Solid State Logic ORIGIN User manual

www.solidstatelogic.com
SWITCHED
EXT TB OUT
ON
EXT
to +10dB
GAIN
+48V
48V
MIC
+
-
MONITOR
LINE
+
-
+
-
PRE
IN
L R
1 2 3 4 5 6 7 8 910 11 12 13 14 15 16
+dB
TRIM
+2 to +70dB
[-12 to +55dB]
IN
FLIP
+
-
+
-
PRE
IN
FLIP
PATH
PATH
FROM LF
PAN
MIX
PAN
MIX
L R
SOLO
SOLO
CUT
SOLO
POST SF PAN
L R L R
LEVEL
POST SF PAN
1 2 3 4
LEVEL
PRE SF
LEVEL
PRE SF
LEVEL
PRE SF
LEVEL
PRE SF
FOLLOW
PATH
PAN
FLIP
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
PRE FLIP
+
-
DIRECT OUT
PATH
+
-
RETURN L
± 20dB
dB
TRIM
+
-
RETURN R dB
L R L R
LEVEL
LEVEL
LEVEL MIX
AFL
1 2 3 4 5 6 7 8 910 11 12 13 14 15 16
1/2
3/4
5/6
7/8
9/10
11/12
13/14
15/16
CUT
FB 1
FB 2
L R L R
to 0dB
to 0dB
to 0dB
+
-
INPUT
PATH
+
-
+
MONO LMONO R
MUTE BALANCE
to +3dB
+3dB to
MIX
SOLO
+
-
+
-
TRIM
BUS 1 SEND OUT
BUS 2 SEND OUT
+
-
+
-
BUS 3 SEND OUT
BUS 4 SEND OUT
SUBGROUP
1L OUT
SUBGROUP
1R OUT
BUSES 1 - 16
L R
MIX AFL PFL
M
L R
MIX AFL
L R
MIX AFL
AUX 1 - 4
CUE A B
+
-
+
-
BUS 15 SEND OUT
BUS 16 SEND OUT
BUSES 1 - 16
LEVEL
L R
L R
AFL
AFL +
-
+
-
CUE AL OUT
CUE AR OUT
to +10dB
LEVEL
AFL +
-
+
-
CUE BL OUT
CUE BR OUT
LEVEL
AFL +
-
AUX 1 OUT
LEVEL
AFL +
-
AUX 2 OUT
LEVEL
AFL +
-
AUX 3 OUT
LEVEL
AFL +
-
AUX 4 OUT
CUE AL
CUE AR
CUE BL
CUE BR
OSC
SLATE
SLATE
L R L R
L R
STUDIO
F/B 1
L R
F/B 2
EXT 1L
EXT 1R
EXT 4L
EXT 4R
C/ROOM L
C/ROOM R
CUE AL
CUE AR
CUE BL
CUE BR
to +10dB
LEVEL
L R
L R
AFL
AFL +
-
+
-
F/BACK AL OUT
EXT 1L
EXT 1R
to +10dB
LEVEL
AFL +
-
+
-
to +10dB
LEVEL
AFL +
-
+
-
STUDIO L OUT
STUDIO R OUT
+
TALKBACK MIC
FRONT PANEL TRIM
(+40 to +65dB)
dB
+
-
TALKBACK
MIC
INPUT
LISTEN
MIC
INPUT
+
-
SEND
LISTEN TO
TALKBACK
LISTEN
OUT
LISTEN
(Feed To Monitor Section)
+
+
TALK
F/BACK AR OUT
F/BACK BL OUT
F/BACK BR OUT
+
+
TALK
+
+
TALK
ALL
to 0dB
TALKBACK
LEVEL
to 0dB
