HD COLOR CAMERA
HXC-100
SERVICE MANUAL
Volume 2 1st Edition

HXC-100/V2 (J, E)
!警告
このマニュアルは，サービス専用です。
お客様が，このマニュアルに記載された設置や保守，点検，修理などを行うと感電や火災，
人身事故につながることがあります。
危険をさけるため，サービストレーニングを受けた技術者のみご使用ください。
!WARNING
This manual is intended for qualified service personnel only.
To reduce the risk of electric shock, fire or injury, do not perform any servicing other than that
contained in the operating instructions unless you are qualified to do so. Refer all servicing to
qualified service personnel.
!WARNUNG
Die Anleitung ist nur für qualifiziertes Fachpersonal bestimmt.
Alle Wartungsarbeiten dürfen nur von qualifiziertem Fachpersonal ausgeführt werden. Um die
Gefahr eines elektrischen Schlages, Feuergefahr und Verletzungen zu vermeiden, sind bei
Wartungsarbeiten strikt die Angaben in der Anleitung zu befolgen. Andere als die angegeben
Wartungsarbeiten dürfen nur von Personen ausgeführt werden, die eine spezielle Befähigung
dazu besitzen.
!AVERTISSEMENT
Ce manual est destiné uniquement aux personnes compétentes en charge de l’entretien. Afin
de réduire les risques de décharge électrique, d’incendie ou de blessure n’effectuer que les
réparations indiquées dans le mode d’emploi à moins d’être qualifié pour en effectuer d’autres.
Pour toute réparation faire appel à une personne compétente uniquement.

1
HXC-100/V2 (J, E)
目次 /TableofContents
このマニュアルについて
本書の目的.......................................................................................................3(J)
関連マニュアル..............................................................................................3(J)
商標について..................................................................................................3(J)
ManualStructure
Purposeofthismanual..............................................................................3(E)
Relatedmanuals............................................................................................3(E)
Trademarks.....................................................................................................3(E)
1. SpareParts
1-1. 補修部品注意事項.............................................................................. 1-1
1-1. NotesonRepairParts...................................................................... 1-1
1-2. ExplodedViews.................................................................................. 1-2
1-3. ElectricalPartsList.........................................................................1-13
1-4. OptionalFixtures.............................................................................1-88
1-5. SuppliedAccessories......................................................................1-88
2. BlockDiagrams
 Overall.................................................................................................... 2-2
3. SchematicDiagrams
 CD-61...................................................................................................... 3-2
 CN-3069..............................................................................................3-22
 CN-3070..............................................................................................3-22
 CN-3071..............................................................................................3-22
 CN-3072..............................................................................................3-22
 CN-3073..............................................................................................3-22
 CN-3074..............................................................................................3-22
 CN-3075..............................................................................................3-22
 CN-3076..............................................................................................3-23
 CN-3077..............................................................................................3-23
 CN-3078..............................................................................................3-23
 DPR-298..............................................................................................3-24
 DR-632.................................................................................................3-42
 ENC-112..............................................................................................3-44
 FL-348..................................................................................................3-46
 LE-355..................................................................................................3-46
 MB-1125.............................................................................................3-47
 MS-91...................................................................................................3-49
 NR-80....................................................................................................3-50
 PA-353.................................................................................................3-52
 SE-949..................................................................................................3-53
 SW-1402.............................................................................................3-53
 SW-1403.............................................................................................3-53
 SW-1404.............................................................................................3-53
 SW-1405.............................................................................................3-53
 SW-1406/A........................................................................................3-53
 SW-1407.............................................................................................3-53
 SY-363..................................................................................................3-55
 TG-265.................................................................................................3-72
 TX-126.................................................................................................3-76
 FrameWiring....................................................................................3-83
4. BoardLayouts
 CD-61...................................................................................................... 4-2
 CN-3069................................................................................................ 4-4
 CN-3070................................................................................................ 4-4
 CN-3071................................................................................................ 4-4
 CN-3072................................................................................................ 4-4
 CN-3073................................................................................................ 4-4
 CN-3074................................................................................................ 4-4
 CN-3075................................................................................................ 4-5
 CN-3076................................................................................................ 4-5
 CN-3077................................................................................................ 4-5
 CN-3078................................................................................................ 4-5
 DPR-298................................................................................................ 4-6
 DR-632................................................................................................... 4-9
 ENC-112................................................................................................ 4-9
 FL-348..................................................................................................4-10
 LE-355..................................................................................................4-10
 MB-1125.............................................................................................4-11
 MS-91...................................................................................................4-12

