FIG. 5
2:0010:00
45_
black
collet
cut, if
needed
-- STEP3: INSTALL FAUCET--
A.PREPAREMOUNTING HOLE
1.Select1of thefollowingplacesforthefaucet.Be
sureit will fit flatagainst thesurface,andthereis
spaceunderneathfortubing(see FIG. 8,page8).
' Useanexistingsinktopholefora sprayhoseor
otherfaucet.A1”to1-1/4”diameterholeisneed-
ed.
'Drill anewholeinthecountertopnext tothe
sink.
'Drill anewholeinthesinktop.
CAUTION:Toavoid damagingasink beyond re-
pair,consultaqualified plumberorinstallerfor
guidestodrill holesinporcelainorstainless steel.
2.If drillingisneeded,makethe1”to1-1/4”diame-
terhole.
3.Placeplumbersputtyaroundthedrilledhole(FIG.
6) toprevent waterleakagearoundthebaseof the
faucet.

7
-- STEP3: INSTALL FAUCET(cont.)--
B.ASSEMBLE FAUCET
1.Ifnotalreadyassembled,installtherubberwasher,
spacer,flat (orlock) washerandhexnutontothe
threadedfaucetstud.
2.ApplyTeflontapetothe endof thefaucetstud.
Turnthetubingadapterwithabluecolletontothe
stud andhandtighten,thenwrench1/4turnonly.
BE CAREFULNOT TOCROSS THREAD.
3.Wet theo-ringsealsonthefaucetspout.Then,re-
moveand discardtheshortpieceof tubingfromthe
faucetbodyandinsert thespoutinit’splace.
4.CONNECTTUBINGTOFAUCET ASFOLLOWS.
a.Taketheseparatelengthof3/8”blacktubing
and,puttingendthroughthelargerholeintherub-
berwasher,slideendontothelargerbarbfittingon
thebottomof thefaucet.
Note:Tosoftenendoftubing,holdunderhotwater.
b.Route1/4”redtubingfromROup throughthe
sinkholeandslideendontothesmallerbarbfitting
(heatendifneeded)onthefaucet.
c.Route3/8”bluetubingfromROup throughthe
sinkholeand pushendall thewayintothetubing
adapterfittingonthebottomof thefaucet.Pull on
thetubingto besureit’sheldfirmlyintheadapter
fitting.See pages 12 and13 fortubingconnection
instructions.
5.Lowerthefaucetintothesinkorcountertophole.
6.Ontheundersideof thesinkorcountertop,insert
thelargesteelwasherbetweenthemountinghole
andthespaceronthefaucetstud (see assembled
view).Then,turnthehexnutup tothespacerand
tighten.Tightenthehex nutsothefaucetcan not
move,butdonotovertightenand breakthefaucet.
-- STEP4: INSTALL RO
ASSEMBLY--
Hangtheassemblyontheincludedhangerwashers,
orlayonthecabinet floor,as desired.
1.RefertoFIG.7forwallmounting.Holdtheassem-
blyup tothewall surfaceandmarklocationsforthe
hangerwashers.Indicatormarksontopofthebrack-
etaretheneeded10-1/2”apart.
2.Installhangerwashersatleast15-1/2”upfromthe
cabinet floor,allowingroomtoremovesumpsfrom
filterheads.Woodscrews areprovided,orobtain
otherfastenersasneeded.
FIG. 7
ASSEMBLEDIN
MOUNTINGHOLE
faucet&spout
rubberwasher
spacer
flat(orlock)
washer
hexnut
tubingadapter
plumbersputty
holeinsinkor
countertop
steelwasher
tubing barb
fittings
removetub-
ing piece
insertspout
TUBINGFROM
ROSYSTEM
1/4” redtubing
fromROdrain
3/8” blue
tubing
3/8” black tubing
todrainpoint
steelwasher
spacer
hexnut
10-1/2”
FIG. 6
hanger
washer (2)
screw(2)
15-1/2”
min.
upfrom
floor
bluecollet
10-1/2” indicators

8
-- STEP5: INSTALL STORAGETANK,
MAKEREMAININGTUBINGCONNECTIONS--
1.CONNECTDRAIN TUBING, FAUCET TO
DRAINADAPTER:ReferringtoFIG.8,runtheloose
section(connectedtofaucetbarbfitting)ofblack
3/8”tubingfromthefaucettothedrainadapter,with
ablackcollet,installedonpage6.Cut thistubingas
neededtorouteinas straightofarun aspossible,
withoutloops,dips,lowspotsorkinks.Cut theend
of thetubingsquare.Then,pushall thewayintothe
fitting.Pull onthetubingto besureit’sheldfirmly
intheadapterfitting.See pages 12 and13 fortubing
connectioninstructions.
