SERVICE MANUAL
CD RADIO CASSETTE-CORDER
US Model
Canadian Model
E Model
SPECIFICATIONS
CFD-E75
Photo:White model
Ver 1.0 2001.03
9-873-110-11 Sony Corporation
2001C0500-1 Audio Entertainment Group
C2001.3 General Engineering Dept.
CD Model Name Using Similar Mechanism NEW
Section Optical Pick-up Name KSS-213C
TAPE Model Name Using Similar Mechanism NEW
Section Tape Transport Mechanism Type MF-V5-117
AUDIO
(US model only)
POWER SPECIFICATIONS
POWER OUTPUT AND TOTAL HARMONIC
DISTORTION
With 4-ohm loads, both channels driven from
100 - 10,000 Hz; rated 1.5 W per channel-
minimum RMS power, with no more than 10 %
total harmonic distortion in AC operation.
Other Specifications
CD player section
System
Compact disc digital audio system
Laser diode properties
Material: GaAlAs
Wave length: 780 nm
Emission duration: Continuous
Laser output: Less than 44.6 µW
(This output is the value measured at a distance of about
200 mm from the objective lens surface on the optical
pick-up block with 7 mm aperture.)
Spindle speed
200 r/min (rpm) to 500 r/min (rpm) (CLV)
Number of channels
2
Frequency response
20 - 20 000 Hz +0/–1 dB
Wow and flutter
Below measurable limit
Radio
US, Canadian, *E92, Taiwan, Mexican models
section
Frequency range
FM: 87.6 - 108 MHz
AM: 530 - 1 710 kHz
Antennas
Frequency range
Singapore, Argentina models
FM: Telescopic antenna
AM: Built-in
FM: 87.6 – 108 MHz
AM:
IF FM: 10.7 MHz
AM/MW: 450 kHz
Aerials
FM: Telescopic aerial
AM/MW: Built-in ferrite bar aerial
531 – 1,602 kHz
ferrite bar antenna
Cassette-corder section
Recording system
4-track 2 channel stereo
Fast winding time
Approx. 120 sec. with Sony cassette C-60
Frequency response
TYPE I (normal): 70 - 13 000 Hz
General
Speaker
Full range: 8 cm (3 1⁄4 in.) dia.,
4 Ω, cone type (2)
Outputs
Headphones jack (stereo minijack)
For 16 - 64 Ωimpedance headphones
Power output
2 W + 2 W (at 4 Ω, 10 % harmonic distortion
in AC operation)
Power
US, Canadian, *E92, Taiwan, Mexican models
Singapore, Argentina models
230 V AC, 50 Hz
requirements
For CD radio cassette-corder:
120 V AC, 60 Hz
9 V DC, 6 size C (R14) batteries
For memory back-up:
4.5 V DC, 3 size AA (R6) batteries
For remote control:
3 V DC, 2 size AA (R6) batteries
Power consumption
AC 14 W
Battery life
For CD radio cassette-corder:
FM recording
Sony R14P: approx. 5 h
Sony alkaline LR14: approx. 20.5 h
Tape playback
Sony R14P: approx. 6 h
Sony alkaline LR14: approx. 27 h
CD playback
Sony R14P: approx. 1.5 h
Sony alkaline LR14: approx. 8 h
Dimensions
Approx. 283 ×165 ×281 mm (w/h/d)
(11 1⁄4× 6 1⁄2×11 1⁄8 inches)(incl. projecting parts)
MassApprox. 3.5 kg (7 lb. 11 oz) (incl. batteries)
Supplied accessories
AC power cord (1)
Remote control (1)
*E92: Central and South America model
Design and specifications are subject to change without
notice.
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

