Sony HDR-PJ800 User manual

SERVICE MANUAL
Revision History
Published by Sony Techno Create Corporation
Sony Corporation
LEVEL 3
HDR-PJ800/PJ810/PJ810E/PJ820/PJ820E_L3
Check the SERVICE NOTE (LEVEL 2) before the service.
983477111.pdf
Digital HD Video Camera Recorder
The components identified by mark
0or dotted line with mark 0are
critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque 0sont critiques pour la
sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
9-834-771-11
Ver. Date History Contents S.M. Rev.
issued
1.0 2013.12 Official Release — —
2013L08-1
© 2013.12
Ver. 1.0 2013.12
Photo: HDR-PJ800/BLACK
US Model
AEP Model
North European Model
E Model
Hong Kong Model
Chinese Model
Korea Model
Tourist Model
Japanese Model
HDR-PJ800/PJ810/PJ810E/PJ820/PJ820E
Distinguishing MM-102 Boards (HDR-PJ800/PJ820/PJ820E)
Three types of MM-102 board are used in this unit.
When repairing an MM-102 board, identify its type by the IC model names printed on the surface of IC8101 and IC8201 on the MM-102 board.
IC8101 IC8201
Type A KLMBG4WE4A-A001T01 KLMBG4WE4A-A001T01
Type B THGBM7G8T4JBAIRH10 THGBM7G8T4JBAIRH10
Type C KLMCG8WE4A-A001T01 No Mount
Note:
IC8101 and IC8201 cannot be replaced with any other type of IC. Be sure to replace them with the same type of IC.
When replacing Type A or Type B of IC8101 and IC8201, be sure to replace IC8101 and IC8201 together.

– 2 –
HDR-PJ800/PJ810/PJ810E/PJ820/PJ820E_L3
SAFETY-RELATED COMPONENT WARNING!!
COMPONENTS IDENTIFIED BY MARK 0OR DOTTED LINE WITH
MARK 0ON THE SCHEMATIC DIAGRAMS AND IN THE PARTS LIST
ARE CRITICAL TO SAFE OPERATION. REPLACE THESE COMPO-
NENTS WITH SONY PARTS WHOSE PART NUMBERS APPEAR AS
SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUBLISHED BY
SONY.
ATTENTION AU COMPOSANT AYANT RAPPORT
À LA SÉCURITÉ!
LES COMPOSANTS IDENTIFIÉS PAR UNE MARQUE 0SUR LES
DIAGRAMMES SCHÉMATIQUES ET LA LISTE DES PIÈCES SONT
CRITIQUES POUR LA SÉCURITÉ DE FONCTIONNEMENT. NE REM-
PLACER CES COMPOSANTS QUE PAR DES PIÈCES SONY DONT
LES NUMÉROS SONT DONNÉS DANS CE MANUEL OU DANS LES
SUPPLÉMENTS PUBLIÉS PAR SONY.
Caution
Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type.
Dispose of used batteries according to the instructions.
注意
電池の交換は，正しく行わないと破裂する恐れがあります。
電池を交換する場合には必ず同じ型名の電池又は同等品と
交換してください。
使用済み電池は，取扱指示に従って処分してください。
SAFETY CHECK-OUT
After correcting the original service problem, perform the following
safety checks before releasing the set to the customer.
1. Check the area of your repair for unsoldered or poorly-soldered
connections. Check the entire board surface for solder splashes and
bridges.
2. Check the interboard wiring to ensure that no wires are “pinched”
or contact high-wattage resistors.
3. Look for unauthorized replacement parts, particularly transistors,
that were installed during a previous repair. Point them out to the
customer and recommend their replacement.
4. Look for parts which, through functioning, show obvious signs of
deterioration. Point them out to the customer and recommend their
replacement.
5. Check the B+ voltage to see it is at the values specified.
6. Flexible Circuit Board Repairing
• Set the soldering iron tip temperature to 350 °C approximately.
• Do not touch the soldering iron on the same conductor of the circuit
board (within 3 times).
• Be careful not to apply force on the conductor when soldering or
unsoldering.
1. 注意事項をお守りください。
 サービスのとき特に注意を要する個所については，キャビ
ネット，シャーシ，部品などにラベルや捺印で注意事項を
表示しています。これらの注意書き及び取扱説明書等の注
意事項を必ずお守り下さい。
2. 指定部品のご使用を
 セットの部品は難燃性や耐電圧など安全上の特性を持った
ものとなっています。従って交換部品は，使用されていた
ものと同じ特性の部品を使用して下さい。特に回路図，部
品表に0印で指定されている安全上重要な部品は必ず指定
のものをご使用下さい。
3. 部品の取付けや配線の引きまわしはもとどおりに
 安全上，チューブやテープなどの絶縁材料を使用したり，
プリント基板から浮かして取付けた部品があります。また
内部配線は引きまわしやクランパによって発熱部品や高圧
部品に接近しないよう配慮されていますので，これらは必
ずもとどおりにして下さい。
4. サービス後は安全点検を
 サービスのために取外したネジ，部品，配線がもとどおり
になっているか，またサービスした個所の周辺を劣化させ
てしまったところがないかなどを点検し，安全性が確保さ
れていることを確認して下さい。
5. チップ部品交換時の注意
 ・ 取外した部品は再使用しないで下さい。
 ・ タンタルコンデンサのマイナス側は熱に弱いため交換時
は注意して下さい。
6. フレキシブルプリント基板の取扱いについて
 ・ 半田こてのこて先温度は約350℃に設定してください。
 ・ 同一パターンに何度もコテ先を当てないで下さい。（3回
以内）
 ・ パターンに力が加わらないよう注意して下さい。
サービス，点検時には次のことにご注意ください。
– ENGLISH – – JAPANESE –
UNLEADED SOLDER
This unit uses unleaded solder.
Boards requiring use of unleaded solder are printed with the lead free
mark (LF) indicating the solder contains no lead.
(Caution: Some printed circuit boards may not come printed with the
lead free mark due to their particular size.)
: LEAD FREE MARK
Be careful to the following points to solder or unsolder.
• Set the soldering iron tip temperature to 350 °C approximately.
If cannot control temperature, solder/unsolder at high temperature
for a short time.
Caution: The printed pattern (copper foil) may peel away if the
heated tip is applied for too long, so be careful!
Unleaded solder is more viscous (sticky, less prone to
flow) than ordinary solder so use caution not to let solder
bridges occur such as on IC pins, etc.
• Be sure to control soldering iron tips used for unleaded solder and
those for leaded solder so they are managed separately. Mixing un-
leaded solder and leaded solder will cause detachment phenomenon.
無鉛半田について
本機には無鉛半田が使用されています。
無鉛半田を使用している基板には，無鉛（LeadFree）を意味する
レッドフリーマークがプリントされています。
（注意：基板サイズによっては，無鉛半田を使用していてもレッ
ドフリーマークがプリントされていないものがありま
す）
：レッドフリーマーク
無鉛半田は，下記の点に注意して使用してください。
・ 半田こてのこて先温度は約350℃に設定してください。
 温度調節が無理な場合は，高温短時間で作業を行ってくだ
さい。
 注意：半田こてを長く当てすぎると，基板のパターン（銅
箔）がはがれてしまうことがありますので，注意して
ください。また，従来の半田よりも粘性が強いため，
IC端子などが半田ブリッジしないように注意してく
ださい。
・ 半田こてのこて先は，必ず無鉛半田用と有鉛半田用に分け
て管理してください。
 無鉛半田と有鉛半田が混在すると剥離現象が発生してしま
います。
注意
如果电池更换不当会有爆炸危险。
只能用同样类型或等效类型的电池来更换。
务必按照说明处置用完的电池。

2-1
Ref. No. Part No. DescriptionRef. No. Part No. Description
HDR-PJ800/PJ810/PJ810E/PJ820/PJ820E_L3
(ENGLISH)
NOTE:
• -XX, -X mean standardized parts, so they may have some differ-
ences from the original one.
• Items marked “*” are not stocked since they are seldom required for
routine service. Some delay should be anticipated when ordering
these items.
• The mechanical parts with no reference number in the exploded
views are not supplied.
• Due to standardization, replacements in the parts list may be dif-
ferent from the parts specified in the diagrams or the components
used on the set.
• CAPACITORS:
uF: μF
• COILS
uH: μH
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• SEMICONDUCTORS
In each case, u: μ, for example:
uA...: μA... , uPA... , μPA... ,
uPB... , μPB... , uPC... , μPC... ,
uPD..., μPD...
(JAPANESE)
【使用上の注意】
• ここに記載されている部品は,補修用部品であるため,回路図及び
セットに付いている部品と異なる場合があります。
• -XX,-Xは標準化部品のため, セットに付いている部品と異なる場
合があります。
• *印の部品は常備在庫しておりません。
• コンデンサの単位でuFはμFを示します。
• 抵抗の単位Ωは省略してあります。
 金 被：金属被膜抵抗。
 サンキン：酸化金属被膜抵抗。
• インダクタの単位でuHはμHを示します。
• 半導体の名称でuA...,uPA...,uPB...,uPC...,uPD...等はそれぞれμA...,
μPA...,μPB...,μPC...,μPD...を示します。
The components identified by mark 0
or dotted line with mark 0are critical
for safety.
Replace only with part number specified.
Les composants identifiés par une mar-
que 0sont critiques pour la sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
0印の部品，または0印付の点線で囲まれた部品は，
安全性を維持するために，重要な部品です。
従って交換時は，必ず指定の部品を使用してください。
When indicating parts by reference num-
ber, please include the board name.
図面番号で部品を指定するときは基板名又はブロック
を併せて指定してください。
お願い
1-889-592-11 AN-1006 FLEXIBLE BOARD
*********************
A-1990-787-A CM-1007 BOARD, COMPLETE
***********************
(All mounted parts are not supplied, but they are included in CM-1007 COMPLETE
BOARD.)
1-887-472-11 FP-2099 FLEXIBLE BOARD
*********************
1-887-475-11 FP-2102 FLEXIBLE BOARD
*********************
A-1991-212-A ST BLOCK ASSY
(Not supplied) FP-2104 FLEXIBLE BOARD, COMPLETE
*******************************
(TH001 and FP-2104 FLEXIBLE COMPLETE BOARD are not supplied, but they are
included in ST BLOCK ASSY.)
< DIODE >
D0001 6-503-445-01 DIODE CL773SCW02SDWT
D0002 6-503-445-01 DIODE CL773SCW02SDWT
< THERMISTOR >
TH001 (Not supplied) THERMISTOR, NTC (SMD)
A-1917-913-A FP-2105 FLEXIBLE BOARD, COMPLETE
*******************************
(CN2102 is not supplied, but this is included in FP-2105 FLEXIBLE COMPLETE
BOARD.)
< CONNECTOR >
CN2102 (Not supplied) CONNECTOR (SHOE)
A-1975-584-A LSV-1650A
(Not supplied) FP-2178 FLEXIBLE BOARD, COMPLETE
*******************************
(FP-2178 FLEXIBLE COMPLETE BOARD is not supplied, but this is included in LSV-
1650A.)
< CAPACITOR >
C001 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C002 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
< CONNECTOR >
CN4901 1-820-745-11 CONNECTOR, BOARD TO BOARD
1-889-088-11 FP-2180 FLEXIBLE BOARD
*********************
1-889-089-11 FP-2181 FLEXIBLE BOARD
*********************
1-889-128-11 FP-2186 FLEXIBLE BOARD (A/B)
*************************
1-889-129-11 FP-2187 FLEXIBLE BOARD
*********************
1-889-175-11 FP-2188 FLEXIBLE BOARD
*********************
A-1991-236-A FR-1008 BOARD, COMPLETE
***********************
< CAPACITOR >
C4403 1-118-168-11 CERAMIC CHIP 1uF 20% 6.3V
C4404 1-118-168-11 CERAMIC CHIP 1uF 20% 6.3V
< CONNECTOR >
CN4401 1-779-328-51 CONNECTOR, FFC/FPC 8P
CN4402 1-784-650-21 CONNECTOR 2P
< DIODE >
D4401 6-502-193-01 DIODE SML-D12V8WT86SN
< IC >
IC4401 6-600-629-01 IC RS-470
< RESISTOR >
R4401 1-240-691-91 METAL CHIP 470 5% 1/20W
A-2043-878-A LD-1014 BOARD, COMPLETE (SERVICE)
*******************************
(C5152, C6804, C6805, C6808, C6809, C6826, C6827, C6828, C6830, C6831, C6832,
C6833, C6834, C6836, CN4101, CN4102, IC5150, IC6741, IC6742 and L5150 are not
supplied, but they are included in LD-1014 COMPLETE BOARD (SERVICE).)
< CAPACITOR >
C0302 1-118-047-11 CERAMIC CHIP 10uF 10% 16V
C1401 1-165-897-91 TANTAL. CHIP 22uF 20% 10V
*C4101 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
C5151 1-118-047-11 CERAMIC CHIP 10uF 10% 16V
C5152 (Not supplied) CERAMIC CHIP 0.1uF 10% 10V
C5153 1-118-047-11 CERAMIC CHIP 10uF 10% 16V
C5154 1-118-047-11 CERAMIC CHIP 10uF 10% 16V
*C6741 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
C6742 1-118-047-11 CERAMIC CHIP 10uF 10% 16V
2-2. ELECTRICAL PARTS LIST
Note1 : イメージャの交換時は6-1ページの“イメージャ交換時の
注意”を必ずお読みください。
Caution
Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type.
Dispose of used batteries according to the instructions.
注意
電池の交換は，正しく行わないと破裂する恐れがあります。
電池を交換する場合には必ず同じ型名の電池又は同等品と交換し
てください。
使用済み電池は，取扱指示に従って処分してください。
Note 2: Replace the battery holder (BH4201) together when replac-
ing the lithium storage battery (BT4201) on the RH-1003
board. (The battery holder removed once cannot be used
again.)
When mounting these parts, mount new battery holder first
and attach new lithium battery next.
Note 2: RH-1003基板のリチウム蓄電池（BT4201）を交換する場合
はバッテリホルダ（BH4201）も同時に新品に交換して下さ
い。（一度使用したバッテリホルダは再使用できません。）
部品 取り付けの際は， 先にバッテリホルダを取り付けてか
らリチウム電池を装着して下さい。
Note1 : Be sure to read “Precautions for Replacement of Imager”
on page 6-1 when changing the imager.
AN-1006 CM-1007 FP-2099 FP-2102 FP-2104 FP-2105 FP-2178 FP-2180 FP-2181 FP-2186 FP-2187 FP-2188 FR-1008 LD-1014
印の部品には、秘密情報が含まれています。
修理の際は、指示に従った対応を行ってください。
交換後の対象基板及び対象ICは、破壊のうえ廃棄してください。
The components identified by mark contain confidential information.
Strictly follow the instructions whenever the components are re-
paired and/or replaced.
Destroy and discard the prescribed board and IC after they are
replaced.
Les composants identifiés par le symbole contiennent des infor-
mations confidentielles.
Suivez scrupuleusement les instructions chaque fois qu'un com-
posant est remplacé et / ou réparé.
Veuillez détruire et éliminer les circuits imprimés et / ou les circuits
intégrés que vous avez remplacés.
标识有 的元件包含机密信息。
更换或维修元件时，请严格遵守指⽰。
更换后的电路板和IC，应予以报废。
注意
如果电池更换不当会有爆炸危险。
只能用同样类型或等效类型的电池来更换。
务必按照说明处置用完的电池。

