Sony DSC S730 - Cyber-shot Digital Camera User manual

Sony EMCS Co.
DSC-S730 2007K0200-1
© 2007.11
Published by KohdaTEC9-852-239-11
Revision History
Revision History
Internal memory
ON BOARD
Internal memory
ON BOARD
SERVICE MANUAL
Link
Link
SERVICE NOTE
SPECIFICATIONS
BLOCK DIAGRAM
DISASSEMBLY REPAIR PARTS LIST
Ver. 1.0 2007.11
DIGITAL STILL CAMERA
US Model
Canadian Model
AEP Model
UK Model
E Model
Australian Model
Hong Kong Model
Chinese Model
Korea Model
Tourist Model
The components identified by
mark or dotted line with
mark are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
DSC-S730
In case of the lens block assy, main board, or main frame assembly failure,
contact your local Sony Service Headquarter for the measures.

DSC-S730
— 2 —
SPECIFICATIONS
Design and specifications are subject to change
without notice.
[LCD screen]
LCD panel: 6.0 cm (2.4 type) TFT drive
Total number of dots: 112 320 (480×234) dots
[Power, general]
Power: LR6 (size AA) Alkaline batteries (2), 3 V
HR15/51:HR6 (size AA) Nickel-Metal
Hydride batteries (2) (not supplied), 2.4 V
ZR6 (size AA) Oxy Nickel Primary Battery
(2) (not supplied), 3 V
AC-LS5K AC Adaptor (not supplied), 4.2 V
Power consumption (during shooting): 1.2 W
Operating temperature: 0 to 40 C (32 to 104 F)
F)
Storage temperature: –20 to +60 C (–4 to +140
Dimensions: 91.4×61.0×29.1 mm (3 5/8×2 1/2×
1 3/16 inches) (W/H/D, excluding
protrusions)
Mass: Approx. 189 g (6.7 oz) (including two
batteries and strap, etc.)
Microphone: Monaural
Buzzer
Exif Print: Compatible
PRINT Image Matching III: Compatible
PictBridge: Compatible
[System]
Image device: 7.20 mm (1/2.5 type) color CCD,
Primary color filter
Total pixel number of camera:
Approx. 7 410 000 pixels
Effective pixel number of camera:
Approx. 7 201 000 pixels
Lens: 3×zoom lens f = 5.8 – 17.4 mm (35 –
105 mm when converted to a 35 mm still
camera) F2.8 (W) – 4.8 (T)
Exposure control: Automatic exposure, Scene
Selection (7 modes)
White balance: Automatic, Daylight, Cloudy,
Fluorescent, Incandescent, Flash
File format (DCF compliant):
Still images: Exif Ver. 2.21 JPEG compliant,
DPOF compatible
Movies: AVI (Motion JPEG)
Recording media: Internal Memory (approx.
22 MB), "Memory Stick Duo"
Flash: Flash range (ISO sensitivity
(Recommended Exposure Index) set to Auto):
approx. 0.5 to 3.5 m (1 feet 7 3/4 inches to 11
feet 5 7/8 inches) (W)/approx. 0.5 to 2.0 m (1
feet 7 3/4 inches to 6 feet 6 3/4 inches) (T)
[Input and Output connectors]
(USB) A/V OUT terminal:
Video, Audio (Monaural), USB
communication
USB communication:
Hi-Speed USB (USB 2.0 compliant)

