Sony VGC-V3M User manual

N
User Guide
VGC-V3 Series (PCV-E31M/PCV-F31M)

1
nN
Read this first
Read this first
Notice
©2005 Sony Corporation. All rights reserved.
This manual and the software described herein, in whole or in part, may not be reproduced, translated, or reduced to any machine-readable form without prior written
approval.
Sony Corporation provides no warranty with regard to this manual, the software, or other information contained herein and hereby expressly disclaims any implied
warranties or merchantability or fitness for any particular purpose with regard to this manual, the software or such other information. In no event shall Sony
Corporation be liable for any incidental, consequential, or special damages, whether based on tort, contract, or otherwise, arising out of or in connection with this
manual, the software, or other information contained herein or the use thereof.
Macrovision: This product incorporates copyright protection technology that is protected by U.S patents and other intellectual property rights. Use of this copyright
protection technology must be authorised by Macrovision, and is intended for home and other limited viewing uses only unless otherwise authorised by Macrovision.
Reverse engineering or disassembly is prohibited.
In the manual, the ™ or ®marks are not specified.
Sony Corporation reserves the right to make any modification to this manual or the information contained herein at any time without notice. The software described
herein is governed by the terms of a separate user licence agreement.
Please note that the illustrations in this manual may not necessarily apply to your model. Please see the Specifications sheet for the specific configuration
of your VAIO.

2
nN
Read this first
ENERGY STAR
As an ENERGY STAR Partner, Sony has determined that this product meets the ENERGY STAR guidelines for energy efficiency. The International ENERGY STAR
Office Equipment Program is an international program that promotes energy saving through the use of computers and their office equipment. The program backs the
development and dissemination of products with functions that effectively reduce energy consumption. It is an open system in which business proprietors can
participate voluntarily. The targeted products are office equipment such as computers, displays, printers, facsimiles and copiers. Their standards and logos are
uniform among participating nations.
ENERGY STAR is a U.S. registered mark.
Environmental information
Halogenated flame retardants are not used in cabinets.
Corrugated cardboard is used for packaging cushions.
Owner's record
The serial number, model number and product key are located on the back of your Sony desktop. Record the numbers and refer to
them if you call VAIO-Link. See also the printed Specifications sheet.

3
nN
Read this first
Safety information
General
❑Opening the unit, for whatever reason, could lead to damages that are not covered by the guarantee.
❑To avoid electrical shock, do not open the cabinet. Refer servicing to qualified personnel only.
❑To prevent fire or shock hazard, do not expose your VAIO desktop to rain or moisture.
❑If reporting a gas leak, do not use the modem or a telephone in the vicinity of the leak.
❑Avoid using the modem during a severe electrical storm.
❑Do not move your computer while the system is in Standby mode.
❑The magnetic properties of some objects can have serious consequences for your hard disk drive. They can erase the data on
the hard disk drive and cause the computer to malfunction. Do not place your computer near or on any objects, which emit
magnetic fields, mainly:
❑TV sets
❑Speakers
❑Magnets and magnetic bracelets.
You can find detailed safety information in the Regulations Guide.
Audio/video
Audio and picture distortion may occur if this equipment is positioned in close proximity to any equipment emitting electromagnetic
radiation.

4
nN
Read this first
Connectivity
❑Never install modem or telephone wiring during a severe lightning storm.
❑Never install telephone jacks in wet locations unless the jack is specifically designed for wet locations.
❑Take care when installing or modifying telephone lines.
❑To disconnect your VAIO completely from the mains voltage, unplug the power cable.
❑Make sure that the socket outlet is easily accessible.
Optical disc drive
The use of optical instruments can cause eye hazard. As the laser beam used in this product is harmful to the eyes, do not attempt
any disassembling process. For servicing, refer to qualified personnel only.