2-2
Ref. No. Part No. Description Ref. No. Part No. Description Ref. No. Part No. DescriptionRef. No. Part No. Description
HDR-PJ800/PJ810/PJ810E/PJ820/PJ820E_L3
C6744 1-118-047-11 CERAMIC CHIP 10uF 10% 16V
*C6800 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C6801 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C6802 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C6803 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
C6804 (Not supplied) CERAMIC CHIP 0.01uF 10% 16V
C6805 (Not supplied) CERAMIC CHIP 0.01uF 10% 16V
*C6806 1-118-033-11 CERAMIC CHIP 0.047uF 10% 10V
*C6807 1-118-033-11 CERAMIC CHIP 0.047uF 10% 10V
C6808 (Not supplied) CERAMIC CHIP 0.1uF 10% 10V
C6809 (Not supplied) CERAMIC CHIP 0.1uF 10% 10V
*C6814 1-118-033-11 CERAMIC CHIP 0.047uF 10% 10V
*C6815 1-118-033-11 CERAMIC CHIP 0.047uF 10% 10V
*C6816 1-118-033-11 CERAMIC CHIP 0.047uF 10% 10V
*C6817 1-118-033-11 CERAMIC CHIP 0.047uF 10% 10V
*C6824 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C6825 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
C6826 (Not supplied) CERAMIC CHIP 0.1uF 10% 10V
C6827 (Not supplied) CERAMIC CHIP 0.1uF 10% 10V
C6828 (Not supplied) CERAMIC CHIP 0.22uF 20% 6.3V
*C6829 1-118-341-11 CERAMIC CHIP 0.0033uF 10% 16V
C6830 (Not supplied) CERAMIC CHIP 0.1uF 10% 10V
C6831 (Not supplied) CERAMIC CHIP 0.1uF 10% 10V
C6832 (Not supplied) CERAMIC CHIP 0.1uF 10% 10V
C6833 (Not supplied) CERAMIC CHIP 0.1uF 10% 10V
C6834 (Not supplied) CERAMIC CHIP 0.1uF 10% 10V
C6835 1-118-462-11 CERAMIC CHIP 1uF 10% 10V
C6836 (Not supplied) CERAMIC CHIP 0.001uF 10% 25V
C6837 1-118-029-11 CERAMIC CHIP 0.0022uF 10% 16V
C6838 1-118-029-11 CERAMIC CHIP 0.0022uF 10% 16V
C6843 1-118-462-11 CERAMIC CHIP 1uF 10% 10V
*C7100 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C7101 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C7701 1-118-033-11 CERAMIC CHIP 0.047uF 10% 10V
*C7702 1-118-033-11 CERAMIC CHIP 0.047uF 10% 10V
C7703 1-118-029-11 CERAMIC CHIP 0.0022uF 10% 16V
*C7704 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
C7705 1-118-029-11 CERAMIC CHIP 0.0022uF 10% 16V
*C7706 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
< CONNECTOR >
CN4101 (Not supplied) CONNECTOR, FPC (ZIF) 51P
CN4102 (Not supplied) CONNECTOR, FPC (ZIF) 51P
CN4103 1-822-245-61 CONNECTOR, FPC (LIF (NON-ZIF)) 20P
*CN6801 1-820-729-61 CONNECTOR, FPC (ZIF) 51P
CN7100 1-843-088-23 CARD CONNECTOR
< DIODE >
D2101 6-501-216-01 DIODE CL-271HR-C-TS
< IC >
IC5150 (Not supplied) IC TPS63060DSCR
IC6741 (Not supplied) IC DRV8835DSSR
IC6742 (Not supplied) IC LV8417CS-TE-L-H
IC6800 6-716-760-01 IC R2J30503LG
*IC6801 6-808-503-01 IC BU24130GU-E2
*IC6802 6-719-361-01 IC MM3416A28URE
< COIL >
L5150 (Not supplied) INDUCTOR 2uH
< TRANSISTOR >
*Q4101 6-553-023-01 TRANSISTOR FK3303010L
*Q6801 6-552-344-01 TRANSISTOR DRA3143T0L
< RESISTOR >
R2101 1-218-941-81 METAL CHIP 100 5% 1/16W
R2102 1-218-953-11 METAL CHIP 1K 5% 1/16W
*R5150 1-250-546-11 METAL CHIP 130K 1% 1/16W
R5151 1-250-519-11 METAL CHIP 10K 1% 1/16W
R6800 1-240-812-11 METAL CHIP 15K 0.5% 1/20W
R6801 1-250-553-11 METAL CHIP 270K 1% 1/16W
R6802 1-250-553-11 METAL CHIP 270K 1% 1/16W
R6803 1-240-707-91 METAL CHIP 10K 5% 1/20W
R6804 1-240-707-91 METAL CHIP 10K 5% 1/20W
*R6812 1-250-509-11 METAL CHIP 3.9K 1% 1/16W
R6813 1-250-519-11 METAL CHIP 10K 1% 1/16W
*R6814 1-250-549-11 METAL CHIP 180K 1% 1/16W
R6815 1-250-517-11 METAL CHIP 8.2K 1% 1/16W
R6816 1-250-551-11 METAL CHIP 220K 1% 1/16W
R6817 1-250-519-11 METAL CHIP 10K 1% 1/16W
R6818 1-250-517-11 METAL CHIP 8.2K 1% 1/16W
*R6819 1-250-549-11 METAL CHIP 180K 1% 1/16W
R6820 1-250-483-11 METAL CHIP 330 1% 1/16W
R6821 1-250-551-11 METAL CHIP 220K 1% 1/16W
*R6822 1-250-511-11 METAL CHIP 4.7K 1% 1/16W
R6823 1-250-533-11 METAL CHIP 39K 1% 1/16W
R6824 1-250-517-11 METAL CHIP 8.2K 1% 1/16W
R6825 1-250-505-11 METAL CHIP 2.7K 1% 1/16W
R6826 1-250-533-11 METAL CHIP 39K 1% 1/16W
R6827 1-250-517-11 METAL CHIP 8.2K 1% 1/16W
R6828 1-250-505-11 METAL CHIP 2.7K 1% 1/16W
< COMPOSITION CIRCUIT BLOCK >
RB2100 1-234-372-11 RES, NETWORK 100 (1005X4)
RB2101 1-234-372-11 RES, NETWORK 100 (1005X4)
RB6801 1-234-380-21 RES, NETWORK 47K (1005X4)
< SENSOR >
SE7701 8-826-002-52 GYRO SENSOR GSU-X370D/N-S (PITCH/YAW)
A-1917-502-A LF-2025 FLEXIBLE BOARD, COMPLETE
*******************************
< CONNECTOR >
CN201 1-816-655-61 CONNECTOR, FFC/FPC 8P
CN202 1-816-655-61 CONNECTOR, FFC/FPC 8P
1-887-303-13 LF-2026 FLEXIBLE BOARD
*********************
1-889-091-11 LF-2063 FLEXIBLE BOARD
*********************
A-1999-451-A MM-102 BOARD, COMPLETE (SERVICE)
(PJ810/PJ810E)
A-1999-452-A MM-102 BOARD, COMPLETE (SERVICE)
(PJ800/PJ820/PJ820E)
*****************************************
< CAPACITOR >
C8102 1-118-465-11 CERAMIC CHIP 4.7uF 10% 16V
C8103 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C8104 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C8202 1-118-465-11 CERAMIC CHIP 4.7uF 10% 16V
(PJ800/PJ820/PJ820E: Type A, B)
C8203 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
(PJ800/PJ820/PJ820E: Type A, B)
C8204 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
(PJ800/PJ820/PJ820E: Type A, B)
*C8701 1-116-738-11 CERAMIC CHIP 1uF 10% 6.3V
< CONNECTOR >
*CN8101 1-816-647-61 FFC/FPC CONNECTOR (LIF) 18P
< FERRITE BEAD >
FB8701 1-481-361-21 FERRITE, EMI (SMD)
FB8702 1-481-361-21 FERRITE, EMI (SMD)
FB8703 1-481-361-21 FERRITE, EMI (SMD)
FB8704 1-481-361-21 FERRITE, EMI (SMD)
FB8705 1-481-361-21 FERRITE, EMI (SMD)
FB8706 1-481-361-21 FERRITE, EMI (SMD)
FB8707 1-481-361-21 FERRITE, EMI (SMD)
FB8708 1-481-361-21 FERRITE, EMI (SMD)
< IC >
*IC8101 6-719-919-01 IC KLMCG8WE4A-A001T01
(PJ800/PJ820/PJ820E: Type C)
*IC8101 6-720-022-01 IC KLMBG4WE4A-A001T01
(PJ810/PJ810E, PJ800/PJ820/PJ820E: Type B)
*IC8101 6-721-326-01 IC THGBM7G8T4JBAIRH10
(PJ800/PJ820/PJ820E: Type B)
*IC8201 6-720-022-01 IC KLMBG4WE4A-A001T01
(PJ800/PJ820/PJ820E: Type A)
*IC8201 6-721-326-01 IC THGBM7G8T4JBAIRH10
(PJ800/PJ820/PJ820E: Type B)
IC8701 6-716-442-11 IC MM3404A29URE
< RESISTOR >
R8101 1-218-965-11 METAL CHIP 10K 5% 1/16W
R8112 1-218-990-81 SHORT CHIP 0
R8202 1-218-990-81 SHORT CHIP 0
(PJ800/PJ820/PJ820E: Type A, B)
< COMPOSITION CIRCUIT BLOCK >
RB8101 1-242-962-21 RES, NETWORK 82 (1005X4)
RB8102 1-242-962-21 RES, NETWORK 82 (1005X4)
A-1991-235-A OC-1003 BOARD, COMPLETE
***********************
(C7711, CN4302, IC7711, R7711, R7712, R7713, R7714, R7715 and SE7711 are not
supplied, but they are included in OC-1003 COMPLETE BOARD.)
< CAPACITOR >
*C4301 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
C7711 (Not supplied) CERAMIC CHIP 0.33uF 10% 6.3V
C7712 1-116-713-11 CERAMIC CHIP 22uF 20% 10V
*C7713 1-118-033-11 CERAMIC CHIP 0.047uF 10% 10V
*C7714 1-118-033-11 CERAMIC CHIP 0.047uF 10% 10V
*C7715 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C7717 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
C7718 1-118-026-11 CERAMIC CHIP 470PF 10% 25V
*C7719 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
< CONNECTOR >
CN4301 1-818-677-71 CONNECTOR, FPC (ZIF) 19P
CN4302 (Not supplied) CONNECTOR, FFC/FPC 6P
CN4303 1-779-328-51 CONNECTOR, FFC/FPC 8P
< IC >
IC7711 (Not supplied) IC NJM3232MG2 (TE2)
< RESISTOR >
R7711 (Not supplied) METAL CHIP 15K 1% 1/20W
R7712 (Not supplied) METAL CHIP 150K 1% 1/20W
R7713 (Not supplied) METAL CHIP 10K 1% 1/20W
R7714 (Not supplied) METAL CHIP 22K 1% 1/20W
R7715 (Not supplied) METAL CHIP 22K 1% 1/20W
< MR SENSOR >
RM4301 1-489-369-11 MR SENSOR (RM)
< SENSOR >
SE7711 (Not supplied) SENSOR, ANGULAR VELOCITY
A-1991-238-A PD-1027 BOARD, COMPLETE
***********************
(C7731, CN4501, IC8010 and R5300 are not supplied, but they are included in PD-
1027 COMPLETE BOARD.)
< CAPACITOR >
*C3701 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C4501 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
C5300 1-118-462-11 CERAMIC CHIP 1uF 10% 10V
C5301 1-118-039-11 CERAMIC CHIP 1uF 10% 25V
C7731 (Not supplied) CERAMIC CHIP 4.7uF 20% 6.3V
*C7732 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C7733 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
C8040 1-118-040-11 CERAMIC CHIP 2.2uF 10% 16V
C8041 1-118-040-11 CERAMIC CHIP 2.2uF 10% 16V
C8042 1-118-477-11 CERAMIC CHIP 2.2uF 10% 6.3V
C8043 1-118-168-11 CERAMIC CHIP 1uF 20% 6.3V
C8044 1-118-045-11 CERAMIC CHIP 2.2uF 10% 25V
C8045 1-118-477-11 CERAMIC CHIP 2.2uF 10% 6.3V
C8046 1-118-462-11 CERAMIC CHIP 1uF 10% 10V
C8047 1-118-462-11 CERAMIC CHIP 1uF 10% 10V
LD-1014 LF-2025 LF-2026 LF-2063 MM-102 OC-1003 PD-1027

2-3
Ref. No. Part No. Description Ref. No. Part No. Description Ref. No. Part No. DescriptionRef. No. Part No. Description
HDR-PJ800/PJ810/PJ810E/PJ820/PJ820E_L3
C8048 1-118-045-11 CERAMIC CHIP 2.2uF 10% 25V
C8049 1-118-168-11 CERAMIC CHIP 1uF 20% 6.3V
C8050 1-118-168-11 CERAMIC CHIP 1uF 20% 6.3V
C8051 1-118-168-11 CERAMIC CHIP 1uF 20% 6.3V
C8052 1-118-168-11 CERAMIC CHIP 1uF 20% 6.3V
C8053 1-118-462-11 CERAMIC CHIP 1uF 10% 10V
C8054 1-118-462-11 CERAMIC CHIP 1uF 10% 10V
C8055 1-118-168-11 CERAMIC CHIP 1uF 20% 6.3V
< CONNECTOR >
CN4501 (Not supplied) CONNECTOR, FPC (ZIF) 51P
CN4503 1-778-506-21 PIN, CONNECTOR (PC BOARD) 2P
CN4505 1-821-652-11 CONNECTOR, BOARD TO BOARD (REC
*CN4506 1-822-910-11 CONNECTOR, FPC (LIF (NON-ZIF))
*CN8040 1-842-522-21 CONNECTOR, FPC (ZIF) 61P
*CN8041 1-822-910-11 CONNECTOR, FPC (LIF (NON-ZIF))
< DIODE >
D8040 6-502-934-01 DIODE DB2S31100K8
D8080 6-500-240-01 DIODE DF5A6.8JE (TPLR3)
< FUSE >
*F061 1-576-872-31 FUSE (0.25A/50V)
< IC >
IC5300 6-718-155-01 IC R1207N823B-TR-FE
IC8010 (Not supplied) IC BU79R272-E2
< COIL >
L5300 1-460-369-11 INDUCTOR 33uH
< TRANSISTOR >
Q8080 6-552-758-01 TRANSISTOR RN4986FE
Q8081 6-552-758-01 TRANSISTOR RN4986FE
< RESISTOR >
R5300 (Not supplied) METAL CHIP 15 1% 1/16W
R5301 1-250-449-11 METAL CHIP 12 1% 1/16W
< SENSOR >
*SE4501 1-487-118-11 GMR SENSOR
*SE7731 1-490-064-31 SENSOR 3 AXIAL ACCELERATION
A-1991-241-A PJ-1008 BOARD, COMPLETE
***********************
(C2512, C2603, C2604, C2605, C2615, C2622, C2623, C2625, C2706, C2707, C2711,
C2712, IC2602, IC2603, L2704, RB2603 and X2601 are not supplied, but they are
included in PJ-1008 COMPLETE BOARD.)
< CAPACITOR >
C2501 1-116-749-11 CERAMIC CHIP 22uF 20% 6.3V
*C2504 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
*C2506 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
*C2507 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
*C2508 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
C2512 (Not supplied) CERAMIC CHIP 0.1uF 10% 10V
C2513 1-116-749-11 CERAMIC CHIP 22uF 20% 6.3V
C2514 1-165-897-91 TANTAL. CHIP 22uF 20% 10V
C2601 1-118-462-11 CERAMIC CHIP 1uF 10% 10V
C2602 1-118-462-11 CERAMIC CHIP 1uF 10% 10V
C2603 (Not supplied) CERAMIC CHIP 0.1uF 10% 10V
C2604 (Not supplied) CERAMIC CHIP 0.1uF 10% 10V
C2605 (Not supplied) CERAMIC CHIP 0.01uF 10% 16V
C2615 (Not supplied) CERAMIC CHIP 0.1uF 10% 10V
*C2617 1-128-965-11 CERAMIC CHIP 13PF 5% 50V
*C2618 1-128-965-11 CERAMIC CHIP 13PF 5% 50V
C2622 (Not supplied) CERAMIC CHIP 0.1uF 10% 10V
C2623 (Not supplied) CERAMIC CHIP 0.1uF 10% 10V
C2624 1-118-462-11 CERAMIC CHIP 1uF 10% 10V
C2625 (Not supplied) CERAMIC CHIP 0.1uF 10% 10V
C2701 1-118-037-11 CERAMIC CHIP 0.22uF 10% 25V
C2702 1-118-037-11 CERAMIC CHIP 0.22uF 10% 25V
C2703 1-118-037-11 CERAMIC CHIP 0.22uF 10% 25V
C2704 1-118-462-11 CERAMIC CHIP 1uF 10% 10V
C2706 (Not supplied) CERAMIC CHIP 0.1uF 10% 10V
C2707 (Not supplied) CERAMIC CHIP 0.1uF 10% 10V
C2708 1-116-749-11 CERAMIC CHIP 22uF 20% 6.3V
C2709 1-116-749-11 CERAMIC CHIP 22uF 20% 6.3V
C2710 1-118-477-11 CERAMIC CHIP 2.2uF 10% 6.3V
C2711 (Not supplied) CERAMIC CHIP 0.1uF 10% 10V
C2712 (Not supplied) CERAMIC CHIP 0.1uF 10% 10V
*C2715 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
*C2716 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
C2717 1-118-168-11 CERAMIC CHIP 1uF 20% 6.3V
C2718 1-116-749-11 CERAMIC CHIP 22uF 20% 6.3V
C2719 1-116-749-11 CERAMIC CHIP 22uF 20% 6.3V
< CONNECTOR >
CN2501 1-822-395-51 CONNECTOR, BOARD TO BOARD 60P
*CN2502 1-816-643-51 FFC/CONNECTOR, FPC (LIF) 10P
*CN2503 1-821-503-11 CONNECTOR, FPC (ZIF) 39P
CN2601 1-816-655-61 CONNECTOR, FFC/FPC 8P
< DIODE >
*D2701 6-503-185-01 DIODE DSR520, H3SONYF
< CONTACT TERMINAL >
ET251 1-780-945-11 TERMINAL, CONTACT
< IC >
IC2601 6-719-198-01 IC MM3411A33URE
IC2602 (Not supplied) IC W25X40CLNYD1
IC2603 (Not supplied) IC DPP3430
*IC2701 6-721-273-01 IC PAD2000
< COIL >
L2701 1-481-035-11 INDUCTOR 10uH
L2702 1-457-526-11 INDUCTOR 2.2uH
L2704 (Not supplied) INDUCTOR 2uH
< RESISTOR >
R2601 1-240-729-91 METAL CHIP 1M 5% 1/20W
R2602 1-240-683-91 METAL CHIP 100 5% 1/20W
R2608 1-240-718-91 METAL CHIP 100K 5% 1/20W
R2609 1-240-718-91 METAL CHIP 100K 5% 1/20W
R2621 1-240-705-91 METAL CHIP 6.8K 5% 1/20W
R2622 1-220-166-81 METAL CHIP 43 5% 1/16W
R2623 1-220-166-81 METAL CHIP 43 5% 1/16W
R2625 1-220-166-81 METAL CHIP 43 5% 1/16W
R2702 1-240-718-91 METAL CHIP 100K 5% 1/20W
R2707 1-240-718-91 METAL CHIP 100K 5% 1/20W
*R2708 1-248-336-11 RES-CHIP 0.1 1% 1/3W
R2709 1-240-705-91 METAL CHIP 6.8K 5% 1/20W
< COMPOSITION CIRCUIT BLOCK >
RB2602 1-234-377-21 RES, NETWORK 4.7K (1005X4)
RB2603 (Not supplied) RES, NETWORK 6.8K (1005X4)
RB2604 1-234-381-11 RES, NETWORK 100K (1005X4)
RB2701 1-234-381-11 RES, NETWORK 100K (1005X4)
< VIBRATOR >
X2601 (Not supplied) QUARTZ CRYSTAL UNIT (24MHz)
A-1991-234-A RH-1003 BOARD, COMPLETE
***********************
(C3401, C3402, C3505, C3507, C3508, C5801, C5803, C8509, C8510, C8511, C8512,
C8513, C8514, C8524 and IC8501 are not supplied, but they are included in RH-1003
COMPLETE BOARD.)
(BT4201 is not included in RH-1003 COMPLETE BOARD.)
< BATTERY HOLDER >
BH4201 1-251-928-21 SOCKET, BATTERY
< BATTERY >
BT4201 1-756-134-15 BATTERY, LITHIUM (SECONDARY)
< CAPACITOR >
C3401 (Not supplied) CERAMIC CHIP 0.022uF 10% 10V
C3402 (Not supplied) CERAMIC CHIP 0.022uF 10% 10V
*C3504 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
C3505 (Not supplied) CERAMIC CHIP 0.001uF 10% 25V
C3507 (Not supplied) CERAMIC CHIP 0.01uF 10% 16V
C3508 (Not supplied) CERAMIC CHIP 0.01uF 10% 16V
C3510 1-118-168-11 CERAMIC CHIP 1uF 20% 6.3V
*C4201 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
C4203 1-118-168-11 CERAMIC CHIP 1uF 20% 6.3V
C4204 1-118-047-11 CERAMIC CHIP 10uF 10% 16V
C5800 1-116-717-11 CERAMIC CHIP 10uF 20% 10V
C5801 (Not supplied) CERAMIC CHIP 220PF 10% 25V
C5803 (Not supplied) CERAMIC CHIP 0.1uF 10% 10V
C5805 1-118-047-11 CERAMIC CHIP 10uF 10% 16V
C8500 1-118-462-11 CERAMIC CHIP 1uF 10% 10V
C8501 1-118-462-11 CERAMIC CHIP 1uF 10% 10V
*C8503 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C8504 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
C8505 1-118-462-11 CERAMIC CHIP 1uF 10% 10V
C8506 1-118-462-11 CERAMIC CHIP 1uF 10% 10V
*C8507 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C8508 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
C8509 (Not supplied) CERAMIC CHIP 0.001uF 10% 25V
C8510 (Not supplied) CERAMIC CHIP 0.001uF 10% 25V
C8511 (Not supplied) CERAMIC CHIP 0.001uF 10% 25V
C8512 (Not supplied) CERAMIC CHIP 0.001uF 10% 25V
C8513 (Not supplied) CERAMIC CHIP 0.001uF 10% 25V
C8514 (Not supplied) CERAMIC CHIP 0.001uF 10% 25V
C8515 1-118-462-11 CERAMIC CHIP 1uF 10% 10V
C8516 1-118-462-11 CERAMIC CHIP 1uF 10% 10V
C8517 1-118-462-11 CERAMIC CHIP 1uF 10% 10V
C8518 1-118-462-11 CERAMIC CHIP 1uF 10% 10V
*C8519 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
C8520 1-118-462-11 CERAMIC CHIP 1uF 10% 10V
C8521 1-116-717-11 CERAMIC CHIP 10uF 20% 10V
C8522 1-116-729-11 CERAMIC CHIP 2.2uF 20% 10V
C8523 1-116-729-11 CERAMIC CHIP 2.2uF 20% 10V
C8524 (Not supplied) CERAMIC CHIP 0.0047uF 10% 6.3V
C8525 1-118-026-11 CERAMIC CHIP 470PF 10% 25V
*C8526 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C8527 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
< CONNECTOR >
*CN4201 1-842-522-21 CONNECTOR, FPC (ZIF) 61P
*CN4202 1-816-649-51 FFC/CONNECTOR, FPC (LIF) 22P
*CN4203 1-816-649-51 FFC/CONNECTOR, FPC (LIF) 22P
CN4204 1-816-654-61 FFC/FPC CONNECTOR (LIF) 6P
< FERRITE BEAD >
FB3401 1-400-331-11 FERRITE, EMI (SMD) (1005)
FB3402 1-400-331-11 FERRITE, EMI (SMD) (1005)
< IC >
*IC4201 6-719-358-01 IC MM3416A25URE
*IC5800 6-720-371-01 IC TPS61305AYFFR
*IC8500 6-719-793-01 IC AK4695ECB-L
IC8501 (Not supplied) IC MM3411A28URE
< JACK >
J3401 1-793-703-21 JACK (DIA. 3.5)
J3402 1-818-055-21 JACK
< COIL >
L5800 1-481-926-11 INDUCTOR 2.2uH
< TRANSISTOR >
*Q3401 6-552-354-01 TRANSISTOR DRC3144E0L
*Q4201 6-552-700-01 TRANSISTOR SSM3K15AMFV, L3SF
< RESISTOR >
R3501 1-208-895-81 METAL CHIP 2.2K 0.5% 1/16W
R3503 1-218-968-11 METAL CHIP 18K 5% 1/16W
R3504 1-218-968-11 METAL CHIP 18K 5% 1/16W
R4201 1-240-713-91 METAL CHIP 33K 5% 1/20W
R4202 1-240-695-91 METAL CHIP 1K 5% 1/20W
R8500 1-208-703-11 METAL CHIP 6.8K 0.5% 1/16W
R8501 1-208-703-11 METAL CHIP 6.8K 0.5% 1/16W
R8502 1-208-895-81 METAL CHIP 2.2K 0.5% 1/16W
R8503 1-208-871-81 METAL CHIP 220 0.5% 1/16W
R8504 1-208-871-81 METAL CHIP 220 0.5% 1/16W
R8505 1-208-895-81 METAL CHIP 2.2K 0.5% 1/16W
PD-1027 PJ-1008 RH-1003