— 3 —
DSC-S730
SAFETY-RELATED COMPONENT WARNING!!
COMPONENTS IDENTIFIED BY MARK OR DOTTED LINE WITH
MARK ON THE SCHEMATIC DIAGRAMS AND IN THE PARTS
LIST ARE CRITICAL TO SAFE OPERATION. REPLACE THESE
COMPONENTS WITH SONY PARTS WHOSE PART NUMBERS
APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS
PUBLISHED BY SONY.
ATTENTION AU COMPOSANT AYANT RAPPORT
À LA SÉCURITÉ!
LES COMPOSANTS IDENTIFÉS PAR UNE MARQUE SUR LES
DIAGRAMMES SCHÉMATIQUES ET LA LISTE DES PIÈCES SONT
CRITIQUES POUR LA SÉCURITÉ DE FONCTIONNEMENT. NE
REMPLACER CES COMPOSANTS QUE PAR DES PIÈSES SONY
DONT LES NUMÉROS SONT DONNÉS DANS CE MANUEL OU
DANS LES SUPPÉMENTS PUBLIÉS PAR SONY.
1. Check the area of your repair for unsoldered or poorly-soldered
connections. Check the entire board surface for solder splashes
and bridges.
2. Check the interboard wiring to ensure that no wires are
"pinched" or contact high-wattage resistors.
3. Look for unauthorized replacement parts, particularly
transistors, that were installed during a previous repair. Point
them out to the customer and recommend their replacement.
4. Look for parts which, through functioning, show obvious signs
of deterioration. Point them out to the customer and
recommend their replacement.
5. Check the B+ voltage to see it is at the values specified.
6. FLEXIBLE Circuit Board Repairing
Keep the temperature of the soldering iron around 270 C
during repairing.
Do not touch the soldering iron on the same conductor of the
circuit board (within 3 times).
Be careful not to apply force on the conductor when soldering
or unsoldering.
Unleaded solder
Boards requiring use of unleaded solder are printed with the lead-
free mark (LF) indicating the solder contains no lead.
(Caution: Some printed circuit boards may not come printed with
the lead free mark due to their particular size.)
: LEAD FREE MARK
Unleaded solder has the following characteristics.
Unleaded solder melts at a temperature about 40 C higher than
ordinary solder.
Ordinary soldering irons can be used but the iron tip has to be
applied to the solder joint for a slightly longer time.
Soldering irons using a temperature regulator should be set to
about 350 C.
Caution: The printed pattern (copper foil) may peel away if the
heated tip is applied for too long, so be careful!
Strong viscosity
Unleaded solder is more viscous (sticky, less prone to flow) than
ordinary solder so use caution not to let solder bridges occur such
as on IC pins, etc.
Usable with ordinary solder
It is best to use only unleaded solder but unleaded solder may
also be added to ordinary solder.
SAFETY CHECK-OUT
After correcting the original service problem, perform the following
safety checks before releasing the set to the customer.
CAUTION
Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type.

— 4 —
DSC-S730
TABLE OF CONTENTS
1. SERVICE NOTE
1-1. Process After Fixing Flash Error·····································1-1
1-2. Method for Copying or Erasing the Data in Internal
Memory ···········································································1-1
2. DISASSEMBLY
2-1. Disassembly·····································································2-1
3. BLOCK DIAGRAM
3-1. Overall Block Diagram ···················································3-1
4. REPAIR PARTS LIST
4-1. Exploded Views ·······························································4-1
4-1-1. Overall Section ······························································4-1
4-1-2. Main Frame Block ·························································4-2
4-2. Accessories ······································································4-3
Section Title Page

1-1
DSC-S730
The data can be copied/erased by the operations on the Setup screen. (When erasing the data, execute formatting the internal memory.)
Note: When replacing the camera, erase the data in internal memory of the board before replacement.
Method for Copying the Data in Internal Memory
Method for Formatting the Internal Memory
1. SERVICE NOTE
1-1. PROCESS AFTER FIXING FLASH ERROR
Method for Initializing the Flash Error
1-2. METHOD FOR COPYING OR ERASING THE DATA IN INTERNAL MEMORY
Initializes the setting to the default setting.
Even if you execute this function, the images stored in the internal memory are retained.
1Select [OK] with von the control button, then press z.
The message "Initialize all settings Ready?" appears.
2Select [OK] with v, then press z.
The settings are reset to the default setting.
To cancel initializing
Select [Cancel] in step 1or 2, then press z.
Be sure not to power off the camera while initializing.
Initialize
Copies all images in the internal memory to a "Memory Stick Duo".
1Insert a "Memory Stick Duo" having sufficient free capacity.
2Select [OK] with von the control button, then press z.
The message "All data in internal memory will be copied Ready?" appears.
3Select [OK] with v, then press z.
Copying starts.
To cancel copying
Select [Cancel] in step 2or 3, then press z.
Use batteries with enough power remaining. If you attempt to copy image files using batteries with little
remaining charge, the batteries may run out, causing copying to fail or possibly corrupting the data.
You cannot select images to copy.
The original images in the internal memory are retained even after copying. To delete the contents of the
internal memory, remove the "Memory Stick Duo" after copying, then format the internal memory
([Format] in [Internal Memory Tool]).
A new folder is created on the "Memory Stick Duo" and all the data will be copied to it. You cannot
choose a specific folder and copy images to it.
The (Print order) marks on the images are not copied.
Copy
This item does not appear when a "Memory Stick Duo" is inserted in the camera.
Formats the internal memory.
Note that formatting permanently erases all data in the internal memory, including even protected images.
1Select [OK] with von the control button, then press z.
The message "All data in internal memory will be erased Ready?" appears.
2Select [OK] with v, then press z.
The format is complete.
To cancel formatting
Select [Cancel] in step 1or 2, then press z.
Format

