Sony VGN-UX230P - VAIO UX Series Micro PC User manual

VGN-UX230P
VAIO®UXSeriesMicroPC
TheVAIO®UXMicroPCisdesignedforfull-sizecomputingina
pocket-sizepackage.
ULTRA-PORTABLE DESIGN.
The VAIO®UX Micro PC is so small and lightweight you won’ t believe it ’s a full-functioning PC.
But this remarkably compact dynamo is designed for productivity on the go. With a 4.5 ” wide
SVGA (1024x600) display with XBRITE™LCD technology, Intel®Core™Solo Ultra Low Voltage
CPU for fast processing, and Microsoft®XP Professional operating system on board. And
because this is a full-functioning PC using the OS you already know, application user
interfaces are familiar and easy to use. Advanced Wireless capabilities are built right in, and
expansion is a breeze with the included port replicator.
A TRULY MOBILE WIRELESS COMPANION.
True mobility is about broad access, just as much as it is about slim, lightweight design. And
the VAIO®UX Micro PC is taking that access farther than ever before. With integrated wireless
Wide Area Network (WAN) technology, you can access the Cingular Wireless EDGE network to
extend your wireless coverage beyond LAN access networks and hotspots. And with
integrated wireless LAN and Bluetooth®technology , the VAIO®UX Micro PC gives you the
freedom to go farther, do more, and stay connected.
COMMUNICATION ON THE GO.
The VAIO®UX Micro PC is communications-ready, with integrated camera and built-in
microphone and speakers, so you’re equipped to communicate via VoIP virtually anywhere
WLAN or WWAN service is available.
INGENIOUS DESIGN.
An integrated keyboard and stylus allow you to choose the input method you prefer. VAIO®
Touch Launcher and Instant Command enable quick and easy program access, and the
biometric fingerprint sensor stores your passwords so you can access applications and
secure web sites without having to type them. And the UX Micro PC really makes smart use of
all its display space. With control buttons for zooming, scrolling, and a stick pointer, as well
as the ability to view in either landscape or portrait orientations, you know you’ll be able to
view documents, applications, and media in the most appropriate way.
TheVAIO® UXMicroPCputstheworldin your pocket andatyour
fingertips.Theultra- portablefull -functioningPCwitha4.5 ” wide
SVGAscreen ,Intel® Core ™SoloULVCPUandMicrosoft®XP
Professionaloperatingsystem,aswellasintegratedwirelessLAN ,
wirelessWAN ,Bluetooth®technology ,andcommunications -
focused hardwarebuiltrightin, designed forproductivityonthe go.
11
13
3
3
5
12
3
13
11
3
13
5
12

SonyElectronicsInc. • 16530ViaEsprillo • SanDiego,CA92127 • 800.222.7669 • www.sony.com
LastUpdated:12/08/2006
VGN-UX230P
VAIO®UXSeriesMicroPC
Specifications
General
ComputerType: MicroPC
TypeofUse: UltraPortable
ActionButtons: MouseLeft,MouseRight,Scroll,
MagnifyScreen(ZoomIn/Out),Capture,Center
Button,WirelessLANOn/Off,VAIOTouchLauncher
PointingDevice: Pointer
Security:BiometricFingerprintSensor
Hardware
Keyboard:64keyswith0.15mmstrokeand8.6mm
pitch
Camera:2Built-inCameras(front:0.3Mpixelsandback:
1.3Mpixels)
Built-inmicrophone
Processor
Type:Intel®Core ™ SoloProcessorU1200
UltraLowVoltage
Speed:1.06GHz
FrontSideBusSpeed: 533MHz
L2Cache: 2MB
Technology:Intel®Centrino®MobileTechnology
