Sonim XP5560 BOLT Installation guide

1
FAQ
GUIDE
SONIM XP5560
BOLT 2
English

2
Copyright © 2013 Sonim Technologies, Inc.
SONIM and the Sonim logo are trademarks of Sonim
Technologies, Inc. Other company and product names
may be trademarks or registered trade-marks of the
respective owners with whom they are associated.
Reference Documentation
For more information about any of the features discussed
in this guide, refer to Sonim XP5560 BOLT 2 user
guide available at http://www.sonimtech.com/support/
downloads.php.

3
Contents
Push-to-talk - General ———————— 4
Managing Alerts———————— 6
Managing PTT Calls———————— 7
Troubleshooting PTT Issues———————— 12
Sonim XP5560 BOLT 2 - Features———————— 14
Sonim XP5560 BOLT 2 - Support———————— 22

4
Push-to-talk - General
What is Push-to-talk (PTT)?
• Push-to-talk (PTT) is a special feature on a mobile
phone that combines the functionality of a walkie-
talkie or 2-way radio with the normal handset
features. It provides simple communication to a
group of people with just a push of a button.
• It allows the customer to instantly reach other PTT
contacts by eliminating the dialing and ringing steps
in a regular cellular call. PTT calls can be made to
one person or to a group of people.
• It is also referred to as Push-to-Talk (PTT).
How does PTT work?
• PTT is based on half-duplex communication (ability
to speak over the same channel but not at the same
time). It uses Voice over internet protocol (VoIP).
• The person who talks, keeps the PTT button
pressed, while others can only listen. Thereafter
the speaker releases the PTT button, and the next
speaker presses the button and starts talking.
• A PTT call will end automatically after approximately
40 secs if no one presses the PTT button. Otherwise
in a two way call, the call will end when one person
hits the end key.
Is PTT number different from my mobile number?
No, the PTT phone number is the same as your 10 digit
mobile number. But this number should be provisioned
by the operator for PTT to work.
Can I turn off the speaker phone for PTT calls?
Yes, You can select one of the following options to turn
off the speaker phone for PTT calls.
1. while on the PTT screen, go to Menu > Settings >
Audio setting > Speaker > Off. After disabling the
speaker,the PTT audio will come over the earpiece.
You can turn on/off the speaker using # key.
2. You can also enable vibrate for incoming call
option, after enabling this option, phone will vibrate
for an incoming PTT call.
What will be the status of the PTT application if I
activate Flight mode?
You will logout of PTT and the presence status will
change to Ofine state. If you try to access PTT, you
will get a “Could not connect, Please try again later”
message.
How many entries are displayed in the Call history
screen?
A maximum of 10 entries and 5 Sub entries are displayed
in the call history screen.
Is PTT secure?
Yes, PTT is secure because only a known device can
access the network and all data is completely encrypted
over a secure HSPA channel.
Can I access my other phone features like regular
voice calls, browser, messaging etc. While in active
PTT Session?
Yes. You can make regular voice calls, access browser,
messaging Only when you are on active Radio group call,
by pushing the Radio group call to background using

5
Push-to-talk - General
back key.
This feature cannot be enabled for 1-1 PTT
call/ad-hoc group call/personal group call/
conference group call.
What are PTT contacts?
Contacts which can be provisioned in PTT server are
PTT contacts.PTT contacts are different from your phone
address book.
How many PTT contacts can I have in my PTT
Contact list?
• A PTT subscriber can have Max 1024 contacts in
PTT contact list.
• You can have maximum 40 groups.
The maximum number of supported contacts
depends on the software conguration.
Can I delete all PTT contacts at a time?
No, you have to delete contacts individually.
Can we turn off the chirp notication sound, when we
release the PTT button?
Yes, you can control the PTT tones from the PTT settings,
by enabling Silent SOS. Select PTT settings > Silent
SOS > Enable, to activate Silent SOS.
How does Auto-start function work?
When Auto-start feature is enabled, you will be
automatically logged in to PTT when the phone is
switched ON/Switch from Flight mode to Normal mode.
If auto-start is disabled, you must manually login to PTT
when the phone is switched ON/Switch from Flight mode
to Normal mode.