2-1
DSC-S730
5
1
2
3
4
1 Open the BT LID
4
5
CABINET (REAR) ASSY
2 SCREW M 1.7 X 2.7
3 SCREW TP 1.7 X 4
SCREW TP 1.7 X 3.5
1
2
3
4
1
LCD
2
LCD PLATE
3
SCREWTP 1.4 X 3.5
4
SCREW TP 1.4 X 4
3
1
2
1
CABINET (FRONT) ASS
Y
2 SCREW TP 1.4 X 2.5
3
SCREW TP 1.4 X 3
1
2
3
1 BT LID SHAFT
(To 2-2 Page)
2 BT LID
3 BT LID SPRING
Note :
When CABINET(FRONT) ASSY is
removed, the plate will bends if
CABINET(FRONT) ASSY is inclined
too much.
Please remove CABINET (FRONT)
ASSY as in parallel as possible.
plate
2-1. DISASSEMBLY
2. DISASSEMBLY
The following flow chart shows the disassembly procedure.

DSC-S730 2-2
Shorting jig
(1k
Ω / 1W)
Caution
Note :
After discharged, a transparent
seal is put again.
Do not lose the transparent seal
removed when discharged.
3
1
2
1 STRAP SHAFT
(From 2-1 Page)
2
RL BLOCK
3
SCREW TP 1.4 X 3
1
3
1
ST BLOCK ASSY
2
SCREW TP 1.7 X 3.5
3
SCREW TP 1.7 X 6.5
1
2
3
1
SUPPORT (JACK)
2
MAIN MOUNT
3
SCREW TP 1.4 X 2.5
4
SCREW TP 1.7 X 3.5
4
1
2
3
5
4
1 JACK LID
2
MAIN FRAME
3 LENS BLOCK ASSY
4 LID
5
SCREW TP 1.4 X 3
2