Memory
Type:DDR2
Installed:512MB(PC2-3200)
Maximum:512MB
Speed:400MHz
Hard Drive
Capacity:30GB
Speed:4200rpm
Interface:UltraATA
ImpactProtection: Yes(G-Sensor ™ ShockProtection)
Audio
SoundSystem: Windows ®soundsystemcompatible
withBuilt-inmonauralspeakers
Display
ScreenorDisplayTechnology: SVGA
ScreenSize: 4.5"
Resolution:1024x600
XBRITE™LCDTechnology: Yes
Graphics
Processor:Intel®GraphicsMediaAccelerator950
VideoRAM: 128MB[DynamicallyShared(RAM/Video)
Memory]
Chipset:Intel®945GMS
Inputs and Outputs
EthernetPort: 1
HeadphoneJack: 1
i.LINK®Interface:1
MemoryStick®MediaSlot: 1-SupportsOptional
MemoryStickDUO ™ mediawithMagicGate®
functionality
MicrophoneInput: 1
PortReplicatorConnector(s): 1(Bottom)
USBPort(s): 1(2.0compliant)
1
2
11
DC- In: 1
Networking/Modem
EthernetProtocol: FastEthernet(RJ-45)
EthernetSpeed: 10Base-T/100Base- TX
WirelessLAN: Intel®PRO/Wireless3945ABGNetwork
Connection(802.11a/b/g)
WirelessWAN: IntegratedWirelessWideArea
Network(WAN) accessingCingularWireless
NationalEDGENetworkwithSmartWi ™ technology
(WirelessWANandWirelessLANradiodonot
transmitsimultaneously)
Bluetooth®Technology:IntegratedBluetooth®
Technology
Power
BatteryType: StandardLithium-ionBattery(VGP-
BPS6)
EstimatedBatteryLife: 2.5-4.5hours (Standard
Battery),5.0-9.5hours (LargeCapacityBattery)
PowerRequirements: 41W+10%
Software
OperatingSystem: Microsoft® Windows ®XP
ProfessionalwithSP2
SuppliedSoftware: Microsoft®Works8.5
60-DayTrialVersionofMicrosoft®Office2003
60-DayTrialVersionofMicrosoft®DigitalImage
StarterEdition2006
Sony®OriginalSoftware: ImageConverter -PSP ™
Transfer
SmartWi ™ ConnectionManager
SonicStage®-DigitalMusic
VAIOMedia ™ -NetworkFileSharing
VAIO®TouchLauncher
60-minuteTrialVersionofJeopardy®
60-minuteTrialVersionofWheelofFortune®
SecurityandAnti-VirusSoftware: Norton®Internet
Security ™ 60-DaySubscription
TrendMicro ™ Anti-Spyware(30-DayTrial)
VAIO®RecoveryWizard
VAIO®SupportCentral
VAIO®SecurityCenter
VAIO®Update
Service and Warranty Information
LimitedWarranty: 1YearLimitedWarranty
TelephoneSupport: 1year(toll-freetechnical
telephoneassistance,available24/7)
OnlineandEmailSupport: Supportavailablefrom
http://www.esupport.sony.com
Dimensions
Weight:1.2lbswithstandardbattery(weightis
approximateandmayvary)
Measurements:5.91”(W)x3.74”(H)x1.27-1.50”(D)
Supplied Accessories
CingularSIMCard
StandardLithium-ionbattery(VGP-BPS6)
ACAdapter(VGP-AC16V7)
PortReplicator(VGP-PRUX1)-14- pini.LINK ®
interface ,3USB2.0,Ethernet,VGA-Out,A/V-outand
DC-in
SoftCarryingCase
PowerCord
Stylus
VGA/LANAdapter -Ethernet,VGA-OutandA/V-Out
Strap
3
13
5
7
7
10
14
8
9
6
Optional Accessories
AdditionalPortReplicator(VGP-PRUX1)
LargeCapacityBattery(VGP-BPL6)
Bluetooth®WirelessMouse(VGP-BMS30)
40GB Ultra-portableHardDrive(VGP-UHDP04)
ACAdapter(VGP-AC16V7)
LCDProtectionSheet(VGP-FLS8)
2-PackStylus(VGP-ST1)
Bluetooth®GPSReceiver(VGP-BGU1)
DVD±RDL/DVD±RWDrive (VGP-DDRW4)
Color:Silver
UPCCode: 027242713024
1.GHz denotesmicroprocessor internalclock speed; otherfactorsmay
affectapplication performance.CPU speedwill be reducedunder
certainoperating conditions.
2.GB meansone billionbytes when referringtohard drivecapacity.
Accessiblecapacity mayvary. Aportion of harddiskspace isreservedas
arecovery partition.
