SERVICE MANUAL
LEVEL 2
• For ADJUSTMENTS (SECTION 6), refer to SERVICE MANUAL, ADJ (987672851.pdf).
• For INSTRUCTION MANUAL, refer to SERVICE MANUAL, LEVEL 1 (987672841.pdf).
• For MECHANISM ADJUSTMENTS, refer to the “DV MECHANICAL ADJUSTMENT MANUAL
Z (Z200) MECHANISM ”(9-876-724-11) .
•Reference number search on printed wiring boards is available.
•TO TAKE OUT A CASSETTE WHEN NOT EJECT (FORCE EJECT)
Link
SERVICE NOTE
DISASSEMBLY
BLOCK DIAGRAMS
FRAME SCHEMATIC DIAGRAMS
SCHEMATIC DIAGRAMS
PRINTED WIRING BOARDS
REPAIR PARTS LIST
SPECIFICATIONS
SERVICE NOTE
DISASSEMBLY
BLOCK DIAGRAMS
FRAME SCHEMATIC DIAGRAMS
SCHEMATIC DIAGRAMS
PRINTED WIRING BOARDS
REPAIR PARTS LIST
SPECIFICATIONS
Link
Revision History
Revision History
On the VC-359 board
This service manual provides the information that is premised the circuit board replacement service and not intended repair
inside the VC-359 board.
Therefore, schematic diagram, printed wiring board, waveforms, mounted parts location and electrical parts list of the VC-359
board are not shown.
The following pages are not shown.
Mounted parts location ............................. Pages 4-99 to 4-100
Electrical parts list................................... Pages 5-19 to 5-27
How to use
Acrobat Reader
How to use
Acrobat Reader
Schematic diagram .............................Pages 4-27 to 4-68
Printed wiring board............................Pages 4-93 to 4-96
DCR-HC65
RMT-831
DCR-HC65
US Model
Canadian Model
E Model
Korean Model
DIGITAL VIDEO CAMERA RECORDER
Ver 1.0 2004. 03
Z (Z200) MECHANISM

—2 —
DCR-HC65
SPECIFICATIONS
Video camera recorder
System
Video recording system
2 rotary heads, Helical scanning system
Still image recording system
Exif Ver. 2.2 *1
*1 “Exif” is a file format for still images,
established by the JEITA (Japan Electronics
and Information Technology Industries
Association). Files in this format can have
additional information such as your
camcorder’s setting information at the time of
recording.
Audio recording system
Rotary heads, PCM system
Quantization:12 bits (Fs 32 kHz, stereo 1,
stereo 2), 16 bits (Fs 48 kHz, stereo)
Video signal
NTSC color, EIA standards
Usable cassette
Mini DV cassette with the mark
printed
Tape speed
SP: Approx. 18.81 mm/s
LP: Approx. 12.56 mm/s
Recording/playback time (using a DVM60
cassette)
SP: 60 min
LP: 90 min
Fast forward/rewind time (using a DVM60
cassette)
Approx. 2 min 40 sec
Viewfinder
Electric viewfinder (color)
Image device
3.6 mm (1/5 type) CCD (Charge Coupled
Device)
Gross: Approx. 1 070 000 pixels
Effective (still): Approx. 1 000 000 pixels
Effective (movie): Approx. 690 000 pixels
LensCarl Zeiss Vario-Tessar
Combined power zoom lens
Filter diameter: 30 mm (1 3/16 in.)
10 × (Optical), 120 × (Digital)
F = 1.8 ~ 2.3
Focal length
3.2 - 32 mm (5/32 - 1 5/16 in.)
When converted to a 35 mm still camera
In CAMERA-TAPE:
46 - 460 mm (1 13/16 - 18 1/8 in.)
In CAMERA-MEMORY:
38 - 380 mm (1 1/2 - 15 in.)
Color temperature
[AUTO], [ONE PUSH], [INDOOR]
(3 200 K), [OUTDOOR] (5 800 K)
Minimum illumination
7 1x (lux) (F 1.8)
0 lx (lux) (during NightShot plus function)*
* Objects unable to be seen due to the dark can be
shot with infrared lighting.
Input/Output connectors
Audio/Video input/output
10-pin connector
Input/output auto switch
Video signal: 1 Vp-p, 75 Ω (ohms),
unbalanced
Luminance signal: 1 Vp-p, 75 Ω(ohms),
unbalanced
Chrominance signal: 0.286 Vp-p, 75 Ω
(ohms), unbalanced
Audio signal: 327 mV (at output impedance
more than 47 kΩ(kilohms)), Input impedance
more than 47 kΩ(kilohms),Output impedance
with less than 2.2 kΩ(kilohms)
DV input/output
4-pin connector
Headphone jack
Stereo minijack (Ø3.5 mm)
LANC jack
Stereo mini-minijack(Ø2.5 mm)
USB jack
mini-B
MIC jack
Minijack, 0.388 mV low impedance with DC
2.5 to 3.0 V, output impedance 6.8 kΩ
(kilohms) (Ø3.5 mm), Stereo type
LCD screen
8.8 cm (3.5 type)
Total dot number
123 200 (560 ×220)
General
Power requirements
DC 7.2 V (battery pack)
DC 8.4 V (AC Adaptor)
Average power consumption (when using the
battery pack)
During camera recording using the viewfinder
2.7 W
During camera recording using the LCD
3.8 W
Operating temperature
0°C to 40°C (32°F to 104°F)
Storage temperature
-20°C to + 60°C (-4°F to + 140°F)
Dimensions (approx.)
68 ×89 ×172 mm (2 3/4 ×3 5/8 ×6 7/8 in.)
(w/h/d)
Mass (approx.)
560 g (1 lb 3 oz) main unit only
650 g (1 lb 6 oz) including the NP-FP50
rechargeable battery pack and DVM60
cassette.
Supplied accessories
See page 5-14.
AC Adaptor AC-L25A/L25B
Power requirements
AC 100 - 240 V, 50/60 Hz
Current consumption
0.35 - 0.18 A
Power consumption
18 W
Output voltage
DC 8.4 V, 1.5 A
Operating temperature
0°C to 40°C (32°F to 104°F)
Storage temperature
-20°C to + 60°C (-4°F to + 140°F)
Dimensions (approx.)
56 × 31 ×100 mm (2 1/4 ×11/4×4 in.)
(w/h/d) excluding the projecting parts
Mass (approx.)
190 g (6.7 oz) excluding the power cord
Rechargeable battery pack (NP-FP50)
Maximum output voltage
DC 8.4 V
Output voltage
DC 7.2 V
Capacity
4.9 Wh (680 mAh)
Dimensions (approx.)
31.8 ×18.5 ×45.0 mm
(1 5/16 ×3/4 × 1 13/16 in.) (w/h/d)
Mass (approx.)
40 g (1.5 oz)
Operating temperature
0°C to 40°C (32°F to 104°F)
Type
Lithium ion
Design and specifications are
subject to change without notice.

—3 —
DCR-HC65
1. Check the area of yourrepairforunsolderedor poorly-soldered
connections. Checkthe entire board surface for solder splashes
and bridges.
2. Check the interboard wiring to ensure that no wires are
"pinched" or contact high-wattage resistors.
3. Look for unauthorized replacement parts, particularly
transistors, that were installed during a previous repair. Point
them out to the customer and recommend their replacement.
4. Look for partswhich,through functioning, showobvioussigns
of deterioration. Point them out to the customer and
recommend their replacement.
5. Check the B+ voltage to see it is at the values specified.
6. Flexible Circuit Board Repairing
•Keep the temperature of the soldering iron around 270˚C
during repairing.
• Do not touch the soldering iron on the same conductor of the
circuit board (within 3 times).
• Be careful not to apply force on the conductor when soldering
or unsoldering.
Unleaded solder
Boards requiring use of unleaded solder are printed with the lead-
free mark (LF) indicating the solder contains no lead.
(Caution: Some printed circuit boards may not come printed with
the lead free mark due to their particular size.)
: LEAD FREE MARK
Unleaded solder has the following characteristics.
•Unleaded solder melts at a temperature about 40°C higher than
ordinary solder.
Ordinary soldering irons can be used but the iron tip has to be
applied to the solder joint for a slightly longer time.
Soldering irons using a temperature regulator should be set to
about 350°C.
Caution: The printed pattern (copper foil) may peel away if the
heated tip is applied for too long, so be careful!
•Strong viscosity
Unleaded solder is more viscous (sticky, less prone to flow) than
ordinary solder so use caution not to let solder bridges occur such
as on IC pins, etc.
•Usable with ordinary solder
It is best to use only unleaded solder but unleaded solder may
also be added to ordinary solder.
SAFETY CHECK-OUT
After correcting the original service problem, perform the following
safety checks before releasing the set to the customer.
SAFETY-RELATED COMPONENT WARNING!!
COMPONENTS IDENTIFIED BY MARK 0OR DOTTED LINEWITH
MARK 0ON THE SCHEMATIC DIAGRAMS AND IN THE PARTS
LIST ARE CRITICAL TO SAFE OPERATION. REPLACE THESE
COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS
APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS
PUBLISHED BY SONY.
ATTENTION AU COMPOSANT AYANT RAPPORT
À LA SÉCURITÉ!
LES COMPOSANTS IDENTIFÉS PAR UNE MARQUE 0SUR LES
DIAGRAMMES SCHÉMATIQUES ET LA LISTE DES PIÈCES SONT
CRITIQUES POUR LA SÉCURITÉ DE FONCTIONNEMENT. NE
REMPLACER CES COMPOSANTS QUE PAR DES PIÈSES SONY
DONT LES NUMÉROS SONT DONNÉS DANS CE MANUEL OU
DANS LES SUPPÉMENTS PUBLIÉS PAR SONY.
CAUTION :
Dangerofexplosionifbattery isincorrectlyreplaced.
Replace only with the same or equivalent type.

