Solution Ozone AIS-WTSO01 User manual

AIS-WTSO01
Domesc Air Treatment
User Manual
Ver: 1.01
Cered by:

2
..EN
AIS-WTSO01 - User Manual (EN)
Introducon and principle of the product
This ozone purier is specially designed for domesc use, to obtain disinfecon and
sterilizaon of the ambient air. It provides the right amount of ozone for air treatment to
kill bacteria, remove bad odors and remove harmful gases.
This equipment works at low voltage (12V DC).
Ozone is a powerful oxidant. The O3 molecule is very unstable and combines with other
substances to oxidize them quickly. Therefore, it has many industrial and consumer
applicaons related to oxidaon.
Specicaons
Precauons to be taken before use
1 - Remove the equipment from the packaging and check if it includes all components.
2 - Please read the User Manual carefully.
3 - Do not let water into the equipment. Do not install the equipment near water sources.
4 - Install the equipment on the wall at a Safety height to ensure it is out of reach of
children.
5 - Make sure the equipment is correctly installed, vercally.
6 - Do not use the equipment if the cover is removed.
7 - Do not perform any maintenance with the equipment connected to electricity.
8 - Check if the air intake, in the rear, and other venlaon holes are clear.
9 - Do not insert any objects into the equipment.
10 - Use a so cleaning cloth. Do not clean this appliance with chemical or abrasive
cleaning products.
11 - Do not breathe ozone directly. Avoid contact between the air outlet and the nose.
Model AIS-WTSO01 Ozone output - Dry Air (RH 30%) 300 mg/H to 2.5L/
min
Input voltage 100 - 240 V AC Ozone output - Ambient Air (RH 85%) 230 mg/H to 2.8L/
min
Output voltage 12 V DC Supply gas Ambient Air
Consume < 12 W Operang temperature 0 - 60ºC
Dimension 223 x 162.5 x 54.5 mm Material Plasc ABS
Weight 0.96 kg Power cord length 120 cm

3
Equipment structure
Front Back Boom
..EN
AIS-WTSO01 - User Manual (EN)

Applicaons
1 - Eliminates bacteria, fungi, microorganisms and viruses - Ozone is an oxidizing agent
capable of eecvely oxidizing more than 99% of bacteria, fungi, microorganisms and
viruses.
2 - Complete space disinfecon - Ozone is one of the most powerful disinfectants, 100%
natural and dispenses the addion of any chemicals. Being a gas disinfecon system, it allows
ecient disinfecon of all corners of a space, including the base of furniture and desks that
are usually forgoen. The Domesc Air Treatment is the ideal system to disinfect rooms,
bedrooms, kitchens, or any domesc area or reduced spaces eecvely and completely.
3 - Removes obsolete odours and odours - The Domesc Air Treatment produces ozone, a
powerful oxidizing agent, which will oxidize harmful toxic elements and organic odours in the
air, removing bad odours and reducing their toxicity without any secondary polluon.
4 - Removes dust, pollens and germs - Domesc Air Treatment allows you to eliminate dust,
smoke and pollen parcles, which give rise to allergies. Ozone is a powerful oxidizing agent
that kills various bacteria and germs in the air.
Operaon Mode
1 - Remove the equipment and power cord from the box.
2 - Place the equipment in a vercal posion, preferably xed to a wall (using the sucon
cups or the Fastening System) to ensure that the ozone outlet is not blocked.
3 - Turn on the power cord. They will light four dots on the display, which means the device is
on. Adjust the operaon according to your need.
4 - Aer nishing using the equipment, turn o the power cord. The display will be
completely erased, which means the device is o.
5 - The equipment allows two operaon opons:
- Mode A: Single Operaon
- Mode B: Automac Operaon
4
..EN
AIS-WTSO01 - User Manual (EN)

Mode A: Single Operaon
Conrm that there are no people or animals in the room to be disinfected (some plants are
not ozone-resistant so to raise the concentraon to levels of disinfecon you should remove
them from space). Close all doors or windows.
You can return to the room aer 30 minutes aer the ozone dissipaon me in the room.
Note: Do not breathe the ozone directly. Aer turning on the equipment leave the space
immediately and return only to turn o the equipment. According to OSHA standards, it
should not remain in a space where ozone is being produced for more than 1 minute per 30
m2.
Diagram Display Descripon Instrucons
All OFF
Totally OFF OFF
.... ON
Four dots
ON
Connect the equipment to the electric
current.
00:00
00:00
Press the buon to start Single Mode.
The 00:00 mer (MM:SS) will light up on the
display.
MM:SS
MM:SS
Press to start the adjustment, the digits
will blink. Press again to increase the
running me (increases 5 minutes with each
selecon to a maximum of 30 minutes).
Press to decrease the operang me
(reduces minute to minute with each
selecon, to a minimum value of 0 minutes).
MM:SS ON
MM:SS
(minutes &
seconds)
ON
Press the buon again to conrm the
adjustment. The equipment will start
producing ozone immediately, so you should
leave the room and close the door.
00:00
00:00
Standby (in pause)
At the end of the me, the equipment will go
into standby mode, with the mer at 00:00.
5
..EN
AIS-WTSO01 - User Manual (EN)

