Sony Handycam ccd-tr913e User manual

CCD-TR913E/TR950E

RMT-708

SERVICE MANUAL

VIDEO CAMERA RECORDER

MICROFILM

B501 MECHANISM

Photo: CCD-TR950E

SPECIFICATIONS

For MECHANISM ADJUSTMENT, refer to

the “8mm Video MECHANICAL

ADJUSTMENT MANUAL ” (9-973-801-11).

AEP Model

North European Model

East European Model

Russian Model

CCD-TR913E/TR950E

UK Model

CCD-TR913E

Ver 1.0 1999.02

— 2 —

SAFETY-RELATED COMPONENTWARNING!!

COMPONENTS IDENTIFIED BY MARK !OR DOTTED LINEWITH

MARK !ON THE SCHEMATIC DIAGRAMS AND INTHE PARTS

LIST ARE CRITICAL TO SAFE OPERATION. REPLACE THESE

COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS

APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS

PUBLISHED BY SONY.

1. Check the area of yourrepairforunsolderedorpoorly-soldered

connections. Checkthe entire board surface for solder splashes

and bridges.

2. Check the interboard wiring to ensure that no wires are

"pinched" or contact high-wattage resistors.

3. Look for unauthorized replacement parts, particularly

transistors, that were installed during a previous repair. Point

them out to the customer and recommend their replacement.

4. Look for parts which, through functioning, showobvious signs

of deterioration. Point them out to the customer and

recommend their replacement.

5. Check the B+ voltage to see it is at the values specified.

6. Flexible Circuit Board Repairing

• Keep the temperature of the soldering iron around 270˚C

during repairing.

• Do not touch the soldering iron on the same conductor of the

circuit board (within 3 times).

• Be careful not to apply force on the conductor when soldering

or unsoldering.

SAFETY CHECK-OUT

After correcting the original service problem, perform the following

safety checks before releasing the set to the customer.

Model

Destination

Lens Optical

Digital

Color EVF

B/W EVF

CCD-TR913E

AEP1, AEP2, UK, NE,

EE, RU

20×

80×(Note)

CCD-TR950E

AEP, NE, EE, RU

20×

80× (Note)

Remark

®: With VF-126 board

®: With VF-129 board

Table for difference of function

Note :AEP1, EE, NE, RU model is 360×.• Abbreviation

NE : North European Model

EE : East European Model

RU : Russian Model

Supplied accessories

— 3 —

TABLE OF CONTENTS

SERVICE NOTE

1. POWER SUPPLY DURING REPAIRS ····························· 6

2. TO TAKE OUT A CASSETTE WHEN NOT EJECT

(FORCE EJECT) ································································ 6

SELF-DIAGNOSIS FUNCTION

1. Self-diagnosis Function ······················································ 7

2. Self-diagnosis Display························································ 7

3. Service Mode Display ························································ 7

3-1. Display Method ·································································· 7

3-2. Switching of Backup No. ··················································· 7

3-3. End of Display···································································· 7

4. Self-diagnosis Code Table ·················································· 8

1. GENERAL

Checking supplied accessories ··················································1-1

Quick Start Guide ······································································1-1

1. Connecting the mains lead·················································1-1

2. Inserting a cassette ·····························································1-1

3. Recording a picture····························································1-1

4. Monitoring the playback picture in the viewfinder ···········1-1

Getting Started···········································································1-1

Using this manual ··································································1-1

Step 1 Preparing the power supply ········································1-2

Step 2 Inserting a cassette······················································1-3

Recording – Basics ····································································1-4

Recording a picture································································1-4

Checking the recording – EDITSEARCH/Rec Review ········1-6

Playback – Basics ······································································1-6

Connections for playback ······················································1-6

Playing back a tape ································································1-7

Advanced Recording Operations ···············································1-8

Photo recording······································································1-8

Using the wide mode ·····························································1-8

Using the fader function ························································1-9

Using special effects – Picture effect ·····································1-9

Using special effects – Digital effect ···································1-10

Using the PROGRAM AE function ·····································1-11

Adjusting the exposure manually ········································1-11

Focusing manually·······························································1-12

Superimposing a title ···························································1-12

Making your own titles ························································1-13

Using the built-in light·························································1-13

Advanced Playback Operations···············································1-14

Playing back a tape with digital effects ·······························1-14

Editing on Other Equipment····················································1-14