—4 —
DCR-HC65
TABLE OF CONTENTS
1. SERVICE NOTE
1-1. SERVICE NOTE ·····························································1-1
1. NOTE FOR REPAIR ·······················································1-1
2. POWER SUPPLY DURING REPAIRS ··························1-2
3. TO TAKE OUT A CASSETTE WHEN NOT EJECT
(FORCE EJECT) ·····························································1-2
1-2. SELF-DIAGNOSIS FUNCTION····································1-3
1. SELF-DIAGNOSIS FUNCTION····································1-3
2. SELF-DIAGNOSIS DISPLAY ·······································1-3
3. SELF-DIAGNOSIS CODE TABLE································1-4
2. DISASSEMBLY
2-1. DISASSEMBLY······························································2-1
2-2. SERVICE POSITION ·····················································2-3
2-3. CIRCUIT BOARDS LOCATION ···································2-5
2-4. FLEXIBLE BOARDS LOCATION ································2-6
HELP (List of caution points is shown here.)
3. BLOCK DIAGRAMS
3-1. OVERALL BLOCK DIAGRAM (1/4) ···························3-1
3-2. OVERALL BLOCK DIAGRAM (2/4) ···························3-3
3-3. OVERALL BLOCK DIAGRAM (3/4) ···························3-5
3-4. OVERALL BLOCK DIAGRAM (4/4) ···························3-7
3-5. POWER BLOCK DIAGRAM (1/2) ································3-9
3-6. POWER BLOCK DIAGRAM (2/2) ······························3-11
4. PRINTEDWIRING BOARDS AND
SCHEMATIC DIAGRAMS
4-1. FRAME SCHEMATIC DIAGRAM (1/2)·······················4-1
FRAME SCHEMATIC DIAGRAM (2/2)·······················4-3
4-2. SCHEMATIC DIAGRAMS
•CD-513 (CCD IMAGER)
SCHEMATIC DIAGRAM ············································4-7
•CK-141 (RELAY, FUNCTION KEY)
SCHEMATIC DIAGRAM ············································4-9
•FP-911 FLEXIBLE
SCHEMATIC DIAGRAM ··········································4-10
•JK-268 (JACK)
SCHEMATIC DIAGRAM ··········································4-11
•JM-016 (JACK-2)
SCHEMATIC DIAGRAM ··········································4-11
•PD-219 (RGB DRIVE, TIMING GENERATOR)
SCHEMATIC DIAGRAM ··········································4-13
•CONTROL KEY BLOCK (SB7800)
SCHEMATIC DIAGRAM ··········································4-13
•LB-102 (EVF BACK LIGHT)
SCHEMATIC DIAGRAM ··········································4-15
•MS-210 (MS CONNECTOR)
SCHEMATIC DIAGRAM ··········································4-15
•MI-051 (INDICATOR, IR SENSOR)
SCHEMATIC DIAGRAM ··········································4-17
•FS-087 (MF PHOTO SENSOR)
SCHEMATIC DIAGRAM ··········································4-17
•FP-909 FLEXIBLE
SCHEMATIC DIAGRAM ··········································4-17
•SL-064 (FUNCTION KEY)
SCHEMATIC DIAGRAM ··········································4-19
•FP-912 FLEXIBLE
SCHEMATIC DIAGRAM ··········································4-19
•FP-910 FLEXIBLE
SCHEMATIC DIAGRAM ··········································4-20
•CONTROL KEY BLOCK (PS7800)
SCHEMATIC DIAGRAM ··········································4-21
•CONTROL KEY BLOCK (FK7800)
SCHEMATIC DIAGRAM ··········································4-21
•FP-228/467/826 FLEXIBLE
(S/T REEL SENSOR, TAPE SENSOR)
SCHEMATIC DIAGRAM ··········································4-23
Shematic diagram of theVC-359 board is not shown.
Pages from 4-27 to 4-68 are not shown.
4-3. PRINTED WIRING BOARDS
•CD-513 (CCD IMAGER) (-11) (-12)
PRINTED WIRING BOARD ·····································4-73
•CK-141 (RELAY, FUNCTION KEY) (-11)
PRINTED WIRING BOARD ·····································4-75
•CK-141 (RELAY, FUNCTION KEY) (-12)
PRINTED WIRING BOARD ·····································4-77
•FS-087 (MF PHOTO SENSOR)
PRINTED WIRING BOARD ·····································4-79
•JK-268 (JACK)
PRINTED WIRING BOARD ·····································4-79
•JM-016 (JACK-2) (-11) (-12)
PRINTED WIRING BOARD ·····································4-81
•MI-051 (INDICATOR, IR SENSOR)
PRINTED WIRING BOARD ·····································4-83
•SL-064 (FUNCTION KEY)
PRINTED WIRING BOARD ·····································4-83
•MS-210 (MS CONNECTOR) (-11) (-12)
PRINTED WIRING BOARD ·····································4-85
•PD-219(RGB DRIVE, TIMING GENERATOR)
PRINTED WIRING BOARD ·····································4-87
•FP-228/467/826 FLEXIBLE
(S/T REEL SENSOR, TAPE SENSOR)
PRINTED WIRING BOARD ·····································4-89
•LB-102 (EVF BACK LIGHT)
PRINTED WIRING BOARD ·····································4-89
Printed wiring boardoftheVC-359 boardisnot shown.
Pages from 4-93 to 4-96 are not shown.
4-4. MOUNTED PARTS LOCATION ·································4-97
Mountedpartslocationofthe VC-359 board isnot shown.
Pages from 4-99 to 4-100 are not shown.
5. REPAIR PARTS LIST
5-1. EXPLODED VIEWS ······················································5-3
5-1-1.OVERALL SECTION·····················································5-3
5-1-2.CABINET (R) SECTION ···············································5-4
5-1-3.LCD SECTION ·······························································5-5
5-1-4.CABINET (L) SECTION-1 ············································5-6
5-1-5.CABINET (L) SECTION-2 ············································5-7
5-1-6.MAIN CHASSIS SECTION ···········································5-8
5-1-7.EVF SECTION································································5-9
5-1-8.LENS SECTION ···························································5-10
5-1-9.MECHANISM DECK OVERALL (Z200) ···················5-11
5-1-10. LS CHASSIS BLOCK ASSEMBLY ··························5-12
5-1-11. MECHANICAL CHASSIS BLOCK ASSEMBLY ····5-13
Other accessories ···························································5-14
5-2. ELECTRICAL PARTS LIST ········································5-15
ElectricalpartslistoftheVC-359boardisnotshown.
Pages from 5-19 to 5-27 are not shown.