5
nN
Read this first
Regulatory information
Sony hereby declares that this product is in compliance with the essential requirements and other relevant provisions of European Directive 1999/5/EC
(radio equipment and telecommunications terminal equipment Directive).
Models with Wireless LAN: Models without Wireless LAN:
Declaration of Conformity
The European Union is targeting the free movement of goods for the internal market and to prevent technical barriers to trade. This effort has resulted in several EU
Directives asking that manufacturers make their products comply with essential standards. Manufacturers are required to affix the "CE" mark on the products they
sell and to draw up a "Declaration of Conformity" (DoC).
Primarily, the Declarations of Conformity are intended for the market surveillance authorities as proof that products satisfy the required standards. Additionally, Sony
provides these EU DoC's on the website www.compliance.sony.de as a service to our customers.
You can search for all Declarations of Conformity available for a specific product by typing in the model name in the search box. A list of matching documents will
be displayed and can be downloaded. Please note that the availability of declarations depends on the scope of the EU Directives and the individual product
specifications.
Before activating the built-in modem, please read the Regulations Guide.
You can find detailed safety information in the Regulations Guide.
If your model is equipped with Wireless LAN, please read the Regulations Guide before activating the Wireless LAN functionality.
Depending on the country, usage of the Wireless LAN functionality may be restricted. For country-specific details, please refer to the Regulations Guide. The
Wireless LAN PC functionality which is incorporated into this unit has passed Wi-Fi certification, and complies with the interoperability specifications established by
WECA (Wireless Ethernet Compatibility Alliance).

6
nN
Read this first
Disposing of the internal memory backup battery
❑Your Sony VAIO desktop is equipped with an internal back-up memory battery (motherboard battery) that should not have to be
replaced during the lifetime of the product. If you want to replace the battery, please contact VAIO-Link: www.vaio-link.com
❑Keep away from children.
❑Dispose of the battery properly at its end-of-life.
❑In some areas the disposal of non-hazardous batteries in household or business waste may be prohibited. Please use the public
waste collection system.
Disposing of the AA batteries
AA batteries are delivered with this VAIO (keyboard, mouse and remote control).
❑Do not handle damaged or leaking batteries.
❑Dispose of promptly and properly at end-of-life.
❑May explode or leak if recharged, disposed of in fire, mixed with other types of battery or
improperly installed.
❑Keep away from children.
❑In some areas, the disposal of batteries in household or business waste may be prohibited.
Please use the public waste collection system.

7
nN
Welcome
Welcome
Congratulations on purchasing a Sony VAIO computer. Sony has combined leading-edge technology in audio, video, computing
and communications to provide you with state-of-the-art personal computing.
As well as exceptional performance, here are the main features you can enjoy:
❑Sony audio and video quality – The high-quality internal speakers and graphics enable you to take advantage of today’s
advanced multimedia applications, games, and entertainment software.
❑Wireless setup – Thanks to the Wireless LAN (IEEE 802.11b/g) technology, you can communicate freely, without cables or wires.
❑VAIO Zone – Take advantage of this new software application, allowing you to enjoy music, video, and photos locally or through
a home networking environment. If your computer has TV tuner functionalities, you can also watch/record TV on your VAIO.
❑tvtv – tvtv takes your VAIO's TV functions to a new level. Never miss your favourite TV programme again, by remote-recording
it via the Internet onto your TV tuner-equipped VAIO. The tvtv Interactive Programme Guide gives you a comprehensive overview
of what's on when and automatically synchronises it with your VAIO, wherever you happen to be at the time.
❑Multimedia features – Make the most out of your audio and video CDs and DVDs, even record them yourself.
❑Sony Memory Stick PRO slot – This compact digital storage medium allows you to easily transfer images, sounds, data and
text between cameras, computers, and more.
❑Windows XP with Service Pack 2 – Your system includes the latest operating system from Microsoft.
❑Excellent customer support – If you are experiencing any problems with your computer, please check the VAIO-Link website
for a possible solution: www.vaio-link.com. Before contacting VAIO-Link, please try to solve the problem by using the search
functionality in Help and Support Center or by reading this guide, your printed Troubleshooting Guide, your printed Recovery
Guide or the manuals and help files for the peripherals or software.

8
nN
Welcome
Documentation pack
Your documentation pack contains printed information and user guides to read on your computer.
Guides are provided in PDF format, which you can easily browse through and print out.
The My Club VAIO portal is a perfect starting point to use your VAIO - a comprehensive collection of everything you need to get the
most from your PC.
The user guides are collected under Documentation, which can be shown as follows:
1Go to Start and click the My Club VAIO icon .
2Click Documentation.
3Select the guide you want to read.
✍You can manually browse to the user guides by going to My Computer > VAIO (C:) (your C drive) > Documentation > Documentation and opening the folder for your
language.
You may have a separate disc for the documentation of bundled accessories.

