SERVICE MANUAL

LEVEL 2

Link

SERVICE NOTE

DISASSEMBLY

BLOCK DIAGRAMS

FRAME SCHEMATIC DIAGRAMS

SCHEMATIC DIAGRAMS

PRINTED WIRING BOARDS

ADJUSTMENTS

REPAIR PARTS LIST

SPECIFICATIONS

SERVICE NOTE

DISASSEMBLY

BLOCK DIAGRAMS

FRAME SCHEMATIC DIAGRAMS

SCHEMATIC DIAGRAMS

PRINTED WIRING BOARDS

ADJUSTMENTS

REPAIR PARTS LIST

SPECIFICATIONS

Link

On the VC-283 board

This service manual provides the information that is premised the circuit board replacement service and not intended repair

inside the VC-283 board.

Therefore, schematic diagram, printed wiring board, waveforms, mounted parts location and electrical parts list of the VC-283

board are not shown.

The following pages are not shown.

Schematic diagram .............................Pages 4-33 to 4-70

Printed wiring board ............................Pages 4-89 to 4-92

Waveforms ...........................................

Pages 4-94 to 4-95

Mounted parts location .............................

Pages 4-98 to 4-99

Electrical parts list ................................... Pages 6-18 to 6-25

DCR-TRV40/TRV40E/

TRV50/TRV50E

RMT-811

US Model

Canadian Model

DCR-TRV50

AEP Model

East European Model

DCR-TRV40E/TRV50E

UK Model

Australian Model

DCR-TRV50E

E Model

DCR-TRV40/TRV40E/TRV50/TRV50E

Hong Kong Model

DCR-TRV40/TRV50E

Tourist Model

DCR-TRV40/TRV40E

Korea Model

DCR-TRV40

Chinese Model

DCR-TRV40E

J MECHANISM

Revision History

Ver 1.3 2003. 11

• For INSTRUCTION MANUAL, refer to separate file (992995171.pdf).

• For MECHANISM ADJUSTMENTS, refer to the “DV MECHANICAL ADJUSTMENT MANUAL VI

J MECHANISM ” (9-929-807-11).

• HOW TO OPEN THE FLASH WHEN THE FLASH DOESN’T OPEN

DIGITAL VIDEO CAMERA RECORDER

Photo: DCR-TRV50E

—2 —

DCR-TRV40/TRV40E/TRV50/TRV50E

SPECIFICATIONS

SAFETY-RELATED COMPONENT WARNING!!

COMPONENTS IDENTIFIED BY MARK 0OR DOTTED LINEWITH

MARK 0ON THE SCHEMATIC DIAGRAMS AND IN THE PARTS

LIST ARE CRITICAL TO SAFE OPERATION. REPLACE THESE

COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS

APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS

PUBLISHED BY SONY.

ATTENTION AU COMPOSANT AYANT RAPPORT

À LA SÉCURITÉ!

LES COMPOSANTS IDENTIFÉS PAR UNE MARQUE 0SUR LES

DIAGRAMMES SCHÉMATIQUES ET LA LISTE DES PIÈCES SONT

CRITIQUES POUR LA SÉCURITÉ DE FONCTIONNEMENT. NE

REMPLACER CES COMPOSANTS QUE PAR DES PIÈSES SONY

DONT LES NUMÉROS SONT DONNÉS DANS CE MANUEL OU

DANS LES SUPPÉMENTS PUBLIÉS PAR SONY.

COVER

CAUTION :

Danger of explosion if battery is incorrectly replaced.

Replace only with the same or equivalent type.

Video camera

recorder

System

Video recording system

2 rotary heads

Helical scanning system

Audio recording system

Rotary heads, PCM system

Quantization: 12 bits (Fs 32 kHz,

stereo 1, stereo 2), 16 bits

(Fs 48 kHz, stereo)

Video signal

PAL colour, CCIR standards

DCR-TRV40/TRV50:

NTSC colour, EIA standards

DCR-TRV40E/TRV50E: DCR-TRV40/TRV50:

Chrominance signal: 0.3 Vp-p,

DCR-TRV40E/TRV50E:

Usable cassette

Mini DV cassette with the

mark printed

Tape speed

SP: Approx. 18.81 mm/s

LP: Approx. 12.56 mm/s

Recording/playback time

(using cassette DVM60)

SP: 1 hour

LP: 1.5 hours

Fastforward/rewind time

(using cassette DVM60)

When using the battery pack:

Approx. 2 min. and 30 seconds

When using the AC power adaptor:

Approx. 1 min. and 45 seconds

Viewfinder

Electric viewfinder (colour)

Image device

4.5 mm (1/4 type) CCD (Charge

Coupled Device)

Gross: Approx. 1 550 000 pixels

Effective (still):

Approx. 1 390 000 pixels

Effective (moving):

Approx. 970 000 pixels

Lens

Carl Zeiss Vario-Sonnar

Combined power zoom lens

Filter diameter: 37 mm

(1 1/2 in)

10×(Optical), 120×(Digital)

F=1.8~2.2

Focal length

4.2 – 42 mm (3/16 – 1 11/16 in.)