3-1
DSC-S730
3-1. OVERALL BLOCK DIAGRAM
3. BLOCK DIAGRAM
PXCLK
HD
VD
CDS_EN
SCLK
SDATA
AFERST
TG_EN
VSUB_Con1
VSUB_Con2
CCD_ON
TG_ON
CDS_ON
CCD[0..11]
LEN S_P S
SHUTTE R_M1
SHUTTER_M0
FOCUS_PI
ZOOM_PR
ZOOM_PI
LENS_SDATA
LENS_SCLK
LENS_EN
LCD_HD
LCD_VD
LCD_EN
LCD_MCLK
LCD_SCLK
LCD_SDATA
LCD[0..7]
MLCD_ON
BL
USB_DE T
AV_DET
VI
DEO_OUT
LINE _O UT
BEEPER
D+
D-
FA23
FA20
FA22
FA21
MD[0..7]
WE
WP
R/B
ALE
CE0
RE
MS_CLK
CLE
MS_INS#
STA_LED
SW_TELE
SW_WIDE
SW_KEY_ADC
PWR_CTRL
CCD_ON
FLASH_RDY
FLASH_CHG_L
STROBE_TRG
STROBE_CHG
RAMCAS
RAMRAS
RAMLDQS
RAMUDQS
RAMUDM
RAMC LK_N
RAMCLK
RAMCLK_EN
RAMCS_N
RAMWE_
N
RAMLDM
RAMD[0..15]
RAMA[0..14]
RAMREF
DGND
DGND
DGND
+5VM
+13.4V
+5VM
DGND
DGND
DGND
DGND
DGND
+3.3V
-7.5V
+13.4V
+3.1VD
+3.1V D
BAT_LOAD
PWRKEY
PWR_KEY
PWR_ON
VP
-7.5 V
+2.5VD
+3.3V
+3.1VD
+5VM
+1.8VD
FLASH_VP
+3.1VD
+2.5V D
DGND
+1.8V D
+3.1VD
+2.5VD
+3.3V
+3.3VS
VP
UGND
+3.1VD
DGND
+3.1VD
+5VM
+3.1VD
SW_PLAYBACK
FLASH_VP
STROBE_Trg
FLASH_RDY
STROBE_CHG
AF_LED
+13.4V
BEEPER
+3.1VD
STROBE_PWR
MS_ON
CCD_ON1
IN1
IN2
IN3
IN4
SW_KEY_ADC1
SHUT1
SHUT2
PW_LED
+3.1VD
DGND
DDR
DDR
DGND
+2.5VD
RAMD[0..15]
RAMA[0..14]
RAMLDM
RAMWE_N
RAMCAS
RAMRAS
RAMCS_N
RAMLDQS
RAMUDQS
RAMUDM
RAMCLK_N
RAMCLK
RAMCLK_EN
RAMREF
12
RED RED
CDS
CDS
+3.3V
CCD[0..11]
VD
CDS_EN
HD
SCLK
SDATA
AFERST
TG_EN
PXCLK
VSUB_Con1
VSUB_Con2
-7.5V
+13.4V
CCD_ON
DGND
TG_ON
CDS_ON
4 1
3 2
32.768 K Hz 32.768 K Hz
12
FLASH
FLASH
+5VM
DGND
FLASH_VP
+3.1VD STROBE_CHG
FLASH_RDY
FLASH_CHG_L
STROBE_TRG
AF_LED
STROBE _PWR
1
4
2
3
NC
S
P1
, P2
S
,
12
GREEN
GREEN
GREEN
1 2
ME MOR Y
MEM ORY
MD[0..7]
CLE
WE
WP
ALE
CE0
RE
R/B
MS_ C LK
FA23
FA20
MS_INS#
FA22
FA21
+3.1VD
MS_ON
DGND
3 1 4 2
56
SW
SW
+3.1VD
DGND
SW_KEY_ADC
STA_LED
SW_KEY_ADC1
POWER
POWER
CCD_ON
-7.5V
PWR_CTRL
+13.4V
+2.5VD
+1.8VD
+3.3V
+3.1VD
+5VM
VP
DGND
CCD_ON1
31 4 2
56
1 2
DSP
DSP
VSUB_Con1
AFERST
VSUB_Con2
CCD[
0..11]
PXCLK
SCLK
SDATA
CDS_EN
VD
TG_EN
HD
RAMD [0..15]
RAMREF
RAMA[0. .14]
RAMC LK_E N
RAMLDQS
RAMWE_N
RAMCS_N
RAMRAS
RAMCAS
RAMLDM
RAMUD M
LENS_EN
STROBE_CHG
SHUTTER_M 0
SHUTTER_M1
LENS _SC LK
LENS _SDATA
LENS _PS
USB_DET
D-
D+
PWR_C TRL
STROBE_TRG
PWR_ON
LCD[0..7]
LCD_HD
LCD_VD
LCD_SDATA
LCD _EN
LCD _SCLK
LCD_MCLK
LINE_O UT
VIDEO_OUT
FLASH_CHG_L
VP
DGND
+1.8VD
+3.1VD
+2.5VD
+3.3VS
ZOOM_P I
FOCUS_PI
ZOOM_PR
BL
STA_LED
BEEPER
BAT_LOAD
CE0
AV_DET
MS_ INS#
SW_TELE
SW_WIDE
ALE
CLE
WP
R/B
MD[0..7]
RE
MLCD_ON
WE
FA21
FA22
FA20
FA23
MS_CLK
PWRKEY
SW_KEY_ADC
CDS_ON
TG_ON
CCD_ON
FLASH_RD Y
+3.3V
SW_PLAYBACK
AF_LED
RAMUD QS
RAMC LK
RAMCLK_N
BEEPE R
MIC MIC_N
STROBE_PWR
MS_ON
CCD_ON1
IN1
IN2
IN3
IN4
SW_KEY_ADC1
PWR_KE Y
SHUT1
SHUT2
PW_LED
JACK
JAC K
D+
D-
+3.1VD
USB_D ET
DGND
A/V_DET
VIDEO_OUT
LINE_O UT
BEEPERUGND
12
LCD
LCD
+3.1VD
DGND
MLCD_ON
+5VM
LCD_EN
LCD_MCLK
LCD_VD
LCD_HD
LCD_SCLK
LCD _SDATA
LCD [0..7]
BL
13
2
31 4 2
5
6
LENS
LENS
LENS_PS
SHUTTER_M1
SHUTTER_M0
LENS_EN
LENS _SC LK
LENS _SDA TA
+5VM
+3.1VD
ZOOM_PI
FOCUS_PI
ZOOM_P R
DGND
IN1
IN2
IN3
IN4
12
TOP
TOP
PWR_KEY
SHUT1
SHUT2
PW_LED
+3.1VD
DGND
Power
4
Out
1
GND_3
3
GND_2
2
MIC1
SPM0204HD5
MIC1
SPM0204HD5
AUO LCD
2.36
INCH
PANEL
SELF TIMER LED
POWER LED
FLASH
CHARGER Q5
Q2
CAPACITOR
100UF 300V
FLASH TUBE
STROBE & TOP BOARD
MAIN BOARD
LENS BLOCK
MEMORY STICK
PC
ZOOM SENSOR
ZOOM MOTOR
FOCUS SENSOR
FOCUS MOTOR
IRIS MOTOR
SHUTTER MOTOR
BUZZER
MODE DIAL
FUNCTION KEY
MS LED
12MHZ
33.75MHZ
IRIS(METER)
LENS
LCD_BACKLIGHT
MC4_4.72X3.76_173
G2412-0039-00
-7.5V
VP
FLASH_VP
-7.5V
12
R131
100K
BATT+2
1
2
C187
R
7X_V
52
_
K
P00
01
12
F5 1A/24V
1
2
R
5X
_V6
1_KU1.
0
C186
R
5X
_V6
1_KU1.
0
12
F3 1.6A/32V
2
13
Q42
AO3415
BATT-2
1
2
C160
R
5
X_V
61
_K
U
1
.
0
2
13
Q29
AO3415
12
R163
100K
1
2
X_V
52
_
K
P00
01
C159
R
7X_V
52
_
K
P00
01