SLATE
LISTEN
LEVEL
to 0dB
+
-
+
-
IN
+
-
+
-
BUS COMP
+
-
+
-
MIX L OUT
MIX R OUT
AFL L
AFL R
PFL
+
-
MAIN L OUT
+
-
MAIN R OUT
ALT 1
+
-
ALT 1L OUT
+
-
ALT 1R OUT
ALT 2
+
-
ALT 2L OUT
+
-
ALT 2R OUT
ALT 3
+
-
ALT 3L OUT
+
-
ALT 3R OUT
MAIN
CUT L
CUT R
-1
POL
3dB
MONO
+
LISTEN
POWER
CUT
P/AFL
LISTEN
iJACK
+
-
L R
+
-
+
-
+
-
+
-
EXT 1
+
-
EXT 1L
EXT 1R
EXT 4
EXT 2
EXT 3
EXT 2L
EXT 2R
EXT 3L
EXT 3R
10K
1.5K
to 0dB
LEVEL
CUT
DIM
+dB
+dB
MIX
SUM
PFL
PFL
0 to -40dB
LEVEL
to 0dB
LEVEL
BALANCE
to 0dB
0dB to
AFL L
AFL R
+
+
TRIM
± 20dB
TRIM
± 20dB
to 0dB
LEVEL
Headphone Jacks (under armrest/front buffer)
EXT OSC +dB
440Hz
to +10dB
LEVEL
TRIM
TRIM
TRIM
TRIM
TRIM
to 0dB
to 0dB
to 0dB
to 0dB
to +10dB
to 0dB
±20dB
±20dB
±20dB
±20dB
±20dB
±20dB
OSC
Channel Strip (x32)
Stereo Return (x4)
Stereo Groups (x8)
Oscillator
Communications (Foldback and Studio)
Control Room Monitoring
Stereo Cues
Aux Sends
Mix Bus
Track Buses (x16)
AFL/PFL
IN FRONT
SOLO
LINE
F/B 1 F/B 2
MON
+
-
OSC OUT
IN
S/C
VCA
INSERT
-1
ø
FLIP
PATH
IN
0dB
0dB
0dB
HPF
EQ
VCA
S/C
VCA
VCA
KEY
INSERT INSERT COMP
to +10dB
to +10dB
to +10dB
to +10dB
BUS SEND 1
BUS SEND 2
BUS SEND 3
BUS SEND 4
BUS SEND 5
BUS SEND 6
BUS SEND 15
BUS SEND 16
C/ROOM L
C/ROOM R
EXT 1L
EXT 1R
EXT 4L
EXT 4R
DRIVE
-10dB
± 20dB
BELL BELL
LF HF
Hz
CUT
to 0dB
to +10dB
to 0dB
+
-
EXT TB OUT
TONE
SLATE
TONE
SLATE
OSC
SLATE
SLATE
LF
INSERT
SF
INSERT
OVERLOAD
(-3dB below
Path Clip)
≥1
LARGE
FADER
SMALL
FADER
CUT
SOLO
CUT
BUS SENDS
VIA DB-25 LINK
OR HALF NORMALLED
PATCH ROW
+
-
+
-
SUBGROUP
8L OUT
SUBGROUP
8R OUT
LISTEN
FRONT PANEL TRIM
+40 to +65dB
TALKBACK
COMPRESSOR
LISTEN
COMPRESSOR
TALKBACK
LINE
INPUT
LISTEN
LINE
INPUT
FRONT
PANEL
XLR
dB
+
-
+
-
+
-
O R I G I N
Drawn: NF, CJ
Revison: 1.10
Date: 15.10.2019
ORIGIN
Installation Guide

