SERVICE MANUAL
CASSETTE-CORDER
US Model
Canadian Model
AEP Model
E Model
Chinese Model
TCM-459V
Tourist Model
TCM-36/459V
Model Name Using Similar Mechanism NEW
Tape Transport Mechanism Type MT-459V-118
SPECIFICATIONS
TCM-36/459V
Photo: TCM-459V
Ver 1.22004.03
9-923-317-12 Sony Corporation
2004C05-1 Personal Audio Company
© 2004.03 Published by Sony Engineering Corporation

– 2 –
SECTION 1
GENERAL
TABLE OF CONTENTS
1. GENERAL ................................................................... 2
2. DISASSEMBLY ......................................................... 3
3. MECHANICAL ADJUSTMENTS....................... 5
4. ELECTRICAL ADJUSTMENTS......................... 6
5. DIAGRAMS
5-1. Block Diagram ................................................................ 7
5-2. Printed Wiring Boards..................................................... 9
5-3. Schematic Diagram ......................................................... 13
6. EXPLODED VIEWS................................................ 16
7. ELECTRICAL PARTS LIST ............................... 19
Flexible Circuit Board Repairing
• Keep the temperature of the soldering iron around 270 ˚C dur-
ing repairing.
• Do not touch the soldering iron on the same conductor of the
circuit board (within 3 times).
• Be careful not to apply force on the conductor when soldering
or unsoldering.
Notes on chip component replacement
• Never reuse a disconnected chip component.
• Notice that the minus side of a tantalum capacitor may be dam-
aged by heat.
TAPE COUNTER
EAR
MIC
VOL
Flat mic
VOR (TCM-459V)
MIC SENS (TCM-459V)
BATT/REC
rREC
pSTOP
(PLAY
0REW/REVIEW
)FF/CUE
PAUSE c
SPEED CONTROL
DC IN 3V
• Parts Identification

– 3 –
SECTION 2
DISASSEMBLY
CABINET (REAR), CASSETTE LID
Note: Follow the disassembly procedure in the numerical order given.
• This set can be disassembled in the order shown below.
SET CABINET (REAR) MAIN BOARD BELT
CASSETTE LID MECHANISM DECK
(MT-459V-118)
8 cassette lid
5 strap
3 two claws
2 screw
4 cabinet (rear)
1 three screws
(B1.7 × 10)
7 boss
7 boss
9 cassette spring
3 claw
6 flexible board
(CN102)

– 4 –
MAIN BOARD, MECHANISM DECK (MT-459V-118)
REC lever
screw
(1.7)
S101
screw
(M1.4)
NOTE FOR INSTALLATION
• MAIN BOARD
On installation MAIN board
adjust the S101 and REC lever.
7 claw
3 screw
(1.7)
4 screw
(M1.4)
5 MAIN board
8 mechanism deck
(MT-459V-118)
6 three screws
(IB lock)
knob (pause)
2 Remove the two solders
of the head lead (HRP901).
1 Remove two solders
of motor leads (M901).
S105
Note: On installation MAIN
board adjust the S105
and knob (pause).