2
CFD-E75
TABLE OF CONTENTS
1. SERVICING NOTES.............................................. 4
2. GENERAL .................................................................. 5
3. DISASSEMBLY
3-1. Disassembly Flow ........................................................... 8
3-2. Cabinet Lower Assy ........................................................ 8
3-3. AC INLET Board, Power Board..................................... 9
3-4. TUNER Board, MAIN Board ......................................... 9
3-5. Cover Plate Assy ............................................................. 10
3-6. Optical Pick-up Device (KSS-213C).............................. 10
3-7. Cabinet Front Assy.......................................................... 11
3-8. Tape Mechanism Deck (MF-V5-117) ............................ 11
3-9. CD Lid ............................................................................. 12
3-10. Lid Cassette Assy, LCD Board ....................................... 12
3-11. Head (HRP301), Motor Assy (M301), Belt ................... 13
3-12. Connector Setting............................................................ 13
4. MECHANICAL ADJUSTMENTS...................... 14
5. ELECTRICAL ADJUSTMENTS
Tape Deck Section ......................................................... 14
Tuner Section ................................................................. 15
CD Section ..................................................................... 17
6. DIAGRAMS
6-1. Block Diagram – CD Section – .................................... 19
6-2 Block Diagram – TUNER Section – ............................ 20
6-3. Block Diagram – MAIN Section – ............................... 21
6-4. Block Diagram – POWER SUPPLY Section – ............ 22
6-5. Printed Wiring Board – CD Section – .......................... 24
6-6. Schematic Diagram – CD Section – ............................. 25
6-7. Printed Wiring Board – TUNER Section – .................. 26
6-8. Schematic Diagram – TUNER Section – ..................... 27
6-9. Printed Wiring Board – TAPE DECK Section – .......... 28
6-10. Schematic Diagram – TAPE DECK Section –............. 28
6-11. Printed Wiring Boards – MAIN/LCD Boards –........... 29
6-12. Schematic Diagram – MAIN Board (1/2) – ................. 30
6-13. Schematic Diagram – MAIN (2/2)/LCD Boards – ...... 31
6-14. Printed Wiring Boards – PANEL Section – ................. 32
6-15. Schematic Diagram – PANEL Section –...................... 33
6-16. Printed Wiring Boards
– POWER SUPPLY Section – ....................................... 34
6-17. Schematic Diagram
– POWER SUPPLY Section – ....................................... 35
6-18. IC Pin Function Description .......................................... 38
7. EXPLODED VIEWS
7-1. Cabinet Section ............................................................... 40
7-2. Cabinet Upper Section .................................................... 41
7-3. Cabinet Front Section ..................................................... 42
7-4. Cabinet Lower Section.................................................... 43
7-5. Tape Mechanism Deck Section-1 (MF-V5-117)............ 44
7-6. Tape Mechanism Deck Section-2 (MF-V5-117)............ 45
8. ELECTRICAL PARTS LIST .............................. 46
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