2.CONNECTTUBINGTOWATERSUPPLY:Usethe
tubinginsert,ferruleandnuttofastenthe1/4”green
tubingtothesaddlevalvefittinginstalledonpage5.
Tightenthenut withawrench.
3.MovethestoragetankintoplacenexttotheROas-
sembly.Youcanstandthetankupright,orlayiton
side.Applynomorethan2wrapsofTeflontapeto
thethreadsonthenippleatthetopofthetank.Hand
tighten,thenwrench1/4turnonly,theotherin-
cludedtubingadapterfittingwiththeyellowcollet
ontothetanknipple.BECAREFULNOT TOCROSS
THREAD.
4.Runthe3/8”yellowtubingtothefittinginstalled
instep3.Besurethe endof thetubingiscutsquare,
andinsertall thewayintothefitting.Again,pull on
thetubingto besureit’sheldfirmlyinthefitting.
watersupply
valve
drainadapter
sinkp---trap
ROproduct
waterfaucet
COLDHOT
3/8” black tubing, to
largerbarbonfaucet
TYPICALUNDERSINKINSTALLATION
OPEN
CLOSE
insert
ferrule
nut
FIG. 8
yellowcollet
tubingadaptor
Note:See noteonpage 4
regardingtubinglengths.
See note on
codesinthe state
ofMassachusetts,
page 5.

9
-- STEP6:SANITIZING,PRESSURETESTING&PURGING--
SANITIZING
Sanitizingisrecommended uponinstallationof the
ROsystem,andafterservicinginnerparts.It isim-
portantfortheservicepersontohaveclean hands
whilehandlinginnerpartsofthesystem.
CAUTION:BesuretoremovetheROmembrane
andbothfiltercartridges as follows,beforesanitiz-
ing.Chlorinewill destroy theRO membrane car-
tridge.
1.BesurethewatersupplytotheRO isturnedoff,
andtheROfaucet isopentorelievepressure.
2.ReferringtoFIG. 9,page11,press inwardwhile
turningtheROcaptotheleft(?) toremovefromthe
bracket/membranehousing.Remove(usepliers)
theROcartridgefromthehousing.Placethecar-
tridgeinacleanplasticbag.
3.Besuretheo-ringsealisintheROcap.Replacethe
ROcapand pushinwardwhileturningtotheright
(?) tolock.
4.Removethepostfiltersump,turningtotheleft.
Takethecartridgefromthesumpand placeinthe
plasticbag.Replacethesumpandtightensecurely.
5.Removetheprefiltersumpandcartridge.Also
placethiscartridgeinthecleanbag.
6.If neededtoclean,flushtheprefiltersumpwith
freshwater.Then,fillwithwatertoabout1”fromthe
top.Add 1.0ounceofchlorine(ordinary5.25%
householdbleach...Hilex,Clorox,etc.)andmixinthe
water.Donotadd chlorinefirst.Concentrated,it
will attackplastics.
7.Carefullyreplacethesumpontheprefilterhead
andtightensecurely.
8.SlowlyopenthewatersupplytotheRO.
9.OpentheROfaucet,lockingtheleverupward,
against thespout.
10.Allow watertocirculatethroughtheROsystem
untilyousmellthebleachodor.Thenclosethefaucet
andallow theROtostandidlefor20 minutes.
11.Afterthe20minutes,opentheROfaucetandrun
wateruntil thebleachodorisgone.
12.Turnoff thewatersupplytotheRO.
13.Be sureyourhandsare clean.Then,repeatsteps
1-5 and7,onlyreplace all cartridges.
Important:RefertoFIG. 9,page11,andtopage12
whenreplacingcartridges.Theprefilter(left side)
cartridgehas lightgraycoloring,andthepostfilter
(rightside)has bluecoloring.
PRESSURETESTING
1.Dotheprecedingsanitizingproceduresbefore
pressuretesting.
