Sony Ipela XI's XIS-10DC User manual

WIDE VIEW CAMERA
XIS-10DC
SERVICE MANUAL
1st Edition

XIS-10DC
!WARNING
This manual is intended for qualified service personnel only.
To reduce the risk of electric shock, fire or injury, do not perform any servicing other than that
contained in the operating instructions unless you are qualified to do so. Refer all servicing to
qualified service personnel.
!WARNUNG
Die Anleitung ist nur für qualifiziertes Fachpersonal bestimmt.
Alle Wartungsarbeiten dürfen nur von qualifiziertem Fachpersonal ausgeführt werden. Um die
Gefahr eines elektrischen Schlages, Feuergefahr und Verletzungen zu vermeiden, sind bei
Wartungsarbeiten strikt die Angaben in der Anleitung zu befolgen. Andere als die angegeben
Wartungsarbeiten dürfen nur von Personen ausgeführt werden, die eine spezielle Befähigung
dazu besitzen.
!AVERTISSEMENT
Ce manual est destiné uniquement aux personnes compétentes en charge de l’entretien. Afin
de réduire les risques de décharge électrique, d’incendie ou de blessure n’effectuer que les
réparations indiquées dans le mode d’emploi à moins d’être qualifié pour en effectuer d’autres.
Pour toute réparation faire appel à une personne compétente uniquement.
Für Kunden in Deutschland
Entsorgungshinweis: Bitte werfen Sie nur entladene
Batterien in die Sammelboxen beim Handel oder den
Kommunen. Entladen sind Batterien in der Regel dann,
wenn das Gerät abschaltet und signalisiert “Batterie
leer” oder nach längerer Gebrauchsdauer der Batterien
“nicht mehr einwandfrei funktioniert”. Um
sicherzugehen, kleben Sie die Batteriepole z.B. mit
einem Klebestreifen ab oder geben Sie die Batterien
einzeln in einen Plastikbeutel.
For the customers in the Netherlands
Voor de klanten in Nederland
Dit apparaat bevat een B2O5-Li batterij voor memory
back-up.
Raadpleeg uw leverancier indien de batterij toch
vervangen moet worden.
Hoe u de batterijen moet verwijderen, leest u in de tekst
van deze handleiding.
Gooi de batterij niet weg maar lever deze in als klein
chemisch afval (KCA).
Lever het apparaat aan het einde van
de levensduur in voor recycling, de
batterij zal dan op correcte wijze
verwerkt worden.
For safety, do not connect the connector for peripheral
device wiring that might have excessive voltage to the
following port(s).
: NETWORK port
Follow the instructions for the above port(s).