4-1
DSC-S730
4. REPAIR PARTS LIST
4-1. EXPLODED VIEWS
4-1-1. OVERALL SECTION
Ref. No. Part No. Description Ref. No. Part No. Description
1X-2188-411-1 CABINET (FRONT) ASSY
2X-2188-412-1 CABINET (REAR) ASSY
33-286-696-01 SHAFT, STRAP
43-286-697-01 BLOCK, RL
53-286-698-01 LCD
6A-1444-049-A ST BLOCK ASSY
73-286-700-01 SHAFT, BT LID
8 3-286-701-01 LID, BT
9 3-286-702-01 SPRING, BT LID
10 3-286-703-01 LID, JACK
11 3-287-023-11 SCREW M1.7 X 2.7
12 3-287-026-01 SCREW TP1.4 X 2.5
13 3-287-028-01 SCREW TP1.7 X 3.5
14 3-287-027-01 SCREW TP1.7 X 4
15 3-287-025-01 SCREW TP1.4 X 3
16 3-287-032-01 SCREW TP1.7 X 6.5
17 3-296-920-01 SCREW TP1.4 X 3.5
18 3-296-921-01 SCREW TP1.4 X 4
19 3-299-366-01 SCREW TP1.7 X 3.5
• Refer to cover for mark .
ns: not supplied
Note : The adjustment is not required after replacing the LCD
1
2
3
4
5
6
7
9
Main Frame Block
(See Page 4-2)
ns
11
17
12
18
13
14
15
8
16
10
19
15
(Note)

4-2
DSC-S730
Ref. No. Part No. Description
4-1-2. MAIN FRAME BLOCK
101 3-286-699-01 SUPPORT (JACK)
102 3-287-024-01 SCREW TP1.4 X 3
103 3-287-026-01 SCREW TP1.4 X 2.5
104 3-287-028-01 SCREW TP1.7 X 3.5
105 3-286-704-01 FRAME, MAIN
4. REPAIR PARTS LIST
ns: not supplied
101
105
102
102
103
104
104
Note 1 : In case of the lens block assy or main board failure,
contact your local Sony service Headquarter for
the measures.
Note 2 : When separate lens block assy and main board for
main frame replacement, assemble original lens block
assy and main board back after repaire.
(Note 2)
(Note 1)
ns
ns
(Note 1)
ns