6
What is an Send Alert?
The Send Alert feature allows you to send an alert to an
individual PTT contact, and request them to call back.
• You can send an Alert only to PTT contacts in
Available state.
• You can send alerts only to a single contact and
cannot be sent to a group.
• You can send an alert if you are in Busy state. But
the receiver will not be able to call you back.
How do I send an alert?
You can send an alert using one of the following ways:
1. Highlight a contact either in the PTT call history
screen / PTT Contacts screen/ groups or from
current call screen > select Actions and and press
the Alert soft key to send an alert.
2. Highlight any contact and press send key(Green
key).
How do I respond to an alert?
• When you receive an alert, press and hold the LSK
key (Yes) to initiate a PTT call to the sender.
• Press the RSK key (No) to dismiss or discard the
alert.
How can we respond to an incoming alert, when the
keypad is locked?
You can ignore or call back to the incoming alert, when
the keypad is locked.
1. Click LSK key (Yes) to place a PTT call to sender.
2. Click RSK key (No) to dismiss or ignore the alert.
Managing Alerts

7
Managing PTT Calls
How do I activate PTT in my XP5560 BOLT 2?
PTT service must be initialized on your phone, before
making PTT calls.
When you switch ON the phone , for the rst time, you
can activate your PTT service by either :
1. Select Menu > TELUS Link.
OR
Simply press the Push-to-talk button on the left
side of your phone.
2. Once registered, Contact list is displayed. A Green
Icon is displayed at the top left corner of the home
screen and the PTT service is enabled. The PTT
service will retrieve all the existing PTT contacts and
groups.
How do I disable the PTT button?
To disable PTT launch from left side button,
1. Logout of the PTT application.
2. Select Menu > Settings > Dedicated key > PTT
Button > select Off.
How to make a PTT call?
To dial a PTT call,
1. Select the contact/group from PTT contacts/PTT
groups, or from the call history.
2. Press and hold the PTT button.
3. Continue to hold the PTT button to aquire oor and
speak.
4. Release the PTT button when you nish speaking.
5. To end the call, press End Call (LSK) key or End
key.
What is one-to-one PTT call?
This is a simple PTT session where just one caller and
one recipient are involved in the conversation.
What is an ad-hoc group call?
You can quickly make a single call to many contacts in
the PTT Contacts list. You can initiate a ad-hoc group call
to maximum of 10 online contacts.
How do I block PTT calls to my phone?
If you wish to completely block incoming PTT calls,
change your presence status to Busy.
Can I receive and intiate a cellular call while in active
PTT call?
You can receive a cellular call only while on an active
radio group call.
If You accept cellular call PTT call will disconnect.
You cannot initiate a cellular call when you are
on 1-1 PTT call/Personal/conference/ad-hoc
calls.
Will I receive PTT call while in active cellular call?
You will not receive PTT calls, while in active cellular call.
Once the cellular call ends, a PTT Missed call alert will be
displayed to notify the user.

8
Managing PTT Calls
How long can I talk over PTT call?
During a PTT call, you can speak continuously for a
maximum of 90 seconds.Floor will release automatically
after 90 seconds. You have to press the PTT button again
to continue speaking.
The maximum talk duration for speaking
continuously and the maximum duration for a
single PTT session are server congured.
Why does a PTT call get disconnected automatically?
When the PTT call is established and none of the users
speaks until oor idle time expires i.e 40 seconds, the
call will get disconnected automatically. Floor idle time is
server congured.
How to speak when connected to a Wired Headset?
When connected to a wired headset, you should use
the PTT button on the phone and the microphone of the
wired headset to speak.
If a PTT wired headset is used, then the PTT oor can be
taken and released using the button in the wired headset.
How can I adjust the tone volume while on a PTT/
voice call?
While on a PTT call but you are not speaking, press the
side volume button to adjust the volume accordingly. You
can also adjust the volume by selecting Menu > Settings
> Audio settings > Tone volume while in PTT idle state.
Can we set customized alerts for missed PTT calls?
Sonim XP5560 BOLT 2 does not support customized
alerts for missed PTT calls. You can use only the default
tones.
Can we send group PTT alerts?
Sonim XP5560 BOLT 2 does not support group PTT
alerts.
How can we notify a person about missed calls when
they are on a GSM call?
The missed call symbol ( ) will be displayed next to
the PTT icon ( ), when there is a missed call during a
cellular call.
Can we use the PTT button to initiate a PTT call, when
the keypad is locked?
The phone keypad lock must be unlocked to initiate a
PTT call using the PTT button.
Can I make regular voice calls to PTT contacts?
No, you cannot make regular voice calls to PTT contacts
from PTT contact list.
Can I make regular voice calls to received alerts?
No, you cannot dial regular voice calls to received alerts.
Can I view PTT contacts/Groups in native
phonebook?
No, you canot view PTT contacts/groups from native
phone book.
Are PTT events part of native call history?