2HXC-100/V2 (J, E)
 NR-80....................................................................................................4-12
 PA-353.................................................................................................4-12
 SE-949..................................................................................................4-13
 SW-1402.............................................................................................4-13
 SW-1403.............................................................................................4-13
 SW-1404.............................................................................................4-13
 SW-1405.............................................................................................4-13
 SW-1406/A........................................................................................4-13
 SW-1407.............................................................................................4-13
 SY-363..................................................................................................4-14
 TG-265.................................................................................................4-18
 TX-126.................................................................................................4-19

3 (J)
HXC-100/V2 (J, E)
このマニュアルについて
本書の目的
本書は，HDCOLORCAMERAHXC-100 のサービスマニュアル Volume2です。
本書は，システム／サービスエンジニアの方々にご使用いただくことを想定し，本
機の保守に関する情報，部品レベルまでのサービスを前提とした情報（パーツリスト，
回路図，マウント図等）を記載しています。
関連マニュアル
本機には，この「サービスマニュアル Volume2」のほかに，下記のマニュアルが用
意されています。
. HXC-100取扱説明書（HXC-100に付属）
HXC-100を実際に運用および操作するのに必要なマニュアルです。
部品番号：4-137-704-0X（日本語）
部品番号：4-137-704-1X（英語）
. HXC-100取扱説明書 CD-ROM 版（UC,CE モデルに付属）
HXC-100を実際に運用および操作するのに必要なマニュアルです。
英語，フランス語，ドイツ語，イタリア語，およびスペイン語のオペレーション
マニュアル(PDF)が収録されています。
部品番号：4-137-707-0X
. サービスマニュアル Volume1( 別途用意 )
HXC-100 の保守に関する情報と，部品交換および調整などのサービスに関する情
報を記載しています。
.“SemiconductorPinAssignments”CD-ROM版（別途用意）
この “SemiconductorPinAssignments”CD-ROM 版は，放送用および業務用の機器
に使用されている半導体を検索することができます。
本書には，その機種に使用されている半導体一覧とその ID番号を記載しています
ので，この CD-ROM版と合わせて使用してください。
部品番号：9-968-546-06
商標について
このマニュアルに記載されている商標および登録商標は下記のとおりです。
.FRAM は，米国ラムトロンインターナショナル社の登録商標です。

3 (E)
HXC-100/V2 (J, E)
Manual Structure
Purpose of this manual
This manual is the service manual Volume 2 for HD Color Camera HXC-100.
This manual describes the information items that premise the service based on the
components parts such as spare parts lists, schematic diagrams and board layouts,
assuming use of system and service engineers.
Related manuals
Besides this service manual Volume 2 the following manual is available for this unit.
.HXC-100 Operation Instructions (Supplied with HXC-100)
This manual is necessary for application and operation of HXC-100.
Part number: 4-137-704-0X (Japanese)
Part number: 4-137-704-1X (English)
.HXC-100 Operation Instructions CD-ROM (Supplied with UC and CE
model)
This manual is necessary for application and operation of HXC-100.
The CD-ROM contains the English, French, German, Italian, and Spanish operation
instructions (PDF).
Part number: 4-137-707-0X
.Service manual Volume 1 (Available on request)
Describes the maintenance and service information necessary for parts replacement
and adjustments of HXC-100.
.“Semiconductor Pin Assignments” CD-ROM (Available on request)
This “Semiconductor Pin Assignments” CD-ROM allows you to search for semi-
conductors used in Broadcast and Professional equipment.
This manual contains a complete list of semiconductors and their ID Nos., and thus
should be used together with the CD-ROM.
Part number: 9-968-546-06
Trademarks
Trademarks and registered trademarks used in this manual are follows.
.FRAM is a registered trademark of Ramtron International Corporation.

