SolarVenti SControl User manual

In general:
Only 12 volt voltage on the system.
Power supply: 12 V 2Amp.
S1 (solar collector temperature sensor)
should be mounted in order for the
SControl to work.
Complete safety instrucons can be
found in the installaon guide, which
you should also read carefully.
This quick guide only deals with the
simple instrucons for mounng and
use of the SControl.
NOTE: Before touching the electronic
circuits inside the SControl, you must
briey touch, for example, a water tap
or grounding device, in order to avoid
damaging certain components. You may
have lile stac electricity in your body,
which should be discharged rst.
This describes very briey how to mount and adjust the
SControl for systems that must funcon for dehumidicaon
System 4 for unheated basement
System funcons:
1 or more exhaust fan (max 25 wa in all)
Forced venlaon at too high humidity (70% RH)
Dew point control to prevent condensaon
Timer funcon acve for interval venlaon (also at night)
Since all cellars are very dierent, there may be a need for
individual adjustment of the operang mode.
SControl - Quick guide Eng.
The SControl is xed with one
more screw at the boom.
Hang up on scerew
Screw
Loosen screw to
separate the SControl
Screw on wall
The SControl must be placed in
the basement itself in order to
register the moisture
here. If this is not possible,
it can be extended with an ad-
dional external combi-sensor.
Posion:
About 160 cm from the ground
and 2 meters or more away
from the solar air inlet valve.
At the oppossite end of the
garage in relaon to the gate
or outlet valve.
Status Dewpoint
Collector 37,5 0C
Fan 50%

RED WHITE
To S1
BROWN BLUE
9-led wire from the Solar-
Ven contain all these
colors
12 volt
in here
SControl operaon
Cable mounng
Return key OK key
conrms
Dial for opons
seng
Micro key
When pressed, within 7
seconds the fan speed
can be changed by
turning the dial.
Aer 1 hour, the speed
returns to the xed
seng.
Micro key 2
Here you can quickly adjust the type of opera-
on you want:
1) Auto
2) Turn o system
3) Moisture
4) Cooling of house
5) Timer
6) Control of temperature
Auto is the general basic seng - open to all
changes. The other opons only run the pro-
gram specied. For example, "Timer" runs only
clock control and nothing else unl you press
"Auto" again.
Colour on dial means:
constant light ashes
All is OK Manuel operaon
Sensor inter-
rupted/shortcut
Too lile Update/upstart
power runs
See photo
page 4
Red Green
Yellow
Extra thin wire for signal from K2
Black wire not in use.

Do this:
1: Connect the SControl with 12
volts from the power supply. If
you do not have electricity in
the room, use a 12 volt baery.
During the normal operaon of
the SControl, the status screen is
displayed.
If no buon is pressed for 2
minutes, the display light goes o.
2: To reacvate the background
light, press any key.
To switch between menu items,
turn the dial.
The screen shows:Explanaon:
Auto 12.21
Room 1 22,50C
Sengs
Apparatus info
3: When you see you can
press here on the OK key and get
into the submenu. Do this at the
sengs point. Each me you
have selected a value - press the
OK key, and the value is saved.
Here these opons are shown:
Language selecon, summer
me seng, clock, date, desired
mode of operaon (- choose 4),
Sengs 12.22
Language
Summer me
Clock
4: First select your preferred
language and conrm with the
OK key - and proceed through the
menu to set the clock etc. Under
system, select No. 4.
Do you have the me and curiosity to look
more into the opportunies that the SControl
oers, you will nd that there are many ways
to use a good solar air collector.
It is, for example, excellent in keeping houses
and cellars dry, fresh and free of dangerous
radon.
A SolarVen can do much more than just
create heat. For example, the fresh air is also
cleaned of pollen and dust parcles down to
5µM in size - and the lter stays clean with
the heat from the sun.
See much more at www.solarven.dk
- A genuine Danish product
Factory sengs that you can change:
Factory: Possibility:
Max allowed moisture in
the room: 70% RH 30 - 90%
Fan rotaon: High Low stand. high max
(20% 50% 80% 100%)
Start temperature in collector: 50C 10 - 400C
+ dierenal control before start. (It must be warmer in the collector than
inside the garage. )
When set in menu for garages, the fan will automacally start at a
humidity level above 70% regardless of the temperature in the
collector. If the humidity level does not begin to fall within a few
minutes, the fan will stop again.
-
See the full descripon in the installaon and user manual
System 4 in general (Moisture in basement)
a
The fans always run when it is warmer in the collector than in the room where
the SCon controller is placed. That means that it also adds heat.
The fan stops again when it is colder outside than inside.
a
The mer funcon i acve at night: The fan will run some minutes every hour
to remove extra moisture. Please read the Textbook from SolarVen to un-
derstand this special procedure.
Fan also starts when there is more than the allowable moisture (RH > 70%)
The fan stops again when the moisture level is brought down to the desired
level or if no improvement is achieved by driving within fx. 20 minutes. (Can
be set).
This can be expanded with several operang modes such as cooling.

RED WHITE
Til
BROWN BLUE
BLACK to V1
Cable from SolarVen
+-
If you do not have electricity in the room
you can connect a 12 V baery here -
which can be charged by a solar cell.
12 V Power supply
Red Green
Yellow
Extra thin wire for signal from K2
Black wire not in use.
9-led wire from the SolarVen
contain all these colors
To S1
SolarVen A/S
Fabriksvej 8
DK 8881 Thorsø, Denmark
www.solarven.dk [phone]
info@solarven.dk