– 5 – – 6 –
Precaution
• Supplied voltage: 2.5 V
• Switch and control position
VOR switch (S401): OFF (459V)
PAUSE switch (S105): OFF
VOL (RV101): mechanical mid
SPEED CONTROL (RV602): mechanical center
MIC SENS switch (S201): H (459V)
TestTape
Record/Playback Head Azimuth Adjustment
Procedure:
Mode: playback
1. Turn the adjustment screw to obtain the maximum reading on
level meter.
Note: Several peaks may appear, but take the maximum.
2. After the adjustment, lock the adjustment screw with suitable
locking compound.
Adjustment Location:
BELT
1 capstan belt
2 FR belt
3 counter belt
SECTION 3
MECHANICAL ADJUSTMENTS
TapeTension Measurement
1. Clean the following parts with a denatured-alcohol-moistened
swab:
record/playback head pinch roller
erase head rubber belt
capstan idler
2. Demagnetize the record/playback head with a head demagne-
tizer. (Do not bring the head demagnetizer close to the erase
head.)
3. Do not use a magnetized screwdriver for the adjustments.
4. After the adjustments, apply suitable locking compound to the
parts adjusted.
5. The adjustments should be performed with the rated power
supply voltage (2.5 V) unless otherwise noted.
Torque Measurement
Mode Torque Meter Meter Reading
FWD 22 – 48 g•cm
CQ-102C (0.31 – 0.67 oz•inch)
Forward Back 1.0 – 4.5 g•cm
Tension (0.014 – 0.063 oz•inch)
FF, REW CQ-201B more than 50 g•cm
(more than 0.69 oz•inch)
Mode Tension Meter Meter Reading
FWD CQ-403C more than 50 g
(more than 1.76 oz)
SECTION 4
ELECTRICAL ADJUSTMENTS
0 dB=0.775 V
Tape Speed Adjustment
Procedure:
Mode: playback
1. Play back WS-48A (tape end part) and adjust RV601 so that
the frequency counter reading becomes 3,000 ± 15 Hz.
2. Play back WS-48A tape the beginning and the end part, check
that the frequency counter reading is within same standard of
step1.
Adjustment Location:
[MAIN BOARD] (Side B)
Type Signal Used for
P-4-A063 6.3 kHz, –10 dB head azimuth adjustment
WS-48A 3 kHz, 0 dB tape speed adjustment
level meter
test tape
P-4-A063
(6.3 kHz, –10 dB) 10 k
Ω
set
EAR jack
+
–
frequency
counter
Standard tape for adjusting
WS-48A
(3 kHz, 0 dB) 10 k
Ω
EAR jack
set
+
–
adjustment screw
IC101
S102
RV601
RV602
IC501

Ver 1.2

Ver 1.2

Ver 1.2

– 15 – – 16 –
• IC Block Diagrams
IC101 LA4168ML-TE-L
IC501 MM1251BFBE
SECTION 6
EXPLODED VIEWS
• Items marked “*” are not stocked since they
are seldom required for routine service. Some
delay should be anticipated when ordering
these items.
• The mechanical parts with no reference num-
ber in the exploded views are not supplied.
• Accessories and packing materials are given
in the last of the electrical parts list.
NOTE:
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• Color Indication of Appearance Parts
Example:
KNOB, BALANCE (WHITE) . . . (RED)
↑↑
Parts Color Cabinet's Color
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
(1) CABINET SECTION
3
23
23 23
21
4
5
22
21 20
19
18
17 16
114
13
15
23
SP901
24
(including MIC101)
9
7
6
11
10
812
23
1
1 3-318-382-31 SCREW (1.7), TAPPING
2 3-345-648-51 SCREW (M1.4), TOOTHED LOCK
*3 A-3021-022-A MAIN BOARD, COMPLETE (TCM-459V)
*3 A-3021-024-A MAIN BOARD, COMPLETE (TCM-36)
4 3-008-612-01 TERMINAL, PLUS
5 3-924-750-01 TERMINAL, MINUS
6 3-924-744-01 SPRING (CLAW DETECTION), TENSION
7 3-018-311-01 CLAW, ERASING PREVENTION
8 3-018-310-01 KNOB (PAUSE)
9 4-969-980-21 SCREW (IB LOCK)
10 3-578-101-41 PLATE, ORNAMENTAL
11 3-018-307-01 CABINET (FRONT) (TCM-459V)
11 3-018-307-31 CABINET (FRONT) (TCM-36)
*12 1-669-038-11 LED BOARD
13 3-936-424-01 SPRING, CASSETTE
14 4-017-441-01 CUSHION (B)
*15 3-924-757-01 BRACKET (SPEAKER)
16 3-924-761-01 STRAP
17 3-018-309-01 LID, BATTERY CASE
18 3-018-308-11 CABINET (REAR) (TCM-459V)
18 3-018-308-31 CABINET (REAR) (TCM-36)
19 3-018-312-01 FOOT (A)
20 3-334-565-11 SCREW (B1.7X10), TAPPING
21 3-023-856-01 FOOT (B)
22 3-907-531-01 SCREW
23 3-831-441-XX SPACER, KNOB
24 X-3375-895-1 LID SUB ASSY, CASSETTE (TCM-459V)
(including MIC101)
24 X-3375-897-1 LID SUB ASSY, CASSETTE (TCM-36)
(including MIC701)
SP901 1-505-838-11 SPEAKER (3.6CM)