1-1
SECTION 1
SERVICE NOTE
DCR-HC65
Make sure that the flat cable and flexible board are not cracked of
bent at the terminal.
Do not insert the cable insufficiently nor crookedly.
Cut and remove the part of gilt
which comes off at the point.
(Take care that there are
some pieces of gilt left inside)
When remove a connector, don't pull at wire of connector.
Be in danger of the snapping of a wire.
When installing a connector, don't press down at wire of connector.
Be in danger of the snapping of a wire.
1-1. SERVICE NOTE
1. NOTE FOR REPAIR

1-2
DCR-HC65
2. POWER SUPPLY DURING REPAIRS
In this unit, about 10 seconds after power is supplied to the battery terminal using the regulated power supply (8.4V), the power is shut off so
that the unit cannot operate.
This following two methods are available to prevent this. Take note of which to use during repairs.
Method 1.
Use the AC power adaptor (AC-L25).
Method 2.
Connect the servicing remote commander RM-95 (J-6082-053-B) to the LANC jack, and set the commander switch to the “ADJ”side.
3. TO TAKE OUT A CASSETTEWHEN NOT EJECT (FORCE EJECT)
1Open the flash.
2Remove the cabinet (F) section.
3Remove the cabinet (R) section.
4Remove the EVF section.
5Remove the VC-359 board.
6Remove the mechanism deck.
7Supply +4.5V from the DC power supply to the loading motor and unload with pressing the cassette compartment.
VC-359
VC-359 board
DC power supply (+4.5Vdc
)
Loading motor

1-3
DCR-HC65
1-2. SELF-DIAGNOSIS FUNCTION
1. SELF-DIAGNOSIS FUNCTION
When problems occur while the unit is operating, the self-diagnosis
function starts working, and displays on the viewfinder, or LCD
screen what to do. This function consists of two display; self-
diagnosis display and service mode display.
Detailsof the self-diagnosis functionsareprovidedinthe Instruction
manual.
2. SELF-DIAGNOSIS DISPLAY
When problems occur while the unit is operating, the counter of the
viewfinder or LCD screenconsistsofanalphabetand4-digitnumber,
which blinks at 3.2Hz. This 5-character display indicates the
“repairedby:”,“block”inwhichtheproblemoccurred, and “detailed
code”of the problem.
Note: The “self-diagnosis display”data will be kept even if the lithium battery (BT151 of CK-141 board) is removed.
1 1
3 1C
Repaired by:
Refer to page 1-4.
Self-diagnosis Code Table.
Indicates the appropriate
step to be taken.
E.g.
31 ....Reload the tape.
32 ....Turn on power again.
Block Detailed Code
Blinks at 3.2Hz
C : Corrected by customer
H : Corrected by dealer
E : Corrected by service
engineer
Viewfinder or LCD screen
C : 3 1 : 1 1

1-4E
DCR-HC65
3. SELF-DIAGNOSIS CODETABLE
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
E
E
E
E
E
Block
Function
04
21
22
31
31
31
31
31
31
31
31
31
31
31
31
32
32
32
32
32
32
32
32
20
61
61
62
62
Detailed
Code
00
00
00
10
11
20
21
22
23
24
30
40
42
10
11
20
21
22
23
24
30
40
42
00
00
10
00
01
Symptom/State
Non-standard battery is used.
Condensation.
Video head is dirty.
LOAD direction. Loading does not
complete within specified time
UNLOAD direction. Loading does not
complete within specified time
T reel side tape slacking when unloading .
Winding S reel fault when counting the
rest of tape.
T reel fault.
S reel fault.
T reel fault.
FG fault when starting capstan.
FG fault when starting drum.
FG fault during normal drum operations.
LOAD direction loading motor time-
out.
UNLOAD direction loading motor
time-out.
T reel side tape slacking when
unloading.
Winding S reel fault when counting the
rest of tape.
T reel fault.
S reel fault.
T reel fault.
FG fault when starting capstan.
FG fault when starting drum
FG fault during normal drum
operations
Data on A page or D page are rewriten.
Difficult to adjust focus
(Cannot initialize focus.)
Zoom operations fault
(Cannot initialize zoom lens.)
Steadyshot function does not work well.
(With pitchangularvelocity sensor output
stopped.)
Steadyshot function does not work well.
(With yaw angular velocity sensor output
stopped.)
Self-diagnosis Code
Repaired by:
Correction
Use the info LITHIUM battery.
Remove the cassette, and insert it again after one hour.
Clean with the optional cleaning cassette.
Load the tape again, and perform operations from the beginning.
Load the tape again, and perform operations from the beginning.
Load the tape again, and perform operations from the beginning.
Load the tape again, and perform operations from the beginning.
Load the tape again, and perform operations from the beginning.
Load the tape again, and perform operations from the beginning.
Load the tape again, and perform operations from the beginning.
Load the tape again, and perform operations from the beginning.
Load the tape again, and perform operations from the beginning.
Load the tape again, and perform operations from the beginning.
Remove the battery or power cable, connect, and perform
operations from the beginning.
Remove the battery or power cable, connect, and perform
operations from the beginning.
Remove the battery or power cable, connect, and perform
operations from the beginning.
Remove the battery or power cable, connect, and perform
operations from the beginning.
Remove the battery or power cable, connect, and perform
operations from the beginning.
Remove the battery or power cable, connect, and perform
operations from the beginning.
Remove the battery or power cable, connect, and perform
operations from the beginning.
Remove the battery or power cable, connect, and perform
operations from the beginning.
Remove the battery or power cable, connect, and perform
operations from the beginning.
Remove the battery or power cable, connect, and perform
operations from the beginning.
Make data on A page and D page correct value.
Inspect the lens block focus MR sensor (Pin 1, 2of CN5101 of
VC-359 board) when focusing is performed when the focus ring is
rotated in the focus manual mode, and the focus motor drive circuit
(IC5101 of VC-359 board) when the focusing is not performed.
Inspect the lens block zoom reset sensor ( Pin wh of CN5101 of
VC-359 board ) when zooming is performed when the zoom switch
is operated and the zoom motor drive circuit (IC5101 of VC-359
board) when zooming is not performed.
Inspect pitch angular velocity sensor (SE401 of CD-513 board)
peripheral circuits.
Inspect yaw angular velocity sensor (SE402 of CD-513 board)
peripheral circuits.

DCR-HC65
2-1 2-2
2-1. DISASSEMBLY
The following flow chart shows the disassembly procedure.
SECTION 2
DISASSEMBLY
BB
B
VC-359
VC-359
C
A
D
B
EFG
1 Open the cassette lid.
2 Two screws (M1.7x2.5) silver
3 Two screws (M1.7x2.5) silver
4 Screw (M1.7x2.5) silver
5 Eject knob
6 Cabinet (G) section
1 Open the cassette lid.
2 Two screws (M1.7x4) silver
3 Screw (M1.7x4) silver
4 Three screws (M1.7x2.5) silver
5 Open the LCD panel.
6 Two screws (M1.7x4) silver
7 FP-920 flexible board (51P)
8 Cabinet (R) section
1 Tape (R), fixed
2 Tape (CK), fixed
3 Spacer (R), fixed
1 Screw (M1.7x4) silver
2 Two screws (M1.7x2.5) silver
3 Craw
4 VC radiation plate assembly
5 Harness fixed tape
6 FP-916 flexible board (21P),
Control key block(FK7800)(14P)
7 Raise the Finder
8 Three tapping screws
(M1.7x3.5) silver
9 EVF section
1 Screw (M1.7x4) silver
2 Shield sheet (JK)
3 Two tapping screw
(M1.7x3.5) silver
4 Screw
5 JM-016 board,
JK-268 board,
FP-918 flexible board, etc.
6 Five tapping screws
(M1.7x3.5) silver
7 Control key block (PS7800),
ST bracket (front)
1 FP-913 flexible board (33P),
Flexible board (from lensdevice)(29P)
2 Control key block(PS7800)(10P)
3 Screw (M1.7x4) silver
4 Screw (M1.7x4) silver
5 Two screws (M1.7x2.5) silver
6 Open the cassette lid.
7 FP-918 flexible board (27P)
8 VC-359 board, Mechanism deck,
Cabinet (G) section, etc.
1 Two tapping screws (M1.7x3.5) silver
2 Lens section
1 Open the cassette lid.
2 Screw (M1.7x4) silver
3 FP-912 flexible board (30P)
4 Battery panel section
5 Flexible board (CN9102) (27P)
6 Flexible board (CN9103) (27P)
7 FP-919 flexible board (27P)
8 FP-910 flexible board (6P)
9 Two screws (M1.7x2.5) silver
q; Flexible board (CN9101) (10P)
qa Flexible board (CN6501) (10P)
qs VC-359 board
qd Four screws (M1.4x1.5) silver
qf Mechanism deck
1 Screw (M1.7x4) silver
2 Open the jack cover assembly.
3 Screw (M1.7x4) silver
4 Two screws (M1.7x4) silver
5 FP-919 flexible board (28P)
6 Cabinet (F) section
2
3
6
4
5
2
3
5
4
6
1
A
A
A
A
A
2
3
1
B
A
B
C
E
EF
A
A
A
B
A
C
C
B
B
G
A
BD
A
B
A
4
6
5
1
2
3
6
3
4
7
1
2
3
8
6
4
4
65
8
3
2
1
7
8
a
a
4
5
8
1
2
8
5
9
6
1
4
2
3
C
1
2
7
6
1
2
7
3
1
4
3
q;
qa
qd
8
6
qf
5
9
7
qs
4
1
2
5
7
a
b
a
b
a
4 Harness (PC-131) (10P)
5 Harness (PC-132) (14P)
6 FP-911 flexible board (6P)
7 Two screws (M1.7x4) silver
8 LCD section
5
9
7
1 Four screws (M1.7x4) silver
2 P cabinet (C) assembly (841)
3 Harness (PC-131) (10P)
4 Harness (PC-132) (14P)
5 Two screws (M1.7x2.5) silver
1 VF shield sheet
2 Two tapping screws (M1.7x5) black
3 Remove the EVF block .
4 Two tapping screws (M1.7x5) black
5 Pull out the VF lens assembly in the
direction of the arrow a.
6 Two tapping screws (M1.7x4) black
7 Remove the craw.
8 VF lens assembly.
6 Hinge section
7 Control key block (SB7800) (6P
)
8 P cabinet (M) assembly
9 PD-219 board,
LCD unit (ACX531AKM-J),
Light guide plate block
6
7
5
8
HELP 01
HELP 02
Tapping screw
M1.7x3.5
3-078-890-01
Screw
M1.7x4
3-078-893-21
Screw
M1.7x4
3-055-573-21
Tapping screw
M1.7x5
3-080-222-21
Tapping screw
M1.7x4
3-080-222-11
Silver Black
Screw
M1.7x2.5
3-989-735-01
Special screw
1.4x1.5
3-062-214-01

