Sonance CINEMA TWO SUB SYSTEM User manual

Create the magic of the movie theater experience at home
Sonance Cinema®Series speakers bring THX®-certified movie magic
right into your home, no matter what size your home theater room is.
Regardless of which series you choose, you’ll hear films precisely as
their makers intended them to sound, along with stunningly
realistic-sounding stereo and multi-channel music.
Sonance Cinema®Ultra II Speakers
Sonance Cinema Ultra II Speakers are THX Ultra 2-certified, and
offer the ultimate in performance for both cinema and multi-channel
music applications even in the largest theater rooms. The Cinema
Ultra II LCR and SUR both incorporate a 3-way driver configuration
and low-resonance MDF baffles, and both have a rotating
midrange/tweeter panel that allows horizontal placement while
maintaining their THX-certified performance. Integrated back boxes
maintain that performance in spite of wall cavity variations and
reduce sound spillover into adjacent rooms, and RotoLock®
mounting clamps provide quick, easy installation.
Sonance Cinema Select Speakers
Sonance Cinema Select speakers bring true cinema performance to
those with smaller theater rooms. By incorporating a precise 2-way
driver configuration with low-resonance MDF baffles, Cinema Select
speakers perform just as impressively with music as they do with film
soundtracks. Their small footprint let them practically disappear into
the decor, while their RotoLock mounting clamps make them quick and
easy to install.
Sonance Cinema Cabinet Speakers
Sonance's new Cinema Cabinet LCR speakers offer legendary Sonance
quality and performance to listeners who can’t use Cinema Series
in-wall speakers. By incorporating the same drivers and voicing as
Cinema Ultra II and Cinema Select in-wall LCR speakers, these
THX-certified Cinema Cabinet Speakers can even be mixed-and-
matched with their in-wall counterparts while maintaining the character
and quality of the Sonance sound.
The new enclosure is a key to the Cinema Cabinet speaker's superior
performance. The 1" thick MDF baffle and back panels maintain
ultra-high rigidity and banish resonances. An exclusive laminate made
up of 1/2" MDF and 1/2" particle board maximizes stiffness and
reduces resonances in the top, bottom and side panels.
Sonance Cinema Subwoofers
Sonance Cinema Subwoofers will add the impact and drama that
makes watching movies at home so much fun. When installed in new
construction with the required Cinema TWO.SUB in-wall enclosures,
the THX Ultra-certified Cinema TWO.SUB system produces thunderous
bass performance in even the largest theater rooms. The in-wall
Cinema SUB system brings-home the bass in smaller theater rooms,
while The SUB provides THX Select-certified bass performance in
installations where a stand-alone sub would work best.

Cinema Ultra II
Ultra 2 LCR Ultra 2 SUR Ultra 2 Cabinet
Grille
Grille
Select LCR Select SUR
The Sub
Cinema SUB System
Select Cabinet
Cinema Select
Cinema TWO.SUB System
Cinema SUB
Features
• THX Ultra2 and THX Select certified speakers bring true theater performance to
any size theater room
• Stunningly realistic-sounding performance with stereo and multi-channel music
• RotoLock® mounting system makes in-wall installation quick and easy
(LCR & SUR models only)
• Cabinet models match their in-wall counterparts, allowing mixing-and-matching
while maintaining character and quality of “the Sonance sound”
Accessories
• Cinema TWO.SUB Acoustic Enclosure (Required for the Cinema TWO.SUB System
to achieve THX-certified performance)
• Cinema Ultra II Acoustic Enclosure (For Cinema Ultra II LCR & SUR, and Cinema
Sub System)
• Cinema Ultra II Flexbracket (For Cinema Ultra II LCR & SUR)
• Cinema Select Acoustic Enclosure (For Cinema Select LCR & SUR)
• Cinema Select Flexbracket (For Cinema Select LCR & SUR)