– 17 –
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
(2) MECHANISM DECK SECTION-1
(MT-459V-118)
51 X-3370-386-1 PINCH ROLLER ASSY
52 3-925-146-01 BUTTON (FF) ())
53 3-925-147-01 BUTTON (REW) (0)
54 3-925-148-01 BUTTON (PLAY) (()
55 3-925-145-11 BUTTON (REC) (r)
56 3-936-409-01 BUTTON (STOP) (p)
57 1-548-582-11 COUNTER, TAPE (SMALL TYPE)
58 3-924-625-01 LEVER (HEAD)
59 3-924-645-01 BRACKET (HEAD)
60 3-924-685-01 SPRING (AZIMUTH), COMPRESSION
61 3-704-197-91 SCREW (IB LOCK)
62 3-375-135-01 SCREW (1.4), SPECIAL
63 3-376-177-01 SCREW (M1.4X3.8)
64 3-925-107-01 SPRING (IDLER), COMPRESSION
65 3-924-637-01 GEAR (FF)
66 3-924-673-01 GEAR (S REEL)
67 3-924-674-01 SPRING (B. T), COMPRESSION
68 3-924-641-01 GEAR (T REEL)
69 3-924-726-01 SPRING (M GROUND), TORSION
70 3-924-681-01 BELT (CAPSTAN)
71 3-925-109-01 CUSHION (MOTOR)
72 3-925-108-01 SCREW (MOTOR)
73 3-924-644-01 SPRING (POWER TENSION), TENSION
74 3-348-160-11 SCREW (M1.4X1.6), PRECISION PAN
75 3-018-522-01 COUNTER, BRACKET
76 3-924-675-01 PULLEY (COUNTER)
77 3-924-683-01 BELT (COUNTER)
78 3-376-407-01 SCREW (M1.4)
HRP901 1-500-073-11 HEAD, MAGNETIC (RECORD/PLAYBACK)
M901 1-698-588-11 MOTOR, DC (CAPSTAN/REEL)
63
62
61
60
59
58
74
64 65
66
67
69
68
M901
70
71
72
73
76
77
52
53
54
55
56
51
HRP901
75
78
57

– 18 –
101 3-321-483-11 RING, RETAINING (0.25)
102 3-701-437-51 WASHER
103 X-3370-384-1 FLYWHEEL ASSY
104 3-924-623-01 LEVER (PLAY)
105 3-924-621-01 LEVER (REW)
106 3-924-620-01 LEVER (FF)
107 X-3370-388-1 TABLE ASSY, FELT
108 3-924-642-01 SPRING (FR), TORSION
109 3-924-629-01 LEVER (DETECTION)
110 3-925-207-01 SPRING (SHUT. OFF), TENSION
111 3-924-630-01 LEVER (S. OFF)
112 X-3370-387-1 LEVER ASSY, IDLER
113 3-924-682-01 BELT (FR)
114 X-3370-385-1 PULLEY (FR) ASSY
115 3-924-628-01 LEVER (FR)
116 3-924-633-01 SPRING (STOP), TENSION
117 3-924-622-01 LEVER (STOP)
118 3-924-643-01 SPRING (PR), TORSION
119 3-924-684-01 SPRING (LOCK PLATE), TENSION
120 3-924-619-01 LEVER (SW)
121 3-924-639-01 LEVER (CR)
122 3-924-618-01 LEVER (LOCK)
123 3-925-208-01 SPRING (REC), TENSION
124 3-924-624-01 LEVER (REC)
125 X-3375-018-1 CHASSIS SUB ASSY
126 3-924-613-01 GEAR (FR)
127 3-024-378-01 SPRING (FR LEVER), TORSION
128 3-703-925-21 SCREW (M1.4)
129 3-936-405-01 LEVER (RELEASE)
130 3-578-242-11 WASHER
131 3-014-082-02 SPACER
HE901 1-500-515-11 HEAD, MAGNETIC (ERASE)
(3) MECHANISM DECK SECTION-2
(MT-459V-118)
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
113
114 127
101
115
122
119
117
116
112
101
111110
109
107
108
106
105 104
124
123
118
125
126
101
131
102
102
103
not
supplied
130
129 128
120
121
HE901