9
nN
Welcome
Printed documentation
The printed part of your documentation pack includes the following:
❑A Specifications sheet, containing a table of specifications, a list of bundled software and, on the reverse side, a guide to setting
up your VAIO;
❑A Troubleshooting Guide, where you will find VAIO-Link information and solutions to common problems;
❑A Recovery Guide, where you will find an explanation about the recovery process of your VAIO;
❑Booklets containing the following information: Sony Guarantee conditions, Safety Regulations, Modem Regulations and
Wireless LAN Regulations.
Help and Support Center
Help and Support Center is a comprehensive resource for practical advice, tutorials, and demonstrations to help you learn to use
Microsoft Windows XP and your VAIO. Use the Search feature, Index, or table of contents to view all Windows Help resources,
including those that are on the Internet.
To access Help and Support Center, proceed as follows:
1Go to Start.
2Click Help and Support.

10
nN
Welcome
My Club VAIO
In My Club VAIO, you can find:
Documentation, which gives you:
❑Access to the User Guide. This guide explains the features of your VAIO in detail, how to use these features confidently and
safely, connect peripheral devices and more.
❑Access to Help and Training. This is the portal of VAIO Help and Support Center.
❑Important information about your computer, in the form of notices and announcements.
In My Club VAIO you can also find:
Accessories
Want to expand the capabilities of your VAIO? Click on this icon and have a look at your compatible accessories.
Software
Feeling creative? Click this icon for an overview of your software and check out our upgrade options.
Wallpapers
Click this icon and check out our most popular Sony and Club VAIO wallpapers.
Links
Click this icon and check out our most popular Sony and Club VAIO websites.
Further sources
❑Consult the Online Help files of the software you are using for detailed information on features and troubleshooting.
❑Go to www.club-vaio.com to find online tutorials about your favourite VAIO software.

11
nN
Welcome
Ergonomic considerations
Whenever possible, try and take into account the following ergonomic considerations when using your new computer, whether at
home or in the office:
❑Position of the keyboard and mouse – Make sure the keyboard is directly in front of you. Keep your forearms horizontal, with
your wrists in a neutral, comfortable position while using the keyboard or mouse – not at an angle. Let your upper arms hang
naturally at your sides. Place the mouse at the same level as the keyboard and use your whole arm to move it.
❑Position and viewing angle of the display – Set the display at a comfortable viewing distance. Make sure the display screen
is at eye level or slightly lower. Use the display’s tilting feature to find the best position. You can reduce eye-strain and muscle-
fatigue by adjusting the tilt of the display to the proper position. Remember to adjust the brightness setting of the display.
❑Furniture and posture – Sit in a chair with good back support. Adjust the level of the chair so your feet are flat on the floor. A
footrest may make you more comfortable. Sit in a relaxed, upright posture and avoid slouching forward or leaning too far
backwards.
❑Lighting – Choose a location where windows and lights do not create glare or reflection on the display. Use indirect lighting to
avoid bright spots reflecting on the display. Proper lighting adds to your comfort and work effectiveness.
❑Ventilation – Make sure you leave at least 25 cm of space behind and on each side of the main unit.
❑And finally – Remember to have breaks during sessions with your computer. Excessive use of the computer may strain muscles
or tendons.

12
nN
Using your VAIO
Using your VAIO
Once you have read and followed the information on the printed Specifications sheet, you can start using your computer safely and
confidently. Read on to get the most out of using your VAIO computer.
❑Shutting down your computer safely (page 13)
❑Using the keyboard (page 14)
❑Using the pointing device (page 18)
❑Using the mouse (page 20)
❑Using the TV function (page 23)
❑Using the disc drive (page 24)
❑Using the modem (page 27)
❑Using power modes (page 28)
❑Using the Memory Stick (page 30)
❑Using PC Cards (page 33)
❑Using Wireless LAN (WLAN) (page 35)

13
nN
Using your VAIO
Shutting down your computer safely
It is important that you shut down your computer properly so you do not lose unsaved data.
To shut down your computer, proceed as follows:
1Turn off any peripherals connected to your computer.
2Click the Start button.
3Click Turn Off Computer.
The Turn off computer window appears.
4Click Turn Off.
5Respond to any prompts warning you to save documents or to consider other users and wait for your computer to turn off
automatically.
The power indicator turns off.
✍See the printed Troubleshooting Guide if you have problems shutting down your computer.

