SOLZAIMA Alpes 8 kW User manual

Wood Pellet Stove
Instruction Manual
English
Models
Alpes 8 kW | Alpes 10 kW
Douro 17 kW | Douro 23 kW
Read these instructions carefully before installing, using and servicing the unit.
The product is supplied with this instruction manual.
Mod. 216-C

Thank you for purchasing a SOLZAIMAunit.
Please read this manual carefully and retain it for future reference.
* All our products fulfil the requirements of the Construction Products Regulation
(REg. UE nº305/2011) and have been approved with the CE conformity mark;
* The Free Standing Pellet Fires are manufactured in compliance with the EN
14785:2008 Standards
* SOLZAIMA bears no responsibility for any damage to the unit if it is installed by
non-qualified personnel;
* SOLZAIMA is not responsible for any damage to units not installed and used in
compliance to the instructions included in this manual;
* All local regulations, including but not limited to national and European standards,
must be observed when installing, operating and servicing the unit;
* Whenever you need assistance, you should contact your unit’s supplier or installer.
You must have the wood pellet stove serial number located on the identification plate
on unit's back panel and on the sticker on the plastic cover of this manual ready.
*The technical service must be performed by the unit Installer or Supplier, except on
situations where the assessment performed by the installer or service engineer
determines that SOLZAIMA should be contacted, if required.

Contents
1. Package content ...........................................................................................................3
1.1. Unpacking the free standing fire..............................................................................3
2. Safety precautions ........................................................................................................4
2.1. For your safety, we recommend that: ......................................................................5
3. Technical specifications.................................................................................................7
4. Installation of the free standing pellet fire unit.............................................................. 11
8.1. Assembly of removable parts................................................................................12
8.2. Installation requirements.......................................................................................16
8.3. Installation of ducts and fume extraction systems:.................................................16
8.4. Installation without a chimney................................................................................17
8.5. Installation with a chimney ....................................................................................21
8.6. Hydraulic Installation (only for the backboiler model).............................................22
9. Fuel.............................................................................................................................23
10. Use of the Free Standing Pellet Fire............................................................................24
11. Remote Control...........................................................................................................25
11.1. Infrared remote control (Alpes models) ...........................................................25
11.2. Remote control and display.............................................................................26
11.3. Display information summary..........................................................................27
11.3.1. Menu…………………………………………………………………………27
11.3.2. Water temperature (only for the backboiler model)………………….…27
11.3.3. Date/Time…………………………………………………………………..28
11.3.4. Timer……………………………………………………………………..…30
11.3.5. Sleep……………………………………………………………………..…34
11.3.6. Configuration menu…………………………………………………….…34
11.3.7. User Info……………………………………………………………………39
12. Start-up.......................................................................................................................41
12.1. Stop................................................................................................................42
12.2. Turning off the unit..........................................................................................42
12.3. Instructions for removing the side covers........................................................42
12.3.1. Remove side covers…………………………………………………. .......42
12.3.2. Pellet reservoir lid………………………………………………… ............42
12.4. Filling the pellet reservoir................................................................................43
12.5. Installation and operation with the remote control............................................43
12.5.1. Instructions for remote control assembly………………………… ......…45

13. Humidifier (only in the Alpes models)...........................................................................47
14. Installation of the optional UPS connection Safety Kit..................................................48
15. Maintenance ...............................................................................................................50
16. Alarms / failures / recommendation list .......................................................................61
17. Installation diagrams (only backboiler models –Douro 17kW and Douro 23kW)..........63
17.1. Central heating installation diagram................................................................63
17.2. Wood and pellet central heating installation diagram.......................................64
17.3. Wall back boiler pellet central heating installation diagram..............................65
17.4. Installation diagram for central heating and household water heating using a
cylinder thermostat..........................................................................................66
17.5. Symbols..........................................................................................................67
18. Electrical diagram of the Free Standing Pellet Fire unit................................................68
19. Performance graphs for the UPSO 15-55 CIAO circulating pump................................69
................................................................................................................................................69
20. Life cycle of a Free Standing Pellet Fire unit................................................................70
21. SUSTAINABILITY........................................................................................................70
22. Glossary......................................................................................................................71
23. Warranty .....................................................................................................................73
24. Annexes......................................................................................................................74

2
Solzaima
Solzaima's vision has always been to provide the cleanest, renewable and more cost-
effective energy. This is why for more than 35 years we've been dedicated to
manufacturing biomass heating units and solutions.
As a result of the persistence and unconditional support from a network of partners,
Solzaima is currently the leader in biomass heating units manufacturing, especially with
its range of central heating units with backboilers and free standing pellet fires.
We deliver biomass heating units to approximately 20,000 homes every year. This
effectively demonstrates consumers' interest in more ecological and economic solutions.
Solzaima has been awarded Quality certificate ISO9001:2008 and Environmental
certificate ISO14001:2004.