Visit SSL at:
www.solidstatelogic.com
© Solid State Logic
All rights reserved under International and Pan-American Copyright Conventions
SSL®and Solid State Logic®are ® registered trademarks of Solid State Logic.
ORIGIN™, SuperAnalogue™, VHD™ and PureDrive™ are trademarks of Solid State Logic.
All other product names and trademarks are the property of their respective owners and are hereby acknowledged.
No part of this publication may be reproduced in any form or by any means, whether mechanical or electronic,without the written
permission of Solid State Logic, Oxford, OX5 1RU, England.
As research and development is a continual process, Solid State Logic reserves the right to change the features and
specifications described herein without notice or obligation.
Solid State Logic cannot be held responsible for any loss or damage arising directly or indirectly from any error or omission in
this manual.
PLEASE READ ALL INSTRUCTIONS, PAY SPECIAL HEED TO SAFETY WARNINGS.
E&OE
May 2020
Revision History
Revision V1.0 - January 2020 - Initial Release
Revision V1.1 - February 2020 - First Minor Revision Release
Revision V1.2 - May 2020 - Correction of Leg Fixing Detail

About ORIGIN
ORIGIN takes a fresh look at what a large format console needs to do to work in harmony with a modern DAW-driven production
studio. The functional design looks back at the ‘ORIGIN’ of in-line consoles for signal flow inspiration, but its circuits are at the
cutting edge of SSL’s latest analogue developments. These new analogue designs deliver huge dynamic range and bandwidth yet
still have the characterful, pleasing qualities of space and depth that analogue audio breathes on digital audio.
ORIGIN’s simple signal flow and layout make it easy to understand and use, while powerful features such as channel direct outputs,
a fully balanced electronic architecture and precision bargraph meters make it a perfect partner for the highest quality converters
and DAWs in the most professional production applications.
A unique and innovative modular centre section allows ORIGIN to adapt to different applications and priorities, whether being used
as a purely tracking console with additional boutique analogue additions to the 19” rack centre section, or a very digital/analogue
hybrid approach with screens and controllers easily reached from the centre of the console.
ORIGIN offers engineers and producers the tools required for everything from large-scale tracking to hybrid mix down session.
Taking sustainability, ergonomics, modern gain-staging and communication requirements into consideration, ORIGIN offers a
reassuringly familiar Master Control feature-set with some ahead-of-the-curve functionality.

Contents
ORIGIN Installation Guide
Table of Contents
Safety First! 1
Important Safety Information 1
Definitions 1
Electrical Safety Warning 1
Safety Earth Connection 2
Mains Supply and Phases 2
Mains Isolation and Over-Current Protection 2
Physical Safety 3
Environmental 3
Regulatory Information 4
CE Certification 4
FCC Certification 4
Instructions for disposal of WEEE by users in the European Union 4
RoHS Notice 4
California Proposition 65 4
Help and Advice 5
Commissioning and Training 5
Warranty 5
Factory Warranty 5
Extended Warranty 5
Special Tools and Fasteners 5
User Guide 5
ORIGIN Power, Weight and Dimensions 6
General precautions 7
Unpacking 7
Safety Notices 7
IMPORTANT - ORIGIN Frame Structure and Manoeuvering The Console. 7
Dismantling the shipping crate 8
Mounting the console on the legs (if supplied) 9
Fitting/Removing the Sculpted End Trim 11
Installation in rooms with difficult/awkward access. 12
ORIGIN Master Section 13
About the ORIGIN Master Section and centre section rack layout. 13
VERY IMPORTANT INFORMATION 13
Making Connections 17
Origin Rear View - Power and Audio Connectors 17
Audio Connector Details 17
Microphone Inputs 17
Channel DB-25 Connectors 18
Channel DB-25 Pinouts 18
Channel DB-25 Pinouts cont'd 19
LF (Large Fader) Insert Returns 19

Contents
ORIGIN Installation Guide
Channel DB-25 Pinouts cont'd 20
SF (Small Fader) Insert Returns 20
Master Section DB-25 Connectors 21
Master Section DB-25 Pinouts 21
Master Section DB-25 Pinouts Cont'd 22
Master Section DB-25 Pinouts Cont'd 23
Suggested Patchbay Layout 24
Appendix A - Performance Specication 25
Audio Performance 25
PureDrive™ Channel Input Microphone/Line Amplifier 25
Monitor Input Line Input Amplifier 25
Channel Equaliser 26
Overall Channel Signal Chain Specifications 26
Crosstalk 27
Overall Console Noise 27
Environmental Requirements 27
Appendix B - ORIGIN Block Diagram 28

