DCR-HC17E/HC19E/HC21/HC21E/HC22E/HC32/HC32E/HC33/HC33E
Ver 1.4 2006.10
DIGITAL VIDEO CAMERA RECORDER
NON MS model: DCR-HC17E/HC19E/HC21/HC21E/HC22E
MS model: DCR-HC32/HC32E/HC33/HC33E
•For ADJUSTMENTS (SECTION 6), refer to SERVICE MANUAL, ADJ (9-876-782-51).
• For INSTRUCTION MANUAL, refer to SERVICE MANUAL, LEVEL 1 (9-876-782-41).
•For MECHANISM ADJUSTMENTS, refer to the “DV MECHANICAL ADJUSTMENT MANUAL VIII
Z (Z200/Z210/Z300/Z310) MECHANISM ” (9-876-724-1[]).
•Reference No. search on printed wiring boards is available.
•Table for differences of function of each model.
•TO TAKE OUT A CASSETTE WHEN NOT EJECT (FORCE EJECT)
• HELP: Sheet attachment positions and procedures of processing the flexible boards/harnesses are shown.
On the VC-376/377 boards
This service manual provides the information that is premised the circuit board replacement service and not intended repair
inside the VC-376/377 boards.
Therefore, schematic diagrams, printed wiring boards, mounted parts location and electrical parts list of the VC-376/377 boards
are not shown.
Z MECHANISM (MDX-Z210)
Sony EMCS Co.
2006J0500-1
© 2006.10
Published by Kohda TEC
9-876-782-31
Photo: DCR-HC32
DCR-HC21/HC32
US Model
Canadian Model
Korea Model
DCR-HC17E/HC19E/HC22E/HC32E
AEP Model
East European Model
North European Model
DCR-HC19E/HC22E/HC32E
UK Model
DCR-HC21/HC21E/HC32/HC32E
E Model
DCR-HC21E/HC32E
Australian Model
Hong Kong Model
DCR-HC21/HC33
Brazilian Model
DCR-HC21E/HC33E
Chinese Model
DCR-HC32/HC32E
Tourist Model
RMT-830/831
DCR-HC17E/HC19E/HC21/HC21E/HC22E/
HC32/HC32E/HC33/HC33E

— 2 —
DCR-HC17E/HC19E/HC21/HC21E/HC22E/HC32/HC32E/HC33/HC33E
SPECIFICATIONS
Focal length f=2.3 - 46 mm (3/32 - 1 13/16 in.)
DCR-HC17E/HC19E/HC21/
HC21E/HC22E:
In CAMERA:
44 - 880 mm (1 3/4 - 34 1/32 in.)
DCR-HC32/HC32E/HC33/
HC33E:
When converted to a 35 mm
still camera
In CAMERA-TAPE:
44 ~ 880 mm (1 3/4 - 34 1/32 in.)
In CAMERA-MEMORY:
44 ~ 880 mm (1 3/4 - 34 1/32 in.)
Color temperature [AUTO], [ONE PUSH],
[INDOOR] (3 200 K),
[OUTDOOR] (5 800 K)
Minimum
illumination 5 lx (lux) (F 1.8) 0 lx (lux) (during NightShot plus
function)*
2
*
1
“Exif” is a file format for still images, established
by the JEITA (Japan Electronics and Information
Technology Industries Association). Files in this
format can have additional information such as
your camcorder’s setting information at the time of
recording.
*
2
Objects unable to be seen due to the dark can be
shot with infrared lighting.
System
Video recording
system 2 rotary heads, Helical scanning system
DCR-HC32/HC32E/HC33/HC33E:
DCR-HC21/HC32/HC33:
Still image
recording system
Exif Ver. 2.2*1
Audio recording
system Rotary heads, PCM system Quantization: 12 bits (Fs 32 kHz,
stereo 1, stereo 2), 16 bits
(Fs 48 kHz, stereo)
Video signal NTSC color, EIA standards
DCR-HC17E/HC19E/HC21E/
HC22E/HC32E/HC33E:
PAL color, CCIR standards
Usable cassette Mini DV cassette with the
mark printed
Tape speed SP: Approx. 18.81 mm/s
LP: Approx. 12.56 mm/s
Recording/
playback time SP: 60 min LP: 90 min
(using a DVM60 cassette)
Fast forward/
rewind time Approx. 2 min 40 s (using a DVM60 cassette)
Viewfinder Electric viewfinder
(black and white)
Image device
DCR-HC32/HC33:
DCR-HC21:
DCR-HC17E/HC19E/HC21E/
HC22E:
3 mm (1/6 type) CCD (Charge
Coupled Device)
Gross: Approx. 680 000 pixels
Effective (still): Approx.
340 000 pixels
Effective (movie): Approx.
340 000 pixels
Gross: Approx. 680 000 pixels
Effective (movie): Approx.
340 000 pixels
DCR-HC32E/HC33E:
Gross: Approx. 800 000 pixels
Effective (still): Approx.
400 000 pixels
Effective (movie): Approx.
400 000 pixels
Lens Carl Zeiss Vario-Tessar
Combined power zoom lens
Filter diameter: 25 mm (1 in.)
20 ×(Optical), 640 ×(Digital,
DCR-HC17E), 800 ×(Digital,
DCR-HC19E/HC21/HC21E/
HC22E/HC32/HC32E/HC33/
HC33E)
F=1.8 - 3.1
Gross: Approx. 800 000 pixels
Effective (movie): Approx.
400 000 pixels
Input/Output connectors
Audio/Video
input/output
(DCR-HC17E/
HC19E/HC21/
HC21E)
10-pin connector
Input/output auto switch
(DCR-HC32/
HC32E/HC33/
HC33E)
Video signal: 1 Vp-p, 75 Ω
0.3 Vp-p, 75 Ω(ohms,
DCR-HC32E/HC33E),
unbalanced
Audio signal: 327 mV (at output
impedance more than 47 kΩ
(kilohms)),
Input impedance more than 47 kΩ
(ohms), unbalanced
Luminance signal: 1 Vp-p,
75 Ω(ohms), unbalanced
mini-B
Chrominance signal: 0.286 Vp-p,
75 Ω(ohms, DCR-HC32/HC33),
(kilohms), Output
impedance with less than 2.2 kΩ
(kilohms)
Audio/Video
output 10-pin connector
(DCR-HC17E/
HC19E/HC21/
HC21E/HC22E)
Video signal: 1 Vp-p, 75 Ω
0.3 Vp-p, 75 Ω(ohms,
DCR-HC17E/HC19E/HC21E/
HC22E), unbalanced
Audio signal: 327 mV (at output
impedance more than 47 kΩ
(kilohms)), Output
(ohms), unbalanced
Luminance signal: 1 Vp-p,
75 Ω(ohms), unbalanced
Chrominance signal: 0.286 Vp-p,
75 Ω(ohms, DCR-HC21),
impedance with less than 2.2 kΩ
(kilohms)
LANC jack Stereo mini-minijack (φ2.5 mm)
LCD screen
Picture 6.2 cm (2.5 type)
Total dot number 123 200 (560 × 220)
General
Power
requirements DC 7.2 V (battery pack) DC 8.4 V (AC Adaptor)
Average power
consumption DCR-HC32/HC32E/HC33/
HC33E:
During camera recording using
During camera recording using
the viewfinder 2.1 W
the viewfinder 1.9 W
the LCD 2.4 W
During camera recording using
During camera recording using
the LCD 2.5 W
During camera recording using
the viewfinder and the LCD 2.6 W
DCR-HC17E/HC19E/HC21/
HC21E/HC22E:
Operating
temperature 0 °C to 40 °C (32 °F to 104 °F)
Storage
temperature -20 °C to + 60 °C (-4 °F to + 140 °F)
Dimensions
(approx.) 54.7 × 90 × 111.7 mm (2 1/4 × 3 5/8 × 4 1/2 in.) (w/h/d)
Mass (approx.) 400 g (14 oz) main unit only
460 g (1 lb) including the
NP-FP30 rechargeable battery
pack and DVM60 cassette.
Supplied
accessories AC Adaptor (1)
Power cord (1)
Handycam Station (1)
(DCR-HC22E/HC32/HC32E/
HC33/HC33E)
Wireless Remote Commander
(1) (DCR-HC19E/HC21/HC21E/
HC22E/HC32/HC32E/HC33/
HC33E)
Shoulder Strap (1) (DCR-HC19E/
HC21/HC21E/HC22E/HC32/
HC32E/HC33/HC33E)
21-pin adaptor (1)
(DCR-HC22E/HC32E)
Conversion 2P adaptor (1)
(DCR-HC21/HC32: E, JE/
HC32E: JE)
Rechargeable battery pack
NP-FP30 (1)
CD-ROM “Picture Package
Ver. 1.5” (1)
“Memory Stick Duo” 16MB (1)
(DCR-HC33/HC33E)
Memory Stick Duo adaptor (1)
(DCR-HC33/HC33E)
See page 5-29
A/V connecting cable (1)
Shoe cover (1)
Operating Guide (1)
USB cable (1) (DCR-HC19E/
HC21/HC21E/HC22E/HC32/
HC32E/HC33/HC33E)
USB jack
DV input/output
(DCR-HC21/
HC21E)
(DCR-HC17E/
HC19E)
4- pin connector
4- pin connector
DV output
– Continued on next page –