2. DISASSEMBLY
2. DISASSEMBLY
DCR-HC65
2-3 2-4
2-2. SERVICE POSITION
VC-359
VC-359
VC-359
AC power
adaptor AC IN
8
1
3
1
[SERVICE POSITION TO CHECK THE VTR SECTION]
Connection to Check the VTR Section
To check the VTR section, set the VTR to the "Forced VTR power ON" mode.
Operate the VTR functions using the adjustment remote commander (with the HOLD switch set in the OFF position.)
Setting the "Forced VTR Power ON" mode
1) Select page: 0, address: 01, and set data: 01.
2) Select page: 0, address: 10, and set data: 00.
3) Select page: A, address: 10, set data: 02, and press the
PAUSE button of the adjustment remote commander.
To eject the cassette, short-circuit between
pin
3 and pin 1 (GND) of CN1205 on
the VC-359 board for 1 second.
Exiting the "Forced VTR Power ON" mode
1) Select page: 0, address: 01, and set data: 01.
2) Select page: 0, address: 10, and set data: 00.
3) Select page: A, address: 10, set data: 00, and press the
PAUSE button of the adjustment remote commander.
4) Select page: 0, address: 01, and set data: 00.
Adjustment remote
commander (RM-95)
LANC
JK-268 board
JM-016 board FP-918 Flexible
board (27P)
CN9103
CN9102
CN9101
CN6501
CN1207
CN2101
CN1205
CN1201
VC-359 board
Mechanism deck
Battery panel section
DC-IN
I/F unit for LANC control
(J-6082-521-A)
CPC-15
(J-6082-564-A)
A/V
2
3
5
4
6
1
A
A
A
A
A2
3
1
B
A
B
4
6
5
7
8
B
C
A
B
1
2
3
4
8
5
9
6
7
A
A
B
4
5
8
6
1
2
7
3
B
G
A
1
2
4
3
q;
qa
qd
8
6
qf
5
9
7
qs
C1
2
A
C
C
3
6
a
a
4
1
2
5
7
Monitor TV
FP-912 Flexible
board (30P)

2-5
DCR-HC65
2. DISASSEMBLY
2. DISASSEMBLY
2-3. CIRCUIT BOARDS LOCATION
CCD IMAGER
RELAY, FUNCTION KEY
MF PHOTO SENSOR
JACK
JACK-2
EVF BACK LIGHT
INDICATOR, IR SENSOR
MS CONNECTOR
RGB DRIVE, TIMING GENERATOR
FUNCTION KEY
TIMING GENERATOR, S/H, AGC, A/D CONV., LENS DRIVE, CAMERA PROCESS, MPEG
MOVIE/DIGITAL STILL PROCESS, 64Mbit SDRAM, BUFFER, HI/DIGITAL STILL CONTROL,
32Mbit FLASH, 16Mbit SDRAM, DV SIGNAL PROCESS, DV INTERFACE, REC/PB AMP,
VIDEO I/O, DRUM/CAPSTAN/LOADING DRIVE, CAMERA/MECHA CONTROL, HI CONTROL,
EVF VIDEO, AUDIO I/O, MIC AMP, DC IN, CHARGE, DC/DC CONVERTER, CONNECTOR
CD-513
CK-141
FS-087
JK-268
JM-016
LB-102
MI-051
MS-210
PD-219
SL-064
NAME FUNCTION
CD-513
LB-102
PD-219
SL-064
CK-141
VC-359
VC-359
MS-210
JM-016
MI-051
FS-087
JK-268

2-6E
DCR-HC65
2. DISASSEMBLY
2. DISASSEMBLY
2-4. FLEXIBLE BOARDS LOCATION
The flexible boards contained in the lens block is not shown.
CONTROL KEY BLOCK
(PS7800)
CONTROL KEY BLOCK
(FK7800)
CONTROL KEY BLOCK
(SB7800)
FP-922
FP-913
FP-921
FP-92
3
FP-920
FP-911
FP-919
FP-910
FP-916
FP-912
FP-909
FP-918

DCR-HC65
HELP
HELP
Sheet attachment positions and procedures of processing the flexible boards/harnesses are shown.
Fixed (CK) tape
Fixed (R) space
r
Fixed (R) tape
Alignment position
HELP 02
HELP 01

DCR-HC65
Link
Link
3. BLOCK DIAGRAMS
OVERALL BLOCK DIAGRAM (4/4)
POWER BLOCK DIAGRAM (1/2)
OVERALL BLOCK DIAGRAM (3/4)
OVERALL BLOCK DIAGRAM (2/4) POWER BLOCK DIAGRAM (2/2)
OVERALL BLOCK DIAGRAM (1/4)
OVERALL BLOCK DIAGRAM (4/4)
POWER BLOCK DIAGRAM (1/2)
OVERALL BLOCK DIAGRAM (3/4)
OVERALL BLOCK DIAGRAM (2/4) POWER BLOCK DIAGRAM (2/2)
OVERALL BLOCK DIAGRAM (1/4)