1-1
HXC-100/V2 (J, E)
1-1. Notes on Repair Parts
1. Safety Related Components Warning
w
Components marked !are critical to safe operation.
Therefore, specified parts should be used in the case of
replacement.
2. Standardization of Parts
Some repair parts supplied by Sony differ from those
used for the unit. These are because of parts common-
ality and improvement.
Parts list has the present standardized repair parts.
3. Stock of Parts
Parts marked with “o” at SP (Supply Code) column of
the spare parts list may not be stocked. Therefore, the
delivery date will be delayed.
4. Harness
Harnesses with no part number are not registered as
spare parts.
Section 1
Spare Parts
1-1. 補修部品注意事項
1. 安全重要部品
!警告
!印のついた部品は安全性を維持するために重要
な部品です。したがって，交換する時は必ず指定
の部品を使ってください。
2. 部品の共通化
 ソニーから供給する補修用部品は，セットに使われて
いるものと異なることがあります。
 これは部品の共通化，改良等によるものです。
 部品表には現時点での共通化された補修用部品が記載
されています。
3. 部品の在庫
 部品表の SP（Supplycode）欄に“o”で示される部品は
在庫していないことがあり，納期が長くなることがあ
ります。
4. ハーネス
 部品番号の記載されていないハーネスは，サービス部
品として登録されていません。

1-2 HXC-100/V2 (J, E)
Inside Panel
1-2. Exploded Views
e
f
e
f
c
ab
c
a
b
13
12
10
9
3
5
5
7
6
5
15
5
7
6
2
4
11
1
4
8
6
7
6
7
14
BVTP3 x10
BVTP3 x10
No. Part No. SP Description
1 A-1708-081-A s MOUNTED CIRCUIT BOARD, SW-1402
2 A-1708-082-A s MOUNTED CIRCUIT BOARD, SW-1404
3 X-2348-330-1 s COVER ASSY, INSIDE (G)
4 2-640-315-02 o SCREW (M2X5), SMALL, +P, SW
5 3-603-679-02 s STAINLESS SCREW +B3X10
6 3-672-250-01 s RING (M2.6), O
7 3-701-439-11 s WASHER
8 3-870-137-02 s CAP, DROP PROTECTION
9 4-138-542-01 s COVER, SW
10 4-138-673-01 s LID, POWER SW
No. Part No. SP Description
11 4-138-719-01 s RUBBER, DROP PROTECTION
12 4-138-726-11 s SHEET, INSIDE(MULTI)
13 4-138-727-01 s LABEL(HANDLE)
14 4-138-735-01 s CUSHION (LARGE)
15 4-138-737-01 s CUSHION (SMALL)
7-685-647-91 s SCREW +BVTP 3X10 TYPE2 TT(B)

1-3
HXC-100/V2 (J, E)
Outside Panel
116
120
117
112
115
114
112
115
114
108
105
121
114
115
112
110
111
119
111
113
112
112
101 102 103
106
106106
119
121
121
121
121
107
107
121
121
104
121
109
118
118
109
BVTP3 x10
BVTP3 x10
UC JCE
No. Part No. SP Description
101 A-1705-805-A s TRIAX CN (K) ASSY (UC)
102 A-1705-819-A s TRIAX CN (T) ASSY (J)
103 A-1705-822-A s TRIAX CN (F) ASSY (CE)
104 A-1707-920-A s MOUNTED CIRCUIT BOARD, TX-126
105 A-1708-275-A s MOUNTED CIRCUIT BOARD, FL-348
106 1-500-082-21 s CLAMP, SLEEVE FERRITE
107 !1-833-470-21 s CABLE, FLEXIBLE FLAT (33P)
108 1-836-686-11 s CABLE, CONNECTOR WITH COAXIAL
109 2-640-315-02 o SCREW (M2X5), SMALL, +P, SW
110 3-176-525-01 o WASHER, SPRING
111 3-602-464-02 s WASHER, CONDUCTIVE
112 3-603-679-02 s STAINLESS SCREW +B3X10
113 3-637-901-11 s SCREW M2.6X5
114 3-672-250-01 s RING (M2.6), O
115 3-701-439-11 s WASHER
116 3-704-177-11 s EMBLEM (NO.7), SONY
117 4-138-545-11 s COVER, OUTSIDE
118 4-138-680-01 s SUPPORT, OUTSIDE PANEL
119 4-138-707-01 s WASHER, TRIAX(2)
120 4-138-738-01 s CUSHION, OUTSIDE
121 4-382-854-51 s SCREW (M3X6), P, SW (+)
7-685-647-91 s SCREW +BVTP 3X10 TYPE2 TT(B)

