Sony VPCL116FX User manual

VPCL116FX/B
VAIO® L Series All - in - One Touch Screen
The touchscreen PC that ’s also an HDTV.
EXTREME PC PERFORMANCE
Enjoy the powerful performance of an Intel ® Core™2 Quad Q8400S processor
(2.66GHz ) with 6GB of pre - installed system memory.
The VAIO ® L All - in - One comes pre - installed with Genuine Microsoft ® Windows ® 7 Home
Premium .
Store your digital photos, HD Videos, TV programming and important documents on the
roomy 500GB (7200rpm) hard disk drive.
Tackle virtually any graphics requirement with a NVIDIA ® GeForce ® GT 240M GPU and
1GB of dedicated video RAM.
GO AHEAD. TOUCH IT.
A cutting edge multi - touch screen allows for simple, intuitive touch access to internet
and digital TV, social networks, photos, movies and more. Easily scroll, zoom and rotate
by flicking, pinching, twisting and tapping.
BORN FROM SONY ® HD TECHNOLOGY
A 24 widescreen display (1920 x 1080) and stunning LCD technology delivers vibrant
colors and dazzling picture clarity in full 1080 high definition.
A Blu - ray Disc™optical drive lets you playback HD movies in crystal - clear resolution.
ENDLESS FEATURES
An independent HDMI™input lets you connect compatible cable/satellite set - top -
boxes, Sony ® PS3 ™systems or other HDMI enabled devices without booting up into
Windows ® (HDMI™cable sold separately).
Never miss a minute of your favorite programming again. Integrated NTSC / ATSC TV
tuner let you watch and record live TV including local and over - the - air HD channels.
Extend the reach of your touchscreen PC with A2DP Bluetooth ® technology . It's ideal
for advanced wireless communication and streaming uncompromised CD - quality
stereo music to Bluetooth ® technology enabled speakers or headphones.
Picture in Picture lets you watch TV and use your PC at the same time while connecting
a cable or satellite set - up box via the HDMI ™input.
SOFTWARE YOU CAN TOUCH
Bring your media to life with VAIO Media Gallery software. With a simple and intuitive
touch interface and the magic of Sony ’ s intelligent analysis technologies you can
experience your photos, music and videos in new and exciting ways.
A contemporary high - definition PC/TV with a stunning 24 ” (diag.) multi -
touch screen that allows intuitive touch access to internet and TV, Blu - ray
Disc™movies, music, social networks, photos and more. With a Blu - ray
Disc player and HDMI™in, it’s the ultimate multimedia machine for any
room in the house.
1
6
8
15

Sony Electronics Inc. • 16530 Via Esprillo • San Diego, CA 92127 • 1.800.222.7669 • www.sony.com
Last Updated: 09/27/2010
VPCL116FX/B
VAIO® L Series All - in - One Touch Screen
Specifications
General
Computer Type: Desktop
Type of Use: All - in -One
Hardware
Keyboard: QWERTY, 19.05 mm pitch, 2.7 mm stroke
Action Buttons: Action Buttons on Keyboard -Standby,
VAIO, Volume -/ +, Muting, Zoom In, Zoom Out
Action Buttons on PC -PC On / Off, Display off
Camera: Built -in MOTION EYE® camera and microphone
with face-tracking technology (640x480) VGA
Processor
Type: Intel® Core™ 2 Quad Processor Q8400S
Speed: 2.66GHz
Front Side Bus Speed: 1333MHz
L2 Cache: 4MB
Memory
Installed: 6GB PC2 - 6400 (2GBx3)
Maximum: 12GB
Type/Speed: DDR2/800MHz
Hard Drive
Capacity: 500GB
Speed: 7200rpm
Type: Serial ATA
Optical Drive
BD-R DL Read: 5x max
BD-R Read: 5x max
BD-RE DL Read: 5x max
BD-RE Read: 5x max
BD-ROM Read: 5x max
CD Support: Read / Write (CD/-R/-RW)
DVD Support: Read / Write (DVD±R/±RW/±R DL/-RAM)
Expansion Slots
Multimedia Card Reader: One Memory Stick PRO™
(Standard / Duo) media slot with MagicGate®
functionality
One Secure Digital (SD memory card) media slot
Audio
Sound System: Intel® High Definition Audio with Dolby®
Digital Live
Speakers (Total): Built -in 2 x 5.5 Watt stereo speakers
Display
Screen Size: 24" Touchscreen
Resolution: 1920 x 1080
Technology: Full HD
Graphics
Processor: NVIDIA ® GeForce® GT 240M GPU with Total
Available Graphics Memory of 3807MB (max.)