1 (E)
XIS-10DC
Table of Contents
Manual Structure
Purpose of this manual ........................................................................................ 5 (E)
Related manuals................................................................................................... 5 (E)
Trademarks .......................................................................................................... 6 (E)
Contents ............................................................................................................... 7 (E)
1. Service Overview
1-1. Main Parts Location .............................................................................. 1-1 (E)
1-2. Removing/Reattaching the Outer Parts ................................................. 1-1 (E)
1-2-1. Louver .................................................................................. 1-1 (E)
1-2-2. Lower Cover ......................................................................... 1-2 (E)
1-2-3. Clear Dome Assembly ......................................................... 1-3 (E)
1-3. Backup Battery Replacement ................................................................ 1-3 (E)
1-4. Precautions when Replacing the Parts of SNT-1 Board ....................... 1-4 (E)
1-5. Description of Internal Switch .............................................................. 1-5 (E)
1-6. Circuit Protection Parts (Fuse) .............................................................. 1-6 (E)
1-7. Signal Inputs and Outputs of Cables ..................................................... 1-6 (E)
1-8. Periodic Replacement Parts................................................................... 1-7 (E)
1-9. Replacing the Electrolytic Capacitor .................................................... 1-8 (E)
1-10. Note on Desiccant .................................................................................1-8 (E)
1-11. Unleaded Solder .................................................................................... 1-8 (E)
2. Replacement of Main Parts and Boards
2-1. Index ...................................................................................................... 2-1 (E)
2-2. Removing/Reattaching the PTZ Camera (SNC-RZ30NB) ................... 2-2 (E)
2-3. Removing/Reattaching the 360dCamera Module .................................2-4 (E)
2-4. Removing/Reattaching the Peltier Element .......................................... 2-5 (E)
2-5. Removing/Reattaching the Heaters ....................................................... 2-6 (E)
2-5-1. Upper Heater ........................................................................ 2-6 (E)
2-5-2. Lower Heater ........................................................................ 2-8 (E)
2-6. Removing/Reattaching the Fans ........................................................... 2-9 (E)
2-6-1. Fan (Exhaust) ....................................................................... 2-9 (E)
2-6-2. Fan (Aspiration) ................................................................. 2-10 (E)
2-6-3. Fan (Circulation) ................................................................ 2-11 (E)
2-6-4. Fan (Cooling) ..................................................................... 2-12 (E)
2-7. Removing/Reattaching the Packings................................................... 2-13 (E)
2-7-1. Packing (Exhaust) ..............................................................2-13 (E)
2-7-2. Packing (Dome) ................................................................. 2-14 (E)
2-7-3. Packing (Case) ...................................................................2-15 (E)

2 (E) XIS-10DC
2-8. Replacing the Desiccant ...................................................................... 2-16 (E)
2-9. Removing/Reattaching the Boards ...................................................... 2-17 (E)
2-9-1. PS-699 Board ..................................................................... 2-17 (E)
2-9-2. SNT-1 Board ...................................................................... 2-18 (E)
2-9-3. VISCA Board ..................................................................... 2-19 (E)
3. Circuit Description
3-1. SNT-1 Board ......................................................................................... 3-1 (E)
3-1-1. Digital Image Data Processing Circuit ................................. 3-1 (E)
3-1-2. Outline of SH CPU Operation ..............................................3-1 (E)
3-1-3. System ROM ........................................................................ 3-1 (E)
3-1-4. System Memory ................................................................... 3-1 (E)
3-1-5. RTC Circuit .......................................................................... 3-1 (E)
3-1-6. PC Card Control Block ........................................................ 3-1 (E)
3-1-7. Network Control Block ........................................................3-2 (E)
3-1-8. External RS-232C Communication Block ...........................3-2 (E)
3-1-9. DIP Switch Block ................................................................. 3-2 (E)
3-2. PS-699 Board ........................................................................................ 3-2 (E)
3-2-1. Power Block .........................................................................3-2 (E)
3-2-2. FAN/Heater/Peltier Element Control Block ........................ 3-2 (E)
4. Checking and Adjustment During Board Replacement
4-1. Preparation ............................................................................................ 4-1 (E)
4-1-1. Service Tool List ..................................................................4-1 (E)
4-1-2. Connection ........................................................................... 4-1 (E)
4-2. Cautions for Replacing the SNT-1 Board ............................................. 4-2 (E)
4-3. Operation Check.................................................................................... 4-2 (E)
4-3-1. Network Connection Procedure ........................................... 4-2 (E)
4-3-2. RTC Check ........................................................................... 4-4 (E)
4-3-3. PC Card Slot Check ............................................................. 4-4 (E)
4-4. Updating the Software........................................................................... 4-4 (E)
4-5. Resetting of Date/Time Data .................................................................4-6 (E)
5. Spare Parts
5-1. Notes on Repair Parts .................................................................................. 5-1
5-2. Exploded Views .......................................................................................... 5-2
5-3. Electrical Parts List ................................................................................... 5-11
5-4. Frame List ................................................................................................. 5-16
5-5. Supplied Accessories ................................................................................ 5-16