3
1. Package content
Solzaima ships the unit with the following components:
- Free standing pellet fire model Alpes 8 kW, Alpes 10 kW, Douro 17kW or Douro 23 kW
- Side covers, top front cover and bottom front cover
- Instruction Manual
- Power cable
- Humidifier lid and humidifier (only for Alpes models)
- Cleaning bar handle (only for Alpes models) –IR remote control (only for Alpes models)
1.1. Unpacking the free standing fire
When unpacking the unit, please refer to the illustrations below. First remove the
retractable bag containing the cardboard box (Figure 1-a). Then pull the cardboard box
out (Figure 1-b) by lifting it and remove the bag containing the free standing fire unit
(Figure 1-c) and the styrofoam plates. Finally, unscrew the four parts securing the unit to
the wood pallet (Figure 1-d and -e).
a) b) c)

4
d) e)
Figure 1 –Unpacking the free standing fire unit
2. Safety precautions
Solzaima is not liable for any damages to the unit if the specified precautions, warnings
and operating procedures are not followed.
Units manufactured by Solzaima are easy to operate and special attention was given to
their components in order to protect users and installers against accidental damages.
The units must only be installed by an authorised engineer, who should supply the client
with a relevant statement of conformity and who shall be liable for the final installation
and consequent product good operating conditions.
This unit must be used according to its intended use as specified by the manufacturer.
The manufacturer is excluded from all liability, by contract or by tort, caused by injury to
people, animals or property arising from misuse or faulty installation or servicing.
After removing the packaging, verify the contents to check their integrity and
completeness. If the content of the package fails to correspond to that indicated in point
1, contact the salesperson from whom you purchased the unit.
All the unit's components guarantee its operation and energy efficiency and should only
be replaced with original parts provided by an authorised technical assistance centre.
The unit must be serviced at least once a year by the installation engineer.
This manual is provided with the product. Please keep it close to the unit.

5
2.1. For your safety, we recommend that:
Make sure you fully read and understand this instruction manual before using the free
standing pellet fire as a biomass heating unit.
Make sure that the hydraulic circuit was correctly assembled and connected to the
water supply before turning on the free standing pellet fire (only in water models –Douro
17kW and Douro 23kW);
The free standing pellet fire is not intended for use by children or persons with
reduced physical, sensory or mental capabilities, or lack of experience or knowledge,
unless they are under supervision or have been instructed concerning the use of the unit.
Do not touch the free standing fire when barefoot or if any part of your body is wet or
humid;
Do not tamper with safety or adjustment features without the manufacturer's
authorization;
Do not cover or reduce the size of the vents at the installation area;
The free standing pellet fire requires a clear space around the unit for proper
combustion, so possible air tightness of the location or any existing air extraction sources
in the room may prevent the unit proper operation;
The existence of vents is a requisite for proper combustion;
Do not leave the packing materials near children;
During normal operation, Free Standing Fire unit's door must not be opened;
Some parts of the unit may overheat during normal operation, so avoid direct contact
with parts such as the door handle and glass;
Check the existence of any obstructions on the fume duct before turning on the unit
after a long period of inactivity;
This free standing pellet fire unit is intended for residential use in protected areas.
Safety systems may turn off the unit. If this occurs, contact the technical assistance. In
any circumstances should you attempt to interfere with the safety systems;
The free standing pellet fire is a biomass heating unit equipped with an electric fume
extractor. The occurrence of any power failure during its use may prevent fume
extraction and the room will be filled with smoke. For this reason, you should have a
natural fume extraction system, like a chimney, available;