2.Openthewatersupplyshutoff valvetotheRO.
3.Openthemainwatersupply valveandseveral
housefaucetstopurgeairfromthesystem.Close
faucetswhenwater runs smooth.
4.Inabout2 hours,pressurewill start to buildinthe
ROsystem.Then,carefullycheckallfittingsandcon-
nectionsforwaterleaks.Correctleaksifanyare
found.
Note:Whenthesystemisfirstpressurized,water
may‘‘spurt’’fromthefaucetairgapholeuntil airis
expelledfromtheROsystem.
PURGING ROMEMBRANE
Importantpurginginstructions:TheROcartridge
contains a food gradepreservativethatyoushould
cleanfromitbeforeusingwaterfromthesystem.The
preservativewill giveproduct wateranunpleasant
tasteandodor.
1.Allow thestoragetanktofill forabout4hours.
Then,opentheROfaucetuntilthetankisemptyand
flowstops.
2.ClosetheROfaucetandallowthetanktofillagain
for4hours.Then,opentheROfaucetandempty
again.
Repeatsteps1and2topurgethestoragetank4times.Then,theROsystemisreadyto
makeproduct waterforuse.

10
-- HOWYOUR REVERSEOSMOSIS SYSTEMWORKS--
PREFILTER
Waterfromthecoldsupplypipe enterstheROas-
semblyprefilterfirst (FIG. 8 andschematicbelow).
Theprefilterhas a replaceablesedimentcartridge
withactivatedcarboninitscomposition.Thecar-
tridge(10micron)removessand,silt,dirt,othersedi-
ments,anduptotheppmofchlorineshowninthe
specificationsfromthefeedwater.Chlorinewillde-
stroy theROmembrane.Filtered,clean,chlorine-
free waterflowsfromtheprefilter,totheROmem-
branecartridge.
IMPORTANT:See prefiltermaintenance,page11.
REVERSE OSMOSIS(RO) CARTRIDGE
Thecartridgeinsideof theROhousing,is a tightly
wound,specialmembrane.Waterisforcedthrough
thecartridgeandthemembraneremovesthedis-
solvedsolids andorganicmatter.Highqualityprod-
uct water(about1ounceper minute)exitstheRO
housingandgoestothestoragetank,ortothepost-
filterandROfaucet.Reject water,withthedissolved
solids andorganicmatter,isroutedthroughtheflow
controlandtothedrain.
STORAGETANK
Thestoragetankholdsup to2.3gallonsofproduct
water.Adiaphragminsidethetank keepswater
pressurizedtoabout30 psi,whenthetankisfull,to
providefastflowfromtheROfaucet.Thetank,when
empty,ispressurizedto5-7psi.
POSTFILTER
Afterleavingthestoragetank,butbeforegoingtothe
ROfaucet,productwatergoesthroughthepostfilter.
Thepostfilteris anactivatedcarbontypefilter.Any
remainingtastes andodors areremovedfromthe
product water.Taste-free,odor-free,clean,high
qualitydrinkingwateris availableforuse.
FAUCET
Thesinkorcountertopfaucethas a handoperated,
spring-loadedclosedlevertoprevent thewasteof
drinkingwater.Youcanalsokeepthefaucetopenby
pushingupwardontheleverandlockingitagainst
thefaucetspout.
Tocomplywithplumbingcodes,anair-gapisbuilt
intothefaucetdrainwaterconnection.
SHUTOFF ASSEMBLY
Toconservewater,thedrinkingwatersystemhas an
automaticshutoffsystem.Whenthestoragetankhas
filledtocapacity,andthedrinkingwaterfaucetis
closed,pressureclosestheshutoff tostopflowinto
theRO.Pressureinthestoragetankis abouthalfof
thewatersupplypressure.Afterdrinkingwateris
used,and pressureinthesystemdrops,theshutoff
openstoallow waterflowagain.
CHECK VALVE
Acheck valve(FIG. 10)islocatedintheoutletendof
theROhousing,oppositeofthecap.Thecheckvalve
prevents a backwardflowofproduct waterfromthe
storagetank.AbackwardflowcouldrupturetheRO
membrane.
FLOWCONTROL
Waterflow throughtheROmembraneisregulated
bytheflowcontrol.Itmaintainsthedesiredflowrate
to obtainthehighestqualitydrinkingwater.The
flowcontrolislocatedintheendofthe1/4”reddrain
tubing,at theROhousingdrainport.Asmall cone-
shapedscreenfitsoverthe endof theflowcontrolto
help preventpluggingwithdrainwatersediments.