Cinema Select LCR Cabinet
Tweeter: 1" (25mm) Silk dome,
Ferrofluid-cooled, shielded magnet
Woofer: 6-1/2" (165mm) Carbon fiber cone,
rubber surround, shielded magnet
Frequency Response: 80Hz - 20kHz ±3dB
Power Handling: 5 watts minimum;
125 Watts maximum
Impedance: 8Ωnominal; 5Ωminimum
Sensitivity: 90dB SPL (2.83V 1 meter)
Baffle & Back Panel Material: 1” MDF
Top, Bottom & Side Panel Material:
Laminate (1/2” MDF; 1/2” particle board)
Grille Material: Black cloth
Adjustments: ±3dB Tweeter level, boundary
compensation
Dimensions (W x H x D): 7-1/2 x 11" x
11-1/2" (190mm x 279mm x 292mm)
Shipping Weight: 18 lbs. (8.2 KG) each
Sold 1 Each
Cinema Ultra II SUR
Tweeter: Two 3/4" (19mm) Silk domes,
Ferrofluid-cooled
Midrange: Two 3” (76mm) One-piece black
aluminum cones, rubber surrounds
Woofer: 8" (203mm) One-piece black aluminum
cone, rubber surround
Frequency Response: 50Hz - 20kHz ±3dB
Impedance: 6Ωnominal; 4Ωminimum
Power Handling: 5 watts minimum;
200 Watts maximum
Sensitivity: 90dB SPL (2.83V 1 meter)
Grille Material: Perforated aluminum
Adjustments: Rotating midrange/tweeter array
Dimensions (W x H x D): 11-9/16" x 20-1/4" x 3-
7/8" (294mm x 514mm x 98mm)
Cutout Dimensions (W x H): 10-1/4” x
18-3/4” (260mm x 476mm)
Shipping Weight: 29 lbs. (13.2 KG) pair
Sold in Pairs
Cinema Ultra II LCR
Tweeter: 3/4" (19mm) Silk dome,
Ferrofluid-cooled, shielded magnet
Midrange: Two 3” (76mm) One-piece black
aluminum cones, rubber surrounds,
shielded magnets
Woofer: 8" (203mm) One-piece black
aluminum cone, rubber surround,
shielded magnet
Frequency Response: 70Hz - 20kHz ±3dB
Impedance: 6Ωnominal; 4Ωminimum
Power Handling: 5 watts minimum;
200 Watts maximum
Sensitivity: 90dB SPL (2.83V 1 meter)
Grille Material: Perforated aluminum
Adjustments: Rotating midrange/tweeter array
Dimensions (W x H x D): 11-9/16" x 20-1/4" x
3-7/8" (294mm x 514mm x 98mm)
Cutout Dimensions (W x H): 10-1/4” x
18-3/4” (260mm x 476mm)
Shipping Weight: 18 lbs. (8.2 KG) each
Sold 1 Each
Cinema Ultra II
Cinema Ultra II LCR Cabinet
Tweeter: 3/4" (19mm) Silk dome,
Ferrofluid-cooled, shielded magnet
Midrange: Two 3” (76mm) One-piece black
aluminum cones, rubber surrounds,
shielded magnets
Woofer: 8" (203mm) Black aluminum cone,
rubber surround, shielded magnet
Frequency Response: 70Hz - 20kHz ±3dB
Impedance: 6Ωnominal; 4Ωminimum
Power Handling: 5 watts minimum;
200 Watts maximum
Sensitivity: 90dB SPL (2.83V 1 meter)
Baffle & Back Panel Material: 1” MDF
Top, Bottom & Side Panel Material:
Laminate (1/2” MDF; 1/2” particle board)
Grille Material: Black cloth
Adjustments: ±3dB Tweeter level, boundary
compensation, rotating midrange/tweeter array
Dimensions (W x H x D): 10-1/8" x 18-3/8"
x 11-1/2" (257mm x 467mm x 292mm)
Shipping Weight: 35 lbs. (15.9 KG) each
Sold 1 Each
Cinema Select SUR
Tweeter: Two 1" (25mm) Silk domes,
Ferrofluid-cooled
Woofer: 6-1/2" (165mm) Carbon fiber cone,
rubber surround
Frequency Response: 80Hz - 20kHz ±3dB
Impedance: 8Ωnominal; 7Ωminimum
Power Handling: 5 watts minimum;
135 Watts maximum
Sensitivity: 90dB SPL (2.83V 1 meter)
Grille Material: Perforated Aluminum
Adjustments: None
Dimensions (W x H x D): 8-1/4" x 12-3/16" x
3-5/8" (210mm x 310mm x 92mm)
Cutout Dim. (W x H): 6-7/8" x 10-3/4"
(175mm x 273mm)