9
Managing PTT Calls
No PTT events are not a part of native call history.
Can I set any key as a PTT button?
No, you can use only keys that are the dedicated for PTT
operations.
Can I play media le or FM radio during PTT call?
No, you cannot perform any native phone operations
while in PTT call.
Can I send message to PTT contacts?
Yes, you can send the messages to PTT contacts using
one of the following options.
• Highlight or mark contact from PTT contact list/
history/ group, select Actions > Send message.
• Select PTT > Message tab > Actions > New
Text Chat, select a contact to compose and send
message.
Can I receive a PTT call during operation with other
phone applications?
Yes, you can receive all PTT calls and notications while
user is busy in other phone applications.
Can I take oor using Bluetooth headset?
Yes, if you are using PTT Bluetooth headset, then you
can take a oor using PTT button in Bluetooth headset.
Can I set different tone other than default one to PTT
call?
No, you cannot change the tone.
Can I turn off the Bluetooth as a audio source?
Yes When bluetooth accessories is connected to the
phone, PTT audio will will be routed to the bluetooth
accessories. When bluetooth accessories is switched
off/disconnected, PTT audio will be routed through the
phone speaker.
Can I view the Presence status of the PTT contact
from the Native phone book ?
No, you cannot view the presence status of the PTT
contacts from native phone book.
Can I make a PTT call from the native phonebook to
PTT contacts if the PTT application is logged out?
No, you cannot make PTT calls while in logged out state.
Is it possible to forward/ignore cellular calls during a
PTT call?
Yes, You can ignore/forward a cellular call. The call will
automatically forward to the selected number.
To set the phone number for call forwarding, select Native
phone Menu > Calls > Call settings > Call forwarding
> forword if no answer/forword if busy > Activate >
Choose number to whom you want to forward the
cellular call > save.
GSM call is highest priority , if you accept GSM call on
top of PTT call, PTT call will be disconnected. If you
ignore the voice call, PTT call will continue.
By default the option is disabled.

10
Managing PTT Calls
Can I get another PTT call while in PTT call?
Yes, you can initiate/receive another PTT call only when
you are in active Radio group call.
This is not applicable for 1-1 PTT call/ad-hoc
group call/personal group call/conference
group call.
What PTT operations can I perform, when my
presence status is set to Busy?
You can perform the following operations if your presence
status is set to Busy:
• Initiate PTT call. After initiating the PTT call,
presence status will be changed to available.
• Send/receive messages.
• Send alerts.
Presence status will be changed to Busy, when user
activate meeting/silent prole.
What PTT operations can I perform, when I am on a
radio group call?
You can perform the following operations if your are on a
radio group call:
• Push the Radio group call to background. You can
initiate 1-1 PTT call,personal, and conference group
call.
• Access the any other menu during ongoing PTT call.
• Cannot take the oor, atleast 1 member should exist
in the Radio group call.
• Send alerts.
What PTT operations can I perform, when I am in
current call tab?
You can perform the following operations when you are in
current call tab:
• Send message to any user.
• Add contact to the contact list.
• Manage contacts and groups.
• Send alerts to any contact.
What PTT operations can I perform during a PTT call?
You can do following operations during PTT call
• Navigate to contacts, groups and instant messages
tab
• Send instant message
• Send alerts
• Add Contact
You cannot receive PTT call if other user acknowledge
yes for Alert,instead you will get missed call
Can I disable the continuous beep tones, when
received alerts are ignored?
Yes, you can disable the alert time out tone. Select Call
logs > Missed alert > and highlight the entry.
What will happen if I enable Silent SOS feature?
After enabling silent SOS, all the tones (PTT incoming
alert tone,oor control tone,error tone) will be played in

11
Managing PTT Calls
phone earpiece.
What is Alert Me mode?
If You set MY presence as Alert Me, you will be Notied
whether to accept or reject the PTT call.
To set Alert Me mode, select PTT > Menu > Mystatus >
My presence, select Alert Me and click LSK.
Can I send instant messages to Groups?
Yes, you can send instant messages to Radio and
Conference groups.
To send IM’s to Radio/Conf groups, select PTT > Groups
> Conf/Radio groups > Actions > Send message to,
compose and send message.
You cannot send instant messages to personal
groups.