PREFILTER
PRODUCT
WATER
STORAGE
ROMEMBRANE
check
valve
drainflow
control
AUTOMATIC
SHUTOFF
WATER
INPOSTFILTER
PRODUCT
WATER
FAUCET
airgap
gravity
drain
REVERSEOSMOSIS
SCHEMATIC
RED
YELLOW
BLUE
GREEN
PRODUCTWATER

11
-- CAREOFYOUR REVERSEOSMOSIS SYSTEM--
Tokeepyour reverseosmosis systemoperatingand
makinghighqualitywater,youmustmakesuresup-
plywateris alwayswithinthelimits showninthe
specifications. Goodsupplywaterhelpstoassure
longerlifefromtheROmembranecartridge,prefilter
andpostfiltercartridges.However,eachofthesewill
wearoutintimeandneedreplacement.
Thisreverseosmosis systemcontainsareplaceable
treatmentcomponentcriticalforeffectiveremovalof
totaldissolvedsolids.Thewatershouldbetested
periodicallytoverifythesystemisperformingsatis-
factorily.
IftheROassemblyiswallmounted,youmaybeable
toreplacepartswiththeassemblyleft onthewall.If
not,simplylift theROassemblyfromthemounting
washers andlayonthecabinet floorwhenreplacing
theprefilterand post filtercartridges andROmem-
brane.
Note:Topreventspillage,placeacontainerunder
theROassembly,orput theROassemblyinacon-
tainertocatchthewater.
CAUTION:Beforedisconnectingparts,besureto
closethewatersupply valvetotheRO.
PREFILTERAND POSTFILTER
CARTRIDGES
You must replace theprefiltercartridgeoftentopro-
tect theRO membranefrombeing destroyedby chlorine,
and/orfrompluggingwithsedimentsinyourwater
supply.If thewatersupplycontainsbothchlorine
andsediments,replacetheprefiltercartridgeatleast
every6monthsofproduct wateruse.Replacemore
oftenthan6monthsifitbeginstoplugwithsedi-
ments.
Ifthewaterhassedimentsonly,withnochlorine,you
maynoticea slower makingofproduct wateras the
prefiltercollectsthesediments.Whenthisoccurs,re-
placetheprefiltercartridge.Alsoreplacethepostfilter
cartridge.
Toreplacethefiltercartridges(see FIG.9):
1.TurnoffthewatersupplyandopentheROfaucet
torelievepressure.
2.Remove(turntotheleft)bothsumpsfromthefilter
heads.Becareful...thesumps arefull of water.
3.Removeanddiscardtheinnercartridgesinaprop-
er manner.Flushtheinsidesof thesumpswithfresh
water.Donot losethelargeo-ringseals.
4.Insertnewcartridges,andwithlubricated*o-rings
inplace,turnonandtightenthesumps.
Note:Theprefiltercartridgehas lightgraynetting
andendcaps.Thepostfilterhas blue.Donotinter-
change.
*Note:Usealubricantapprovedforuseonapotable
watersupply.
ROCartridge
postfilter
cartridge
(blue)o--ring
seal
sump
prefilter
cartridge
(lt.gray)
Turnsumpsinthe
direction of the arrow
toremove.Turn
oppositewaytoinstall
and tighten.
o--ring sealROcap
mounting
washers(2)
FIG. 9
(ROcartridge
o--ring sealson
thisend)
ROMEMBRANECARTRIDGE
Thelifeof theROmembranecartridgedepends
mostlyonthepHof thesupplywatertotheROsys-
tem(seespecifications).Cartridgelifeis shorterwith
higherpH.For example,if supplywater pH isfrom6.8
to7.7,thecartridgemaylastforwellover1year.However,
cartridgelifemaybeas shortas6monthsif thepH isas
high as8.5to10.HigherpH weakensthecartridge
membraneandcausespin-holeleaks.
It’stimetoreplacetheROcartridgewhenthepro-
ductionrateand/orqualityofproduct waterdrops.
Productwatermaybegintotastedifferentorbad,in-
dicatingsolids andorganics arepassingthroughthe
ROmembrane.To besureitistheROcartridge,re-
placetheprefilterand postfiltercartridgesfirst.