3 (E)
XIS-10DC
6. Semiconductor Pin Assignments
7. Block Diagram
Overall ......................................................................................................... 7-1
8. Schematic Diagrams
PS-699 ......................................................................................................... 8-2
SNT-1 .......................................................................................................... 8-3
Frame Wiring .............................................................................................. 8-8
9. Board Layouts
PS-699 ......................................................................................................... 9-2
SNT-1 .......................................................................................................... 9-4

5 (E)
XIS-10DC
Manual Structure
Purpose of this manual
This manual is the Service manual of the Wide View Camera XIS-10DC.
This manual is intended for use by trained system and service engineers, and
provides the information of maintenance and detailed service (parts replacement,
guideline for adjustment, schematic diagrams, board layouts, detailed parts list).
n
The PTZ camera (SNC-RZ30NB) of the unit is the equivalent of the Network
Camera SNC-RZ30N. Refer to the service manual of SNC-RZ30N if service for the
PTZ camera is required.
Related manuals
Besides this “Service manual”, the following manuals are available.
..
..
.Installation Manual (Supplied with the Unit.)
This manual is necessary for installation of this unit.
Part number: 3-869-355-1X
..
..
.“User’s Guide” PDF (Included in the CD-ROM Supplied with the Unit.)
This manual is necessary for application and operation (and installation) of this
unit.
Part number: 3-869-356-XX
..
..
.SNC-RZ30N/RZ30P Service Manual (Available on request)
This manual is necessary for servicing the PTZ camera (SNC-RZ30NB).
Part number: 9-955-377-0X
..
..
.“Semiconductor Pin Assignments” CD-ROM (Available on request)
This “Semiconductor Pin Assignments” CD-ROM allows you to search for
semiconductors used in this unit.
Semiconductors that cannot be searched for on this CD-ROM (Latest edition at the
time of issue of this manual.) are listed in the service manual for each unit. The
service manual contains a complete list of all semiconductors and their ID Nos.,
and thus should be used together with the CD-ROM.
Part number: 9-968-546-XX

6 (E)
XIS-10DC
Trademarks
Trademarks and registered trademarks used in this manual are as follows.
.Windows, Windows XP, and Windows NT are registered trademarks of Microsoft
Corporation in the United States and other countries.
.Memory Stick is a registered trademark of Sony Corporation.
.Compact Flash is a registered trademark of San Disk Corporation in the United
States and other countries.
.Ethernet is a registered trademark of Xerox Corporation in the United States and
other countries.
Other system names, product names, and company names appearing in this manual
are trademarks or registered trademarks of their respective holders.

7 (E)
XIS-10DC
Contents
This service manual is organized by the following sections.
Section 1 Service Overview
Explains the information that is required to service, (the locations of main part,
removal of cabinet, replacement of backup battery, and periodic replacement parts,
etc.).
Section 2 Replacement of Main Parts and Boards
Explains the replacement of mechanical parts and boards.
Section 3 Circuit Description
Explains the circuit operation of this unit.
Section 4 Check and Adjustment During Board Replacement
Explains the operation check and adjustment after service of this unit.
Section 5 Spare Parts
Describes the exploded views, the mechanical parts list, and the electrical parts list.
Section 6 Semiconductor Pin Assignments
This section contains information on semiconductors used for this unit.
It includes a complete list of the semiconductors and their ID Nos. for retrieving
information on “Semiconductor Pin Assignments” CD-ROM, which is available
separately.
Please refer to this section together with the “Semiconductor Pin Assignments” CD-
ROM.
Information on the semiconductors not contained in the latest CD-ROM at the time
of issue of this manual, if any, is given in this section as well.
Section 7 Block Diagram
Describes the overall block diagram of this unit.
Section 8 Schematic Diagrams
Describes the schematic diagrams of this unit.
Section 9 Board Layouts
Describes the board layouts of the circuit boards of this unit.

