Somerdata DRSS-1080 Owner's manual

DRSS-1080
Digital Signal Splitter
Copyright © 2007 Somerdata Ltd.
INSTALLATION AND OPERATION
Applicable Products
DRSS Signal Splitter for 2048kbits/s ITU G.703 bitstreams
Part Numbers: DRSS-ASSY-0019
E1SS-1080
DRSS-1080
Document Reference
DRSS-MAN-R119
Publication Date
17 August 2007
Published by
Somerdata Ltd.
1 Riverside Business Park
St Annes Road
Bristol
BS4 4ED
UK
Sales & Customer Support
Phone: [phone]
Fax: [phone]
E-Mail: [email protected]m
[email protected]m
Website: www.somerdata.com

DRSS-1080 Digital Signal Splitter
Installation and Operation
DECLARATION OF CONFORMITY
Name of Manufacturer:
Somerdata Ltd.
Address of Manufacturer:
Somerdata Ltd
1 Riverside Business Park
Bristol
BS4 4ED
United Kingdom
Equipment description:
Digital Signal Splitter
Model:
DRSS-1080/ E1SS-1080
Conforms to the following Product Specifications:
Safety: IEC 950
EMC: 89/336/EEC EN55022 Harmonised Standard
The product complies with the requirements of the Electromagnetic
Compatibility Directive 89/336/EEC as amended and the Low Voltage
Directive 73/23/EEC and carries the CE marking accordingly.
Signed:
Position: Technical Director
Date: 19th July 2007

DRSS-1080 Digital Signal Splitter
Installation and Operation
NOTICES
Copyright © 2007 Somerdata Ltd. All Rights Reserved.
This publication is protected by copyright and all rights are
reserved. No part of it may be reproduced or transmitted by any
means or in any form, without prior consent in writing from
SomerData.
The information in this User Guide has been carefully checked
and is believed to be accurate. However, SomerData assumes
no responsibility for any inaccuracies that may be contained in
this publication.
In no event will SomerData be liable for direct, indirect, special,
exemplary, incidental, or consequential damages resulting from
any defect or omission in this manual, even if advised of the
possibility of such damages.
In the interest of continued product development, SomerData
reserves the right to make improvements in this publication and
the products it describes at any time, without notice or obligation.
All product names mentioned herein are used for identification
purposes only, and may be the trademarks or registered
trademarks of their respective companies.

DRSS-1080 Digital Signal Splitter
Installation and Operation
SOMERDATA AND THE ENVIRONMENT
Introduction
SomerData is committed to design and introduce products that
conform to applicable environmental legislation and standards.
One of our missions is to integrate environmental stewardship
into the business of providing quality products, services, and
customer support at the best value.
In order to achieve this, SomerData has established a
strategic team to focus on the importance of meeting our
environmental obligations in the design, manufacture and
suport of our products.
We have developed a broad appreciation of the impact of
these directives on our entire business model, from technical
processes for materials, to finished goods manufacturing.
Current Compliance Activities
The Company’s current environmental compliance
commitment has been structured to meet the following
European Union directives:
Restriction of Use of Hazardous Substance or RoHS
Compliance (EU Directive 2002/95/EC)
Waste Electrical & Electronic Equipment or WEEE
Compliance (EU Directive 2002/96/EC)
Our goal is to meet or exceed compliance obligations of these
EU directives.

DRSS-1080 Digital Signal Splitter
Installation and Operation
Restriction of Use of Hazardous Substances (RoHS)
Somerdata has also established a RoHS qualification process
to help ensure that products meet stringent reliability and
quality requirements, as well as regulatory compliance
requirements.
The maximum allowable hazardous substance at a
homogeneous material level under the EU RoHS Directive is
shown in the following table.
From 1st July 2006 all SomerData manufactured products
used lead-free soldering
Substances
Maximum
Concentration
Values (ppm)
Lead and its compounds
1000
Mercury and its compounds
1000
Hexavalent Chromium (Cr+6)
1000
Cadmium and its compounds
100
PolyBrominated Biphenyls (PBBs)
1000
PolyBrominated Diphenyl Ethers
(PBDEs)
1000

DRSS-1080 Digital Signal Splitter
Installation and Operation
54BWaste Electrical & Electronic Equipment (WEEE)
Somerdata products may be recycled free of charge in the UK
at any local authority recycling centre as long as the
SomerData logo appears on the product and the following
WEEE producer registration number is quoted:
WEE/HA0074UR/PRO.

