Sony PCV-LX920 - Vaio Slimtop Computer User manual

VAIO Slimtop™
Computer QuickStart

3
Contents
Welcome.................................................................5
Features......................................................................................... 5
Unpacking Your Computer ............................................................ 8
To Choose an Ergonomic Location
for your Computer....................................................................... 10
Setting Up Your
VAIO Slimtop Computer......................................11
To Set Up Your Computer ........................................................... 11
To Turn On Your Computer ......................................................... 16
To Register Your Computer.......................................................... 17
To Use the Stand by Mode .......................................................... 19
To Use the Hibernate Mode ......................................................... 21
To Shut Down Your Computer .................................................... 22
About the Software
on Your Computer ...............................................23
Overview of Software Titles ......................................................... 23
Troubleshooting ..................................................29
Topics.......................................................................................... 29
Notes on Use............................................................................... 42
For Answers to Your Software Questions.................................... 47
Resources ................................................................................... 50
Index .....................................................................51

VAIO Slimtop Computer QuickStart
4

5
Welcome
Congratulations on your purchase of the Sony VAIO® computer! Your
new, high-performance, multimedia computer combines state-of-the-art
computer functionality with the latest audio, video and information
technology features.
Features
VAIO AV Applications
This suite of Sony original applications includes PictureGear™, Smart Capture,
DVgate™, DigitalPrint, SonicStage™, MovieShaker™, VisualFlow™, and
Media Bar™ DVD Player. These software applications make it easy to use
advanced multimedia techniques to develop your personal audio and video
creations. Using the i.LINK ports, you can capture, view, and share both still and
video images, then catalog everything for fast, easy storage and retrieval.
i.LINK (IEEE1394) interface
Two built-in i.LINK® ports, located on the front and rear panels, provide you
with digital connection capability. The i.LINK name and logo identify a high-
speed communication interface, which allows you to easily connect compatible
digital camcorders.
✍Your computer may not be equipped with all of the hardware features listed in this
section. To view the specific hardware configuration for your system, see the
Specifications sheet.
✍i.LINK is a trademark of Sony used only to designate that a product contains an
IEEE1394 connection. The i.LINK connection may vary, depending on the software
applications, operating system and compatible i.LINK devices. All products with an
i.LINK connection may not communicate with each other.
Please refer to the documentation that came with your compatible i.LINK device for
information on operating conditions and proper connection. Before connecting
compatible i.LINK PC peripherals to your system, such as an optical or hard disk drive,
confirm their operating system compatibility and required operating conditions.

VAIO Slimtop Computer QuickStart
6
Sony Pen Tablet display
This 15-inch LCD pen tablet display creates a superb interface with your
software applications. You can use the supplied VAIO®Pen to draw, sketch, or
write directly onto the tablet screen. The Sony Pen Tablet combines the best
features of an active matrix screen with the control of a graphics tablet. Your
graphics tablet display has built-in Harman/Kardon®stereo speakers.
CD-RW/DVD Combo Drive
This versatile drive, which plays DVD-ROM, CD-ROM, CD-RW, and CD-R
media, utilizes optical technology that provides increased storage capacity and a
rich multimedia computing experience. This drive is the ideal solution for
making backups and archiving data, with the ability to store up to 650 MB of
removable, rewritable storage on a single rewritable CD. Save your movies,
videos and images to CD-R or CD-RW media, to share with family and friends.
AutoAlert E-mail Notification System
The AutoAlert™E-mail Notification System has custom software that
automatically downloads your e-mail on a preset schedule using Microsoft®
Outlook®Express software. An LED light on the display instantly lets you know
when new mail has arrived.
Sony Memory Stick media slot
The next generation of digital storage media is smaller than a stick of gum. Easily
deliver information between Memory Stick®media-equipped devices, such as
cameras, transferring images, sounds, data and text.
VAIO®Convertible keyboard
The innovative palm rest converts to a keyboard cover for a sleek look when your
keyboard is not in use. Four Programmable Power Keys (PPKs) let you launch
applications with the push of a button.
Compact system components
Enjoy the system’s versatility by positioning the components in an arrangement
of your choice.

Features
7
Sony audio and video quality
Take advantage of today’s advanced multimedia applications, games, and
entertainment software with the Sony high-fidelity audio system and high-
powered 3-D graphics.
Microsoft®Windows®XP Home Edition operating system
Your system includes this latest consumer operating system from Microsoft.
Preinstalled software
All the software on your computer is preinstalled, configured, and ready to use
right out of the box.
Communications
You have the choice of a variety of popular online services to browse the Internet,
access e-mail, send faxes, and much more.
Exceptional performance
Your computer includes an Intel®processor, a 10Base-T/100Base-TX Fast
Ethernet interface, and a V.90 compatible data/fax modem.*
* Actual upload and download speeds may vary due to line conditions, ISP support, and gov-
ernment regulations.