4-3
DSC-S730
Checking supplied accessories.
A/V cable
3-196-980-01
Wrist strap
2-050-981-01
USB cable
3-196-981-01
LR6 (size AA) Alkaline Battery
(Note 1)
4-2. ACCESSORIES
4. REPAIR PARTS LIST
Note 1: This item is supplied with the unit as an accessory,
but is not prepared as a service part.
CD-ROM
(Cyber-shot application software/
"Cyber-shot Handbook"/
"Cyber-shot Step-up Guide")
 * 3-281-191-51 (POLISH)
 * 3-281-191-61 (CZECH)
 * 3-281-191-71 (HUNGARIAN)
 * 3-281-191-81 (SLOVAK)
 * 3-281-191-91 (SWEDISH)
 * 3-281-192-11 (FINNISH)
 * 3-281-192-21 (NORWEGIAN)
 * 3-281-192-31 (DANISH)
 * 3-281-192-41 (THAI)
 * 3-281-192-51 (MALAYSIAN)
 * 3-281-192-61 (TURKISH)
 * 3-281-192-71 (GREEK)
 * 3-281-192-81 (UKRAINIAN)
Instruction Manual
*3-281-189-01
Cyber-shot Handbook(PDF)
The CD-ROM supplied contains all of language version of
the Instruction Manual in pdf (Cyber-shot Handbook.pdf) for printing.
 3-281-198-11 (ENGLISH) (CND, AEP, UK, E, AUS, HK, JE)
 3-281-198-21 (FRENCH, ITALIAN) (CND, AEP)
 3-281-198-31 (SPANISH, PORTUGUESE) (AEP, E, JE)
 3-281-198-41 (GERMAN, DUTCH) (AEP)
 3-281-198-51 (TRADITIONAL CHINESE, SIMPLIFIED CHINESE) (E, HK, JE)
 3-281-198-61 (RUSSIAN, UKRAINIAN) (AEP)
 3-281-198-71 (ARABIC, PERSIAN) (E)
 3-281-198-81 (KOREAN) (KR, JE)
 3-281-198-91 (POLISH, CZECH) (AEP)
 3-281-199-11 (HUNGARIAN, SLOVAK) (AEP)
 3-281-199-21 (SWEDISH, FINNISH) (AEP)
 3-281-199-31 (NORWEGIAN, DANISH)(AEP)
 3-281-199-41 (THAI, MALAYSIAN) (E)
 3-281-199-51 (TURKISH, GREEK) (AEP)
 3-281-199-61 (ENGLISH, SPANISH) (US)
 3-281-199-71 (SIMPLIFIED CHINESE) (CH)
 * 3-281-190-11 (ENGLISH)
 * 3-281-190-21 (FRENCH)
 * 3-281-190-31 (ITALIAN)
 * 3-281-190-41 (SPANISH)
 * 3-281-190-51 (PORTUGUESE)
 * 3-281-190-61 (GERMAN)
 * 3-281-190-71 (DUTCH)
 * 3-281-190-81 (TRADITIONAL CHINESE)
 * 3-281-190-91 (SIMPLIFIED CHINESE)
 * 3-281-191-11 (RUSSIAN)
 * 3-281-191-21 (ARABIC)
 * 3-281-191-31 (PERSIAN)
 * 3-281-191-41 (KOREAN)
The printed matter is not supplied. If required,
please order it with the part number below.
NOTE:
Items marked “*” are not stocked since they are seldom required for routine service.
Some delay should be anticipated when ordering these items.
Abbreviation
AUS : Australian model
CH : Chinese model
CND : Canadian model
HK : Hong Kong model
JE : Tourist model
KR : Korea model

MANUFACTURER: KAMAYA ELECTRIC CO.,LTD.
TYPE: FCC16162AD
RATING: 1.6A
MANUFACTURER: KAMAYA ELECTRIC CO.,LTD.
TYPE: FCC10102AD
RATING: 1.0A
MAIN BOARD
【 Regarding Fuse 】
・
F5
F3
F5
F3
DSC-S730

DSC-S730
Revision History
Reverse
Ver.
1.0
Date
2007.11
History
Official Release
Contents
—
S.M. Rev.
issued
—
985223911.pdf