DRSS-1080 Digital Signal Splitter
Installation and Operation
Revision History
Issue
Date
Notes
2
July 2011
Part number change, contact address update
1
17 Aug 2007
Initial Issue

DRSS-1080 Digital Signal Splitter
Installation and Operation
CONTENTS
1. INTRODUCTION 1-1
WHAT’S IN THIS USER GUIDE 1-1
USER GUIDE AVAILABILITY 1-2
2. PRODUCT DESCRIPTION 2-1
INTRODUCTION 2-1
1X 8SPLITTER 2-2
3. INPUT/OUTPUT CONNECTIONS 3-1
INTRODUCTION 3-1
SIGNAL INPUT/OUTPUT SIGNAL PATHS 3-2
REAR PANEL 3-3
BNC 3-3
3-PIN IEC 3-3
4. CONTROLS AND INDICATORS 4-1
INTRODUCTION 4-1
FRONT PANEL 4-1
REAR PANEL 4-1
POWER 4-2
SIGNAL 4-2
AC POWER SWITCH 4-2
5. OPERATION 5-1
INTRODUCTION 5-2
SOURCE STREAM 5-3
TERMINATION 5-3
OUTPUTS 5-4
OUTPUT TERMINATION 5-4
6. SPECIFICATIONS 6-1
INPUT STREAM 6-2
SIGNAL INTERFACE 6-2
LINE CODE 6-2
INPUT IMPEDANCE 6-2
SIGNAL AMPLITUDE 6-2

DRSS-1080 Digital Signal Splitter
Installation and Operation
PULSE WIDTH 6-2
INPUT JITTER TOLERANCE 6-2
INPUT ISOLATION 6-2
CONNECTORS 6-2
UN-POWERED PERFORMANCE 6-3
OUTPUT STREAMS 6-4
SIGNAL INTERFACE 6-4
LINE CODE 6-4
OUTPUT IMPEDANCE 6-4
PULSE WIDTH 6-4
OUTPUT JITTER ATTENUATION 6-4
INPUT TO OUTPUT DELAY 6-4
OUTPUT ISOLATION 6-4
CONNECTORS 6-4
PHYSICAL 6-5
CHASSIS 6-5
DIMENSIONS 6-5
WEIGHT 6-5
ENVIRONMENTAL 6-5
TEMPERATURE 6-5
RELATIVE HUMIDITY 6-5
POWER 6-5
SUPPLY 6-5
CONNECTOR 6-5
7. SUPPORT 7-1
IN THIS SECTION 7-1
WHAT TO DO IF YOU HAVE A PROBLEM 7-1
SERVICING,MAINTENANCE AND REPAIRS 7-1
IF YOU NEED SUPPORT 7-2
SOMERDATA CONTACT INFORMATION 7-2
SUPPORT REQUESTS 7-3
RETURNS 7-4
END-OF-LIFE DISPOSAL 7-5
WASTE OF ELECTRICAL &ELECTRONIC EQUIPMENT (WEEE) 7-5

DRSS-1080 Digital Signal Splitter
Installation and Operation
8. INDEX 8-1

DRSS-1080 Digital Signal Splitter
Installation and Operation
This page intentionally blank