DCR-HC65
3. BLOCK DIAGRAMS
3. BLOCK DIAGRAMS
3-1. OVERALL BLOCK DIAGRAM (1/4)
3-1 3-2
( ) : Number in parenthesis ( ) indicates the division number of schematic diagram where the component is located.
SECTION 3
BLOCK DIAGRAMS
IC7601
AUDIO
I/O
D/A CONV.
A/D CONV.
IC7101
VIDEO
IN/OUT
AGC
ACC
IC7101 Y OUT
Y
C
V
Y
C
V
IC6401
DV
SIGNAL
PROCESS
RF
SIGNAL
PROCESS
IC6301
DV
INTERFACE
IC8401
DIGITAL
STILL
CONTROL
IC8502
16Mbit
SDRAM
IC8503
32Mbit
FLASH MEMORY
MANUAL
FOCUS
SENSOR
MF A
MF B
DIGITAL
STILL
PROCESS
29
20 26
35
1
291 304
12
42
213
53
29 37
38 35
910
16 35
X8801
20MHz
IC5003
CH SO,SCK
MF A
MF B
CAM SO,SI,SCK
16
34
20
TPA
NTPA
TPB
NTPB
ZOOM MOTOR
DRIVE
(DV)
18
IC5001
IRIS DRIVE
+,-
IRIS HALL
+,-
135
11
ND HALL
+,-
ND DRIVE
+,-
CCD OUT
+,-
V1-V4
RG,H1,H2
78
71
23
73
10
75
FMR A,B
ZOOM RST ZOOM RST
77
CN2101
LCK0LCK0 VCK
TRCK0
RYO0-RYO3,DEHD,DEVD.DEFLD.SGOUT
RYI0-RYI3,DE0-DE3
RCO0-RCO3,EDHD,EDVD.EDFLD.FRMREF
TIMING
GENERATOR
FOCUS
MOTOR
DRIVE
22
CD-513 BOARD (1/2)
21
EXT STROBO
EXT STROBO
ZOOM RST
25
IC5101
ND
FILTER
DRIVE
IRIS
DRIVE
VC-359 BOARD(1/4)
FP-913
(FLEXIBLE)
(1/2)
2
12
IC401
LENS ASSY
M
IC8801
18
PITCH AD
YAW/PITCH
8
H
H
MR
IRIS
(SHUTTER)
SENSOR
YAW AD
AMP 129
YAW SENSOR
PITCH SENSOR
SE402
12 11
SE401
M
M
FOCUS
MOTOR
4-1 14 16 18
CD-513 BOARD (2/2)
CAMERA CONTROL
ZOOM
MOTOR
M
CN5101
CCD
IMAGER
NIGHT SHOT
ZOOM
RESET
SENSOR
ND FILTER
METER
TO
OVERALL
BLOCK DIAGRAM
(3/4)
ZOOM VR AD
CN002
130
3
CN5001CN201
CN201
CN5001
20
18
14
16
1
187
TO
OVERALL
BLOCK DIAGRAM
(4/4)
(PAGE 3-8)
AGC
A/D CONV.
IC201
4
IC8403
IC8404
4-1
59
53
5
2
1
22
23
20
9
10
12
67
72
32
17
25
X5001
66MHz
47
ADCK27
CAM SO,SI,SCK
ADCK27
CHCK CHCK
VCK
HD,VD,FLD HD,VD,FLD
47
48
12
1
CLPOB
CH SO,SCK
XNS SW
(1/21)
(1/21)
FOCUS +,-
SPCK
(IC6201)
EN1
DIR1A
DIR1B
EN1
DIR1A
DIR1B
ZOOM A,XA,B,XB
(13/21)
(1/2)
(2/21)
CN201 CN5001
4
5
3
2
44 45
92
91
90
11
12
13
228
229
230
248
250
251
1
2
CN702
MS-210
BOARD(1/2)
CK-141
BOARD
(1/3)
MEMORY
STICK
Duo
CONNECTOR
CN001
(USB)
CN2101
CN156
CN701
USB D+,D-
30-33 11-13
23-21
15 16 24
•••
XSHD,XSHP,CLPDM
CN201
CN5001
5
4
S/H
IC202
•30
31
•
••
4
6
30
28
MS BS,DIO,SCLK MS BS,DIO,SCLK
CLK
GEN
IC6202
64Mbit
SDRAM
X8401
48MHz
MS BS
MS DIO
MS SCLK
IFI HD
IFI VD
IFI OE
168
86
169
114
157
3
71
|
56
6
|
9
227
|
224
223
|
216
|
208
199
261
|
252
42
|
45 6
|
9
20
245
33
238
119122
177
42
213
53
198
|
215
185
186
29
20
H1
J1
C5
B6
C10
B11
K2
L2
B1
C4
F3
E3 K12
F1
G3
K6
L4
M9
J9
K9
L9
26
35
IFI Y0-Y7
IFI C0-C3
A0-A10, A12
1
2
13
12
15
17
9
6
26
24
MS BS,DIO,SCLK
DO-D15
6
5
3
CN151
10
9
7
CN1203
85
81
78
6
5
3
10
8
38
29 36
45
116 98 121 137
MPEG
MOVIE
PROCESS
25 16 13
10 148
CAMERA
PROCESS
VIDEO
A/D
CONV.
AUDIO
SIGNAL
PROCESS
USB
I/F
28
29
158
159
156
53
60
95
96
168
127
167
126
92
93
46
7
269
270
271
268
280
281
282
279
265
266
267
264
273
275
276
272
284
139
82
89
87
26
34
151
152
150
47
46
52
40
39
45
301
302
17
16
298
299
143 79
47104
45
41
139
162
120
163
119
186
150
187
149
58
112
111
60
121
71
122
70
72
14
73
13
166
124
125
123
12
15
21
27
34
36
18
14
22
39
48
42
54 107
152 189
55 153
190 109
155 192
IC6201
2
4
8
9
71
77
57
62
7
8
3
5
4
7
8
3
VD SO,SCK
VD SO,SCK
VSP SO,SI,SCK
VSP SO,SI,SCK
VSP SO,SI,SCK
MC BUSMC BUS
SPCK
SPCK
SPCK
RF INRF IN
REC CKREC CK
REC DTREC DT
SWP
FRRV
TRRT
TRRV
SWP
FRRV
TRRT
TRRV
FRRV
TRRT
TRRV
ADATAIN0
ADATAIN1
HY1 PLL 27INHY1 PLL 27IN
ADATAOUT0
ADATAOUT1
SFD BCK
DSCK VM
ADATAIN0
ADATAIN1
ADATAOUT0
ADATAOUT1
SFD BCK
EVF R
EVF G
EVF B
EVF HD
EVF VD
PANEL HD
PANEL VD
S.Y I/O
SP+
SP-
MIC L
MIC R
SP+
SP-
MIC L
MIC R
HP L
HP R
CN1201 CN502
AUDIO R I/O
AUDIO L I/O
VIDEO I/O
DATA FROM SFD
A1-A22
A1-A22
DSCK VM
USB CLK
1
2
4
D0-D15
195 174
D0-D15A0-A13
A1-A19 D0-D15
DATA FROM SFD
DATA TO SFD
DATA TO SFD
SFD BCK L
R
L
R
S.C I/O
PANEL R
PANEL G
PANEL B
EVF R
EVF G
EVF B
EVF HD
EVF VD
PANEL HD
PANEL VD
IC6201 Y OUT
IC6201 C OUT
IC1701 Y OUT
IC7101 Y OUT
IC7101 C OUT
IC7101 C OUTIC7101 C OUT
PANEL R
PANEL G
PANEL B
TO
OVERALL
BLOCK DIAGRAM
(2/4)
3
TO
OVERALL
BLOCK DIAGRAM
(2/4)
4
AV IN/OUT
CN501
JM-016
BOARD(1/2)
JK-268
BOARD
(1/2)
(16/21)
RCI0-RCI3,DE4-DE7
LBUS0-LBUS3
AUDIO SIGNAL
VIDEO SIGNAL
VIDEO/AUDIO SIGNAL
D0-D15
D0-D15
13 14 1
38 33 64
19 18 10
IC5201
(3/21)
(5/21)
(7/21)
(7/21)
(6/21)
(1/2)
(7/21) (7/21)
77
115 241
122
137
102
CAM SO,SI,SCK
USB D+,D-
USB D+,D-
USB D+,D-
AD4-AD13
A0-A13
161 144
DV
SIGNAL
PROCESS
170
|
185
AD0-AD13
AD0-AD13 AD0-AD13
(4/21)
(8/21) (9/21)
(11/21)
(PAGE 3-3)
(PAGE 3-3)
(PAGE 3-5)
54
H12
J11
K11
FP-913
(FLEXIBLE)(2/2)
FP-912
(FLEXIBLE)(1/3)
FP-921
(FLEXIBLE)(1/2)
FP-920
(FLEXIBLE)
(1/3)
FP-912
(FLEXIBLE)
(2/3)
5
4
6
1
9
5
10
16
211
210
42
43
45
CN1202
FP-919
(FLEXIBLE)
(1/3)
10
8
CN101
MI-051
BOARD
(1/3)
19
21
CN103
FP-922
(FLEXIBLE)
2
4
CN851
PH0851
PH0852
FS-087 BOARD
5
3
CN1201
10
11
CN552
J551
(HEADPHONE)
2
4
HP L
HP R
FP-918
(FLEXIBLE)(1/3)