2-4
Ref. No. Part No. Description Ref. No. Part No. Description Ref. No. Part No. DescriptionRef. No. Part No. Description
HDR-PJ800/PJ810/PJ810E/PJ820/PJ820E_L3
R8506 1-240-699-91 METAL CHIP 2.2K 5% 1/20W
R8507 1-240-699-91 METAL CHIP 2.2K 5% 1/20W
R8508 1-240-722-91 METAL CHIP 220K 5% 1/20W
< COMPOSITION CIRCUIT BLOCK >
RB3501 1-234-377-21 RES, NETWORK 4.7K (1005X4)
*RB3502 1-246-123-21 RES, NETWORK 27 (1005X4)
RB4201 1-234-376-11 RES, NETWORK 2.2K (1005X4)
< SWITCH >
S4201 1-798-119-11 SWITCH, TACTILE
S4202 1-798-119-11 SWITCH, TACTILE
S4203 1-798-119-11 SWITCH, TACTILE
S4204 1-798-119-11 SWITCH, TACTILE
S4205 1-798-119-11 SWITCH, TACTILE
S4206 1-798-119-11 SWITCH, TACTILE
< SENSOR >
*SE4201 1-487-118-21 GMR SENSOR
A-1999-450-A VC-1022 BOARD, COMPLETE (SERVICE)
********************************
(C0312, C0313, C0401, C0402, C4002, C4004, C4006, C5102, C5207, C5651,
C5652, C5701, C5702, C5703, C5704, C5712, C5714, C5715, C6021, C6023, C8830,
CN0500, CN3301, CN4001, CN4002, CN4901, CN9000, IC3001, IC5100, IC5500,
IC5651, IC5700, IC6000, IC8000, IC8120, IC8201, R1105, R5100, R5201, R6021,
R6062, R6120, R6121, R6123, R6124, R6125 and X6000 are not supplied, but they are
included in VC-1022 COMPLETE BOARD (SERVICE).)
< CAPACITOR >
*C0100 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
C0102 1-116-717-11 CERAMIC CHIP 10uF 20% 10V
C0104 1-118-040-11 CERAMIC CHIP 2.2uF 10% 16V
C0312 (Not supplied) CERAMIC CHIP 0.01uF 10% 16V
C0313 (Not supplied) CERAMIC CHIP 0.01uF 10% 16V
C0401 (Not supplied) CERAMIC CHIP 0.001uF 10% 25V
C0402 (Not supplied) CERAMIC CHIP 0.1uF 10% 10V
*C1041 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C1042 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C1061 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
*C1082 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C1105 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
*C1126 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
C1140 1-116-713-11 CERAMIC CHIP 22uF 20% 10V
*C3001 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C3302 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
C4002 (Not supplied) CERAMIC CHIP 220PF 10% 25V
C4004 (Not supplied) CERAMIC CHIP 0.01uF 10% 16V
C4006 (Not supplied) CERAMIC CHIP 0.01uF 10% 16V
*C4901 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
C5100 1-118-462-11 CERAMIC CHIP 1uF 10% 10V
C5101 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C5102 (Not supplied) CERAMIC CHIP 0.01uF 10% 16V
C5103 1-118-039-11 CERAMIC CHIP 1uF 10% 25V
C5104 1-118-462-11 CERAMIC CHIP 1uF 10% 10V
C5105 1-118-462-11 CERAMIC CHIP 1uF 10% 10V
C5106 1-118-462-11 CERAMIC CHIP 1uF 10% 10V
*C5107 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
C5108 1-118-477-11 CERAMIC CHIP 2.2uF 10% 6.3V
C5109 1-118-477-11 CERAMIC CHIP 2.2uF 10% 6.3V
C5110 1-118-040-11 CERAMIC CHIP 2.2uF 10% 16V
C5111 1-118-040-11 CERAMIC CHIP 2.2uF 10% 16V
C5112 1-118-040-11 CERAMIC CHIP 2.2uF 10% 16V
C5114 1-118-040-11 CERAMIC CHIP 2.2uF 10% 16V
C5116 1-116-713-11 CERAMIC CHIP 22uF 20% 10V
*C5117 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
*C5118 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
*C5120 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
*C5200 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
C5201 1-118-041-11 CERAMIC CHIP 4.7uF 10% 10V
*C5202 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C5203 1-116-738-11 CERAMIC CHIP 1uF 10% 6.3V
C5204 1-118-462-11 CERAMIC CHIP 1uF 10% 10V
C5205 1-118-462-11 CERAMIC CHIP 1uF 10% 10V
*C5206 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
C5207 (Not supplied) CERAMIC CHIP 4.7uF 20% 6.3V
C5208 1-118-462-11 CERAMIC CHIP 1uF 10% 10V
C5209 1-118-462-11 CERAMIC CHIP 1uF 10% 10V
*C5500 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
C5501 1-118-462-11 CERAMIC CHIP 1uF 10% 10V
*C5600 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
C5630 1-118-480-11 CERAMIC CHIP 4.7uF 10% 6.3V
C5631 1-118-462-11 CERAMIC CHIP 1uF 10% 10V
*C5640 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
C5650 1-118-039-11 CERAMIC CHIP 1uF 10% 25V
C5651 (Not supplied) CERAMIC CHIP 0.22uF 10% 6.3V
C5652 (Not supplied) CERAMIC CHIP 0.1uF 10% 10V
C5653 1-118-040-11 CERAMIC CHIP 2.2uF 10% 16V
C5654 1-118-047-11 CERAMIC CHIP 10uF 10% 16V
C5655 1-118-047-11 CERAMIC CHIP 10uF 10% 16V
C5656 1-118-039-11 CERAMIC CHIP 1uF 10% 25V
C5657 1-118-039-11 CERAMIC CHIP 1uF 10% 25V
C5658 1-118-386-11 CERAMIC CHIP 0.1uF 10% 16V
C5700 1-116-713-11 CERAMIC CHIP 22uF 20% 10V
C5701 (Not supplied) CERAMIC CHIP 0.1uF 10% 10V
C5702 (Not supplied) CERAMIC CHIP 0.1uF 10% 10V
C5703 (Not supplied) CERAMIC CHIP 0.1uF 10% 10V
C5704 (Not supplied) CERAMIC CHIP 0.1uF 10% 10V
C5705 1-118-480-11 CERAMIC CHIP 4.7uF 10% 6.3V
C5707 1-128-606-91 CERAMIC CHIP 15PF 5% 25V
C5708 1-118-477-11 CERAMIC CHIP 2.2uF 10% 6.3V
C5709 1-128-605-11 CERAMIC CHIP 12PF 5% 25V
C5710 1-128-605-11 CERAMIC CHIP 12PF 5% 25V
C5711 1-128-605-11 CERAMIC CHIP 12PF 5% 25V
C5712 (Not supplied) CERAMIC CHIP 0.1uF 10% 10V
C5714 (Not supplied) CERAMIC CHIP 0.1uF 10% 10V
C5715 (Not supplied) CERAMIC CHIP 0.1uF 10% 10V
*C6005 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C6006 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C6007 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C6009 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C6010 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
C6021 (Not supplied) CERAMIC CHIP 4.7uF 20% 6.3V
*C6022 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
C6023 (Not supplied) CERAMIC CHIP 4.7uF 20% 6.3V
*C6024 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C6025 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
C6062 1-118-477-11 CERAMIC CHIP 2.2uF 10% 6.3V
*C6063 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C6065 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C6066 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C6102 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C6122 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C6123 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C6124 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C6132 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C6133 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C6140 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
*C8121 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C8122 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C8123 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
C8201 1-118-477-11 CERAMIC CHIP 2.2uF 10% 6.3V
C8202 1-118-477-11 CERAMIC CHIP 2.2uF 10% 6.3V
C8205 1-118-477-11 CERAMIC CHIP 2.2uF 10% 6.3V
*C8206 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C8207 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C8209 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C8211 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C8630 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
*C8632 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
C8800 1-118-462-11 CERAMIC CHIP 1uF 10% 10V
C8830 (Not supplied) CERAMIC CHIP 0.22uF 20% 6.3V
< CONNECTOR >
*CN0400 1-843-120-21 HEADER ASSEMBRY
CN0500 (Not supplied) SOCKET, USB CONNECTOR
*CN3001 1-821-502-11 CONNECTOR, FPC (ZIF) 29P
CN3301 (Not supplied) CONNECTOR, HDMI (TYPE-D)
CN4001 (Not supplied) CONNECTOR, FPC (ZIF) 51P
CN4002 (Not supplied) CONNECTOR, FPC (ZIF) 51P
CN4003 1-843-469-11 CONNECTOR, FPC (ZIF) 61P
*CN4004 1-821-503-11 CONNECTOR, FPC (ZIF) 39P
*CN4005 1-816-644-51 FFC/CONNECTOR, FPC (LIF) 12P
*CN4006 1-816-647-61 FFC/CONNECTOR, FPC (LIF) 18P
CN4007 1-580-789-21 PIN, CONNECTOR (SMD) 6P
CN4901 (Not supplied) CONNECTOR, FPC (ZIF) 51P
CN4902 1-821-858-61 CONNECTOR, FPC (LIF (NON-ZIF)) 24P
CN9000 (Not supplied) CONNECTOR, HDMI (TYPE-D)
< DIODE >
D5600 8-719-421-71 DIODE MA132WA
D6081 6-503-126-01 DIODE DA2S10100K8
D6082 6-503-126-01 DIODE DA2S10100K8
D8800 6-503-126-01 DIODE DA2S10100K8
*D9000 6-502-988-01 DIODE RB480Y-40T2R
< FUSE >
F0300 1-576-415-31 FUSE (2A/32V)
F0301 1-576-415-31 FUSE (2A/32V)
F0302 1-576-406-31 FUSE (1.4A/32V)
F0400 1-523-231-31 FUSE (2.5A/50V)
*F4901 1-523-026-41 FUSE (0.25A/36V)
< FERRITE BEAD >
FB0301 1-481-349-21 EMI FERRITE (SMD) (1608)
FB0500 1-400-331-11 FERRITE, EMI (SMD) (1005)
FB0501 1-400-331-11 FERRITE, EMI (SMD) (1005)
FB0502 1-400-331-11 FERRITE, EMI (SMD) (1005)
*FB1061 1-481-250-11 INDUCTOR, FERRITE BEAD (1005)
FB1062 1-400-050-11 INDUCTOR, FERRITE BEAD
*FB1083 1-481-250-11 INDUCTOR, FERRITE BEAD (1005)
*FB1084 1-481-250-11 INDUCTOR, FERRITE BEAD (1005)
*FB3301 1-481-250-11 INDUCTOR, FERRITE BEAD (1005)
*FB6000 1-481-250-11 INDUCTOR, FERRITE BEAD (1005)
*FB6080 1-481-250-11 INDUCTOR, FERRITE BEAD (1005)
*FB6081 1-481-250-11 INDUCTOR, FERRITE BEAD (1005)
< IC >
IC3001 (Not supplied) IC TC7SZ32FU, RSONYJ
IC4901 6-711-178-01 IC TC74VHC125FK (EL, K)
IC4902 6-706-489-01 IC TC7SH32FU
IC5100 (Not supplied) IC BD8336GU-E2
IC5200 6-716-945-01 IC BD8331GU-E2
IC5500 (Not supplied) IC BD2224G-BZTR
IC5600 6-716-783-01 IC BD11600NUX-E2
*IC5630 6-714-833-01 IC TPS2553DBVR-1
IC5630 6-717-848-01 IC NCP380HSNAJAAT1G
IC5640 6-716-783-01 IC BD11600NUX-E2
IC5651 (Not supplied) IC OZ8072PN-C5-0-TR
IC5700 (Not supplied) IC MB9AF004BGL-G-103-ERE1
IC6000 (Not supplied) IC KSZ4G4G01A
IC6001 6-716-878-01 IC AK8153AU-L
IC8000 (Not supplied) IC BU79T272-E2
IC8120 (Not supplied) IC MB8AA4590BGL-G-ERE1
*IC8200 6-721-219-01 IC ADV7610BBCZ-RL
IC8201 (Not supplied) IC MM3416A33URE
IC8630 6-718-186-01 IC CS48L10-CWZR
< COIL >
*L0101 1-460-553-21 INDUCTOR 4.7uH
L0102 1-460-473-11 INDUCTOR 4.7uH
L0103 1-460-473-11 INDUCTOR 4.7uH
L0105 1-460-370-11 INDUCTOR 10uH
L0106 1-460-359-11 INDUCTOR 4.7uH
L1063 1-414-842-21 INDUCTOR 15nH
L1064 1-414-842-21 INDUCTOR 15nH
L5650 1-460-358-11 INDUCTOR 2.2uH
*L6021 1-481-103-21 INDUCTOR 4.7uH
*L9000 1-460-611-11 COMMON MODE CHOKE COIL
*L9001 1-460-611-11 COMMON MODE CHOKE COIL
< TRANSISTOR >
Q0201 6-551-630-01 TRANSISTOR RN1102MFV (TL3S
Q0202 8-729-055-01 TRANSISTOR RN4984FE
Q0300 6-552-842-01 TRANSISTOR QS8J2FU7TR
*Q1101 6-552-344-01 TRANSISTOR DRA3143T0L
*Q3001 6-552-354-01 TRANSISTOR DRC3144E0L
Q3002 8-729-053-57 TRANSISTOR RN1902FE
*Q3003 6-552-348-01 TRANSISTOR DRC3114E0L
Q3201 6-551-202-01 TRANSISTOR LM6K1FS8T2R
Q4901 6-551-630-01 TRANSISTOR RN1102MFV (TL3S
RH-1003 VC-1022