When converted to a 35 mm still

camera

In CAMERA:

48 – 480 mm (1 15/16 – 19 in.)

In MEMORY:

40 – 400 mm (1 5/8 – 15 3/4 in.)

Colour temperature

Auto, HOLD (Hold), nIndoor

(3 200 K), Outdoor (5 800 K)

Minimum illumination

7 lx (lux) (F 1.8)

0 lx (lux) (in the NightShot mode)*

* Objects unable to be seen due to

the dark can be shot with infrared

lighting.

Input/Output connectors

S video input/output

4-pin mini DIN

Luminance signal: 1 Vp-p,

75 Ω(ohms), unbalanced

Chrominance signal: 0.3 Vp-p,

75 Ω(ohms), unbalanced

Audio/Video input/output

AV MINI JACK, 1 Vp-p,

75 Ω(ohms), unbalanced, sync

negative

327 mV, (at output impedance

more than 47 kΩ(kilohms))

Output impedance with less than

2.2 kΩ(kilohms)/Stereo minijack (ø

3.5 mm)

Input impedance more than

47 kΩ(kilohms)

DV input/output

4-pin connector

Headphone jack

Stereo minijack (ø 3.5 mm)

LANC jack

Stereo mini-minijack (ø 2.5 mm)

USB jack

mini-B

MIC jack

Minijack, 0.388 mV low impedance

with 2.5 to 3.0 V DC, output

impedance 6.8 kΩ(kilohms) (ø 3.5

mm)

Stereo type

LCD screen


8.8 cm (3.5 type)

72.2 ×50.4 mm (2 4/5 ×2 in.)

Total dot number

246 400 (1 120 ×220)

Wireless communications

(DCR-TRV50/TRV50E only)

Communications system

Bluetooth standard Ver.1.1

Max. baud rate

1) 2)

Approx. 723 kbps

Output

Bluetooth standard Power Class 2

Communications distance

Max. wireless distance Approx. 10

m (393 3/4 in.) (When connecting to

BTA-NW1)

Compatible Bluetooth profile

Generic Access Profile

Dial-up Networking Profile

Operating frequency band

2.4 GHz band (2.400 GHz –

2.483 5 GHz)

Max. baud rate of Bluetooth

standard Ver.1.1

Varies according to the distance

between communicating devices,

presence of obstacles, radiowave

conditions, and other factors.

This is a specification matched to

specific usage requirements

between Bluetooth compatible

devices. It is laid down in the

Bluetooth standards.

General

Power requirements

7.2 V (battery pack)

8.4 V (AC power adaptor)

Average power consumption

(when using the battery pack)

During camera recording using

LCD

4.4 W

Viewfinder

3.3 W

Operating temperature

0°C to 40°C (32°F to 104°F)

Storage temperature

–20°C to + 60°C

(–4°F to + 140°F)

Dimensions (Approx.)

72 ×91 ×168 mm

(2 7/8 ×3 5/8 ×6 5/8 in.) (w/h/d)

Mass (Approx.)

700 g (1 lb 8 oz)

main unit only

800 g (1 lb 12 oz)

including the battery pack

NP-FM50, cassette DVM60 and lens

cap

Supplied accessories

See page 3.

AC power adaptor

Power requirements

100 – 240 V AC, 50/60 Hz

Power consumption

23 W

Output voltage

DC OUT: 8.4 V, 1.5 A in the

operating mode

Operating temperature

0°C to 40°C (32°F to 104°F)

Storage temperature

–20°C to + 60°C

(–4°F to + 140°F)

Dimensions (approx.)

125 ×39 ×62 mm

(5 ×1 9/16 ×2 1/2 in.) (w/h/d)

excluding projecting parts

Mass (approx.)

280 g (9.8 oz)

excluding mains lead

Battery pack

Maximum output voltage

DC 8.4 V

Output voltage

DC 7.2 V

Capacity

8.5 Wh (1 180 mAh)

Dimensions (approx.)

38.2 ×20.5 ×55.6 mm

(1 9/16 ×13/16 ×2 1/4 in.)

(w/h/d)

Mass (approx.)