DCR-HC65
3. BLOCK DIAGRAMS
3. BLOCK DIAGRAMS
3-3 3-4
3-2. OVERALL BLOCK DIAGRAM (2/4) ( ) : Number in parenthesis ( ) indicates the division number of schematic diagram where the component is located.
PD-219 BOARD(1/2)
VC-359 BOARD(2/4)
RGB
DRIVE COM
VR,VG,VB
COM
BL ON EXTDA
COS
3.5INCH
COLOR
LCD UNIT
LCD901
ND901
CN605
CN606
IC602
34
33
32
26
20
21
22
TIMING
GENERATOR
1
31
30
29
45
42
44
CN301
PANEL R,G B
HD
VD
TIMING
GENERATOR
COLOR
EVF
UNIT
17
16
18
LB-102 BOARD
9
5
10
7
19
8
1
BACKLIGHT
DRIVE
D303
BACK
LIGHT
R,G,B
EN, VST, REF, PCG, VCK, XSTBY,BLK,HCK1/2, HST
COM
Q9303
IC9302
CN302
LCD902
21
CN9301
CN1203
CN602
CN601
13
17
14
15
3
12
IC9301
RGB
DRIVE
EVF R,G,B
EVF HD
EVF VD
(15/21)
(15/21)
(17/21)
BL HIGH
BL REG
BL DET
XLED
BL LOW
(STARTER)
BACK
LIGHT
20
21
22
45
42
44
34
33
32
26
18
1
28
17
16
14
12
10
10
6
MIC L
MIC R
SHOE MIC L
L
R
MIC AMP
IC7701
22
14
36
48
SHOE MIC L
FP-916 (FLEXIBLE)
FP-918
(FLEXIBLE)
(2/3)
FP-919
(FLEXIBLE)
(2/3)
CONTROL KEY BLOCK
(FK7800)(1/2)
FP-920
(FLEXIBLE)
(2/3)
CK-141
BOARD
(2/3)
CN1206
INTELLIGENT
ACCESSORY
SHOE (1/2)
2
MI-051 BOARD (2/3)
JM-016 BOARD (2/2)
CN105 CN1202CN101
CN1201
CN502
MIC901
MIC UNIT
MIC
L
MIC
R
J501
16
TO
OVERALL
BLOCK DIAGRAM (3/4)
(PAGE 3-5)
6
TO
OVERALL
BLOCK DIAGRAM (4/4)
(PAGE 3-7)
5
TO
OVERALL
BLOCK DIAGRAM (1/4)
(PAGE 3-2)
3
TO
OVERALL
BLOCK DIAGRAM (1/4)
(PAGE 3-2)
4
33
3
1
35
3
1
1
3
10
11
28
26
10
11 12
EVF HD
EVF VD
EVF R
EVF G
EVF B
PANEL HD
PANEL VD
PANEL R
PANEL G
PANEL B
SP+
SP-
MIC L
MIC R
15
5
5
6
30
31
23
7
AUDIO SIGNAL
VIDEO SIGNAL
MIC
(PLUG IN POWER)
VD,SO,SI,SCK
48
31
20
6PSIG 16
24
51
50
20
22
19
CN151
47
46
22
21
29
45
1
2
32
30
33
CN152
CN157
CN153
9
10
2
3
1
2
3
1
4
8
1
2
12
14
9
10
4
8
12
14
23
24
4
5
3
22
19
14
2
17
5
19
21
2
48
3
10
SP901
SPEAKER
INVERTER
BACK
LIGHT
DRIVE
T600
Q612
Q611
( )
LED DRIVE
VD SI, SCK
BL CONT
VD SO
SP+, SP-
BL CONT

DCR-HC65
3. BLOCK DIAGRAMS
3. BLOCK DIAGRAMS
3-3. OVERALL BLOCK DIAGRAM (3/4) ( ) : Number in parenthesis ( ) indicates the division number of schematic diagram where the component is located.
3-5 3-6
X8801
20MHz
16
MODE SW A - MODE SW C
CONTROL
SREEL FG
CAP ON,CAP FWD
DRUM PWM
FRRV
TRRT
TRRV
TAPE LED ON
13
CAP PWM
|
LOAD,UNLOAD
DRUM PG
15
DEW AD
66
63
65
36
38
1
80
77
75
67
64
33
32
72
69
63
68
65
74
78
76
69
67
70
23
179
178
52
32
33
45
CAP FG
TAPE END
TAPE TOP
106
DRUM FG
TREEL FG
MECHA
108
|
EEPROM
VD SO, SCK
VD SO, SI, SCK
EEP SO, SI, SCK
VSP SO,SI,SCK
VSP SO,SI,SCK
SWP, FRRV, TRRT, TRRV
SWP
MC BUS
HI SO,SI,SCK
REC PROOF
CHIME SDA,CHIME SCK,CHIME VDD
XCC DOWN
CAP ERROR
DRUM ERROR
24
21
IC2301
PWM
75
77
SWITCHING
SWITCHING
Q2305
Q2306
26
SENSOR
MOTOR
Z MECHA DECK
(MDX-Z200)
DRUM FG AMP
S902
1
|
LOADING
DRIVE MOTOR
H902
H901
C. C. DOWN
S903
CN9102
D901
6
17
CONNECTOR
TAPE TOP SENSOR
Q901
DRUM FG
CAPSTAN
MODE
22
SENSOR
12
S REEL
SWITCH
XCC DOWN
S REEL +, –
T REEL +, –
LM +, –
15
MOTOR
CN9103
25
TAPE END DETECT
4PIN
T REEL
|
TAPE TOP DETECT
7
LOADING MOTOR
TAPE LED
M
REEL FG AMP
M902
REC PROOF
9
13
SENSOR
DRUM
TAPE END SENSOR
|
20
1
5
CAPSTAN
DRUM PG
23
|
10
M
18
DRUM PG AMP
11
CAP VS
DEW
17
4
25
DRUM VS
FG
M903
9
DRUM
Q902
MIC902
|
M901
20
22
TO
OVERALL
BLOCK DIAGRAM
(4/4)
21
SWP
CN1207
FOR ADJUSTMENTS
REC/PB 6
CN6501
EVEN 3
ODD
2
5
VSP SO, SCK
REC CK
REC DT
TO
OVERALL
BLOCK DIAGRAM
(1/4)
(PAGE 3-2)
VC-359 BOARD(3/4)
166
165
FG AMP
(13/21)
(13/21)
(2/2)
(12/21)
(12/21)
(10/21)
(19/21)
164
172
190
89
88
197
198
192
193
31
30
119
180
1
3
4
35
53 52
49
50
29
25
21
19
20
18
IC6501
44
46
RF IN
SPCK
RF IN 35
RF MON 30
RF SWP 39
SWP 38
REC CK
REC DT
RF MON
IC9101
MOTOR
DRIVE
MOTOR
DRIVE
CAPSTAN
DRIVE
IC9101
LPF
4
|
1
11
14
|
M
CN9101
IC8802
IC8801
AMP
CAPSTAN
DRUM
41
44
43
45
26 27
7 8
22 23 DEW AD
DRUM U,V,W
CAP U,V,W
FG 1,2
(1/2)
(2/2)
(1/2)
2
TO
OVERALL
BLOCK DIAGRAM
(1/4)
(PAGE 3-3)
6
(PAGE 3-8)
7
10
3
9
4
LPF
CPC
DIGITAL VIDEO/AUDIO SIGNAL
82
80
83
86
84
87
6
5
7
562
CN1207
FOR ADJUSTMENTS
CPC