3
CFD-E75
ATTENTION AU COMPOSANT AYANT RAPPORT
À LA SÉCURITÉ!
LES COMPOSANTS IDENTIFIÉS PAR UNE MARQUE 0
SUR LES DIAGRAMMES SCHÉMATIQUES ET LA LISTE
DES PIÈCES SONT CRITIQUES POUR LA SÉCURITÉ
DE FONCTIONNEMENT. NE REMPLACER CES COM-
POSANTS QUE PAR DES PIÈCES SONY DONT LES
NUMÉROS SONT DONNÉS DANS CE MANUEL OU
DANS LES SUPPLÉMENTS PUBLIÉS PAR SONY.
SAFETY-RELATED COMPONENT WARNING!!
COMPONENTS IDENTIFIED BY MARK 0OR DOTTED
LINE WITH MARK 0ON THE SCHEMATIC DIAGRAMS
AND IN THE PARTS LIST ARE CRITICAL TO SAFE
OPERATION. REPLACE THESE COMPONENTS WITH
SONY PARTS WHOSE PART NUMBERS APPEAR AS
SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUB-
LISHED BY SONY.
Notes on chip component replacement
•Never reuse a disconnected chip component.
•Notice that the minus side of a tantalum capacitor may be dam-
aged by heat.
SAFETY CHECK-OUT
After correcting the original service problem, perform the follow-
ing safety check before releasing the set to the customer:
Check the antenna terminals, metal trim, “metallized”knobs,
screws, and all other exposed metal parts for AC leakage.
Check leakage as described below.
LEAKAGE TEST
TheAC leakage from any exposed metal part to earth ground and
from all exposed metal parts to any exposed metal part having a
return to chassis, must not exceed 0.5 mA (500 microamperes).
Leakage current can be measured by any one of three methods.
1. A commercial leakage tester, such as the Simpson 229 or RCA
WT-540A. Follow the manufacturers’instructions to use these
instruments.
2. A battery-operatedAC milliammeter. The Data Precision 245
digital multimeter is suitable for this job.
3. Measuring the voltage drop across a resistor by means of a
VOM or battery-operated AC voltmeter. The “limit”indica-
tion is 0.75 V, so analog meters must have an accurate low-
voltage scale. The Simpson 250 and Sanwa SH-63Trd are ex-
amples of a passive VOM that is suitable. Nearly all battery
operated digital multimeters that have a 2VAC range are suit-
able. (See Fig. A)
Fig. A. Using an AC voltmeter to check AC leakage.
1.5 k Ω 0.15 µF
AC
voltmeter
(0.75 V)
To Exposed Metal
Parts on Set
Earth Ground
CAUTION
Use of controls or adjustments or performance of procedures
other than those specified herein may result in hazardous ra-
diation exposure.
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

4
CFD-E75 SECTION 1
SERVICING NOTES
The laser diode in the optical pick-up block may suffer electro-
static break-down because of the potential difference generated
by the charged electrostatic load, etc. on clothing and the human
body.
During repair, pay attention to electrostatic break-down and also
use the procedure in the printed matter which is included in the
repair parts.
The flexible board is easily damaged and should be handled with
care.
NOTES ON LASER DIODE EMISSION CHECK
The laser beam on this model is concentrated so as to be focused
on the disc reflective surface by the objective lens in the optical
pick-up block. Therefore, when checking the laser diode emis-
sion, observe from more than 30 cm away from the objective lens.
LASER DIODE AND FOCUS SEARCH OPERATION
CHECK
1. Turn POWER switch on with no disc inserted and make Func-
tion switch to CD position.
2. Open the lid for CD.
3. Turn on S701 as following figure.
4. Press the [ ] (CD) button.
5. Confirm the laser diode emission while observing the object-
ing lens. When there is no emission, Auto Power Control cir-
cuit or Optical Pick-up is broken.
Objective lens moves up and down three times for the focus
search.
NOTES ON HANDLING THE OPTICAL PICK-UP
BLOCK OR BASE UNIT
u
MODEL IDENTIFICATION

MODEL NO. CFD-E75
US, Canadian, *E92, Taiwan,
Mexican models: AC: 120 V 60 Hz 14 W
Singapore, Argentine models: AC: 230 V -50 Hz 14
W
CHUCK PLATE JIG ON REPAIRING
On repairing CD section, playing a disc without the CD lid, use
Chuck Plate Jig.
• Code number of Chuck Plate Jig: X-4918-255-1
*E92: Central and South America model
S701
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