Dubbing a tape ·····································································1-14

CustomizingYour Camcorder ·················································1-15

Changing the MENU settings ··············································1-15

Resetting the date and time··················································1-16

Additional Information ····························································1-17

Usable cassettes and playback modes··································1-17

Changing the lithium battery in your camcorder ·················1-17

Troubleshooting ···································································1-18

Self-diagnosis display ··························································1-19

Warning indicators and messages ········································1-19

Using your camcorder abroad··············································1-19

Maintenance information and precautions···························1-19

Quick Reference ······································································1-21

Identifying the parts and controls ········································1-21

Quick function guide ···························································1-23

2. DISASSEMBLY

2-1. Cabinet (R) Assembly (TR913E), (TR950E) ··················2-2

2-2. Mechanism Deck ·····························································2-3

2-3. Color EVF Block, VF-126 Board (TR950E)···················2-4

2-4. B/W EVF Block, VF-129 Board (TR913E) ····················2-5

2-5. Lens Block·······································································2-6

2-6. Mechanism Deck, VC-214, DD-117 Boards···················2-7

2-7. Video Light ······································································2-9

2-8. CF-58 Board (TR913E)···················································2-9

CF-58 Board (TR950E)···················································2-9

2-9. How to Identify Drum and Note····································2-10

2-10. Circuit Boards Location ················································2-11

2-11. Flexible Boards Location ··············································2-12

3. BLOCK DIAGRAMS

3-1. Overall Block Diagram ···················································3-1

3-2. Camera/Video Block Diagram ········································3-5

3-3. VTR/Camera Control Block Diagram·····························3-9

3-4. Servo Block Diagram ····················································3-12

3-5. Mode Control Block Diagram ·······································3-15

3-6. Audio Block Diagram ···················································3-19

3-7. Color EVF Block Diagram (CCD-TR950E) ·················3-23

3-8. B/W EVF Block Diagram (CCD-TR913E)···················3-27

3-9. Power Block Diagram ···················································3-29

4. PRINTEDWIRING BOARDS AND

SCHEMATIC DIAGRAMS

4-1. Frame Schematic Diagram-1···········································4-1

Frame Schematic Diagram-2···········································4-4

4-2. Printed Wiring Boards and Schematic Diagrams ············4-7

• CD-209 (CCD Imager)

Printed Wiring Board and

Schematic Diagram ·········································4-8

• VC-214 (Camera Processor,Y/C Processor, Focus/Zoom

Motor Drive, REC/PB Head AMP, Video/Interface, IR,

Mode Control, Servo, System Control,Audio Processor)

Printed Wiring Board ····································4-11

• VC-214 (Camera Processor)(1/10)

Schematic Diagram .......................................4-17

• VC-214 (Y/C Processor)(2/10)

Schematic Diagram ·······································4-19

• VC-214 (Focus/Zoom Motor Drive)(3/10)

Schematic Diagram ·······································4-25

• VC-214 (REC/PB Head AMP)(4/10)

Schematic Diagram ·······································4-27

• VC-214 (Video/Interface)(5/10)

Schematic Diagram ·······································4-30

• VC-214 (IR Transmitter)(6/10)

Schematic Diagram ·······································4-33

• VC-214 (Mode Control)(7/10)

Schematic Diagram ·······································4-36

• VC-214 (Servo)(8/10)

Schematic Diagram ·······································4-39

• FP-249 (S/T Reel Sensor), FP-356 (Top Sensor),

FP-355 (Tape LED) Flexible Board ····························4-42

• VL-25 (Video Light)

Printed Wiring Board ····································4-43

• VC-214 (HI Control)(9/10)

Schematic Diagram ·······································4-44

• VC-214 (Audio)(10/10)

Schematic Diagram ·······································4-47

• SE-85 (Steady Shot), PJ-94 (AV IN/OUT)

Printed Wiring Boards···································4-50

• SE-85 (Steady Shot), PJ-94 (AV IN/OUT)

Schematic Diagrams ·····································4-53

• MA-353 (Stereo MIC AMP, Laser Link)

Printed Wiring Board ····································4-55

• MA-353 (Stereo MIC AMP, Laser Link)

Schematic Diagram ·······································4-57

• VF-126 (Color EVF)