— 3 —
DCR-HC17E/HC19E/HC21/HC21E/HC22E/HC32/HC32E/HC33/HC33E
Handycam Station DCRA-C121
(DCR-HC32/HC32E/HC33/HC33E)
Audio/Video
input/output 10-pin connector Input/output auto switch Video
signal: 1 Vp-p, 75 Ω (ohms),
unbalanced
Luminance signal: 1 Vp-p, 75 Ω
(ohms), unbalanced
Chrominance signal: 0.286 Vp-p,
75 Ω(ohms, DCR-HC32/HC33),
0.3 Vp-p, 75 Ω(ohms,
DCR-HC32E/HC33E),
unbalanced
Audio signal: 327 mV (at output
impedance more than 47 kΩ
(kilohms)),
Input impedance more than
47 kΩ(kilohms), Output
impedance with less than 2.2 kΩ
(kilohms)
USB jack mini-B
DV input/output 4-pin connector
Handycam Station DCRA-C122
(DCR-HC22E)
Audio/Video
output 10-pin connector Video signal: 1 Vp-p, 75 Ω
(ohms), unbalanced
Luminance signal: 1 Vp-p, 75 Ω
(ohms), unbalanced
Chrominance signal: 0.3 Vp-p,
75 Ω(ohms,), unbalanced
Audio signal: 327 mV (at output
impedance more than 47 kΩ
(kilohms)), Otput impedance with
less than 2.2 kΩ(kilohms)
USB jack mini-B
DV input/output 4-pin connector
AC Adaptor AC-L25A/L25B
Power
requirements AC 100 - 240 V, 50/60 Hz
Current
consumption 0.35 - 0.18 A
Power
consumption 18 W
Output voltage DC 8.4 V*
Operating
temperature 0 °C to 40 °C (32 °F to 104 °F)
Storage
temperature -20 °C to + 60 °C (-4 °F to + 140 °F)
Dimensions
(approx.) 56 × 31 × 100 mm (2 1/4 × 1 1/4 × 4 in.) (w/h/d) excluding the
projecting parts
Mass (approx.) 190 g (6.7 oz) excluding the
power cord
* See the label on the AC Adaptor for other
specifications.
Rechargeable battery pack NP-FP30
Maximum output
voltage DC 8.4 V
Output voltage DC 7.2 V
Capacity 3.6 wh (500 mAh)
Dimensions
(approx.) 31.8 × 18.5 × 40.5 mm (1 5/16 × 3/4 × 1 13/16 in.) (w/h/d)
Mass (approx.) 40 g (1.5 oz)
Operating
temperature 0 °C to 40 °C (32 °F to 104 °F)
Type Lithium ion
Design and specifications are subject to change
without notice.

— 4 —
DCR-HC17E/HC19E/HC21/HC21E/HC22E/HC32/HC32E/HC33/HC33E
Table for differences of function
•Abbreviation
AUS:Australian model
BR : Brazilian model
CH : Chinese model
CND: Canadian model
EE : East European model
HK : Hong Kong model
JE : Tourist model
KR : Korean model
NE : North European model
NON MS model
Model DCR-HC17E DCR-HC19E DCR-HC21 DCR-HC21E DCR-HC22E
Destination AEP, NE, EE AEP, UK, NE, EE US, CND, E, KR, E, HK, AUS, CH AEP, UK, NE, EE
BR
Color system PAL PAL NTSC PAL PAL
Memory Stick Duo ××× ××
A/V jack OUT OUT OUT OUT OUT
DV Interface OUT OUT IN/OUT IN/OUT IN/OUT (Note)
Remote commander ×a(RMT-830) a(RMT-830) a(RMT-830) a(RMT-830)
Cradle (Handycam Station) ××× ×a
CR board ××× ×CR-050
VC board VC-376 VC-376 VC-376 VC-376 VC-376
MS model
Model DCR-HC32 DCR-HC32E DCR-HC33 DCR-HC33E
Destination US, CND, E, KR, AEP, UK, NE, EE, BR CH
JE E, HK, AUS, JE
Color system NTSC PAL NTSC PAL
Memory Stick Duo aaa a
A/V jack IN/OUT IN/OUT IN/OUT IN/OUT
DV Interface IN/OUT (Note) IN/OUT (Note) IN/OUT (Note) IN/OUT (Note)
Remote commander a(RMT-831) a(RMT-831) a(RMT-831) a(RMT-831)
Cradle (Handycam Station) aaa a
CR board CR-050 CR-050 CR-050 CR-050
VC board VC-377 VC-377 VC-377 VC-377
Note: DV Interface on the Cradle (Handycam Station)