76 g (2.7 oz)

Type

Lithium ion

“Memory Stick”

Memory

Flash memory

8MB: MSA-8A

Operating voltage

2.7 – 3.6 V

Power consumption

Approx. 45 mA in the operating

mode

Approx. 130 µA in the standby

mode

Dimensions (approx.)

50 ×2.8 ×21.5 mm

(2 ×1/8 ×7/8 in.) (w/h/d)

Mass (approx.)

4 g (0.14 oz)

Design and specifications are

subject to change without notice.

—3 —

DCR-TRV40/TRV40E/TRV50/TRV50E

1. Check the areaof your repairfor unsoldered or poorly-soldered

connections. Check the entireboard surface for soldersplashes

and bridges.

2. Check the interboard wiring to ensure that no wires are

"pinched" or contact high-wattage resistors.

3. Look for unauthorized replacement parts, particularly

transistors, that were installed during a previous repair. Point

them out to the customer and recommend their replacement.

4. Look for parts which,through functioning, show obvious signs

of deterioration. Point them out to the customer and

recommend their replacement.

5. Check the B+ voltage to see it is at the values specified.

6. Flexible Circuit Board Repairing

• Keep the temperature of the soldering iron around 270˚C

during repairing.

• Do not touch the soldering iron on the same conductor of the

circuit board (within 3 times).

• Be careful not to apply force on the conductor when soldering

or unsoldering.

Unleaded solder

Boards requiring use of unleaded solder are printed with the lead-

free mark (LF) indicating the solder contains no lead.

(Caution: Some printed circuit boards may not come printed with

the lead free mark due to their particular size.)

: LEAD FREE MARK

Unleaded solder has the following characteristics.

•Unleaded solder melts at a temperature about 40°C higher than

ordinary solder.

Ordinary soldering irons can be used but the iron tip has to be

applied to the solder joint for a slightly longer time.

Soldering irons using a temperature regulator should be set to

about 350°C.

Caution: The printed pattern (copper foil) may peel away if the

heated tip is applied for too long, so be careful!

•Strong viscosity

Unleaded solder is more viscous (sticky, less prone to flow) than

ordinary solder so use caution not to let solder bridges occur such

as on IC pins, etc.

•Usable with ordinary solder

It is best to use only unleaded solder but unleaded solder may

also be added to ordinary solder.

SAFETY CHECK-OUT

After correcting the original service problem, perform the following

safety checks before releasing the set to the customer.

qg qh

1AC-L10A/L10B/L10C AC power adaptor (1),

mains lead (1)

2NP-FM50 battery pack (1)

3A/V connecting cable (1)

4Wireless Remote Commander (1)

5Size R6 (size AA) battery for Remote

Commander (2)

6Shoulder strap (1)

7Lens cap (1)

8Lens hood (1)

9“Memory Stick” (1)

0USB cable (1)

qa CD-ROM (USB Driver) (1)

qs Cleaning cloth (1)

qd Stylus (1) (DCR-TRV50/TRV50E only)

qf 21-pin adaptor (European models only) (1)

qg 2-pin conversion adaptor (1)

(Tourist model only)

SPVD-008 (Except US, Canadian model only)

SPVD-008 (I) (US, Canadian model only)

qh 2-pin conversion adaptor (1)

(E, Hong Kong model only)

•SUPPLIED ACCESSORIES

Makesure thatthe followingaccessories are supplied with yourcamcorder.

—4 —

DCR-TRV40/TRV40E/TRV50/TRV50E

TABLE OF CONTENTS

1. SERVICE NOTE

1-1. SERVICE NOTE ·····························································1-1

1. POWER SUPPLY DURING REPAIRS ··························1-1

2. HOW TO OPEN THE FLASH WHEN THE FLASH

DOESN’T OPEN ····························································1-1

3. TO TAKE OUT A CASSETTE WHEN NOT EJECT

(FORCE EJECT) ·····························································1-1

4. DISCHARGING OF THE FLASHLIGHT POWER

SUPPLY CAPACITOR ···················································1-2

4-1. PREPARING THE SHORT JIG ······································1-2

4-2. DISCHARGING THE CAPACITOR······························1-2

1-2. SELF-DIAGNOSIS FUNCTION····································1-3

1. SELF-DIAGNOSIS FUNCTION····································1-3

2. SELF-DIAGNOSIS DISPLAY ·······································1-3

3. SERVICE MODE DISPLAY ··········································1-3

3-1. Display Method ·······························································1-3

3-2. Switching of Backup No. ················································1-3

3-3. End of Display·································································1-3