1-1 (E)
XIS-10DC
M3 x10
Set screw
(PSW5 x10)
Cap Cap Plate
Hole
Projection
Wire
Louver plate
Louver
SNT-1 board
PS-699 board
VISCA board
PTZ camera
360dcamera
module
Section 1
Service Overview
c
The screws and wires of the outer parts are made in
stainless steel to be adaptable for outdoor use.
If the parts have fallen or lost, use the parts that are
specified in the parts list.
1-1. Main Parts Location
1-2. Removing/Reattaching the Outer
Parts
1-2-1. Louver
Removal
1. Loosen the screw, and remove the cap in the direction
of the arrow.
n
When removing the cap, turn it clockwise (looking
from the bottom) in about 15d, and remove the three
projections of the louver plate from the three holes in
the cap.
2. Remove the set screw (PSW5 x10), and remove the
wire from the cap.

1-2 (E)
XIS-10DC
C5 x16
Set screw
(PSW5 x10)
Wire
Lower cover
Hexagon socket head screws
(M8 x16)
Louver plate
Louver
Wire
3. Remove the four hexagon socket head screws, and
remove the louver plate and the louver.
Installation
4. Reattach the louver in the reverse order of steps 1 to 3.
n
When attaching the louver, make sure to put the wire
through the holes.
1-2-2. Lower Cover
Removal
1. Loosen the four screws, and remove the lower cover.
2. Remove the set screw (PSW5 x10), and remove the
wire from the lower cover.
Installation
3. Reattach the lower cover in the reverse order of steps 1
and 2.

1-3 (E)
XIS-10DC
+_
SNT-1 board
Unsolder
Vanadium lithium rechargeable battery
1-2-3. Clear Dome Assembly
Removal
1. Remove the lower cover. (Refer to Section 1-2-2.)
2. Loosen the four screws, and remove the clear dome
assembly and the dome fix plate.
Installation
3. Reattach the clear dome assembly and the dome fix
plate, and tighten the four screws.
n
When attaching the clear dome assembly, align the
hole of the clear dome assembly to the positioning
boss of the lower cover.
4. Reattach the lower cover. (Refer to Section 1-2-2.)
P4 x12
Hole
Clear dome
assembly
Dome fix plate
Lower cover
Positioning
boss
1-3. Backup Battery Replacement
The vanadium lithium rechargeable battery is mounted on
the SNT-1 board of the unit for the backup.
Replace the rechargeable battery in the following proce-
dure as required.
c
When replacing the part, be sure to use the specified one
below.
Replacement with a part other than the specified part will
result in fire hazards and electric hazards.
Ref. No. Name Part No.
BT151 Vanadium-lithium !1-528-944-11
rechargeable battery (VL2330)
n
When replacing the battery, check that the battery orienta-
tion (+_) is correct.
Removal
1. Remove the louver. (Refer to Section 1-2-1.)
2. Remove the PS-699 board. (Refer to Section 2-9-1.)
3. Remove the SNT-1 board. (Refer to Section 2-9-2.)
4. Unsolder the vanadium-lithium rechargeable battery
from the SNT-1 board.

1-4 (E)
XIS-10DC
Installation
5. Solder a new vanadium-lithium rechargeable battery to
the SNT-1 board.
m
.Be sure that the soldering iron does not contact with
the battery directly.
.Perform soldering at a temperature under 350 dC
within 5 seconds. When applying the soldering iron
again, wait until the battery has cooled down to
room temperature.
6. Reassemble the unit in the reverse order of steps 1 to
3.
1-4. Precautions when Replacing the
Parts of SNT-1 Board
When RTC (IC152), backup battery (BT151) or diode
(D309) on the SNT-1 board is replaced, the calendar/clock
data stored in RTC (IC152) is erased.
When the data is erased, set the calendar/clock data again
referring to Section 4-5.
RTC (IC152)
The calendar/clock function in RTC (IC152) is operated by
a power supplied from the backup battery (BT151) even in
the state of a board (mount board).
When replacing RTC (IC152), be careful that the pattern of
pin 8 does not short with the patterns of pin 1 (+3.3 V) or
pin 4 (GND).
When a short occurs, the backup battery (BT151) is
wasted.
Backup battery (BT151)
Replace the backup battery correctly according to Section
1-3.