ORIGIN Installation Guide
Safety And Regulations
1
Safety First!
Important Safety Information
This section contains definitions and warnings, and practical information to ensure a safe working environment. Please take time
to read this section before undertaking any installation work.
Before use please also refer to the Safety Guide for ORIGIN, which is included in all new console shipments.
Denitions
‘Maintenance’
All maintenance must be carried out by fully trained personnel.
Note: It is advisable to observe suitable ESD precautions when maintaining electronic assemblies.
‘Non-User Adjustments’
Adjustments or alterations to the equipment may affect the performance such that safety and/or international compliance standards
may no longer be met. Any such adjustments must therefore only be carried out by fully trained personnel.
‘Users’
This equipment is designed for use solely by engineers and competent operators skilled in the use of professional audio equipment.
‘Environment’
This product is a class A product intended to form an integrated component part of a professional audio production environment
wherein it will perform to specification providing that it is installed according to professional practice.
Electrical Safety Warning
When installing or servicing any item of SSL equipment with power applied, when cover panels are removed, HAZARDOUS
CONDITIONS CAN EXIST.
These hazards include:
-High voltages
-High energy stored in capacitors
-High currents available from DC power busses
-Hot component surfaces
Any metal jewellery (watches, bracelets, neck-chains and rings) that could inadvertently come into contact with uninsulated
parts should always be removed before reaching inside powered equipment.

Safety And Regulations
2ORIGIN Installation Guide
Safety Earth Connection
Any mains powered item of SSL equipment that is supplied with a 3-core mains lead (whether connectorised or not) must always
have the earth wire connected to the mains supply ground AND PRECAUTIONS SHOULD BE MADE SO THAT THE GROUNDING
IS NOT DEFEATED. This is the safety earth and grounds the exposed metal parts of the racks and enclosures and must not be
removed for any reason.
ALL MAINS CORDS SUPPLIED ARE FITTED WITH AN IEC 60320 C13 TYPE SOCKET. WHEN CONNECTING TO SUPPLY
OUTLETS ALWAYS REFER TO THE RATING LABEL ON THE REAR OF THE CONSOLE AND ENSURE THAT APPROPRIATE SIZED
CONDUCTORS AND PLUGS ARE USED TO SUIT LOCAL ELECTRICAL REQUIREMENTS.
Mains Supply and Phases
To ensure safe operation of this equipment, connect only to an AC power source that contains a protective earthing (PE) conductor.
This equipment is designed for connection to single phase supplies with the neutral conductor at earth potential – category TN
or TT – and is fitted with a protective fuse in the live conductor only. This equipment is not designed for use with live and neutral
connections reversed or where the neutral conductor is not at earth potential (IT supplies). This equipment should not be connected
to a power system that switches open the return (neutral) lead when the return lead also functions as the protective earth (PE).
Mains cables will be coded with either of the following colour schemes:
1 or 2
LIVE: Brown Black
NEUTRAL: Blue White
EARTH: Yellow/Green Green
The ratings label, which details the console power requirements, is located adjacent to the mains inlet connectors on the power
input panel beneath the rear of the console.
DEN Apparatets stikprop skal tilsluttes en stikkontakt med jord, som giver forbindelse til stikproppens jord.
FIN Laite on liitettävä suojamaadoituskoskettimilla varustettuun pistorasiaan.
NOR Apparatet må tilkoples jordet stikkontakt.
SWE Apparaten skall anslutas till jordat uttag.
Mains Isolation and Over-Current Protection
An external disconnect device is required for this equipment which must be installed according to current wiring regulations. A
detachable power cord, as fitted to this equipment, is a suitable disconnect device.
An external over-current protection device is required to protect the wiring to this equipment which must be installed according
to the current wiring regulations. The fusing or breaking-current is defined in the product specification. In certain countries this
function is supplied by use of a fused plug.
Some units (specifically, those fitted with PSU Redundancy) utilise multiple power sources. This is clearly marked on the equipment.
The finished installation must also be clearly marked to ensure that all sources of power are removed before servicing work begins.