ToreplacetheROcartridge(see FIG.9):
1.TurnoffthewatersupplyandopentheROfaucet
torelievepressure.
continued

12
-- CAREOFYOUR REVERSEOSMOSIS SYSTEM--
2.Press inwardwhileturningtheROcaptotheleft
(?)toremovefromthebracket/membranehousing.
3.Useapliers,orheavy wiremadeintoahook,to
pull theROcartridgefromthehousing.
Note:Sanitizingisrecommendedafterservicingin-
nerpartsof thesystem(see page9).
4.Install thenewcartridge,endwitho-ringsealsin-
ward.Workbackandforthtogetall thewayin(end
ofcartridgeabout1-1/4”infromendofhousing).
5.LubricatetheROcapo-ringsealifdry.Replacethe
o-ringintothecap.Press inwardonthecapwhile
turningtotheright(?)tolock.Thecapwillnotgoon
if theROcartridgeisnot fullyseatedinward.
6.Checktheflowcontrolandscreen(see below).
7.PurgetheRO membranecartridgefollowinginstruc-
tionsonpage9.
FLOWCONTROLAND SCREEN
Theflowcontrol isvitalforproperoperationof the
ROmembranecartridge.Thecontrolkeepswater
flowthroughthemembraneattheneededratetoob-
tainthebestqualityproduct water.
WheneverservicingtheROsystem,checktheflow
controlto besurethesmall holethroughitisclean
andunrestricted.Alsocheckandcleanorreplacethe
cone-shapedscreeninfrontof thecontrol.TheRO
membranecannotdischargeminerals andimpuri-
tiestothedrainiftheflowcontrolplugswithforeign
material.Ifthishappens,itonlytakes ashorttimefor
themembranetofoulandbecomeuseless.
Toclean/replaceflowcontroland screen(FIG.10):
1.At thedrainconnection,depress thecollet (FIG.
11) withafingerwhilecarefullypullingonthedrain
tubingtoremove.
2.Removetheflowcontrolfromthe endof thedrain
tubing.Besurethecenterholeisclean.
3.Checkthedraintubingto besureit’sclean.Then,
insertthecleanedornewflowcontrolintothetubing.
4.Withasmallscrewdriver,carefullyremovethecol-
letando-ringfromthedrainport.Usea small need-
le-nosepliersortweezerstoremovethescreenfrom
thedrainport.Thoroughlyclean,or replacewitha
newscreen.Install,pointedend down.
Note:Visuallycheckto besureitispositionedcor-
rectly.
5.Inspect theo-ringandcollet.Replaceif worn,cut
orotherwisedamaged.Carefullyreplaceintothe
drainport.
6.Besuretheflowcontrol isinthe endof thetubing,
thenpushall thewayintothefitting.
flow(control)insert
screen
1/4”tubing
check
valve
TO
DRAIN
FIG. 10
cap o-ring
spring
ball
drain port
o--ring seal
collet
TUBING CONNECTION
(all push-infittinglocations)
ThisROsystemincludespush-infittingsforquick
tubingconnectionatmostlocations.If workingwith
thefittings,dothefollowing.
Connection(FIG.11):
1.Usea sharpcutterorknifetocut the endoftubing
square.
2.Inspect the end(about1”)of thetubingto besure
therearenonicks,scratchesorother roughspots.If
needed,cut thetubingagain.
3.Pushtubingthroughthecolletandallthewayinto
fitting.Full engagementis 11/16”for1/4”tubing,
and3/4”for3/8”tubing.
continued

13
-- CAREOFYOUR REVERSEOSMOSIS SYSTEM--
TUBINGCONNECTION (continued)
If tubingisused,otherthansuppliedwiththesys-
tem,besureitisofhighquality,exactsizeandround-
ness witha smoothsurface.
ToDisconnectTubing:Pushthecolletinwardand
holdwithafingerwhilepullingthetubingout.
collet(depress to
removetubing)
tubing
FIG. 11
o--ring seal
collet
fitting
Pusho-ringsealinto
bottomofport, then
follow withcollet.
Replacing colletand
o-ring seal
cut tubing squarecollet
Tubing correctly cutand connected
11/16”(1/4”tubing)
3/4”(3/8”tubing)
engagement
end of tubing round and
smooth,withnocuts,
nicks orflatspots
ChangingColletand O-ring(FIG.11):
1.Witha small screwdriver,removethecolletando-
ringfromthefitting.