1-5 (E)
XIS-10DC
1-5. Description of Internal Switch
SNT-1 Board
Ref. No. Name Description Factory default setting
S151 System selector switch This switch switches the operation mode (normal Normal mode
mode or test mode) of this unit.
Normal mode:
Test mode:
S152 Reset switch This unit is restarted by pressing this switch. —
S153 System reset switch The system of this unit is returned to the factory —
settings by supplying the power while pressing
and holding this switch.
O N
1 2 3 4
O N
1 2 3 4
S151
S152
S153
DC B A
1
2
3
4
SNT-1 board (Side A)

1-6 (E)
XIS-10DC
DC +12.0 V
GND, or _
White
Black
Green (with yellow stripe)
1
2
1-6. Circuit Protection Parts (Fuse)
The PS-699 board of the unit equips the fuse as a circuit
protection part.
The fuse melts if overcurrent flows or the unit overheats
due to a unit problem.
When replacing the fuse, be sure to use the following
designated parts.
Correct the cause resulting in the melting of the fuse before
replacement.
w
Use Designated Parts
The fuse/IC link is an important part for ensuring safety.
Replacement with parts other than those designated will
result in fire hazards and electric hazards. Therefore be
sure to use only the designated parts.
PS-699 Board
Ref.No. Part No./Parts name
F1 !1-533-804-21
F2 On-chip fuse 2.5 A, 125 V
F101
F11 !1-576-212-21
F12 On-chip fuse 1.25 A, 125 V
F51 !1-576-328-11
F52 On-chip fuse 8.0 A, 125 V
F53
F54
DC +12.0 V
White
Black GND
, or _
1-7. Signal Inputs and Outputs of Cables
1Power cable
n
Connect the power cable to the power unit that satisfies the
following requirement specification.
Power voltage: DC 11.0 V to 13.8 V (at the rug terminal)
Ripple less than 50 mV p-p
Power current: 12 A or more (standard)
25 A or more (from starting to within 100
ms)
Cable color Signal name
White DC +12.0 V
Black GND or _
Former type
Cable color Signal name
White DC +12.0 V
Green (with yellow stripe) GND or _*
Black GND or _*
*: Be sure to connect together to _or GND of the power unit.

1-7 (E)
XIS-10DC
2Network port (RJ45 modular jack)
10BASE-T/100BASE-TX
n
Connect the UTP cable (CAT5) to the network port.
When connecting directly to the computer, use a cross
cable.
When connecting to the network such as HUB, use a
straight cable.
(External view)
Pin No. Signal name
1 TXD+
2 TXD_
3 RXD+
4 TXD_CT1
5 TXD_CT2
6 RXD_
7 RXD_CT1
8 RXD_CT2
18
1-8. Periodic Replacement Parts
It is necessary to periodically replace the following parts of
this unit.
For replacing these parts, refer to Section 2.
n
The replacement period shown in the following table is not
the guaranteed term of parts.
This replacement period is shown only as a guide for
continuous running according to the specification of this
unit.
In addition, the replacement period varies depending on the
environment and conditions of how the part has been used.
Part name Part No. replacement period
(as a guide)
PTZ camera A-1094-478-A 1 year
Fan (Exhaust) 1-787-339-11 8 years
Fan (Aspiration) 1-698-667-31 5 years
Fan (Circulation) 1-698-667-21 5 years
Fan (Cooling) 1-763-957-11 3 years
Peltier element 1-417-579-11 3 years
Upper heater 1-797-239-11 3 years
Lower heater 1-797-239-11 3 years
Packing (Exhaust) 3-868-928-01 If crack and split are
Packing (Dome) 3-868-929-01 caused during repair or
Packing (Case) 3-868-930-01 maintenance, replace it.