Video RAM: 1GB dedicated Video RAM
Chipset: Intel® P43 Express Chipset
TV Tuner: Yes -NTSC / ATSC
Inputs and Outputs
Audio In: 1 (Line In)
Microphone Input: 1
USB Port(s): 5 (2.0 compliant)
i.LINK® Connection: 1 (4pin) i.LINK® connector (IEEE
1394)
Headphone Output(s): 1
S/PDIF Output(s): 1
Ethernet Connection (s): 1
HDMI™Input: 1
Power
Input Voltage: 100 - 240V
1
7
10
9
Start - up Times
Average Boot Time: 60 sec
Average Resume Time from Suspend: 2 sec
First Boot Time: 5 min
Wireless/Networking
Ethernet Protocol: 10Base - T / 100Base - TX / 1000Base -T
(Gigabit)
Ethernet Speed: Fast Ethernet (RJ- 45)
Wi- Fi: (802.11b/g/n)
Bluetooth® Technology: Integrated Stereo A2DP (2.1 +
EDR)
Software
Operating System: Genuine Microsoft® Windows® 7
Home Premium 64- bit
Supplied Software: Microsoft® Works SE 9.0 w/ 60 - Day
Trial Version of Microsoft® Office Home and Student
2007
The VAIO® Software Experience: VAIO Care™-System
diagnostics and maintenance
VAIO® Multimedia Suite: VAIO ® Media Gallery -Touch
friendly multimedia management software
VAIO ® Movie Story -Simple Movie Creation
VAIO ® Media plus -Multimedia Streaming Software
*Please access VAIO® Help and Support from your
PC for a complete list of software applications and
trials.
Anti -Virus Software: Norton Internet Security™ 2009 30 - Day
Trial Offer
Service and Warranty Information
Telephone Support: 1 year toll -free technical assistance
available 24/7 at 888 - 476 - 6972
Online and Email Support: Available from
http://www.esupport.sony.com/EN/VAIO
Onsite/In-Home Service: 1 year limited warranty with
Onsite/In-Home Service . See actual warranty for
details.
Limited Warranty Term: 1 year limited warranty . See
actual warranty for details.
Environmental Information
EPEAT ™: Silver
RoHS®: Compliant
ENERGY STAR®: 5.0
Dimensions
Weight: 27.6 lbs. (CPU and Display only)
Measurements: 22.9"(W) x 16.9"(H) x 7.4"(D) (CPU and
Display only)
Supplied Accessories
Power Cord
Wireless Keyboard
Wireless Mouse
Remote Control
Batteries
Color: Black
UPC Code: 027242780378
1.GHzdenotesmicroprocessorinternalclockspeed;otherfactorsmay
affectapplication performance. CPU speed will be reduced under
certain operating conditions.
2.GBmeansonebillion bytes when referring to hard drive capacity.
Accessiblecapacitymayvary.Aportionof hard disk space is
reservedasarecoverypartition.
3.Requires802.11ncompatibleaccesspoint.Somefunctionalitymay
requireInternetservices.
4.BroadbandInternetservicerequiredalongwiththirdpartyservices
whichmay require a subscription or other servicefee.
5.Compatibilityandperformanceina64bit environment may vary.
Checkwith the manufacturer ofyoursoftwareor accessory to ensure
youhave the latest updates.
6. Viewable area measured diagonally.
7.Non - metricweights and measures are approximate and mayvary.
8.Measuredatthenarrowestpoint
9.i.LINKisa trademark of Sony used only to designate that a product
containsanIEEE 1394 connector. All products with an i.LINK
connectormaynotcommunicatewitheachother.
10.TotalAvailable Graphics Memory refers to the new Windows ®7
classificationofgraphics memory, which varies depending on the
operatingcondition, version of device driver and systemmemory size.