2.Besuretheportisclean,thenlubricateandinsert
theo-ringsealtothebottomof theport.
3.Pushthecolletinward until itlocksinplace.
CAUTION
DO NOTUSEVINEGAR,OROTHERACID
BASEDCLEANERSONTHISROSYSTEM.THEY
WILLDEGRADESOMEROSYSTEMPARTS.AL-
WAYSUSESOAPANDWATER.
Thisreverseosmosissystemcontainsareplaceable
treatmentcomponentcriticalforeffectiveremoval
of totaldissolvedsolids.Thewatershouldbe
testedperiodicallytoverifythesystemisperform-
ingsatisfactorily.
AUTOMATICSHUTOFF SERVICE
If theshutoff assemblyrequires service,besureto
reassemblepartsexactlyas showninFIG. 12,andto
reconnect tubingas shownonpages 10 and16.
diaphragm
diaphragm
plunger
screw(4)
SHUTOFF
ASSEMBLY
Elbowfittingturns
intoOUTport.
collet
MaleElbow,1/8”
NPTx1/4”Tubing
MaleConnector,
1/8”NPTx1/4”Tube
Tee Fitting,
1/4”NPTx3/8”
Tube
FIG. 12
tubing

14
-- CAREOFYOUR REVERSEOSMOSIS SYSTEM--
REVERSEOSMOSIS SYSTEMCAREGUIDE
MODELNO.625.347001
1.ATLEASTevery6months,replacetheprefilterand postfiltercartridges.Cleanor replacetheflowcontroland
screen.
2.ReplacetheROmembranecartridgewhenthepercentrejectionoftotaldissolvedsolids(TDS)isless thanshown
inthespecifications(see B,below).
Ifanyofthefollowingoccurbeforethe6months,replaceasdirected.
A.SlowMakingofProductWater:Replacetheprefiltercartridge.
If theproductionratedoesnotimprove,replacethepostfiltercar-
tridge andROmembranecartridge.
C.ChlorineTasteand/orOdor:Replacetheprefilter,postfilterand
ROmembranecartridges.
B.HighTotalDissolved Solids(TDS)inProductWater:Youcan
getafree TDStest throughsomeSearsretail storesorservice
departments.If thestoreorservicedepartmentdoesnothave a
TDSmeter,youcansendtreatedanduntreatedwatersamplesto
awateranalysislabfortesting.Itisimportant totestboththe
treatedanduntreatedwatertodeterminesystemperformance.If
theTDSisnotwithinthesystem’sperformanceguidelines,
replacetheprefilter,postfilterandROmembranecartridges.
OTHERTROUBLESHOOTING
PROBLEMCAUSECORRECTION
Chlorinetasteand/or
odorintheROproduct
water
Theppmofchlorineinyourwatersupply
exceedsmaximumlimits,andhasde-
stroyedtheROmembrane.
Ifthewatersupplycontainsmorethan2.0ppmofchlorine,addi-
tionalfilteringofthewatersupplytotheROisneeded.Correct
thisconditionbeforedoingmaintenanceontheROsystem.
Theprefilterisnolonger removingchlo-
rinefromthewatersupply.Replacetheprefilter,postfilterandROmembranecartridges,
flowcontrol,andscreen.
Othertasteand/orodorPostfilterexpended.Replacethepostfiltercartridge.If taste andodorpersists,re-
p
l
a
c
e
t
h
e
p
r
e
f
i
l
t
e
r
c
a
r
t
r
i
d
g
e
,
R
O
m
e
m
b
r
a
n
e
c
a
r
t
r
i
d
g
e
,
f
l
o
w
c
o
n
-
ROmembranecartridge expended.
p
l
a
c
e
t
h
e
p
r
e
f
i
l
t
e
r
c
a
r
t
r
i
d
g
e
,
R
O
m
e
m
b
r
a
n
e
c
a
r
t
r
i
d
g
e
,
f
l
o
w
c
o
n
-
trol,andscreen.
Contaminationinproductwaterstorage.Usesanitizing procedures.Replacethepostfiltercartridge.