5
CFD-E75
SECTION 2
GENERAL This section is extracted from
instruction manual.
4
Connect the supplied AC power cord (see page 24).
1 Press ZPUSH OPEN/CLOSE down
to open the CD compartment and
place the CD on the CD
compartment.
2 Close the lid of the CD compartment.
3 Press u(Non the remote).
The player turns on (direct power-on)
and plays all the tracks once.
Basic Operations
3
Playing a CD
Display
With the label side up
1, 2
PUSH OPEN/CLOSE
PUSH OPEN/CLOSE
Playing timeTrack number
Basic Operations
5
Use these buttons for additional operations
POWER
x
u
Jog dial
VOLUME +, —
ZPUSH
OPEN/CLOSE
To Do this
adjust the volume Press VOLUME +, —(VOL +, —on
the remote).
stop playback Press x.
pause playback Press u(Xon the remote).
Press the button again to resume
play after pause.
go to the next track Turn the jog dial clockwise.
(On the remote, press >.)
go back to the previous track Turn the jog dial counterclockwise.
(On the remote, press ..)
remove the CD Press ZPUSH OPEN/CLOSE.
turn on/off the player Press POWER.
About CD-Rs/CD-RWs
This player is compatible with CD-Rs/CD-RWs but
playback capability may vary depending on the quality of
the disc, the recording device and application software.
6
Listening to the radio
Connect the supplied AC power cord (see page 24).
1Press RADIO BAND¥AUTO
PRESET until the band you want
appears in the display (direct power-
on).
2Hold down TUNE + or —until the
frequency digits begin to change in
the display.
The player automatically scans the
radio frequencies and stops when it
finds a clear station.
If you can't tune in a station, press
the button repeatedly to change the
frequency step by step.
Display
Indicates an FM stereo
broadcast
12
RADIO
AUTO PRESET
BAND
TUNE
Basic Operations
7
Use these buttons for additional operations
To Press
adjust the volume VOLUME +, —
(VOL +, —on the remote)
turn on/off the radio POWER
To improve broadcast reception
Reorient the antenna for FM. Reorient the player itself for
AM.
for FM for AM
Tip
If the FM broadcast is
noisy, press MODE until
Monoappears in the
display and the radio will
play in monaural.
POWER
VOLUME +, —
MODE
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

6
CFD-E75
8
Playing a tape
Connect the supplied AC power cord (see page 24).
1Press xZ to open the tape
compartment and insert a recorded
tape. Use TYPE I (normal) tape only.
Close the compartment.
2Press n.
The player turns on (direct power-on)
and starts playing.
With the side you want
to play facing you
Display
21
Basic Operations
9
Use these buttons for additional operations
To Press
adjust the volume VOLUME +, —
(VOL +, —on the remote)
stop playback xZ
fast-forward or rewind the tape mor M
pause playback X
Press the button again to
resume play after pause.
eject the cassette xZ
turn on/off the player POWER
xZ
X
m, M
POWER
VOLUME +, —
10
Recording on a tape
Connect the supplied AC power cord (see page 24).
1Press xZ to open the tape
compartment and insert a blank tape.
Use TYPE I (normal) tape only.
2Select the program source you want
to record.
To record from the CD player, insert
a CD (see page 4) and press xon the
CD section.
To record from the radio, tune in the
station you want (see page 6).
3
With the side you want to
record on facing you
Display
1
RADIO
AUTO PRESET
BAND
Basic Operations
11
3Press zto start recording
(nis depressed automatically).
Use these buttons for additional operations
Tips
¥Adjusting the volume or the
audio emphasis (see page
18) will not affect the
recording level.
¥If the AM program makes a
whistling sound after you've
pressed zin step 3, press
MODE to select the
position of ISS
(Interference Suppress
Switch) that decreases the
noise the most.
¥For the best results, use the
AC power as a power
source.
¥To erase a recording,
proceed as follows:
1 Insert the tape whose
recording you want to
erase.
2 Press X.
3 Press n.
4 Press z.
5 Press X.
xZ
X
POWER
MODE
n
To Press
stop recording xZ
pause recording X
Press the button again to resume
recording.
turn on/off the player POWER
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

7
CFD-E75
The Timer
19
Before you set the clock, connect the power
source (see page 24).
1Press MENU¥ALARM until CLOCK
appears in the display, then press
DSPL¥ENT MEM.
The hour digit flashes.
2Turn the jog dial to set the current hour.
Then press DSPL¥ENT MEM.
The minute digits flash. Set the minutes
by turning the jog dial until the correct
minute is displayed.
The Timer
Setting the clock
— —:—— indication appears in the display
until you set the clock.
DSPL
ENT MEMJog dial
3 Press DSPL¥ENT MEM.
The clock starts from 00 seconds.
Tip
The time display system: 12-hour system
AM 12:00 = midnight
PM 12:00 = noon
MENU
ALARM
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

