Sony eVilla NTE-D101 User manual

Use this section to store your account information for future
reference. Fill out this section using the information determined
during the registration of your eVilla account. (See page 10 for
instructions on registering your account.)
Primary Account Username
Primary Account Email Address
Primary Account Password
Primary Local Internet Access Telephone Number
eVilla Network Entertainment Center Serial Number
eVilla Network Entertainment Center Model Number
MYINFORMATION
Example: [email protected]
See page 12 for tips on selecting your email address.
If you write your password here, others may have access to it.
For security reasons, you may want to write a “hint” that will
help you remember it later.
Located on the identification panel on the rear of the unit.
Example: myname
This is also the first part of your email address—before the @ symbol.
NTE-D101
How to Contact Us
CUSTOMER SUPPORT
For questions about billing,
service plans and product
returns, information or
assistance with your
Internet access account or
email, or for problems with
your device, contact us at:
Web Site:
sony.com/eVilla
Email:
[email protected]
Toll Free:
1 888-344-9400
Or, write to:
Sony Customer Service Center
12451 Gateway Blvd.
Ft Myers, FL 33913
See page 10 for information on choosing this number.

3
Welcome Home . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Keeping Your Device Clean and Safe . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Helpful Resources . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Using the Getting Started Guide
Accessing the eGuide
Using the Quick Reference Card
Taking the Tour. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
On the Front
On the Back
Getting Connected . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
The Keyboard
The Scroll Mouse
Moving In (Registration) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Registering Your eVilla Internet Access Account
Choosing an Internet Access Number
Entering Your Personal Information
Providing Payment Information
Entering a Username
Entering a Password
Coming Home . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Logging In
Dialing Up
Exploring the eVilla Neighborhoods . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
eVilla Home
The Web
Email
Getting Familiar with the Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
The Toolbars
The Tray
The Status Bar
The Media Player
The File Manager
The Hardware Icons
Leaving Home . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Saving Favorite Web Sites or Email Drafts
Logging Out
Hanging up
Powering Off
Where to Get More Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Review the eGuide
Visit the eVilla Web Site
Learn the Language
Connecting Additional Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
USB Printer
External Storage Device
Speakers
Solving Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Speaking the Internet Language . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
The Legal Stuff . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Index. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
TABLEOFCONTENTS

4

1
WELCOMEHOME
Congratulations on your purchase of the eVilla™ Network
Entertainment Center—the most convenient way to
communicate and enjoy multimedia entertainment through the
Internet. After a simple registration process, you’ll be able to
connect to the world with the touch of a button. We’re glad you
chose the Sony eVilla Network Entertainment Center as your
home on the Internet. We think you will be, too.
The eVilla Network Entertainment Center offers easy access to
the most popular features of the Internet, including the World
Wide Web, email, convenient content channels, and much more.
With a high-resolution FD Trinitron display, built-in speakers and
Memory Stick media slot, you’ll enjoy a rich multimedia
experience. Here’s just a brief sample of how powerful the eVilla
Network Entertainment Center is:
nEasy and powerful on-screen displays to get you around
nTruly private and customized online experience for up to
four (4) people in your household
nEnjoy daily automatic downloads of email and Web
content without tying up your telephone line
nConvenient automatic software management allows you
to enjoy maintenance-free operation
And when it comes to using the Internet, you can:
nKeep up with the latest news and information from
around the world
nShare photographs and movies with family and friends
through electronic mail
nTune in to your favorite Internet channels for music and
radio
nShop, get latest sports scores or plan your next family
vacation
nProvide your kids with a powerful resource for
researching their homework assignments
nWatch exciting Internet video
nAnd so much more
Because the eVilla Network Entertainment Center is so easy and
fun to use, it’s a great way to feel right at home on the Internet.
We’re certain it will soon become one of the most welcome
additions to your home.