ORIGIN Installation Guide
Safety And Regulations
3
Physical Safety
The console surface is too heavy for one person to move; ensure sufficient manpower is available when positioning
the console and any associated IO or peripheral equipment.
If the console trim is removed for any reason then there may be sharp edges exposed on the frame metalwork.
Environmental
Evaluation of apparatus based on altitude not exceeding 2000m. There may be some potential safety hazard if the
apparatus is operated at altitude exceeding 2000m.
Evaluation of apparatus based on temperate climate conditions only. There may be some potential safety hazard
if the apparatus is operated in tropical climate conditions.
Tools
Origin issuppliedwitha pairofT-handle ModulePullers(SSLPart #53911152A)and a2mmAllenKeytoaidewith maintenanceofthechannel
strips. Other tools that may be needed for installation are an 8mm Metric (M8) spanner/socket or adjustable spanner to attach the legs.
If there is a need to remove the end trim of the console, a #2 Pozidriv screwdriver will be needed for the front buffer/armrest to end
trim screws.

Safety And Regulations
4ORIGIN Installation Guide
Regulatory Information
CE Certication
ORIGIN is CE compliant. Note that cables supplied with SSL equipment may be fitted with ferrite rings at each
end.
This is to comply with the current regulations and these ferrites should not be removed.
If any of the console metalwork is modified in any way – particularly the addition of holes for custom switches etc. – this may the
adversely affect the CE certification status of the product.
FCC Certication
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated
in a commercial environment.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is
likely to cause harmful interference in which case the user will be required to correct the interference at his own expense.
Instructions for disposal of WEEE by users in the European Union
The symbol shown here, which is on the product or on its packaging, indicates that this product must not
be disposed of with other waste. Instead, it is the user’s responsibility to dispose of their waste equipment
by handing it over to a designated collection point for recycling of waste electrical and electronic
equipment. The separate collection and recycling of your waste equipment at the time of disposal will
help to conserve natural resources and ensure that it is recycled in a manner that protects human health
and the environment. For more information about where you can drop off your waste equipment
for recycling, please contact your local city office, your household waste disposal service or where you purchased the product.
RoHS Notice
Solid State Logic has conformed and this product has conformed to European Union’s Directive 2011/65/EU on Restrictions of
Hazardous Substances (RoHS) as well as the following sections of California law which refer to RoHS, namely sections 25214.10,
25214.10.2, and 58012, Health and Safety Code; Section 42475.2, Public Resources Code.
California Proposition 65
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov

ORIGIN Installation Guide
Safety And Regulations
5
Help and Advice
Commissioning and Training
Commissioning
• ORIGIN consoles do not include on-site commissioning by an SSL engineer as standard.
• Commissioning can be requested at the time of purchase at additional cost and is usually expected to take one working day.
• You should contact your local SSL office or agent at least four weeks prior to delivery to arrange a commissioning date.
Please note: The console must be installed in a clean environment. The presence of dust – particularly cement particles – increases
the chance of long-term damage being caused to the moving faders and other controls. Such damage may cause the warranty
to be rendered invalid.
Training
A range of operational and maintenance training options are available from SSL or one of our authorised representatives.
For further information please contact SSL’s Support Department at: [email protected].
Warranty
Factory Warranty
All new systems include a 13 month warranty which commences on the date of shipment. This warranty includes:
-Technical support – phone, fax and e-mail – via your local distributor or office during normal business hours
-Supply of exchange parts*
-Service engineer visits (note that travel and subsistence costs are not covered by the warranty)
* It is not anticipated that a visit from an SSL engineer will be necessary in the majority of cases where a replacement part is
required. Console sub-assemblies are designed to be easily removable to facilitate replacement.
Extended Warranty
The standard warranty period may optionally be extended up to a maximum of 5 years on a ‘Parts supply’ basis.
To order extended warranty please contact your SSL representative or e-mail SSL’s Service department at:support@solidstatelogic.
com.
Special Tools and Fasteners
Each ORIGIN console is supplied with a pair of M4 thread T-Bar module removal tools (SSL Part No. 53911152A) which fix into the
threaded holes that are exposed when the upper and lower channel fixing screws are removed.
Other than this no special tools are required for maintenance. All fasteners are Metric sizes and threads. Most screws used to fix
panels are M3 Hex headed countersunk or cap screws which need a 2 mm hex, or Allen key to remove, or they are Pozidriv #2
headed screws. The feet are fixed with 8 mm (M8) Hex nuts (supplied).
User Guide
The ORIGIN User Guide can be downloaded from the ORIGIN section of the SSL website at : https://www.solidstatelogic.com