3.Requires compatiblewireless LANaccess point, soldseparately.Internet
connectionmay requirefees.
4.DVD Media/Formatsare notuniversally compatible.
5.Interoperability amongBluetooth®devices varies.
6.i.LINK isa trademarkof Sony usedonlyto designatethata product
containsan IEEE1394 connector.All products withani.LINK connector
maynot communicatewith eachother.
7.Actual batterylife mayvary based onproductsettings, usagepatterns
andenvironmental conditions.
8.See actuallimited warrantyfor details. Foracopy ofSony ’ swarranty,
pleasevisit
www.sony.com/pcsupport,call toll - free888 - 476 - 6972(888 - 4SONYPC),or
writeto SonyElectronics, 12451Gateway Boulevard, FortMyers,FL
33913.
9.For certainthird partysoftware applications, Sonyprovidesfirst level
PhoneSupport. Additionaltelephone supportmay be availablefrom
theapplicable 3rdparty vendor.Availability and scheduleforany such
supportis determinedby theapplicable software vendor.
10.The MicrosoftOffice 200360 - DayTrial software isintended for
evaluationpurposes only.This trialsoftware is installedonyour system
andyou mustactivate thesoftware before youcanuse it.Product
activationprocedures willbe detailedduring initial launchofthe
software;activation requiresInternet access.This software hasan
expirationdate of60 daysfrom date offirstuse, atwhichtime the
softwarewill operateunder reduced - functionalitymode, limitingend -
useoptions andoperations.
11.Viewable areameasured diagonally.
12.Broadband Internetservice requiredalong with third - partyservices
whichmay requirea subscriptionfee or otherservicefee.
13.Subscription with CingularWireless required. See
www.sonystyle.com/cingularfor complete offerdetails, price plans,
serviceterms andconditions andcoverage map. Call1 - 888 - 739 - VAIO
(8246)for serviceactivation.
14.The MicrosoftDigital ImageStarter Edition 200660 - DayTrial software
includedwith thiscomputer systemis intended forevaluationpurposes
only.The softwarehas beenpartially installed andyoumust complete
installationof thesoftware beforeyou can useit.This softwarehasan
expirationdate of60 daysfrom date offirstuse, atwhichtime the
softwarewill operateunder reduced - functionalitymode, limitingend -
useroptions andoperations.
ComputerInterface: Thecomputer industrylacks standards, andtherefore,
thereare amultitude ofvarying software packagesandadd - onhardware
options.This personalcomputer isnot manufactured tooperateany
specificsoftware, andSony doesnot and cannotmakeany warrantyor
representationwith respectto theperformance of thisproductwith any
particularsoftware packagesand/or non - Sonyadd - onhardware options
exceptthose mentionedin thisdocument. Sony herebydisclaimsany
representationsor warrantythat thisproduct is compatiblewithany
combinationof productsyou maychoose to connect.WhileSony
representativesor Sonyauthorized dealersmay be abletoassist youand
maymake recommendations,they areNOT authorized tovaryor waivethis
disclaimer.Purchasers mustdetermine forthemselves the suitabilityand
compatibilityof thehardware andsoftware in eachandevery particular
instance.Software titlespre - installedon the SonyNotebook Computer are
subjectto changewithout notice.Simulated graphic shownondisplay. Pre -
installedsoftware maynot beidentical to retailversionsor haveall
documentation.This productmeets thestandards of theInternational
EnergyStar Programfor energyefficiency. Features andspecifications
aresubject tochange withoutnotice. Non - metricweights and
measurementsare approximate.
©2006Sony ElectronicsInc. Allrights reserved. Reproductioninwhole orin
partwithout writtenpermission isprohibited. Sony, i.LINK,MemoryStick,
SonicStage,VAIO, XBRITE,G - Sensor,Sound Reality, MemoryStick Duo,
SmartWi,MagicGate, VAIOMedia andlike.no.other are trademarksofSony.
Inteland Centrinoare registeredtrademarks and Coreisa trademarkof
IntelCorporation. Microsoftand Windowsare registered trademarksof
MicrosoftCorporation. CingularWireless isa registered trademarkof
CingularWireless LLC2005. Allother trademarks aretrademarksof their
respectiveowners.
Printedin U.S.A.12/06.