8
CFD-E75
• This set can be disassembled in the order shown below.
SECTION 3
DISASSEMBLY
Note: Follow the disassembly procedure in the numerical order given.
3-2. CABINET LOWER ASSY
3-1. DISASSEMBLY FLOW
Cabinet lower assySet “AC INLET board”, “POWER board”
“TUNER board”, “MAIN board”
Cover plate assy Optical pick-up device
(KSS-213C)
Cabinet front assy Tape mechanism deck
(MF-V5-117)
CD lid
“Lid cassette assy”,
“LCD board”
“Head (HRP301)”,
“motor assy (M301)”, “belt
”
1 two screws
(BVTP3
× 14)
2 four screws
(BVTP3
× 10)
3
5
4 two screws
(BVTP3
× 14)
6 connector
(CN322)
7 connector
(CNP392)
8 cabinet lower assy
4 screw
(BVTP3
× 14)
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

9
CFD-E75
3-3. AC INLET BOARD, POWER BOARD
3-4. TUNER BOARD, MAIN BOARD
2 two screws
(BVTP3
× 10)
3 AC INLET board
5 two screws
(BVTP3
× 10)
1 connecto
r
(CN902)
4 connector
(CNP901)
6 POWER board
2 four screws
(BVTP3
× 10)
9 four screws
(BVTP3
× 10)
3 TUNER board
1 connector
(CNP1)
4 connector
(CNP321)
5 connector
(CNP802)
6 FFC cable 27P
(CNP801)
7 wire (flat type) (14 core)
(CNP323)
8 FFC cable 13P
(CNP322)
0 MAIN board
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

10
CFD-E75
3-5. COVER PLATE ASSY
3-6. OPTICAL PICK-UP DEVICE
(KSS-213C)
6 two screws
(BVTP3
× 10)
2 connector
(CNP802)
1 connector
(CNP321)
3 FFC cable 27P
(CNP801)
4 wire (flat type) (14 core)
(CNP323)
5 FFC cable 13P
(CNP322)
6 four screws
(BVTP3
× 10)
6 four screws
(BVTP3
× 10)
7 cover plate ass
y
1 four screws
(2.6
× 10)
2 optical pick-up devic
e
(KSS-213C)
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

11
CFD-E75
3-7. CABINET FRONT ASSY
3-8. TAPE MECHANISM DECK
(MF-V5-117)
2 wire (flat type) (14 core)
(CNP323)
7 two screws
(BVTP3
× 10)
6 four screws
(BTP2.6
× 8)
4 Push the knob (stop/eject).
5
3 connector
(CNP321)
8 cabinet front assy
1 FFC cable 27P
(CNP801)
1 four screws
(BVTP3
× 10)
2 tape mechanism deck
(MF-V5-117)
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

12
CFD-E75
3-9. CD LID
3-10. LID CASSETTE ASSY, LCD BOARD
1 screw
(BTP2.6
× 8)
2 damper
driver
CD lid
4 CD lid
3 boss
1 two screws
(BTP2.6
× 8
)
2 two claws
3 lid cassette assy
4 LCD board
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

13
CFD-E75
3-11. HEAD (HRP301), MOTOR ASSY (M301), BELT
6 two screws
(B2.6
× 5)
7 motor assy (M301
)
8 belt
5 head (HRP301)
1 screw
(BVTT2
× 6)
3 Remove
four solders.
4 TC board
2
3-12. CONNECTOR SETTING
MAIN board
TUNER board
CNP1
CNP321
CN322
CNP802
CNP801
CN303
TC board
CN321
CNP32
2
Note: When connecting leads, set it as shown in the figure.
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