Ref. No. Part No. Description Ref. No. Part No. Description Ref. No. Part No. Description
HDR-PJ800/PJ810/PJ810E/PJ820/PJ820E_L3
2-5E
Q4902 6-552-874-01 TRANSISTOR RW1C025ZPT2CR
*Q5600 6-552-529-01 TRANSISTOR DMC964010R
Q5700 6-552-999-01 TRANSISTOR RW1E025RPT2CR
Q5701 6-551-630-01 TRANSISTOR RN1102MFV (TL3S
Q5702 6-553-038-01 TRANSISTOR DRA3115T0L
Q8800 6-551-631-01 TRANSISTOR RN1104MFV (TL3S
Q8801 6-552-874-01 TRANSISTOR RW1C025ZPT2CR
Q8830 6-550-576-01 TRANSISTOR SSM6E01TU
Q9000 6-551-202-01 TRANSISTOR LM6K1FS8T2R
*Q9001 6-552-700-01 TRANSISTOR SSM3K15AMFV, L3SF
Q9002 8-729-055-01 TRANSISTOR RN4984FE
< RESISTOR >
R0205 1-240-718-91 METAL CHIP 100K 5% 1/20W
*R0207 1-257-309-11 METAL CHIP 1M 1% 1/20W
*R0208 1-257-309-11 METAL CHIP 1M 1% 1/20W
*R0209 1-257-301-11 METAL CHIP 470K 1% 1/20W
*R0210 1-257-301-11 METAL CHIP 470K 1% 1/20W
R0401 1-240-714-91 METAL CHIP 47K 5% 1/20W
R1003 1-240-685-91 METAL CHIP 150 5% 1/20W
*R1062 1-250-507-11 METAL CHIP 3.3K 1% 1/16W
*R1066 1-250-469-11 METAL CHIP 82 1% 1/16W
R1068 1-240-685-91 METAL CHIP 150 5% 1/20W
R1083 1-240-687-91 METAL CHIP 220 5% 1/20W
R1084 1-240-685-91 METAL CHIP 150 5% 1/20W
R1089 1-240-679-91 METAL CHIP 47 5% 1/20W
R1105 (Not supplied) METAL CHIP 15K 1% 1/20W
R1106 1-240-687-91 METAL CHIP 220 5% 1/20W
R3001 1-240-718-91 METAL CHIP 100K 5% 1/20W
R3201 1-240-695-91 METAL CHIP 1K 5% 1/20W
R3202 1-240-718-91 METAL CHIP 100K 5% 1/20W
R3329 1-240-679-91 METAL CHIP 47 5% 1/20W
R4002 1-240-700-91 METAL CHIP 2.7K 5% 1/20W
R4905 1-240-718-91 METAL CHIP 100K 5% 1/20W
R5100 (Not supplied) METAL CHIP 47K 1% 1/20W
R5200 1-218-941-81 METAL CHIP 100 5% 1/16W
R5201 (Not supplied) METAL CHIP 100K 1% 1/20W
*R5202 1-257-273-11 METAL CHIP 33K 1% 1/20W
R5500 1-240-707-91 METAL CHIP 10K 5% 1/20W
R5630 1-240-711-91 METAL CHIP 22K 5% 1/20W
*R5631 1-257-267-11 METAL CHIP 18K 1% 1/20W
R5640 1-240-707-91 METAL CHIP 10K 5% 1/20W
R5650 1-240-679-91 METAL CHIP 47 5% 1/20W
*R5654 1-250-503-11 METAL CHIP 2.2K 1% 1/16W
R5655 1-240-699-91 METAL CHIP 2.2K 5% 1/20W
R5656 1-240-699-91 METAL CHIP 2.2K 5% 1/20W
R5701 1-240-701-91 METAL CHIP 3.3K 5% 1/20W
R5702 1-240-697-91 METAL CHIP 1.5K 5% 1/20W
R5711 1-240-711-91 METAL CHIP 22K 5% 1/20W
R5712 1-218-934-11 METAL CHIP 27 5% 1/16W
R5713 1-218-934-11 METAL CHIP 27 5% 1/16W
R6002 1-240-695-91 METAL CHIP 1K 5% 1/20W
R6021 (Not supplied) METAL CHIP 12K 1% 1/20W
R6041 1-240-695-91 METAL CHIP 1K 5% 1/20W
*R6060 1-257-249-11 METAL CHIP 3.3K 1% 1/20W
*R6061 1-257-249-11 METAL CHIP 3.3K 1% 1/20W
R6062 (Not supplied) METAL CHIP 12K 1% 1/20W
R6081 1-240-683-91 METAL CHIP 100 5% 1/20W
R6082 1-240-683-91 METAL CHIP 100 5% 1/20W
R6084 1-240-685-91 METAL CHIP 150 5% 1/20W
R6085 1-240-681-91 METAL CHIP 68 5% 1/20W
R6120 (Not supplied) METAL CHIP 240 1% 1/20W
R6121 (Not supplied) METAL CHIP 240 1% 1/20W
R6123 (Not supplied) METAL CHIP 240 1% 1/20W
R6124 (Not supplied) METAL CHIP 10K 1% 1/20W
R6125 (Not supplied) METAL CHIP 10K 1% 1/20W
R8800 1-218-965-11 METAL CHIP 10K 5% 1/16W
R8801 1-250-567-11 METAL CHIP 1M 1% 1/16W
R8830 1-240-718-91 METAL CHIP 100K 5% 1/20W
R8831 1-240-695-91 METAL CHIP 1K 5% 1/20W
R9000 1-240-712-91 METAL CHIP 27K 5% 1/20W
< COMPOSITION CIRCUIT BLOCK >
*RB0200 1-234-384-11 RES, NETWORK 1M (1005X4)
RB1081 1-234-376-11 RES, NETWORK 2.2K (1005X4)
RB1083 1-234-372-11 RES, NETWORK 100 (1005X4)
RB1084 1-234-372-11 RES, NETWORK 100 (1005X4)
RB1101 1-234-378-21 RES, NETWORK 10K (1005X4)
RB1104 1-234-380-21 RES, NETWORK 47K (1005X4)
RB1105 1-234-381-11 RES, NETWORK 100K (1005X4)
*RB3001 1-234-938-21 RES, NETWORK 3.3K (1005X4)
RB3101 1-234-380-21 RES, NETWORK 47K (1005X4)
RB4003 1-234-372-11 RES, NETWORK 100 (1005X4)
RB4004 1-234-373-21 RES, NETWORK 220 (1005X4)
RB4005 1-234-373-21 RES, NETWORK 220 (1005X4)
RB4901 1-234-378-21 RES, NETWORK 10K (1005X4)
RB5700 1-234-378-21 RES, NETWORK 10K (1005X4)
RB6080 1-234-372-11 RES, NETWORK 100 (1005X4)
RB6082 1-200-051-21 RES, NETWORK 150 (1005X4)
RB8201 1-234-380-21 RES, NETWORK 47K (1005X4)
RB9000 1-234-375-21 RES, NETWORK 1K (1005X4)
< VARISTOR >
VDR500 1-802-090-21 VARISTOR, CHIP
VDR501 1-802-090-21 VARISTOR, CHIP
VDR502 1-802-090-21 VARISTOR, CHIP
< VIBRATOR >
X5700 1-781-525-11 VIBRATOR, CRYSTAL (32.768kHz)
X5701 1-814-304-11 VIBRATOR, CRYSTAL (12MHz)
X6000 (Not supplied) QUARTZ CRYSTAL OSCILLATOR (72MHz)
X8200 1-814-515-11 QUARTZ CRYSTAL OSCILLATOR (28.636363MHz)
A-1991-231-A WF-1004 BOARD, COMPLETE
***********************
(C7402, CP7300, ET2301 and IC7401 are not supplied, but they are included in WF-
1004 COMPLETE BOARD.)
< CAPACITOR >
*C2305 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
C2307 1-117-730-81 CERAMIC CHIP 1.2PF 0.1PF 16V
C7301 1-118-477-11 CERAMIC CHIP 2.2uF 10% 6.3V
C7302 1-118-477-11 CERAMIC CHIP 2.2uF 10% 6.3V
C7303 1-118-477-11 CERAMIC CHIP 2.2uF 10% 6.3V
C7304 1-118-477-11 CERAMIC CHIP 2.2uF 10% 6.3V
C7305 1-118-477-11 CERAMIC CHIP 2.2uF 10% 6.3V
*C7401 1-118-458-11 CERAMIC CHIP 0.1uF 10% 6.3V
C7402 (Not supplied) CERAMIC CHIP 100PF 1% 50V
C7403 1-164-845-11 CERAMIC CHIP 5PF 0.25PF 50V
< CONNECTOR >
CN2301 1-821-858-61 CONNECTOR, FPC (LIF (NON-ZIF)) 24P
CN2302 1-794-375-21 PIN, CONNECTOR 2P
< COMPOSITION CIRCUIT BLOCK >
CP7300 (Not supplied) WLAN MODULE
< CONTACT TERMINAL >
ET2301 (Not supplied) ON BOARD CONTACT
< IC >
*IC7401 6-715-114-01 IC CXD9950AK
< RESISTOR >
R2316 1-240-718-91 METAL CHIP 100K 5% 1/20W
< COMPOSITION CIRCUIT BLOCK >
RB7301 1-234-372-11 RES, NETWORK 100 (1005X4)
RB7302 1-234-372-11 RES, NETWORK 100 (1005X4)
VC-1022 WF-1004

4-1
HDR-PJ800/PJ810/PJ810E/PJ820/PJ820E_L3
4. BLOCK DIAGRAMS
4-1. OVERALL BLOCK DIAGRAM (1/4)( ) : Number in parenthesis ( ) indicates the division number of schematic diagram where the component is located.
13
14
18,20,22,24, 26,28,30,32
GCS2_0_DOP0 - 3,
GCS2_0_DOM0 - 3
DOP0 - 3,
DOM0 - 3
SENS_HD
SENS_VD
6XRESET_18
CLK_SYS_IN
CLK_CMOS_IN
SENS_SI/SO/SCK/XCS
PDATA0 - 23 D0±, D1±
CN4004CN1001
G15
H15
AH14
AF15
D23
A5
1
3
INCK
K1
C3
J3
H3
V29
M26
8, 9, 11, 12
13
14
18,20,22,24, 26,28,30,32
6
8, 9, 11, 12
IRIS
(SHUTTER)
LENS BLOCK (1/2) CM-1007 BOARD
CONTROL
SWITCH BLOCK
(PS42300)
LF-2063
FLEXIBLE
BOARD
XHS
XVS
XCLR
SDO, SDI,
SCK, XCE
CPU, CAMERA DSP,
AV SIGNAL PROCESS,
LENS CONTROL,
MODE CONTROL,
HDMI PROCESS
(6/19 - 13/19)
IC6000
(1/3)
IC5700
(1/2)
VC-1022 BOARD (1/3)
CLOCK
GENERATOR
(6/19)
IC6001
CMOS
IMAGER
IC1001
VIDEO
SELECTOR
(17/19)
IC8120
AUDIO DSP
(15/19)
IC8630
LCD SERIAL
INTERFACE
TRANSMITTER
(17/19)
IC8000
LCD_XHD
LCD_XVD B4
A4
LCD_CLK
LCD_XHD
LCD_XVD
LCD_CLK
LCD_XHD
LCD_XVD
LCD_CLK
LCD_DATEN LCD_DATEN
XPANEL_EVF_PS XPANEL_EVF_PS
XCS_IC_8120
MISO_SDA
XCS_IC_8120
AV_SO/SCK
MISO_SDA
BCK_OUT_KJR,
LRCK_OUT_KJR,
MCK_INOUT_KJR
BCK_OUT_KJR,
LRCK_OUT_KJR,
MCK_INOUT_KJR
BCK_OUT_KJR,
LRCK_OUT_KJR,
MCK_INOUT_KJR
SDO_KJR SDO_KJR
Q1101
L13
K12
HSYNC_CS
VSYNC_WE G6
F5
PCLK
DATEN_CMD
XCS_LCD
CLK±
IC_6800_IC_6000_CLK
HDMI_RX_PDATA0 - 23 TMDS_DATA0± - 2±
HDMI
RECEIVER
(16/19)
IC8200
L4
L3
HDMI_RX_HSYNC
HDMI_RX_VSYNC F9
E9
TMDS_CLOCK±
DDCSDA_RX
DDCSCL_RX
SDO_IC_8120
BCK_OUT_IC_8120, LRCK_OUT_IC_8120,
MCK_OUT_IC_8120
HDMI_INPUT_HPA
B1 XSYS_RST
XSYS_RST
XSYS_RST XSYS_RST
XSYS_RST
I2C_SDA/SCK B6
D1
A6
HDMI_RX_I2S/DE/VCK
HDMI_RX_MCLK/SCLK/LRCK
X6000
72MHz
X1001
72MHz
X8200
28.636363MHz
LCD_R_0 - 7, LCD_G_0 - 7, LCD_B_0 - 7
LCD_B_0 - 7
OVERALL (4/4)
(PAGE 4-4)
2
OVERALL (3/4)
(PAGE 4-3)
4
OVERALL (2/4)
(PAGE 4-2)
3
18
17
1
3,5,6,8,9,11
12, 14
HPD
SWITCH
Q3201
CN3301
CN4901
8, 9, 14, 15
11, 12
TP_X 37
AV_SO/SCK 38, 39
I2C_SDA/SCK
AV_SO/SCK
I2C_SDA/SCK
20, 21
AV_SO/SCK
I2C_SDA/SCK
KEY_AD1
KEY_AD1, SS,
XPOWER_LED,
ZOOM_VR_AD
CN4005
XBB_RST
XBB_RST
XBB_RST
22
SP_L/R
SP_L/R
2, 3
XCS_EVF
XCS_EVF
AUDIO_L_I/O,
AUDIO_R_I/O
SDI0_SPDIF_IN_MAG
SDI1_MAG
SDI0_SPDIF_IN_KJR
SDI1_KJR
XCS_IC_8630
40
TP_Y 41
TP_SEL1 6
PANEL_NOR_REVERSE 5
PJ_TEMP_AD
XCS_LCD, TP_SEL1
PANEL_NOR_REVERSE,
PJ_TEMP_AD
TP_X
TP_Y
TP_SEL2
42
AV_SO/SCK
MISO_SDA
XPOWER_TACT_SW
USB SELECT
(4/19)
IC5600
LANC/UART
SELECT
(5/19)
IC5640
USB ACTIVE
SWITCH
Q5702
CN0500
CN9000
CN0400
MULTI
HDMI
OUT
USB_D+/-_MULTI
USB_D+/-_KJR
USB_SEL
USBVCC
AD_JACK_IN USB_ID, AD_JACK_IN,
DEBUG_UART0_RXD,
BOOT_SERIAL_IN
UART_TX/LANC_SIG
DEBUG_UART0_RXD,
BOOT_SERIAL_IN
POWER CONTROL
(2/19)
08
10
USB_ID
4
8
9
COMPO_VIDEOCOMPO_VIDEO
13
15
XRESET_REQ XRESET_REQ
XRESET_REQ
7
2, 311, 122, 3
LANC_SIG
DEBUG_UART0_TXD
SEL_UART_LANC
XPOWER_TACT_SW
XPOWER_TACT_SW
LED DRIVE
Q0201 SYS_CHG_LED
SYS_CHG_LED
SYS_DD_SI/SO/SCK
SYS_DD_SI/SO/SCK SYS_DD_SO/SCK
LANC_IC_ON
LANC_SIG
DC/DC CONVERTER
(1/19)
IC5100
DC/DC CONVERTER,
LANC DRIVER
(1/19)
IC5200
X5701
12MHz L9
L8
H11
G16
V13
X5700
32.768kHz L6
L5
BUILT-IN
USB CABLE
CHARGE
USB_D+/-_DWN
USB_D+/-_DWN
USB_D+/-_DWN
LANC_SI/SO
OVERALL (4/4)
(PAGE 4-4)
5
OVERALL (3/4)
(PAGE 4-3)
1
AUDIO_L_I/O,
AUDIO_R_I/O
PROJECTOR
IN
HDMI_TXCN/TXCP HDMI_TXCN/TXCP
HDMI_TX0SOP-TX2SOP, HDMI_TX0SON-TX2SON
15
17
18
3,5,6,8,9,11
12, 14
SDA HDMI_SDA
SCL
CEC
HotPlugDetect
HDMI_SCL
HDMI_CEC
HDMI_HPD
LEVEL SHIFT
Q9000
LEVEL SHIFT
Q9001
1 LEVEL SHIFT
Q9002
: VIDEO SIGNAL
: AUDIO SIGNAL
: VIDEO/AUDIO SIGNAL
XPANEL_POWER_ON
4
5
11
2
8, 9
SS
ZOOM_VR_AD
XPOWER_LED

