Sony PCV-J100 - Vaio Desktop Computer Assembly Instructions

Upgrading and Maintaining
Your VAIO Computer
®
®

2
Upgrading and Maintaining Your
VAIO®PCV-J100 Computer
In the future you may want to install additional boards to expand the functionality
of your computer. This section describes how to open your computer and insert
add-in boards, add memory, replace the lithium battery, and install an additional
hard disk drive. For more information on upgrading your Sony computer, see the
computer Reference Manual. You can download the Reference Manual from the
Sony Web site at http://www.sony.com/pcsupport.
Overview
The procedures in this section assume you are familiar with the general
terminology associated with personal computers and withthe safety practices and
regulatory compliance required for using and modifying electronic equipment.
Read “Notes on Use” in the VAIO®User Guide before upgrading your Sony
computer.
!Always switch the power off and remove the power cord from the computer before
you open the system or connect your computer to peripheral equipment;
otherwise, damage may occur to the integrated circuits in your computer.
!Electrostatic discharge (ESD) can damage disk drives, add-in cards, and other
components. Follow the procedures described here only at an ESD workstation. If
such a station is not available, do not work in a carpeted area and do not handle
materials that produce or hold static electricity (cellophane wrappers, for
example). Ground yourself by maintaining continuous contact with an unpainted
metal portion of the chassis while performing the procedure.

Removing the sideplate
3
Removing the sideplate
To remove the sideplate:
1Remove the screw from the mid-right of the metal sideplate.
2Slide the sideplate backward and out.
Inserting an Add-in Board
Your computer has one open PCI expansion slot, enabling you to install add-in
boards to expand the functionality of your system.
!If you remove the sideplate immediately after you shut down your computer, the
components may be too hot to touch. Wait until the internal parts of the system
unit cool down before you attempt to remove the sideplate.
Removing the PCV-J100 sideplate
✍Some models, such as Configure-to-Order systems, may already contain installed
add-in cards.
!Make sure you observe the proper safety precautions when you add boards to
your Sony computer. See “Notes on Use” in the VAIO User Guide.

VAIO PCV-J100 Upgrading and Maintaining
4
To insert an add-in board:
1Shut down your computer and turn off all peripheral devices, such as your
printer.
2Unplug your computer and any peripheral devices.
3Remove the sideplate as described on page 3.
4Locate the available expansion slot. Remove the screw, and then remove the
slot cover.
Removing the PCV-J100 slot cover

Adding Memory
5
5Install the add-in board by plugging it into the expansion slot.
6Attach any internal cables that the board requires (see the manual for the
add-in board).
7Replace the sideplate and reinstall the screws as described on page 16.
8Connect all peripheral devices and AC power, and then turn on the computer.
Adding Memory
The computer has two memory slots. For memory upgrades, use only 3.3V 64-bit
PC-100 SDRAM DIMM modules. Sony computer supplies, accessories, and
peripherals can be purchased from your dealer or by contacting Sony at http://
www.sony.com/accessories.
Installing a PCI board in the PCV-J100
!Make sure you observe the proper safety precautions when you add DIMMs to
your Sony computer. See “Notes on Use” in the VAIO User Guide.

VAIO PCV-J100 Upgrading and Maintaining
6
To install memory:
1Shut down your computer and turn off all peripheral devices, such as your
printer.
2Unplug your computer and any peripheral devices.
3Remove the sideplate as described on page 3.
4If necessary, remove any cables, add-in cards, or other components to access
the DIMM sockets.
5Handle the DIMM only by the edges, and remove it from its anti-static
package.
6Locate the keys on the bottom edge of the DIMM.
7Align the DIMM over the socket.
8Firmly insert the bottom edge of the DIMM into the socket.
Installing memory in the PCV-J100
!To avoid damaging the DIMM socket, move the DIMM socket tabs slightly
outward to relieve pressure. The DIMM should then click easily into place.
Latch
Edge connectors
Center notch
Notch
Slot

Adding Memory
7
9Press evenly against the DIMM’s upper corners. The end latches snap into
position automatically.
10 Reinstall any add-in cards or components you removed.
11 Replace the sideplate and reinstall the screws, as described on page 16.