2
KEEPINGYOUR DEVICE CLEANANDSAFE
This section provides you with some key instructions on how to
clean your eVilla Network Entertainment Center and keep it
from being damaged.
nDangerously high voltages are present inside the unit.
Do not open the cabinet. Refer servicing to qualified
personnel only.
nThe eVilla case holes are for ventilation. Never place
anything in the holes.
nAvoid spilling food or liquids on or near your eVilla
device.
nUse a soft, dry cloth to clean the screen, cabinet,
controls and keyboard. You can use an anti-static dusting
spray (compressed air) designed for VCRs, computer
monitors and television sets to clean between the keys of
the keyboard.
nAvoid using an anti-static solution or similar additives as
they may scratch the screen.
nAvoid cleaning the device with ammonia-based or
chlorine cleaners or sprays.
nAvoid using household detergents to clean any part of
the device as they may scratch or damage the unit.
nAvoid using abrasive pads, scouring powders or
solvents, such as alcohol or benzene.
nKeep the device out of direct sunlight and away from
heat vents, radiators and other heat sources.
nDo not rub, scratch or tap the surface of the screen with
sharp or abrasive items such as ballpoint pens or
screwdrivers. This type of contact may result in a
scratched picture tube.

3
HELPFULRESOURCES
Using the Getting Started Guide
The Getting Started Guide is intended to assist you with setting
up and getting familiar with your eVilla Network Entertainment
Center. In this guide you’ll find information on:
neVilla hardware and software features, pages 4-8
nConnecting the keyboard, scroll mouse, phone and power
cords, page 6
nSetting up your eVilla Internet access account, pages
10-13
nUsing the eVilla keyboard, scroll mouse and other
features, pages 7-8
nThe look and feel of the user interface, pages 16-27
nWhere to find answers to your questions, pages 28 and
31
nConnecting additional accessories, pages 29-30
nProblem solving, page 31
Accessing the eGuide
The complete operating instructions, called the eGuide, are
available online. All your usage questions can be answered
quickly and easily without having to search for the printed
manual. Simply click the ONLINETIPSicon in the upper right
corner of most of the screens for information on that section.
Using the Quick Reference Card
A handy quick reference card also comes with your device. This
card fits conveniently under your keyboard. Use it to remind you
how to perform some of the most common Web and email tasks.
Online Tips
icon

4
TAKINGTHETOUR
This section provides you with a quick look at the structure of
the eVilla components: the front and back of the eVilla device,
the keyboard and the scroll mouse.
On the Front
VOLUME up/down
Buttons
Increase or decrease
the volume.
WEB Button
One-touch access
to the
Web neighborhood.
eVilla Home Button
One-touch access
to the eVilla Home
neighborhood.
EMAIL Button
One-touch access
to the
email neighborhood.
EMAIL Indicator
Lights up when
new email
has arrived.
Speaker Area
Listen to
the system sounds,
audio and music.
Memory Stick®
Media Slot
Use Sony Memory
Stick storage media
to access and save
pictures, music or
other files.
POWER Button
Starts or shuts down
your device.
The light indicates
when the system is
on (glows green),
sleeping (glows
amber) or
off (no light).
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
System
Reset hole
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.

5
On the Back
note
Power connection
Connect to AC power.
Audio out
Connect headphones or
external speakers.
2 USB ports
Connect printers and
external storage devices.
Mouse connection
Connect to the
scroll mouse.
Keyboard connection
Connect to the keyboard.
Phone line in
Connect to the
phone jack.
. . . . . . . .
. . . . . . . . . . . . . . . . . . . . .
. . . . . . . .
. . . . . . . . . . . . . . . . . . . . . .
. . . . . . . .
. . . . . . . . . . . . . . . . . . . . . .
. . . . . . . .
. . . . . .
Mic in
Reserved for future use.
Ethernet connection
Reserved for future use.
Additional speakers, printers and external storage
devices are not included. You may purchase eVilla-
supported products separately. Please go to the
eVilla Web site at sony.com/eVilla for a current list
of compatible products.