System makesproduct
watertoo slowlyWatersupplytotheROsystemnotwithin specifications.Increasewaterpressure,preconditionthewater,etc., asneeded toconformbeforedoingmaintenanceontheROsystem.
PrefilterorROmembranecartridges
pluggedwithsediments.Replacetheprefiltercartridge.If ratedoesnotincrease,replace thepostfiltercartridge,ROmembranecartridge,flowcontrol,
andscreen.
System makeslower
amountofproductwater
than usual
Storagetankair-chargeless than5--- 7
psi.OpenROfaucetand draintankuntil flowslowstoadrip.Keep faucetopenandcheck tankpressure.If low,pressurizeto6psi.
Closefaucet torefill thetank.
Hightotaldissolvedsol-
ids(TDS)inproductwa-
ter
WatersupplytotheROsystemnotwithin
specifications.Increasewaterpressure,preconditionthewater,etc., asneeded toconformbeforedoingmaintenanceontheROsystem.
ROmembranecartridge expended.Replacetheprefilter,postfilterandROmembranecartridges,
flowcontrol,andscreen.
Waterleakingfromfau-
cetairgapholeDrainsideof faucetairgap(3/8” tubing) plugged,restricted,orincorrectlycon-
nectedtodrainpoint.
Inspectandeliminaterestrictionorplug.Refertoinstallation
instructionsforproperdrainconnection.
Continualwaterflowto
drainCheck valveorautomaticshutoff assem- blyplugged,restrictedorpartswornClean,repairor replace asneeded.
Note:Sanitizingisrecommendedafterservicinginnerpartsof thesystem(see page9).

15
-- DIMENSIONSandSPECIFICATIONS--
16”
16”
9”dia.
15”STORAGE
TANK
Metric
Supplywaterpressurelimits........................ 40 --- 125 psi280 --- 860 kPa
Supplywatertemperaturelimits..................... 40 --- 100 °F5--- 40°C
Maximumtotaldissolvedsolids(TDS)............... 2000 ppm
Maximumwaterhardness@6.9pH................. 10 gpg
Maximumiron,manganese,hydrogensulfide......... 0
Chlorineinwatersupply(max.ppm)................ 2.0
SupplywaterpH limits(pH)........................ 4--- 10
Product(quality)water,24 hours¬................. 6gal.22.7liters
Wastewaterpergallonofproductwater¬........... 5gal.18.9liters
PercentrejectionofTDS,minimum(newmembrane)¬90 --- 95
Storagetank capacity(max.)....................... 2.3gal.8.7liters
Automaticshutoff control........................... yes
¬feedwatersupplyat50 psi,77°F,and750 TDS--- Qualitywaterproduction,amountofwaste
waterandpercentrejectionallvarywithchangesinpressure,temperature andtotaldissolvedsolids.

-
DRAIN
ADAPTER
1
2
3
4
5
6
7
8
7
9
10
11
12
13
14
15
16
17
18
19
20
21
21
8
9
22
23
24
25
26
27
28
29
30
31
32
33
o-ring seals
11
SADDLE VALVE
See noteoncodesinthe state
ofMassachusetts,page 5
1/4”Tubing
Bracket/Membrane Housing
PUSH-- INFITTINGS
o--ring seal
collet
34
¬1/4”-3/8”
¬
17
¬
-
35
36
16
-- REPAIRPARTS--
KenmoreReverseOsmosisDrinkingWaterSystem,ModelNo.625.347001

17
-- REPAIRPARTS--
KenmoreReverseOsmosisDrinkingWaterSystem,ModelNo.625.347001
Key
No.Part NumberDescriptionofPart
1 7205350 Faucet
2 7207920 Adaptor,7/16”-24 x3/8” Tubing
3 7185788 Screw,#10-12 x5/8” (8req.)
4 42-34702 ROMembraneCartridge
5 7177175 O-ringSeal,1-7/8” x2-1/8”
6 7174965 ROCap
7 7207881 Elbow,3/8” NPTx3/8” Tube(2req.)
8 7156535 Head(2req.)
9 7170246 O-ringSeal,3-3/8” x3-5/8” (2req.)
10 42-34370 FilterCart., T&OPostfilter
11 7156569 Sump(2req.)
12 7171674 Connector,1/8” NPTx1/4” Tubing
13 7171682 Elbow,1/8” NPTx1/4” Tubing
14 7112442 ValveTop
15 7112434 ValveCenter
16 7014979 Plunger
17 7099296 Diaphragm(2req.)