– 19 –
SECTION 7
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts speci-
fied in the diagrams or the components used
on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when order-
ing these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
Ref. No. Part No. Description Remark
When indicating parts by reference
number, please include the board.
LED MAIN
• Abbreviation
CH : Chinese
CND: Canadian
EE : East European
*1-669-038-11 LED BOARD
*********
1-669-039-11 LED FLEXIBLE BOARD
< LED >
D501 8-719-057-99 LED SML-211YT-T86 ( i)
D502 8-719-059-96 LED SML-210LT-T86 (BATT • /REC)
D503 8-719-059-96 LED SML-210LT-T86 (BATT ••)
< RESISTOR >
R202 1-216-049-11 RES, CHIP 1K 5% 1/10W
(TCM-459V)
R403 1-216-295-00 SHORT 0 (TCM-459V)
< SWITCH >
S201 1-572-922-11 SWITCH, SLIDE (MIC SENS) (TCM-459V)
S401 1-572-922-11 SWITCH, SLIDE (VOR) (TCM-459V)
************************************************************
*A-3021-022-A MAIN BOARD, COMPLETE (TCM-459V)
*A-3021-024-A MAIN BOARD, COMPLETE (TCM-36)
*********************
3-008-612-01 TERMINAL, PLUS
< CAPACITOR >
C101 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C102 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
C103 1-135-091-00 TANTALUM CHIP 1uF 20% 16V
C104 1-135-151-21 TANTALUM CHIP 4.7uF 20% 4V
C105 1-135-151-21 TANTALUM CHIP 4.7uF 20% 4V
C106 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C107 1-163-077-00 CERAMIC CHIP 0.1uF 10% 25V
C108 1-163-017-00 CERAMIC CHIP 0.0047uF 5% 50V
C109 1-163-001-11 CERAMIC CHIP 220PF 10% 50V
C110 1-135-091-00 TANTALUM CHIP 1uF 20% 16V
C111 1-135-151-21 TANTALUM CHIP 4.7uF 20% 4V
C112 1-164-182-11 CERAMIC CHIP 0.0033uF 10% 50V
C113 1-164-005-11 CERAMIC CHIP 0.47uF 16V
C114 1-164-346-11 CERAMIC CHIP 1uF 16V
C115 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
C116 1-164-346-11 CERAMIC CHIP 1uF 16V
C117 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C118 1-164-489-11 CERAMIC CHIP 0.22uF 10% 16V
C119 1-164-489-11 CERAMIC CHIP 0.22uF 10% 16V
C120 1-126-153-11 ELECT 22uF 20% 6.3V
C121 1-135-201-11 TANTALUM CHIP 10uF 20% 4V
C124 1-124-259-11 ELECT 4.7uF 20% 16V
C125 1-124-434-00 ELECT 220uF 20% 4V
C126 1-164-346-11 CERAMIC CHIP 1uF 16V
C127 1-124-434-00 ELECT 220uF 20% 4V
C128 1-124-433-00 ELECT 100uF 20% 4V
C129 1-126-153-11 ELECT 22uF 20% 6.3V
C130 1-163-035-00 CERAMIC CHIP 0.047uF 50V
C132 1-164-346-11 CERAMIC CHIP 1uF 16V
C134 1-164-182-11 CERAMIC CHIP 0.0033uF 10% 50V
C136 1-164-346-11 CERAMIC CHIP 1uF 16V
C137 1-164-346-11 CERAMIC CHIP 1uF 16V
C138 1-164-346-11 CERAMIC CHIP 1uF 16V
C140 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C141 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C142 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C145 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C146 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C201 1-135-073-00 TANTALUM CHIP 0.33uF 10% 35V
C401 1-126-153-11 ELECT 22uF 20% 6.3V
(TCM-459V)
C402 1-124-257-00 ELECT 2.2uF 20% 35V
(TCM-459V)
C403 1-164-505-11 CERAMIC CHIP 2.2uF 16V
(TCM-459V)
C501 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C502 1-135-201-11 TANTALUM CHIP 10uF 20% 4V
C503 1-164-346-11 CERAMIC CHIP 1uF 16V
C504 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
C505 1-126-157-11 ELECT 10uF 20% 6.3V
< CONNECTOR/JACK >
CN101 1-750-061-11 JACK, DC (POLARITY UNIFIED TYPE)
(DC IN 3V)
* CN102 1-691-378-21 CONNECTOR, FFC/FPC (ZIF) 14P