6
GETTINGCONNECTED
The connections on the back of the unit are marked according to
what you plug into them. Plug the keyboard, scroll mouse,
phone cord and power cord into their corresponding
connections. The cords and jacks are color coded. Match the
colors to assure you have plugged the keyboard and scroll
mouse into the proper jacks. The cords can only be inserted one
way, with the flat side of the connector aligned with the left side
of the jack. Be sure the connections are solid.
note
When you have plugged all the connections into the device, plug
the phone cord and the power cord into the wall jacks.
note
For more information. . .
on connecting other accessories, such as printers and speakers,
see page29.
Be sure to place the device close to a power outlet
and phone jack. If you do not have a phone jack
near the site you have selected, you may need to
purchase a longer phone cord. Do not run cords
where they could be tripped on or damaged.
Use the splitter if you have a single phone jack and
want to have a phone next to your eVilla device.
Plug the splitter into the telephone wall jack, then
plug the eVilla device and the phone into the
splitter’s jacks.

7
The Keyboard
The eVilla keyboard is compact, functional and provides one-
touch access to the information you’ll want most. Across the top
of the keyboard is a row of buttons. These are the NET GUIDE
channel buttons. Simply press a button to go instantly to the
Net Guide channel of your choice.
For more information. . .
on the Net Guide, see page17.
The eVilla keyboard includes a shortcut key which can be used
to perform common tasks such as copying and pasting text.
For more information. . .
on the supported shortcuts, look up “keyboard shortcuts” in the
eGuide.
Attach the palm rest by inserting the tabs into the slots on the
underside of the keyboard and sliding it into the locked position.

8
The Scroll Mouse
There are three parts to the scroll mouse — the two buttons and
the scroll wheel. When sitting on a flat surface, the mouse fits
comfortably in the palm of your hand. Your fingers should
naturally rest on the two buttons. When you move the mouse,
you will see a hand move around on the screen; this is
commonly known as the cursor .
Point and Click
Move the cursor over an active element (for example, a
hardware icon or Net Guide channel) or an Internet link. This is
the “pointing” part. Press the left button one time (called
“clicking”) to open or activate that feature. After you click to
perform a task, the cursor changes to let you know the
information is processing. Or,move the cursor within a line of
text, for instance while you are editing an email message, and
click the left button to place the cursor there. Within text, the
cursor appears as a flashing vertical line.
You may be familiar with the computer concept of “double
clicking” an icon to open it. You can use this method with the
eVilla Network Entertainment Center or click once to select an
item, then click the proper action icon to perform the desired
function, such as: OPEN, CLOSEor DELETE.
Scrolling
Use the scroll wheel between the two mouse buttons to easily
maneuver up and down through an email or a Web site that
extends beyond the vertical size of the screen. Merely roll the
wheel away from you to move up on the page, or roll it toward
you to move down.
For more information. . .
and detailed instructions on using the click, scroll and drag
features of the scroll mouse, look up “Using the Scroll Mouse” in
the eGuide.
Left
button Right button
Scroll
wheel

9
MOVINGIN(REGISTRATION)
Now that you’ve connected the keyboard, scroll mouse, phone
cord and power cord, you’re ready to go. The POWERbutton is
located on the front of the unit to the left of the Memory Stick
media slot.
When you press the POWERbutton, the indicator light turns
green and the eVilla Network Entertainment Center comes alive.
The first time you start the device you will see the Sony logo;
then, the Welcome screen appears. You can choose to register
your eVilla Internet access account or preview eVilla’s features.
nTo preview the features, click STARTTOUR.
nTo register, click REGISTER.
note You must register your Internet access account
before you can use the eVilla Network Entertainment
Center on the Internet. Please read the End User
License Agreement included with your device before
you register. It provides the terms and conditions for
use of the eVilla device and its software.
The screens you see on your eVilla unit may not look
exactly as depicted in this guide. Sony continues to
update the eVilla software to bring the best and foremost
to you.