4-2
HDR-PJ800/PJ810/PJ810E/PJ820/PJ820E_L3
4-2. OVERALL BLOCK DIAGRAM (2/4)( ) : Number in parenthesis ( ) indicates the division number of schematic diagram where the component is located.
PJ-1008 BOARD
PD-1027 BOARD
FP-2178 FLEXIBLE
BOARD
14
47 - 50, 53 - 56
35 - 38, 41 - 44
23 - 26, 29 - 32
20 ,21
3, 4, 7, 8, 11,12,16,17
PDATA16 - 23
P1
B1
B3 C11
DMD
CONTROL
(2/3)
IC2603
LCD SERIAL
INTERFACE
RECEIVER
(3/4)
IC8010
LED
DRIVE
(3/3)
IC2701
PDATA8 - 15
PDATA0 - 7
HSYNC_CS
12
N5
VSYNC_WE
19 PCLK
15 DATEN_CMD
DMD_HS_CLK_P/N
24
DMD_LS_RDATA
32
DMD_LS_WDATA
36
DMD_DCLK
26
DMD_DEN_ARSTZ
LED_SEL0,
LED_SEL1
INTZ
RESETZ
SPIO_DIN_GPIO,
SPIO_DOUT_GPIO,
SPIO_CLK_GPIO,
SPIO_CSZ0_GPIO
SPIO_DIN/DOUT,
SPIO_CLK,
SPIO_CSZ0 FLASH
MEMORY
(2/3)
IC2602
18, 20
13
I2C_SDA/SCL
DMD_HS_WDATA_C - F_P/N
18, 20
2, 4, 5, 7, 10,12,13,15
DCLK_P/N
21
LS_RDATA
35
LS_WDATA
37
LS_CLK
23
DMC_DEN_ARSTZ
1, 2
LED_ANODE
3, 4
RED_CATHODE
9, 10
BLU_CATHODE
7, 8
GRN_CATHODE
6
PJ_TEMP_ADPJ_TEMP_ADPJ_TEMP_ADPJ_TEMP_AD
D_P0 - P3, D_M0 - M3
CN4901CN2503
CN2501
14
47 - 50, 53 - 56
35 - 38, 41 - 44
23 - 26, 29 - 32
LCD_DR0 - 7
LCD_DR0 - 7
G6
LCD_DG0 - 7
LCD_DG0 - 7
LCD_DB0 - 7
LCD_DB0 - 7
LCD_HD
LCD_HD
12
F5
B6
LCD_VD
LCD_VD
19
LCD_CK
LCD_CK
LCD_DR0 - 7
LCD_DG0 - 7
LCD_DB0 - 7
LCD_HD
LCD_VD
LCD_CK
XCS_LCD
AV_SO/SCK
XCS_LCD
AV_SO/SCK
TP_X
TP_Y
TP_X
TP_Y
TP_R
TP_BOT
15
LCD_DATEN
LCD_DATEN
18, 20
13
I2C_SDA/SCLI2C_SDA/SCL
CN4505
CN4503
31
30
32
6 - 13
14 - 21
22 - 29
CN8040
CN2502
PROJECTOR
UNIT
X2601
24MHz
J1
H1
TOUCH
PANEL
3.0 INCH
WIDE COLOR
LCD
LCD901
(LCD MODULE)
36
34, 35
CN4506
CN4501
Q8080, Q8081
4
1
2
5
TP_SEL1 TOUCH PANEL
INTERFACE
SE4501
PANEL
NORMAL/REVERSE
DETECT
(4/4)
SP901
(SPEAKER)
I2C_SDA/SCL
SE7731
3 AXIAL
ACCELERATION
SENSOR
(2/4)
30
10
SP_L, SP_R SP_R±
15
11
46
12
13, 14 40, 4131, 3249, 50
1, 2
37, 38, 43, 44
D0±, D1±
CLK±
XBB_RST
FP-2180 FLEXIBLE
BOARD
PJ_TEMP_AD
XCS_LCD
AV_SO/SCK
TP_X
TP_Y
I2C_SDA/SCL
TP_SEL1
SP_L, SP_R
47
D0±, D1±
CLK±
XBB_RST
PANEL_NOR_REVERSE PANEL_NOR/REV
OVERALL (1/4)
(PAGE 4-1)
3
: VIDEO SIGNAL
: AUDIO SIGNAL
08

4-3
HDR-PJ800/PJ810/PJ810E/PJ820/PJ820E_L3
4-3. OVERALL BLOCK DIAGRAM (3/4)( ) : Number in parenthesis ( ) indicates the division number of schematic diagram where the component is located.
3
1
5
RH-1003 BOARD
AUDIO
PROCESSOR
(3/4)
IC8500
LED DRIVER
(1/4)
IC5800
Q3401
LCD_XHD
B3
LCD_XVD
LCD_CLK
5
6
4
CN4203
COLOR EVF
UNIT
LCD902
CN4201
XBB_RST 3
AV_SO/SCK
HP_R_OUT
HP_L_OUT
17, 19
XCS_EVF 20
30
59, 60 43, 4714, 15 16, 17
LCD_DB0 - 7
LCD_XHD
LCD_XVD
LCD_CLK
XBB_RST
XCS_EVF
LCD_DB0 - 7LCD_DB0 - 7
LCD_XHD
LCD_XVD
LCD_CLK
XBB_RST
XCS_EVF
AV_SO/SCK
AV_SO/SCK
18 - 22
LED1_3_K
3 - 7
LED2_K
TH
XCS_IC_8500
21 - 2345, 48
13 BEEP_PWM_P
I2C_SDA/SCK
I2C_SDA/SCK
42
1
XSYS_RST
HP_JACK_IN
MIC_JACK_IN
1
10
D3
XSYS_RST
46 SDI1_MAG
BCK_OUT_IC_8120,
LRCK_OUT_IC_8120,
MCK_OUT_IC_8120
AUDIO_L_I/O,
AUDIO_R_I/O
26
27
19
11
29
32 - 39
FP-2187
FLEXIBLE
BOARD
FP-2104 FLEXIBLE
BOARD
AN-1006 FLEXIBLE
BOARD
8 - 11, 13 - 16
(HEADPHONE)
J3402
EXT_MIC_L
INT_MIC_L
INT_MIC_R
INT_MIC_F
EXT_MIC_R
J3401
(L)
PLUG IN
POWER
CN4204
CN4202
(R)
(F)
44
SHOE_MIC_FL/FR
SDO_IC_8120
25
SP_L_+, SP_R_-
SDI0_SPDIF_IN_MAG
MIC901
MICROPHONE
UNIT
D0001, D0002
(VIDEO LIGHT)
TH001
Q4201
XEVF_SW
6
KEY_AD2
2
XPOWER_TACT_SW
8
EVF PULL OUT
DETECT
(4/4)
SE4201
S4201 - S4206
53
2, 3 15, 1947, 48 45, 4639 - 4114, 17
49
20
61
52
16
36
35
43
51
33
23 - 30
18
37
56
60
54
AV_SO/SCK
XCS_IC_8500
BEEP_PWM_P
I2C_SDA/SCK
XSYS_RST
HP_JACK_IN
MIC_JACK_IN
SDI1_MAG
BCK_OUT_IC_8120,
LRCK_OUT_IC_8120,
MCK_OUT_IC_8120
AUDIO_L_I/O,
AUDIO_R_I/O
SHOE_MIC_FL/FR
SDO_IC_8120
SP_L/R
SDI0_SPDIF_IN_MAG
XEVF_SW
KEY_AD2
XPOWER_TACT_SW
AUDIO_L_I/O,
AUDIO_R_I/O
XEVF_SW
XPOWER_TACT_SW
FP-2181
FLEXIBLE
BOARD
WF-1004 BOARD
CN2301
ET2301
CN2302
CN4902
23
2
187
178
205
214
520
223
421
322
12 - 15
1, 2
10 - 13
WIRELESS LAN
ANTENNA
WIRELESS LAN
MODULE
CP7300
WLAN_SD_CLK
WLAN_SD_CMD
XWLAN_RST
WLAN_SD_D0 - D3
31
NFC
INTERFACE
IC7401
BUFFER
(19/19)
IC4901
BUFFER CONTROL
(19/19)
IC4902
NFC_SCK
NFC_SW
NFC_SEL
NFC_IRQ
XNFC_RFDET
NFC_DATA
NFC_L1/L2
WLAN_ANT_MOD
WLAN_SD_CLK
WLAN_SD_CLK,
WLAN_SD_CMD,
XWLAN_RST
WLAN_SD_CMD
XWLAN_RST
WLAN_SD_D0 - D3WLAN_SD_D0 - D3
NFC_SCK
NFC_SW
NFC_SW,
NFC_IRQ,
XNFC_RFDET
NFC_SELNFC_SEL
XCS_NFC
NFC_IRQ
XNFC_RFDET
NFC_DATA
DWN_NFC_SCK
DWN_NFC_SO
DWN_NFC_SO,
DWN_NFC_SI,
DWN_NFC_SCK
DWN_NFC_SI ANT901
NFC
ANTENNA
DWN_NFC_SO,
DWN_NFC_SI,
DWN_NFC_SCK
2 - 9
10 - 17
MM-102 BOARD FP-2188
FLEXIBLE
BOARD
CN8101 CN4006
11
13
8
6
TE1_CLK
TE1_CMD
INTERNAL
MEMORY
(1/2)
IC8101
INTERNAL
MEMORY
(2/2)
IC8201
PJ800/PJ820/PJ820E
TE1_DAT_0 - 7
TE1_DAT_0 - 7
TE1_DAT_0 - 7
TE1_CLK
TE1_CMD
MMC_CLK
MMC_CMD
MMC_DAT_0 - 7
FP-2186
FLEXIBLE
BOARD (B)
(1/2)
LD-1014 BOARD (1/2)
MSX_CLK
CN4002
(1/2)
CN7100
CN4102
(2/2)
VC-1022 BOARD (2/3)
D6081
MSX_BIO_0 - 3
16 MSX_BS
18 MSX_INS_HIZ
MSX_INS_HIZ
47
20 - 23
SD_CLK
D6082
SD_DAT_0 - 3
34
XMS_ACC_LED
44
SD_CMD
32 SD_WP
25 SD_XSDCD
SD_XSDCD
MSX_INS_HIZ
SD_XSDCD
46
27 - 30
36
34
5
29 - 32
18
8
20
27
6
MSX_CLK
MSX_BIO_0 - 3
MSX_BS
MSX_INS_HIZ
SD_CLK
SD_DAT_0 - 3
XMS_ACC_LED
SD_CMD
SD_WP
SD_XSDCD
D2101
(ACCESS)
22 - 25
17
7
14
8, 10, 11,16
15
6
26
24
1, 3, 21, 23
08
CN3001
5
15
7
26 - 28
20
22
18
19
1 - 314, 165, 6
23, 24
IHS_ID1 - ID3ID1 - ID3
12, 14
AUDIO_L_I/O,
AUDIO_R_I/O
EXT_STROBE_ON
X_CONTACT
ST_F3
6ST_F2
IHS_ID1 - ID3
EXT_STROBE_ON
EXT_STRB_SI/SO
SHOE_MIC_FL/FR
STROBE SWITCH
(14/19)
IC3001
Q3003
EXT_STRB_SCK
EXT_STRB_CONT
LEVEL SHIFT
Q3001, Q3002
MUITI
INTERFACE
SHOE
FP-2105 FLEXIBLE BOARD
CN2102
WALN_SD_CMD/AUDIO_L,
XGPS_RST/XWLAN_RST/AUDIO_R
F1/EXT_EVF_SO
X_CONTACT
F2/EXT_EVF_S1
F3/EXT_EVF_SCK
MIC_L_GVIF_SDATA_P,
MIC_L_GVIF_SDATA_N
OVERALL (1/4)
(PAGE 4-1)
1
OVERALL (1/4)
(PAGE 4-1)
4
MEMORY
STICK
PRO DUO
SD
: VIDEO SIGNAL
: AUDIO SIGNAL
: VIDEO/AUDIO SIGNAL
CPU, CAMERA DSP,
AV SIGNAL PROCESS,
LENS CONTROL,
MODE CONTROL,
HDMI PROCESS
(6/19 - 13/19)
IC6000
(2/3)
IC5700
(2/2)
POWER CONTROL
(2/19)
CN4003
DWN_XCS
PJ810/PJ810E/PJ820/PJ820E

4-4
HDR-PJ800/PJ810/PJ810E/PJ820/PJ820E_L3
4-4. OVERALL BLOCK DIAGRAM (4/4)( ) : Number in parenthesis ( ) indicates the division number of schematic diagram where the component is located.
FP-2186
FLEXIBLE
BOARD (B)
(2/2)
FP-2186
FLEXIBLE
BOARD (A)
FP-2099
FLEXIBLE
BOARD
LF-2025
FLEXIBLE
BOARD
LF-2026 FLEXIBLE
BOARD
CONTROL
SWITCH BLOCK
(RS42300)
ROLL SENSOR
AMP
(1/2)
IC7711
REMOTE
SENSOR
IC4401
IRIS/ND
MOTOR DRIVE
(2/5)
IC6801
PITCH/YAW
DRIVE
(1/5)
M901
(PITCH)
OPTICAL IMAGE
STABILIZER
LENS BLOCK (2/2)
IC6741
LENS BARRIER
DRIVE
(1/5)
IC6742
STEADYSHOT
PROCESSOR,
FOCUS/ZOOM
MOTOR DRIVE
(2/5)
IC6800
PANEL
OPEN/CLOSE
DETECT
(2/2)
SE4301
ROLL
SENSOR
(1/2)
LENS
BARRIER
UNIT
SE7711
D4401
(RECORDING)
CN4002
(2/2)
CN4103CN4301
CN4102
(2/2)
CN4001CN4101
CN6801
CN102
VC-1022 BOARD (3/3)LD-1014 BOARD (2/2)
OC-1003 BOARD
DIAL_A/B
KEY_AD3
9
XTALLY_LED
22
4012
SIRCS_SIG
20 VST_C_CHARGE
XTALLY_LED
SIRCS_SIG
VST_C_CHARGE
VST_C_CHARGE
21
ROLL_AD
14
XPANEL_POWER_ON
45
6, 7
43
38
DIAL_A/B
Q4101
KEY_AD3
ROLL_AD
DIAL_A/B
KEY_AD3
ROLL_ADROLL_AD
XTALLY_LED
SIRCS_SIG
XPANEL_POWER_ONPANEL_O/C_GMR PANEL_O/C_GMR
7
45, 46
IC_6801_SI/SO/SCK
37 - 39 13 - 15
9
13
20
10, 11
CN4302
DIAL_A/B
KEY_AD3
1
08
2
1
6
7
2, 6
11
7
PITCH/YAW
SENSOR
(4/5)
SE7701
1
9, 10
3, 4
16, 17
1, 2
18, 19
IC_6801_XCS
3319 IC_6801_VD
3022 XIC_6801_RST
3517 IC_6800_IC_6801_CLK
IC_6800_IC_6801_CLK
IC_6801_SI/SO/SCK
I_DRIVE±, I_BIAS±,
I_HALL±
IC_6800_SI/SO/SCK
24, 25, 27 25, 27, 28
IC_6800_SI/SO/SCK
XCS_IC_6801
26
26 IC_6800_XCSXCS_IC_6800
29
23 IC_6800_INT_REQIC_6800_INT_REQ
32
20 CAM_VCAM_V
46
6XIC_6800_CPU_RSTXIC_6800_CPU_RST
IC_6801_VD
IC_6801_VD
XIC_6801_RST
IC_6800_IC_6801_CLK
IC_6800_IC_6801_CLK
IC_6801_PIO0/PIO1
IC_6801_PIO0/PIO1
39, 40 12, 13
ZM_DIR_A/BZM_DIR_A/B
SHUTTER_A
SHUTTER_XA
SHUTTER_A
SHUTTER_XA
SHUTTER_A
SHUTTER_XA
4111 ZM_ENBZM_ENB
3814 IC_6800_EXPOSEIC_6800_EXPOSE
4210 IC_6800_P_LIMITIC_6800_P_LIMIT
36
16
XSYS_RST
XSYS_RST
439ZM_SENSAZM_SENSE1A
ZM_SENSE1A
12
40 LENS_TEMP_ADLENS_TEMP_AD
43
9LENSV_ENLENSV_EN
4210 LENS_COVER_DIR
30
32
31
LENS_COVER_DIR_PWM
LENSV_EN
LENS_COVER_DIR_PWM
E20
K20
L12
C7
E3
F5
D1
D5
OVERALL (1/4)
(PAGE 4-1)
2
OVERALL (1/4)
(PAGE 4-1)
5
21, 22
23 - 26
27, 46
34, 35, 37, 38, 40, 41
ND_DRIVE±, ND_BIAS±,
ND_HALL±
PITCH_BIAS±,
PITCH_HALL±
28, 30, 31, 39, 44, 45
IRIS_DRIVE±/OPEN,
IRIS_BIAS±, IRIS_HALL±
2 - 6, 8
ND_DRIVE±/IN,
ND_BIAS±, ND_HALL±
14 - 18, 20
FOCUS±
PITCH±
YAW_BIAS±,
YAW_HALL±
YAW±
FOCUS±
11,12 32, 42 F_MR_A/B
F_MR_A/B
F_MR_A/B
29 50
Z_PI_C
10 33
1 - 6
20 - 22
15 - 17
L_TEMP_OUT LENS_TEMP_AD
PITCH_INA_O,
PITCH_INB_O
PITCH±
PITCH_AD
YAW_AD
7 - 12
YAW_INA_O,
YAW_INB_O
YAW±
CN201 CN101
ZOOM_A/B/XA/XB
25, 26, 47,48
ZOOM_A/B/XA/XB
MM
1 - 46 - 8
M902
(YAW) CN202
MM
5 - 71, 2, 4
13 - 1821 - 237 - 121 - 5
PITCH_BIAS±,
PITCH_HALL±
PITCH±
YAW_BIAS±,
YAW_HALL±
PITCH_BIAS±,
PITCH_HALL±
PITCH_BIAS-,
PITCH_HALL±
YAW_BIAS±,
YAW_HALL±
YAW_BIAS-,
YAW_HALL±
YAW±
FP-2102
FLEXIBLE
BOARD CN4303
CN4402 CN4401
FR-1008 BOARD
5, 6 3, 4
7, 8
3
2
XTALLY_LED
SIRCS_SIG 12
14
5
1, 2
LENS TEMP
SENSOR
IRIS
DRIVE
ND
DRIVE
FOCUS
DRIVE
ZOOM
DRIVE
XTALLY_LED
SIRCS_SIG
VST_C_CHARGE
8
6
15
F4901
XSYSAD_SEL_2
SYSTEM_AD
SYSTEM
AD
Q4901, Q4902 SYSAD_SEL_1
CPU, CAMERA DSP,
AV SIGNAL PROCESS,
LENS CONTROL,
MODE CONTROL,
HDMI PROCESS
(6/19 - 13/19)
IC6000
(3/3)