Shipping Weight: 10 lbs. (4.5 KG) Pair
Sold in Pairs
Cinema Select LCR
Tweeter: 1" (25mm) Silk dome, Ferrofluid-
cooled, shielded magnet
Woofer: 6-1/2" (165mm) Carbon fiber cone,
rubber surround, shielded magnet
Frequency Response: 80Hz - 20kHz ±3dB
Impedance: 8Ωnominal; 5Ωminimum
Power Handling: 5 watts minimum;
135 Watts maximum
Sensitivity: 90dB SPL (2.83V 1 meter)
Grille Material: Perforated aluminum
Adjustments: None
Dimensions (W x H x D): 8-1/4" x 12-3/16" x
3-5/8" (210mm x 310mm x 92mm)
Cutout Dim. (W x H): 6-7/8" x 10-3/4"
(175mm x 273mm)
Shipping Weight: 5 lbs. (2.3 KG) each
Sold 1 Each
Cinema TWO.SUB System
SUBWOOFER PANELS
Woofer: Four 10" (254mm) aluminum cones
(two on each panel) with rubber surrounds,
shielded magnets
Frequency Response: 32Hz - 250Hz ±3dB
Sensitivity: 91dB (2.83V/1 meter)
Grille Material: Perforated Metal
Dimensions (W x H x D, ea. panel): 15" x 26-1/4"
x 5-1/4" (381mm x 667mm x 133mm)
Shipping Weight: 82 lbs (25.4 kg) system
AMPLIFIER
Power (both channels driven): 190 watts
RMS/ch @ 3Ω
Total Harmonic Distortion: <.2% 20Hz - 1kHz
@ 3Ω
Input Impedance: 47k ohms
Power Consumption: 750 watts (625VA)
at full output
Controls: Continuously variable crossover,
0º/180º phase, output level, mode
Dimensions (W x H x D): 16" x 5-3/8" x 12-5/8"
(425mm x 137mm x 321mm)
RMF Dimensions (W x H x D): 19" x 5-1/4" x
12-1/2" (483mm x 133mm x 318mm)
Cinema SUB System
SUBWOOFER PANELS
Woofer: Four 8" (203mm) one-piece black
aluminum cones (two on each panel) with
rubber surrounds
Frequency Response: 35Hz - 150Hz ±3dB
Sensitivity: 91dB (2.83V/1 meter)
Grille Material: Perforated Metal
Dimensions (W x H x D, ea. panel): 11-9/16" x
20-1/4" x 3-7/8" (294mm x 514mm x 98mm)
Cutout Dimensions (W x H): 9-7/8" x 18-1/2"
(251mm x 470mm)
Shipping Weight: 47 lbs (21.3 kg) system
AMPLIFIER
Power (both channels driven): 120 watts RMS/ch
@ 3Ω
Controls: Continuously variable crossover,
0º/180º phase, output level
Dimensions (W x H x D): 16-3/4” x 3-7/8” x
12-1/2” (425mm x 98mm x 318mm)
RMF Dimensions (W x H x D): 19” x 3-1/2” x
12-1/2” (483mm x 89mm x 318mm)
The Sub
Woofer: 12" (305mm) coated paper cone,
rubber surround, video shielded
Frequency Response: 35 Hz - 250 Hz ±3dB
Amplifier Power Output: 150 watts
Crossover: THX Mode; Fixed 250Hz,
12dB/octave; Variable Mode: 45 - 150Hz,
12dB/octave
Input Sensitivity: 170mv for maximum output
Power Consumption: 470 watts at full output
Dimensions (W x H x D): 15" x 19" x 19"
(381mm x 482mm x 482mm)
Space Requirement (W x H x D): 15-1/4" x
19-1/2" x 21-1/8"
(387 x 495 x 537mm) includes space for front
grille, rear heat sink, feet and power cord)
Shipping Weight: 84 lbs (38 kg) each
Cinema Select
Cinema SUB
All Sonance speakers come with a lifetime warranty. (Does not apply to amplifiers.)
For more details download instruction manuals at www.sonance.com

Above photo and cover photo courtesy of Modern Home Systems. www.modernhomesystems.com

212 Avenida Fabricante • San Clemente, CA 92672-7531 • Tel:[phone]•949-492-7777• Fax:[phone]•949-361-5151
©2005 Sonance. Sonance, Sonance Cinema, and RotoLock are registered trademarks. All rights reserved. All other trademarks are trademarks of their respective companies.
All specifications subject to change without notice. 33-3502 03.05