– 20 –
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MAIN
< FERRITE BEAD >
FB101 1-414-235-21 INDUCTOR CHIP 0uH
FB102 1-414-235-21 INDUCTOR CHIP 0uH
< IC >
IC101 8-759-492-49 IC LA4168ML-TE-L
IC501 8-759-399-49 IC MM1251BFBE
< JACK >
J101 1-766-847-11 JACK (EAR)
J102 1-766-847-11 JACK (MIC (PLUG IN POWER))
< COIL >
L501 1-412-032-11 INDUCTOR CHIP 100uH
< TRANSISTOR >
Q101 8-729-800-37 TRANSISTOR 2SD1048-X7
Q102 8-729-402-84 TRANSISTOR XN4601
Q103 8-729-420-50 TRANSISTOR UN5215
Q104 8-729-230-72 TRANSISTOR 2SA1362YG
Q106 8-729-800-37 TRANSISTOR 2SD1048-X7
Q107 8-729-420-53 TRANSISTOR UN5115
Q108 8-729-402-93 TRANSISTOR UN5214-TX
Q109 8-729-402-96 TRANSISTOR UN5114
Q110 8-729-420-50 TRANSISTOR UN5215
Q201 8-729-420-50 TRANSISTOR UN5215
Q401 8-729-420-24 TRANSISTOR 2SD1819A-QRS-TX(TCM-459V)
Q402 8-729-420-50 TRANSISTOR UN5215 (TCM-459V)
Q501 8-729-402-93 TRANSISTOR UN5214-TX
Q502 8-729-403-17 TRANSISTOR XN1215
Q503 8-729-420-24 TRANSISTOR 2SD1819A-QRS-TX
< RESISTOR >
R101 1-216-065-00 RES, CHIP 4.7K 5% 1/10W
R102 1-216-049-11 RES, CHIP 1K 5% 1/10W
R103 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
R104 1-216-073-00 METAL CHIP 10K 5% 1/10W
R105 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R106 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R108 1-216-085-00 METAL CHIP 33K 5% 1/10W
R109 1-216-037-00 METAL CHIP 330 5% 1/10W
R110 1-216-037-00 METAL CHIP 330 5% 1/10W
R111 1-216-071-00 METAL CHIP 8.2K 5% 1/10W
R112 1-216-071-00 METAL CHIP 8.2K 5% 1/10W
R113 1-216-081-00 METAL CHIP 22K 5% 1/10W
R114 1-216-065-00 RES, CHIP 4.7K 5% 1/10W
R116 1-216-089-00 RES, CHIP 47K 5% 1/10W
R117 1-216-065-00 RES, CHIP 4.7K 5% 1/10W
R118 1-216-009-00 METAL CHIP 22 5% 1/10W
R119 1-216-121-00 RES, CHIP 1M 5% 1/10W
R122 1-216-081-00 METAL CHIP 22K 5% 1/10W
R123 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R130 1-216-097-00 RES, CHIP 100K 5% 1/10W
R131 1-216-059-00 METAL CHIP 2.7K 5% 1/10W
R132 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R133 1-216-045-11 METAL CHIP 680 5% 1/10W
R134 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R136 1-216-097-00 RES, CHIP 100K 5% 1/10W
R137 1-216-073-00 METAL CHIP 10K 5% 1/10W
R141 1-216-073-00 METAL CHIP 10K 5% 1/10W
R142 1-216-025-00 RES, CHIP 100 5% 1/10W
R143 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R201 1-216-037-00 METAL CHIP 330 5% 1/10W
R401 1-216-105-00 RES, CHIP 220K 5% 1/10W
(TCM-459V)
R402 1-216-097-00 RES, CHIP 100K 5% 1/10W
(TCM-459V)
R404 1-216-295-00 SHORT 0 (TCM-459V)
R501 1-216-107-00 METAL CHIP 270K 5% 1/10W
R502 1-216-103-00 METAL CHIP 180K 5% 1/10W
R503 1-216-081-00 METAL CHIP 22K 5% 1/10W
R504 1-216-083-00 METAL CHIP 27K 5% 1/10W
R505 1-216-033-00 METAL CHIP 220 5% 1/10W
R506 1-216-037-00 METAL CHIP 330 5% 1/10W
R507 1-216-051-00 METAL CHIP 1.2K 5% 1/10W
R508 1-216-037-00 METAL CHIP 330 5% 1/10W
R509 1-216-045-00 RES, CHIP 680 5% 1/10W
R510 1-216-041-00 METAL CHIP 470 5% 1/10W
R511 1-216-075-00 METAL CHIP 12K 5% 1/10W
R512 1-216-081-00 METAL CHIP 22K 5% 1/10W
R513 1-216-009-00 METAL CHIP 22 5% 1/10W
R514 1-216-021-00 METAL CHIP 68 5% 1/10W
R601 1-216-295-00 SHORT 0
R602 1-216-049-11 RES, CHIP 1K 5% 1/10W
R603 1-216-051-00 METAL CHIP 1.2K 5% 1/10W
< VARIABLE RESISTOR >
RV101 1-225-597-11 RES, VAR, CARBON 10K (VOL)
RV601 1-223-584-11 RES, ADJ, CARBON 2.2K
RV602 1-225-598-11 RES, VAR, CARBON 2K (SPEED CONTROL)
< SWITCH >
S101 1-771-321-11 SWITCH, SLIDE (REC/PB)
S102 1-771-092-21 SWITCH, PUSH (1 KEY) (POWER)
S105 1-572-922-11 SWITCH, SLIDE (PAUSE)
< THERMISTOR (POSITIVE) >
THP601 1-810-007-11 THERMISTOR, POSITIVE
THP602 1-803-117-11 THERMISTOR, POSITIVE
************************************************************
MISCELLANEOUS
**************
HE901 1-500-515-11 HEAD, MAGNETIC (ERASE)
HRP901 1-500-073-11 HEAD, MAGNETIC (RECORD/PLAYBACK)
M901 1-698-588-11 MOTOR, DC (CAPSTAN/REEL)
SP901 1-505-838-11 SPEAKER (3.6cm)
************************************************************