10
Registering Your eVilla Internet Access Account
Registering your eVilla account to access the Internet is a snap.
Use the scroll mouse to click REGISTERwhen the Welcome
screen appears. A series of screens leads you step-by-step
through the process.
note
tip
Choosing an Internet Access Number
Initially, the system dials a toll-free number to register your
account. After that, it uses a local telephone number to connect
to the Internet. Access numbers will be suggested to you during
the registration process. Be sure you choose one or more that
are in your local toll-free zone so you do not have to pay
additional telephone charges while you are on the Internet.
tip
If for any reason you need to stop the process before
it is complete, don’t worry. The display appears as
soon as you power on again, and the account
registration process automatically starts over.
For easy access when you need it, record your
account information in the space provided on the
inside front cover of this guide.
Please contact your local telephone company to
assure the telephone number you select to access
the Internet is free of any toll charges. Sony cannot
be held responsible for any additional telephone
charges incurred while using this device.

11
Entering Your Personal Information
In this step you’ll provide information like your name, address,
phone number and credit card information to register your
account. The information is typed into a series of very easy,
self-explanatory screens. It is completely safe and private. The
information is sent to Customer Service over a secure, direct
phone connection.
Example:
Providing Payment Information
You must supply a debit or credit card number for monthly
billing of your Internet access account. You’ll also need the
name on the card and the expiration date, just like you would if
you were ordering something over the phone.
note The subscription fee for Internet access is a
monthly fee. Charges will vary depending on the
type of service. Your Internet access is being
provided by EarthLink, Inc. an Internet Service
Provider (ISP) that is not affiliated with Sony. Your
use of this service may be subject to additional
terms and conditions as set forth by EarthLink.

12
Entering a Username
During the account registration process you will be asked to enter
a primary account username. This name becomes part of your
email address. Enter something that is easy for you and your
friends to remember. Your name is always a good choice, as is a
hobby or special interest. Additional usernames and email
addresses, up to a total of four per e Villa device, can be set up
once your e Villa account is registered. Not only does each user
have a unique username and email address, they can save their
own favorite Web sites and have their own email address book.
Each user logs in using their own username and password.
You only need to enter your username here. Your e Villa device
automatically enters the rest of the address that identifies your
Internet access account as an e Villa account.
Example:
The username is the part of your email address that is
individualized and makes your address completely unique.
An email address has three parts:
nthe username
(should be between 6 and 20 characters long)
nthe @symbol
nthe hostname/domain of the user,
eVilla.com for eVilla Network Entertainment Center
users.
Example:
[email protected]—Pronounced “my name at eVilla dot com.”
note It’s possible that the username you want is
already being used by someone else, so be
prepared with a couple of possibilities.

13
Entering a Password
Enter a password that is easy for you to remember, but hard for
others to guess. It is best not to use your birth date or your
name. Combining letters and numbers is a good strategy. Write
a hint for yourself on the inside front cover of this guide as a
reminder in case you forget your password.
note
Case Sensitivity
Your username and password are case sensitive. When you
enter them in the registration screen, be sure to note how you
typed them. For example, if your password is Fido, you must
type it that way (not fido or FIDO) to access your account later.
For more information. . .
on adding other users to your account, look up “Setup” in the
eGuide.
If you do forget your password, don’t worry. Call
the toll-free number listed on the inside front cover.

14
COMINGHOME
In this section, you’ll learn how to log in and dial up so you can
begin using your eVilla Network Entertainment Center.
Logging In
Logging in is like unlocking the door to your own, personal
room. In your room you might keep your private email address
book, your favorite Web sites and your own, private electronic
communication (called email). Each user (up to four) has a
private room.
If there are several people using your system, you must log in
before you can access your account. When you power on, the
eVilla Login box appears. If you are the only user registered
on the system, the box does not appear and you are not
required to log in.
note
For more information. . .
on adding up to three additional users, look up “Setup” or
“Users” in the eGuide.
To log in:
1. Click your username in the eVilla Login box to highlight it.
2. Click in the Password text box to place the cursor there, and
type the password you selected when you registered your
e Villa Internet access account.
3. Click LOGIN .
note
In order to use passwords, you must enable this
feature in Setup. See the eGuide for instructions on
changing the security setting.
If the device was not powered off after someone else
used it and they did not log out, simply click the LOG
OUTicon located at the bottom of the screen, then log
in using your own username. If you are working in
someone else’s account, you will not be able to access
your email, address book or Favorites.