— 5 —
DCR-HC17E/HC19E/HC21/HC21E/HC22E/HC32/HC32E/HC33/HC33E
SAFETY-RELATED COMPONENTWARNING!!
COMPONENTS IDENTIFIED BY MARK 0OR DOTTED LINEWITH
MARK 0ON THE SCHEMATIC DIAGRAMS AND IN THE PARTS
LIST ARE CRITICAL TO SAFE OPERATION. REPLACE THESE
COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS
APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS
PUBLISHED BY SONY.
ATTENTION AU COMPOSANT AYANT RAPPORT
À LA SÉCURITÉ!
LES COMPOSANTS IDENTIFÉS PAR UNE MARQUE 0SUR LES
DIAGRAMMES SCHÉMATIQUES ET LA LISTE DES PIÈCES SONT
CRITIQUES POUR LA SÉCURITÉ DE FONCTIONNEMENT. NE
REMPLACER CES COMPOSANTS QUE PAR DES PIÈSES SONY
DONT LES NUMÉROS SONT DONNÉS DANS CE MANUEL OU
DANS LES SUPPÉMENTS PUBLIÉS PAR SONY.
1. Checkthe area ofyour repairforunsoldered orpoorly-soldered
connections. Check theentire boardsurfaceforsolder splashes
and bridges.
2. Check the interboard wiring to ensure that no wires are
"pinched" or contact high-wattage resistors.
3. Look for unauthorized replacement parts, particularly
transistors, that were installed during a previous repair. Point
them out to the customer and recommend their replacement.
4. Look for parts which,through functioning, show obvioussigns
of deterioration. Point them out to the customer and
recommend their replacement.
5. Check the B+ voltage to see it is at the values specified.
6. FLEXIBLE Circuit Board Repairing
•Keep the temperature of the soldering iron around 270°C
during repairing.
•Do not touch the soldering iron on the same conductor of the
circuit board (within 3 times).
•Be careful not to apply force on the conductor when soldering
or unsoldering.
Unleaded solder
Boards requiring use of unleaded solder are printed with the lead-
free mark (LF) indicating the solder contains no lead.
(Caution: Some printed circuit boards may not come printed with
the lead free mark due to their particular size.)
: LEAD FREE MARK
Unleaded solder has the following characteristics.
•Unleaded solder melts at a temperature about 40°C higher than
ordinary solder.
Ordinary soldering irons can be used but the iron tip has to be
applied to the solder joint for a slightly longer time.
Soldering irons using a temperature regulator should be set to
about 350°C.
Caution: The printed pattern (copper foil) may peel away if the
heated tip is applied for too long, so be careful!
•Strong viscosity
Unleaded solder is more viscous (sticky, less prone to flow) than
ordinary solder so use caution not to let solder bridges occur such
as on IC pins, etc.
•Usable with ordinary solder
It is best to use only unleaded solder but unleaded solder may
also be added to ordinary solder.
SAFETY CHECK-OUT
After correcting the original service problem, perform the following
safety checks before releasing the set to the customer.
CAUTION
Dangerofexplosion ifbatteryisincorrectlyreplaced.
Replace only with the same or equivalent type.

— 6 —
DCR-HC17E/HC19E/HC21/HC21E/HC22E/HC32/HC32E/HC33/HC33E
TABLE OF CONTENTS
1. SERVICE NOTE
1-1. Note for Repair ································································1-1
1-2. Power Supply During Repairs ·········································1-1
1-3. To Take Out a Cassette when not Eject (Force Eject) ·····1-2
1-4. Self-diagnosis Function ···················································1-2
1-4-1.Self-diagnosis Function ···················································1-2
1-4-2.Self-diagnosis Display·····················································1-2
1-4-3.Self-diagnosis Code Table ···············································1-3
2. DISASSEMBLY
2-1. Disassembly·····································································2-1
2-2. Mechanism Deck Service Position··································2-5
2-3. LCD Service Position······················································2-7
2-4. The Method ofAttachment of FP-185 Flexible Board····2-8
2-5. Circuit Boards Location ··················································2-9
2-6. Flexible Boards Location ··············································2-10
3. BLOCK DIAGRAMS
3-1. Block Diagrams (Non MS model)···································3-1
3-1-1.Overall Block Diagram (1/5) (Non MS model) ··············3-1
3-1-2.Overall Block Diagram (2/5) (Non MS model) ··············3-3
3-1-3.Overall Block Diagram (3/5) (Non MS model) ··············3-5
3-1-4.Overall Block Diagram (4/5) (Non MS model) ··············3-7
3-1-5.Overall Block Diagram (5/5) (Non MS model) ··············3-9
3-1-6.Power Block Diagram (1/3) (Non MS model) ··············3-11
3-1-7.Power Block Diagram (2/3) (Non MS model) ··············3-13
3-1-8.Power Block Diagram (3/3) (Non MS model) ··············3-15
3-2. Block Diagrams (MS model) ········································3-17
3-2-1.Overall Block Diagram (1/6) (MS model) ····················3-17
3-2-2.Overall Block Diagram (2/6) (MS model) ····················3-19
3-2-3.Overall Block Diagram (3/6) (MS model) ····················3-21
3-2-4.Overall Block Diagram (4/6) (MS model) ····················3-23
3-2-5.Overall Block Diagram (5/6) (MS model) ····················3-25
3-2-6.Overall Block Diagram (6/6) (MS model) ····················3-27
3-2-7.Power Block Diagram (1/3) (MS model) ······················3-29
3-2-8.Power Block Diagram (2/3) (MS model) ······················3-31
3-2-9.Power Block Diagram (3/3) (MS model) ······················3-33
4. PRINTEDWIRING BOARDS AND
SCHEMATIC DIAGRAMS
4-1. Frame Schematic Diagrams·············································4-1
4-2. Schematic Diagrams························································4-5
CD-533 (CCD IMAGER)················································4-7
PD-237 (LCD DRIVE, BACKLIGHT DRIVE)············4-65
CR-050 (CRADLE TERMINAL) ·································4-67
SI-042 (REMOTE COMMANDER RECEIVER,
PITCH/YAW SENSOR) ················································4-69
FP-182 FLEXIBLE ·······················································4-71
JK-278 (JACK) ······························································4-71
MS-249 (MS CONNECTOR) ·······································4-71
LB-109 (EVF, EVF BACKLIGHT) ······························4-73
FP-186 FLEXIBLE (PANEL REVERSE DETECT) ····4-73
FP-180 FLEXIBLE (DC IN) ·········································4-74
FP-187 FLEXIBLE (CONTROL SWITCH)·················4-74
FP-826, FP-467, FP-228 FLEXIBLE····························4-75
CONTROL KEY BLOCK (SS10300) ··························4-77
CONTROL KEY BLOCK (SB9000) ····························4-78
Section Title Page Section Title Page
4-3. Printed Wiring Boards ···················································4-79
CD-533 ··········································································4-81
PD-237···········································································4-91
CR-050 ··········································································4-93
SI-042 ············································································4-94
LB-109···········································································4-94
JK-278 ···········································································4-95
MS-249 ··········································································4-96
FP-180, FP-186, FP-187 FLEXIBLE····························4-97
FP-826, FP-467, FP-228 FLEXIBLE····························4-99
4-4. Waveforms···································································4-101
4-5. Mounted Parts Location ··············································4-117
5. REPAIR PARTS LIST
5-1. Exploded Views ····························································5-2
5-1-1. Overall Assembly··························································5-2
5-1-2. F Panel Block ································································5-3
5-1-3. Lens Block ····································································5-4
5-1-4. Cabinet (R) Block ·························································5-5
5-1-5. CS Block ·······································································5-6
5-1-6. Bat EVF Block······························································5-7
5-1-7. Mechanism Deck ··························································5-8
5-1-8. LS Chassis Block Assembly ·········································5-9
5-1-9. Mechanism Chassis Block Assembly ·························5-10
5-2. Electrical Parts List ·····················································5-11