Printed Wiring Board ····································4-61

— 4 —

• VF-126 (Color EVF)

Schematic Diagram ·······································4-63

• FK-8500, SS-8500 (Control Switch Block)

Schematic Diagram ·······································4-68

• VF-129 (B/W EVF)

Printed Wiring Board and

Schematic Diagram .......................................4-69

• CF-58 (User Control)

Printed Wiring Board ....................................4-72

• CF-58 (User Control)

Schematic Diagram ·······································4-75

• DD-117 (DC/DC Converter)

Printed Wiring Board ····································4-79

• DD-117 (DC/DC Converter)

Schematic Diagram ·······································4-81

5. ADJUSTMENTS

5-1. CAMERA SECTION ADJUSTMENT ···························5-1

1-1. Preparations before Adjustment (Camera Section) ·········5-1

1-1-1.List of Service Tools ························································5-1

1-1-2.Adjusting Items When Replacing Main Parts ·················5-2

1-1-3.Preparations ·····································································5-3

1-1-4.Precaution ········································································5-5

1. Setting the Switch····························································5-5

2. Order of Adjustments ······················································5-5

3. Subjects ···········································································5-5

1-2. Initialization of D, E, F Page Data ··································5-6

1. Initializing the D, E, F Page Data····································5-6

2. Modification of D, E, F Page Data ··································5-6

3. D Page Table····································································5-6

4. F Page Table ····································································5-7

5. E Page Table ··································································5-10

1-3. Camera System Adjustments ·········································5-13

1. HALL Adjustment ·························································5-13

2. Flange Back Adjustment ···············································5-13

2-1. Flange Back Adjustment (1) ··········································5-13

2-2. Flange Back Adjustment (2) ··········································5-14

3. Flange Back Check························································5-14

4. Picture Frame Setting ····················································5-15

5. AGC Gain Calibration Adjustment ·······························5-15

6. Color Reproduction Adjustment ····································5-16

7. IRIS IN/OUT Adjustment ·············································5-16

8. MAX GAIN Adjustment ···············································5-17

9. Auto White Balance Standard Data Input ·····················5-17

10. Auto White Balance Adjustment ···································5-18

11. White Balance Check ····················································5-19

12. AngularVelocity Sensor Sensitivity Preset and

Steady Shot Check·························································5-20

1-4. Color Electronic Viewfinder System Adjustment

(CCD-TR950E) ·····························································5-21

1. EVF Initial Data Input ···················································5-21

2. VCO Adjustment (VF-126 board) ·································5-22

3. Bright Adjustment (VF-126 board) ·······························5-22

4. ContrastAdjustment (VF-126 board) ····························5-23

5. Backlight Consumption Current Adjustment

(VF-126 board)······························································5-23

6. White Balance Adjustment (VF-126 board)··················5-24

1-5. Monochrome Electronic Viewfinder System

Adjustment (CCD-TR913E)··········································5-25

1-5-1.Horizontal Slant Check ·················································5-25

1-5-2.Centering Adjustment ····················································5-25

1-5-3.Focus Adjustment ··························································5-25

1-5-4.Aberration Adjustment ··················································5-26

1-5-5.Horizontal Amplitude Adjustment (VF-129 board) ······5-26

1-5-6.Vertical Amplitude Adjustment (VF-129 board) ···········5-27

1-5-7.Brightness Adjustment (VF-129 Board)························5-27

1-5-8.Horizontal Amplitude, Vertical Amplitude,

Focus Check ··································································5-27

5-2. MECHANISM SECTION ADJUSTMENT ··················5-28

2-1. Operating Without Cassette ···········································5-28

2-2. Tape Path Adjustment ····················································5-28

5-3. VIDEO SECTION ADJUSTMENT ······························5-29

3-1. Preparations Before Adjustments ··································5-29

3-1-1.Equipment to Required··················································5-29

3-1-2.Precautions on Adjusting ···············································5-30

3-1-3.Adjusting Connectors ····················································5-30

3-1-4.Connecting the Equipments···········································5-31

3-1-5.Alignment Tape ·····························································5-32