12
Troubleshooting PTT Issues
I can’t make a PTT call.
• Subscription to PTT Services: You can access
PTT services only if you subscribe to PTT services
from the carrier. Contact your operator for more
information.
• Check for coverage: You must be within the
network coverage area to make a PTT call. Check
your idle screen to ensure you have a radio signal
( ).
• Check your status: If you see a red icon ( ) in
the upper left corner of the screen, PTT is turned off.
To change your status to Available, press the PTT
button. Login screen will appear. Select OK to login.
The red icon will turn into green icon ( ) when the
login is successful. You can now make PTT calls.
I am not receiving PTT calls.
• Your presence may be set to Busy ( ). If your
presence is set to Busy, indicated by a red icon (
) you will not receive PTT calls. Change the presence
to available by selecting Menu > TELUS Link >
menu > my presence > available > Ok.
• The phone prole should not be set to meeting/
silent. Change the phone prole.
I can’t hear PTT calls.
The speaker phone might have turned off and the voice
is routed through the phone earpiece. Please turn the
speaker back ON to hear PTT calls via loudspeaker. Turn
on the speaker by pressing the # key or select Menu >
TELUS Link > Settings > Audio settings > Speaker >
on.
The phone might be in meeting/silent mode. Disable
meeting/silent mode.
People cannot hear me on their PTT phone.
Remember to press and hold the PTT button and begin
speaking after an audibe tone. You should speak directly
into the phone’s microphone in a normal voice. Release
the PTT button only after you have nished speaking.
I am not able to add new contacts or groups.
• Check if you are logged in to PTT service. Then,
complete one of the following options:
• Press Menu > Add new contact > Add
contact by name and search the contact by
name.
• b) Press Menu > Add new contact > Add
contact by number and search the contact by
number.
• Check if you are trying to add contact to public
groups( Radio and conference group). You can
not add/edit/remove the public groups as they are
server created groups.
Some of the members in ‘group member screen’ have
a different icon. What do they indicate?
These icons indicate the following presence status of the
PTT contacts.
• Ofine user -
• Available user -
• Alert me user -
• Busy user -

13
Sonim XP5560 BOLT 2 - Features
What frequency bands does the Sonim XP5560 BOLT
2 work with?
The Sonim XP5560 BOLT 2 supports 3G: UMTS: BC1
(2100), BC2 (1900), BC5 (850) and 2G GSM 850, GSM
900, DCS 1800 and PCS 1900 bands.
Does the Sonim XP5560 BOLT 2 support micro SD
slots?
The Sonim XP5560 BOLT 2 includes a micro SD slot
located next to SIM card slot, and supports up to 16
GB of extended memory. The SD card slot is behind the
battery. You have to remove the battery and insert the
card. You can access the SD card contents from My Files
> Memory Card.
What are the two small buttons on the right side of my
Sonim XP5560 BOLT 2 for?
The two small buttons on the right side of the Sonim
XP5560 BOLT 2 are used to adjust the volume while in a
phone call and while playing audio/video les.
Can I make IP calls from my Sonim XP5560 BOLT 2?
The Sonim XP5560 BOLT 2 does not support IP calls.
How can I activate the browser features on my Sonim
XP5560 BOLT 2?
Pre-dened settings are congured in Software for
operators. You cannot edit these operator settings.
Contact your operator for more information.
How can I activate the MMS features on my Sonim
XP5560 BOLT 2?
Internet settings are already pre-dened and congured.
You cannot edit these operator settings. Contact your
operator for more information.
Can you help me congure e-mail on my Sonim
XP5560 BOLT 2?
The Sonim XP5560 BOLT 2 supports POP3/SMTP and
IMAP. For Gmail, Yahoo, Hotmail pre-congured settings
are available. This can be accessed with just User name
& password.
If user wants to congure any other accounts they have
to congure and create an e-mail account to access the
e-mail functionality on your Sonim XP5560 BOLT 2.
The Sonim XP5560 BOLT 2 does not support
Active Sync.
Why do I receive a certicate error, while retrieving/
sending e-mail?
When certicate for an account is not installed in the
phone, you will get an error. You can install the required
certicate using the following steps.
1. In the certicate error screen, select Options or
press the center Menu key.
Certicate installation screen to install the new
certicate is displayed.
2. Select Install > OK.
3. Enter a certicate Label name in the editor.
Certicate label is a unique user-dened name for
the new certicate. You can enter any name, to
identify the certicate, easily.