ORIGIN Installation Guide
Console Data
6
ORIGIN Power, Weight and Dimensions
Approx. Dimensions are shown in mm [and feet-inches] in the diagrams below.
Other specs are:
Approximate Weight: 357 lb / 162 kg including legs and trim ( 315 lb / 143 lb excluding legs)
Approximate Power Consumption:
Typically <900 Watts, 1200 Watts maximum when on
Typically <40 Watts when in standby/sleep.
1420 [4'-7 7/8"]
1781 [5'-10 1/8"]
1869 [6'-1 5/8"]
1819 [5'-11 5/8"]
984 [3'-2 3/4"]
540 [1'-9 1/4"]
735 [2'-5"]
1078 [3'-6 3/8"]
472 [1'-6 5/8"]
337 [1'-1 1/4"]
96 [3 3/4"]
8 [3/8"] ADJUSTABLE
1069 [3'-6 1/8"]

ORIGIN Installation Guide
Unpacking and Mounting Hardware
7
General precautions
-To prevent damage to the controls and cosmetics, avoid placing heavy objects on the control surface, obstructing
the faders, scratching the surface with sharp objects, or rough handling and vibration.
-Protect the equipment from damage through liquid or dust contamination. Avoid dust or small objects getting into
the fader slots. Power off and cover the console when it is not being used for a long period.
-Electronic technology can be affected by extreme cold. If the equipment has been stored in sub-zero temperatures
allow time for it to reach normal operating temperature before use. Recommended operating temperature for
ORIGIN is +1 degree (Non-condensing) to 40 degrees Celsius.
-Avoid using the equipment in extreme heat and direct sunlight. Make sure the console ventilation slots are not
obstructed and that there is adequate air movement around the equipment.
-ORIGIN is designed to be permanently mounted in a fixed installation. If the console has to be moved, please consult
SSL for packing and transportation advice.
-Avoid the use of chemicals, abrasives or solvents. Clean the control surface with a soft brush and dry lint-free cloth.
-It is recommended that servicing is carried out only by an authorised SSL support partner or agent. Contact details
for your local distributor can be found on the SSL web site or by contacting [email protected].
-SSL do not accept liability for damage caused by maintenance, repair or modification by unauthorised personnel.
WARNING: To reduce the risk of re or electric shock do not expose this apparatus to rain or moisture.
ATTENTION: An de réduire les risques de choc électrique, ne pas exposer cet appareil à l'humidité ou à la pluie.
Unpacking
ORIGIN is supplied in a sealed wooden shipping crate similar to that shown:
Approximate crate dimensions:
Length : 2040mm (80.3 inches)
Height : 680mm (26.8 inches)
Depth : 1210mm (47.6 inches)
Volumetric weight for shipping : 280 kg, 617.3 lb
Safety Notices
IMPORTANT: Please read the safety notice information included in the Safety Guide supplied inside the box before using
ORIGIN.
IMPORTANT - ORIGIN Frame Structure and Manoeuvering The Console.
The structure of ORIGIN is built on a strong steel U-beam which spans the width of the base of the console. Only
this should be used to lift and manoeuver the console when using a forklift or other mechanical lifting aid.
DO NOT USE THE OPTIONAL REMOVABLE END TRIM TO MOVE OR HANDLE THE CONSOLE.