1-1
DCR-HC17E/HC19E/HC21/HC21E/HC22E/HC32/HC32E/HC33/HC33E
1-1. NOTE FOR REPAIR
Make sure that the flat cable and flexible board are not cracked of
bent at the terminal.
Do not insert the cable insufficiently nor crookedly.
Cut and remove the part of gilt
which comes off at the point.
(Be careful or some
pieces of gilt may be left inside)
When remove a connector, don’t pull at wire of connector.
It is possible that a wire is snapped.
When installing a connector, don’t press down at wire of connector.
It is possible that a wire is snapped.
1-2. POWER SUPPLY DURING REPAIRS
In this unit, about 10 seconds after power is supplied to the battery terminal using the regulated power supply (8.4V), the power is shut off so
that the unit cannot operate.
These following method is available to prevent this.
Method:
Use the AC power adaptor (AC-L25A/L25B).
1. SERVICE NOTE

1-2
DCR-HC17E/HC19E/HC21/HC21E/HC22E/HC32/HC32E/HC33/HC33E
1-4. SELF-DIAGNOSIS FUNCTION
1-4-1. Self-diagnosis Function
When problems occur while the unit is operating, the self-diagnosis
function starts working, and displays on the viewfinder or LCD
screen what to do. This function consists of two display; self-
diagnosis display and service mode display.
Detailsof the self-diagnosisfunctions are providedin theInstruction
manual.
1-4-2. Self-diagnosis Display
When problems occur while the unit is operating, the counter of the
viewfinder or LCD screen shows a 4-digit display consisting of an
alphabet and numbers, which blinks at 3.2 Hz. This 5-character
display indicates the “repaired by:”, “block” in which the problem
occurred, and “detailed code” of the problem.
1 1
3 1C
Repaired by:
Refer to “1-4-3. Self-diagnosis Code Table”.
Indicates the appropriate
step to be taken.
E.g.
31 ....Reload the tape.
32 ....Turn on power again.
Block Detailed Code
Blinks at 3.2Hz
C : Corrected by customer
H : Corrected by dealer
E : Corrected by service
engineer
Viewfinder or LCD screen
C : 3 1 : 1 1
1-3. TO TAKE OUT A CASSETTE WHEN NOT EJECT (FORCE EJECT)
1Refer to “2. DISASSEMBLY” to remove the mechanism deck block.
2Disconnect the CN9002 of VC-376 board (NON MS model) or CN6002 of VC-377 board (MS model).
3Supply +4.5V from the DC power supply to the loading motor and unload with a pressing the cassette compartment.
NON MS model: DCR-HC17E/HC19E/HC21/HC21E/HC22E
MS model: DCR-HC32/HC32E/HC33/HC33E
VC-376/VC-377 board
DC power supply (+4.5Vdc)
Loading motor
Disconnect the CN9002 of VC-376 board (NON MS model)
or CN6002 of VC-377 board (MS model).
CN9002 (NON MS model)/
CN6002 (MS model)

1-3
DCR-HC17E/HC19E/HC21/HC21E/HC22E/HC32/HC32E/HC33/HC33E
1-4-3. Self-diagnosis Code Table
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
C
Block
Function
04
21
22
31
31
31
31
31
31
31
31
31
31
31
31
31
32
32
32
32
32
32
32
32
32
32
32
32
32
Detailed
Code
00
00
00
10
11
20
21
22
23
30
31
40
41
42
43
44
10
11
20
21
22
23
30
31
40
41
42
43
44
Symptom/State
Non-standard battery is used.
Condensation.
Video head is dirty.
LOAD direction. Loading does not
complete within specified time
UNLOAD direction. Loading does not
complete within specified time
T reel side tape slacking when unloading .
S reel side tape slacking when unloading .
T reel fault.
S reel fault.
FG fault when starting capstan.
FG fault during normal capstan operations.
FG fault when starting drum.
PG fault when starting drum.
FG fault during normal drum operations.
PG fault during normal drum operations.
Phase fault during normal drum operations.
LOAD direction loading motor time-
out.
UNLOAD direction loading motor
time-out.
T reel side tape slacking when
unloading.
S reel side tape slacking when
unloading.
T reel fault.
S reel fault.
FG fault when starting capstan.
FG fault during normal capstan
operations.
FG fault when starting drum.
PG fault when starting drum.
FG fault during normal drum
operations.
PG fault during normal drum
operations.
Phase fault during normal drum
operations.
Self-diagnosis Code
Repaired by:
Correction
Use the InfoLITHIUM battery.
Remove the cassette, and insert it again after one hour.
Clean with the optional cleaning cassette.
Load the tape again, and perform operations from the beginning.
Load the tape again, and perform operations from the beginning.
Load the tape again, and perform operations from the beginning.
Load the tape again, and perform operations from the beginning.
Load the tape again, and perform operations from the beginning.
Load the tape again, and perform operations from the beginning.
Load the tape again, and perform operations from the beginning.
Load the tape again, and perform operations from the beginning.
Load the tape again, and perform operations from the beginning.
Load the tape again, and perform operations from the beginning.
Load the tape again, and perform operations from the beginning.
Load the tape again, and perform operations from the beginning.
Load the tape again, and perform operations from the beginning.
Remove the battery or power cable, connect, and perform
operations from the beginning.
Remove the battery or power cable, connect, and perform
operations from the beginning.
Remove the battery or power cable, connect, and perform
operations from the beginning.
Remove the battery or power cable, connect, and perform
operations from the beginning.
Remove the battery or power cable, connect, and perform
operations from the beginning.
Remove the battery or power cable, connect, and perform
operations from the beginning.
Remove the battery or power cable, connect, and perform
operations from the beginning.
Remove the battery or power cable, connect, and perform
operations from the beginning.
Remove the battery or power cable, connect, and perform
operations from the beginning.
Remove the battery or power cable, connect, and perform
operations from the beginning.
Remove the battery or power cable, connect, and perform
operations from the beginning.
Remove the battery or power cable, connect, and perform
operations from the beginning.
Remove the battery or power cable, connect, and perform
operations from the beginning.