1-8 (E)
XIS-10DC
1-9. Replacing the Electrolytic Capacitor
The electrolytic capacitor used in this unit needs to be
replaced periodically.
When a service for repair or maintenance is provided, and
if the unit has been used for a long period of time, it is
recommended that the following electrolytic capacitor (or
assembled parts that include it) to be replaced once after
having consent from the customer. Refer to Section 5-3 for
the part number of the replacing part.
n
The length of the operating life varies depending on the
environment and conditions of how the part has been used.
Make note that the part is not guaranteed for the number of
years described below. It is served as a guide for replace-
ment.
Board name Ref. No. Average length of
operating life
PS-699 C11 5 years
C14 5 years
C51 5 years
C52 5 years
C53 5 years
C54 5 years
C101 5 years
C103 5 years
C113 5 years
C159 5 years
C160 5 years
SNT-1 C12 5 years
C305 5 years
C306 5 years
C307 5 years
1-10. Note on Desiccant
After servicing (repair/check), immediately before rein-
stalling the unit, be sure to replace the desiccant.
For replacing the desiccant, refer to Section 2-8.
Desiccant: 3-868-940-01
n
The desiccant is used to prevent dew condensation in the
clear dome.
1-11. Unleaded Solder
Boards requiring use of unleaded solder are printed with a
lead free mark (LF) indicating that the solder contains no
lead.
(Caution: Some printed circuit boards may not come
printed with the lead free mark due to their particular size.)
: LEAD FREE MARK
m
.Be sure to use the unleaded solder for the printed circuit
board printed with the lead free mark.
.The unleaded solder melts at a temperature about 40 dC
higher than the ordinary solder, therefore, it is recom-
mended to use the soldering iron having a temperature
regulator.
.An ordinary soldering iron can be used but the iron tip
needs to be applied to the solder joint for a slightly
longer time. The printed pattern (copper foil) may peel
off if the heated tip is applied for too long, so be careful.

XIS-10DC 2-1 (E)
2-1. Index
The parts and boards explained in this section are shown below.
Section 2
Replacement of Main Parts and Boards
6
2
!-
3
!;
9
0
8
8
5
1
!=
7
![
4
!]
!\
No. Part/board name Explained section
1PTZ camera (SNC-RZ30NB) 2-2
2360dcamera module 2-3
3Peltier element 2-4
4Upper heater 2-5-1
5Lower heater 2-5-2
6Fan (Exhaust) 2-6-1
7Fan (Aspiration) 2-6-2
8Fan (Circulation) 2-6-3
No. Part/board name Explained section
9Fan (Cooling) 2-6-4
0Packing (Exhaust) 2-7-1
!- Packing (Dome) 2-7-2
!= Packing (Case) 2-7-3
![ Desiccant 2-8
!] PS-699 board 2-9-1
!\ SNT-1 board 2-9-2
!; VISCA board 2-9-3

XIS-10DC
2-2 (E)
CN13CN14 CN2
*
CN14
Clamp
Clamp
CN18
CN3
PSW4 x10
PTZ camera
assembly
PS-699 board SNT-1 board
CN13 CN12
Upper case assembly
Lower case
assembly
CN17
CN16
PS-699 board
CN15
C5 x 20
C5 x 20
*: CN2/PS-699 board is mounted on the lower side (side B) of the unit
(Serial No. 10001 to 10005).
2-2. Removing/Reattaching the
PTZ Camera (SNC-RZ30NB)
Removal
1. Remove the louver. (Refer to Section 1-2-1.)
2. Loosen the four screws, and remove the
upper case assembly.
3. Disconnect the harness from the connectors
(CN12, CN13, and CN15 to CN17) on the
PS-699 board.
4. Remove the harness from the two clamps.
5. Disconnect the harness from the connectors
(CN2, CN14, and CN18) on the PS-699
board.
6. Disconnect the harness from the connectors
(CN3, CN13, and CN14) on the SNT-1
board.
7. Remove the four screws, and remove the PTZ
camera assembly.