1-4 HXC-100/V2 (J, E)
SY-363 Board, Power Supply Assembly
No. Part No. SP Description
201 A-1705-807-A s POWER SUPPLY ASSY
202 A-1707-921-A s MOUNTED CIRCUIT BOARD, SY-363
203 A-1708-084-A s MOUNTED CIRCUIT BOARD, SW-1407
204 A-8286-163-B s PAD ASSY,SHOULDER
205 A-8286-346-A s PAD ASSY,SHOULDER
206 !1-528-174-11 s BATTERY, LITHIUM (CR2032 TYPE)
207 2-640-315-02 o SCREW (M2X5), SMALL, +P, SW
208 !4-138-724-01 s SHEET, PS CASE THERMAL
209 4-138-743-01 s SHEET, PS CASE SLIDE
210 4-382-854-51 s SCREW (M3X6), P, SW (+)
7-623-923-01 s WASHER 2.6, NYLON
7-682-548-09 s SCREW +B 3X8
OPTION
Low-repulsion shourder pad
(position fixed)
For
CD-61 board
For
CD-61 board
a
a
b
c
d
c
d
b
204
210
210
210
201
206
210
202
207
203
209
208
205
B3 x8
W 2.6, NYLON
HARNESS (AC)

1-5
HXC-100/V2 (J, E)
CD-61 Board, DPR-298 Board
No. Part No. SP Description
301 A-1707-917-A s MOUNTED CIRCUIT BOARD, ENC-112
302 A-1707-918-A s MOUNTED CIRCUIT BOARD, DPR-298
303 A-1707-919-A s MOUNTED CIRCUIT BOARD, CD-61
304 !1-831-104-11 s CABLE, FLEXIBLE FLAT (24 CORE)
305 2-640-315-02 o SCREW (M2X5), SMALL, +P, SW
306 !4-138-723-01 s SHEET, DPR THERMAL
307 !4-138-724-01 s SHEET, PS CASE THERMAL
308 4-138-743-01 s SHEET, PS CASE SLIDE
309 4-382-854-51 s SCREW (M3X6), P, SW (+)
a
a
a
c
d
a
b
a
a
b
For chassis
(Power supply assembly)
c
d
305
309
309
302
309
305
303
309
301 305
309
308
307
304
306

1-6 HXC-100/V2 (J, E)
Front Panel
No. Part No. SP Description
401 2-623-773-11 s BOLT (M3X8), STAINLESS
402 2-640-315-02 o SCREW (M2X5), SMALL, +P, SW
403 3-603-679-02 s STAINLESS SCREW +B3X10
404 3-678-629-04 s LEVER, MOUNT
405 3-701-505-01 s SET SCREW, DOUBLE POINT 3X3
406 3-710-054-01 s KNOB, FILTER
407 !4-138-444-01 s PANEL, FRONT (1M)
408 4-138-678-01 s CLAMP, CABLE
409 4-138-681-01 s COVER, SS SW
410 4-654-273-02 s ACE (M2), LOCK
7-623-208-22 s SW 3,TYPE 2
409
404
403
407
401
410
408
403
402
406
405
SW3
CCD block assembly

1-7
HXC-100/V2 (J, E)
CCD Block Assembly
No. Part No. SP Description
501 A-1706-080-A s CCD BLOCK ASSY (RP)
502 A-1707-916-A s MOUNTED CIRCUIT BOARD, TG-265
503 A-1708-085-A s MOUNTED CIRCUIT BOARD, SE-949
504 A-1708-086-A s MOUNTED CIRCUIT BOARD, NR-80
505 A-1708-273-A s MOUNTED CIRCUIT BOARD, DR-632
506 1-788-765-21 s FILTER UNIT, OPTICAL
507 !1-832-133-11 s CABLE, FLEXIBLE FLAT (50 CORE)
508 !1-836-688-11 s CABLE, FLEXIBLE FLAT (36 CORE)
509 !1-836-689-11 s CABLE, FLEXIBLE FLAT (10 CORE)
510 2-640-315-02 o SCREW (M2X5), SMALL, +P, SW
511 3-699-048-01 s CAP, MOUNT
512 4-138-446-01 s PLATE, FILTER ID (S)
7-627-452-18 s SCREW,PRECISION +K 2X3
502
510
501 508
507
510
507
505
509
507
510
510
510
512
503
510
504
510
511
506
K2 x3
PA-353 board
HARNESS
(BI-PA)
PA-353
board