4. SELF-DIAGNOSIS CODE TABLE································1-4

2. DISASSEMLY

2-1. LCD SECTION (PD-165 BOARD) ································2-3

2-2. EVF SECTION (LB-078 BOARD)·································2-4

2-3. TOP CABINET ·······························································2-5

2-4. FRONT PANEL SECTION·············································2-6

2-5. MA-408 BOARD ····························································2-7

2-6. CABINET (R) SECTION (1)··········································2-8

2-7. CABINET (R) SECTION (2)··········································2-8

2-8. BATTERY SECTION ·····················································2-9

2-9. BT-003 BOARD (TRV50/TRV50E) ·······························2-9

2-10. EXTERNAL CONNECTOR (HOT SHOE) ·················2-10

2-11. DD HEAT SINK····························································2-10

2-12. EVF SECTION······························································2-11

2-13. FLASH UNIT (FLASH SECTION) (1) ························2-11

2-14. FLASH UNIT (FLASH SECTION) (2) ························2-12

2-15. FLASH UNIT (FLASH SECTION) (3) ························2-12

2-16. FLASH UNIT (FLASH SECTION) (4) ························2-13

2-17. DD-176 BOARD ···························································2-14

2-18. VC-283 BOARD, MECHANISM DECK (1) ···············2-15

2-19. VC-283 BOARD, MECHANISM DECK (2) ···············2-15

2-20. VC-283 BOARD, MECHANISM DECK (3) ···············2-16

2-21. LENS SECTION ···························································2-16

2-22. JK-219 BOARD ····························································2-17

2-23. CD-381 BOARD, 690C (CZ) BLOCK ASSEMBLY

(LENS DEVICE)···························································2-17

2-24. CS FRAME ASSEMBLY ··············································2-20

2-25. FLASH UNIT································································2-20

2-26. CONTROL SWITCH BLOCK (PS-2890) ····················2-21

2-27. MEMORY STICK CONNECTOR ·······························2-21

2-28. CK-115 BOARD, SPEAKER (2.0CM)·························2-22

2-29. HINGE SECTION·························································2-22

2-30. HINGE ASSEMBLY ·····················································2-23

2-31. CIRCUIT BOARDS LOCATION ·································2-24

2-32. FLEXIBLE BOARDS LOCATION ······························2-25

3. BLOCK DIAGRAMS

3-1. OVERALL BLOCK DIAGRAM (1/4) ···························3-1

3-2. OVERALL BLOCK DIAGRAM (2/4) ···························3-3

3-3. OVERALL BLOCK DIAGRAM (3/4) ···························3-5

3-4. OVERALL BLOCK DIAGRAM (4/4) ···························3-7

3-5. POWER BLOCK DIAGRAM (1/2) ································3-9

3-6. POWER BLOCK DIAGRAM (2/2) ······························3-11

4. PRINTED WIRING BOARDS AND

SCHEMATIC DIAGRAMS

4-1. FRAME SCHEMATIC DIAGRAM (1/4)·······················4-1

FRAME SCHEMATIC DIAGRAM (2/4)·······················4-3

FRAME SCHEMATIC DIAGRAM (3/4) ·······················4-5

FRAME SCHEMATIC DIAGRAM (4/4) ·······················4-7

4-2. SCHEMATIC DIAGRAMS ··········································4-11

•CD-381 (CCD IMAGER)

SCHEMATIC DIAGRAM ····························4-11

•JK-219 (AV IN/OUT, STEADY SHOT)

SCHEMATIC DIAGRAM ····························4-13

•CK-115 (CONTROL SWITCH)

SCHEMATIC DIAGRAM ····························4-15

•FK-2890, PS-2890 (CONTROL SWITCH BLOCK), FP-

460 FLEXIBLE

SCHEMATIC DIAGRAM ···························4-17

•MA-408 (1/2)(MIC AMP, REMOTE COMMANDER

RECEIVER)

SCHEMATIC DIAGRAM ····························4-19

•MA-408 (2/2)(LANC, EXT MIC)

SCHEMATIC DIAGRAM ····························4-21

•PD-165 (1/2)(RGB DRIVE, TIMING GENERATOR)

SCHEMATIC DIAGRAM ····························4-23

•PD-165 (2/2)(LCD DRIVER, BACK LIGHT)

SCHEMATIC DIAGRAM ····························4-25

•DD-176 (1/2)(DC/DC CONVERTER)

SCHEMATIC DIAGRAM ····························4-27

•DD-176 (2/2)(CONNECTOR)

SCHEMATIC DIAGRAM ····························4-29

•FP-100 (MODE SWITCH), FP-228 (DEW SENSOR),

FP-102 (TAPE TOP/END SENSOR, S/T REEL)

FLEXIBLE BOARD ·····································4-31

Shematic diagram of the VC-283 board are not shown.