1-4E
DCR-HC17E/HC19E/HC21/HC21E/HC22E/HC32/HC32E/HC33/HC33E
E
E
E
E
E
Block
Function
61
61
61
62
62
Detailed
Code
00
10
11
00
01
Symptom/State
Difficult to adjust focus
(Cannot initialize focus.)
Zoom operations fault
(Cannot initialize zoom lens.)
Focus lens intializing failure and zoom
lens initializing failure occur
simultaneously.
Steadyshot function does not work well.
(Withpitch angularvelocitysensor output
stopped.)
Steadyshot function does not work well.
(With yaw angular velocity sensor output
stopped.)
Self-diagnosis Code
Repaired by:
Correction
Inspect the lens block focus reset sensor (Note) when focusing is
performed when the touch panel is operated in the focus manual
mode and the focus motor drive circuit (Note) when the focusing
is not performed.
Inspect the lens block zoom reset sensor (Note) when zooming is
performed when the zoom switch is operated and the zoom motor
drive circuit (Note) when zooming is not performed.
Inspect the flexible board for breakage or loose connection.
If not faulty, inspect the focus and zoom motor drive circuit (Note).
Inspect pitch angular velocity sensor (SE601 of SI-042 board)
peripheral circuits.
Inspect yaw angular velocity sensor (SE602 of SI-042 board)
peripheral circuits.
Note: Focus reset sensor Pin wa of CN3101 on VC-376 board (NON MS model)
Pin wa of CN3701 on VC-377 board (MS model)
Focus motor drive circuit IC3101 of VC-376 board (NON MS model)
IC3707 of VC-377 board (MS model)
Zoom reset sensor Pin qh of CN3101 on VC-376 board (NON MS model)
Pin qh of CN3701 on VC-377 board (MS model)
Zoom motor drive circuit IC3101 of VC-376 board (NON MS model)
IC3707 of VC-377 board (MS model)
NON MS model: DCR-HC17E/HC19E/HC21/HC21E/HC22E
MS model: DCR-HC32/HC32E/HC33/HC33E

DCR-HC17E/HC19E/HC21/HC21E/HC22E/HC32/HC32E/HC33/HC33E
HELP
HELP
2-1 2-2
The following flow chart shows the disassembly procedure.
2-1. DISASSEMBLY
2. DISASSEMBLY
1Tape (A) x1
2P2 tapping screw x2
3Hinge blind
4FP-187 flexible board
5Tapping screw x1
6P2 tapping screw x2
7Claw x6
8P cabinet (C) 103
1FP-185 flexible board: CN601
2FP-186 flexible board: CN609
3Control key block (SB9000):CN602
4P2 tapping screw x1
5Claw x2
6PD-237 board, D901, LCD901
1P2 lock ace screw (M1.7) x1
2Cpc lid
3Screw (M1.7) x7
4Claw x8
5Flexible flat cable (FFC-038): CN603
6F panel block
7FP-190 flexible board: CN1003 (cradle model)
8FP-185 flexible board: CN1006
9FP-187 flexible board: CN1002
0Cabinet (R) block
Non Cradle model: DCR-HC17E/HC19E/HC21/HC21E
Cradle model: DCR-HC22E/HC32E/HC33/HC33E Non MS model: DCR-HC17E/HC19E/HC21/HC21E/HC22E MS model: DCR-HC32/HC32E/HC33/HC33E
1P2 lock ace screw (M1.7) x1
2P2 lock ace screw (M1.7) x1
3Slide the EVF block.
4P2 tappping screw x1
5Tape (A) x2
6Open the cabinet (G) block.
7FP-180 flexible board: CN2001
8FP-181 flexible board: CN7001 (MS model)/
CN9301 (non MS model)
9BAT EVF block
1Cushion (F2)
2Tape (W) x1
3Flexible board: CN 3101 (VC-376 board)/
CN3701 (VC-377 board)
4FP-178 flexible board: CN3002 (VC-376 board)/
CN3101 (VC-377 board)
5P2 lock ace screw (M1.7) x1
6Boss x2
7Lens block
1Ccrew (M1.7) x1
2BT panel block
1
4
4
13
4
6
9
5
7
8
2
1
5
2
3
4
6
6
7
1
2
3
3
3
97
8
0
5
6
1
77
8
5
6
23
4
2
1
2
3
5
6
4
to Page 2-3
HELP

DCR-HC17E/HC19E/HC21/HC21E/HC22E/HC32/HC32E/HC33/HC33E
HELP
HELP
1P2 tapping screw (M1.7) x3
2P2 lock ace screw (M1.7) x1
3Control key block (SS10300)
4P2 lock ace screw (M1.7)
x2
5CS frame block
6JK-278 board
1Flexible board: CN1001
2Connector
x2 : CN9002, 9003 (VC-376 board)/
CN6002, 6003 (VC-377 board)
3P2 lock ace screw (M1.7)
x1
4Connector x2 : CN6501, 9001 (VC-376 board)/
CN4301, 6001 (VC-377 board)
5FP-182 flexible board: CN1008
6Hook
x2
7VC-376 board/VC-377 board
1P2 lock ace screw (M1.7)
x3
2Screw (M1.4x1.5) x4
3MD frame block
4Mechanism deck
1Flexible board: CN704
2P2 lock ace screw (M1.7)
x1
3Eject knob
4P2 lock ace screw (M1.7)
x1
5Tapping screw x3
6P2 lock ace screw (M1.7) x2
7CS block
1
5
6
6
7
23
4
1
1
2
3
4
2
6
7
1
4
5
3
1
2
4
6
5
3
from Page 2-2
2-3 2-4

DCR-HC17E/HC19E/HC21/HC21E/HC22E/HC32/HC32E/HC33/HC33E
2-2. MECHANISM DECK SERVICE POSITION
1
4
4
13
4
6
9
5
7
8
2
3
3
3
97
8
0
5
6
2
1
5
6
6
7
23
4
1
1
2
3
4
2
6
7
1
4
5
3
1
2
4
6
5
3
Connection to Check the Mechanism deck
To check the mechanism deck, set the Camera orVTR to the "Forced power ON" mode.
(Or, connect the control key block (SS10300) to the CN1001 of VC-376/VC-377 board and set the power switch
to the "CAMERA" or "PLAY/EDIT" position.)
Operate the VTR function using the adjustment remote commander
(with the HOLD switch set in the OFF position).
Setting the "Forced Camera Power ON" mode
1) Select page:0, address: 01, and set data:01.
2) Select page:A (MS model)/ D (Non MS model),
address: 10, set data:01 and press
the PAUSE button of the adjustment remote
commander.
Setting the "ForcedVTR Power ON" mode
1) Select page:0, address: 01, and set data:01.
2) Select page:A (MS model)/ D (Non MS model),
address: 10, set data:02 and
press the PAUSE button of the adjustment remote
commander.
Exiting the "Forced Power ON" mode
1) Select page:0, address: 01, and set data:01.
2) Select page:A (MS model)/ D (Non MS model),
address: 10, data:00, and press the PAUSE
button of the adjustment remote commander.
3) Select page:0, address: 01, and set data:00.
1
2
Color monitor
A/V jack (MS model)
A/V OUT jack (Non MS model)
LANC jack
BT panel block
JK-278 board
VC-376 board (Non MS model)
VC-377 board (MS model)
Lens block
Mechanism deck
Control key block
(SS10300)
1
CPC-15
(J-6082-564-A)
I/F unit for LANC control
(J-6082-521-A)
8
Adjustment
remote commander
(RM95)
AC adaptor AC IN
Non MS model: DCR-HC17E/HC19E/HC21/HC21E/HC22E
MS model: DCR-HC32/HC32E/HC33/HC33E
*:To eject a cassette, connect the cabinet (L) block assembly.
*
1
5
2
3
4
6
6
7
2-5 2-6

