SONARAY ST-5150 User manual

PRODUCT
MODEL
NUMBER ST-5150 ST-5300
POWER
CONSUMPTION 148W 304W
OPERATING
VOLTAGE 100-277V AC ~ 50/60Hz
HOUSING
MATERIAL Aluminum
OPERATING
TEMPERATURE -40°C ~ +45°C / -40°F ~ +113°F
IP
RATING 65
EPA
RATING 2.21 ft² 2.95 ft²
BUG
RATING B3-U2-G3 B4-U2-G4
WEIGHT 13.09 18.70
DIMENSIONS 20.27 x 13.11 x 3.14 26.96 x 13.11 x 3.54
Shoebox Area Light Installation Guide
ATTENTION
INSTALLATION PREPERATION
1. Take out the luminaire from the box and place it on a level platform for easy installation.
2. For proper operation, a qualied electrician should perform the installation.
3. Ensure the normal ambient temperature of the installation location is between -40°C ~ +45°C.
4. Ensure the voltage of the luminaire is capatable with the onsite voltage before installation.
5. Any luminaire with damaged power cord should not be installed.
Note: The power must be cut off before installation.
LIVE = BLACK
NEUTRAL = WHITE
GROUND = GREEN
TECHNICAL PARAMETERS INSTALLATION DIAGRAM (PC - PHOTOCELL)
1. When the photocell function is required, the photocell should ne installed on the back of the xture. When it’s
not required, a shorting cap will be installed on the back of the lamp.
REV: 21 0101 0000
TYPEDATE
PROJECT
NOTES
www.sonarayled.com
®
©2021 | SONARAY LED LIGHTING HEADQUARTERS | 34 LAKEVIEW COURT VERONA, VA 24482 USA | OFFICE 844.202.5606 | FAX [phone]
This manual instructs the important information of installation and operation. Be sure to strictly follow
the instructions before use. To ensure correct installation and operation of the product, carefully read
and understand all contents of this guide. Any mechanical or electrical modications to the product
will void warranty and may cause dangerous hazards. To avoid potential issues caused by high
temperature, be sure no objects are on the lens while the product is switched on.
GENERAL MAINTENANCE
Make sure there is no power running to the luminaire when performing maintenance.
The lens and the housing can be cleaned using a soft cloth without any corrosive material.
SITUATION POSSIBLE REASON POSSIBLE SOLUTION
LED
DOES NOT
LIGHT UP
Incorrect input wiring Conrm wire colors
No power to the luminaire Recycle power or check power connection
Incorrect voltage Conrm voltage
LED
FLICKER
Poor power connection Check power connection
Input voltage uctation Conrm voltage
TROUBLESHOOTING

3. Loosen the four bolts on the SF bracket, properly connect the wires together, and pull the wires through the pole.
4. Place the bracket on the pole and secure the four bolts to complete the installation.
1. Remove the bracket mounting screws from the xture, open the side lid of the bracket and run the wires through
the bracket. (Figure 3)
2. Install the bracket back onto the xture then cover the side lid and tighten it. (Fixture 4)
Shoebox Area Light Installation Guide
INSTALLATION DIAGRAM (DM - DIRECT MOUNT)
INSTALLATION DIAGRAM (SF - SLIPFITTER MOUNT)
1. Remove the bracket mounting screws from the xture and run the wires through the bracket. (Figure 1)
2. Install the bracket back onto the xture. (Fixture 2)
3. Fix the DM bracket to a sqaure pole or a wall using a bolt. Open the side lid of the bracket and pull the wire
into the junction box and connect the wires correctly, and secure the junction box.
4. Remove the silicon plate if mounting to a round pole.
REV: 21 0101 0000
TYPEDATE
PROJECT
NOTES
www.sonarayled.com
®
©2021 | SONARAY LED LIGHTING HEADQUARTERS | 34 LAKEVIEW COURT VERONA, VA 24482 USA | OFFICE 844.202.5606 | FAX [phone]

1. Remove the bracket mounting screws from the xture and run the wires through the bracket. (Figure 5)
2. Install the bracket back onto the xture. (Fixture 6)
Shoebox Area Light Installation Guide
INSTALLATION DIAGRAM (YM - YOKE MOUNT)
3. Drill holes on the wall as shown below.
4. Fasten the expansion bolts into the wall.
5. Connect the xture to the bracket and tighten the screws. Connect the wires correctly and put them through the
junction box.