Pages from 4-33 to 4-70 are not shown.

4-3. PRINTED WIRING BOARDS ·····································4-71

•CD-381 (CCD IMAGER)

PRINTED WIRING BOARD ·······················4-71

•FP-460 FLEXIBLE BOARD ·····································4-72

•JK-219 (AV IN/OUT, STEADY SHOT)

PRINTED WIRING BOARD ·······················4-73

•CK-115 (CONTROL SWITCH)

PRINTED WIRING BOARD ·······················4-77

•MA-408 (MIC AMP, REMOTE COMMANDER

RECEIVER, LANC, EXT MIC)

PRINTED WIRING BOARD ·······················4-79

•FP-461 FLEXIBLE BOARD ·····································4-81

•SE-124 (MF-SENSOR)

PRINTED WIRING BOARD ·······················4-82

•PD-165 (RGB DRIVE, TIMING GENERATOR, LCD

DRIVER, BACK LIGHT)

PRINTED WIRING BOARD ·······················4-83

•DD-176 (DC/DC CONVERTER, CONNECTOR)

PRINTED WIRING BOARD ·······················4-85

•FP-100 (MODE SWITCH), FP-228 (DEW SENSOR),

FP-102 (TAPE TOP/END SENSOR, S/T REEL)

FLEXIBLE BOARDS···································4-87

•LB-078 (EVF BACK LIGHT)

PRINTED WIRING BOARD ·······················4-87

Printed wiring board of the VC-283 board are not shown.

Pages from 4-89 to 4-92 are not shown.

4-4. WAVEFORMS ······························································4-93

Waveforms of the VC-283 board are not shown.

Pages from 4-94 to 4-95 are not shown.

—5 —

DCR-TRV40/TRV40E/TRV50/TRV50E

4-5. MOUNTED PARTS LOCATION ·································4-96

Mounted parts location of the VC-283 board is not shown.

Pages from 4-98 to 4-99 are not shown.

5. ADJUSTMENT

1. Adjusting items when replacing main parts and boards. ···5-2

5-1. CAMERA SECTION ADJUSTMENT ···························5-4

1-1. PREPARATIONS BEFORE ADJUSTMENT

(CAMERA SECTION) ···················································5-4

1-1-1.List of Service Tools························································5-4

1-1-2.Preparations ·····································································5-5

1-1-3.Precaution ········································································5-7

1. Setting the Switch····························································5-7

2. Order of Adjustments ······················································5-7

3. Subjects ···········································································5-7

1-2. INITIALIZATION OF 8, A, B, C, D, E, F, 1B, 1E, 1F

PAGE DATA ····································································5-8

1-2-1.INITIALIZATION OF A, D PAGE DATA ······················5-9

1. Initializing the A, D Page Data········································5-9

2. Modification ofA, D Page Data ······································5-9

3. A Page Table····································································5-9

4. D Page Table··································································5-10

1-2-2.INITIALIZATION OF B, 1B PAGE DATA ··················5-11

1. Initializing the B, 1B Page Data ····································5-11

2. Modification of B, 1B Page Data ··································5-11

3. Loader Writing Inhibit Mode Setting ····························5-11

4. Writing the Network Default Setting Value

(DCR-TRV50/TRV50E) ················································5-11

5. B Page Table ··································································5-12

6. 1B Page Table ································································5-12

1-2-3.INITIALIZATION OF 8, C PAGE DATA·····················5-13

1. Initializing the 8, C Page Data·······································5-13

2. Modification of 8, C Page Data ·····································5-13

3. 8 Page Table···································································5-13

4. C Page Table ··································································5-14

1-2-4.INITIALIZATION OF E, F, 1E, 1F PAGE DATA ········5-16

1. Initializing the E, F, 1E, 1F Page Data ··························5-16

2. Modification of E, F, 1E, 1F Page Data·························5-16

3. E Page Table ··································································5-17

4. F Page Table ··································································5-18

5. 1E Page Table ································································5-19

6. 1F Page Table ································································5-20