14
CFD-E75 SECTION 4
MECHANICAL ADJUSTMENTS SECTION 5 ELECTRICAL ADJUSTMENTS
Tape Speed Adjustment
Setting:
Function: TAPE
Procedure:
1. Playback WS-48A (tape center) in the FWD state.
2. Adjsut the volume in CAPSTAN/REEL motor (M301) so that
the frequency counter reading becomes 3,000 Hz.
Specified Value: 2,930 to 3,030 Hz
3. Confirm that the frequency at the beginning and that at the
end of tape winding are between 2,940 to 3,060 Hz.
Adjustment Location:
PRECAUTION
1. Setting
MEGA BASS control : OFF
TAPE DECK SECTION 0 dB=0.775 V
Test tape
Type Signal Used for
WS-48A 3 kHz, 0 dB Tape Speed Adjustment
+
–
set
Test tape
WS-48A
(3 kHz, 0 dB) frequency counte
r
3.2 Ω
POWER board
CNP392 pin 2
POWER board
CNP392 pin 1
Tape speed
Adjustment
CAPSTAN/REEL motor
(M301)
–TAPE deck block –
Mode Tension Meter Meter Reading
FWD CQ-403A more than 100 g
(more than 3.53 oz)
• TapeTension Measurement
PRECAUTION
1. Clean the following parts with a denatured-alcohol-moistened
swab :
record/playback head pinch roller
erase head rubber belts
capstan idlers
2. Demagnetize the record/playback head with a head demagne-
tizer. (Do not bring the head magnetizer close to the erase head.)
3. Do not use a magnetized screwdriver for the adjustments.
4. The adjustments should be performed with the rated power
supply voltage unless otherwise noted.
• Torque Measurement
Mode Torque Meter Meter Reading
2.95 – 6.86 mN•m
FWD CQ-102C (30 – 70 g•cm)
(0.42 – 0.97 oz•inch)
0.15 – 5.39 mN•m
FWD CQ-102C (1.5 – 5.5 g•cm)
Back Tension (0.021 – 0.076 oz•inch)
more than 5.89 mN•m
FF CQ-201B (more than 60 g•cm)
(more than 0.83 oz•inch)
more than 5.89 mN•m
REW CQ-201B (more than 60 g•cm)
(more than 0.83 oz•inch)
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

15
CFD-E75
AM IF ADJUSTMENT
Adjust for a maximum reading on level meter
T1 450 kHz
AM VCO VOLTAGE ADJUSTMENT
Adjustment Part Frequency Display Reading on Digital Voltmeter
L4 530 kHz 1.0 ±0.05 V
Confirmation 1,710 kHz 5.3 ±0.7 V
AM TRACKING ADJUSTMENT
Adjust for a maximum reading on level meter
L3 620 kHz
CT3 1,400 kHz
FM IF ADJUSTMENT
Adjust for a minimum reading on level meter
T2 10.7 MHz
FM VCO VOLTAGE ADJUSTMENT
Adjustment Part Frequency Display Reading on Digital Voltmeter
L2 108 MHz 3.0 ±0.2 V
Confirmation 87.5 MHz 1.3 ±0.3 V
FM TRACKING ADJUSTMENT
Adjust for a maximum reading on level meter
L1 87.5 MHz
CT1 108 MHz
Adjustment Location: TUNER and POWER board (See page 16)
TUNER SECTION 0 dB=1 µV
[AM]
Setting:
Function : RADIO
RADIO BAND button : AM
[FM]
Setting:
Function : RADIO
RADIO BAND button: FM
• Repeat the procedures in each adjustment several times, and the
tracking adjustments should be finally done by the trimmer ca-
pacitors.
• Remove FM antenna in FM adjustment.
AM RF signal
generator
30% amplitude
modulation by
400 Hz signal
Output level:
as low as possible
Put the lead-wire
antenna close to
the set.
+
–
level mete
r
set
3.2 Ω
POWER board
CNP392 pin 2
POWER board
CNP392 pin 1
FM RF signal
generator
22.5 kHz frequency
deviation by 400 Hz
signal
Output level:
as low as possible
+
–
level mete
r
POWER board
CNP392 pin 2
POWER board
CNP392 pin 1
set
3.2 Ω
0.01 µF
TUNER board
TP (GND)
TUNER board
TP (ANT)
digital voltmete
r
TP (VT)
TP (GND)
100 k Ω
TUNER board
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