4-5
HDR-PJ800/PJ810/PJ810E/PJ820/PJ820E_L3
4-5. POWER BLOCK DIAGRAM (1/3) ( ) : Number in parenthesis ( ) indicates the division number of schematic diagram where the component is located.
DC/DC CONVERTER
(1/19)
IC5100
USB POWER
MANAGEMENT
(3/19)
IC5651
POWER CONTROL
(2/19)
IC5700
DC/DC CONVERTER,
LANC DRIVER
(1/19)
IC5200
PVDD1A
CORE_UNREG,
IO_UNREG
MT_UNREG,
XC_UNREG
SHOE_UNREG_FUSE SHOE_UNREG_FUSE
XC_UNREG
D_1.0V
E1
PVDD1B
E2
D1LX1A
D2LX1B
D3FB1
L0101
PVDD3A D_1.8V, A_1.8V A1
PVDD3B
B1
A2LX3A
B2LX3B
B2LDO1_FB
C4FB3
L0103
PVDD5A D_3.3V, A_3.3V H5
PVDD5B
G5
H4LX5A
G4LX5B
E3FB5
L0105
PVDD6A MT_5.0V, J_5.0V D8
PVDD6B
D7
E8LX6A
E7LX6B
D5FB6
L0106
PVDD2 D_1.2V
HB_1.2V
C8 B8LX2
C5FB2
A5LDO1_OUT
L0102
LDO1_ENB
LDO1_ON D6
DD_ON1
DD_ON1
DD_ON1
SYS_BGL_SDA
SYS_BGL_SCL
F5
LDO2_ENBE5
A6LDO1_SOURCE
B1PVDD_LDO1
B4LDO2_SOURCE
D_1.2V
HB_1.8V
A4LDO2_OUT
C9P5F
E2P2C
G10 P53
G11 P10/AN00
H10 P50/SIN3
H9P51/SOT3
H8P52/SCK3
C10 P17/AN07
F3P33/INT11
E4P2A/INT06
H4P44
B11 VCC_B11
C4P0F/NMIX/WKUP0
L7INITX
A_1.0V_IC_5200
A_1.0V_IC_5200
D_3.3V
D_3.3V
A1LDO1_OUT
C1 LDO1_ON
BATT
E1
ACVGE3
PVDD_CPH2
AVDD
B7
CSG6
DOUT
E6
DINF6
CLK
SYS_DD_SI
SYS_DD_IC_5100_XCS
CSE3
XPANEL_POWER_ON XPANEL_POWER_ON
08
E8P5B/INT26 XPWR_OFF
SYS_DD_SO
SYS_DD_SCK
D1SYS1
UNREG_IC_5651_OUT
D2SYS2
A2SW100
B6PVBUS
C3SUS
G7
DIND3
CLK
SYS_DD_SO
SYS_DD_SCK
SYS_DD_IC_5200_XCS D4
VTR_UNREGE6
UNREG_IN_DET
F2
A4 PVDD_LDO2 HDMI_5V A3LDO2_OUT
B6LOAD_IN
D7P08
XLANC_PWR_ONC4
XLANC_PWR_ON
K1P3F/INT15
A5 LDO2_ON
D6 LANC_DC
D2 DD_ON
SYS_UNREGIN E4 UNREG_IN
K5P60/INT16 USB_SUSREQ_KJR USB_SUSREQ_KJR
XPWR_OFF
VUC
C1VCC_C1
J11 VCC_J11
L2VCC_L2
F5 VUC
XRST_DWN E5 VUC_RST
MSX_3.3V
MXS_3.3V
A6LOAD_OUT
EVER_3V
EVER_3V
EVER_3V
VBUS_5V
VBUS_5V
VBUS_5V
VBUS_5V
USB_SUSREQ_KJR
F6 EVER3
F4VCH
MS_PWR_ON
LDO_3.3V_OUTMT_5.0V
D_1.8V, A_1.8V
BATT_LI_3V
B5LOAD_ON
B+
SWITCH
Q5700, Q5701
BATTGE2
B+
SWITCH
Q0300
DC JACK
DETECT
Q0202
5
6
4
2
3
1
BATT_IB
BATT/XEXT
BATT/XEXT
BATT_IB
VC-1022 BOARD (1/3)
BATT_UNREG
UNREG_IC_1101_IN
CN4007
1
6
15
1
CN0400
CN0500
ACVE4
ACV_UNREG
ACV_UNREG
VBUS1A5
USB_VBUS_STD USB_VBUS_ARM
D_2.8V/LANC_DC
D_3.3V
D_3.3V
LANC_DC
D_3.3V
LANC_DC
XPOWER_TACT_SW
XPOWER_TACT_SW
USB_VBUS_MULTI
VBUS2B5
SDAC6
LANC/UART SELECT
(5/19)
IC5640
SCLD6
P24/INT00/WKUP1
C2
P30/INT08
E1
42D-
21D-
D-
7
SIO2
J5
P63/INT19
K8
P58/SCK1
F8
F0400
F0300
F0302
F0301
P57/SOT1F9
USB_5601_EN
SYS_BGL_SDA
SYS_BGL_SCL
USB_5601_EN
SYS_BATTSENSE
F11 P11/AN01
SYS_ACVSENSE
DD_ON
D3
MULTI
STROBE SWITCH
(14/19)
IC3001
HDMI
RECEIVER
(16/19)
IC8200
19
HDMI_5V
CN9000
HDMI OUT
19
HDMI_5V_RX
CN3301
PROJECTOR
IN
8 - 11
17
13
16
FP-2105 FLEXIBLE
BOARD
CN3001 CN2102
LOGIC_VDD
SHOE_UNREG
MULTI
INTERFACE
SHOE
B+ SWITCH UNREG_SHOE
SHOE_UNREG_ON
LOGIC_VDD
ST_VCC_ON
Q8800, Q8801
B+ SWITCH
Q8830
D_3.3V
D_3.3V
CN4005
6
EVER_3VEVER_3V 3
CONTROL
SWITCH BLOCK
(PS42300)
POWER (2/3)
(PAGE 4-6)
A
POWER (2/3)
(PAGE 4-6)
E
POWER (2/3)
(PAGE 4-6)
D
FB0301
BATTERY
TERMINAL
S
DC IN
J901
(DC JACK)
7, 12
3.3V REG
(16/19)
IC8201
VDD
4
CE
1
3VOUT
XC_UNREG
D_1.2V
MT_5.0V, J_5.0V
D_3.3V, A_3.3V
D_1.8V, A_1.8V
MSX_3.3V
EVER_3V
A_1.0V_IC_5200
HB_1.8V
HB_1.2V
D_1.0V
VBUS_5V
POWER (2/3)
(PAGE 4-6)
B
LDO_3.3V_OUT
D_3.3V
D_1.8V, A_1.8V
D_1.2V
MT_5.0V
POWER (3/3)
(PAGE 4-7)
C
BUILT-IN
USB CABLE
CHARGE

4-6
HDR-PJ800/PJ810/PJ810E/PJ820/PJ820E_L3
4-6. POWER BLOCK DIAGRAM (2/3) ( ) : Number in parenthesis ( ) indicates the division number of schematic diagram where the component is located.
IC6801
LENS BARRIER
DRIVE
(1/5)
IC6742
PITCH/YAW DRIVE
(1/5)
IC6741
PITCH/YAW
SENSOR
(4/5)
SE7701
IC6800
2.8V REG
(2/5)
IC6802
CN6801
CN101
CN102
43
48, 49 35 - 3842 - 4950, 51
LD-1014 BOARD
RH-1003 BOARD
VDD
F_MR_VCC F_MR_VCC
4
CE
1
3VOUT
ENA
C3
19
PITCH_BIAS+
18
CN7100
19
12
YAW_BIAS+
PITCH_BIAS+
YAW_BIAS+
24
19
5
13
28
CN4301
CN4102
8 - 17
CN4202
CN4203
CN4201
CN4101
CN4303CN4103
2
13
4
Z_PI_A
Z_PI_A
XZM_RST_LED
XZM_RST_LED
MR_A_2.8V
7.0V REG
(1/5)
IC5150
IN
2
EN
3
9VOUT
ROLL SENSOR
AMP
(1/2)
LENS
BLOCK
IC7711
2.5V REG
(4/4)
IC4201
VDD
4
CE
1
3VOUT
LED DRIVER
(1/4)
IC5800
AUDIO
PROCESSOR
(3/4)
IC8500
CLOCK
GENERATOR
(6/19)
IC6001
EVF PULL OUT
DETECT
(4/4)
SE4201
SW_C1
C1
SW_C2
C2
HC_SEL
B3
TX-MASK
C3
A2VOUT
2.8V REG
(3/4)
IC8501
VDD
4
CE
1
3VOUT
VBUS
DETECT
BUS POWER SWITCH
(5/19)
IC5630
EN 3
X_FAULT 4
1IN
K4 SD1_O1
A_3.3V
XC_UNREG
D_1.2V
MT_5.0V
D_3.3V
D_3.3V
EVER_3.0V
D_3.3V
D_1.8V
22
1
SD_VCC
MSX_3.3V
SD_VCC
J_5.0VJ_5.0V
VDD
MSX_3.3V
VOUT_LED_A
D_3.3V
A_1.8V
CPU, CAMERA DSP,
AV SIGNAL PROCESS,
LENS CONTROL,
MODE CONTROL,
HDMI PROCESS
(6/19 - 13/19)
IC6000
D_1.8V
EVER_3.0V
BATT_LI_3V
XPOWER_TACT_SW
D2101
(ACCESS)
MR_A_2.8V
D_3.3V
EVER_3.0VEVER_3.0V
MR_A_2.8V
LED DRIVE
Q6801
MEMORY
STICK
PRO DUO
SD
XCON_7.0V_OUT
XIC_6801_RST
XIC_6801_RSTXIC_6801_RST
ROLL SENSOR
(1/2)
SE7711
19
7
16
44
2
8
4
3
4
7
1D_3.3V 8
FP-2099
FLEXIBLE
BOARD
OC-1003 BOARD
PANEL
OPEN/CLOSE
DETECT
(2/2)
RM4301
Q4101
1
PANEL_O/C_GMR
XPANEL_POWER_ON
XPANEL_POWER_ON
3, 4 14 - 173 - 101, 2
FP-2186
FLEXIBLE
BOARD (A)
FP-2186
FLEXIBLE
BOARD (B)
CN4001
8
50
44
48
49
48
53 - 56
5
3
8
28
30
FP-2187
FLEXIBLE
BOARD
CN4003
6 - 9
57
59
54
34
32
45
20
FR-1008 BOARDFP-2102
FLEXIBLE
BOARD
FP-2104
FLEXIBLE
BOARD
CN4401
REMOTE
SENSOR
IC4401
D4401
(RECORDING)
D0001, D0002
CN4002
XZM_RST_LED
A_3.3V
XC_UNREG
XC_UNREG
D_1.2V
D_1.2V
MT_5.0V
MT_5.0V, J_5.0V
D_3.3V
D_3.3V, A_3.3V
D_1.8V
D_1.8V, A_1.8V
D_1.8V,
A_1.8V
SD_3.3V
SD_3.3V
MSX_3.3V
MSX_3.3V
EVER_3V
EVER_3V
XPANEL_POWER_ON
XPANEL_POWER_ON
2230
AVINE4
VIDEO LIGHT
COLOR EVF
UNIT
LCD902
L5800
BT4201
LITHIUM
BATTERY S4201
POWER
J_5.0V
D_3.3V
D_1.8V
EVER_3V
BATT_LI_3VBATT_LI_3V
XPOWER_TACT_SW XPOWER_TACT_SW
A_1.8V
A_1.0V_IC_5200
A_1.0V_IC_5200
D_3.3V
A_3.3V
MSX_3.3V
PAD_PROJ_ON
L18 GPIO_S_11
XPWR_OFF
L20 GPIO_S_6
MS_PWR_ON
W25 USB_CHG_HL
USB_SUSREQ_KJR
M19 GPIO_S_5
SD_PWR_ON
M20 GPIO_S_4
MMC_PWR_ON
M10 ND_DIR_A
ST_VCC_ON
L7 IRIS1
SHOE_UNREG_ON
AA23 VBUS_EN
VBUS_EN
J_5.0V VOUT 6
W22 USB_OCI
V11 SA_TDI
E20 FRC_RTG_OUT0
VBUS_XOVR_CUR
L17 GPIO_S_13
XVBUS_DET_MULTI
VCC_MMC
WLAN_VOUT_3.3V
D_1.2V
HB_1.2V
HB_1.8V
D_1.0V
HB_1.8V
HB_1.2V
D_1.0V
L6021
FB1062
Q5600
D5600
E19 GPIO_SB_1
XVBUS_DET_STD_AVBUS_5V
VBUS_5V
Y23 USB_VBUS
XVBUS_DET
USB_VBUS_MULTI
POWER (1/3)
(PAGE 4-5) E
POWER (3/3)
(PAGE 4-7) F
POWER (1/3)
(PAGE 4-5) D
POWER (1/3)
(PAGE 4-5) A
VC-1022 BOARD (2/3)
B+ SWITCH
(1/19)
IC5500
EN 3
1
08
VIN
D_3.3V VOUT 5
POWER (1/3)
(PAGE 4-5)
B
XCLRC7
STEADYSHOT
PROCESSOR,
FOCUS/ZOOM
MOTOR DRIVE
(2/5)
IRIS/ND
MOTOR DRIVE
(2/5)
LF-2026
FLEXIBLE
BOARD
CN202
CN201
5
2
LF-2025
FLEXIBLE
BOARD
PJ810/PJ810E/PJ820/PJ820E