1-3. CAMERA SYSTEM ADJUSTMENTS ························5-21

1. 40.5MHz/54MHz Origin Oscillation Adjustment

(VC-283 board) ·····························································5-21

2. HALL Adjustment ·························································5-22

3. MAX GAIN Adjustment ···············································5-23

4. CCD Output 2ch Matching Adjustment (1) ··················5-23

5. CCD Output 2ch Matching Adjustment (2) ··················5-24

6. MR Adjustment ·····························································5-24

7. Flange Back Adjustment (Using Minipattern Box)·······5-25

8. Flange Back Adjustment (Using Flange Back Adjustment

Chart and Subject More Than 500mAway) ·················5-26

8-1. Flange Back Adjustment (1) ··········································5-26

8-2. Flange Back Adjustment (2) ··········································5-26

9. Flange Back Check························································5-27

10. Picture Frame Setting ····················································5-27

11. Color Reproduction Adjustment····································5-28

12. Auto White Balance & LV Standard Data Input ···········5-29

13. Auto White Balance Adjustment ···································5-30

14. White Balance Check ····················································5-31

15. Mechanical Shutter Adjustment ····································5-32

16. Black Defective CCD Adjustment·································5-32

17. Strobe Light Level Adjustment ·····································5-33

18. Strobe White Balance Adjustment & Check ·················5-33

19. AF Laser Output Adjustment ········································5-34

20. AF Laser Check ·····························································5-35

21. Steady Shot Check·························································5-36

1-4. COLOR ELECTRONIC VIEWFINDER SYSTEM

ADJUSTMENT·····························································5-37

1. VCO Adjustment (VC-283 board) ································5-37

2. RGB AMP Adjustment (VC-283 board) ·······················5-38

3. Contrast Adjustment (VC-283 board) ···························5-38

4. Backlight Adjustment (VC-283 board) ·························5-39

5. White Balance Adjustment (VC-283 board) ·················5-39

1-5. LCD SYSTEM ADJUSTMENT ···································5-40

1. VCO Adjustment (PD-165 board) ·································5-40

2. RGB AMP Adjustment (PD-165 board)························5-41

3. Contrast Adjustment (PD-165 board)····························5-41

4. COM AMP Adjustment (PD-165 board)·······················5-42

5. V COM Adjustment (PD-165 board) ····························5-42

6. White Balance Adjustment (PD-165 board)··················5-43

5-2. MECHANISM SECTION ADJUSTMENT··················5-44

2-1. HOE TO ENTER RECORD MODE WITHOUT

CASSETTE ···································································5-44

2-2. HOE TO ENTER PLAYBACK MODE WITHOUT

CASSETTE ···································································5-44

2-3. TAPE PATH ADJUSTMENT ········································5-44

1. Preparation for Adjustment ···········································5-44

2. Processing after Completing Operations:······················5-44

5-3. VIDEO SECTION ADJUSTMENT······························5-45

3-1. PREPARATIONS BEFORE ADJUSTMENTS ············5-45

3-1-1.Equipment to Required··················································5-45

3-1-2.Precautions on Adjusting ···············································5-46

3-1-3.Adjusting Connectors ····················································5-47

3-1-4.Connecting the Equipment ············································5-47

3-1-5.Alignment Tapes····························································5-48

3-1-6.Input/Output Level and Impedance ·······························5-48

3-2. SYSTEM CONTROL SYSTEM ADJUSTMENT ········5-49

1. Initialization of 8, A, B, C, D, E, F, 1B, 1E, 1F

Page Data·······································································5-49

2. Touch Panel Adjustment ················································5-49

3. Serial No. Input ·····························································5-50

3-1. Company ID Input·························································5-50

3-2. Serial No. Input ·····························································5-50

3-3. SERVO AND RF SYSTEM ADJUSTMENT ···············5-52

1. Cap FG Duty Adjustment (VC-283 Board)···················5-52

2. PLL f0& LPF f0Adjustment (VC-283 Board)··············5-52

3. Switching Position Adjustment (VC-283 Board) ··········5-53

4. AGC Center Level and APC & AEQ Adjustment ·········5-53

4-1. Preparations before adjustments····································5-53

4-2. AGC Center LevelAdjustment (VC-283 Board) ··········5-53

4-3. APC & AEQ Adjustment (VC-283 Board) ···················5-54

4-4. Processing after Completing Adjustments ····················5-54

5. PLL f0& LPF f0Fine Adjustment (VC-283 Board)······5-55

3-4. VIDEO SYSTEM ADJUSTMENTS·····························5-56

1. Chroma BPF fo Adjustment (VC-283 Board) ···············5-56

2. SVIDEO OUTY LevelAdjustment (VC-283 Board) ····5-56

3. S VIDEO OUT Chroma Level Adjustment

(VC-283 Board)·····························································5-57

VIDEO OUTY, Chroma Level Check (VC-283 Board) ··

5-57

3-5. AUDIO SYSTEM ADJUSTMENTS ····························5-58

1. Playback Level Check ···················································5-59

2. Overall Level Characteristics Check ·····························5-59

3. Overall Distortion Check···············································5-59

4. Overall Noise Level Check············································5-59

5. Overall Separation Check··············································5-59

5-4. SERVICE MODE ··························································5-60

4-1. ADJUSTMENT REMOTE COMMANDER ················5-60

1. Using the adjustment remote commander ·····················5-60

2. Precautions upon using the adjustment remote

commander ····································································5-60