ORIGIN Installation Guide
Unpacking and Mounting Hardware
8
Dismantling the shipping crate
Unbolt Crate Lid
1
Remove Foam Brace
2
Unbolt and Remove All Four
Wood Sides
3
Remove Console From Base
CONSOLE = 162 kg (357 lb)
4 PEOPLE MUST LIFT AND
USE LIFTING APPARATUS!
4
Remove Optional Legs From
Base**
**If Purchased
6
Remove Foam Base Tray
5

ORIGIN Installation Guide
Unpacking and Mounting Hardware
9
Mounting the console on the legs (if supplied)
Ensure that the legs, leg bolts, console are
conveniently located for assembly.
In the diagram on the left the foam base tray
is in position behind the console to provide a
cushioned base to protect the rear of the console
and the floor when fitting the legs.
1
Once the crate is dismantled, the next activity is to remove the console, legs and fixing nuts from the shipping
crate and to mount the console on it's legs. It is suggested that the foam lattice used in the shipping crate is used
to protect the floor and console when fitting the legs
CAUTION: The console weighs approx 150kg (330lb), multiple people and/or lifting supports must be used to
remove the console from the shipping crate.
Lift** the console and gently place it onto its rear.
The console will rest in a near vertical position
on the rear panel heatsinks and the cable tray
mounted on the rear edge.
**The console is heavy! Several strong people
will be needed for this activity.
2

ORIGIN Installation Guide
Unpacking and Mounting Hardware
10
With the console carefully resting on it's rear,
use the eight M8 nuts supplied to attach the legs
onto the studs protruding from the console base.
It is important for a person to support the console
as the legs are attached as the additional weight
of the legs will change the centre of gravity,
3
With the legs attached securely, the console
can be lifted to it's final position.
The rubber feet at the base of the legs have
a small amount of screw adjustment allowing
adjustment for uneven floors.
4

ORIGIN Installation Guide
Unpacking and Mounting Hardware
11
Fitting/Removing the Sculpted End Trim
If Sculpted End Trim has been ordered, this will normally be fitted prior to packing. It is possible to remove this end trim, for example
to reduce the overall width of the console, or to provide a surface to mate to third party furniture.
Removing the end trim starts with removing the three
cross headed screws that secure the front buffer/
armrest (1 in the diagram above) and the three 2mm
hex headed retaining screws (2 in the diagram on
the right) on the bottom edge of the trim. With these
six screws removed the trim can be gently slid up
vertically to align the keyhole slots with the locating
lugs and then removing the trim horizontally.
Fitting the trim is the opposite process, i.e. position
the trim keyhole locating apertures so they locate
onto the end of the console over the locating studs,
then gently slide the trim down vertically so that the
bottom three locating screw holes align with the
threaded holes in the end of the console, then screw
the trim in place with the three trim retaining screws
(2 in the diagram on the right) and the other three
screws inside of the front buffer/armrest (1 in the
diagram above).
2
1
1
Keyslots in sculpted end
trim interlock with studs
in end of ORIGIN console
frame
2

ORIGIN Installation Guide
Unpacking and Mounting Hardware
12
Installation in rooms with dicult/awkward access.
The console is supplied as a whole assembly built on a substantial and structural steel inverted U beam. If the console as a whole
assembly is impossible to manoeuver into the room it is destined for it is possible to break it into smaller, lighter pieces, however
this requires mechanical advice and involves removing and re-instating some internal wiring in the console. For further information
please contact SSL’s Support Department at: [email protected].