17
17
18
3
15
5
13
16
12
14
11
8
11.Seeactuallimitedwarrantyfordetails.ForacopyofSony'swarranty,
please visit www.esupport.sony.com, call toll - free888 - 476 - 6972(888 -
4SONYPC),or write toSonyElectronics,12451 Gateway Boulevard,
FortMyers,FL33913.
12.Forcertainthird party software applications, Sony provides first level
phonesupport.Additional telephone support may be available from
theapplicable3rdpartyvendor. Availability and schedule for any
such support is determined by the applicable software vendor.
13.60 - DayTrial Version of Microsoft ® Office2007 - Thistrial softwarewill
workonlyfor60daysafteryou first use it. You will not be able to use
thesoftwareifyoudonotactivateitasdescribedthefirsttimeyou use
thesoftware. You can activatethesoftware by Internet: Internet
servicechargesmayapply.Ifyouwant to keep using the software
afterthe60 - daytrial period, youmustconvertto the perpetual
version.Youcanconvertonlinebyfollowingthe conversion
instructions presented during setup and paying the required fees.
14.When available, Sony will provide Onsite/In - HomeServicein
fulfillmentofitslimited warranty obligations. Any such services are
subjecttothe terms and conditions of the limited warranty. See
actualLimited Warranty for details. Onsite/In - HomeServicewill be
providedvia third - partytechniciantobedispatched as needed
following phone - basedtroubleshooting. Some repairs may be
accomplishedwith self repair kits. Onsite/In - HomeServicemaynot be
available in all locations.
15.Interoperability and compatibility among Bluetooth ®devicesvary.
16.NortonInternetSecurity™200930 - day subscription is pre - installed
onyour Sony VAIO PC. Youneedtoactivate the software for the
producttowork.Afteryour30 - daysare finished, buy Norton Internet
Securityto continue to beprotectedfrom viruses, hackers and
identifytheft.
17.Basedonoriginalfactoryimageandwill vary with product
configurationchanges and additional software added tothe hard
drive.
18. Excluding end user interaction.
ComputerInterface:For this product,there are a multitude of varying
software packages and add - onhardwareoptions.Thisproductisnot
manufacturedtoworkwith any specific software, and Sony does not and
cannotmake any warranty orrepresentationwith respect to the
performanceofthisproductwithanyparticularsoftwarepackages
and/or non - Sony add - onhardwareoptionsexcept those mentioned here.
Sonyhereby disclaims anyrepresentationsorwarranties that this
product is compatible with any combination of non - Sonyproductsyou
maychoose to connect toit.WhileSony representatives or Sony
authorizeddealersmaybeableto assist you and may make
recommendations,they are NOT authorizedtovary or waive this
disclaimer.Purchasers must determine for themselves the suitability and
compatibilityofthehardwareandsoftwareineachandevery particular
instance.Software titles pre - installedon the Sony computer are subject
tochangewithoutnotice.Preinstalledsoftwaremaynotbeidenticalto
retailversionsorhave all documentation. Features and specifications are
subjectto change without notice. Non - metricweights and measuresare
approximateand may vary.
Lampinthisproductcontainsmercury.Disposalofthesematerialsmay
beregulatedduetoenvironmentalconsiderations.Thisproductmeets
thestandards of the InternationalEnergyStar Program for energy
efficiency.Fordisposal or recycling information, please contact your local
authoritiesor the Electronic Industries Alliance (www.eiae.org).
©2009Sony Electronics Inc. Allrightsreserved.Reproduction in whole or
inpartwithoutwrittenpermissionisprohibited.Sony,i.LINK,VAIO,VAIO
Care,Sonylogo, VAIO logo, MOTIONEYEandMemory Stick PRO are
trademarksofSonyintheU.S.and in other countries. Intel and Core are
trademarksoftheIntelCorporationintheU.S.andinothercountries.
Microsoft,WindowsLive,andWindows are registered trademarks of the
MicrosoftCorporation in the U.S. and inothercountries. Blu - rayDiscis a
trademark.Bluetooth and theBluetoothlogoare registered trademarks
ofSIG,Inc.DolbyisaregisteredtrademarkofDolbyLaboratories.ENERGY
STARis a registered U.S. trademark.HDMIis a trademark of HDMI
LicensingLLC. PS3 is atrademarkofSony Computer Entertainment. All
othertrademarksaretrademarksoftheirrespectiveowners.
Printed11/09.
