Key Technologies
Key Features
DVP-NC80V/B
5-Disc DVD/SA-CD/CD Progressive Scan Changer

5 Disc DVD/CD Changer

Super Audio CD Playback (2 Channel/Multi Channel)

Precision Drive™ 3 System Compensates For Flaws in DVD
Discs

DVD-RW (Video Mode/VR mode w/CPRM)
DVD-R/DVD+RW/DVD+R Playback1

MP3 (CD-R/RW, DVD+RW/+R/-R/-RW) and JPEG (CD-R/RW,
DVD+RW/+R/-R/-RW, Kodak) Playback1

12 Bit Video DAC with 108Mhz Processing

Dolby® Digital and dts® 5.1 Channel Output

192KHz/24bit Audio DAC/96 kHz/24 bit Digital Output

Multi-Disc Resume- 40 disc

Precision Cinema Progressive™ technology

Coaxial/Optical Digital Output

TV and Multi Channel Virtual Surround
Precision Drive™ 3 System Past generations of Precision Drive were only able to compensate for warped discs
by moving the entire optical block, which took more time and limited the amount of correction possible. Sony's
new Precision Drive™ 3 system simplifies the process by moving the lens-instead of the entire optical block-for
faster and more accurate error correction.
Precision Cinema Progressive™ Technology·Many other DVD players detect image changes at the scan line
level-Sony's Precision Cinema Progressive (PCP) system detects them at the pixel level. The picture is more
faithful to the source-whether film or video-because separate, optimized algorithms are used to handle the
differing pixel behavior. Separate algorithms are also used to process the moving and still parts of an image,
resulting in sharp backgrounds with moving objects that are virtually free from motion artifacts.
MP3 Playback1Playing MP3 Music on a Sony DVD player is easy. Just insert an MP3 encoded disc and press
MENU. A blue screen pops up to display your folders. Scroll down the list using the remote or front panel cursor
control to select the folder you want. The green files screen pops up to show the files in the selected folder.
Select the file you want to hear and you're done. Finding music couldn't be easier.

Specifications
Video
DAC (D/A Converter): 12bit/108MHz
Format(s) Supported: DVD-RW/-R (Video/VR Mode
with CPRM) DVD+RW/+R Playback1, JPEG
(CD-R/-RW,DVD+RW/+R/-R/-RW, Kodak)1
Audio
Digital-to-Analog Converter: 192kHz/24bit Audio DAC
Sound Mode: Dolby® Digital and dts® decoding
Format(s) Supported: MP3 Playback1
(CD-R/RW,DVD-R/-RW/+R/+RW), CD
(CD/CD-R/CD-RW)/VCR/SVCD1
Inputs and Outputs
Analog Audio Output(s): 5.1 Channels
Analog Video Output(s): Component x1, S-Video x1,
Composite x1
Digital Audio Output(s): Optical x 1, Coaxial x 1
Analog Audio Output(s): (R+L) x1
Power
Power Requirements: AC120V, 60 Hz
DVP-NC80V/B
Weight
9 lbs. 11 oz. (4.4Kg)
Dimensions (WHD)
17" x 3 7/15" x 16 1/8"
UPC Code
0272426675940
1. Playback may not be compatible with all discs, depending on
recording conditions
©2005 Sony Electronics Inc.
Sony, Precision Cinema Progressive, Precision Drive, and SmoothScan
are trademarks of Sony. Dolby is a registered trademark of Dolby
Laboratories. dts is a trademark of Digital Theater Systems, L.P. All
other trademarks are property of their respective owners.
Features and specifications are subject to change without notice.
Non-metric weights and measures are approximate.