16
CFD-E75
Adjustment Location:
TP
(VT)
TP
(GND)
TP
(ANT)
–TUNER BOARD (Component Side) –
–TUNER BOARD (Conductor Side) –
L4
AM VCO Voltage Adjustment
L2
FM VCO Voltage Adjustment
AM Tracking Adjustment CT3
L3
FM Tracking Adjustmen
t
T1 AM IF Adjustment
T2 FM IF Adjustment
L1
CT1
– POWER BOARD (Conductor Side) –
14
CNP392
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

17
CFD-E75
CD SECTION
CD section adjustments are done automatically in this set.
In case of operation check, confirm that focus bias.
Focus Bias Check
1. Connect the oscilloscope to TP (RF) andTP (GND) on the CD
board.
2. Insert the disc (YEDS-18). (Part No. : 3-702-101-01)
3. Press the [ ] (CD) button.
4. Confirm that the oscilloscope waveform is as shown in the
figure below. (eye pattern)
A good eye pattern means that the diamond shape (◊) in the
center of the waveform can be clearly distinguished.
• RF signal reference waveform (eye pattern)
VOLT/DIV: 0.2 V (with the 10: 1 probe in use.)
TIME/DIV: 500 ns
0.85 ±0.2 Vp-p
When observing the eye pattern, set the oscilloscope
for AC range and raise vertical sensitivity.
Adjustment Location:
u
IC701
TP (GND)
TP
(RF)
– CD BOARD (Conductor Side) –
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

18
CFD-E75
MEMO
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

CFD-E75
1919
SECTION 6
DIAGRAMS
6-1. BLOCK DIAGRAM – CD Section –
A
B
D13
10
11
13
10
11
F
E
C
I-V AMP
DETECTOR
12
11
17
18
26 SL+
SL–
F–
F+
T+
T–
SPINDLE
MOTOR DRIVE
M701
(SPINDLE)
S701
(LIMIT)
SLED
MOTOR DRIVE
27
M702
(SLED)
FOCUS
COIL DRIVE
TRACKING
COIL DRIVE
SP+
SP– 3
25
9
19
FIN
TIN
SLIN
SPIN
FOCUS/TRACKING COIL DRIVE,
SPINDLE/SLED MOTOR DRIVE
IC702
LD
PD
LASER DIODE
OPTICAL PICK-UP
(KSS-213C)
2-AXIS
DEVICE
(FOCUS)
(TRACKING)
2
1
9
14
9
14
7
5
7
5
3
2
3
2
4
1
4
1
22
CNP701
M
M
7MUTE
AUTOMATIC
POWER
CONTROL
Q701
8FIN2
7FIN1
+
MIX 4
RF
LPF
EQ
PH
BH
10 TIN1
9TIN1
A/D
SW
LPF
TRACK
JUMP
TBAL
80 LDD APC
AUDIO
ADJUST
SERVO
PROCESSOR
RUPTURE
DETECT
79
LDS
SW
AGC
D/A
13
FE
15
TE
20
TDO
21
FDO
23
SLDO
22
SPDO
S/H
3
EFM
IN SLISE LEVEL
CONTROL
ERROR
CORRECTION
AUDIO CD
C1 – 2, C2 – 2
RAM
8FS
DIGITAL
FILTER
INTERPOLATION
MUTE
ATTENUATION
DEEMPHASIS
1 BIT
DAC
42
LCHO
45
RCHO
LPF
39
DOUT
AUDIO
OUT
FSEQ
PLL
VCEC
CLV, CAV
CONTROL
FRAME SYNC
DETECT,
PROTECT INSERT,
EFM DECODE
31
RAM
DRF 67
25
CONT4
72
CONT1
66
*RES
61
CE
62
CL
63
DI
64
DO
65
*WRQ
RF AMP, FOCUS/TRACKING SERVO,
DIGITAL SIGNAL PROCESSOR,
CLV SERVO, D/A CONVERTER
IC701
5
9
7
3
4
6
10
12
1 CD-WRQ
8 CD DO
9 CD DI
7 CD CL
6 CD CE
5 CD-RES
8
10 CD DRF
11 CD FSEQ
*WRQ
DO
DI
CL
CE
*RES
DRF
FSEQ
5
9
7
3
4
6
10
12
8
CD L-OUT
CNP702 CNP323
20
CD DOOR
1
2
CNP801
S701
CD LID
OPEN/CLOSE
3
CNP322
(1/5) TO MAIN
SECTION
(Page 21)
A
SYSTEM
CONTROLLER
IC801
(1/3)
MAIN
BOARD
(1/4)
CD BOARD
R-CH
: CD PLAY
•R-ch is omitted due to same as L-ch.
•SIGNAL PATH
GENERAL-PURPOSE
PORTS
COMMAND
INTERFACE
DRF
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