DCR-HC65
3. BLOCK DIAGRAMS
3. BLOCK DIAGRAMS
3-4. OVERALL BLOCK DIAGRAM (4/4) ( ) : Number in parenthesis ( ) indicates the division number of schematic diagram where the component is located.
3-7 3-8
C
BH001
BATTERY
TERMINAL
Q2101,
Q2102
Q2105,Q2106
10MHz
X8201
X8202
32.768KHz
CN1206
DC IN
J001
IC2301
DC/DC
CONVERTER
RESET
LANC I/O A 1.5V
USB 3.1V
MT 5V
A 1.2V
D 1.2V
IC8401
I/F 42
43
77
14
53
62
VCC
XRESET
VOUT
IB SI
IB SO
BATT/XEXT
IC8201
HI CONTROL
HI CONTROL
28
29
52
51
5
35
57
37
XCC DOWN
234
131
REC PROOF REC PROOF
ZOOM VR AD
EXT STROBO
XCC DOWN
CHIME SDA
CHIME SCK
CHIME AD0
CHIME SDA
CHIME SCK
CHIME VDD
CHIME AD1
CHIME AD2
SO
VTR DD ON
SHOE ON
CN1203
LANC I/O
RESET
3V REG
44
CN2101
55
SHOE ID1 54
SHOE ID2
25
24
23SI
X 0A
X 1A
X TAL
X TAL
TXC, RXD, SCK
HI EVER SO,SCK
SCK
RXD
95
94
93 TXD
CAM DD ON
254 IR ON
SCK
40
39 LANC IN
LANC IN LANC OUT
LANC OUT
FAST CHARGE
73 XRESET
BATT/XEXT
VTR DD ON
CAM DD ON
SHOE ON
FAST CHARGE
BATT SIG
Q8201
BATT SIG
LI 3V
LANC SIG
10
8
9
7
3
6
5
HI EVER SO
HI EVER SCK
16
EVER 3.0V
CAM 15V
CAM -7.5V
BATT UNREG
VTR UNREG
SHOE UNREG
(6/21)
(2/2)
(14/21)
(19/21)
(2/2)
(7/21)
SHOE UNREG
SHOE UNREG
LANC SIG
EXT STROBO
SHOE ID1,2
TO
OVERALL
BLOCK DIAGRAM(3/4)
(PAGE 3-5)
56
54
246
.
247
.
134
HI SO
HI SI
XHI SCK
97
98
.
.
99
EEP TXD
EEP RXD
EEP SCK
103
104
105
135
136
EEPROM
IC8402
.
.
7
TO
OVERALL
BLOCK DIAGRAM(1/4)
(PAGE 3-1)
1
.
.
KEY AD3
KEY AD0
KEY AD3
KEY AD0
KEY AD5
KEY AD5
D001 (CAMERA TAPE)
D002 (CAMERA MEMORY)
D003 (PLAY/EDIT)
144
142
139
.
.
57
45
51
48
47
49
.
14
15
.
.
.
.
.
.
20
21
.
.
.
4
6
5
7
8
.
(2/2)
INTELLIGENT
ACCESSORY
SHOE
.
.
.
.
.
.
5
2
6
.
.
D 1.5V
AU 2.8V
RP 2.8V
A 2.8V
D 2.8V, NS 2.8V
NS 2.8V
EP 2.8V
D 1.9V
CAM 3.1V
A 4.6V
AU 4.6V
EP 4.6V
RP 4.6V
EP 8.5V
13.5V
BL REG BL CONT
HI SO,SI,SCK
LED
DRIVE
Q1201, 1202
EJECT SW
S001
TOUCH
PANEL
I/F
POWER SW
MODE SW
Q8403
(LANC)
J552
3
4
.
VC-359 BOARD(4/4)
JK-268 BOARD
(2/2)
MI-051 BOARD (3/3)
FP-910 (FLEXIBLE)
FP-909
(FLEXIBLE)
FP-918 (FLEXIBLE)
(3/3)
CONTROL KEY
BLOCK (FK7800)
(2/2)
LANC SIG
CN1205
CN1201 CN552
34
3
26 11
XPOWER SW 1
XMODE SW 2
XCAM LED 10
XMEM LED 11
XVTR LED 12
SIRCS PWM 45
XEJECT SW 4
SIRCS SIG 41
XF TALLY LED 16
TP SEL1
TP Y
TP SEL2
TP X
250
249
138
.
.
137
.
287 MS LED ON
LED
DRIVE
Q8408
145 KEY AD6
141 KEY AD2
140 KEY AD1
SL-064
BOARD
MS-210
BOARD (2/2)
PD-219
BOARD (2/2)
CONTROL KEY
BLOCK (SB7800)
FP-912
(FLEXIBLE)
(3/3)
28
12
36
29
32
40
1
37
35
34
.
11
10
.
9
.
16
14
11
20
17
21
27
30
22
25
CN1202 CN101
CN102 S001
S002
24
22
17
16
15
12
11
.
7
5
4
9
2
10
1
ZOOM VR
RV001
TO
OVERALL
BLOCK DIAGRAM(2/4)
(PAGE 3-3)
5
PHOTO SW
PHOTO FREEZE
PHOTO REC
START/STOP SW
( )
CONTROL KEY
BLOCK (PS7800)
CN1208
5
7
12
13
14
18
17
4
3
.
FP-919
(FLEXIBLE)
(3/3)
D001
(NIGHT SHOT)
D002 (TALLY)
IC101
REMOTE
COMMANDER
RECEIVER
4
FOCUS SW
BACK LIGHT SW
CN802
CN701
CN153
CN601
LED DRIVE
Q801
BATTERY INFO SWS803
D801
(EASY)
EASY SW
S801 KEY AD1
EASY LED
XMS LED ON
XCHARGE LED
KEY AD6
XRESET SW
TPX
TPY
TP SEL1
2
3
4
7
9
CN155
CN156
5
4
3
7
9
D701 (ACCESS)
D702 (CHARGE)
10
8
.
9
.
CN602
10
8
.
9
.
CN603
1
2
.
4
.
5
.
6
5
.
CN152
6
5
.
CN154
4
3
.
CN604
3
4
.
TOUCH
PANEL
I/F
TOUCH
PANEL
START/STOP SW
LCD BACKLIGHT SW
PANEL
REVERSE SW
Q601, 602
S001, 002
CN151
24
40
16
23
20
12
51
15
17
18
.
41
42
.
43
.
FP-920
(FLEXIBLE)
(3/3)
FP-923
(FLEXIBLE)
FP-921
(FLEXIBLE)
(2/2)
FP-911
(FLEXIBLE)
RESET
BT151
LITHIUM
BATTERY
(SECONDARY)
S151
PANEL
OPEN/CLOSE SW
S152
BATT LI 3V
KEY AD2
CK-141 BOARD
(3/3)
2
9
XCHARGE LED
17
EASY MODE LED ON
6
XBATT INFO SW
3

DCR-HC65
3. BLOCK DIAGRAMS
3. BLOCK DIAGRAMS
3-5. POWER BLOCK DIAGRAM (1/2) ( ) : Number in parenthesis ( ) indicates the division number of schematic diagram where the component is located.
3-9 3-10
L2316
L2317
L2318
F003
F004
F002
F007
L2309
L2326
L2325
L2310
L2313
L2314
BATT/XEXT
F006
L2306
D2305
L2315
L2321
L2322
L2319
L2320
61 VCC1
51
44
60
58
43
38
55
50
48
IC2301
DC/DC CONVERTER
RESET,LANC I/O
63
49
67
VCC01
VCC02
OUT1-1
68
OUT2
IN1
29
+INE2
A 1.5V
D 1.5V
A 1.2V
D 1.2V
CAP VS
DRUM VS
CAP ERROR
Q2101,
2102
Q2105,2106
SHOE ON
SHOE UNREG
CHARGE
SWITCH
BATT UNREG
ACV UNREG
Q2103,
2104
C
BATT SIG
DC IN
J001
VC-359 BOARD (1/2)
LF2101
CN2101
BH001
BATTERY
TERMINAL
DRUM ERROR
4.6 V
47
46
45
Q2301
Q2308
SWITCHING
RECT
INIT CHARGE ON
A 1.5V
D 1.5V
USB 3.1V
D 1.9V
D 2.8V
MT 5V
MT 5V
A 4.6V
CAP VS
CAP ERROR
DRUM VS
DRUM ERROR
CAM DD ON
CAM 15V
CAM -7.5V
13.5V
CAM 3.1V
AL 2.8V
AU 4.6V
AU 2.8V
RP 4.6V
RP 2.8V
A 2.8V
BATT UNREG
TO
POWER
BLOCK
DIAGRAM
(2/2)
(PAGE 3-11)
13.5V
CAM 15V
EP 8.5V
CAM -7.5V
CAM DD ON
AL 2.8V
BL REG
BL CONT
PR 2.8V
A 2.8V
D 2.8V
AU 2.8V
EP 2.8V
D 1.9V
USB 3.1V
A 4.6V
AU 4.6V
EP 4.6V
RP 4.6V
CAM 3.1V
1.2V REG
Q2320,Q2321
Q2313,Q2314 A 1.2V
D 1.2V
VTR UNREG
EP 4.6V
EP 8.5V
EP 2.8V
BL REG
BL CONT
EVER 3.0V
COLOR
EVF
UNIT
BACK
LIGHT
LED
IC9302 IC9301
TIMING
GENERATOR
RGB
DRIVE
BACK LIGHT
DRIVE
CN9301
BL ON
CN301
D303
CN302
LCD902
EP 8.5V
D 2.8V
EP 2.8V
EP 4.6V
16
LB-102 BOARD
-7.5V
REG
Q2315,
2316
15V
REG
13.5V
REG
2
8
1
19
CN1208
R1218
D001-003
20
18
L9303
L9302
CN1206
CN1203
CN151
INTELLIGENT
ACCESSORY
SHOE
6
5
4ZOOM VR
RV001
C/D/MT UNREG
BL UNREG
VTR UNREG
1
TO
POWER
BLOCK
DIAGRAM
(2/2)
(PAGE 3-12)
2
F001 2.8V/4.6V UNREG
8
CONTROL
KEY
BLOCK
(PS7800)
3220
S151
BT151
LITHIUM
BATTERY
(SECONDARY)
RESET
POWER
CK-141
BOARD
(1/2)
XLANC PWR ON
BATT IN
HI EVER SO
HI EVER SCK
XCS DD
VCC VOUT
7
XRESET
57
BATT/XEXT
ACV SENS
FAST CHARGE
FAST CHARGE
VTR DD ON
INIT CHARGE ON
HI CONTROL
1
2
IC8201
37
66
77
65
XMODE SW
BATT SENS
38
XPOWER SW
SHOE ON
35
42
43
14
62
53
20
67
21
14
13
15
D2301
D2302
3V REG
I/F
Q8201
BATT SIG
XRESET
XPOWER SW
XMODE SW
OFF (CHG)
ON
MODE
LI 3V
IB SI
IB SO
31
73 RESET
DIN
CLK
LD
CTL1
VCC3
VOUT4
VREF
RT
BATTERY
IN
DETECT
5.6V
REG
LANC I/O
L2307
Q2303
SWITCHING
70
72
OUT3-1
OUT3-2
10
IN3
41
VR
L2308
Q2302
SWITCHING
73
OUT4
9
62
IN4
VB
L2305
Q2304
SWITCHING
75
OUT5
24
+INE5
L2302
Q2305
Q2303
SWITCHING
77
OUT6
21
+INE6
L2303
L2304
Q2312
Q2310
8.5V
REG
Q2311
L2301
Q2306
SWITCHING
79
OUT7
VCONT6
VOUT6
VCONT5
VOUT5
REG6CTL
6
3
5
1
2
IN7
Q2307
SWITCHING
D2304
RECT
3.1V REG
IC2302
1
45
3.1V REG
IC2303
1
45
64
OUT1-2 66
12
NS 2.8V
(14/21)
(19/21)
(19/21)
(19/21)
(15/21) (15/21)
27
25
21
14
11
17
16
20
30
22
FP-912
(FLEXIBLE)
CONTROL KEY
BLOCK (FK7800)
FP-920
(FLEXIBLE)
FP-916
(FLEXIBLE)
(1/2)
FP-918JK-268
BOARD (FLEXIBLE)
9
10
6
CN1201
23
24
CN552
9
8
MODE LED
Q2309 1.9V REG
4
5V REG
Q2317-2319
(LANC)
J552
35
•
34
18
17
23
•
22
3
2

