BDP-S1
3-275-197-11(1)
© 2007 Sony Corporation
BDP-S1 supports Dolby TrueHD and Dolby Digital Plus decoding which is not noted in operating
instruction.
Please refer to this sheet for audio output signals.
About the audio output signals
The audio output differs as follows, depending on the source, output jack, and the selected settings.
*1“2 Channel” and “5.1 Channel” are selectable under “Audio Output Mode” in “Speakers” Setup.
*2PCM : when “Dolby Digital” or “DTS” in “Audio Setup” is set to “Downmix PCM.”
Bitstream : when “Dolby Digital” or “DTS” in “Audio Setup” is set to “Dolby Digital” or “DTS.”
*3Selectable under “Audio (HDMI)” in “Audio Setup.”
*4Selectable under “Audio (HDMI)” in “Audio Setup.” Resulting output may differ depending on the connected HDMI device.
*5When the sampling frequency is 192 kHz, the player downmixes to 2ch signals even if the disc or source is 5.1ch.
*6Outputs 7.1ch LPCM signals decoded from Dolby Digital Plus audio stream.
*7Outputs 7.1ch LPCM signals decoded from Dolby True HD audio stream.
The player outputs up to 7.1ch LPCM when the source sampling frequency is 48 kHz; up to 5.1ch at 96 kHz; up to 2ch at 192 kHz.
Dolby and the double-D symbol are trademarks of Dolby Laboratories.
“DTS” and “DTS Digital Surround” are registered trademarks of DTS, Inc.
AUDIO OUT L/R jacks*1DIGITAL OUT (OPTICAL/
COAXIAL) jacks*2HDMI OUT jack*3
2ch 5.1ch PCM Bitstream PCM*4Auto*4
BD-
ROM Linear PCM 2ch 2ch 2ch 2ch LPCM 2ch LPCM 2ch LPCM 2ch LPCM
5.1ch
*
5
2ch Downmix 5.1ch 2ch Downmix
LPCM
2ch Downmix
LPCM 5.1ch LPCM 5.1ch LPCM
7.1ch 2ch Downmix 5.1ch
Downmix
2ch Downmix
LPCM
2ch Downmix
LPCM 7.1ch LPCM 7.1ch LPCM
Dolby Digital 2ch Downmix 5.1ch 2ch Downmix
LPCM Dolby Digital 5.1ch LPCM Dolby Digital
Dolby Digital Plus 2ch Downmix 5.1ch 2ch Downmix
LPCM Dolby Digital 7.1ch LPCM*6Dolby Digital
Dolby TrueHD 2ch Downmix 5.1ch 2ch Downmix
LPCM Dolby Digital 7.1ch LPCM*7Dolby Digital
DTS 2ch Downmix 5.1ch 2ch Downmix
LPCM DTS 5.1ch LPCM DTS
DTS-HD 2ch Downmix 5.1ch 2ch Downmix
LPCM DTS 5.1ch LPCM DTS
DVD Linear PCM 2ch 2ch 2ch LPCM 2ch LPCM 2ch LPCM 2ch LPCM
Dolby Digital 2ch Downmix 5.1ch 2ch Downmix
LPCM Dolby Digital 5.1ch LPCM Dolby Digital
DTS 2ch Downmix 5.1ch 2ch Downmix
LPCM DTS 5.1ch LPCM DTS
Jacks/
settings
Disc/source