14
Sonim XP5560 BOLT 2 Features
Example: yahoocert1
4. Select Options > Done.
The message “Certicate imported” is displayed,
when the certicate is installed successfully.
Which audio and image formats does my Sonim
XP5560 BOLT 2 support?
The Sonim XP5560 BOLT 2 supports the audio formats
.mp3/.wav/.amr/.aac and the image formats .jpg/.bmp/.
gif.
Will Bluetooth connections remain active once a
wired headset is inserted into my Sonim XP5560 BOLT
2?
The Bluetooth connection will be active when you insert
a wired headset. But the audio routing will depend on the
bluetooth headset.
Why do I get a message “enter NP code”, after
inserting the SIM card?
Your phone may be locked to a specic operator. Contact
the phone operator for assistance.
How can I download pictures and ring tones to my
Sonim XP5560 BOLT 2?
You can download pictures and ring tones through the
browser. If your Sonim XP5560 BOLT 2 is Bluetooth
enabled, the pictures and ring tones can be transferred
from another Bluetooth-enabled device. You can also
receive the pictures and ring tones through MMS.
How do I activate the loudspeaker on my Sonim
XP5560 BOLT 2?
To activate the loudspeaker when you are on a call, press
H-Free on the screen or press the center Menu key
during the call to toggle between normal and hands-free
mode.
How do I activate the vibrate feature on my Sonim
XP5560 BOLT 2?
To activate the vibrate feature on the Sonim XP5560
BOLT 2 phone:
1. Long press the # key to toggle between Normal and
Meeting modes on the idle screen.
Or select Menu > Settings > Proles > General >
Customize > Alert type.
2. Select one of the following alert types: Ring only,
Vibrate only, Vibrate and ring, or Vibrate then ring
Once vibrate option is activated, vibrate icon is displayed
on idle screen.
Where can I nd the les transferred to my Sonim
XP5560 BOLT 2?
To access the transferred les, select Menu > My les.
Select the required folder from the File manager screen.
How should I activate the Bluetooth connection?
To activate the Bluetooth, select Menu > Settings >
Connectivity tab > Bluetooth > Power > On.
Does my phone ring when connected to a wired

15
Sonim XP5560 Phone Features
headset?
When a wired headset is connected, the ring tone is
heard in both the phone speaker and wired headset.
Does my phone ring when connected to a Bluetooth
headset?
When a Bluetooth headset is connected, the ring tone is
heard in both the phone speaker and Bluetooth headset.
Can I assign ring tones to specic groups on my
Sonim XP5560 BOLT 2?
You can assign ringtones to specic groups by selecting
Menu > Phonebook > Options > Caller groups > Group
settings > Group ringtone.
How can I adjust the number of rings before the call is
forwarded?
There is no feature to set the number of rings before the
call is forwarded.
How do I change the ring tone volume on my Sonim
XP5560 BOLT 2?
To set the ring tone volume in the Sonim XP5560 BOLT
2, select Menu >Settings > Proles > General >
Customize > Volume > Ringtone.
Can I transfer contact information over Bluetooth
possible with the Sonim XP5560 BOLT 2?
Single and Multiple contacts can be transferred via
Bluetooth.
How do I switch the LED torch ON on my Sonim
XP5560 BOLT 2?
To turn on the torch, press and hold key “5” of the phone.
Press and hold the button again to turn off the torch. The
torch will work only if the phone is in idle screen mode.
How do I set up battery alerts for my Sonim XP5560
BOLT 2?
To set a Battery alert, select Menu > Settings >Proles
> Customize > Extra tone > Warning.
How do I set the voice mail number in the Sonim
XP5560 BOLT 2?
To set the voice mail number, select Menu > Messages >
Message settings > Text message > Voicemail server
> Options > Edit. Enter the voice mail number provided
by your operator.
You can also long press the number key 1 to access the
voice mail.
How can I listen to the voice mail using my Sonim
XP5560 BOLT 2?
To listen to the voicemail, select Menu > Messages >
Message settings > Text message > Voicemail server
> Options > Call voice mail > OK.
You can also long press the number key 1 to access the
voice mail.
How can I listen to recorded audio les on my Sonim
XP5560 BOLT 2?