DCR-HC17E/HC19E/HC21/HC21E/HC22E/HC32/HC32E/HC33/HC33E
2-3. LCD SERVICE POSITION
1
4
4
3
3
3
97
8
0
5
6
1
77
8
5
6
23
4
2
CPC-15
(J-6082-564-A)
Lighit guide plate block
Lcd panel
PD-237 board I/F unit for LANC control
(J-6082-521-A)
1
8
AC adaptor AC IN
Adjustment
remote commander
(RM95)
1
2
3
5
6
4
FP-185 flexible board
Fold
Adhesive tape Adhesive tape
Boss
Rib
Hinge cover (M)
Hinge cover (M)
Hinge (103) assembly
A
B
Fold
2Set the hinge cover (M) inthe shown below.
FP-185 flexible board
1The Aand A, Band Bsection are united
and an angle is folded.
3Set the FP-185 flexible board in the direction of arrow A,
and then turn the hinge (103) assembly in the direction of arrow B.
BA
2-4. THE METHOD OF ATTACHMENT OF FP-185 FLEXIBLE BOARD
2-7 2-8

DCR-HC17E/HC19E/HC21/HC21E/HC22E/HC32/HC32E/HC33/HC33E
MS-249
CR-050
(Cradle model)
PD-237
VC-376 (Non MS model)/
VC-377 (MS model)
SI-042
JK-278
CD-533 LB-109
Board Name Function
CD-533 CCD IMAGER
CR-050 CRADLE TERMINAL
JK-278 JACK
LB-109 EVF, EVF BACKLIGHT
MS-249 MS CONNECTOR
PD-237 LCD DRIVE, BACKLIGHT DRIVE
SI-042 REMOTE COMMANDER RECEIVER, PITCH/YAW SENSOR
VC-376 A/D CONVERTER, TIMING GENERATOR, LENS DRIVE, EVR,
DV SIGNAL PROCESS, DV INTERFACE, REC/PB AMP, VIDEO OUT,AUDIO I/O
EVF DRIVE, CAMERA/MECHA CONTROL, SERVO, HI CONTROL, DC IN,
DC/DC CONVERTER, CONNECTOR
VC-377 A/D CONVERTER, TIMING GENERATOR, LENS DRIVE, VIDEO/AUDIO DSP,
DS/HI CONTROL, FLASH, SDRAM, DV SIGNAL PROCESS, DV INTERFACE,
REC/PB AMP, VIDEO, AUDIO I/O, EVF DRIVE, CAMERA/MECHA CONTROL,
SERVO, HI CONTROL, DC IN, DC/DC CONVERTER, CONNECTOR
FP-181 flexible
FP-185 flexible
FP-178 flexible
FP-182 flexible
FP-187 flexible
Control key block
(SS10300)
Control key block
(SB9000)
FP-180 flexible
FP-190 flexible
(Cradle model)
FFC-038 flexible FP-186 flexible
2-5. CIRCUIT BOARDS LOCATION
Non Cradle model: DCR-HC17E/HC19E/HC21/HC21E
Cradle model: DCR-HC22E/HC32/HC32E/HC33/HC33E
Non MS model: DCR-HC17E/HC19E/HC21/HC21E/HC22E
MS model: DCR-HC32/HC32E/HC33/HC33E
2-6. FLEXIBLE BOARDS LOCATION
Non Cradle model:DCR-HC17E/HC19E/HC21/HC21E
Cradle model: DCR-HC22E/HC32/HC32E/HC33/HC33E
2-9 2-10E

HELP
DCR-HC17E/HC19E/HC21/HC21E/HC22E/HC32/HC32E/HC33/HC33E
HELP
Sheet attachment positions and procedures of processing the flexible boards/harnesses are shown.
BT panel assy
Tape (BT)
FP-180 flexible board
FP-181 flexible board
FP-180 flexible board
VC-376/VC-377 board Tape (A)
Tape (A)

DCR-HC17E/HC19E/HC21/HC21E/HC22E/HC32/HC32E/HC33/HC33E
Link
Link
3. BLOCK DIAGRAMS
POWER BLOCK DIAGRAM (2/3)
OVERALL BLOCK DIAGRAM (2/5)
OVERALL BLOCK DIAGRAM (3/5)
POWER BLOCK DIAGRAM (1/3)
OVERALL BLOCK DIAGRAM (5/5)
OVERALL BLOCK DIAGRAM (1/5)
OVERALL BLOCK DIAGRAM (4/5) POWER BLOCK DIAGRAM (3/3)
POWER BLOCK DIAGRAM (2/3)
POWER BLOCK DIAGRAM (3/3)
OVERALL BLOCK DIAGRAM (2/5)
OVERALL BLOCK DIAGRAM (4/5)
OVERALL BLOCK DIAGRAM (3/5)
POWER BLOCK DIAGRAM (1/3)
OVERALL BLOCK DIAGRAM (5/5)
OVERALL BLOCK DIAGRAM (1/5)
NON MS model
Link
Link
POWER BLOCK DIAGRAM (2/3)
OVERALL BLOCK DIAGRAM (2/6)
OVERALL BLOCK DIAGRAM (4/6)
OVERALL BLOCK DIAGRAM (3/6)
POWER BLOCK DIAGRAM (1/3)
OVERALL BLOCK DIAGRAM (6/6)
OVERALL BLOCK DIAGRAM (1/6)
OVERALL BLOCK DIAGRAM (5/6)
POWER BLOCK DIAGRAM (3/3)
POWER BLOCK DIAGRAM (2/3)
POWER BLOCK DIAGRAM (3/3)
OVERALL BLOCK DIAGRAM (2/6)
OVERALL BLOCK DIAGRAM (4/6)
OVERALL BLOCK DIAGRAM (5/6)
OVERALL BLOCK DIAGRAM (3/6)
POWER BLOCK DIAGRAM (1/3)
OVERALL BLOCK DIAGRAM (6/6)
OVERALL BLOCK DIAGRAM (1/6)
MS model
NON MS model: DCR-HC17E/HC19E/HC21/HC21E/HC22E
MS model: DCR-HC32/HC32E/HC33/HC33E