1-8 HXC-100/V2 (J, E)
Front Boards, MB-1125 Board
No. Part No. SP Description
601 A-1708-075-A s MOUNTED CIRCUIT BOARD, MB-1125
602 A-1708-078-A s MOUNTED CIRCUIT BOARD, CN-3070
603 A-1708-079-A s MOUNTED CIRCUIT BOARD, CN-3071
604 A-1708-080-A s MOUNTED CIRCUIT BOARD, MS-91
605 A-1708-083-A s MOUNTED CIRCUIT BOARD, SW-1405
606 !1-831-081-11 s CABLE, FLEXIBLE FLAT (45 CORE)
607 !1-831-156-11 s CABLE, FLEXIBLE FLAT (36 CORE)
608 !1-966-584-11 s HARNESS, SUB (FRONT-MIC)
609 !1-966-586-11 s HARNESS, SUB (FRONT)
610 !1-966-587-11 s HARNESS, SUB (INSIDE)
611 !1-966-592-11 s HARNESS, SUB (POWER-SW)
612 !1-966-597-11 s HARNESS, SUB (ASSIGNABLE)
613 2-640-315-02 o SCREW (M2X5), SMALL, +P, SW
614 3-679-679-04 s KNOB,VR(AUDIO)
615 3-692-111-02 s KNOB,RE
616
613
613
612
610
604
613
607
617
616
601
613
613
613
606
613
613
603
618
602
613
605
615
619
613
614
608
613
611
609
BVTP3 x12
HARNESS
(POWER-CTL)
HARNESS
(STANDBY)
HARNESS
(LENS)
No. Part No. SP Description
616 4-137-924-01 s CLAMP (PJ-15B), CABLE
617 4-137-926-01 s SADDLE (LES-0505), EDGE
618 4-138-732-01 s CUSHION, LENS CN
619 4-138-733-01 s CUSHION, FRONT SW
7-685-648-99 s SCREW +BVTP 3X12 TYPE2 TT(B)

1-9
HXC-100/V2 (J, E)
Bottom
No. Part No. SP Description
701 A-8279-993-C s SHOE(D)ASSY,V
702 2-678-968-01 o TAPE AS (1215)
703 3-271-563-01 s SCREW +P M4X6
704 3-603-679-02 s STAINLESS SCREW +B3X10
705 3-626-781-03 s STOPPER
706 3-626-960-02 s GUARD,TAIL
707 3-637-901-11 s SCREW M2.6X5
708 3-729-072-02 s SCREW, +K (4X8)
709 3-796-946-02 s TAPE(A)
710 3-854-769-02 s SHOE(D),CAMERA
711 3-854-770-02 s WEDGE(D),MOUNTING
7-621-555-30 s SCREW +K2X5
709
706
704
702
710
708
711
703
701
704
707
705
704
a
a
a

1-10 HXC-100/V2 (J, E)
Top
No. Part No. SP Description
801 A-1708-072-A s MOUNTED CIRCUIT BOARD, LE-355
802 A-1708-073-A s MOUNTED CIRCUIT BOARD, SW-1403
803 A-1708-077-A s MOUNTED CIRCUIT BOARD, CN-3069
804 A-8278-412-J s SHOE ASSY,VF
805 X-2348-333-1 s SUB ASSY, HANDLE
806 X-2348-338-1 s COVER ASSY, HANDLE
807 X-3710-037-1 s SUSPENSION ASSY (C)
808 !1-966-589-11 s HARNESS, SUB (HANDLE-SW)
809 !1-966-590-11 s HARNESS, SUB (HANDLE-TALLY)
810 2-640-315-02 o SCREW (M2X5), SMALL, +P, SW
811 3-603-679-02 s STAINLESS SCREW +B3X10
812 3-627-853-07 s SHOE,SLIDE
813 3-637-901-11 s SCREW M2.6X5
814 3-654-615-02 s COLLAR, SUSPENSION
815 3-701-447-11 s WASHER, 10
816 3-701-505-01 s SET SCREW, DOUBLE POINT 3X3
817 3-710-024-02 s PACKING, VF
818 3-711-765-01 s BOLT (M3), HEXAGON SOCKET
819 4-138-139-01 s STOP RING 9, TYPE-CE
820 4-138-535-01 s PLATE, VF SHOE
814
807
824
819
827
815
816
821
823
809
811
830
801
808
802
810
822
806
831
829
817
805
814
807
811
826
820
825 816
812
804
818
803
813 828
W10 WAVE
SW3
HARNESS
(VF)
a
a
b
b
No. Part No. SP Description
821 4-138-536-01 s LEVER, LOCK
822 4-138-542-01 s COVER, SW
823 4-138-676-01 s GRIP
824 4-138-679-01 s SCREW, BLIND
825 4-138-691-01 s SCREW, PIPE CAP
826 4-138-692-01 s PIPE, VF SLIDE
827 4-138-693-01 s SCREW, VF SLIDE LOCK
828 4-138-694-01 s LOCK, VF SLIDE
829 4-138-727-01 s LABEL(HANDLE)
830 4-138-742-01 s CUSHION, HANDLE TALLY
831 4-654-273-02 s ACE (M2), LOCK
7-623-208-22 s SW 3,TYPE 2
7-623-710-57 s WASHER 10, WAVE TYPE