16
Sonim XP5560 BOLT 2 Features
To listen to the recorded audio les, select Menu >
My les > Phone or Memory card > Audio. Select
the required audio le. The speaker is turned on
automatically, and you can hear the record.
How do I dial the international prex “+” on my Sonim
XP5560 BOLT 2?
Press and hold the number key 0 until the + symbol is
displayed.
Where do I nd information on the features and user
guide of my Sonim XP5560 BOLT 2?
The Sonim XP5560 BOLT 2 features are available on our
web sites http://www.sonimtech.com/products/.
What are MIL Specs and IP Ratings?
MIL Specs and Ingress Protection Ratings are an
indicator for the ruggedness of a device. The Sonim
XP5560 BOLT 2 exceeds MIL-Spec 810G and is IP-68
certied. For more information, refer http://en.wikipedia.
org/wiki/MIL-STD-810 and http://en.wikipedia.org/wiki/
IP_Code.
Where can I get more software (Java applications) for
Sonim XP5560 BOLT 2?
You can download additional Java applications
downloaded & installed with the Web browser. You can
also install Java les directly from the folder My Files >
Java on the phone or on the memory card.”
How can I use the text reader function?
The text reader can conveniently display regular text les
(*.txt) located in My Files > Other on the phone or on the
memory card.
What is safeguard? How do we enable this feature in
the phone?
Safeguard allows to set a password and prevent
unauthorized usage of keypad, messages, phonebook,
call history, browser, modify auto start, modify
phonebook, restore factory settings, restrict calls options
and my les of your phone.
Select Menu > Settings > Security settings >
Safeguard > On. Input password message pops up.
Enter the password. Select OK.
After this is set, everytime the particular option for which
safeguard set is accessed, you will be requested to
enter the password. If the password is wrong you cannot
access the phone.
To activate the safeguard protection for accessing the
messages, phonebook, call history, my les, keypad,
modify autostart, modify phonebook, restore factory
settings and restrict calls options in your phone, select
Menu > Settings > Security settings > Safeguard >
On. Select Activation and select the required option to be
protected.
To change the safeguard password, select Menu >
Settings > Security settings > Safeguard > Change
safeguard password. Enter the old password and
the new password. Re-enter the new password for
conrmation and select OK.
The default password for safeguard is 1234.
Can I tether my XP5560 BOLT 2 for Internet access?
The Sonim XP5560 BOLT 2 supports tethering. Wireless
dial -up connection can be created on your laptop/
computer.

17
Does the Sonim XP5560 BOLT 2 supports roaming,
How does 3G Roaming work? (Canada and the US)
The Sonim XP5560 BOLT 2 supports roaming in areas
outside your network carrier’s coverage. Roaming may
incur additional fees. For more information contact your
network operator.
The phone will automatically connect to the local network
based on operator agreements, when Network Selection
is set to Automatic. If the automatic connection is not
successful, user can manually search available networks
and connect to valid network( Menu > Settings >
Network settings > Network selection > Selection
mode > Manual > Select network).
Does the Sonim XP5560 BOLT 2 support voice dialing
or voice commands?
The Sonim XP5560 BOLT 2 does not support voice
dialing/voice commands.
Can I sync my phone book to my Bluetooth Car Kit?
The Sonim XP5560 BOLT 2 supports the Bluetooth
protocol for synchronizing the phone book between
handset and car kit.
Can we change the display font size in XP5560 BOLT
2?
The display font size is xed and you cannot change it.
How can we assign a shortcut key to a custom built
application?
You cannot assign a shortcut key to a custom built
application. This feature is not supported.
How do you enable the Speed dial option?
To enable the Speed dial, select Menu > Settings >
Phone settings > Dedicated key > Speed dial > ON.
Is recent recipient list option present to send SMS/
MMS?
This feature is not supported.
Will the Voice mail icon get updated automatically if
there is more than one Voice mail?
No. The Voice mail icon is a small envelope icon with
numeric one. The icon will remain the same, irrespective
of the number of Voice mails received.
Will the Bluetooth Headset get connected
automatically to the phone after the message ‘Allow
this device to connect automatically?’ is popped up?
No, the Bluetooth Headset is not connected to the device
automatically. You have to manually connect the headset
for the rst time.
Does the media player pause automatically when
disconnecting the Bluetooth headset or wired
headset?
No, the media player is not paused automatically when
disconnecting the Bluetooth headset or wired headset.
Can I access the browser during an active call?
You cannot access the browser during an active call.
Can I hear the alert for incoming call, SMS and MMS
Sonim XP5560 BOLT 2 Features