HDR-PJ800/PJ810/PJ810E/PJ820/PJ820E_L3
4-7E
4-7. POWER BLOCK DIAGRAM (3/3) ( ) : Number in parenthesis ( ) indicates the division number of schematic diagram where the component is located.
PROJECTOR
UNIT
34
30
28
10
14
38, 39
9, 11
36
34
VDDI2
CN4901
26
1,3,28,30,
32,38 - 40
4,6,8
34, 38
3,5,7,9,11
10
4,6,8 1 - 3 4 - 63,5,7,9,11
VDDI, VDD
VRST
VBIAS
VOFS
P1P8V
P1P8V
P3P3V
FP-2178
FLEXIBLE
BOARD
LF-2063
FLEXIBLE
BOARD
CM-1007 BOARD
FP-2180
FLEXIBLE
BOARD
PJ-1008 BOARD
PD-1027 BOARD
LED DRIVE
(3/3)
IC2701
DMD CONTROL
(2/3)
IC2603
FLASH
MEMORY
(2/3)
IC2602
CMOS
IMAGER
IC1001
LS_IN
F6
VINAD7
VINR
A4
VINL_A1
A1
VINL_A2
A2
VINC
H6
A_1.8V
CN2501CN4505 CN2503
PJ_SYSPWR
PROJ_ON
PROJ_ON
F7LS_OUT
D3VSPI P1P1V
H7SWC
G6VCORE
B5CNTR_VRST DMD_VRST
B7VBIAS DMD_VBIAS
C7VOFS DMD_VOFS
A5SWN
A7SWP
L2702
L2701 D2701
PROJ_ONE5
A_1.8V
A_1.8V
MT_5.0V
PAD_PROJ_ON
PAD_PROJ_ON
CN1001CN4004
D_1.2V_IMG
39
D_1.8V_IMG
D_3.3V_IMG
34, 38
36, 37 36, 37
39
D_1.2V
D_1.8V
D_3.3V A_2.8V_IMG
33
5
CN8040
CN8041
A_1.8V
GPIO_08 G14
3.3V REG
(2/3)
IC2601
VDD
4
CE 1
3VOUT
DC/DC CONVERTER
(1/4)
IC5300
F061
VIN
6
VFB 3
5VOUT
4CE
LCD SERIAL
INTERFACE
RECEIVER
(3/4)
IC8010
LCD SERIAL
INTERFACE
TRANSMITTER
(17/19)
IC8000
VIDEO
SELECTOR
(17/19)
IC8120
3 AXIAL
ACCELERATION
SENSOR
(2/4)
SE7731
D_3.3V
PANEL
NORMAL/REVERSE
DETECT
(4/4)
SE4501
D_3.3V
MT_5.0V
LCD_PWM
LX1
L5300
3.0 INCH
WIDE COLOR
LCD
LCD901
(LCD MODULE)
BACKLIGHT
48
D_3.3V
A_1.8V
D_3.3V
CN4501
BL_L
BL_H
23, 243-8, 18, 19 20,21,26-28
33
PAD_PROJ_ON
PAD_PROJ_ON
MT_5.0V
A_1.8V
A_1.8V
D_3.3V
D_3.3V
D_1.8V
D_1.2V
CN4901
28, 2933,34,44-49 24-26,31,32
19
2.8V REG
IC1002
VDD
4
CE
1
3VOUT
L1001
FB1001
17, 18
FP-2188
FLEXIBLE
BOARD
MM-102 BOARD
CN8101CN4006
15
MEDIA_3.3V
16
TE1_VCC
MMC_PWR_ON1
D_3.3V
VCC_MMC
MMC_PWR_ON
VCC_MMC
MMC_PWR_ON
2.9V REG
(1/2)
IC8701
VDD
4
CE1
3VOUT
INTERNAL MEMORY
(1/2)
IC8101
INTERNAL MEMORY
(2/2)
IC8201
PJ800/PJ820/PJ820E
1, 2
4
3
FP-2181
FLEXIBLE
BOARD
WF-1004 BOARD
WIRELESS LAN
MODULE
CP7300
CN2301CN4902
7
6
8
EVER_3V
VCC_WLAN_L
WLAN_VCC_H
NFC
INTERFACE
IC7401
BUFFER
(19/19)
IC4901
BUFFER
CONTTOL
(19/19)
IC4902
9WLAN_VCC_H_OUT
D_3.3V
D_1.8V
LDO_3.3V_OUT
LDO_3.3V_OUT
WLAN_VOUT_3.3V
WLAN_VOUT_3.3V
18
08
19
18
16
USB SELECT
(4/19)
IC5600
MT_5.0V
AUDIO DSP
(15/19)
IC8630
D_3.3V
D_1.8V, A_1.8V
D_1.2V
MT_5.0V
VC-1022 BOARD (3/3)
POWER (1/3)
(PAGE 4-5)
C
POWER (2/3)
(PAGE 4-6)
F

5-1
HDR-PJ800/PJ810/PJ810E/PJ820/PJ820E_L3
5. FRAME SCHEMATIC DIAGRAMS
5-1. FRAME SCHEMATIC DIAGRAM (1/2)
1
19
1
19
123
151
OC-1003 BOARD
1
81
8
FR-1008 BOARD
LENS
BARRIER
UNIT
LENS BLOCK
M902
(YAW)
M901
(PITCH)
1
238
39
1
39
40 41
112
13 14
1
6
7
8
15
67
124
25 26
615
16
17 18
19
15
1
228
29 30
31
2
1
6263
60
61
CN4004
CN4005
CN4007
CN0400
CN4902
CN0500
CN3001
CN4003
118
1920
1
2
19
18
20
21
2223
24
25
2
1
50
51
52 53
1
2
19
18
20
21
2223
24
25
2
1
50
51
51
51
51
51
5253
2
1
50
51
52
53
CN4006
CN3301
CN4901
CN9000
CN4001
CN4002
1
1
23 38
39
39
40 41
CN1001
1
1
18
1
18
18
CN8101
2
1
50
51
52 53
2
1
50
51
52 53
120
22 21
CN4101CN4102
SE7701
(PITCH/YAW)
CN4103
129 26 30
2728
CN6801
CN7100
CN2102
22
121 2324
1
1
1
1
1
29
1
218
19
2120
1
2
5
6
1
2
7
8
CN4302
CN4301
CN4303
1
2
7
82
4
1
3
CN4401
CN4402
BUILT-IN
USB CABLE
CN201
18
CN202
1
8
1
2
50
51
1
23
CN101
CN102
VC-1022 BOARD
(SIDE A) VC-1022 BOARD
(SIDE B)
CM-1007 BOARD (SIDE A) CM-1007 BOARD (SIDE B)
LF-2063 FLEXIBLE BOARD
MULTI
INTERFACE
SHOE
MM-102 BOARD
FP-2188
FLEXIBLE BOARD
LD-1014 BOARD (SIDE A)LD-1014 BOARD (SIDE B)
FP-2105 FLEXIBLE BOARD
FP-2186 FLEXIBLE BOARD (A)
FP-2186 FLEXIBLE BOARD (B)
DC IN
MULTI
BATTERY
TERMINAL
J901
DC JACK
CONTROL
SWITCH
BLOCK
(PS42300)
CHARGE
IC8120
(Not supplied)
IC1001
(Not supplied)
IC6000
(Not supplied)
IC5100
(Not supplied)
IC5500
(Not supplied)
IC5700
(Not supplied)
IC8000
(Not supplied)
IC5651
(Not supplied) IC3001
(Not supplied)
HDMI
OUT
PROJECTOR
IN
FP-2099 FLEXIBLE BOARD
LF-2025
FLEXIBLE
BOARD
LF-2026
FLEXIBLE
BOARD
MM
MM
CONTROL
SWITCH
BLOCK
(RS42300)
FP-2102 FLEXIBLE BOARD
FP-2187
FLEXIBLE
BOARD
(Page 5-2)
A
FP-2181
FLEXIBLE
BOARD
(Page 5-2)
C
FP-2180
FLEXIBLE
BOARD
(Page 5-2)
B

HDR-PJ800/PJ810/PJ810E/PJ820/PJ820E_L3
5-2E
5-2. FRAME SCHEMATIC DIAGRAM (2/2)
PJ-1008 BOARD
(SIDE A) PJ-1008 BOARD (SIDE B)
WF-1004 BOARD
(SIDE A)
WF-1004 BOARD
(SIDE B)
PD-1027 BOARD
FP-2104 FLEXIBLE BOARD
FP-2187 FLEXIBLE BOARD
FP-2180
FLEXIBLE
BOARD
RH-1003 BOARD
(SIDE A) RH-1003 BOARD (SIDE B)
FP-2178 FLEXIBLE BOARD
FP-2181 FLEXIBLE BOARD
AN-1006 FLEXIBLE BOARD
2
1
50
51
52 53
21
43
1
2
59
60
1
260
61
1 76
81
76
8
CN4501
CN4503
CN4505
CN4506
CN8040 CN8041
110
11 12
1
238
39
40 41
18
910
CN2502
CN2503
CN2601
1
2
59
60
CN2501
124
25 26
CN2301
13
24
CN2302
1
1
1
1
1
124
24
51
1
51
61
61
22
1
2
39
40
41
42
1
39
43
44
CN4901
D0001, D0002
VIDEO LIGHT
VC-1022
BOARD
(SIDE A)
(Page 5-1)
A
VC-1022
BOARD
(SIDE A)
(Page 5-1)
C
VC-1022
BOARD
(SIDE B)
(Page 5-1)
B
SP901
(SPEAKER)
IC8010
(Not supplied)
LCD901
(LCD MODULE)
3.0 INCH
WIDE COLOR
LCD
TOUCH
PANEL
BACKLIGHT
IC2603
(Not supplied)
IC2602
(Not supplied)
(NC)
PROJECTOR
UNIT
ANT901
(NFC ANTENNA)
IC4201
(Not supplied)
IC8501
(Not supplied)
CN4201
1
260
61
122
2324
CN4202
J3401
J3402
122
2324
CN4203
PLUG IN
POWER
LITHIUM
BATTERY
BT4201 (HEADPHONE)
S4201
S4203
S4204
S4205
S4206
MY VOICE
CANCELING
16
78
CN4204
COLOR EVF
UNIT
LCD902
PROJECTOR
LIGHT
POWER
MIC901
(MICROPHONE UNIT)
S4202
(MODE)
PJ810/PJ810E/PJ820/PJ820E
ET2301
WIRELESS LAN
ANTENNA

6-1
HDR-PJ800/PJ810/PJ810E/PJ820/PJ820E_L3
6. SCHEMATIC DIAGRAMS AND PRINTED WIRING BOARDS
– ENGLISH – – JAPANESE –
Precautions for Replacement of Imager
• If the imager has been replaced, carry out all the adjustments
for the camera section.
• As the imager may be damaged by static electricity from its
structure, handle it carefully like for the MOS IC.
In addition, ensure that the receiver is not covered with dusts
nor exposed to strong light.
イメージャ交換時の注意
・ イメージャを交換した場合は，カメラ部の全調整を行って
ください。
・ イメージャは構造上，静電気により破壊される恐れがある
ため，MOSICと同様に注意して取り扱ってください。
 また，受光部にはゴミの付着，および強い光がはいること
のないように注意してください。
The components identified by mark 0
or dotted line with mark 0are critical
for safety.
Replace only with part number specified.
Les composants identifiés par une mar-
que 0sont critiques pour la sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
When indicating parts by reference num-
ber, please include the board name.
0印の部品，または0印付の点線で囲まれた部品は，
安全性を維持するために，重要な部品です。
従って交換時は，必ず指定の部品を使用してください。
図面番号で部品を指定するときは基板名又はブロック
を併せて指定してください。
お願い
THIS NOTE IS COMMON FOR SCHEMATIC DIAGRAMS AND PRINTED WIRING BOARDS
(In addition to this, the necessary note is printed in each block)
回路図，プリント図共通ノート
（他に必要なノートは各セクションに記載しています）
For Schematic Diagrams
• All capacitors are in μF unless otherwise noted. pF :
μF. 50 V or less are not indicated except for electrolytics
and tantalums.
• Chip resistors are 1/10 W unless otherwise noted.
kΩ=1000 Ω, MΩ=1000 kΩ.
• Caution when replacing chip parts.
New parts must be attached after removal of chip.
Be careful not to heat the minus side of tantalum capacitor,
Because it is damaged by the heat.
• Some chip part will be indicated as follows.
Example C541 L452
22U 10UH
TA A 2520
Kinds of capacitor External dimensions (mm)
Case size
• Constants of resistors, capacitors, ICs and etc with XX
indicate that they are not used.
In such cases, the unused circuits may be indicated.
• Parts with differ according to the model/destination.
Refer to the mount table for each function.
• All variable and adjustable resistors have characteristic curve
B, unless otherwise noted.
• Signal name
XEDIT →EDIT PB/XREC →PB/REC
•: non flammable resistor
• : fusible resistor
• : panel designation
• : B+ Line
• : B– Line
• : IN/OUT direction of (+, –) B LINE.
• : adjustment for repair.
For Printed Wiring Boards
• : Uses unleaded solder.
•: Circuit board
: Flexible board
Pattern from the side which enables seeing.
: pattern of the rear side
(The other layers’ patterns are not indicated)
• Through hole is omitted.
• There are a few cases that the part printed on diagram isn’t
mounted in this model.
• : panel designation
• Chip parts.
Transistor Diode
21
3
21
3
21
3
345
21
123
654
EB
C
31
5
2
46
123
654
31
5
2
46
123
54
43
12
312
45
534
12
14
23
46
2
5
31
12
43
14
23
回路図ノート
・ ケミコン，タンタルを除くコンデンサで，耐圧50V以下の
ものはその耐圧を省略。単位はすべてμF（pはpF）。
・ チップ抵抗で指示のないものは，1/10W以下。
 kΩ＝1000Ω，MΩ＝1000kΩ
・ チップ部品交換時の注意
 取り外した部品は再使用せず，未使用の部品をご使用く
ださい。
 タンタルコンデンサのマイナス側は熱に弱いため注意し
てください。
・ チップ部品には下記のように表示したものがあります。
 例 C541 L452
  22U 10UH
  TA A 2520
  種類 外形寸法（mm）
  ケースサイズ
・ 抵抗，コンデンサ，ICなど定数にXXがあるものは，使用
していない事を示しています。このため，使用していな
い回路が記載されている事があります。
・ ★印のある部品は，機種などにより異なりますので機能
別マウント一覧表を参照してください。
・ 可変抵抗と半固定抵抗で，B特性の表示を省略。
・ 信号名表記について，下記のような場合があります。
 XEDIT → EDIT PB/XREC → PB/REC
・ は不燃性抵抗。
・ はヒューズ抵抗。
・ はパネル表示名称。
・ はB＋ライン。
・ はB−ライン。
・ はBライン（＋，−）の入出力方向を示す。
・ は調整名称。
プリント図ノート
・ ：無鉛半田を使用しています。
・ ：基板
 ：フレキシブル配線板
 見ている面側のパターン。
 ：裏側のパターン
 （他のパターンについては表示されていません）
・ スルーホールは省略。
・ プリント図には，本機で使用していない部品が記載され
ている場合があります。
・ はパネル表示名称。
• Chipparts.
 Transistor Diode
21
3
21
3
21
3
345
21
123
654
EB
C
31
5
2
46
123
654
31
5
2
46
123
54
43
12
312
45
534
12
14
23
46
2
5
31
12
43
14
23
印の部品には、秘密情報が含まれています。
修理の際は、指示に従った対応を行ってください。
交換後の対象基板及び対象ICは、破壊のうえ廃棄してください。
The components identified by mark contain confidential informa-
tion.
Strictly follow the instructions whenever the components are re-
paired and/or replaced.
Destroy and discard the prescribed board and IC after they are
replaced.
Les composants identifiés par le symbole contiennent des infor-
mations confidentielles.
Suivez scrupuleusement les instructions chaque fois qu'un com-
posant est remplacé et / ou réparé.
Veuillez détruire et éliminer les circuits imprimés et / ou les circuits
intégrés que vous avez remplacés.
标识有 的元件包含机密信息。
更换或维修元件时，请严格遵守指⽰。
更换后的电路板和IC，应予以报废。

6-2
HDR-PJ800/PJ810/PJ810E/PJ820/PJ820E_L3
6-1. SCHEMATIC DIAGRAMS
LF-2063
FLEXIBLE
LND002
(PAGE 6-28)
XHS XVS
XCLR
XVS
XHS
XCLR
Note: All mounted parts are not supplied,
but they are included in CM-1007 COMPLETE BOARD.
123456789
A
B
C
D
E
F
A
B
C
D
E
F
08
CM-1007 BOARD
CMOS IMAGER
XX MARK: NO MOUNT
C1020 XX C1018 XX
INCK
JC1008 XX
JC1007 XX
JC1006 XX
JC1001 XX
JC1005 XX
JC1002 XX
JC1004 XX
JC1003 XX
L1003
XX
34
12
L1005
XX
34
12
L1002
XX
34
12
L1004
XX
34
12
R1010 XX
R1004
XX
R1005
XX
R1006
XX
R1007
XX
R1012
XX
R1008
XX
R1002
XX
R1003 XX
C1026
0.47u
C1024
0.47u
C1022 1u
C1025 0.1u
C1023 0.1u C1019 1u C1017 0.1u C1013 0.1u C1011 1u C1010 4.7u C1009 1u C1008 2.2u
C1016 4.7u C1015 4.7u
C1028
0.1u
C1027 0.1u
C1004
1u
C1012 0.1u
C1006
0.001u
C1001
4.7u
C1002
4.7u
C1014 0.001u
C1007
0.1u
C1005
0.001u
C1003
0.1u
C1021 0.1u
CL1003
CL1002
CL1001
CL1005
CL1004
CN1001 39P
1GND
2GND
3INCK
4GND
5GND
6SIGN10170
7GND
8XCE
9SIGN10160
10 GND
11 SDI
12 SDO
13 XHS
14 XVS
15 GND
16 GND
17 GND
18 SIGN10121
19
20 SIGN10122
21 GND
22 SIGN10144
23
24 SIGN10143
25 GND
26 SIGN10146
27
28 SIGN10145
29 GND
30 SIGN10148
31
32 SIGN10147
33 GND
34 D_1.2V_IMG
35 GND
36 GND
37 D_1.8V_IMG
38 D_1.2V_IMG
39 D_3.3V_IMG
DOP3
DOM1
DOM3
DOP1
DOP2
DOM2
D_1.2V_IMG
D_1.8V_IMG
A_2.8V_IMG
D_3.3V_IMG
SCK
SDI
XCE
DOP0
DOM0
SDO
D_1.8V_IMG
DOM1
DOM0
DOM3
DOP1
DOP0
DOP3
DOM2
SDI
XCE
SDO
SCK
D_3.3V_IMG
D_1.2V_IMG
INCK
D_1.8V_IMG
A_2.8V_IMG
DOP2
GND
GND
GND
L1001
10uH
IC1001
IMX186CHL-13
CMOS IMAGER
A1 NC2 A2 NC_A2 A3 NC_A3 A4 VRLT A5 VDDHCM_A5 A6 VDDHPX A7 VDDHDA A8 VDDSUB A9 VDDHCM_A9
A10 NC_A10 A11 NC6
B1 NC_B1 B2 NC_B2 B3 NC_B3 B4 VRLS B5 VSSHPX B6 VLOADLM B7 VSSHDA B8 TAMON2 B9 NC_B9
B10 NC_B10 B11 NC_B11
C1 VDDHCP C2 VSSHCP C3 XCLR C4 VSSLCB_C4
C5
NC_C5
C6
VBGR
C7
BIASRES
C8
TAMON1
C9
VSSLCB_C9
C10
NC_C10
C11
NC_C11
D1
NC_D1
D2
NC_D2
D3
XCE
D9
NC_D9
D10
NC_D10
D11
NC_D11
E1
TENABLE
E2
NC_E2
E3
SDO
E9
NC_E9
E10
NC_E10
E11
NC_E11
F1
TSCANEN
F2
NC_F2
F3
SCK
F9
NC_F9
F10
NC_F10
F11
NC_F11
G1
VDDMO
G2
TOUT
G3
SDI
G9
NC_G9
G10
NC_G10
G11
NC_G11
H1
VSSLSC_H1
H2
VDDLSC_H2
H3
XHS
H9
NC_H9
H10
VSSLSC_H10
H11
VDDLSC_H11
J1
VSSLCN_J1
J2
VDDLCN_J2
J3
XVS
J9
NC_J9
J10
VSSLCN_J10
J11
VDDLCN_J11
K1
INCK
K2
VSSLPL1
K3
VDDLPL1
K4
VSSLIF_K4
K5
NC_K5
K6
NC_K6
K7
NC_K7
K8
NC_K8
K9
VSSLIF_K9
K10 NC_K10
K11 NC_K11
L1 NC_L1
L2 NC_L2
L3 VDDLPL2
L4 NC_L4
L5 DOM0
L6 DOM1
L7 DOM2
L8 DOM3
L9 VDDLIF
L10 NC_L10
L11 NC_L11
M1 NC1
M2 NC_M2
M3 VSSLPL2
M4 VSSLIF_M4
M5 DOP0
M6 DOP1
M7 DOP2
M8 DOP3
M9 VSSLIF_M9
M10 NC_M10
M11 NC3
R1013
1k
R1001
22
IC1002
MM3416A28URE
1
CE
2
GND
3
VOUT
4
VDD
X1001
72MHz
1STANDBY 2
GND
3
OUT
4VDD
COM002
COM003
COM004
COM005
COM008
COM009
COM010 COM011
COM012
COM013
COM014
COM015
COM016
COM017
COM018
COM019
COM020
C1030
2.2u
C1031 2.2u
FB1001
0uH
C1032
4.7u
C1029
0.01u
2.8V REG