3-1-6.Output Level and Impedance·········································5-32

3-1-7.Recording Mode (Standard 8/Hi8) Switching ···············5-32

3-2. System Control System Adjustment ······························5-33

1. Initialization of D, E, F Page Data ································5-33

2. Battery End Adjustment (VC-214 board)······················5-33

3-3. Servo System Adjustments ············································5-34

1. CAP FG OffsetAdjustment (VC-214 board) ················5-34

2. Switching Position Adjustment (VC-214 board)···········5-34

3-4. Video System Adjustments············································5-35

1. 28 MHz Origin Oscillation Adjustment

(VC-214 board) ·····························································5-35

2. AFC f0Adjustment (VC-214 board)······························5-35

3. Filter f0Adjustment (VC-214 board)·····························5-36

4. Y OUT Level Adjustment (VC-214 board) ···················5-36

5. C OUT Level Adjustment (VC-214 board) ···················5-37

6. RP Filter f0Adjustment (VC-214 board) ·······················5-37

7. RECY Current Adjustment (VC-214 board) ················5-38

8. REC L Level Adjustment (VC-214 board)····················5-39

9. REC C Current Adjustment (VC-214 board) ················5-40

3-5. IR Transmitter Adjustments···········································5-41

1. IR Video Carrier Frequency Adjustment

(VC-214 board) ·····························································5-41

2. IR Video Deviation Adjustment (VC-214 board) ··········5-41

3. IR Audio Deviation Adjustment (VC-214 board) ·········5-42

3-6. Audio System Adjustment ·············································5-43

1. 1.5 MHz Deviation Adjustment (VC-214 board) ··········5-44

2. 1.7 MHz Deviation Adjustment (VC-214 board) ··········5-45

3. BPF f0Adjustment (VC-214 board) ······························5-46

5-4. SERVICE MODE ··························································5-47

4-1. Adjustment Remote Commander ··································5-47

1. Using the Adjustment Remote Commander ··················5-47

2. Precautions Upon Using the Adjustment Remote

Commander ···································································5-47

4-2. Data Process ··································································5-48

4-3. Service Mode·································································5-49

1. Test Mode Setting··························································5-49

2. Emergency Memory Address ········································5-50

2-1. EMG Code (Emergency Code) ·····································5-50

2-2. MSW Codes ··································································5-51

3. Bit Value Discrimination ···············································5-52

4. Input/Output Selection Check ·······································5-52

5. LED, LCD (Display Window) Check ···························5-52

6. Record of Use Check·····················································5-53

7. Switch Check (1) ···························································5-53

8. Switch Check (2) ···························································5-54

9. Headphone Jack Check ·················································5-54

6. REPAIR PARTS LIST

6-1. Exploded Views ·······························································6-1

6-1-1.Front Panel (D) Block and Battery Panel (P) Block

Assembly ·········································································6-1

6-1-2.Cabinet (R) Block Assembly ···········································6-2

6-1-3.Cabinet (L) Block and Main Boards Assembly···············6-3

6-1-4.EVF Block Assembly ······················································6-4

— 5 —

*The color reproduction frame is shown on page 251.

6-1-5.Zoom Lens (LSV-630A)··················································6-5

6-1-6.Cassette Compartment Assembly ····································6-6

6-1-7.LS Chassis Assembly ······················································6-7

6-1-8.Mechanism Chassis Assembly ········································6-8

6-2. Electrical Parts List ·························································6-9

— 6 —

SERVICE NOTE

1. POWER SUPPLY DURING REPAIRS

In this unit, about 10 seconds after power is supplied (8.4V) to the

battery terminal using the service power cord (J-6082-223-A), the

power is shut off so that the unit cannot operate.

This following two methods are available to prevent this. Take note

of which to use during repairs.

Method 1.

Connect the servicing remote commander RM-95 (J-6082-053-B)

to the LANC jack, and set the remote commander switch to the

“ADJ” side.

Method 2.

Press the battery switch of the battery terminal using adhesive tape,

etc.

Method 3.

Use the DC IN terminal. (Use the AC power adaptor.)

Pull the timing belt in the direction of

arrow

with a pincette while pressing

the cassette lid (take care not to damage)

to adjust the bending of a tape.

Let go your hold the cassette

lid and rise the cassette

compartment to take out a cassette.

Pincette

Timing belt

Press the cassette lid to rise

the cassette compartment

[DC power supply]

(+5V)

Adjust the bending of a tape

Disconnect CN901

of VC-214 board.