6
Solzaima offers you an optional safety system which allows the Free Standing Fire
unit to be connected to a UPS so that during any power failure the fume extractor will still
operate until complete extraction of all the fumes;
If you intend to use the Free Standing Fire unit while you are away from home or
unattended, you should use the safety system specified above for total safety during any
power failure;
During operation, NEVER turn off the free standing fire unit by disconnecting the
electric plug. The fume extractor on the free standing pellet fire unit is electric so
disconnecting the power plug will prevent the extraction of combustion fumes;
Your unit must be disconnected from the mains for servicing. Before doing this, the
unit must be totally cooled down (if operating before);
Never touch the interior of the unit without disconnecting it from the power mains;
On backboiler models, the maximum temperature of the water that can be set by the
user (water set-point temperature) is 85°C. In the event of a temperature of 90ºC being
reached, the free standing pellet fire unit automatically disconnects and the respective
alarm is activated.

7
3. Technical specifications
FEATURES
Alpes
8kW
Alpes
10kW
Douro
17kW
Douro
23kW
Units
Weight
102
118
200
212
Kg
Height
970
1110
1150
1200
mm
Width
490
490
600
660
mm
Depth
480
450
590
660
mm
Diameter of the fume discharge pipe
80
80
100
100
mm
Reservoir capacity
15
20
30
45
Kg
Maximum heating capacity
177
217
384
520
m³
Maximum overall thermal power (fire
insert/backboiler)
8
9,6
15,1 / 1,9
20,4 / 2,6
kW
Minimum thermal power (fire insert/backboiler)
4,2
5,2
6,0 / 0,9
8,9 / 1,5
kW
Minimum fuel consumption
1,1
1,2
1,6
2,3
Kg/h
Maximum fuel consumption
1,9
2,3
3,9
5,3
Kg/h
Rated electrical current
122
122
134
134
W
Electric power at start-up (<10 min.)
378
378
434
434
W
Rated voltage
230
230
230
230
V
Nominal frequency
50
50
50
50
Hz
Thermal yield at rated thermal power
84,0
88
90,7
90
%
Thermal yield at reduced thermal power
82,8
90
93,7
92
%
Combustion gas flow (max.)
7
7
12
18
g/s
Combustion gas flow (min.)
7
5
7
12
g/s
Max. gas temperature
188
190
138
151
ºC
Min. gas temperature
163
120
78
96
ºC
CO emissions at rated thermal power
0,04
0,03
0,03
0,03
%
CO emissions at reduced thermal power
0,04
0,02
0,03
0,03
%
Draught in the chimney
12
12
12
12
Pa
Unit water volume
-
-
22
22
W
Cross-flow fan sound level
-
-
-
-
dB(A)
Fume extractor sound level
-
-
67,6
67,6
dB(A)
Table 1 –Technical specifications

8
Tests performed using wood pellets with a heating capacity of 4.9 kWh/kg.
The above information was obtained during product homologation tests performed at
independent laboratories accredited for pellet unit tests.
Front Rear Side Top
Figure 2 –Dimensions of the free standing pellet fire unit (air model –Alpes 8 kW)
Front Rear Side Top
Figure 3 –Dimensions of the free standing pellet fire unit (air model –Alpes 10 kW)

9
Front Rear Side Top
Figure –Dimensions of the free standing pellet fire unit (backboiler model –Douro 17 kW)
Front Rear Side Top
Figure 5 –Dimensions of the free standing pellet fire unit (backboiler model –Douro 23 kW)

10
Figure 6 –Hydraulic connections of the free standing pellet fire unit (backboiler model –Douro 17
kW)
Figure 7 –Hydraulic connections of the free standing pellet fire unit (backboiler model –Douro 23
kW)

11
4. Installation of the free standing pellet fire unit
Before installing, please perform the following steps:
Upon reception, check the product for completeness and to determine that is does
not show any damage signs. Any damages or defects should be checked before the
unit is installed.
The unit is equipped with four adjustable height feet at the base which allow for a
simple regulation when installed on a non flat surface.
Figure 8 –Adjustable feet
Remove the instruction manual from the package and hand it over to the client.
Connect an 80mm wide (Alpes 8kW or Alpes 10kW) or or 100mm wide (Douro
17kW or Douro 23kW) duct between the combustion gas output and the outgoing fume
extraction duct of the building (e.g. chimney) –check location diagrams under no. 4.
If a tube is used for combustion air inlet from the outside, it shall be no longer than
60cm horizontally or present offsets (such as bends);
Perform the hydraulic installation (see point 4.6) –(only for the backboiler units –
Douro 17kW or Douro 23kW)
Connect the 230VAC power cable to a grounded socket.
The surface of the unit where the hot air outlet is located must be facing the area to
be heated.
The unit's remote control has a programmable thermostat. As an option, a
conventional external programmer may be used (not included) to automatically setup
the unit's operating periods. This should be connected through cable to the optional
230VAC programmer plug (not provided).