VAIO PCV-J100 Upgrading and Maintaining
8
Replacing the Lithium Battery
After several years, when the lithium battery starts to weaken, the system settings
stored in CMOS RAM, such as the date and time, may be wrong. When this
occurs, you need to replace the lithium battery.
To replace the lithium battery:
1Write down any changes you have made to the settings in the BIOS Setup
utility. If you have not made any changes to the BIOS settings, proceed to
step 2.
2Shut down your computer and turn off all peripheral devices, such as your
printer. Unplug your computer.
3Remove the sideplate as described on page 3.
4If necessary, remove any cables, add-in cards, or other components to access
the lithium battery.
5Remove the old battery and install the new battery with the plus (+) side up.
Installing a lithium battery in the PCV-J100

Replacing the Lithium Battery
9
6Replace the sideplate and reinstall the screws, as described on page 16.
!There is danger of the battery exploding if it is replaced incorrectly. You
must replace the battery only with a CR2032-type lithium battery. Discard
used batteries according to the instructions in the VAIO User Guide.
✍The values stored in the CMOS memory are now reset to the factory default
values. You must run the Setup utility to reset the date, time, passwords, and
other changes you may have made to the BIOS settings. If you do not wish to
customize your BIOS settings, you do not need to run the Setup utility. If you
simply wish to reset the date and time, see Windows®Help for instructions.

VAIO PCV-J100 Upgrading and Maintaining
10
Installing an Additional Hard Disk Drive
Your computer comes with an available internal bay to hold a second standard
3½-inch hard disk drive. (Some models, such as Configure-to-Order systems,
may already have a second hard disk drive.) The hard disk drive access light
blinks when either internal drive is active. For information on how to install
additional drives into the external drive, see the computer Reference Manual. You
can download the Reference Manual from the Sony Web site at http:///
www.sony.com/pcsupport.
1Configure the jumpers on the new drive as a slave (see your drive’s
documentation for configuration instructions).
2Remove the sideplate as described on page 3.
!Before opening the system unit, save any open files, exit Windows, turn off
the power of the computer and all attached peripherals, and then unplug the
power cord.
Installing a hard drive in the PCV-J100

Installing an Additional Hard Disk Drive
11
3Pull the drive holder secure lever and slide the drive holder up and out.
Removing the PCV-J100 drive holder

VAIO PCV-J100 Upgrading and Maintaining
12
4Slide the new drive into the drive holder and align the holes on each side of
the drive bay.
Removing the PCV-J100 drive holder (continued)

Installing an Additional Hard Disk Drive
13
5Secure the drive to the drive holder using the two holes on each side of the
drive holder (screws are provided with the new drive). Do not overtighten the
screws.
6Connect the second drive connector to the new drive. Be sure to orient the
connector so that pin 1 (the red side of the ribbon cable) is aligned with pin 1
of the new drive.
Attaching drive screws in the PCV-J100

VAIO PCV-J100 Upgrading and Maintaining
14
7Connect the second power connector to the new drive.
Attaching drive cables in the PCV-J100

Installing an Additional Hard Disk Drive
15
8Place the drive holder against the inside of the front chassis and slide it back.
Be sure to align the slots on the drive holder with the tabs on the inside of the
chassis. Be sure to slide the drive holder back so that the tabs slip into the
notch at the bottom of the slot.
9Push back the drive holder lever into the original position.
10 Replace the sideplate and reinstall the screws, as described on page 16.
Your computer automatically recognizes the new drive and configures itself
accordingly when you turn it on. Partition and format the new drive following the
instructions provided with the drive.
Replacing the drive holder in the PCV-J100

VAIO PCV-J100 Upgrading and Maintaining
16
Replacing the sideplate
1Align the sideplate to the chassis and slide it toward the front panel. Be sure
to slide the panel onto the unit so that the tabs slip into the lips on the unit.
2Replace the screw at the mid-right of the metal backplate.
3Gently press the frame until it clicks into place.
Replacing the PCV-J100 sideplate