ORIGIN Installation Guide
Unpacking and Mounting Hardware
13
ORIGIN Master Section
About the ORIGIN Master Section and centre section rack layout.
The ORIGIN Master Section is designed to be the heart of a flexible, configurable central layout. The 6U 19" rack width is designed
to be re-positionable for different application priorities. As standard, the master section is fitted in the bottom 6U of the 12U central
rack layout and there are two 3U panels blank panels above. The Master Section is cabled such that it can be placed in any of the
rack slots from the lowest 6U to the top 6U and therefore the blank panels may be re-arranged to support other third party devices
such as keyboards, or controllers. Additionally custom 19" panels, such as switch panels, or trays for controllers may be fitted and
cable access is available through an access hole at the rear of the base of the cavity (see diagram below).
It is possible to fit shallow audio devices, such as 500 series rack modules, into the upper areas of the centre racking, care should
be taken that any devices fitted do not introduce overheating issues, either because of their own power consumption, or because
they restrict airflow, see the IMPORTANT INFORMATION below.
VERY IMPORTANT INFORMATION
HEAT AND VENTILATION
As shown in the drawing below, ventilation through the internal cavity of the centre section is very important. Any device which is
tted into the racking which signicantly restricts airow through the central cavity could create overheating issues for the
electronics in the Master Section. Deep units which could signicantly obstruct airow should have at least a 1U ventilation
panel underneath their rack position to allow airow through the Master Section.
ELECTRICAL NOISE AND INTERFERENCE
Any third party electronics mounted in the centre section racking could expose the Master Section to electrical noise/interference
and compromise the audio performance of ORIGIN. Obviously, SSL cannot be responsible for any issues that may arise because
of this and owners should remove any devices causing such issues to preserve the audio performance of the console.
MOVING THE MASTER SECTION
Though the Master Section is designed to be re-positioned, it is not designed for continuous changes of position, it is moveable to
configure the console for different applications, not to be moved for each session.
Centre Rack Depth - 12u
Master Section Dimensions
6U (267mm, 10.5”) high
483mm(19”) wide x 120mm(4.7”) deep
Ventilation
Inlets
Ventilation
Exhaust
Air Flow
Cable
Access
100mm, 4”
280mm, 11.0”
180mm, 7.0”
Air Flow

ORIGIN Installation Guide
Unpacking and Mounting Hardware
14
Standard Layout
The layout on the left is the default layout from the factory. As can be seen, all
the panels above the Stereo Group faders are 19" format panels. The Master
Section is a 6U panel and above that are two 3U panels. The Meter Panel in
the overbridge is also a 3U panel.
500 Series Racks
In this layout, the two 3U panels have been replaced with a 500 series rack
fitted with 8 mono SSL Dynamics modules and a stereo SSL Bus Compressors.
A 1U grill panel has been fitted above the centre section to aid with ventilation
and the remaining 2U filled with a 2U blank panel.
The lower right blank area next to the Stereo Group faders has an Apple
Magic Trackpad placed on it to show for scale.
IMPORTANT:
Please read the VERY IMPORTANT INFORMATION on the previous page
before fitting any electronic devices into the centre section racking.

ORIGIN Installation Guide
Unpacking and Mounting Hardware
15
Full Sized Keyboard
In this layout, the Master Section has been moved towards the rear of the
console by 3U**. A blank 3U panel has been moved into the space above
the Stereo Group Faders and this can be used for a computer keyboard. The
lower right blank area next to the Stereo Group faders has an Apple Magic
Trackpad.
**NOTE: Moving The 6U Master Section
The 6U ORIGIN Master Section has many of the console audio and control
signals wired to it. Please exercise anti-static precautions before moving and
take great care to ensure no cables are snagged or disconnected when
moving.
DAW Controller Layout
In this layout, the Master Section has been moved to the top 6U of the console
centre section. The two 3U blank panels have been moved into the space
above the Stereo Group Faders and this space is used for a DAW controller.
The lower right blank area next to the Stereo Group faders has an Apple
Magic Trackpad.
**NOTE: Moving The 6U Master Section
The 6U ORIGIN Master Section has many of the console audio and control
signals wired to it. Please exercise anti-static precautions before moving and
take great care to ensure no cables are snagged or disconnected when
moving.