DCR-HC17E/HC19E/HC21/HC21E/HC22E/HC32/HC32E/HC33/HC33E
3-1. BLOCK DIAGRAMS (NON MS model)
3-1-1. OVERALL BLOCK DIAGRAM (1/5) (NON MS model)
3-1 3-2
( ) : Number in parenthesis ( ) indicates the division number of schematic diagram where the component is located.
3. BLOCK DIAGRAMS
DA STRB
SE602
SE601
S601
(LENS COVER OPEN)
YAW AD
PITCH AD
PITCH SENSOR
YAW SENSOR
PITCH/YAW
SENSOR
AMP
8
12
2
18
19
IC602
30
S/H, AGC,
A/D CONVERTER
(1/12)
TIMING
GENERATOR
(1/12)
IC3001
20
18
21
22
25
26
28
31
33
4
40
1643
12
34
41
48
36
42
44
45
X3001
36MHz 5
CN101
CD-533 BOARD
VC-376 BOARD (1/5)
FE CLPOB
V1 – V4, RG,
VSHT, H1, H2
7
CCD
IMAGER
IRIS
(SHUTTER)
H
M
IRIS
METER
M
FOCUS
SENSOR
ZOOM
SENSOR
FOCUS
MOTOR
ZOOM
MOTOR
M
LENS BLOCK
CCD OUT
CN3101
12
8
9
1
ı
4
24
ı
27
21
LENS TEMP
SENSOR
IC3002
IC101
1
ı
4
9
10
12
ı
13
BUFFER
Q101
MODULATOR
Q8602
MODULATOR
Q8601
IRIS
DRIVE
Q3101
HALL GAIN
CONTROL
Q3103
LED
DRIVE
Q1001
2
ı
11
3
SI-042 BOARD (1/3)
NIGHTSHOT
PLUS
CN603
(1/3)
3
VST C RESET
2
5
NS LED K
11
XSHUTTER OPEN
13
CN1004
(1/3)
16
14
8
17
6
(2/12)
IRIS DRIVE
I DRIVE (-)
I BIAS (-)
6
I BIAS (+)
I HALL (-)
HALL AD
7
I HALL (+)
FC A, FC XA,
FC B, FC XB
ZM A, ZM XA,
ZM B, ZM XB
FC SENS OUT
16
ZM SENS OUT
17
THERMO OUT
19
NightShot Vcc
FC RST
ZM RST
LENS TEMP AD
XNS SW
HALL GAIN
IC3102
(2/12)
IC3101
FOCUS
MOTOR
DRIVE
ZOOM
MOTOR
DRIVE
2
4
21
23
9
ı
12
13
ı
16
5
7
17
19
05
SPCK
CAMERA/
MECHA
CONTROL
(7/12)
IC8601
(1/2)
77
78
75
70
69
67
61
80
82
83
62
73
71
23
179
178
OVERALL1 (5/5)
(PAGE 3-10)
9
OVERALL1 (2/5)
(PAGE 3-3)
1
11
5
6
12
8
9
199
ı
208
154
ı
157
164
ı
176
184
ı
186
18
ı
20
180
ı
178
209
216
214
215
212
213
190
LD EN0, LD DIR0A, LD DIR0B
LD EN1, LD DIR1A, LD DIR1B
FC RST
ZM RST
LD EN0, LD DIR0A, LD DIR0B
LD EN1, LD DIR1A, LD DIR1B
14
15
DV SIGNAL
PROCESS
(3/12)
IC6001
YAW AD
PITCH AD
VST C RESET
129
130
IR ON
194
187
127
128
173
100
XSHUTTER OPEN
205
40
59
20
5
ı
8
10
ı
13
CN3002
14
12
ı
9
7
ı
4
1
2
16
15
CLPDM, PBLK,
XSHP, XSHD 19
21
ı
23
3
4
126
127
42
43
130
131
35
38
37
VCK VCK
XRST VTR
CAM DD ON
XRST VTR
XRST VTR
TG AHD, TG AVD
TG ZSG1
TG ZV1
TG ID
TG VGAT
XRST VTR
CAM DD ON
XCS TG
XCS TG
CS CH, CH SO, CH SCK
CS CH, CH SO, CH SCK
CAM SO, CAM SCK
CAM SI, CAM SO, CAM SCKCAM SI, CAM SO, CAM SCK
CAM SI, CAM SO, CAM SCK
46 47 48
39
XTAL AMP
HALL REG
IC3103
(2/12)
IC9201
EVR
(D/A CONVERTER)
(2/12)
FREQ AMPOUT
FREQ TUNE
75
1
1
2
3 8
8
14
HALL AMP
5 7
HALL OFFSET
6
HALL GAIN
12
IRIS PWM, IRIS COM
10
HALL BIAS
1 3
2
6
7
94
95
194
ı
196
TRCKO
143
24
26
ı
28
IC6002
DV INTERFACE
(3/12)
19
LCKO
159 62
78 177
XCS IC 6002
XCS IC 6002
2 – 4
6 – 9 11
75 – 77
22 24 25
33 32
52 – 45
LBUS0-3
USB D±USB D±
USB DET
D24A00 – D31A07, DXXA08, DXXA09, ALE, WRX, RDX
D24A00 – D31A07, DXXA08, DXXA09, ALE, WRX, RDX
52
51
48
47
USB D+
USB
PULL UP
USB 3.1V
Q6003
78
77
96
75
76 OVERALL1 (2/5)
(PAGE 3-4)
2
OVERALL1 (4/5)
(PAGE 3-7)
4
OVERALL1 (3/5)
(PAGE 3-5)
3
OVERALL1 (4/5)
(PAGE 3-8)
5
OVERALL1 (3/5)
(PAGE 3-5)
6
OVERALL1 (4/5)
(PAGE 3-7)
7
OVERALL1 (2/5)
(PAGE 3-3)
8
RECDT
RECA1,2
RECCK
RF IN
DATA TO SFD
SFD BCK
DATA FROM SFD
SFD FCK
SFD LRCK
IC 6001 C OUT
IC 6001 Y OUT
63
68
64
69
67
110
113
121
123
119
141
BUFFER
Q6001 PANEL R
PANEL G
PANEL B
PANEL HD, PANEL VD
116
BW Y
OSD V
OSD V
CAM DD ON
VFO VD, VFO OE
USB DET
MERODY ENV
MERODY CARR
USB ON
XUSB EN
VREF
LINEOUT VD
189
XCS IC 6001
FRRV, TRRV, TRRT
193
XCS IC 6001-2
197
XIRQ IC 6001
192
181
182
129
SWP
161
DRP
162
XCS SFD
187
XCS VFD
188
203
68
97
161
208
214
131
113
204
18
201
132
163
164
155
215
XCS VD, VD SO, VD SCK
XCS VD, VD SI, VD SO, VD SCK VD SI, VD SO, VD SCK
VSP SO, XVSP SCK
VSP SO, XVSP SCK
VSP SI, VSP SO, XVSP SCK
VSP SI, VSP SO, XVSP SCK
SWP
38
39
XCS LCD
XCS EVF
43 XCS AU1
98 BEEP
202
D601
IR EMITTER/
NIGHTSHOT
TPA±, TPB±
AD0 – AD9
A: VIDEO SIGNAL
A: AUDIO SIGNAL
A: VIDEO/AUDIO SIGNAL
A: VIDEO/AUDIO/SERVO SIGNAL