VAIO Slimtop Computer QuickStart
8
Unpacking Your Computer
Your computer may not be supplied with all of the accessories shown, depending
on the system configuration you purchased. For details on the accessories
supplied with your computer, see the Specifications sheet.
Manuals
❑VAIO Slimtop™ Computer QuickStart — Contains information on
unpacking and setting up your computer, supplementary updates, support
information, and software information.
❑The VAIO Slimtop™ Computer User Guide is available electronically on
your computer’s hard drive. To access the online manual:
1 Click Start in the Windows taskbar, then click VAIO Help and Support.
2 From the Help and Support menu, click VAIO User Guide.
Computer and Supplied Accessories
Power cord
System
unit
VAIO Convertible keyboard
Palmrest
Stand
Modem cable
Sony Pen Tablet display
(Shown in upright position)
Mouse
Pen stand
VAIO Pen
Pen tip removing tool
Pen tip replacements (5)

Unpacking Your Computer
9
❑Safety Information —Provides safety and legal information about your
VA I O ®computer.
❑Specifications —Describes the hardware and physical configurations of
your VAIO computer.
❑Microsoft®Windows®XP Home Edition guide —Explains how to use the
basic features of this Windows®operating system.
Recovery CDs
❑System Recovery CD(s) —Enables you to restore the software that shipped
with your computer if it becomes corrupted or is erased. System Recovery
CDs can only be used to restore the hard disk of the Sony computer you
purchased.
❑Application Recovery CD(s) —Enables you to reinstall individual
applications if they become corrupted or are erased.
❑Driver Recovery CD —Enables you to restore device drivers if they
become corrupted or are erased.
Software Library
The Software Library contains the Microsoft software license agreement and the
Sony end-user license agreement.

VAIO Slimtop Computer QuickStart
10
To Choose an Ergonomic Location for your
Computer
Before you get started, find the best location for your new computer.
Planning your workspace
❑Stable work surface —Use a stable work surface large enough to support
the computer and other peripheral equipment.
❑Ventilation —Leave at least eight inches of space on the left and back sides
of your computer to enable proper ventilation.
❑Placement of the keyboard, mouse, and other input devices —Place
your keyboard, mouse, and other input devices so that your arms and hands
are in a relaxed, comfortable position. The keyboard should be directly in
front of you. Adjust the level of the keyboard so that your lower arms are
parallel to the floor. Keep your wrists in a relaxed position when you are
using the keyboard—not angled up or down. Use the palmrest only briefly,
for resting. While typing, never use the palmrest or rest your hands on the
table. Position the mouse at the same level as the keyboard. Hold the mouse
with a relaxed hand, and use your whole arm to move it. Take breaks during
sessions with your computer. Excessive use of the mouse or a joystick may
strain muscles or tendons.
❑Furniture and posture —Sit in a chair with good back support and
armrests. Adjust the level of the chair so your feet are flat on the floor. A
footrest may make you more comfortable. Sit with relaxed, upright
posture—avoid slouching forward or leaning far backward.
❑Viewing angle of the display —Position the display 18 to 26 inches
directly in front of you, with the top of the screen at or a little below eye
level. Use the display’s tilting feature to find the best position. You can
reduce eye strain and muscle fatigue by placing the display in the proper
position.
❑Lighting —Choose a location where windows and lights do not create glare
and reflection on the display. Use indirect lighting to avoid bright spots on
the display. You can also purchase accessories for your display that help
reduce glare. Proper lighting adds to your comfort and work effectiveness.

11
Setting Up Your VAIO
Slimtop Computer
Your computer has many new and exciting features. This section contains
information on setting up your computer and peripheral devices.
To Set Up Your Computer
Attaching the stand to the system unit
1Place the system unit upside down, with the front of the system facing
towards you.
2Insert the stand pegs into the ventilation holes of the system. Place the wider
end of the stand at the rear of the unit as shown.
3Lock the stand onto the system unit by pressing down gently and pulling
forward slightly. The stand clicks into place.
Attaching the slimtop stand
✍The stand keeps the system cool by allowing air to flow under it. Place the system unit
in an upright position using the stand, to avoid overheating of the system unit.

VAIO Slimtop Computer QuickStart
12
Connecting the Sony Pen Tablet display
1Press the lock buttons on both sides of the LCD connector and connect the
LCD cable into the LCD port on the system.
2Release the connector when it clicks into place.
Connecting the Pen Tablet display
✍There are two holes in the base of the Pen Tablet display (on the right and left sides)
for routing the LCD cable to the system. Install your equipment so that you can easily
reach the power outlet in the event of an emergency.