4-2. DATA PROCESS···························································5-61

—6 —

DCR-TRV40/TRV40E/TRV50/TRV50E

4-3. SERVICE MODE ··························································5-62

1. Setting the Test Mode ····················································5-62

2. Emergence Memory Address ········································5-62

2-1. EMG Code (Emergency Code) ·····································5-62

2-2. MSW Code ····································································5-63

3. Bit value discrimination ················································5-64

4. Switch check (1) ····························································5-64

5. Switch check (2) ····························································5-64

6. Switch check (3) ····························································5-65

7. Switch check (4) ····························································5-65

8. Record of Use check (1) ················································5-66

9. Record of Use check (2) ················································5-66

10. Record of Self-diagnosis check ·····································5-66

6. REPAIR PARTS LIST

6-1. EXPLODED VIEWS ······················································6-1

6-1-1.OVERALL SECTION·····················································6-1

6-1-2.CABINET (R) SECTION ···············································6-2

6-1-3.LCD SECTION ·······························································6-3

6-1-4.CABINET (L) SECTION-1 ············································6-4

6-1-5.CABINET (L) SECTION-2 ············································6-5

6-1-6.EVF SECTION································································6-6

6-1-7.LENS SECTION ·····························································6-7

6-1-8.CASSETTE COMPARTMENTASSY, DRUMASSY ···6-8

6-1-9.LS CHASSIS BLOCK ASSEMBLY·······························6-9

6-1-10. MECHANICAL CHASSIS BLOCK ASSEMBLY ····6-10

6-2. ELECTRICAL PARTS LIST ········································6-11

Parts list of the VC-283 board are not shown.

Pages from 6-18 to 6-25 are not shown.

*Color reproduction frame is shown on page 187.

1-1

SECTION 1

SERVICE NOTE

DCR-TRV40/TRV40E/TRV50/TRV50E

COVER

1-1. SERVICE NOTE

1. POWER SUPPLY DURING REPAIRS

In this unit, about 10 seconds after power is supplied to the battery terminal using the regulated power supply (8.4V), the power is shut off so

that the unit cannot operate.

This following two methods are available to prevent this. Take note of which to use during repairs.

Method 1.

Use the AC power adaptor (AC-L10,AC-VQ800 etc.).

Method 2.

Connect the servicing remote commander RM-95 (J-6082-053-B) to the LANC jack, and set the commander switch to the “ADJ” side.

2. HOW TO OPEN THE FLASH WHEN THE FLASH DOESN’T OPEN

VC-283 board

CN1010

: Unloading

: Loading

Loading motor

DC power supply

(+4.5Vdc)

Disconnect from

CN1010 (27P)

of VC-283 board

3. TO TAKE OUT A CASSETTE WHEN NOT EJECT (FORCE EJECT)

1Refer to 2-3 to remove the top cabinet section.

2Refer to 2-4 to remove the front panel section.

3Refer to 2-6, 2-7 to remove the cabinet (R) section.

4Refer to 2-8 to remove the BT panel assembly.

5Refer to 2-9 to remove the BT-003 board. (DCR-TRV50/

TRV50E)

6Refer to 2-10 to remove the external connector and shoe base.

7Refer to 2-11, 2-12 to remove the EVF block.

8Refer to 2-17 to remove the DD-176 board.

9Remove the mechanism deck and VC-283 board.

q; Disconnect CN1010 (27P, 0.3mm) of VC-283 board.

qa Supply +4.5V from the DC power supply to the loading motor

and unload with a pressing the cassette compartment.

Screw (M1.7

4),

lock ace, p2

Screw (M1.7

4),

lock ace, p2

Claw

Top cabinet

Open the Flash unit by pushing the

portion

1-2

DCR-TRV40/TRV40E/TRV50/TRV50E

4. DISCHARGING OF THE FLASHLIGHT POWER SUPPLY CAPACITOR

The power supply capacitor of the flash unit is charged up to the maximum 300V potential.

There is a danger of electric shock by this high voltage when the capacitor is handled by hand. The electric shock is caused by the charged

voltage which is kept without discharging when the main power of the unit is simply turned off. Therefore, the remaining voltage must be

discharged as described below.

4-1. PREPARING THE SHORT JIG

To preparing the short jig. a small clip is attached to each end of a resistor of 1kΩ/1W (1-215-869-11).

Wrap insulating tape fully around the reads of the resistor to prevent electric shock.