DRSS-1080 Digital Signal Splitter
Installation and Operation 1-1
1. INTRODUCTION
In this Section
WHAT’S IN THIS USER GUIDE 1-1
USER GUIDE AVAILABILITY 1-2
What’s in this User Guide
This User Guide covers SomerData’s DRSS-1080/E1SS-1080
Digital Signal Splitter for 2048kbits/s ITU G.703 bitstreams.
Section 2 –PRODUCT DESCRIPTION gives an overview of
your unit’s capabilities and features.
Section 3 –INPUT/OUTPUT CONNECTIONS provides details
of connectors and pinouts.
Section 4 –CONTROLS AND INDICATORS provides details
of connectors and pinouts.
Section 5 –OPERATION describes switch and indicator
functions, signal input / output paths and diagnostics.
Section 6 –SPECIFICATIONS describes the unit’s technical
parameters.
Section 7 –SUPPORT describes the procedure and contact
details for obtaining customer support on this product.
Section 8 –INDEX

DRSS-1080 Digital Signal Splitter
Installation and Operation 1-2
User Guide Availability
Printed copies of Hardware and Software User Guides are
supplied with the original products.
Additional printed copies, including the Programmer’s
Reference Guide can be supplied on request. Please contact
your local supplier or SomerData for ordering details.
Electronic copies (Adobe Acrobat files) are included on the
SomerData CD-ROM that is supplied with the original
products.
The electronic User Guide library, which also includes product
data sheets, can be accessed by browsing the \Documents\
folder for the required document.
Additional and updated copies of the CD-ROM can be
supplied on request. Please contact your local supplier or
SomerData for ordering details.

DRSS-1080 Digital Signal Splitter
Installation and Operation 2-1
2. PRODUCT DESCRIPTION
In this Section
INTRODUCTION 2-1
1X 8SPLITTER 2-2
Introduction
The DRSS/E1SS product range comprises a 1:8 Splitter,
4:1 Switch and programmable 4 x 4 Router for 2048kbits/s ITU
G.703 bitstreams.
Typical applications include the distribution, monitoring and
recording of DAB & DMB Multiplex bitstreams, E1 G.703
bitstream duplication for backup or monitoring..
All DRSS/E1SS models support DAB/DMB ETI and STI
bitstreams that are compatible with ITU G.703.
The units are AC powered and supplied in 1U rackmount
cases.

DRSS-1080 Digital Signal Splitter
Installation and Operation 2-2
1 x 8 Splitter
DRSS/E1SS Splitter provides a means of non-intrusively
monitoring or recording DAB Ensemble Transport Interface
(ETI) bitstreams without loading the original signals.
The source bitstream connection is made through one of two
BNC connectors that are hard-wired in parallel. This means
that the source bitstream passes-through the Splitter without
any in-line curcuitry or delay.
Monitoring and recording equipment can be connected or
disconnected, or power can be removed from the unit, without
disturbing the source bitstream.
Front panel LED indicators provide status display of power
and source stream input signal presence.

DRSS-1080 Digital Signal Splitter
Installation and Operation 3-1
3. INPUT/OUTPUT CONNECTIONS
In this Section
INTRODUCTION 3-1
SIGNAL INPUT/OUTPUT SIGNAL PATHS 3-2
REAR PANEL 3-3
BNC 3-3
Source 3-3
Output 3-3
3-PIN IEC 3-3
Introduction
Input and Output connections are via BNC connectors on the
unit’s rear panel.

DRSS-1080 Digital Signal Splitter
Installation and Operation 3-2
Signal Input/Output Signal Paths
Original Source Stream
Slave Output Streams
G.703 Interfaces
G.703 Interface
Output Connectors
Input and Bypass Connectors
Digital Splitter

DRSS-1080 Digital Signal Splitter
Installation and Operation 3-3
Rear Panel
BNC
Source
Original stream - two connectors allow for a pass-
through connection.
If there is no pass-through connection, the supplied
external 75 Ω terminator must be fitted to the unused
Source connector.
Output
Slave streams - eight identical output streams are
replicas of the Source stream.
3-pin IEC
AC Power

DRSS-1080 Digital Signal Splitter
Installation and Operation 3-4
This page intentionally blank