6-3
HDR-PJ800/PJ810/PJ810E/PJ820/PJ820E_L3
XRST_DWN
Note: C5102, C5207, IC5100, IC5500, R5100 and R5201 are not supplied,
but they are included in VC-1022 COMPLETE BOARD (SERVICE).
123456789
A
B
C
D
E
F
A
B
C
D
E
F
08
VC-1022 BOARD (1/19)
DC/DC CONVERTER
XX MARK: NO MOUNT
R5103 XX
R5102 XX
R5101
XX
R5104 XX
C5500
0.1u
C5501
1u
GND
VOUT
EN
VIN
R5500
10k
IC5500
BD2224G-BZTR
B+ SWITCH
1
VIN
2
GND
3
EN OC
4
VOUT
5
C5104 1u
C5112
2.2u
C5114
2.2u
C5101 0.1u
C5105 1u
C5100 1u
C5102 0.01u
C5106 1u
C5117 10u
C5110
2.2u
C5109 2.2u
C5111
2.2u
C5107
0.1u
C5103 1u
C5120
10u
C5116 22u
C5118
10u
C5108 2.2u
JL5100
CL5102
CL5101
CM0516
CM0517
CM0515
CM0514
CM0519
CM0513
CM0512
CM0518
CM5101
CM5102 CM5103
CM5100
CH1_OUT
LDO2_OUT
CH5_OUT
CH2_OUT
FB6
LDO1_ENB
LDO1_OUT
CS
CLK
DIN
DOUT
LDO1_SOURCE
LDO2_SOURCE
LX6
LX5
LX4
LX3
LX2
LX1
VO_SEL
REG_GND
DD_ON
FB4
PGND4
PGND6
PVDD4
SLOPE1
PVDD1/2/3
PVDD5/CP/AVDD
VREG5.0V
CH3_OUT
PVDD6
LDO2_ENB
CP_OUT
R5100 47k
IC5100
BD8336GU-E2
TEST1
H1
TEST2
H8
TEST3
A8
DD_ON
F5
ROSC
B5
CS
G6
CLK
G7
DIN
F6
DOUT
E6
PVDD_CP
H2
CP_OUT
G2
CFP
G1
CFN
F1
PGND_CP
F2
LDO1_ENB
D6
LDO1_OUT
A5
LDO1_SOURCE
A6
LDO2_ENB
E5
LDO2_OUT
A4
LDO2_SOURCE
B4
PGND6B F7
PGND6A F8
LX6B E7
LX6A E8
PVDD6B D7
PVDD6A D8
PGND5B G3
PGND5A H3
LX5B G4
LX5A H4
PVDD5B G5
PVDD5A H5
PGND4 G8
LX4 H7
PVDD4 H6
PGND3B B3
PGND3A A3
LX3B B2
LX3A A2
PVDD3B B1
PVDD3A A1
PGND2 A7
LX2 B8
PVDD2 C8
SLOPE1 C3
PGND1B C2
PGND1A C1
LX1B D2
LX1A D1
PVDD1B E2
PVDD1A E1
FB1 D3 FB2 C5 FB3 C4 FB4 E4 FB5 E3 FB6 D5
VO_SEL F4
AGND B6
VREG5.0V F3 VREG3.0V C7
VREF_BG C6
AVDD B7
R5203
XX
D0101
XX
R0100
XX
IC5200
BD8331GU-E2
DC/DC CONVERTER, LANC DRIVER
CS
E3
CLK
D4
DIN
D3
DD_ON
D2
ACV_UNREG
F1
BATT_UNREG
E1
VTR_UNREG
E6
ACV_ON
E2
BATT_ON
D1
AGND_COMMON
F3
LANC_DC
D6
DATA_IN
B4
DATA_OUT
D5
LANC_SIG
C5
XLANC_PWR_ON
C4
XLANC_ON
C2
AGND_LANC
C6
UNREG_IN_DET
F2
UNREG_IN
E4
VUC
F5
VUC_RST
E5
VCH
F4
EVER3
F6
LDO1_ON C1
PVDD_LDO1 B1
LDO1_OUT A1
LDO1_FB B2
LDO2_ON A5
PVDD_LDO2 A4
LDO2_OUT A3
LDO2_FB B3
LOAD_ON B5
LOAD_IN B6
LOAD_OUT A6
SGND_LDO A2
C5204
1u
C5202
0.1u
C5205
1u
C5207
4.7u
C5203
1u
C5209
1u
C5200 0.1u
C5206
0.1u
C5208
1u
C5201 4.7u
CM5200
VTR_UNREG
GND
UNREG_IN_DET
PVDD_LDO1
PVDD_LDO2
LDO1_OUT
EVER3
LOAD_OUT
DD_ON
VCH
LOAD_IN
LOAD_ON
VUC
CS
CLK
DIN
ACV_UNREG
BATT_UNREG
ACV_ON
BATT_ON
LANC_DC
DATA_IN
DATA_OUT
LANC_SIG
XLANC_PWR_ON
XLANC_ON
UNREG_IN
VUC_RST
LDO1_ON
LDO2_ON
LDO2_OUT
R5201
100k
R5200 100
R5202
33k
C0102
10u
C0104
2.2u
C0100
10u
COM102
COM002
COM101
COM003
COM004
COM005
COM006
COM007
COM008
COM009
CM0100
IO_UNREG
SYS_DD_SCK
MS_PWR_ON
IO_UNREG
DD_ON1
CORE_UNREG
SYS_DD_IC_5100_XCS
SYS_DD_IC_5200_XCS
LANC_IC_ON
MT_UNREG
LDO1_ON
SD_PWR_ON
LANC_SO
SYS_DD_SO
REG_GND
BATT_LI_3V
SD_3.3V
MSX_3.3V
A_1.0V_IC_5200
SYS_UNREGIN
EVER_3V
VUC
LANC_SI
XLANC_PWR_ON
HB_1.8V
D_1.2V
LANC_DC
D_1.8V
J_5.0V
D_1.0V
MT_5.0V
A_1.8V
D_3.3V
SYS_DD_SI
HB_1.2V
A_3.3V
HDMI_5V
LANC_SIG
J_5.0V_GND
L0102
4.7uH
L0103
4.7uH
L0101
4.7uH
L0106
4.7uH
L0105
10uH
LND103
LND102
LND106
LND105
LND108
LND100
LND109
LND011
DC/DC CONVERTER

6-4
HDR-PJ800/PJ810/PJ810E/PJ820/PJ820E_L3
XRST_DWN
XSYS_RST
Note: C5701, C5702, C5703, C5704, C5712, C5714, C5715 and IC5700 are not supplied,
but they are included in VC-1022 COMPLETE BOARD (SERVICE).
CBE
BEC
S
123456789
A
B
C
D
E
F
A
B
C
D
E
F
08
VC-1022 BOARD (2/19)
POWER CONTROL
XX MARK: NO MOUNT
C5713 XX
C5706
XX
R5705
XX
R5714
XX
R5704
XX
EVER_3V
R0201
XX
R0206
XX
R0204
XX
R0200 XX
R0211
XX
R0203
XX
R0202
XX
MD0
IC5700
MB9AF004BGL-G-103-ERE1
POWER CONTROL
INITX
L7
MD0
L10
PE0/MD1
K9
X0A
L5
X1A
L6
PE2/X0
L8
PE3/X1
L9
P00/TRSTX
A11
P01/TCK/SWCLK
A1
P02/TDI
F6
P03/TMS/SWDIO
L1
P04/TDO/SWO
L11
AVCC
A9
AVRH
B9
AVSS
A8
P10/AN00
G11
P11/AN01
F11
P12/AN02
F10
P13/AN03
E11
P14/AN04
E10
P15/AN05
D11
P16/AN06
D10
P17/AN07
C10
P18/AN08
B10
P19/AN09
B8
P1A/AN10
B7
P1B/AN11
B6
P07/ADTG
C7
P25/INT01
D4
P26/INT02
D3
P27/INT03 D2
P28/INT04 D1
P29/IINT05 E5
P2A/INT06 E4
P2B/INT07 E3
P30/INT08 E1
P31/INT09 F5
P32/INT10 F4
P33/INT11 F3
P3C/INT12 J2
P3D/INT13 J1
P3E/INT14 K2
P3F/INT15 K1
P60/INT16 K5
P61/INT17 K6
P62/INT18 K7
P63/INT19 K8
P64/INT20 K10
P65/INT21 J10
P66/INT22 J9
P67/INT23 J8
P59/INT24 F7
P5A/INT25 E9
P5B/INT26 E8
P5C/INT27 E7
P5D/INT28 D9
P05/INT29 A10
P06/INT30 C8
P21/SIN0 B3
P22/SOT0(SDA0) B2
P23/SCK0(SCL0) C3
P56/SIN1 G7
P57/SOT1(SDA1) F9
P58/SCK1(SCL1) F8
P48/SIN2_0 H5
P49/SOT2_0(SDA2) G5
P4A/SCK2(SCL2) J6
SIO2 J5
P4B/SIN2_1 H6
P4C/SOT2_1 G6
P4D/SIN2_2 J7
P4E/SOT2_2 H7
P50/SIN3 H10
P51/SOT3(SDA3) H9
P52/SCK3(SCL3) H8
P0A/SIN4 D6
P0B/SOT4(SDA4) E6
P0C/SCK4(SCL4)/TIOA06 C5
P36/SIN5 G3
P37/SOT5(SDA5) G2
P38/SCK5(SCL5) G1
P39/SCS5 H3
P0D/INT31 D5
VCC5 A7
USBVOUT B5
USBVCC A5
UDP/UAN0 A3
UDM/UAN1 A4
P20/UHCONX A2
P0E/UAN2 B4
P34/LSI F2
P35/LSO
F1
P0F/NMIX/WKUP0
C4
P24/INT00/WKUP1
C2
P3A/RTCCO/SUBOUT
H2
P40/TIOA00
K3
P41/TIOA01
J3
P42/TIOA02
K4
P68
H11
P3B
H1
P2C
E2
P43
J4
P44
H4
P45
G4
P53
G10
P54
G9
P55
G8
P5E
D8
P5F
C9
P08
D7
P09
C6
VCC_B11
B11
VCC_C1
C1
VCC_J11
J11
VCC_L2
L2
C
L3
VSS_A6
A6
VSS_B1
B1
VSS_C11
C11
VSS_K11
K11
VSS_L4
L4
C5715
0.1u
C5711
12p
C5707
15p
C5709
12p C5710
12p
C5705
4.7u
C5714
0.1u
C5708
2.2u
C5700
22u
C5701
0.1u
C5704
0.1u
C5703
0.1u
C5702
0.1u
C5712 0.1u
CL5701
CM5701
CM5700
CM5702
P05/INT29
P35/LSO
VCC3
EVER
INITX
GND
P00/TRSTX P01/TCK/SWCLK P02/TDI P03/TMS/SWDIO P04/TDO/SWO
VCC
P12/AN02 P13/AN03 P14/AN04 P15/AN05 P16/AN06 P17/AN07 P18/AN08 P19/AN09 P1A/AN10 P1B/AN11 P07/ADTG P25/INT01 P26/INT02
P27/INT03
P28/INT04
P29/IINT05
P2A/INT06
P2B/INT07
P30/INT08
P31/INT09
P32/INT10
P33/INT11
P3C/INT12
P3D/INT13
P3E/INT14
P3F/INT15
P60/INT16
P61/INT17
P62/INT18
P63/INT19
P64/INT20
P65/INT21
P66/INT22
P67/INT23
P59/INT24
P11/AN01
P34_PULLUP
P5C/INT27
P5D/INT28
P06/INT30
P21/SIN0
P22/SOT0(SDA0)
P23/SCK0(SCL0)
P56/SIN1
P5A/INT25
P58/SCK1(SCL1)
P48/SIN2_0
P49/SOT2_0(SDA2)
P4A/SCK2(SCL2)
SIO2
P4B/SIN2_1
P4C/SOT2_1
P4D/SIN2_2
P4E/SOT2_2
P50/SIN3
P51/SOT3(SDA3)
P52/SCK3(SCL3)
P0A/SIN4
P0B/SOT4(SDA4)
P0C/SCK4(SCL4)/TIOA06
P36/SIN5
P37/SOT5(SDA5)
P38/SCK5(SCL5)
P39/SCS5
VCC5
UDP/UAN0
UDM/UAN1
P0E/UAN2
P34/LSI
P0F/NMIX/WKUP0
P24/INT00/WKUP1
P3A/RTCCO/SUBOUT
P40/TIOA00
P41/TIOA01
P42/TIOA02
P68
P3B
P2C
P43
P44
P45
P53
P54
P55
P5E
P5F
P08
P09
P10/AN00
P57/SOT1(SDA1)
MD0
P5B/INT26
Q5702
DRA3115T0L
USB ACTIVE SWITCH
Q5701
RN1102MFV(TL3S
Q5700
RW1E025RPT2CR
12
3
4
56
R5713 27
R5711
22k
R5702
1.5k
R5712 27
R5701
3.3k
RB5700
10k
12 34 56 78
X5701
12MHz
12
34
X5700
32.768kHz
12
34
Q5700, Q5701
B+ SWITCH
DEBUG_UART_OT
DEBUG_UART_IN
BATT_IB
BATT/XEXT_DWN
CL0211
CL0200
CL0208
CL0207 CL0206
CL0204
CL0202
CL0210
CL0203
CL0205
CL0209
JL0204 JL0203 JL0202 JL0201 JL0200
CM0203
CM0205
CM0204
CM0202
SYS_BATTSENSE
SYS_ACVSENSE
EVER_3V
SYSTEM_SET_SENS
SYSTEM_SET_SENS2
REG_GND
SYS_UNREGIN
EVER_3V
XPANEL_POWER_ON
XPOWER_TACT_SW
SD_XSDCD
XLANC_PWR_ON
MSX_INS_HIZ
USB_SUSREQ_KJR
XRESET_REQ
XPWR_OFF
SYS_DD_IC_5100_XCS
REG_GND
DWN_XCS DWN_NFC_SCK DWN_NFC_SO SYS_DD_SI
SYS_SETTING_ON
BATT/XEXT
REG_GND
EVER_3V
LANC_SO
VBUS_5V
EVER_3V
REG_GND
ACV_UNREG
D_3.3V
VUC
SYS_DD_IC_5200_XCS
LANC_IC_ON
DD_ON1
DD_ON2
XEVF_SW
SYS_SETTING_ON
LDO1_ON
SYSTEM_SET_SENS SYSTEM_SET_SENS2
USB_SUSREQ_DWN
SYS_BGL_SCL
SYS_DD_SCK DWN_NFC_SI
SYS_CHG_LED
USB_IC_5651_EN
SYS_DD_SO
LANC_SI
SYS_BGL_SDA
USB_D-_DWN
USB_D+_DWN
BATT_IB
LND200
LND215 LND218 LND217 LND219 LND220
LND226
LND224
LND227
LND230
LND234
LND216
LND241
LND238
LND209
LND225
LND204
LND223
LND208
LND242
LND205
LND207
LND206
LND244 LND243
LND248
LND202
LND203
LND222
LND237
LND211 LND213
LND201
LND212
Q0201
RN1102MFV(TL3S
LED DRIVE
Q0202
RN4984FE
DC JACK DETECT
123
456
R0210
470k
R0207
1M
R0208
1M
R0209
470k
R0205
100k
RB0200
1M
12 34 56 78