4-2. DISCHARGING THE CAPACITOR

1Remove the power supply (Battery orAC power adaptor).

2Open the cassette lid (grip cabinet).

3Remove the two screws with which the grip cover is fixed.

4Remove the grip cover.

5Remove the insulation sheet.

6Short circuit between 3and #terminal of the capacitor with the short jig about 10 seconds.

Note for installing the grip cover

When installing the grip cover, insert it in the claws of the grip cabinet.

1 kΩ/1 W

Wrap insulating tape.

3Two screws, tapping

(M1.7 ×5) 4Grip cover

5Insulation sheet

2Open the cassette lid.

Power supply

capacitor

Flash unit

Short jig

Grip cover

Two claws

1-3

DCR-TRV40/TRV40E/TRV50/TRV50E

1-2. SELF-DIAGNOSIS FUNCTION

1. SELF-DIAGNOSIS FUNCTION

When problems occur while the unit is operating, the self-diagnosis

function starts working, and displays on the viewfinder, LCD screen

or LCD window what to do. This function consists of two display;

self-diagnosis display and service mode display.

Details of the self-diagnosis functions are provided in the Instruction

manual.

2. SELF-DIAGNOSIS DISPLAY

When problems occur while the unit is operating, the counter of the

viewfinder, LCD screen or LCD window consists of an alphabet

and 4-digit numbers, which blinks at3.2 Hz.This5-character display

indicates the “repaired by:”, “block”in which the problem occurred,

and “detailed code”of the problem.

3. SERVICE MODE DISPLAY

The service mode display shows up to six self-diagnosis codes shown in the past.

3-1. Display Method

While pressing the “STOP”key, set the switch from OFF to “VCR”, and continue pressing the “STOP”key for 5 seconds continuously. The

service mode will be displayed, and the counter will show the backup No. and the 5-character self-diagnosis codes.

3-2. Switching of Backup No.

By rotating the control dial, past self-diagnosis codes will be shown in order. The backup No. in the [ ] indicates the order in which the

problem occurred. (If the number of problems which occurred is less than 6, only the number of problems which occurred will be shown.)

[1] : Occurred first time [4] : Occurred fourth time

[2] : Occurred second time [5] : Occurred fifth time

[3] : Occurred third time [6] : Occurred the last time

3-3. End of Display

Turning OFF the power supply will end the service mode display.

Order of previous errors

Backup No. Self-diagnosis Codes

C : 3 1 : 1 1

[3]

Lights up

Viewfinder or LCD screen

[3] C : 3 1 : 1 1 3 C : 3 1 : 11

LCD window

1 1

3 1

C : 3 1 : 11

Repaired by:

Refer to page 1-4.

Self-diagnosis Code Table.

Indicates the appropriate

step to be taken.

E.g.

31 ....Reload the tape.

32 ....Turn on power again.

Block Detailed Code

Blinks at 3.2Hz

C : Corrected by customer

H : Corrected by dealer

E : Corrected by service

engineer

Viewfinder or LCD screen LCD window

C : 3 1 : 1 1

Control dial

Note: The “self-diagnosis display”data will be kept even if the lithium battery (CK-115 board BT5201 of the cabinet (R) assembly) is removed.

LCD window

1-4E

DCR-TRV40/TRV40E/TRV50/TRV50E

4. SELF-DIAGNOSIS CODE TABLE

Block

Function

Detailed

Code

Symptom/State

Non-standard battery is used.

Condensation.

Video head is dirty.

LOAD direction. Loading does not

complete within specified time

UNLOAD direction. Loading does not

complete within specified time

T reel side tape slacking when unloading

Winding S reel fault when counting the

rest of tape.

T reel fault.

S reel fault.

T reel fault.

FG fault when starting capstan.

FG fault when starting drum.

FG fault during normal drum operations.

LOAD direction loading motor time-

out.

UNLOAD direction loading motor

time-out.

T reel side tape slacking when

unloading.

Winding S reel fault when counting the

rest of tape.

T reel fault.

S reel fault.

T reel fault.

FG fault when starting capstan.

FG fault when starting drum

FG fault during normal drum

operations

Difficult to adjust focus

(Cannot initialize focus.)

Zoom operations fault

(Cannot initialize zoom lens.)

Steadyshot function does not work well.

(Withpitchangularvelocitysensoroutput

stopped.)

Steadyshot function does not work well.

(With yaw angular velocity sensor output

stopped.)

Self-diagnosis Code

Repaired by:

Correction

Use the info LITHIUM battery.

Remove the cassette, and insert it again after one hour.

Clean with the optional cleaning cassette.

Load the tape again, and perform operations from the beginning.