18
Sonim XP5560 BOLT 2 - Features
in Meeting and Silent Prole when Bluetooth Headset
is connected?
This depends on the Bluetooth headsets. Some
headsets provide the alert for Incoming call, SMS and
MMS in Meeting and Silent proles when the headset is
connected.
Can I send a vCard from my Sonim XP5560 BOLT 2?
You can send a vCard via Bluetooth/MMS.
Is it possible to send an SMS/MMS to a group?
You can send SMS/MMS to a group.
How do I enable/disable the T9 dictionary on my
Sonim XP5560 BOLT 2?
While writing a message, long press the # key to activate/
deactivate the T9 dictionary.
Can I set the message storage location?
You can set the message storage location to SIM or
phone.
1. Select Menu > Messages > Message Settings.
2. Select the type of message service (Text message or
Multimedia message). You can view all the settings
related to the message Storage location.
How to save sent messages?
To save the Sent messages,
1. Select Menu > Messages > Message Settings.
2. Select the type of message service (Text message or
Multimedia message). You can view all the settings
related to the message Storage location.
How can I enable/disable Read status report for sent
messages?
1. Select Menu > Messages > Message Settings.
2. Select the type of message service (Multimedia
message).
3. Select Common settings > Sending > Read report
> On/Off.
How can I backup and restore contacts via SD Card?
To backup contacts:
1. Go to Contacts > Options > Mark several >
Mark the contacts to be backed up > Options >
Backup contacts > Yes > Select the location in
Memory card to save back up le > Give a name
> Done.
The backed up contact list is saved in .UDX format
in selected location
To restore the backed up contacts:
1. Go to My les and select the .UDX le that was
created while taking backup.
2. Go to Options > Use as > Restore Contacts >
Restore contacts > Mark vCard(Press CSK) > OK.
The contacts present in the selected UDX le are
restored to Phone memory.

19
Sonim XP5560 BOLT 2 - Features
• Contacts cannot be restored to SIM
memory.
• When only Name and Number elds
are lled for the contacts, the same are
backed up and restored successfully.
How can I toggle between upper case letters (ABC)
and lower case letters (abc) on my Sonim XP5560
BOLT 2?
While writing a message, press the # key to switch
between upper and lower case letters.
How many characters does my Sonim XP5560 BOLT 2
support in a message?
This supports characters as per 3GPP. You can enter
upto 160 characters in a single message. However, if
the message contains unicode text, the message size is
reduced accordingly.
Does Sonim XP5560 BOLT 2 support multi-part SMS?
The phone supports multi-part SMS up to 8 pages and
1224 characters .
Page Character Limit
1 160
2 146
3-8 153 in each page
Pictures sent as MMS attachments to other phones
are degraded. How can we reduce the picture size
when sending a MMS?
To maintain the picture quality, disable picture resizing in
multimedia settings. Go to Menu> Messages> Message
settings> Multimedia message> Common settings>
Compose> Picture resizing > off.
Can we change the SMS font size?
You cannot change the SMS font size. This feature is not
supported.
What is the simpler way to navigate between multiple
messages?
No. You cannot directly navigate between multiple
messages. This is not supported.
Can I receive delivery report for sent SMS messages?
No. This feature is not supported
Can I check for software upgrades required for Sonim
XP5560 BOLT 2?
No. Software upgrades will be intitated by the service
provider.
How will I know about any software upgrade
notication sent by the service provider?
You will get a notication prompt to download the
software and steps to upgrade.
Ensure that the phone battery is not low on
charge and data account is enabled.

20
Sonim XP5560 BOLT 2 - Features
Will the user data stored in the phone get lost after
the software upgrade?
No, the user data will not be deleted after the software
upgrade.
After downloading the software can I defer the
upgrade process?
Yes, after download the you have the option to defer the
upgrade process.
How does Use Bluetooth for audio feature work?
When Use Bluetooth for audio is enabled, the audio will
be played through a paired Bluetooth device.
When disabled, the audio will be played through phone
loudspeaker.
By default, Use Bluetooth for audio is enabled.