12
4.1. Assembly of removable parts
After the installation, the Free Standing Fire unit should be fitted with the removable
covers.
Air model - Alpes 8kW and Alpes 10kW
- Top front cover
The following figure shows how to assemble the top front cover. First, remove the two
screws located at the top of the unit (Figure 9-a). Then insert the part (Figure 9-b) with
the lower notches (Figure 9-c) to facilitate the attachment to the unit ( Figure 9-d). Insert
the part by pressing down on it until it clicks into place. Finally, replace and tighten the
two screws (Figure 9-e).
a) b)
c) d)

13
e)
Figure 9 –Assembly of the top front cover of the unit
- Bottom front cover
To assemble the bottom front cover, remove the screws on the unit (Figure 10-1 and b).
Then apply the part (Figure 10-c), by fitting the existing lower notch into the groove on
the unit. Finally, replace and tighten the screws (Figure 10-d).
a) b)
c) d)
Figure 10 –Assembly of the bottom front cover of the unit

14
- Side covers
To install the unit's side covers position the covers and insert them as illustrated, onto the
existing supports.
Figure 11 –Assembly of side covers
- Humidifier
The humidifier is located inside the unit, together with other components (Figure 12-a).
Remove it and install it in the correct location on the top of the unit (Figure 12-b) and
then attach the respective lid (Figure 12-c).
a) b)
c)
Figure 2 –Assembly of the humidifier

15
Backboiler model - Douro 17kW and Douro 23kW
- Top front cover
To install the top front cover, place it over the unit (Figure 13-a) and then tighten the
screws that secure it to the top panel of the unit (Figure 13-b).
a) b)
Figure 13 –Assembly of the top front cover
- Bottom front cover
The bottom front cover can be assembled by removing the screws located on the bottom
part of the unit. Then place the part in the appropriate position (Figure 14-a) and replace
and tighten the screws again (Figure 14-b)
a) b)
Figure 14 –Assembly of the bottom front cover

16
4.2. Installation requirements
The minimum distance between the free standing pellet fire unit and particularly
flammable surfaces is specified in Figure 15.
The top of the unit must be at least 100cm separated from the ceiling, especially in
rooms with ceilings consisting of flammable materials.
The base supporting the unit cannot be made of combustible material (e.g. carpet), so
make sure you use an adequate protection.
a) b)
Figure 15 –Minimum distances from all surfaces: a) upper view of the unit's installation;
b) side view of the unit's installation
Warning!
Keep combustible and flammable materials at a safe distance.
4.3. Installation of ducts and fume extraction systems:
The exhaust pipe must have been designed for this purpose, in compliance to the
location requirements and in accordance with any applicable regulations.
Important! An inspection-T with an airtight lid must be attached to the exhaust
pipe of the unit to allow the regular inspection of the system or discharge of heavy dust
and condensates.

17
As indicated in Figure 15, the exhaust pipe must be assembled so as to allow
cleaning and maintenance of the pipe by inserting inspection points.
Under normal operating conditions, the combustion gas flow should create a draught
of 12 Pa one meter above the chimney neck.
The unit must not share the chimney with other equipment.
Pipes outside the operating area must have double stainless steel insulation and an
internal diameter of 80 mm (air model) or 100mm (backboiler model).
The fume exhaust pipe may generate condensation, so we recommend that the
appropriate systems for collecting condensates should be installed.
4.4. Installation without a chimney
The installation of the free standing pellet fire without a chimney should be performed as
illustrated in Figure 16, equipped with an exhaust pipe (with a minimum diameter of 80
mm for the air model and 100 mm for the backboiler model) directly outside and over
the roof.
Double-walled stainless steel insulated pipes must be used and properly fastened to
avoid condensation.
A T-tube must be installed at the base of the pipe to allow periodic inspections and
annual maintenance, as illustrated in Figure 16.
Figure 17 specifies the basic requirements for installing the chimney to the unit.