Mode B: Automac Operaon
Conrm that there are no people or animals in the room to be disinfected (some plants are
not ozone-resistant so to raise the concentraon to levels of disinfecon you should remove
them from space). Close all doors or windows.
6
..EN
AIS-WTSO01 - User Manual (EN)
Diagram Display Descripons Instrucons
All OFF
Totallly OFF OFF
.... ON
Four dots
ON
Connect the equipment to the electric
current.
OF:ON
OF:ON
To start the auto mode, press the buons
and . The display will be on
OF:ON (HH:MM).
OF:MM
OF:MM
(MM operang
me to be
congured in
minutes)
Press the buon to adjust the seng. The
last two digits will start ashing (ON) so that
the working me can be adjusted.
Press to increase the working me (add 5
minutes to each pressure, up to a maximum
of 30 minutes) and press to reduce the
working me (reduces minute to minute at
each pressure, down to zero).
O.F:MM
H.H:MM
(H.H for pause MM
for operang me)
Press to adjust the pause me. The rst
two digits (OF) will start ashing. Press to
increase the pause me [increases 0.5/1 hour
(30 minutes) to each selecon, up to a
maximum of 24 hours]. Press to decrease
the pause me [reduces 0.1/1 hour (6
minutes) for each selecon to a minimum
value of zero].

Mode B: Automac Operaon (cont.)
The equipment will start producing ozone according to the programmed mes. At the end of
me, the equipment will stop producing ozone.
Ensure that the disinfecon schedule is for periods when no one is in space and ensures the
end of the cycle with a minimum safety interval of 30 minutes before someone returns to
space to fully dissipate ozone in the air.
You can return to the room aer 30 minutes aer the ozone dissipaon me in the room, at
the end of that period, if you want, unplug the equipment from the electric current.
Note: Do not breathe the ozone directly. Aer turning on the equipment leave the space
immediately and return only to turn o the equipment. According to OSHA standards, it
should not remain in a space where ozone is being produced for more than 1 minute per 30
m2.
7
..EN
AIS-WTSO01 - User Manual (EN)
Diagram Display Descripon Instrucons
H.H:MM
H.H:MM
Press the buon again to conrm the
seng. When :MM(ON) is at 00, the
equipment stops producing ozone. The :MM
(ON) display will show the duraon me of
the NEXT cycle, during this me H.H: (OF) will
start the countdown to the next cycle. When
H.H: (OF) is at 0.0, the equipment will again
produce ozone. As long as H.H: is counng
down, the equipment does not produce
ozone.
OF:ON
OF:ON
When you need to recongure the working
and pausing period in Auto Mode, press the
buon again unl the display is in OF:ON.
.... ON
Four dots
ON
To access Mode A, Single Operaon, press the
buons simultaneously and exit
Auto Mode.

8
Failure Analyis
Garantee
1 - This equipment has 2 years free guarantee from the date of delivery, for any defects of
material or workmanship in normal household use. Please present the invoice and guarantee
card. Wear material is not included in the guarantee coverage.
2 - The guarantee is granted only to the original buyer and members of his immediate family.
The guarantee is subject to the following provisions. Any damage or malfuncon caused by
negligence, abuse or otherwise by the User Manual is not covered by this guarantee.
Similarly, any defects or damages caused by unauthorized services or the use of parts that
are not genuine, specied, are not covered.
3 - Under guarantee, we are commied to the repair or replacement of equipment or parts
that present a problem. As a maer of warranty policy, the value of the equipment will not
be refunded. At the me of purchase, register the guarantee card that follows with the
seller’s details.
4 - To trigger the guarantee service, you must return the equipment along with proof of
purchase directly to our company or an authorized distributor. All costs of transporng
submied equipment parts not covered by this guarantee shall be the responsibility of the
buyer.
..EN
Flaw Analysis Soluon
The equipment
does not turn
on
The power cord is disconnected Reconnect the power cord.
Fluxo de água reduzido. Aumente o uxo de água.
Abnormal noise
See if there are any foreign objects inside
the equipment.
Gently shake the machine and remove the
material.
Wrongful xaon to the wall Check the condion of the xture to the wall and
correct it.
For other failures, request professional maintenance with the purchase invoice or guarantee card or return the
equipment to the manufacturer for maintenance.
AIS-WTSO01 - User Manual (EN)

Guarantee Card
www.soluonozone.com
info@soluonozone.com
9
..EN
AIS-WTSO01 - User Manual (EN)
Full Name Phone
Address
Receipt no. Purchase date
Maintenance Record
Maintenance Date
Analysis
Result
Clerk Signature