CFD-E75
2020
6-2. BLOCK DIAGRAM –TUNER Section –
2
24
4 7
20 21
FM
RF AMP
FM
MIX
FM
OSC
FM IF
AMP
IF
BUFFER
AF
BUFFER
AF
AMP MPX MUTE
STEREO/
MONO,
FM/AM
AM IF
AMP
FM
DET
AM
DET
6
FM RF
IN
22 AM
RF AMP
AM
MIX
AM RF
IN
FM/AM
MIX OUT
OSC
OUT
CF2
10.7MHz
FM/AM PLL
IC2
CF4
450kHz
FM
RF OUT
10
QUAD
FM
IF IN 12
15
11
LOUT
MPX
IN
ROUT
13
AM
IF IN
LPF1/BAND
AM OSC FM OSC
FM/AM RF AMP, MIX, OSC,
FM/AM IF AMP, DET, MPX
IC1
L2
FM VCO VOLTAGE
L4
AM VCO VOLTAGE
CT1, L1
FM TRACKING
T1
IFT
CT3, L3
AM TRACKING
LOW-PASS
FILTER
: FM
: AM
X1
75kHz
CT3
L3
AM FERRITE-ROD
ANTENNA
L1
FM RF
XOUT
XIN
AM IN
IF IN
ST-IND
LP-OUT
LP-IN
FM IN
20
19
111218
CT1
D1
L4
AM OSC
L2
FM OSC
LEVEL
DET
ST
IND
14
LPF2/MO-ST
AM
OSC BUFFER
BUFFER
SWALLOW
COUNTER
UNIVERSAL
COUNTER
CCB
INTERFACE
REFERENCE
DIVIDER
UNLOCK
DETECT
PHASE
DETECTOR/
CHARGE PUMP
SHIFT REGISTER & LATCH
1/2
DI
CL
CE
DO
R-DATA
R-CLOCK
R-CE
R-COUNT
R-CH
CNP1
DET
OUT
ANT1
FM TELESCOPIC
ANTENNA
PD
IF OUT ST IND
2
3
1
4
10
BAND
7
MO/ST
13817 16
17 18
16
19
D2
D3
(1/2)
D3
(2/2)
8
9
7
10
TUNER BOARD
T1
AM IF
FROM MAIN
SECTION
(Page 21)
C
D11D10
•R-ch is omitted due to same as L-ch.
•SIGNAL PATH
LOW-PASS
FILTER
B+
11
2
R-MUTE
VT
6
L-CH
MAIN BOARD
(2/4)
6 1
TO MAIN
SECTION
(Page 21)
B
12 BIT
PROGRAMMABLE
DIVIDER
L-CH
CNP322
(2/5)
CN321
(1/2)
T2
FM IF
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com