1-11
HXC-100/V2 (J, E)
Intercom Panel
No. Part No. SP Description
901 A-1708-087-A s MOUNTED CIRCUIT BOARD, CN-3072
902 A-1708-088-A s MOUNTED CIRCUIT BOARD, SW-1406 (UC, J)
903 A-1708-274-A s MOUNTED CIRCUIT BOARD, SW-1406 (CE)
904 A-1708-266-A s MOUNTED CIRCUIT BOARD, CN-3073
905 !1-787-847-11 s FAN, DC (40SQUARE)
906 !1-831-104-11 s CABLE, FLEXIBLE FLAT (24 CORE)
907 2-640-315-02 o SCREW (M2X5), SMALL, +P, SW
908 3-869-842-01 s CAP,SW
909 3-903-660-01 s DROP PROTECTION,TOGGLE
910 4-138-449-01 s SHEET,INCOM(P) (CE)
911 4-138-674-01 s CAP, CONNECTOR (1)
912 4-138-682-01 s SW COVER
913 4-138-683-01 s KNOB, ENCODER
914 4-138-686-01 s DUCT, FAN
915 !4-138-699-01 s PANEL, INCOM
916 4-138-725-01 s SHEET, INCOM(N) (UC, J)
917 4-138-736-01 s SHEET, WATER PROOF INCOM
918 4-654-273-02 s ACE (M2), LOCK
7-685-648-99 s SCREW +BVTP 3X12 TYPE2 TT(B)
UC
J
UC
J
CE
CE
913
910
916
903
902
905
914
907
906
909 908
917
904
918
912
915
918
918
918
911
901
907 BVTP3 x12
HARNESS
(INCOM)

1-12 HXC-100/V2 (J, E)
Connector Panel
No. Part No. SP Description
1001 A-1708-267-A s MOUNTED CIRCUIT BOARD, CN-3074
1002 A-1708-268-A s MOUNTED CIRCUIT BOARD, CN-3075
1003 A-1708-269-A s MOUNTED CIRCUIT BOARD, CN-3076
1004 A-1708-270-A s MOUNTED CIRCUIT BOARD, CN-3077
1005 A-1708-271-A s MOUNTED CIRCUIT BOARD, CN-3078
1006 1-784-240-11 s CONVERTER, COAXIAL CONNECTOR
1007 1-829-055-11 s CABLE ASSEMBLY, COAXIAL
1008 !1-835-324-11 s CABLE, FLEXIBLE FLAT (36 CORE)
1009 !1-966-579-11 s HARNESS, SUB (EARPHONE)
1010 3-637-901-11 s SCREW M2.6X5
1011 3-863-319-01 s BRACKET BNC
1012 4-138-675-01 s CAP, CONNECTOR (2)
1013 4-138-687-01 s COVER, SLIDE SWITCH
1014 !4-138-698-01 s PANEL, MIC
1015 4-138-731-01 s SHEET,WATER PROOF SW
1016 4-654-273-02 s ACE (M2), LOCK
7-685-648-99 s SCREW +BVTP 3X12 TYPE2 TT(B)
1012
1016
1014
1010
1016
1016
1010
1001
1006
1011
1007
1002
1015
1013
1004
1005
1008
1009
1003
BVTP3 x12
HARNESS
(EXT-DC)
HARNESS
(BNC)
HARNESS
(REMOTE)
HARNESS
(AUDIO)
HARNESS
(DC-OUT)
BVTP3 x12