DCR-HC17E/HC19E/HC21/HC21E/HC22E/HC32/HC32E/HC33/HC33E
A: VIDEO/AUDIO/SERVO SIGNAL
A: SERVO SIGNAL
DRUM PWM
05
IC8601
(2/2)
VC-376 BOARD (2/5)
IC9001
(3/3)
IC2201
(1/2)
CAP PWM
DRUM
ERROR
CAP
ERROR
DRUM
MOTOR
DRIVE
FG AMP
PG AMP
53
50
52
49
21 20
18
63
65
68
74
76
78
MECHA
CONTROL
(7/12)
32
33
69
72
26
27
22
23
Q2208
CN9001
DRUM FG
M901
DRUM MOTOR
DRUM VS
LOADING
MOTOR
DRIVE
TAPE END
DETECT
43
45
LPF
Q2207
1
ı
6
10
CAPSTAN
MOTOR
DRIVE
FG AMP
4
DRUM U, V, W
LM ±
LOAD, UNLOAD
TAPE END C
DRUM FG
DRUM PG
CAP VS
CAP FWD, CAP ON
CAP FWD, CAP ON
CAP FG
DRUM FG
DRUM PG
DEW AD
MODE SW A – C MODE SW A-C
LOAD, UNLOAD
TAPE END
TAPE LED ON
TAPE END
CAP FG
9
20
11
18
12
17
14
15
TAPE TOP C
T REEL ±
S REEL ±
TAPE TOP
DETECT
T REEL
FG AMP
S REEL
FG AMP
7
ı
9
26
25
22
25
22
23
DEW AD
1
ı
4
UHE±,
VHE±,
WHE±
CAP U, V, W
CN9003
CN9002
5
M
DRUM PG
M903
CAPSTAN MOTOR
M
HU, HV, HW
DEW SENSOR
MODE SWITCH
S902
Q9002
M902
LOADING MOTOR
Q901
TAPE END
SENSOR
D901
TAPE LED
M
FG1, 2 CAPSTAN FG
Q902
TAPE TOP
SENSOR
H902
T REEL
SENSOR
H901
MIC902
S903
CC DOWN
REC PROOF
S REEL
SENSOR
4PIN
CONNECTOR
(8/12) IC9001
(1/3)
(8/12)
IC9001
(2/3)
(8/12)
1
ı
4
11
ı
14
17
ı
20
6
ı
10
15
DRUM/
CAPSTAN
PWM DRIVE
(11/12)
21
7
24
8FG
PG
LED
DRIVE
TAPE LED K
189
1
IC8602
64k EEPROM
(7/12)
64
67
77
78
75
76
3
1
X8601
20MHz
XCS EEP 10
SERIAL
INTERFACE
38
36
37
XCS IC 9001
34
XRST VTR
OVERALL1 (1/5)
(PAGE 3-2) 1
OVERALL1 (1/5)
(PAGE 3-2) 8
8
XSYS RST 9
LM LIM DET LM LIM DET
41
44
35
SPCKSPCK
EEP SI, EEPSO, EEP SCK
XCRADLE IN
OVERALL1 (1/5)
(PAGE 3-2) 2
OVERALL1 (5/5)
(PAGE 3-9) 10 REC PROOF
CHIME SDA, SCK
XRST VTR
IC 8001 SI, IC 8001 SO. IC 8001 SCK. XCS IC 8001
VIDEO HEAD
CN6501
RF MON ODD
XODD, YODD
XEVEN, YEVEN
SWP
CN1007
EVEN
SWP
IC6501
REC/PB AMP
(4/12)
XCS EEP
2
4
6
5
2
3
1
30
44
35
46
10
9
3
4
38
CPC
(FOR CHECK)
CONT1, SW PS, ALL PS
40
42
39
37
45
CONT1, SW PS, ALL PS
172
29
28
RECDT
RECA1,2
RECCK
RF IN
RF MON
Z MECHA DECK
(MDX-Z210)
VSP SO, XVSP SCKVSP SO, XVSP SCK
SWITCHING
SWITCHING
10
ı
15
7
8
75
77
1
80
31
88
89
31
198
197
15
13
195
196
190
119
16
106
ı
108
63
ı
66
166
165
138
19
30 TAPE TOP TAPE TOP
29
192
TREEL FG TREEL FG
193 25
SREEL FG SREEL FG
REC PROOF
CHIME SDA, CHIME SCK
XCC DOWNXCC DOWN
180
110
87
86
84
2
5
6
SWP
EEP SI, EEPSO, EEP SCK
7
ı
5
ZOOM VR AD
SYS V
181
135
LED
DRIVE
Q8607
XEASY MODE LED
169
3-3 3-4
3-1-2. OVERALL BLOCK DIAGRAM (2/5) (NON MS model) ( ) :Number in parenthesis ( ) indicates the division number of schematic diagram where the component is located.

DCR-HC17E/HC19E/HC21/HC21E/HC22E/HC32/HC32E/HC33/HC33E 3-5 3-6
3-1-3. OVERALL BLOCK DIAGRAM (3/5) (NON MS model) ( ) :Number in parenthesis ( ) indicates the division number of schematic diagram where the component is located.
VC-376 BOARD (3/5)
CN1006
(1/2)
OVERALL1 (1/5)
(PAGE 3-2)
6
OVERALL1 (5/5)
(PAGE 3-9)
11
OVERALL1 (1/5)
(PAGE 3-2)
3
05
A: VIDEO SIGNAL
1
2
3
20
18
16
17
PANEL R
PANEL G
PANEL B
PANEL R
PANEL G
PANEL B
PANEL HD, PANEL VD
TP Y
TP SEL1
TP X
TP Y
TP SEL1
TP X
XCS LCD
XCS LCD
19
22
21
BW Y
PANEL HD, PANEL VD
BW Y
PANEL HD, PANEL VD
LB-109 BOARD
BACKLIGHT
DRIVE
Q9303
B/W
EVF
UNIT
21
22
26
20
42
45
44
48
1
12
13
PANEL R
PANEL G
PANEL B
PANEL HD, PANEL VD
PD-237 BOARD (1/2)
CN601
(1/2)
1
2
3
BL 2.8V
20
BACK LIGHT
DRIVE
Q606, 607,
611, 612 BL 2.8V
BL –15.5V
CN603
5
2
6
3
TP L
TP R
TP BOT
TP TOP
TP Y
TP SEL1
TP X
CN608
6
4
3
BL FB 1
BL H
TOUCH
PANEL
TOUCH
PANEL
I/F
Q601, 602
2.5 inch
COLOR
LCD
UNIT
34
21
22
26
20
42
45
44
48
1
R
G
B
COM, CS
5
3
23
24
2
6–9
11–14
19–22
4
CN605
BACKLIGHT
D901
RGT, PSIG, HCK1, HCK2,
WIDE, REF, HST, PCG,
XSTBY, DWN, EN, VCK, VST
LCD DRIVE
IC602
XCS LCD
33
32
5 – 12
14 16 17
24 28
LCD901
31
43
EXTDA
18
BL ON
VD SI, VD SO, VD SCK
18
16
17
BACKLIGHT
CONTROL
1
3
2
IC601
+
–
19
22
21
12
13
VR
VG
VB
COM, CS
18
16
21
19
5
ı
7
9
ı
15
20
17
CN302
D303
(BACKLIGHT)
HST,HCK1, HCK2,
BLK, STB, VCK, PCG,
REF, VST, EN, PSIG
EVF VR
EVF VG
EVF VB
COM CS
15
14
18
4
ı
13
17
16
CN9301
EVF HST,HCK1, HCK2,
BLK, STB, VCK, PCG,
REF, VST, EN, PSIG
EVF DRIVE
(6/12)
IC9301
XCS EVF
33
6 – 10
12 14 16
17 28 24
LCD902
31
43
XCS EVF
EXTDA
LED K
18 BL ON
EVF BACKLIGHT
CONTROL
(6/12)
1
3
2
IC9303
+
–23
7
8
4
18
ı
9
5
6
CN301
1
VD SI, VD SO, VD SCKVD SI, VD SO, VD SCK
VD SI, VD SO, VD SCK