– 21 –
Ref. No. Part No. Description Remark
ACCESSORIES & PACKING MATERIALS
*******************************
3-862-203-02 MANUAL, INSTRUCTION
(JAPANESE, ENGLISH) (TCM-36: Tourist)
3-862-203-11 MANUAL, INSTRUCTION (ENGLISH)
(TCM-459V: US, AEP, EE, CH)
3-862-203-21 MANUAL, INSTRUCTION (ENGLISH, FRENCH)
(TCM-36/459V: CND, E)
3-862-203-31 MANUAL, INSTRUCTION (FRENCH, SPANISH,
PORTUGUESE, ITALIAN) (TCM-459V: AEP)
3-862-203-41 MANUAL, INSTRUCTION (GERMAN, DUTCH,
SWEDISH, DANISH) (TCM-459V: AEP, EE)
3-862-203-51 MANUAL, INSTRUCTION (SPANISH,
PORTUGUESE, CHINESE, KOREAN)
(TCM-36/459V: E)
3-862-203-61 MANUAL, INSTRUCTION (CHINESE)
(TCM-459V: CH)
3-862-203-71 MANUAL, INSTRUCTION (POLISH, RUSSIAN,
HUNGARIAN, CZECH) (TCM-459V: EE)
Ver 1.1

– 22 –
TCM-36/459V
MEMO

TCM-36/459V
Printing the page that exceedsA4-size two pages (or letter size) is possible by specifying the print
range. (Acrobat Reader Version 4.0 or later)
1. The enlarged print is made, if a smaller range than A4 size is specified and the A4 size is
selected as a print paper.
2. Almost real sized print is made, if the range is specified, meeting the print paper size.
3. The reduced print is made, if a larger range than the print paper size is specified.
Printing by Specifying a Range
In printing out the drawings such as a schematic diagram and a printed wiring board larger than
the printed paper size, they can be printed by specifying the range. (Acrobat Reader Version 4.0
or later)
1. Display the page to be printed.
2. From the File menu, select [Page Setup] and set the paper size.
3. From the Command bar, select [Graphic Select Tool].
(Keep pressing
T
, select )
4. Dragging the cursor, enclose the range on the page to be printed.
5. From theFile menu,select [Print] andmakesure thatthe [Selected Graphic]isalready checked.
Also, if [Fit to page] is checked, the selected range is enlarged or reduced (and rotated as
necessary) meeting the paper size.
6. To cancel the printed range, click an arbitrary position on the screen.
Printing Method for Large Sized Documents Such As Circuit Diagrams
@
!

TCM-36/459V
REVISION HISTORY
Clicking the version allows you to jump to the revised page.
Also, clicking the version at the upper right on the revised page allows you to jump to the next revised
page.
Ver. Date Description of Revision
1.0 1998.02 New
1.1 1998.10 Change of Part No. for INSTRUCTION MANUAL (TCM-36: Tourist)
1.2 2004.03 Addition of DIAGRAMS