Loading motor

DC IN terminal

Battery switch

Battery terminal

’

Battery terminal

‘

Battery SIG terminal

2. TO TAKE OUT A CASSETTE WHEN NOT EJECT (FORCE EJECT)

1Refer to 2-1. to remove the front panel assembly.

2Refer to 2-1. to remove the cabinet (R) assembly.

3Refer to 2-1. to remove the battery panel assembly.

4Refer to 2-1. to remove the cabinet (L) assembly.

5Disconnect CN901 of VC-214 board.

6Add +5V from the DC POWER SUPPLY and unload with a

pressing the cassette lid.

— 7 —

SELF-DIAGNOSIS FUNCTION

1. Self-diagnosis Function

When problems occur while the unit is operating, the self-diagnosis

function starts working, and displays on the viewfinder or Display

window what to do. This function consists of two display; self-

diagnosis display and service mode display.

Detailsof the self-diagnosis functionsare provided in the Instruction

manual.

Note: The “self-diagnosis display” data will be backed up by the coin-type lithium battery (CF-58 board BH001). When this

coin-type lithium battery is disconnected, the “self-diagnosis display” data will be lost by initialization.

2. Self-diagnosis Display

When problems occur while the unit is operating, the counter of the

viewfinder or Display window shows a 4-digit display consisting

ofan alphabet andnumbers, whichblinks at3.2 Hz.This5-character

display indicates the “repaired by:”, “block” in which the problem

occurred, and “detailed code” of the problem.

3. Service Mode Display

The service mode display shows up to six self-diagnosis codes shown in the past.

3-1. Display Method

While pressing the “STOP” key, set the switch from OFF to “PLAYER”, and continue pressing the “STOP” key for 5 seconds continuously.

The service mode will be displayed, and the counter will show the backup No. and the 5-character self-diagnosis codes.

3-2. Switching of Backup No.

By rotating the control dial, past self-diagnosis codes will be shown in order. The backup No. in the [] indicates the order in which the

problem occurred. (If the number of problems which occurred is less than 6, only the number of problems which occurred will be shown.)

[1] : Occurred first time [4] : Occurred fourth time

[2] : Occurred second time [5] : Occurred fifth time

[3] : Occurred third time [6] : Occurred the last time

3-3. End of Display

Turning OFF the power supply will end the service mode display.

Order of previous errors

Backup No. Self-diagnosis Codes

C : 3 1 : 1 1

[3]

Lights up

Viewfinder

[3] C : 3 1 : 1 1

3 C : 3 1 : 11

Display window

1 1

3 1

C : 3 1 : 11

Repaired by:

Refer to page 8 and 9.

Self-diagnosis Code Table.

Indicates the appropriate

step to be taken.

E.g.

31 ....Reload the tape.

32 ....Turn on power again.

Block Detailed Code

Blinks at 3.2Hz

C : Corrected by customer

H : Corrected by dealer

E : Corrected by service

engineer

Viewfinder Display window

C : 3 1 : 1 1

Display window

Control dial

— 8 —

4. Self-diagnosis Code Table

Block

Function

Detailed

Code

Symptom/State

Condensation.

Video head is dirty.

Non-standard battery is used.

LOAD direction. Loading does not

complete within specified time

UNLOAD direction. Loading does not

complete within specified time

T reel side tape slacking when unloading

S reel

side tape slacking when unloading

T reel fault.

S reel fault.

FG fault when starting capstan.

FG fault during normal capstan operations.

FG fault when starting drum.

PG fault when starting drum.

FG fault during normal drum operations.

PG fault during normal drum operations.

Phase fault during normal drum operations.

LOAD direction loading motor time-

out.

UNLOAD direction loading motor

time-out.

T reel side tape slacking when

unloading.

S reel side tape slacking when

unloading.

T reel fault.

S reel fault.

FG fault when starting capstan.

FG fault during normal capstan

operations.

FG fault when starting drum.

PG fault when starting drum.

FG fault during normal drum

operations.

PG fault during normal drum

operations.

Phase fault during normal drum

operations.

Self-diagnosis Code

Repaired by:

Correction

Remove the cassette, and insert it again after one hour.

Clean with the optional cleaning cassette.

Use the InfoLITHIUM battery.

Load the tape again, and perform operations from the beginning.

Remove the battery or power cable, connect, and perform