DCR-HC65
3. BLOCK DIAGRAMS
3. BLOCK DIAGRAMS
3-6. POWER BLOCK DIAGRAM (2/2) ( ) : Number in parenthesis ( ) indicates the division number of schematic diagram where the component is located.
3-11 3-12E
4
3
D702
CHARGE
D801
EASY LED
FB8402
FB8501
Q8404-8406
Q9101
MIC902
D901
H901,
H902
R9120
T REEL,
19
27
4PIN
13
Z MECHA DECK
(MDX-Z200)
SENSOR VCC
CHIME VDD
8
2
CN702
CN156 CN701
D701
D2.8V
D1.2VD1.2V
A1.2V
CONNECTOR
S REEL
SENSOR
TAPE LED
SE401, 402
PITCH/YAW
SENSOR
DRUM FG,PG AMP
MOTOR DRIVE
IC9101
43 REEL FG AMP
LOADING
DRUM,CAP ERROR AMP
TAPE TOP,END DET
DRUM
CAPSTAN FG AMP
CAPSTAN MOTOR DRIVE
MOTOR DRIVE
A 2.8V
RP 2.8V
RP 4.6V
CAM DO ON
D 1.9V
D 2.8V
AU 2.8V
AU 4.6V
VTR UNREG SP VCC
A 1.5V
D 1.5V
D 2.8V
D 1.9V
16
A 4.6V
D 2.8V
A 2.8V A 2.8V
A 2.8V
VTR UNREG
MT 5V
USB 3.1V
A 1.2V
D 1.2V
CAP VS
13.5V
CAP ERROR
DRUM ERROR
DRUM VS
CN9102
TAPE LED A
D 2.8V
MT 5V
VTR UNREG
CHIME PWR CONT XREEL HALL ON
CAM DD ON
MS VCC ON
CHIME PWR CONT
EEPROM
IC8402
REMOTE
COMMANDER
RECEIVER
IC101
OSC
XTAL
IC8403
FLASH
MEMORY
32M
IC8503
MEMORY
STICK
Duo
CONNECTOR
131
IC7701
MIC
AMP
D/A CONV.
A/D CONV.
16M
SDRAM
IC8502
75
77
64
67
XREEL
BL REG
EVER 3.0V
D 2.8V
MS VCC
BL CONT
HALL ON
ZM RST LED
153
45
IC5001
ZOOM
SENSOR
FOCUS
SENSOR
TIMING
GENERATOR
IC5003
AGC
A/D CONV.
LENS ASSY
IC201
CCD
IMAGER
IC202
S/H
IC401
PITCH/YAW
SENSOR
AMP
29
3
CN5101
ZM VCC
MR A2.8V
ZM RST LED
CN201
CN5001
CAM 15V
CAM -7.5V
CAM 3.1V
CD-513 BOARD
VC-359 BOARD(2/2)
MR
RESET
6 28
27
7
IC5002
3.4V REG
3.4V
A 4.6V
AL 2.8V
TO
POWER BLOCK
DIAGRAM
(1/2)
1
130
286
5 4
60
2.9V
REG
IC1201
1
4
55
5
EEPROM
IC8802
IC7601
AUDIO
I/O CAMERA
CONTROL
MECHA
CONTROL
IC8801
IC6501
REC/PB
AMP
IC6202
64Mbit
SDRAM
IC5201
CAMERA
PROCESS
IC6401
DV SIGNAL
PROCESS
RF SIGNAL
PROCESS
IC6201
DV SIGNAL PROCESS
MPEG MOVE PROCESS
DIGITAL STILL PROCESS
AUDIO SIGNAL PROCESS
IC6301
DV
INTERFACE
IC5101IC7101
VIDEO
IN/OUT
AGC
ACC
FOCUS/ZOOM/
IRIS/ND
DRIVE
DIGITAL
HI
CONTROL
IC8401
STILL
CONTROL
REGREG
A 2.8V
RP 2.8V
RP 4.6V
D 1.2V
A 1.2V
AU 2.8V
AU 4.6V
VTR UNREG
NS 2.8V
NS 2.8V
D 2.8V
A 4.6
A 1.5V
D 1.9V
D 1.5V
D 2.8V
CAP VS
CAP ERROR
DRUM VS
DRUM ERROR
CAM DO ON
CAM 15V
CAM -7.5V
13.5V
CAM 3.1V
AL 2.8V
A 4.6V
MT 5V
USB 3.1V
CN101
R1219,
R1220
Q7605
CN605
10
PD-219 BOARD
CK-141
BOARD
(2/2)
SL-064 BOARD
MS-210
BOARD
FP-921
(FLEXIBLE)
FP-920
(FLEXIBLE)
(2/2)
FP-923
(FLEXIBLE)
MI-051 BOARD
FS-087 BOARD
TO
POWER
BLOCK DIAGRAM
(1/2)
(PAGE 3-10)
Q612, T600
3.5INCH
COLOR
LCD
UNIT
LCD901
Q608, 609
BL HIGH
2
RGB
DRIVE
INVERTER
(BACKLIGHT DRIVE)
ACCESS LED
TIMING
GENERATOR
IC602
10
31
CN1203
33
46
•
47
38
•
39
2
23
18
CN606
10
D101
CN1202 D102
NIGHT SHOT LED
TALLY LED
9
14
•
13
20
•
19
27
25
USB 3.1V
(PAGE 3-10)
(16/21) (17/21) (13/21)
(13/21)
(21/21)
(6/21) (7/21) (7/21)
OSC
XTAL
IC8403
(7/21)
NAND
GATE
IC8404
(7/21) (7/21)
(7/21)
(12/21)
(1/21)
(1/21)
(1/21)
(2/21)(11/21)(9/21)
(10/21) (8/21) (4/21) (5/21) (3/21)
FP-919
(FLEXIBLE)
FP-922
(FLEXIBLE)
R1205
Q5101
8
9
2
6
4
CN153
5
CN152
6
4
CN602
5
4
3
CN601
2
CN155
10
9
32
25
2
FP-913 (FLEXIBLE)
FB6201
L5103
L401
20
15
•
16
9
•
10
2
4
CN103
5
CN851
2
PH0851, 0852
MANUAL FOCUS
PHOTO SENSOR
R1202
26
•
27
17
•
18
15
•
16
13
•
14
CN151
19
6
•
5
13
•
14
50
29
25
•
26
34
•
35
36
•
37
38
•
39
5
CN802
ND901
BACK
LIGHT
EP 2.8V
EP 4.6V
EP 8.5V
R1245
R1244
A 4.6V