18 7112426 ValveBottom
19 7030721 Screw,#10-14 x1-3/4” (4req.)
J7133838 Shutoff Assembly¡
20 7208502 Tee,1/4” NPTx3/8Tubing
21 7207899 Elbow,3/8” NPTx1/4” Tube(2req.)
22 42-34373 FilterCart., Sed.--- T&OPrefilter
Key
No.Part NumberDescriptionofPart
23 7205326 StorageTank
24 7207938 Adaptor,1/4” NPTx3/8” Tubing
25 7208366 Bracket/MembraneHousing
26 7133634 Check Ball
27 7110385 Spring
28 7133464 O-ringSeal,7/16” x5/8”
29 7202344 Check ValveCap
30 7095030 ConeScreen
31 7208413 Flow(Control)Insert
32 7011272 SaddleValve
33 7192230 DrainAdapter
34 7209566 Push-inFittingKit, 1/4” À®
7209574 Push-inFittingKit, 3/8” Á®
35 9006062 Screw(2req.)
36 9041700 HangerWasher (2req.)
J42-34334 SumpRemovalWrench®
J7161823 Tubing,1/4” x20’ -white©®
J7161784 Tubing,1/4” x100’ -white©®
J7157280 Tubing,3/8” x20’ -white©®
J7161750 Tubing,3/8” x100’ -white©®
J7208112 Owners’sManual
¡includeskeynumbers14 through19
©tubinglengthsfor remoteinstallations,page 18 (not
included)Directreplacementforcoloredlengthsof
tubing.
Jnotillustrated
ÀÁsee page16foruselocations--- Note:Thiso-ring
andcolletarefor replacementinthebracket/membrane
housingonly.Theydonotfit theotherpush-infittings,
keynos.2,7,12,13,21 and24.
®notincluded

18
-- REMOTELOCATIONFOR REVERSEOSMOSIS SYSTEM--
ROproduct
waterfaucet
COLD
WATER
SUPPLY1/4” greentubing
3/8” bluetubing
STANDPIPE
airgap
airgap
SUMP
airgap
LAUNDRY
TUBFLOOR DRAIN
OPTIONALDRAINPOINTSFOR REJECTWATER
REMOTEROINSTALLATION
(storagetanknotshown)
PossibleremotelocationsfortheROnearbythekitchenorbathroomsinkinclude;(1)abasementarea
underneaththesink,and(2)anadjacentroomorcloset.Longerlengthsoftubingmaybeneeded(seeparts
listonpage 17).
Youcanrun thedraintubing directlyto1ofseveralsuitableopendrainpoints,as shownbelow,bypassing
thefaucetairgapand p---trapdrain.Thistypeofdrainisthepreferredoverthep---trap drainadapter.Check
yourlocalcodes.Alwaysbesureto provideanairgapbetweenthe endofthehose andthedrainpoint.
airgap
red
red
yellow
storage
tank
Note:Tubing colorsas
supplied withROsystem.

19

partno.7208112 (4/99)
Sears,Roebuck andCo., HoffmanEstates,IL60179 U.S.A.
OWNER’S
MANUAL
MODELNO.
625.347001
The modelnumberof
your reverse osmosis
systemisfound on the
rating decal.Thisdecal is
on the top of the bracket.
When requesting service
orordering parts,always
provide the following in-
formation:
zProductType
zModel Number
zPartNumber
zPartDescription
Fortherepairor replacementparts you need
Call 7 am--7 pm,7 days aweek
1-- 800 -- 366 -- PART
(1-- 800 -- 366 -- 7278)
Forin--homemajorbrand repairservice
Call 24 hoursa day,7 days aweek
1-- 800 -- 4-- REPAIR
(1-- 800 -- 473 -- 7247)
Forthelocation ofa
SearsRepairService Centerinyourarea
Call 24 hoursa day,7 days aweek
1-- 800 -- 488 -- 1222
Forinformation on purchasing aSears
Maintenance Agreement,ortoinquire
aboutanexisting Agreement
Call 9 am--5 pm,Monday-- Saturday
1-- 800 -- 827 -- 6655
REPAIRSERVICES
REPAIRSERVICES
America’sRepairSpecialists
Reverse Osmosis
Drinking WaterSystem