To Set Up Your Computer
13
Connecting the keyboard and mouse
1Plug the keyboard cable into the Keyboard port on the Pen Tablet display.
2Plug the mouse cable into the Mouse port on the Pen Tablet display.
Connecting the keyboard and the mouse
KEYBOARD
USB MOUSE

VAIO Slimtop Computer QuickStart
14
Connecting the modem cable
1Unplug your phone cable from the wall jack and plug it into the Telephone
jack on the computer.
2Plug the modem cable (supplied) into the Line jack on the computer, and
then plug the other end into the wall jack.
Connecting the modem cable
Your computer has a protective sticker next to the Ethernet port located
on the rear panel. Connect only 10Base-T and 100Base-TX cables to the
Ethernet port. Using other cables or a telephone cable may result in an
electric current overload and can cause a malfunction, excessive heat or fire
in the port. For help on connecting to a network, see your network
administrator.

To Set Up Your Computer
15
Connecting the power cord
1Plug one end of the power cord into the AC Input port on the back of the
system.
2Plug the other end into a grounded AC wall outlet or power strip.
Connecting the power cord
✍When you plug the power cord into the wall outlet, the power indicators on the system
and LCD light up momentarily, and the fan turns on briefly. This is not a malfunction.

VAIO Slimtop Computer QuickStart
16
To Turn On Your Computer
Turning on your computer
Press the Stand by key on the keyboard to turn on the system and the Sony Pen
Tablet display, or press the Power button on the system unit.
✍When you start your system for the first time, your computer may detect new
equipment and display a dialog box that asks you to restart your computer. Please
respond to this request immediately.
Turning on your computer
✍Pressing any of the keys numbered P1 through P4 starts the computer and launches a
preset application.

To Register Your Computer
17
To Register Your Computer
Take advantage of Sony’s commitment to quality customer support and receive
these benefits by registering your computer:
❑Sony Customer Support —Communicate with a Support Representative
to troubleshoot problems you may be having with your computer.
❑Limited warranty —Protect your investment. See the Warranty Card for
more details.
Setting up your dial-up connection
The first time you turn your computer on, follow these steps to set up your dial-
up connection:
1Click Start from the Windows taskbar and select All Programs.
2Point to Accessories, point to Communications, and then click New
Connection Wizard. The Location Information window appears.
✍You are prompted to register your computer the first time you turn on the unit. Follow
the on-screen instructions to complete the registration process. If you are not able to
register your computer during the first session, you are provided with additional
registration opportunities later.
Location Information window

VAIO Slimtop Computer QuickStart
18
3Enter in your information as requested. Click OK. The Phone and Modem
Options window appears.
4Click to select your dialing location and then click OK. The New Connection
Wizard appears.
5Follow the onscreen instructions to finish setting up your Internet
connection.
Phone and Modem Options window
New Connection Wizard window

To Use the Stand by Mode
19
To Use the Stand by Mode
When you plan to stop using your computer for a short period of time, you can
put it in Stand by mode instead of turning it off completely. Putting the computer
in Stand by mode saves energy and allows a quick return to normal computer use.
You can use any of the following four methods for activating the Stand by mode.
Setting the computer to enter Stand by mode using the Stand
by key
Press the (Stand by) key on the top of the keyboard. The computer goes into
Stand by mode.
Setting the computer to enter Stand by mode using the
Windows taskbar
1Click Start in the Windows taskbar, then select Turn Off Computer.
2Select Stand by.
3Click OK. The computer goes into Stand by mode.
Setting the computer to enter Stand by mode using the Power
button
Briefly press the Power button on the front panel to place your computer into
Stand by mode.
Setting the computer to enter Stand by mode automatically
1Click Start in the Windows taskbar, click Control Panel, then select the
category, Performance and Maintenance. The Performance and Maintenance
dialog box appears.
2Click the Control Panel icon for Power Options. The Power Options
Properties dialog box appears.
✍Save your work, close all applications, and close your Internet connection, if
applicable. Leave the Windows® operating system running.

VAIO Slimtop Computer QuickStart
20
3Select the Power Schemes tab. Choose an option from the Power schemes
drop-down list.
4Click Apply and then click OK.
The computer will go into Stand by mode according to your settings.
Resuming from Stand by mode
There are two ways to bring your computer back from Stand by mode:
❑Press the space bar on your keyboard.
❑Briefly press the power button on your computer.
Stand by mode indicators
You can identify which mode the computer is in by the color of the power
indicator light.
✍To save the settings under a name that is not offered in the Power schemes drop-
down menu, choose your settings and then click Save As.
Color Mode
Amber Computer is in Stand by mode.
Green Computer is in Normal mode, ready to use.
No color Computer is turned off or in Hibernate mode.
