Sony EVI-HD1 User manual

2006 Sony Corporation
HD Color Video Camera
EVI-HD1
A-CKC-100-11(1)
Technical Manual

Features
•The CMOS video camera provides 2,000,000
effective picture elements (pixels) that can shoot
high-definition images to offer superior picture
quality.
•By adopting the DD motor mechanism, in addition to
high-speed pan/tilt action, improvement of the noise
reduction mechanism lets you use the camera for a
variety of purposes.
•The camera allows you to shoot an image using the
1080i high definition video format, which is
equivalent to an HD-TV broadcast.
The camera is compatible with 14 formats, including
59.94 Hz, 50 Hz and the SD video format.
•The camera outputs HD image, conforming to the
SMPTE292M serial digital interface standard. This
allows long distance transmission of high-quality
camera images.
•The camera is equipped with an RS-232C
communication interface. You can select the baud
rate of either 38400 bps or 9600 bps. This allows you
to remotely control the camera at a high
communication speed.

Specifications
System
Video signal 1080i/59.94, 1080i/50, 1080p/29.97,
1080p/25, 720p/59.94,720p/50,
720p/29.97, 720p/25, NTSC
(LB), NTSC (CR), NTSC (SQ),
PAL (LB), PAL(CR), PAL (SQ)
(switched with the SYSTEM
SELECT switch)
Synchronization Internal synchronization
Image device 1/3 type (6 mm), CMOS
Effective picture elements: Approx.
2,000,000 pixels
Lens 10 ×(optical), 40 ×(digital) f = 3.4
– 33.9 mm, F1.8 – F2.1
Horizontal angle: 8 (TELE end) to
70 degrees (WIDE end) (When
an HD signal is output)
Minimum object distance
100 mm (4 inches) (WIDE end)
Minimum illumination
15 lux (F1.8) with 50 IRE
Shutter speed 1/2 to 1/10,000 sec.
Video S/N 50 dB
Pan/tilt action Horizontal: ± 100 degrees
Maximum panning speed: 300
degrees/sec.
Vertical: ± 25 degrees
Maximum tilting speed: 125
degrees/sec.
Input/output connectors
Video output COMPONENT (HD OUT): D-sub
15-pin
Y: 1Vp-p (tri-level sync, at 75-
ohm termination)
Pb/Pr: ± 350 mVp-p, 75-ohm
terminated
HD/VD Sync: 1Vp-p, 75-ohm
terminated
Tri-level Sync: ± 300 mVp-
p,75-ohm terminated
HD-SDI (HD OUT): BNC type, 800
mVp-p, 75 -ohm, conforming to
SMPTE 292M serial interface
standard
VIDEO (SD OUT): RCA phono
jack 1 Vp-p, 75-ohm unbalanced
Synchronization: negative
S VIDEO (SD OUT): Mini DIN 4-
pin type
Control input/output
VISCA IN: Mini DIN 8-pin type,
RS-232C
VISCA OUT: Mini DIN 8-pin type,
RS-232C
Power connector JEITA type4 (DC IN 12V)
General
Input voltage 12 V DC (10.8 to 13.0 V DC)
Current consumption
2.5 A max. (at 12 V DC)
Operating temperature
0°C to 40°C (32°F to 104°F)
Storage temperature
–20°C to +60°C (-4°F to 140°F)
Dimensions Video camera: 259 ×150 ×
169 mm (10 1/4 ×6 ×6 3/4
inches) (w/h/d)
Remote Commander: 56 ×26 ×
210 mm
(2 1/4 ×1 1/16 ×8 3/8
inches) (w/h/d)
Mass Video camera: Approx. 2 kg (4 lb
7 oz)
Remote Commander: 190 g (3.8 oz)
Installation angle
Less than ± 15 degrees to the
horizontal surface
Supplied accessories
AC power adaptor (1)
AC power cord (1)
Remote Commander (1)
Operating Instructions (1)
Design and specifications are subject to
change without notice.

Specifications
Front Side
Top Bottom
Unit: mm (inches)
Dimensions