14
nN
Using your VAIO
Using the keyboard
Your VAIO is delivered with a wireless keyboard. You can place the keyboard anywhere you find comfortable within a range of
10 m* from the main unit.
The keyboard has a standard key arrangement and additional keys that perform specific functions. For more information on the
standard keys and shortcuts, please go to Help and Support Center (Start > Help and Support). The VAIO-Link website
(www.vaio-link.com) also contains glossary information to help you use the keyboard.
* Effective usage distance depending on the environment.

15
nN
Using your VAIO
KEY FUNCTION
1Standby Press the button to place the computer in Standby mode. Press the power button or Standby key briefly to resume normal
operation.
2Numeric keypad Use the numeric keypad to type numbers or to perform basic maths calculations. Press the Num Lock key to activate the
numeric keypad. Press the Num Lock key again to deactivate the numeric keypad.
3Directional arrows The Up, Down, Left, and Right arrow keys move the pointer on the screen.
4Applications The Applications key displays a shortcut menu in certain software programmes. Pressing this key is equivalent to clicking
the right mouse button.
5 Pointing device See Using the pointing device (page 18) for more information.
6Windows The Microsoft Windows key displays the Start menu. Pressing this key is equivalent to clicking Start on the taskbar.

16
nN
Using your VAIO
7<Fn> key Used in combination with other keys to execute commands.
<Fn>+<F2>: Turns off the speaker sound.
<Fn>+<F3>: Decreases the volume of the speakers.
<Fn>+<F4>: Increases the volume of the speakers.
<Fn>+<F5>: Decreases the brightness of the display screen.
<Fn>+<F6>: Increases the brightness of the display screen.
8Function keys The 12 function keys along the top of the keyboard are used to perform certain tasks. The task associated with each function
key may vary from one application to the next.
9LEDscreen Num Lock:
Turns on when the number keys in the numeric keypad are active.
Caps Lock:
Turns on when the letters appear in uppercase as you type. The <Shift> key lowers the case of typed characters when
Caps Lock is on.
Scroll Lock:
Turns on when the screen scrolls differently (not all applications support this function).
10 Battery compartment Storage compartment for the AA batteries.
11 Keyboard feet Extend to adjust the keyboard height.
12 CONNECT button Press to enable the keyboard to communicate with the system unit.
KEY FUNCTION

17
nN
Using your VAIO
Before you use the keyboard
Before attempting to use the wireless keyboard, you must enable communication between the computer and the keyboard.
Four AA batteries, for use in the wireless keyboard, are supplied with your VAIO.
To connect the wireless keyboard, proceed as follows:
1Insert the 4 AA batteries (1) into the wireless keyboard as shown.
2Turn on the computer.
3Slide the power switch on the right-hand side of the keyboard to
turn on the keyboard (2).
4Press the CONNECT button on the right panel of the computer (3).
5Turn the wireless keyboard over and press the
CONNECT button (4). Communication between the wireless
keyboard and the computer is now active.
✍Steps 4 and 5 must be carried out within 10 seconds of each other.
If your wireless keyboard does not operate properly, the batteries may need to be
replaced. Always use the same type and brand of batteries. If your wireless keyboard is
not being used for extended periods of time, remove the batteries to avoid possible
damage from battery leakage. Do not place other wireless devices or metal objects near
your VAIO or wireless keyboard, as this may cause interference. Do not obstruct the
communication between your wireless keyboard and your VAIO.
If you want to put the keyboard in a more ’ergonomical’ position, open the keyboard feet.

18
nN
Using your VAIO
Using the pointing device
The keyboard features a pointing device (1), which controls the cursor on the screen. You can point to, select and drag objects on
the screen using the built-in pointing device.
Action Description
Point Slide one finger on the pointing device to place the pointer (2) on an item or object.
Click Press the left button (3) once.
Double-click Press the left button twice.
Right-click Press the right button (4) once. In many applications, this action displays a shortcut menu.
Drag and select Slide one finger while pressing the left button.

19
nN
Using your VAIO
Before using the pointing device
Before attempting to use the pointing device, you must activate it.
To activate the pointing device, proceed as follows:
1Fold the keyboard out.
2Turn on the Pointing Device switch (1).
3Close the lower part of the cover as shown (2).
You can now use the pointing device together with your keyboard.
4If you only want to use the pointing device, close the cover completely
as shown (3).