15
Dialing Up
The system is set up to allow you to work offline until you are
ready to access the Web or send email. As soon as you select an
option that requires you to be online, such as looking for a Web
site or sending an email, a message appears asking if you want
to go online. If you select OK, the device dials up automatically
and you hear the distinctive sounds that indicatedial up.
When you’re online, if there is no Internet activity for several
minutes the device automatically terminates the connection. If
that happens and you again want to work online, simply
continue what you were doing. As soon as you select an option
that requires you to be online, the “going online” message
appears and the device dials up.
note
For more information. . .
on changing settings, including the automatic disconnect time,
look up “Setup” in the eGuide.
For more information. . .
and instructions on adding users or changing an Internet access
number, look up “Setup” in the eGuide.
In Setup, you can select the amount of time the
system is idle before automatically disconnecting
from the Internet.
This device provides access to numerous Internet services,
such as the World Wide Web and electronic mail (email).
Information on the Internet is created by millions of
individuals and organizations. This is what gives the
Internet its diversity and value. However, some of the
information may include material that you find
objectionable. Sony cannot be held responsible for the
content of material accessed through this device. Please
use it and the Internet responsibly.
The eVilla Network Entertainment Center does not support
all data formats, including some plug-ins, and may not
provide access to all areas of the Internet.

16
EXPLORINGTHEe Villa NEIGHBORHOODS
The eVilla Network Entertainment Center is organized into three
neighborhoods: web, eVilla Home and email. Click the tabs at
the top of the screen to easily get from place to place. You can
also access these neighborhoods with a simple touch of one of
the chrome buttons on the front of the device.
Your screen may appear slightly different.
eVilla Home
The first neighborhood that appears is eVilla Home. This
section allows you to quickly access some of the most
interesting and widely used features of the Web, such as
entertainment, shopping, news, sports, finances and more. In
addition, Net Tools on this page allow you to listen to Internet
radio, watch the latest Internet streaming video clips, store and
view your photographs online, and explore the Attractions.
Net Guide Channels
Audio
Finance
Local
Lifestyle
Sports
Shopping
Net Tools
Video
Photos
Attractions
News
Entertainment

17
Using the Net Guide Channels
You can access the NET GUIDEin two places: icons on eVilla
Home and buttons across the top of your keyboard. Each takes
you directly to an area on the Web that is full of useful
information on that topic. One of the great features of the eVilla
device is that it automatically updates the Net Guide content.
Schedule the update time in Setup — after that, you don’t have
to do a thing. The content contained in these guides is
downloaded from the Internet every day. So, you can review the
Net Guide channels without having to go online!
NEWSKeep up-to-date on what’s happening locally,
nationally and worldwide.
FINANCEMonitor financial market news, use personal
finance tools and track your own personal
stock portfolio.
LOCALCheck on the local weather or traffic before
you venture out, look up restaurants in your
neighborhood, discover special events
happening in your town and much more.
ENTERTAINMENTAccess TV and movie listings, play online
games, and link to entertainment news and
Web sites.
SHOPPINGBring the mall right into your home. Shop for
electronics, flowers, toys and gifts. . .
LIFESTYLEResearch your next family vacation, get
information on health, home and family-
related Web content.
SPORTSKeep track of your favorite teams’ stats and
comprehensive sports news.
For more information. . .
on what’s available in these guides, look up “Net Guide” in the eGuide.
